Gefen DVI-2-HDSDISSL, DVI to HD-SDI Single Link Scaler User Manual
DVI to HD-SDI
Single Link
Scaler
USER MANUAL
www.gefen.com
ASKING FOR ASSISTANCE
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday through Friday.
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
support@gefen.com
Notice
Gefen Inc. reserves the right to make changes in the hard ware, packaging and any
accompanying doc u men ta tion without prior written notice.
The DVI to HD-SDI Single Link Scaler is a trademark of Gefen Inc.
© 2007 Gefen Inc., All Rights Reserved
© 2005 Gefen Inc., All Rights Reserved
1
Introduction
2
Operation Notes
3
Panel Descriptions
4
Menu Functions
6
Supported Input/Output Resolutions
7
RMT-8HDS-IR Installation
8
Firmware Update Procedure
9
Specifi cations
10
Warranty
TABLE OF CONTENTS
INTRODUCTION
Gefen's DVI to HD-SDI Single Link Scaler is the newest revision of our HD-SDI
conversion line incorporating full single link DVI-D conversion scaled up to SD/HD-SDI
single resolutions. Resolutions of up to 1080p are supported over the HDSDI link for
those that want true “High Defi nition”. Performance has been greatly enhanced due to
Gennum’s VXP Scaler onboard; allowing for new features such as: Color & Gamma
Correction, Noise Reduction, Detail Enhancement, Aspect Ratio Selection, Pattern
Generator Mode, & Multiple Language Menu Support. Bottom Line? -- More
performance, less cost.
HOW IT WORKS
DVI devices are connected to the DVI input and SDI devices are connected to the SDI
output. When the source, display and the Scaler are powered and connected, video
signals are converted to the proper format.
CONTENTS
The DVI to HD-SDI Scaler SL package consists of:
(1) DVI to HD-SDI SL Scaler
(1) 6 foot DVI Cable (M-M)
(1) RMT-8HDS-IR Remote Control
(1) 5V DC Power Supply
(1) User's Manual
1
