1x4 AUDIO DA
USER MANUAL
www.gefen.com
ASKING FOR ASSISTANCE
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday through Friday PST
Write To:
Gefen Inc.
C/O Customer Service
20600 Nordhoff St.
Chatsworth, CA 91311
www.gefen.com
support@gefen.com
Notice
Gefen Inc. reserves the right to make changes in the hard ware, packaging and any
accompanying doc u men ta tion without prior written notice.
The 1x4 Audio DA is a trademark of Gefen Inc.
Macintosh is a trademark of Apple Computer Inc.
© 2007 Gefen Inc., All Rights Reserved
TABLE OF CONTENTS
Introduction
1
Box Contents
2
How it works
3
Operation Notes
4
1x4 Audio DA Front Panel Layout
5
1x4 Audio DA Back Panel Functions
6
Link Cable - Wiring Diagram
7
System Specifi cations
8
Warranty
9
INTRODUCTION
Thank you for purchasing the new ex•tend•it 1x4 Audio DA series.
The ex•tend•it 1x4 Audio Distribution DA allows 8 audio locations from the same audio
source. The 1x4 Audio Distribution DA also extends the distributed audio to 4 locations up
to a 1000 feet away with CAT5.
1
BOX CONTENTS
The 1x4 Audio DA system consists of:
(1) 1x4 Audio DA
(1) 5 VDC power supply
(1) Audio cable (6 FT)
(1) User Manual
2
HOW IT WORKS
1X4 Audio DA
The ex•tend•it 1x4 Audio Distribution unit sits next to your audio source. Stereo cables
supplied with the 1x4 Audio Distribution package connects your audio source to the
1x4 Audio Distribution sender. The Audio Extender receiver unit connects to your
speakers or audio output device. One CAT-5 cable per channel connects the 1x4 Audio
Distribution unit and the Audio Extender receive unit to each of the distributed locations
- up to 1000 feet away.
1X4 Audio DA
3
OPERATION NOTES
READ THESE NOTES BEFORE IN STALL ING
OR OPERATING THE 1X4 AUDIO DA SYSTEM
* Industry standard Category-5 (CAT-5) cables are used to link the 1x4 Audio DA and
receiver boxes together.
* The 1x4 Audio DA units are housed in a metal box for better RF shielding.
4
1x4 AUDIO DA FRONT PANEL LAY OUT
1
Front Panel Function Descriptions
1
2
3
+5V - Connects to 5VDC power supply
AUDIO IN - Indicates that the unit is plugged in and powered on
POWER ON INDICATOR - Indicates that the unit is plugged in and powered on
2 3
5
1x4 AUDIO DA BACK PANEL FUNCTIONS
3
1
2
3
POWER - 5 VDC external power supply
AUDIO - Audio mini Jack input from source
Audio Out - RJ-45 connector connects to Audio Extender Receiver units.
6
LINK CABLE - WIRING DIAGRAM
8
1
1
2
RJ-45 Jack
Orange
White/Orange
White/Green
3
4
Blue
5
6
7
Green
White/Blue
White/Brown
8
Brown
1
2
RJ-45 Jack
3
4
5
6
7
7
8
8
1
SPECIFICATIONS
Sample Rate .......................................................................... 5 kHz (min) - 48 kHz (max)
Frequency Response .................................................................................. 20hz - 20khz
Interfaces ...................... 1 x audio - line-out/headphones - mini-phone stereo 3.5 mm - 1
Dimensions ........................................................................................ 1”H x 4”W x 3.75”D
Weight ....................................................................................................................... 3 lbs
8
WARRANTY
Gefen Inc. warrants the equipment it manufactures to be free from defects in material
and workmanship.
If equipment fails because of such defects and Gefen Inc. is notifi ed within two
(2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace
the equipment, provided that the equipment has not been subjected to mechanical,
electrical, or other abuse or modifi cations.
Equipment that fails under conditions other than those covered will be repaired at the
current price of parts and labor in effect at the time of repair. Such repairs are warranted
for ninety (90) days from the day of reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including without
limitation, any implied warranty or merchantability or fi tness for any particular purpose,
all of which are expressly disclaimed.
1. Proof of sale may be required in order to claim warranty.
2. Customers outside the US are responsible for shipping charges to and from Gefen.
3. Copper cables are limited to a 30 day warranty and cable must be free from any
scratches, markings, and neatly coiled.
The information in this manual has been carefully checked and is believed to be
accurate. However, Gefen Inc. assumes no responsibility for any inaccuracies that may
be contained in this manual. In no event will Gefen Inc., be liable for direct, indirect,
special, incidental, or consequential damages resulting from any defect or omission
in this manual, even if advised of the possibility of such damages. The technical
information contained herein regarding 1x4 Audio DA features and specifi cations is
subject to change without notice.
9
