DVI CAT-5
Extender
USER MANUAL
www.gefen.com
Page 2
ASKING FOR ASSISTANCE
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff Street
Chatsworth, CA 91311
www.gefen.com
support@gefen.com
Notice
Gefen Inc. reserves the right to make changes in the hard ware, packaging and any
accompanying doc u men ta tion without prior written notice.
The DVI CAT-5 Extender is a trademark of Gefen Inc.
© 2005-2007 Gefen Inc., All Rights Reserved
Page 3
TABLE OF CONTENTS
1
Introduction
2
DVI CAT-5 Extender Sender Front Panel Descriptions
3
DVI CAT-5 Extender Receiver Front Panel Descriptions
4
How To Connect The DVI CAT-5 Extender
5
Dip Switch Usage Guide
6
CAT5 Link Cable - Wiring Diagram
7
Mounting Plate Installation
8
Specifi cations
9
Warranty
Page 4
OPERATION NOTES
READ THESE NOTES BEFORE IN STALL ING
OR OPERATING THE DVI CAT-5 EXTENDER
• The DVI CAT-5 Extender is housed in a metal box for better RF shielding.
• Your CAT-5 cable should not exceed 150 feet.
• If you don't need DDC data you can use a single CAT-5 cable for the video only. The
DDC will not be connected. An additional 5 VDC power supply will be needed for the
receiver side.
• If the source requires EDID present, you can use the Gefen DVI Detective to provide
EDID information. This will also provide an additional 5v power supply for the receiver
side.
* CAT6 cable is suitable for high resolutions at 50 meters.
Page 5
INTRODUCTION
The DVI CAT-5 Extender sender unit sits next to your computer, DVD player or any settop box with a DVI output. The cable supplied with the DVI CA T-5 Extender connects your
DVI source to the send unit. The DVI CAT-5 Extender receiver unit sits next to your DVI
display - up to 150 feet away. The display plugs into the back of the DVI CAT-5 Extender
receiver unit. Two CAT-5 cables connect the DVI CAT-5 Extender-S and the DVI CAT-5
Extender-R units to each other.
CONTENTS
The DVI CAT-5 Extender system consists of:
the DVI CAT-5 Extender-S
the DVI CAT-5 Extender-R
One DVI to DVI 6 foot M-M
Two DVI CAT5 Extender Wallmounts
One 5 volt power supply
1
Page 6
DVI CAT-5 EXTENDER SENDER FRONT PANEL DESCRIPTIONS
Connects to 5 volt
power supply
DVI input connects to
DVI source
CAT-5 carries
TMDS signals
CAT-5 carries
DDC/HDCP signals
2
Page 7
DVI CAT-5 EXTENDER RECEIVER FRONT PANEL DESCRIPTIONS
Connects to DVI display
Connects to 5 volt
power supply
CAT-5 carries
DDC/HDCP signals
3
CAT-5 carries
TMDS signals
Page 8
HOW TO CONNECT THE DVI CAT-5 EXTENDER
Connect your display to the DVI Extender receiver unit.
1
Connect your source to the DVI Extender sender unit
2
Connect your CAT-5 cables between the sender and the receiver
3
Plug the 5V power supply into the DVI CAT-5 Extender sender unit
4
You should now have picture. If you do not see a picture, try unplugging and re-
5
plugging the DVI input on the DVI Extender sender unit. Make sure your CAT-5
cables are not crossed. Recycle the power on the unit.
* If problems persist try adjusting the Dip Switches by following the Dip Switch
Usage Guide.
4
Page 9
DIP SWITCH USAGE GUIDE
Gefen CAT5 Extenders (sender and receiver) both contain a pair of dip switches
located on the board. These dip switches are used to select from a set of
confi gurations that will equalize the signal to best match the conditions in your setup.
How to open the DVI CAT5 Extender:
1. Unscrew the four screws underneath the unit.
2. Unscrew the 2 hex nuts beside the DVI connector.
3. Slide the top plate off the base to expose the circuit board.
4. The dip switches are located directly on the circuit board.
Sender Dip Switches
Option No. Switch 1 Position Switch 2 Position Description
1 0 (OFF) 0 (OFF) Medium Boost
(Default)
2 1 (ON) 0 (OFF) Strong Boost
Receiver Dip Switches
Option No. Switch 1 Position Switch 2 Position Description
1 0 (OFF) 0 (OFF) EQ 0
(Default)
2 1 (ON) 0 (OFF) EQ 1
3 0 (OFF) 1 (ON) EQ 2
4 1 (ON) 1 (ON) EQ 3
Adjustment Guidelines:
1) Higher EQ level is used to equalize poor/low quality CAT-5e cables
2) Stronger boost is used to drive signals through longer cables
3) It is an optimal balance of Boost and EQ that will result in the best possible
picture.
5
Page 10
CAT5 LINK CABLE - WIRING DIAGRAM
8
1
1
2
RJ-45 Jack
Orange
White/Orange
White/Green
3
4
Blue
5
6
7
Green
White/Blue
White/Brown
8
Brown
1
2
3
RJ-45 Jack
4
5
6
6
7
8
8
1
Page 11
MOUNTING PLATE INSTALLATION
7
Page 12
SPECIFICATIONS
Video Amplifi er Bandwidth ................................................................................. 1.65 GHz
Vertical Frequency Range .................................................................................. 50-60 Hz
Single Link Range ......................................................................................... 1920 x 1200
Input Video Signal...........................................................................................1.2 volts p-p
Input DDC Signal............................................................................................... 5 volts p-p
DVI Input Connector Type ....................................................................................... DVI-D
DVI Output Connector Type .................................................................................... DVI-D
Power Consumption ................................................................................ 15 Watts (max.)
Dimensions ................................................................................ 3.4”W x 3.25”H x 1.25”D
Shipping Weight ....................................................................................................... 3 Lbs
8
Page 13
WARRANTY
Gefen Inc. warrants the equipment it manufactures to be free from defects in material
and workmanship.
If equipment fails because of such defects and Gefen Inc. is notifi ed within one (1)
year from the date of shipment, Gefen System will, at its option, repair or replace the
equipment, provided that the equipment has not been subjected to mechanical, electrical
or other abuse or modifi cations.
Equipment that fails under conditions other than those covered will be repaired at the
current price of parts and labor in effect at the time of repair. Such repairs are warranted
for ninety (90) days from the day of shipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including without
limitation, any implied warranty or merchantability or fi tness for any particular purpose, all
of which are expressly disclaimed.
The information in this manual has been carefully checked and is believed to be accurate.
However, Gefen Inc. assumes no responsibility for any inaccuracies that may be contained
in this manual. In no event will Gefen Inc., be liable for direct, indirect, special, incidental,
or consequential damages resulting from any defect or omission in this manual, even if
advised of the possibility of such damages. The technical information contained herein
regarding the DVI CA T -5 Extender features and specifi cations is subject to change without
notice.
9
