USER MANUAL
20600 Nordhoff St, Chatsworth CA 91311
818-772-9100
-800-545-6900
1
Keyboard
Mouse
Trackball
Touchscreen
ASKING FOR ASSISTANCE
Technical Support:
Telephone (818)
(800) 545-6900
x (818)
Fa
Technical Support Hours:
8:00
W
Ge
AM to 5:00 PM Monday thru Friday.
rite To:
fen Systems
c/o Customer Service
772-9100
772-9120
20600 Nordhoff Street
Chatsworth, CA 91311 USA
Notice
Gefen Systems reserves the right to make changes in the
hardware, packaging and any accompanying documentation
without prior written notice.
ADB100 is a trademark of Gefen Systems
Macintosh is a trade
mark of Apple
, Inc.
© 1995 Gefen Systems, All Rights Reserved
TABLE OF CONTENTS
General Information
Introduction ........................................................ 1
Operation Notes................................................... 2
ADB100 Panel Layout ........................................... 3
ADB100 Function Description ................................ 4
Warranty............................................................. 9
Installation Wiring Diagrams
1 Keyboard Extended............................................ 5
2 Keyboards Local/ Extended................................. 6
2 Keyboard Extended............................................ 7
TSE100 Link Cable ............................................... 8
INTRODUCTION
Thank you for purchasing Gefen Systems'
ADB100 Series. The ADB100 extends your computer
ADB port (keyboard, mouse, trackball, and touch
screen) device up to 1000 feet away from the
location of your Macintosh computer.
The ADB100 system consists of two units, the
ADB100 Sender mode which resides next to the
computer side and the ADB100 Receiver mode, which
resides next to the extended keyboard.
The ADB signal controls the keyboard, mouse,
trackball and other ADB devices such as a touch
screen. The ADB100 buffers the ADB signal through
send and receive line drivers, and the signal is
extended by using standard telephone cable.
You can connect additional ADB100 Series to the
same computer, allowing you to access the computer
from other locations up to 1000 feet apart.
1
OPERATION NOTES
READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE ADB100 SYSTEM.
1. WARNING!: The ADB100 were designed to operate on
Macintosh computers. Do not attempt to use this equipment
with any other type computers.
2. WARNING!: When using a local keyboard not extended
with the ADB100 Sender unit, use the Gefen modified ADB
cable. Modified cable is connected between the ADB100
sender and the local keyboard or mouse.
3. WARNING!: When plugging in a ADB100 Sender unit
ONLY, without the ADB100 receiver unit, the keyboard and
mouse will freeze. The ADB100 Receiver unit must be
connected, and powered up, and the link cable installed
between both units, in order to operate property.
4. Link Cable: Refer to the wiring diagram on page 10 for
wiring instructions.
2
ADB100 PANELS LAYOUT
ADB
ON
GEFEN SYSTEMS
WOODLAND HILLS, CA 91367
MADE IN U.S.A.
SENDER
RECEIVER
3 5
1
P
OWERLINK
2
4
3
FUNCTION DESCRIPTION
ADB
1
Mini din sub connector which connects to the computer
ADB port. (For keyboard, Mouse and Trackball).
2
Power On Light
Power on status indicates that the unit is plugged in.
3
Send/Receiver Switch
Push button switch for setting ADB100 as a Sender or
Receiver unit.
4
Link
RJ-11 Modular Jack which connects to the TSE100R
(Receiver Unit).
5
Power
9 Volt A/C 1A external power supply.
4
1 KEYBOARD EXTENDED - WIRING DIAGRAM
Set switch to IN to receive
Use Power supply at this end
5
Set switch to OUT to send
No power supply is required at this end
2 KEYBOARDS LOCAL/EXTENDED - WIRING DIAGRAM
Set switch to IN to receive
Use Power supply at this end
6
Set switch to OUT to send
No power supply is required at this end
2 KEYBOARDS EXTENDED - WIRING DIAGRAM
7
ADB100 LINK CABLE - WIRING DIAGRAM
8
WARRANTY
Gefen Systems warrants the equipment it manufactures to be free
from defects in material and workmanship.
If equipment fails because of such defects and Gefen Systems is
notified within one (1) year from the date of shipment, Gefen System
will, at its option, repair or replace the equipment, provided that the
equipment has not been subjected to mechanical, electrical, or other
abuse or modifications.
Equipment that fails under conditions other than those covered will
be repaired at the current price of parts and labor in effect at the of
repair. Such repairs are warranted for ninety (90) days from the day of
reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied,
including without limitation, any implied warranty or merchantability or
fitness for any particular purpose, all of which are expressly
disclaimed.
The information in this manual has been carefully checked and is
believed to be accurate. However, Gefen Systems assumes no
responsibility for any inaccuracies that may be contained in this
manual. In no event will Gefen Systems, be liable for direct, indirect,
special, incidental, or consequential damages resulting from any defect
or omission in this manual, even if advised of the possibility of such
damages. The technical information contained herein regarding
ADB100 features and specifications is subject to change without
notice.
All Rights Reserved © Copyright 1995 Gefen Systems
9
