Mini USB-2
Extender
EXT-USB-MINI2
USER’S MANUAL
www.gefen.com
ASKING FOR ASSISTANCE
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday PST
Write To:
Gefen LLC
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
support@gefen.com
Notice
Gefen LLC reserves the right to make changes in the hard ware, packaging and
any accompanying doc u men ta tion without prior written notice.
Mini USB-2 Extender is a trademark of Gefen LLC
© 2010 Gefen LLC, All Rights Reserved
All trademarks are the property of their respective owners
Rev A2
CONTENTS
1 Introduction
2 Operation Notes
3 Features
4 Sender Panel Layout
5 Sender Panel Descriptions
6 Receiver Panel Layout
7 Receiver Panel Descriptions
8 Connecting And Operating The Mini USB-2 Extender
9 Network Cable Wiring Diagram
10 Troubleshooting
12 Specifi cations
13 Warranty
INTRODUCTION
Congratulations on your purchase of the Mini USB-2 Extender. Your complete
satisfaction is very important to us.
Gefen
Gefen delivers innovative, progressive computer and electronics add-on solutions
that harness integration, extension, distribution and conversion technologies.
Gefen’s reliable, plug-and-play products supplement cross-platform computer
systems, professional audio/video environments and HDTV systems of all sizes
with hard-working solutions that are easy to implement and simple to operate.
The Gefen Mini USB-2 Extender
The Mini USB-2 Extender extends any USB device up to 150 feet from the
location of your computer, eliminating the 17.5 feet distance limitation of USB.
The Mini USB-2 sender and receiver units use one CAT-5 cable for extension.
It is optimized for applications where two devices, such as the keyboard and
mouse, must be operated remotely. The USB-2 Extender can even be used to
extend surveillance cameras for security purposes.
How It Works
The Mini USB-2 Extender sender unit is connected to the computer using the
supplied USB cable. The remote peripheral(s) are connected to the receiver unit.
A category-5 (CAT-5) cable is used to link the sender to the receiver.
1
OPERATION NOTES
READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE MINI USB-2 EXTENDER
• The Mini USB-2 Extender sender and receiver were designed to operate on
USB type computers. DO NOT attempt to use this equip ment with any other
type of device.
• Use the computer’s USB port when using a local keyboard that is not
extended with the Mini USB-2 Extender sender unit.
• Only dedicated Category 5 UTP type cable (CAT-5) is recommended for this
application (pin to pin). Filed termination should adhere to the TIA/EIA-568-B
Scheduling
• The length of cable used to connect the Mini USB-2 Extender sender unit to
the Mini USB-2 Extender receiver unit MUST NOT EXCEED 150 feet.
2
FEATURES
Features
• Extends any USB 1.1 device up to 150 feet (45 meters) using CAT-5 cable
• Requires no external power adapter
• Contains internal USB hub
• Provides support for any full-speed 12 Mb/s or low-speed 1.5Mb/s USB
device
• Use either PC or Mac with USB keyboard/mouse
Package Includes
(1) Mini USB-2 Extender Sender unit
(1) Mini USB-2 Extender Receiver unit
(1) User Manual
3
SENDER PANEL LAYOUT
Front Panel
1
Back Panel
2
4
SENDER PANEL DESCRIPTIONS
1 USB Type B Input
This connector will accept a USB Type B cable to connect to a USB host device
(i.e. Computer).
2 RJ-45 Link Connector
This connector will accept a CA T-5 UTP cable to link the sender and receiver
units together.
5
RECEIVER PANEL LAYOUT
Front Panel
1
Back Panel
2
6
RECEIVER PANEL DESCRIPTIONS
1 USB Type A Input
This connector will accept a USB Type A cable to connect to a USB peripheral
device (i.e. Keyboard & Mouse). Two USB peripherals can be connected at the
same time.
2 RJ-45 Link Connector
This connector will accept a CA T-5 UTP cable to link the sender and receiver
units together.
7
CONNECTING AND OPERATING THE MINI USB-2 EXTENDER
How to Connect the Mini USB-2 Extender
1. Connect the USB host device to the USB Type B port on the Mini USB-2
Extender Sender unit using a user supplied USB Type A-B cable.
2. Connect the sender and receiver units together using a CAT-5 UTP cable.
NOTE: Maximum distance of CAT-5 cable should not exceed 150 feet. If fi eld
terminating CAT-5 cabling, please adhere to the TIA/EIA-568-B scheduling.
Please see page 9 for more information.
3. Connect up to two USB peripherals to the USB Type A ports on the Mini
USB-2 Extender Receiver unit using user/device supplied USB cables.
How to Operate the Mini USB-2 Extender
No user confi guration or additional operations are necessary to operate the Mini
USB-2 Extender.
8
NETWORK CABLE WIRING DIAGRAM
Gefen has specifi cally engineered their products to work with the TIA/EIA-568-B
specifi cation. Please adhere to the table below when fi eld terminating cable for
use with Gefen products. Failure to do so may produce unexpected results and
reduced performance.
Pin Color
1 Orange / White
2 Orange
3 Green / White
4 Blue
5 Blue / White
6 Green
7 Brown / White
8 Brown
CAT-5, CAT-5e, and CAT-6 cabling comes in stranded and solid core types.
Gefen recommends using solid core cabling.
Each cable run must be one continuous run from one end to the other. No splices
or use of punch down blocks.
12345678
9
TROUBLESHOOTING
Symptoms/Cause Remedy
All LEDs on the Sender are off.
Cause:
The Sender unit is not receiving
power from the computer
Host LED on Sender is on;
Link LED on Sender is off.
Cause:
There is no connection
between the Sender and
Receiver units.
Link LED on Sender is on;
Host LED on Sender is on.
Link LED on Receiver is on;
Device LED on Receiver is off.
Cause:
a) The USB device is not connected to Receiver.
b) The USB device is malfunctioning.
c) The computer does not recognise the USB device.
d) The computer does not support USB hubs.
e) The extender is malfunctioning.
1. Ensure that the Sender unit is connected
to a USB port on the computer
2. Check that the computer is switched on
and that the OS is running (not in Sleep
mode).
1. Ensure that a Category 5 UTP cable with
straight-through conductors is connected
between the Sender and Receiver units.
2. Ensure that Category 5 cables and connectors are used throughout the entire link
between Sender and Receiver.
3. Check that Category 3 cable has not
been
substituted.
4. Check that the cable length between
Sender and
Receiver does not exceed 50 metres.
5. Connect a short Category 5 patch cord
between the Sender and Receiver units.
Recheck the
operation of the system.
1. Check that the USB device is securely
connected to the USB port on the Receiver
unit.
2. Disconnect the Sender unit from the
computer.
3. Connect the USB device directly to the
USB port on the computer.
4. If the device does not operate properly,
consult the user documentation for the
device.
5. If the device operates properly when
directly connected to the computer, connect
another full speed device (of a different
type) to the Receiver unit. Connect the
Sender unit to the computer.
6. If the second device does not operate,
the extender may be malfunctioning. Contact Gefen technical support for assistance.
7. If the second device does operate properly, the fi rst device may not be compatible
with the extender. Contact Gefen technical
support for assistance.
10
TROUBLESHOOTING
Symptom/Cause Remedies
All LEDs on both Sender and
Receiver are on but the device does
not operate correctly
Cause:
a) The USB device is
malfunctioning.
b) The computer does not recognise
the
USB device.
c) The extender is malfunctioning.
1. Disconnect the Sender unit from the
computer.
2. Connect the USB device directly to
the USB port on the computer.
3. If the device does not operate
properly,
consult the user documentation for the
device.
4. If the device operates properly when
directly connected to the computer,
connect another full speed device
(of a different type) to the Receiver
unit. Connect the Sender unit to the
computer.
5. If the second device does not operate,
the extender may be malfunctioning.
Contact Gefen technical support for
assistance.
6. If the second device does operate
properly, the fi rst device may not be
compatible with the extender. Contact
Gefen technical support for assistance.
11
SPECIFICATIONS
USB device support .............................. Full-Speed 12 Mbs / Low-Speed 1.5 Mbs
USB Input Connectors ................................................................................ Type B
USB Output Connectors .............................................................................. Type A
Link Connector .............................................................................. RJ-45 Shielded
Dimensions ....................................................................... 3.8” W x 1.2” H x 2.7” D
Shipping Weight ............................................................................................ 1 lbs.
12
13
*EXT-ma-USB-MINI2*
Rev A2
20600 Nordhoff St., Chatsworth CA 91311
1-800-545-6900 818-772-9100 fax: 818-772-9120
www.gefen.com support@gefen.com
