Congratulations
on your purchase of the ex
•tend•it ADC Splitter.
Your complete satisfaction is very important to us.
Gefen’s line of KVM (Keyboard Video & Mouse), ADC, DVI, USB, switches,
extenders, converters and splitters is designed to make computer use more
comfortable, more productive and less expensive.
KVM switches allow access to multiple computers from a single keyboard,
while the extenders give the user control over a computer up to 330 feet
away from the work area.
The ex
•tend•it line offers solutions for noise, space and security concerns,
data center control, information distribution, conference room presentation,
and school and corporate training environments.
Our Commitment
Gefen will always offer the finest quality product at the best possible
price. Included in that price is a lifetime of free support from a team of outstanding engineers.
Introduction
The ex
•tend•
it ADC Splitter allows Apple computers with ADC graphics
cards to be connected to 2 ADC flat panel displays. This product is
expandable allowing two ADC Splitters to stack on top of each other so
you can get additional ADC outputs from the same ADC source. The
ADC Splitter keeps your desk clutter-free, relocating your computer to a
safe and secure area, while allowing you to work in a quieter environment.
The ADC Splitter lets you keep one ADC display next to your computer,
while adding a second extended ADC display at an extended location.
Warranty
Gefen Inc. warrants the equipment it manufactures to be free from defects
in material and workmanship. If equipment fails because of such defects
and Gefen Inc. is notified within one (1) year from the date of shipment,
Gefen Inc. will, at its option, repair or replace the equipment, provided
that the equipment has not been subjected to mechanical, electrical, or
other abuse or modifications. Equipment that fails under conditions other
than those covered will be repaired at the current price of parts and
labor in effect at the time of the repair. Such repairs are warranted for
ninety (90) days from the day of re-shipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied,
including without limitation, any implied warranty or merchantability or
fitness for any particular purpose, all of which are expressly disclaimed.
The information in this manual has been carefully checked and is
believed to be accurate. However, Gefen Inc. assumes no responsibility for
any inaccuracies that may be contained in this manual. In no event will
Gefen Inc. be liable for direct, indirect, special incidental, or consequential
damages resulting from any defect or omission in this manual, even if
advised of the possibility of such damages. The technical information
contained herein regarding the ADC Splitter features and specifications is
subject to change without notice.
All Rights Reserved © Copyright 2003 Gefen Inc.
20600 Nordhoff Street, Chatsworth CA 91311
voice: 818 772-9100 fax: 818 772-9120
email:support@gefen.com website: http://www.gefen.com
User Manual
ex•tend•it products
10
theADC Splitter
ADC Distribution Amplifier
ex
•
tend
•
it
repeaters
Repeaters
ADC Repeater
DVI Repeater
Firewire Repeater
extenders
ADC•100
DVI•100
USB•100
USB•200
USB•400
USB•500
CAT5•1000
CAT5•2000
CAT5•3000
CAT5•4000 Matrix
CAT5•5000
CAT5•6000
CAT5•7000
CAT5•8000
hubs
Firewire Hub
DVI Hub
USB Hub
ADC Splitter
VGA Splitter
VDX•600
switchers
DVI Switch
ADC Switcher
CAT5•4000 Matrix
2x1 DVI Switcher
4x1 DVI Switcher
2x2 DVI Switcher
4x1 VGA Switcher
USB Switcher
mini PC/Mac
PC/Mac 2000
convertors
DVI to ADC Adaptor
VGA to ADC Adaptor
DVI to VGA Adaptor
VGA to DVI Adaptor
Adapters
ADC to DVI Adapter
ADC to VGA Adapter
DVI to VGA Adapter
DVImate
DVI Detective
Cables
Fiber Optic Cables
USB Cables
CAT-5 Cables
DVI Cables
Firewire Cables
PS/2 Cables
VGA Cables
4
How to Connect the
ADC Splitter to your Displays
11--
Connect the supplied ADC cable from the graphics card into the ADC
Splitter input.
22--
Connect the cable from your first display into the ADC Out 1 of the
ADC Splitter.
33--
Connect the cable from your second display into the ADC Out 2 of the
ADC Splitter.
44--
Restart your computer only after you’ve made all the connections.
*All the monitors connected to the ADC Splitter must be able to run at the same
native resolution
3
5
6
Wiring Diagram
• Connects Apple computers with
ADC graphics cards to two
ADC flat panel displays
• Can be configured as an ADC
Switcher with multiple outputs
• Allows up to 4 ADC display to
be connected to one ADC
source
• RMT-16 remote control allow
configuration change
• Maintains highest ADC single
link video resolution 1920x1200
• Simultaneous display at local
and remote locations
• ADC cables are used to connect
the ADC input and the
computers output
• Installs in seconds
7
8
Technical Support:
phone:
818-772-9100
fax: 818-772-9120
email: support@gefen.com
web: www.gefen.com
Technical Support Hours:
8:00 am – 5:00 pm PST
Monday -– Friday
Write to:
Gefen, Inc.
c/o Customer Service
20600 Nordhoff St
Chatsworth
CA 91311
USA
Asking for Assistance
Trademarks:
Macintosh is a trademark of Apple Computer Inc.
ex
•tend•it is a trademark of Gefen Inc.
The ADC Splitter is a trademark of Gefen Inc.
© Copyright 2003 Gefen Inc. All Rights Reserved
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
front view
back view
Features
Specifications:
ADC Amplifier Bandwidth:
1.65 GHz
Actual Bandwidth: 1.6 GHz
Input Video Signal: 1.2 volts p-p
Input DDC Signal: 5 volts p-p (TTL)
ADC Connector: JAE 39 pin female
Power Consumption: 208 Watts (max.)
Power Supply: External 24-28 VDC
(optional)
Dimensions: 5”W x 1”H x 4.5”D
Shipping Weight: 3 lbs.
Technical Specifications
Includes:
6’ADC cable (m-m)
the ADC Splitter
Users Manual
