Gefen GTV-COMPSVID-2-HDMIS User Manual

Composite to

HDMI Scaler

GTV-COMPSVID-2-HDMIS

User Manual

gefentv.com

ASKING FOR ASSISTANCE

Technical Support:

Telephone [phone]
[phone]

Fax [phone]

Technical Support Hours:

8:00 AM to 5:00 PM Monday thru Friday PST.

Write To:

Gefen, LLC
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311

www.gefentv.com
[e-mail]

Notice

Gefen, LLC reserves the right to make changes in the hard ware, packaging, and

any accompanying doc u men ta tion without prior written notice.

Composite to HDMI Scaler is a trademark of Gefen, LLC

© 2012 Gefen, LLC. All rights reserved

All trademarks are the property of their respective companies.

Rev A1

CONTENTS

1 Introduction
2 Operation Notes
3 Features
4 Panel Layout
5 Panel Description
6 Connecting And Operating The Composite to HDMI Scaler
7 Confi guring The Composite to HDMI Scaler
12 Specifi cations
13 Warranty

INTRODUCTION

Congratulations on your purchase of the Composite to HDMI Scaler. Your
complete satisfaction is very important to us.

Gefen TV

Gefen TV is a unique product line catering to the growing needs for innovative
home theater solutions. We specialize in total integration for your home theater,
while also focusing on going above and beyond customer expectations to ensure
you get the most from your hardware. We invite you to explore our distinct
product line and hope you fi nd your solutions. Don’t see what you are looking for
here? Please call us so we can better assist you with your particular needs.

The Gefen TV Composite to HDMI Scaler

The new GefenTV Composite to HDMI Scaler takes either Composite Video
or S-Video as input and converts it to digital HDMI video, then scales it up to a
maximum output of 1080p resolution (or 1920x1200 when used with a computer
monitor).

How It Works

Simply plug in your Composite or S-Video video source to its input jack on the
rear of the Scaler. The Scaler will automatically detect the video frequency and
resolution of the source signal, then convert that picture to a digital HDMI video
signal. You will then choose the best output resolution and viewing format of the
picture on your HDTV via the on-screen menu system by using the buttons on
the front of the Scaler.

1

OPERATION NOTES

READ THESE NOTES BEFORE INSTALLING OR

OPERATING THE COMPOSITE TO HDMI SCALER

• The Composite to HDMI Scaler will cross convert between some digital
and audio formats. All audio outputs (HDMI, digital TOSLINK®, and analog
stereo mini-jack) will be active. The Composite & S-video to HDMI Scaler
will not, however, down-mix multi-channel audio formats to 2 channel analog
stereo. Please see the chart on page 6 for more information.

• To switch between Composite and S-Video inputs, press the “+” button

• Compatible with all HDMI and DVI* displays.

2

FEATURES

Features

• Inputs S-Video or Composite Video at 480i or 576i resolutions

• Outputs HDMI video at resolutions of up to 1080p

• Input resolution is automatically detected while the output resolution and
refresh rate can be selected via the on-screen display (OSD) menu system
and front panel push-buttons

• 48MB frame buffer for frame rate conversion

• Scales Composite Video and S-Video to HDMI with embedded audio

• Supports video output resolutions for computer equipment at up to
1920x1200

Package Includes

(1) Composite to HDMI Scaler
(1) 6 ft. 3 RCA Composite Cable (M-M)
(1) 5V DC Power Supply
(1) Quick-Start Guide
