Gefen DVIKVM-241SL User Manual

2x1 DVI KVM SL

Switcher

USER MANUAL

www.gefen.com

ASKING FOR ASSISTANCE

Technical Support:

Telephone [phone]
[phone]

Fax [phone]

Technical Support Hours:

8:00 AM to 5:00 PM Monday thru Friday.

Write To:

Gefen Inc.
c/o Customer Service
20600 Nordhoff Street
Chatsworth, CA 91311

www.gefen.com
[e-mail]

Gefen Inc. reserves the right to make changes in the hard ware, packaging and any

accompanying doc u men ta tion without prior written notice.

2x1 DVI SL Switcher is a trademark of Gefen Inc.

© 2007 Gefen Inc., All Rights Reserved

Notice

TABLE OF CONTENTS

Introduction

1

Features

2

Panel Descriptions

3

Connecting and Operating the SL Switcher

4

Operation Notes

5

RMT2-IR Installation

6

IR Code Confl icts / IR Extender Installation

7

Specifi cations

8

Warranty

9

INTRODUCTION

Congratulations on your purchase of the Gefen 2x1 DVI SL Switcher. Your complete
satisfaction is very important to us.

Gefen’s line of KVM (Keyboard Video & Mouse), DVI, USB, switches, extenders, con­verters and hubs is designed to make computer use more comfortable, more productive
and less expensive. KVM switches allow access to multiple computers from a single
keyboard, while the extenders give the user control over a computer up to 330 feet
away from the work area.

Gefen products offer solutions for noise, space and security concerns, data center con­trol, information distribution, conference room presentation, and school and corporate
training environments.

Our Commitment
Gefen will always offer the fi nest quality product at the best possible price. Included in

that price is a lifetime of free support from a team of outstanding engineers.
Now you can switch easily and reliably between any combination of two single link DVI

& USB 2.0 equipped computers (PC or Mac) - using only one keyboard, display and
mouse. The SL cross platform switcher saves space - there’s no need to work on a desk
crowded with double displays, keyboards and mouse devices. It saves time - there’s no
need to move from one monitor to another to access different computers. And, it saves
money - there’s no need to purchase additional displays, mouse devices, keyboards etc.

1
