Gefen DVI-441DLS User Manual

4x1 DVI DL

Switcher

with Serial Option

USER MANUAL

www.gefen.com

ASKING FOR ASSISTANCE

Technical Support:

Telephone [phone]
[phone]

Fax [phone]

Technical Support Hours:

8:00 AM to 5:00 PM Monday through Friday.

Write To:

Gefen Inc.
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311

www.gefen.com
[e-mail]

Gefen Inc. reserves the right to make changes in the hard ware, packaging and any

accompanying doc u men ta tion without prior written notice.

4x1 DVI DL Switcher is a trademark of Gefen Inc.

© 2007 Gefen Inc., All Rights Reserved

Notice

TABLE OF CONTENTS

Introduction

1

Features

2

Panel Descriptions

3

Connecting and Operating the 4x1 DVI DL Switcher

4

RMT4-IR Installation

5

Dip Switch Guide

6

Operation Notes & Troubleshooting

7

RS-232 Interface

8

Specifi cations

9

10

Warranty

INTRODUCTION

Congratulations on your purchase of the 4x1 DVI DL Switcher. Your complete satisfac­tion is very important to us.

Gefen’s line of KVM (Keyboard Video & Mouse), DVI, ADC, USB, switches, extenders,
converters and hubs is designed to make computer use more comfortable, more pro­ductive and less expensive. KVM switches allow access to multiple computers from a
single keyboard, while the extenders give the user control over a computer up to 330
feet away from the work area. The ex•tend•it line offers solutions for noise, space and
security concerns, data center control, information distribution, conference room presen­tation, and school and corporate training environments.

Our Commitment
Gefen will always offer the fi nest quality product at the best possible price. Included in

that price is a lifetime of free support from a team of outstanding engineers.
Now you can switch easily and reliably between any combination of four dual link DVI

& USB 2.0 equipped computers (PC or Mac) - using only one keyboard, display and
mouse. The DL cross platform switcher saves space - there’s no need to work on a desk
crowded with double displays, keyboards and mouse devices. It saves time - there’s no
need to move from one monitor to another to access different computers. And, it saves
money - there’s no need to purchase additional displays, mouse devices, keyboards etc.

1
