INTRODUCTION
Congratulations on your purchase of the ex•tend•it DVI Super Booster. Your complete satisfaction is
very important to us. Gefen’s line of KVM (Keyboard Video & Mouse), DVI, ADC, USB, switches,
extenders, converters and hubs is designed to make computer use more comfortable, more produc-
tive and less expensive. KVM switches allow access to multiple computers from a single keyboard,
while the extenders give the user control over a computer up to 330 feet away from the work area.
The ex•tend•it line offers solutions for noise, space and security concerns, data center control, infor-
mation distribution, conference room presentation, and school and corporate training environments.
Our Commitment
Gefen will always offer the finest quality product at the best possible price. Included in that price is a
lifetime of free support from a team of outstanding engineers.
Introduction
The ex•tend•it DVI Super Booster extends the length of any DVI cable by regenerating the DVI sig-
nal before it outputs to the DVI monitor or projector. The DVI Super Booster will clean out the digital
noise (sparkles) in your picture. The ex•tend•it DVI Super Booster is connected with a DVI (male to
male) cable from the computer DVI graphic port to the DVI Super Booster input. The DVI Super
Booster output uses a second DVI (male to male) cable to go from the output to any DVI display or
projector with a DVI connector. The box is placed near the display to remove any noise that has
been generated by a long DVI cable.
