RSTI-EP Slice I/O
Module Status
LED
Channel Status
LEDs
GE provides RSTi-EP analog output modules with up to 4 analog outputs at +/-10 V,
GFK-2961A Analog Output Modules EP-4164, EP-4264
December 2015
+/-5 V, 0-10 V, 0-5 V, 2-10 V, 1-5 V, 0-20 mA or 4-20 mA. The resolution is 16 bit per
channel. An output can be connected to each connector, the internal switching is
carried out automatically. The output range is defined using parameterization. A
status LED is assigned to each channel. The outputs are supplied with power from
the output current path (I
The EP-4264 module provides individual channel diagnosis with channel related
error messages.
Each module features a type plate, which includes identification information, the
key technical specifications, and a block diagram. In addition, a QR code allows for
direct online access to the associated documentation. The software for reading the
QR code must support inverted QR codes.
Markers are available as accessories for labelling equipment. Each I/O module can
be labelled using the markers to ensure clear identification when replacing
individual modules or electronic units.
The RSTi-EP station is usually installed on a horizontally positioned DIN rail.
Installation on vertically positioned DIN rails is also possible.
The outputs as well as the sense-lines of the AO modules must not be used as
power outputs.
OUT
).
Analog Output Module
Modules should to be allowed to de-energize for a minimum 10 seconds after
power down, prior to starting any maintenance activity.
Refer to the RSTi-EP Slice I/O User Manual (GFK-2958) for additional information.
Refer to the RSTi-EP Power Supply Reference Guide, a software utility available on
PME V9.00, for detailed power-feed requirements.
Module Features
Control up to four analog outputs
Module diagnosis
Spring style technology for ease of wiring
DIN rail mounted
Double-click installation for positive indication of correct installation
Supports indirect firmware update through the network monitor
Supports hot insertion and extraction
© 2015 General Electric Company. All Rights Reserved.
*
Indicates a trademark of General Electric Company and/or its subsidiaries. All other trademarks are the property of their respective
owners.
2 RSTi-EP Slice I/O Analog Output Module
EP-4164
EP-4264
System Data
Data
Process, parameter, and diagnostic data depend on the network adapter used.
Interface
RSTi-EP system bus
System bus transfer rate
48 Mbps
Channel/channel = no
Outputs
Number
4
1. Voltage (0 – 5 V, ±5 V, 0 – 10 V, ±10 V, 1 – 5 V, 2 – 10 V)
2. Current (0 – 20 mA, 4 – 20 mA)
Response time
1 ms for 4 channels
Resolution
16 bits
Accuracy
0.1 % FSR max., 0.05 % FSR typ.
Temperature coefficient
20 ppm voltage / 31 ppm current measurement / K
Monotony
Yes
Crosstalk between the channels
±0.001 % FSR max.
Repeat accuracy
< ±1 mV eff.
Output ripple
max. 0.001 %
total sensor current of 10 mA per channel but 25 mA per module)
Current load resistance
≤ 600 Ω including field cable resistance
Actuator connection
2-wire (current and voltage; automatic detection), 4-wire (voltage)
Short-circuit-proof
Yes
Module diagnosis
Yes
Individual channel diagnosis
No
Yes
Substitute value
Yes
module
Supply
Supply voltage
20.4V – 28.8V
system current path I
SYS
output current path I
OUT
GFK-2961A
Ordering Information
Module Description
EP-4164 Analog Output, 4 Channels Voltage/Current 16 Bits 2, 3, or 4-Wire
EP-4264 Analog Output, 4 Channels Voltage/Current 16 Bits with Diagnostics 2, 3, or 4-Wire
Specifications
Potential isolation
Output levels
Max. error between T
Voltage load resistance
min
and T
max
Channel/system bus = yes
≥ 1 kΩ (at > 50°C (122 °F) max ambient temperature,
±220 ppm FSR
Can be used with EP-19xx
Current consumption from
Current consumption from
Yes
8 mA
85 mA
RSTi-EP Slice I/O Analog Output Module 3
EP-4164
EP-4264
General data
Operating temperature
-20°C to +60°C (-4 °F to +140 °F)
Storage temperature
-40°C to +85°C (-40 °F to +185 °F)
(operation/transport)
11.5 mm (0.45 in)
76 mm (2.99 in)
Height
120 mm (4.72 in)
Weight
83 g (2.93 oz)
98 g (3.47 oz)
Product
I
IIN
I
IS
IL
EP-4164
8 mA
--
85 mA
--
--
EP-4264
8 mA
--
85 mA
--
--
I
x
Current consumption from the system current path
Must be included when calculating the power supply
LED
EP-4164
EP-4264
Red: Module System Fault or Diagnostic Fault
Red: Module System Fault or Diagnostic Fault
resistance too high or line break detected
resistance too high or line break detected
1.2
--
1.3
--
1.4
--
Red: Channel 1 at voltage output: overload
resistance too high or line break detected
2.2
--
--
2.3
--
--
2.4
--
--
Red: Channel 2 at voltage output: overload
resistance too high or line break detected
Red: Channel 2 at voltage output: overload
resistance too high or line break detected
3.2
--
--
3.3
--
--
3.4
--
--
Red: Channel 3 at voltage output: overload
resistance too high or line break detected
Red: Channel 3 at voltage output: overload
resistance too high or line break detected
4.2
--
--
4.3
--
--
4.4
--
--
GFK-2961A
Air humidity
Width
Depth
I
I
I
I
LEDs
Module
Status
Current Demand for Analog Output Modules
SYS
SYS
Power consumption from input current path
IN
Power consumption from output current path
OUT
Current demand of the connected sensors
S
Current demand of the connected actuators
L
Green: Communication over the system bus
Red: Channel 0 at voltage output: overload
1.1
short-circuit, at current output: shunt
5% to 95%, noncondensing as per IEC 61131-2
OUT
Green: Communication over the system bus
Red: Channel 0 at voltage output: overload
short-circuit, at current output: shunt
short-circuit, at current output: shunt
2.1
resistance too high or line break detected
short-circuit, at current output: shunt
3.1
short-circuit, at current output: shunt
4.1
--
--
--
Red: Channel 1 at voltage output: overload
short-circuit, at current output: shunt
short-circuit, at current output: shunt
short-circuit, at current output: shunt
For public disclosure
4 RSTi-EP Slice I/O Analog Output Module
GFK-2961A
Field Wiring
The connection frame can take up to four connectors, and four wires can be connected to each connector. Those four
connectors are shown in the following figure. The Spring style technology allows either finely stranded or solid wire
conductors with crimped wire-end ferrules or ultrasonically welded wires, each with a maximum cross-section of 1.5
mm² (16 guage), to be inserted easily through the opening in the clamping terminal without having to use tools. To
insert fine stranded wires without wire-end ferrules, the pusher must be pressed in with a screwdriver and released to
latch the wire.
Connector Block
Connector Specifications:
• conductor cross-section 0.14 to 1.5 mm² (26 – 16 guage)
• max. ampacity: 10 A
• 4-pole
The modules do not have a fused sensor/activator power supply. All cables to the connected sensors/actuators must be
fused corresponding to their conductor cross-sections (as per Standard DIN EN 60204-1, section 12).
Refer to the RSTi-EP Slice I/O User Manual (GFK-2958) for additional information.
For technical assistance, go to http://support.ge-ip.com.
Installation in Haza r dous Areas
EQUIPMENT LABELED WITH REFERENCE TO CLASS I, GROUPS A, B, C & D, DIV. 2 HAZARDOUS AREAS IS SUITABLE FOR USE IN
CLASS I, DIVISION 2, GROUPS A, B, C, D OR NON-HAZARDOUS AREAS ONLY
WARNING - EXPLOSION HAZARD - SUBSTITUTION OF COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS I, DIVISION 2;
WARNING - EXPLOSION HAZARD - WHEN IN HAZARDOUS AREAS, TURN OFF POWER BEFORE REPLACING OR WIRING
MODULES; AND
WARNING - EXPLOSION HAZARD - DO NOT CONNECT OR DISCONNECT EQUIPMENT UNLESS POWER HAS BEEN
SWITCHED OFF OR THE AREA IS KNOWN TO BE NONHAZARDOUS.
ATEX Marking
II 3 G Ex nA IIC T4 Gc
Ta: -20°C to +60°C (-4° F to +140 °F)
RSTi-EP Slice I/O Analog Output Module 5
GFK-2961A
Connection Diagrams
EP-4164 EP-4264
For public disclosure
6 RSTi-EP Slice I/O Analog Output Module
EP-4164
EP-4264
GFK-2961A
Connection Block Diagrams
EP-4164
Release History
Catalog Number
Firmware
Version
EP-4264
Date Comments
EP-4164, EP-4264 01.01 Dec-2015 Documentation update only
EP-4164, EP-4264 01.01 Nov-2015 Initial Release
RSTi-EP Slice I/O Analog Output Module 7
1-800-433-2682
GFK-2961A
Important Product Information for this Release
Updates
None – Documentation update only
Funcional Compatibility
N/A
Problems Resolved by this Release
None – Documentation update only
New Features and Enhancements
None – Documentation update only
Known Restrictions and Open Is sues
None
Operational Notes
None
Product Documentation
RSTi-EP Slice I/O Module User Manual (GFK-2958)
RSTi-EP Slice I/O Functional Safety Module User Manual (GFK-2956)
1-434-978-5100
