ASKING FOR ASSISTANCE
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen, LLC
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
support@gefen.com
Notice
Gefen, LLC reserves the right to make changes in the hard ware, packaging, and
any accompanying doc u men ta tion without prior written notice.
4x1 DisplayPort Switcher is a trademark of Gefen LLC
© 2011 Gefen, LLC. All rights reserved.
All trademarks are the property of their respective owners.
Rev A3
CONTENTS
1 Introduction
2 Operation Notes
3 Features
4 Front Panel Layout
5 Front Panel Descriptions
6 Back Panel Layout
7 Back Panel Descriptions
8 IR Remote Control Unit
8 Layout and Description
9 Installing the Battery
10 Confi guring the IR Remote Control Unit
11 Connecting the 4x1 DisplayPort Switcher
11 Wiring Diagram
12 Operating the 4x1 DisplayPort Switcher
12 Front Panel Buttons and LED Indicators
12 Switching sources using the front panel buttons
12 Switching sources using the IR Remote Control Unit
13 Switching sources using RS-232
13 Switching sources using Telnet
14 RS-232 Control
15 RS-232 Commands
15 IP Confi guration
20 General Commands
23 Routing and Extender Commands
24 Telnet Control
26 Specifi cations
27 Warranty
INTRODUCTION
Congratulations on your purchase of the 4x1 DisplayPort Switcher. Your complete
satisfaction is very important to us.
Gefen
Gefen delivers innovative and progressive computer and electronics
add-on solutions that harness integration, extension, distribution, and conversion
technologies. Gefen’s reliable plug-and-play products supplement cross-platform
computer systems, professional audio/video environments, and HDTV systems
of all sizes with hard-working solutions that are easy to install and simple to
operate.
The Gefen 4x1 DisplayPort Switcher
Easily switch between four computers using DisplayPort with the 4x1 DisplayPort
Switcher.
The rack-mountable 4x1 DisplayPort Switcher offers an economical solution for
switching between four different computers to one display location at the touch of
a button.
Eliminating the need to purchase many displays in a studio or professional environment, this versatile solution saves money, supports both Mac and PC-type
computers, and offers uncluttered and increased desktop space.
This Switcher can be controlled using front panel discrete switching, the included
IR Remote control, IP control, or the RS-232 port for switching automation.
The 4x1 DisplayPort Switcher is compatible with all operating systems using
DisplayPort.
How It Works
Connect the four included 6-foot DisplayPort cables between the computers and
the Switcher inputs. Connect the Switcher output to the monitor using a DisplayPort cable. Connect the included 5V DC locking power supply to the 4x1 Switcher
and connect the AC power cord to an available electrical outlet. The currently
selected source will be displayed.
1
OPERATION NOTES
READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE 4X1 DISPLAYPORT SWITCHER
• The 4x1 DisplayPort Switcher supports Pass-through EDID. The Switcher
will use the EDID from the currently connected monitor.
• Dual Link resolutions up to 2560 x 1600 are supported.
• HDCP content is not supported.
• This Switcher does not support DHCP.
• The default IR channel for both the Switcher and the IR Remote Control Unit
is channel 0. See page 10 for more information.
2
FEATURES
Features
• Switches a single Hi-Def display between four DisplayPort-equipped
sources.
• Supports HD resolutions up to 1080p Full HD
• Supports VESA resolutions up to 2560 x 1600
• Supports RGB and YCbCr color spaces
• RS-232 control
• Ethernet / Telenet Control
• IR remote control
• Jack for external IR Receiver
• Saves space on your desktop
• Rack-mountable
Package Includes
(1) 4x1 DisplayPort Switcher
(4) 6ft. DisplayPort Cables
(1) IR Remote Control Unit
(1) 5V DC Locking Power Supply
(1) Set of Rack Ears
(1) User Manual
3
FRONT PANEL LAYOUT
4
Front Panel
21 3
4
FRONT PANEL DESCRIPTIONS
1 Input Indicators (1 - 4)
Each of these LED indicators glows bright blue according to the input selection
(see Input Buttons, below)
2 IR
Receives IR signals from the included IR Remote Control Unit.
3 Input Buttons (1 - 4)
Pressing each of these buttons selects the desired input source (1-4).
4 Power
This LED indicator will glow bright red when the unit is powered.
5
BACK PANEL LAYOUT
6
54
3
Back Panel
2
1
6
BACK PANEL DESCRIPTIONS
1 5V DC
Connect the included 5V DC locking power supply to this receptacle.
2 DP In 1 - DP In 4
Each of these ports will accept a standard DisplayPort source device.
3 DP Out
This port will accept a single standard DisplayPort output device. The currently
selected DisplayPort input source will be output via this port.
4 Ext IR
Connect an IR extender cable to this port.
5 RS-232 Serial Port
This port is used for serial communication using an RS-232 control device. For
details, refer to page 14.
6 Ethernet
Connect the Switcher to a network in order to communicate via Telnet.
7
