Gefen GTV-HDMI-1080PS User Manual

1080p Scaler

GTV-HDMI-1080PS

User Manual

www.gefentv.com

ASKING FOR ASSISTANCE

Technical Support:

Telephone [phone]
[phone]

Fax [phone]

Technical Support Hours:

8:00 AM to 5:00 PM Monday thru Friday.

Write To:

Gefen Inc.
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311

www.gefentv.com
[e-mail]

Notice

Gefen Inc. reserves the right to make changes in the hard ware, packaging and

any accompanying doc u men ta tion without prior written notice.

Gefen TV 1080p HDMI Scaler is a trademark of Gefen Inc.

© 2008 Gefen Inc., All Rights Reserved

All trademarks are the property of their respective companies

Rev X2

CONTENTS

1 Introduction
2 Operation Notes
3 Panel Descriptions
4 Features
5 Connecting And Operating The 1080p HDMI Scaler / Operating The

1080p HDMI Scaler
6 1080p HDMI Scaler Confi guration
11 Specifi cations
12 Warranty

INTRODUCTION

Congratulations on your purchase of the 1080p HDMI Scaler. Your complete
satisfaction is very important to us.

Gefen TV

Gefen TV is a unique product line catering to the growing needs for innovative
home theater solutions. We specialize in total integration for your home theater,
while also focusing on going above and beyond customer expectations to ensure
you get the most from your hardware. We invite you to explore our distinct
product line and hope you fi nd your solutions. Don’t see what you are looking for
here? Please call us so we can better assist you with your particular needs.

The Gefen TV 1080p HDMI Scaler

The Gefen TV 1080p HDMI Scaler allows you to upscale your standard defi nition
or high defi nition HDMI sources to resolutions up to 1080p. Anything from set-
top boxes, DVD players to the next generation of gaming consoles including the
Xbox 360 Elite and Playstation 3 can be plugged into the 1080p HDMI Scaler.

How It Works

The 1080p HDMI Scaler supports HDMI or DVI sources with digital audio as well
as HDMI or DVI Displays. You can input a DVI source with a separate digital
audio signal and the Gefen TV 1080p HDMI Scaler will embed the digital audio
into the HDMI output. Conversely, you can use an HDMI source with a DVI
display and the Gefen TV 1080p HDMI Scaler will extract the audio for the digital
audio out to be used on an external sound system and/or amplifi er

Easy to use on-screen menus accessible through the buttons on the unit or
the IR remote control (sold separately) allow for effortless setup and image
adjustment to accommodate different viewing modes and screen sizes.

1

OPERATION NOTES

READ THESE NOTES BEFORE INSTALLING OR

OPERATING THE 1080P HDMI SCALER

• The 1080p HDMI Scaler will cross convert between digital and analog audio
formats (please see note 1 on page 5 for additional information).

• Compatible with all HDMI and DVI* displays.

• HDMI/HDCP compliant

*When used with a DVI to HDMI adapter

2
