INTRODUCTION

Congratulations on your purchase of the ex•tend•it DVI to VGA Conversion Box. Your
complete satisfaction is very important to us. Gefen’s line of KVM (Keyboard Video &
Mouse), DVI, ADC, USB, switches, extenders, converters and hubs is designed to make
computer use more comfortable, more productive and less expensive.

KVM switches allow access to multiple computers from a single keyboard, while the ex­tenders give the user control over a computer up to 330 feet away from the work area.

The ex•tend•it line offers solutions for noise, space and security concerns, data center
control, information distribution, conference room presentation, and school and corpo­rate training environments.

Our Committment
Gefen will always offer the fi nest quality product at the best possible price. Included in
that price is a lifetime of free support from a team of outstanding engineers.

Introduction
The ex•tend•it DVI to VGA Conversion Box connects analog CRT or LCD monitors to

DVI-D compliant video graphic cards. The DVI to VGA Conversion Box can be used in
conjuction with Gefen's DVI splitters to allow VGA only displays to be connected.

1

FEATURES

Features

• Connects computers with DVI-D connectors to analog SVGA monitors or projectors

• Maintains up to 1920 x 1200 x 60 resolution

• Supports DDWG standard for DVI compliant monitors

• Installs in seconds

• DVI cables are used to connect the computer to the DVI input

Includes:

6’ DVI cable (m-m)
5V Power Supply
DVI to VGA Conversion Box
User's Manual

2

PANEL DESCRIPTIONS

3

Connecting and Operating the DVI to VGA Conversion Box

How to Connect the DVI to VGA Conversion Box

1- Connect your analog monitor to the HD-15 female connector at the
output side of the DVI to VGA Conversion Box.

2- Connect the DVI (m-m) cable between the DVI connector on the graphic
card and the DVI input of the DVI to VGA Conversion Box.

3- Connect the power supply.

Notes: If you are connecting the DVI to VGA Conversion Box to a source that reads
EDID (most computers) the Box will report 1600x1200@60Hz. Gefen support can re­program the EDID to another resolution at request.

4

SPECIFICATIONS

DVI Bandwidth ..................................................................................................... 1.6 GHz

VGA Bandwidth .................................................................................................. 350 MHz

Input Video Signal ......................................................................................... 1.2 volts p-p

Input DDC Signal .................................................................................... 5 volts p-p (TTL)

Maximum Single Link Range ........................................................................ 1920 x 1200

DVI Connector Type ................................................................................................. DVI-I

VGA Connector Type ...............................................................................................HD-15

Power Consumption ............................................................................... 2.5 Watts (max.)

Power Supply .......................................................................................................... 5VDC

Dimensions ..................................................................................... 2.75”W x 1”H x 4.5”D

Shipping Weight ....................................................................................................... 5 Lbs

5
