GE Consumer & Industrial TLE Series 160, TLE Series 225, TLE Series 200, TLE Series 500, TLE Series 400 Installation Manual
...
Critical Power
Installation Guide
Uninterruptible Power Supply
GE Consumer & Industrial SA
General Electric Company
CH – 6595 Riazzino (Locarno)
Switzerland
T +41 (0)91 / 850 51 51
F +41 (0)91 / 850 52 52
www.gecriticalpower.com
imagination at work
TLES_UL_160-500_S2b_UPS_GE_01
TLE Series 160/200/225/ 250
TLE Series 300/350/400/500
Critical Power
Modifications reserved
Page 2/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Model:
TLE Series 160 - 200 - 225 – 250 – 300 – 400 - 500 UL S2B
Issued by:
Product Document Department – Riazzino - CH
Approved by:
R & D Department – Riazzino - CH
Date of issue:
04/23/2018
File name:
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010
Revision:
1.0
Identification No.:
8600180579P
Up-dating
Revision Concern Date
COPYRIGHT © 2018 by GE Consumer & Industrial SA
All rights reserved.
The information contained in this publication is intended solely for the purposes indicated.
The present publication and any other documentation supplied with the UPS system is not to be
reproduced, either in part or in its entirety, without the prior written consent of GE.
The illustrations and plans describing the equipment are intended as general reference only and are not
necessarily complete in every detail.
The content of this publication may be subject to modification without prior notice.
Critical Power
Modifications reserved
Page 3/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Dear Customer,
We thank you for selecting our products and are
pleased to count you amongst our very valued
customers at GE.
We trust that the use of the TLE Series 160 - 500
Uninterruptible Power Supply S
ystem, developed and
produced to the highest standards of quality
, will give
you complete satisfaction.
Please read carefully the Installation Guide
, which
contains all the necessary information and describes all
you need to know about the installation of the UPS.
Thank you for choosing GE !
START-UP AND COMMISSIONING
A GE GLOBAL SERVICES FIELD ENGINEER must perform start-
up and
commissioning of the UPS.
Please Contact GE GLOBAL SERVICES at least two weeks prior to schedule
start-up and commissioning at 1-800-637-1738, or by E-
mail at
pqservice@ge.com .
Distributed in the USA by
Your Service Center
g
GE Consumer & Industrial SA
General Electric Company
CH – 6595 Riazzino (Locarno)
Switzerland
www.gecriticalpower.com
g
GE Energy Connections
Critical Power
3100 Technology – Suite 200
Plano, TX 75074
T: +1 800-637-1738
E: gepqsales@ge.com
www.geindustrial.com/products/
critical-power
g
GE Energy Connections
Critical Power
601 Shiloh Road
Plano, TX 75074
24/7 T: +1 800-637-1738
24/7 F: +1 866-765-3595
E: pqservice@ge.com
Critical Power
Modifications reserved
Page 4/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Preface
Congratulations on your choice of a TLE Series Uninterruptible Power Supply (UPS).
It will help eliminate load disturbances due to unexpected power problem
.
This
Installation Guide
describes how to prepare the installation site, and it provides
weight and
dimensions and procedures for moving, installing and connecting the UPS.
Please refer to the
accompanying User Manual
, which describes the function of the UPS
module, the purpose and location of the switches, the meaning of the system events
related to the front panel indication, and provides procedures for starting and stopping
the equipment.
While every care has been taken to ensure the completeness and accuracy of this manual,
GE
assumes no responsibility or liability for any losses or damages result
ing from the use
of the information contained in this document.
WARNING!
TLE Series 160 - 500 is a Category C3 UPS Product (according to IEC 62040-2).
This is a product for commercial and industrial application in the second environment −
installation restrictions or additional measures may be needed to prevent disturbances.
We recommend that this manual be kept next to the UPS for future references.
If any problems are encountered with the procedures contained in this manual, please
contact your
GE Service Center before you proceed.
This document shall not be copied or reproduced without the permission of
GE.
Some of the information contained in this manual may be changed without notice to
reflect technical improvements.
Safety instructions
Read the safety instructions contained on the following pages carefully before the
installation of the UPS, options and battery system.
Pay attention to the rectangular boxes included in the text:
They contain important information and warning concerning electrical connections and
personnel safety
.
Parallel System version secured with RPA
When included in the text, this symbol refers to operation needed
only for RPA Parallel System.
Critical Power
Modifications reserved
Page 5/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Table of content Page
1 IMPORTANT SAFETY INSTRUCTIONS ............................................................................................................................. 6
2 LAYOUT ............................................................................................................................................................................... 9
2.1 LAYOUT TLE SERIES 160 - 220 - 225 - 250 ....................................................................................................................................................... 9
2.2 LAYOUT TLE SERIES 300 - 400 - 500 ................................................................................................................................................................ 11
3 ENVIRONMENT ................................................................................................................................................................13
3.1 RECYCLING INSTRUCTIONS.................................................................................................................................................................................. 13
4 INSTALLATION .................................................................................................................................................................14
4.1 TRANSPORT................................................................................................................................................................................................................. 14
4.1.1 Dimensions and weights TLE Series 160 - 500 ........................................................................................................................................................... 15
4.2 DELIVERY ...................................................................................................................................................................................................................... 16
4.3 STORAGE ...................................................................................................................................................................................................................... 16
4.3.1 Storage of the UPS .................................................................................................................................................................................................................... 16
4.3.2 Storage of Battery ..................................................................................................................................................................................................................... 16
4.4 PLACE OF INSTALLATION ...................................................................................................................................................................................... 17
4.4.1 UPS location ................................................................................................................................................................................................................................. 17
4.4.2 Battery location .......................................................................................................................................................................................................................... 20
4.5 VENTILATION AND COOLING ............................................................................................................................................................................... 21
4.6 UNPACKING ................................................................................................................................................................................................................ 22
4.7 ELECTRICAL WIRING ............................................................................................................................................................................................... 24
4.7.1 Utility input connection ........................................................................................................................................................................................................... 24
4.7.2 Input/output over current protection and wire sizing ............................................................................................................................................. 25
4.7.3 Data for Input/output and battery over current protection and wire sizing ............................................................................................... 26
4.7.4 Installation requirements....................................................................................................................................................................................................... 29
4.8 WIRING CONNECTION ............................................................................................................................................................................................ 32
4.8.1 TLE Series 160 - 200 - 225 - 250 Power connection with Common Input Utility ..................................................................................... 35
4.8.2 TLE Series 160 - 200 - 225 - 250 Power connection with Dual Input Utility ............................................................................................... 37
4.8.3 TLE Series 300 - 400 - 500 Power connection with Common Input Utility ................................................................................................. 40
4.8.4 TLE Series 300 - 400 - 500 Power connection with Dual Input Utility ........................................................................................................... 42
4.8.5 Use of TLE Series 160 - 500 in eBoost™ Operation Mode ..................................................................................................................................... 45
4.8.6 Use of TLE Series 160 - 500 as frequency converter ............................................................................................................................................... 46
4.9 RPA PARALLEL SYSTEM CONNECTION ............................................................................................................................................................ 47
4.9.1 Power wiring of parallel units .............................................................................................................................................................................................. 47
4.9.2 Parallel control bus connection .......................................................................................................................................................................................... 48
4.9.3 Control bus cable location .................................................................................................................................................................................................... 50
4.10 “EPO - EMERGENCY POWER OFF” COMMAND CONNECTION ............................................................................................................... 52
5 CUSTOMER INTERFACE ..................................................................................................................................................54
5.1 SERIAL PORT J35µP - RS232 (SUB D, FEMALE 9 PIN)................................................................................................................................. 55
5.2 CUSTOMER INTERFACE BOARD .......................................................................................................................................................................... 56
5.2.1 Connector J1 – RJ45 8P8C .................................................................................................................................................................................................... 57
5.2.2 X1 terminal block - Output signals on voltage-free contacts ............................................................................................................................. 57
5.2.3 X1 terminal block - Programmable input free contacts ......................................................................................................................................... 57
5.2.4 X2 terminal block – “EPO - Emergency Power Off” ................................................................................................................................................... 58
5.2.5 X1 terminal block - Gen Set Signaling (GEN ON)......................................................................................................................................................... 58
5.2.6 X1 terminal block - AUX external Maintenance Bypass ......................................................................................................................................... 59
5.2.7 X1 terminal block - eBoost/IEMi control signal ........................................................................................................................................................... 59
6 NOTES ...............................................................................................................................................................................60
6.1 NOTES FORM .............................................................................................................................................................................................................. 60
Critical Power
Modifications reserved
Page 6/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
1 IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important instructions for models TLE Series 160 - 500 that should be followed
during installation and maintenance of the UPS and battery.
GENERAL
- Move the UPS in an upright position in its original package to the final destination room.
To lift the cabinets, use a forklift or lifting belts with spreader bars.
- Check for sufficient floor and elevator loading capacity.
- Check the integrity of the UPS equipment carefully.
If you notice visible damage, do not install or start the UPS.
Contact the nearest GE Service Center immediately.
- WARNING! RISK OF ELECTRICAL SHOCK:
Do not remove covers, there are no user serviceable parts inside.
- After switching off takes 5 minutes for the DC capacitors to discharge because a lethally high voltage
remains at the terminals of the electrolytic capacitors.
- UPS’s and battery system require a 12 months periodic maintenance to operate reliably and safely.
This should be performed by qualified service personnel. The UPS contains its own energy source (battery).
- The field-wiring outlets may be electrically live, even when the UPS is disconnected from the utility.
- Dangerous voltages may be present during battery operation.
- The battery must be disconnected during maintenance or service work.
- This UPS contains potentially hazardous voltages.
- Be aware that the inverter can restart automatically after the utility voltage is restored.
- End user must follow applicable regional occupational safety codes/regulations during installation,
operation and equipment maintenance. This may require additional field marking or labeling defining
appropriate level of PPE (Personal Protection Equipment) to reduce the risk of Arc-flash related injuries.
Contact our GE Service Center for product specific information.
INSTALLATION
- This UPS must be installed and connected only by trained personnel.
- Verify accurately during Commissioning and Maintenance of the UPS, for the following:
Damaged components, squeezed wires and cables, or not correctly inserted plugs.
- After removing the sidewalls of the UPS, make sure that all earth connections when reassembling, are
correctly reattached.
- This UPS is intended for use in a controlled indoor environment free of conductive contaminants and
protected against animals intrusion.
- WARNING! HIGH EARTH LEAKAGE CURRENT:
Earth connection is essential before connecting to AC input!
- Switching OFF the unit does not isolate the UPS from the utility.
- Do not install the UPS in an excessively humid environment or near water.
- Avoid spilling liquids on or dropping any foreign object into the UPS.
- The unit must be placed in a sufficiently ventilated area; the ambient temperature should not exceed 104°F
(40°C).
- Optimal battery life is obtained if the ambient temperature does not exceed 77°F (25°C).
- It is important that air can move freely around and through the unit. Do not block the air vents.
- Avoid locations in direct sunlight or near heat sources.
STORAGE
- Store the UPS in a dry location; storage temperature must be within -13°F (-25°C) to 131°F (55°C).
- The optimal temperature for Battery storage is 68°F (20°C) to 77°F (25°C) and shall never exceed the range -
4°F (-20°C) to 104°F (40°C).
- If the unit is stored for a period exceeding 3 months, the battery must be recharged periodically (time
depending on storage temperature).
BATTERY
- The battery-voltage is dangerous for person’s safety.
- When replacing the battery, use the same cells number, voltage (V), capacity (Ah).
All the battery used, shall be of the same manufacturer and date of production.
- Proper disposal or recycling of the battery is required.
Refer to your local codes for disposal requirements.
- Never dispose of battery in a fire: they may explode.
- Do not open or mutilate battery: their contents (electrolyte) may be extremely toxic.
If exposed to electrolyte, wash immediately with plenty of water.
- Avoid charging in a sealed container.
- Never short-circuit the batteries.
When working with batteries, remove watches, rings or other metal objects, and only use insulated tools.
- In case of air shipment, the cables +/- going to the battery fuses/terminals shall be disconnected and isolated.
Critical Power
Modifications reserved
Page 7/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Safety instructions when working with battery
EXTERNAL BATTERY MUST BE INSTALLED AND CONNECTED TO THE UPS BY
QUALIFIED SERVICE PERSONNEL.
INSTALLATION PERSONNEL MUST READ THIS ENTIRE SECTION BEFORE HANDLING
THE UPS AND BATTERY.
DANGER!
Full voltage and current are always present at the battery terminals.
The battery used in this system can provide dangerous voltages, extremely high currents and a risk of
electric shock.
If the terminals are shorted together or to ground they may cause severe injury.
You must be extremely careful to avoid electric shock and burns caused by contacting battery terminals
or shorting terminals during battery installation.
Do not touch uninsulated battery terminals.
A qualified service person, who is familiar with battery systems and required precautions, must install and
service the battery.
The installation must conform to national and local codes.
Keep unauthorized personnel away from the battery.
The qualified service person must take these precautions:
1 Wear protective clothing, such as rubber gloves and boots and protective eye wear.
Batteries contain caustic acids and toxic materials and can rupture or leak if mistreated.
Remove rings and metal wristwatches or other metal objects and jewellery.
Do not carry metal objects in your pockets where the objects can fall into the battery cabinet.
High energy through conductive materials could cause severe burns.
2 Tools must have insulated handles and must be insulated so that they will not short battery
terminals.
Do not allow a tool to short between individual or separate battery terminals or to the cabinet or
rack.
Do not lay tools or metal parts on top of the battery, and do not lay them where they could fall onto
the battery or into the cabinet.
3 Disconnect charging source prior to connecting or disconnecting battery terminals.
Install the battery as shown on the drawing provided with the battery.
When connecting cables, never allow a cable to short across a battery’s terminals, the string of
battery, or to the cabinet or rack.
4 Align the cables on the battery terminals so that the cable lug will not contact any part of the cabinet
or rack, even if the battery is moved.
Keep the cable away from any sharp metal edges.
5 Install the battery cables in such a way that the UPS or battery cabinet doors cannot pinch them.
6 Do not connect the battery terminal to Ground.
If any battery terminal is inadvertently grounded, remove the source of the ground.
Contacting any part of a grounded battery can cause a risk of electric shock.
7 Determine if battery is inadvertently grounded. If inadvertently grounded, remove source from
ground. Contact with any part of a grounded battery can result in electrical shock.
The likelihood of such shock can be reduced if such grounds are removed during installation and
maintenance.
8 To reduce the risk of fire or electric shock, install the battery in a temperature and humidity
controlled indoor area, free of contaminants.
9 Battery system chassis ground (earth) must be connected to the UPS chassis ground (earth).
If you use conduits, this ground conductor must be routed in the same conduit as the battery
conductors.
10 Where conductors may be exposed to physical damage, protect the conductors in accordance with
all applicable codes.
11 If you are replacing the battery or repairing battery connections, shut OFF the UPS and remove the
battery fuses.
Critical Power
Modifications reserved
Page 8/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Safety symbols and warnings
Safety warnings
The text of this manual contains some warnings to avoid risk to the persons and to avoid damages to
the UPS system and the supplied critical loads.
The non-observance of the warnings reminding hazardous situations could result in human injury and
equipment damages.
Please pay attention to the meaning of the following warnings and symbols.
Throughout this manual the following symbols are defined:
WARNING, if instruction is not followed injury or serious equipment damage may
occur!
CAUTION, internal parts have dangerous voltage present.
Risk of electric shock!
PE (Earth) – GND (Ground)
PROTECTIVE GROUNDING TERMINAL:
A terminal which must be connected to earth ground prior to making any other
connection to the equipment.
A terminal to which or from which an alternating (sine wave) current or voltage
may be applied or supplied.
A terminal to which or from which a direct current or voltage may be applied or
supplied.
This symbol indicated the word “phase”.
This symbol indicates the principal on/off switch in the on position.
This symbol indicates the principal on/off switch in the off position.
Critical Power
Modifications reserved
Page 9/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
2 LAYOUT
2.1 LAYOUT TLE Series 160 - 220 - 225 - 250
Fig. 2.1-1 TLE Series 160 - 200 - 225 - 250 General view
Fig. 2.1-3 Control Panel
Fig. 2.1-4 Connectivity Rack
Fig. 2.1-2 TLE Series 160 - 200 - 225 - 250 General view with open doors
Fig. 2.1-5 Q1 - UPS Output switch
TLES_UL_225-250_S1_UPS_GE_02
TLES_160-400_S1_Customer interface-CI_SNMP_XA_01
SNMP
CI
1 2
EPO
EPO
-
+
J35
µP
XA
TLES_UL_225-250_S1_UPS_GE_03
Q1
I ON
0 OFF
1
2
EPO
EPO
-
+
Q1
I ON
0 OFF
TLES_UL_225-250_S1_Switch Q1_01
Critical Power
Modifications reserved
Page 10/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Fig. 2.1-6 TLE Series 160 - 200 - 225 - 250 General view without protection panels
1 Opening for top cable entry (*)
2
Opening for bottom cable entry (*)
3
Bus bars for Utility input and Load output
4
Bus bars for external Battery connection
CI
Customer Interface Board (see Fig. 2.1-4)
CR
Connectivity Rack
J35µP
Serial port RS232 for IMV protocol
Q1
UPS Output switch
RPA
RPA board (Redundant Parallel Architecture) for Parallel System (option)
SNMP
3-ph SNMP/WEB plug-in adapter (option - see Fig. 2.1-4)
XA
Terminals for “EPO - Emergency Power Off” connection and 24Vdc for external battery switch
*) Remove this panel or provide means to capture metal filings from cutting conduit entry holes
1
4
3
TLES_UL_225-250_S1_UPS_GE_04a
12
EPO
EPO
-
+
XA
CR
J35
µP
RPA
Q1
2
Q1
I ON
0 OFF
Critical Power
Modifications reserved
Page 11/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
2.2 LAYOUT TLE Series 300 - 400 - 500
Fig. 2.2-1 TLE Series 300 – 400 - 500 General view
Fig. 2.2-3 Control panel
Fig. 2.2-4 Connectivity Rack
Fig. 2.2-2 TLE Series 300 – 400 - 500 General view with open doors
Fig. 2.2-5 Q1 - UPS Output switch
TLES_UL_400-500_S1_UPS_GE_02
TLES_160-400_S1_Customer interface-CI_SNMP_XA_01
SNMP
CI
1 2
EPO
EPO
-
+
J35
µP
XA
TLES_UL_400-500_S1_UPS_GE_03a
Q1
12
I ON
0 OFF
EPO
EPO
-
+
TLES_UL_400-500_S1_Switch Q1_01
Q1
I ON
0 OFF
Critical Power
Modifications reserved
Page 12/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Fig. 2.1-6 TLE Series 300 – 400 - 500 General view without protection panels
1 Opening for top cable entry (*)
2
Opening for bottom cable entry (*)
3
Bus bars for Utility input and Load output
4
Bus bars for external Battery connection
CI
Customer Interface Board (see Fig. 2.2-4)
CR
Connectivity Rack
J35µP
Serial port RS232 for IMV protocol
Q1
UPS Output switch
RPA
RPA board (Redundant Parallel Architecture) for Parallel System (option)
SNMP
3-ph SNMP/WEB plug-in adapter (option - see Fig. 2.2-4)
XA
Terminals for “EPO - Emergency Power Off” connection and 24Vdc for external battery switch
*) Remove this panel or provide means to capture metal filings from cutting conduit entry holes
TLES_UL_400-500_S1_UPS_GE_04a
Q1
1
2
I ON
0 OFF
EPO
EPO
-
+
1
XA
CR
RPA
J35
µP
4
Q1
3
2
Critical Power
Modifications reserved
Page 13/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
3 ENVIRONMENT
3.1 RECYCLING INSTRUCTIONS
NOTE !
This product has been designed to respect the
environment, using materials and components respecting
eco-design rules.
It does not contain CFCs (Carbon Fluor Clorid) or HCFCs
(Halogen Carbon Fluor Clorid).
PACKING MATERIAL RECYCLING
GE, in compliance with environment protection, uses only
environmentally friendly material.
UPS packing materials must be recycled in compliance with
all applicable regulations.
RECYCLING AT THE END OF SERVICE LIFE !
GE
, in compliance with environment protection
recommends to the User that the UPS equipment, at the
end of its service life, must be recovered conforming to
the local applicable regulations.
WARNING !
Leads contained in the batteries is a dangerous substance
for the environment, therefore it must be correctly
recycled by specialized companies!
Critical Power
Modifications reserved
Page 14/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4 INSTALLATION
4.1 TRANSPORT
The UPS is packaged on a pallet suitable for handling with a forklift.
The UPS must be moved in
upright position.
Do not tilt cabinets
more than +/- 10° during handling.
Move the UPS in its original package to the final destination site
.
Do not stack other packages on top: This could damage the UPS.
Forklift
Fig. 4.1-1 Position of the forklift when moving the unpacked UPS
Forklift
The UPS may be
lifted with a forklift in
upright position.
Take note of the
center of gravity
marked on the package
.
Crane
Fig. 4.1-2 Position of the carrying belts when moving the unpacked UPS
WARNING !
Check for sufficient floor and
elevator loading capacity.
Transport UPS only in upright
position.
Do not stack other package on top
of the UPS.
Crane
If the UPS has to be lifted by crane, use
suitable carrying belts taking note of the
center of gravity
marked on the
package.
Take all necessary
precautions to
avoid damage to the cabinet while
hoisting the UPS.
WARNING !
When loading / unloading and when
moving the UPS, it is forbidden:
When loading / unloading and when
moving the UPS, pay attention to:
Critical Power
Modifications reserved
Page 15/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.1.1 Dimensions and weights TLE Series 160 - 500
Dimensions and weights
TLE Series 160 - 220 - 225 - 250
Dimensions
(W x D x H):
44.10 x 34.06 x 75.00 inches
1120 x 865 x 1905 mm
Weight: 1345 lbs / 610 kg
Floor loading: 129 lbs/sq.ft / 630 kg/m2
Dimensions and weights
TLE Series 300 - 400 - 500
Dimensions
(W x D x H):
63.78 x 34.06 x 75.00 inches
1620 x 865 x 1905 mm
Weight: 2756 lbs / 1280 kg
Floor loading: 187 lbs/sq.ft / 914 kg/m2
NOTE !
The weight of each single piece is marked outside the package!
34.06"
865mm
44.10"
1120 mm
75.00"
1905mm
TLES_UL_225-250_S1_UPS dimension_GE_01
TLES_UL_400-500_S1_UPS dimension_GE_01
34.06"
865mm
63.78"
1620 mm
75.00"
1905mm
Critical Power
Modifications reserved
Page 16/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.2 DELIVERY
When delivered, inspect the package integrity and the physical condition of the cabinets carefully.
In case of any damage sustained during transport, immediately inform the carrier and contact your GE
Service Center.
A detailed report of the damage is necessary for any insurance claim.
NOTE !
A damaged UPS must never be installed or connected to Utility or Battery!
4.3 STORAGE
4.3.1 Storage of the UPS
The equipment is carefully packed for transport and
storage so that it is in a perfect condition when eventually
installed.
Never leave an UPS outside the building and do not store
the UPS one on top of the other.
We recommend to store the UPS in its original package in
a dry, dust-free room, away fro
m chemical substances,
and with a temperature range not exceeding -13°F (-25°C)
to 131°F (55°C).
In case the battery is included please refer to Section 4.3.2.
Some important functions of the UPS, such as the customized functions, are defined by parameters
stored in a RAM memory.
A small backup Battery located on the Control Unit board supplies the RAM.
If the storage time of the UPS exceeds 1 year, these functions should be verified by an authorized GE
Service Center before putting the UPS into operation.
4.3.2 Storage of Battery
When the delivery includes a maintenance free Battery, keep in mind that they are subject to self-
discharge and therefore you must recharge the Battery.
The storage time without Battery recharge depends on the temperature of the storage site.
The optimal temperature for Battery storage is 68°F (20°C) to 77°F (25°C) and shall never exceed the
range -4°F (-20°C) to 104°F (40°C).
Recharge stored maintenance free Battery every:
6 months when the storage temperature is 68°F (20°C)
3 months when the storage temperature is 86°F (30°C)
2 months when the storage temperature is 95°F (35°C)
Critical Power
Modifications reserved
Page 17/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.4 PLACE OF INSTALLATION
4.4.1 UPS location
NOTE !
UPS installation and connection must be performed by a GE Service Technician only.
If optional cabinets and accessories are included with the UPS, please refer to those
accompanying manuals for installation and operating instructions.
It is important to have a clean, dust-free environment provided with proper ventilation and airconditioning to keep the ambient temperature within the specified operating range.
We strongly advice that the ambient temperature should not exceed 68°F (20°C) to 77°F (25°C) (max.
104°F / 40°C). Refer to Section 4.5.
Check for sufficient floor load capacity before installing the UPS and the Battery.
Refer to Section 4.1.1.
For Battery installation follow the local codes and the recommendation of the battery supplier.
NOTE !
Operation at temperatures higher than 77°F (25°C) will reduce battery life.
Potential consequences are explained in Section 9.1.4 of the User Manual: read and
understand them.
The TLE Series 160 - 500 UPS can radiate radio frequency energy.
Although some RFI (Radio Frequency Interference) filtering is inherent to the UPS there is no guarantee
that the UPS will not influence sensitive devices such as cameras and monitors that are positioned close
by.
If interference is expected, the UPS should be moved away from the sensitive equipment.
Positioning of the UPS TLE Series 160 - 500
Fig. 4.4.1-1 TLE Series 160 - 500 Positioning of the UPS
The rear panel of the UPS may be
mounted flush to a wall or other
structure.
Clearance around the front of the unit
should be sufficient to enable free
passage of personnel with the doors
fully open, and to allow sufficient
airflow to the door vents.
Check section 110-26(A) of the NEC
code for specific requirements.
To guarantee proper cooling air
exhaust, the mandatory minimum
clearance between ceiling and top of
the UPS is 20” (500mm).
A single-phase power outlet (120Vac)
should be provided near the UPS for
connection of power tools, test
equipment or connectivity devices.
This outlet must be grounded.
TLES_UL_225-500_S1_UPS disposition_GE_01
TLE Series 225 & 250
TLE Series 400 & 500
Min.
20" / 500mm
Min.
20" / 500mm
Critical Power
Modifications reserved
Page 18/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
TLE Series 160 - 500 Openings for input and output cable connections
Fig. 4.4.1-2 TLE Series 160 - 220 - 225 - 250 Opening on top of the cabinet for input and output cables connections
Fig. 4.4.1-3 TLE Series 300 - 400 - 500 Opening on top of the cabinet for input and output cables connections
Fig. 4.4.1-4 TLE Series 160 - 220 - 225 - 250 Opening on the bottom of the cabinet for input & output cables connections
Fig. 4.4.1-5 TLE Series 300 - 400 - 500 Opening on the bottom of the cabinet for input & output cables connections
TLE Series 160 - 500 openings are provided on the top (*) and the bottom (*) of the UPS for the
connection of input and output cables.
Pay attention to the position of these openings, when choosing the placement of the UPS.
These openings are covered with a protective plate.
*) Please remove the plate before drilling any holes.
Utility input
Output load
Battery
9.85 "
250 mm
44.10"
1120 mm
0.99 "
25 mm
TLES_UL_225-250_S1_UPS view top_01US
FRONTAL SIDE
1 "
29.53 "
750 mm
34.06 "
865 mm
Utility input
Output load
Battery
10.83 "
275 mm
63.78"
1620 mm
1.38 "
35 mm
TLES_UL_400-500_S1_UPS view top_01US
FRONTAL SIDE
1 "
29.53 "
750 mm
34.06 "
865 mm
FRONTAL SIDE
8.27 "
210 mm
TLES_UL_225-250_S1_UPS view bottom_01US
Utility input
Load output
Battery
29.53 "
750 mm
34.06 "
865 mm
44.10"
1120 mm
0.99 "
25 mm
1.97 "
50 mm
FRONTAL SIDE
9.73 "
247 mm
TLES_UL_400-500_S1_UPS view bottom_01US
Utility input
Load output
Battery
29.10 "
739 mm
34.06 "
865 mm
63.78"
1620 mm
2.05 "
52 mm
2.68 "
68 mm
Critical Power
Modifications reserved
Page 19/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Fixing of the UPS cabinet TLE Series 160 - 500 on the floor
The UPS cabinet is free
standing and normally
does not require to be
bolted to the floor.
The UPS cabinet can be
fixed however to the floor
by bolting it with the
supporting blocks to the
floor.
Fig. 4.4.1.6 Fixing of the UPS cabinet on the floor
Fig. 4.4.1-7 TLE Series 160 - 220 - 225 - 250 UPS cabinet floor fixing points
Fig. 4.4.1-8 TLE Series 300 - 400 - 500 UPS cabinet floor fixing points
TLES_UL_225-500_S2_UPS fixing_01
2.13 " / 54 mm
2.37 " / 60 mm
44.10 " / 1120 mm
27.56 " / 700 mm
14.18" / 360mm
Ø 0.53" / 13.5mm
TLES_UL_225-250_S1_UPS fixing_01
FRONTAL SIDE
29.53 " / 750 mm
34.06 " / 865 mm
2.37 " / 60 mm
TLES_UL_400-500_S1_UPS fixing_02
29.53 " / 750 mm
2.37 " / 60 mm
27.56 " / 700 mm
27.56 " / 700 mm
2.37 " / 60 mm
3.94 " / 100 mm
34.06 " / 865 mm
2.37 " / 60 mm
63.78 " / 1620 mm
Ø 0.53" / 13.5mm
FRONTAL SIDE
2.13 " / 54 mm
Critical Power
Modifications reserved
Page 20/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Fig. 4.4.1-9 TLE Series 160 - 220 - 225 - 250
RPA Parallel System disposition
Fig. 4.4.1-10 TLE Series 300 - 400 - 500
RPA Parallel System disposition
In case of
Parallel System
, try to place the UPS modules in sequence of their numbers
(marked on the packing).
If the units are positioned “side by side”, the side panels must be mounted on all
units.
4.4.2 Battery location
Batteries require a well-ventilated room with controlled temperature to obtain reliable operation.
The Battery can be installed immediately adjacent to the UPS (left or right side) or remotely from the
UPS.
If the Battery is installed remotely from the UPS, a wall mounted DC disconnect device must be installed
within line-of-site to both the UPS and the Battery.
The optimal room temperature for Battery storage is 68°F (20°C) to 77°F (25°C) and shall never exceed
the range -4°F (-20°C) to 104°F (40°C).
The life of valve-regulated batteries will be reduced by 50% for each additional 18°F (10°C) that the
battery ambient temperature is above 77°F (25°C).
The Battery System associated with larger UPS is usually either rack mounted or installed in multiple
Battery Cabinets.
Installation and assembly must be made according to the local standards and Battery System
manufacturer‘s recommendations.
The Battery Circuit Breaker or Battery Fuse Box must be mounted as near as possible to the Battery.
WARNING !
Battery installation and connection must be performed by qualified personnel
only.
Read all safety instructions before proceeding with the installation (see Section 1).
Battery discharging and/or charging activities may cause the emission of
hydrogen gas; therefore, the room requires proper ventilation and fresh air.
Comply with the UL1778-CSAC22.2no170.3 UPS safety standard, ANSI/IEEE P1184
Guide for Batteries for Uninterruptible Power Supply Systems and applicable codes
and governmental regulations.
TLES_UL_225-250_S1_RPA disposition_GE_01US
UPS
3 - 4 - 5 - 6
UPS 2
UPS 1
TLES_UL_400-500_S1_RPA disposition_GE_01US
UPS
3 - 4 - 5 - 6
UPS 1
UPS 2
Critical Power
Modifications reserved
Page 21/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.5 VENTILATION AND COOLING
Fig. 4.5-1 Installation on plain floor Fig. 4.5-2 Installation on raised floor
The heat produced by the UPS is transferred to the environment by its ventilation.
Air inlets for UPS ventilation are located on the front of the UPS, while air outlets are on top of the
cabinet.
A suitable ventilation or cooling system must be installed to extract the heat from the UPS room.
NOTE !
Do not put anything on the top of the cabinet.
19.7” (500mm) of air clearance MUST BE LEFT from the top of the UPS for a sufficient
exhausted air exchange, proper cooling, service access and safety.
Air filtering systems could be required when the UPS operates in a dirty environment.
In order to prevent overheating of the UPS, the available air intake flow rate must exceed the total air
exhaust flow rate requirement of the UPS system.
Contact your GE Service Center for appropriate solutions.
The below table indicates the heat dissipation at full Load at PF = 1 and charged Battery, up to 3280 ft
(1000 m) altitude, for cooling air 77°F (25°C) to 86°F (30°C).
UPS model
Losses
Cooling air flow
VFI
eBoost™ (option)
VFI
PF = 1 PF = 1 PF = 1
TLE Series 160
20137 BTU/hr
5.9 kW
6826 BTU/hr
2.0 kW
1013 CFM
1721 m3/h
TLE Series 200
25256 BTU/hr
7.4 kW
8532 BTU/hr
2.5 kW
1270 CFM
2158 m3/h
TLE Series 225
27986 BTU/hr
8.2 kW
10922 BTU/hr
3.2 kW
1408 CFM
2392 m3/h
TLE Series 250
31741 BTU/hr
9.3 kW
10239 BTU/hr
3.0 kW
1597 CFM
2713 m3/h
TLE Series 300
32765 BTU/hr
9.6 kW
12799 BTU/hr
3.8 kW
1648 CFM
2800 m3/h
TLE Series 400
48123 BTU/hr
14.1 kW
18089 BTU/hr
5.3 kW
2421 CFM
4113 m3/h
TLE Series 500
63823 BTU/hr
18.7 kW
20819 BTU/hr
6.1 kW
3210 CFM
5454 m3/h
NOTE !
Even when eBoost™ Operating Mode
option is available, the ventilation and cooling
system shall be rated as for operation in VFI mode.
Air Extraction
Air Intake
TLES_600-800_S1_UPS ventilation_Raised floor_01GB
TLES_600-800_S1_UPS ventilation_Raised floor_01GB
Air Extraction
Critical Power
Modifications reserved
Page 22/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.6 UNPACKING
Move the equipment in it’s original packing, carton box or wooden case, until the place of installation
and remove the packing and the transport sockets only just before installing the UPS.
Be aware of the heavy weight of the UPS, pay attention when moving the UPS cabinet.
White colour = without any anomaly
Red colour
= anomaly evidence
The package of the TLE Series 160 - 500 is
equipped with ShockWatch (indicator for
shock), and TiltWatch
(indicator for
overthrow) on the outside.
These devices indicate an eventual shock
or overthrow during transport.
Whenever these devices show a
possible anomaly, the UPS shall not be
commissioned.
Please contact your “GE Service
Center”.
Fig. 4.6-1 ShockWatch device
Fig. 4.6-2 TiltWatch device
NOTE !
Be aware of the heavy weight of the UPS, pay attention when moving the UPS
cabinet.
Take care not to damage the UPS when moving by forklift.
A damaged UPS must never be installed or connected to Utility or Battery!
In case of any damage sustained during the transport, immediately inform the
shipping agent!
A detailed report of the damage is necessary for any indemnity claim.
Included in the delivery you can find the following parts:
• An accessories bag.
• Air inlet grids, which must be mounted on the bottom of the cabinet UPS with the screws included.
• Control Bus cables for inter-connecting the UPS modules (only For the RPA system).
• The documentation includes the “Installation Guide & User Manual” and the “UPS Safety Rules”.
PACKING MATERIAL RECYCLING
GE, in compliance with environment protection, use only environmentally
friendly material.
UPS packing materials must be recycled in compliance with all applicable
regulations.
Critical Power
Modifications reserved
Page 23/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
ANTI-HUMIDITY & CORROSION DEVICES
Fig. 4.6-3 TLE Series 160 - 200 - 225 - 250
Location of the “Anti-Humidity & Corrosion devices”
The package of the TLE Series 160 - 500
includes “Anti-Humidity & Corrosion devices”
against the formation of humidity and
corrosion during the transportation and the
storage of the UPS.
TLE Series 160 - 200 - 225 - 250
a. Humidity indicator
b. Desiccant bag (5 pcs.)
c. VCI foil base
d. PE stretch foil
WARNING !
It’s MANDATORY TO REMOVE
the “Anti-
Humidity &
Corrosion devices” during the
unpacking of the UPS!
Humidity indicator
Before removing the devices
“C - VCI foil base” & “D - PE
stretch foil”, check the status
of the “A - Humidity indicator”.
10% to 70%:
The UPS can be commissioned.
80%:
T
he UPS shall not be
commissioned. Please contact
your “GE Service Center”.
Fig. 4.6-4 TLE Series 300 - 400 - 500
Location of the “Anti-Humidity & Corrosion devices”
TLE Series 300 - 400 - 500
a. Humidity indicator
b. Desiccant bag (8 pcs.)
c. VCI foil base
d. PE stretch foil
PROTECTIVE FOIL
Fig. 4.6-5 Location of the “Protective Foil”
TLE Series 160 - 500 is provided with a “Protective Foil”, on
the roof and door/front panels, to prevent material from
falling into UPS.
WARNING !
It’s MANDATORY TO REMOVE the
“Protective Foil” but only just before the
first start-up of the UPS as indicated in the
appropriate label!
The removal of the "PROTECTIVE FOIL"
should be performed only by a GE Service
Technician!
TLES_UL_225-250_S1_UPS Anti-Humidity_01a
1
2
EPO
EPO
-
+
DESICCANT
B
HUMIDITY
INDICATOR
20
%
30
%
40
%
50
%
60
%
70
%
80
%
A
B
A
B
B
B
B
D
C
Q1
I ON
0 OFF
TLES_UL_400-500_S2_UPS Anti-Humidity_01a
Q1
12
I ON
0 OFF
EPO
EPO
-
+
DESICCANT
B
HUMIDITY
INDICATOR
20
%
30
%
40
%
50
%
60
%
70
%
80
%
A
B
B
B
B
B
B
B
B
D
C
A
TLES_UPS Protective foil_01GB
PROTECTIVE FOIL
to remove as indicated
in the label
PROTECTIVE FOIL
to remove
as indicated
in the label
PROTECTIVE FOIL
to remove as indicated
in the label
Critical Power
Modifications reserved
Page 24/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.7 ELECTRICAL WIRING
WARNING !
UPS installation and connection must be performed by a GE Service Technician only.
It is the responsibility of the installation technician to ensure that all local and
national electric codes are adhered to.
Refer to the “Safety prescriptions - Installation” described on Section 1.
4.7.1 Utility input connection
NOTE !
Ensure that the AC and DC external isolators are OFF and locked out to prevent their
inadvertent operation.
Do not apply power to the equipment prior to the commissioning by a GE Service
Technician.
Before any other input connection, connect and check the grounding wire.
The UPS has available input terminations for the Rectifier and Bypass.
The unit may be powered from a Common Input source or Dual Input sources if desired.
Common Input Utility Rectifier & Bypass
Fig. 4.7.1-1 Common Input Utility Rectifier & Bypass
The same power source is to be used for
both Bypass Supply and Rectifier Input
(input F3).
Bear in mind that when the Utility fuses are
opened there is a supply failure to the
Rectifier as well as to the Automatic
Bypass.
In this case, the interconnection links BR1, BR2 and BR3 on the input terminals or bus
bars MUST REMAIN CONNECTED.
Dual Input Utility Configuration Rectifier & Bypass
Fig. 4.7.1-2 Dual Input Utility Rectifier & Bypass
The Bypass and Rectifier use different
power sources (F1 and F2 inputs).
In this case, when the Rectifier-input fuses
are opened, the Automatic Bypass is
supplied by the other connection.
Always verify that the received UPS is as per the configuration ordered.
While installing UPS dual source, the interconnection links BR1, BR2 and BR3 MUST
BE REMOVED. See Fig. 4.8.2-2 & Fig. 4.8.4-2.
Connect a single input Neutral to Bypass Utility (inside the UPS, common Neutral for
Bypass and Rectifier).
Critical Power
Modifications reserved
Page 25/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.7.2 Input/output over current protection and wire sizing
The cabling of the UPS system has to be sized according to the UPS power rating.
Sizing of circuit Breakers, Fuses and cables for Input Utility, output load and Battery must meet the
requirements of local and national electrical codes.
Before connecting the UPS, verify that the Utility Voltage and Frequency, the Output Load Voltage and
Frequency and Battery Data (cells number, floating voltage, autonomy) are according to the required
data.
The protection of the UPS utility input must be exclusively with 3 pole breakers.
In 4-wire distributions (3-phase, 4-wire plus ground):
• Disconnection of the Neutral is not permitted.
The UPS needs the connection of the Neutral to the input, to guarantee the function in TN mode
(Neutral-Earth).
• Caution when using Four-Pole Circuit Breakers as protection to the UPS Load.
A potential problem exists for situations with non-linear Loads, causing the Neutral Current to be
higher than the Phase Current.
Avoid to run the input cables in parallel with the output cables to prevent them from noise induction.
The Three-Phase Utility Power supply must be symmetrical with respect to Ground (wye-connected and
grounded solidly), due to the existence of voltage surge protection devices inside the UPS.
The connection of the Battery to the UPS must be protected with fuses or similar devices according to
technical specifications and in accordance with local standards.
NOTE !
If you use ELCB breaker (Earth Limiting Circuit Breaker) to protect the input
connections, consider the high leakage current generated by the noise suppression
capacitors.
If these ELCB breakers are strictly necessary, we suggest using the largest type
suitable for non-linear current and for delayed operations.
Specific prescriptions apply for 3-wire (3-phase plus ground) distributions; refer to
the specific section for details.
To ensure the circuit selectivity in case of Short- Circuit in the Load equipment, special care must be
taken in choosing the Fuse or Circuit Breaker ratings installed in the output distribution circuits.
Due to the relatively low short-circuit capability of the UPS Inverter, a short-circuit in the Load will cause
an immediate transfer to Utility.
The largest fuse in the output distribution should be at least 1.6 time smaller than the Fuses supplying
the Bypass line.
If circuit selectivity is required while the Load is fed from the Inverter (Bypass Utility not available), the
Largest Fuse or Circuit Breaker should be rated at no more than 20% of the UPS Output Current Rating.
NOTE !
The delivery and installation of fuses and input/output connections of the UPS are at
the customer’s expense, unless agreed otherwise.
Critical Power
Modifications reserved
Page 26/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.7.3 Data for Input/output and battery over current protection and wire sizing
NOTE !
• Please read the safety precautions at the front of this guide carefully, and
thoroughly review the battery manufacturers installation and maintenance
manual before connecting the batteries to the UPS.
• Remote battery cabinet is external and not provided with UPS.
• For Battery and AC input and output circuits the disconnect device is not
provided inside the UPS. It shall be part of the building installation.
• Protect Battery and AC input and output circuits with an appropriate UL489
Branch Circuit Protection (DC fuse or circuit breaker), using the current data in
the chart below.
• Minimum battery cable requirement is based on the current data below.
• The maximum available fault current from the battery supply is: 20kA.
• The minimum breaker voltage rating is 540V.
The AC values below are current ratings per phase.
These maximum and nominal ratings should be considered when choosing the appropriate AC
over current protection device.
NEC (National Electric Code) Section 210-20 (A) rules must be applied.
DC current rating is the nominal battery discharge current which the UPS allows.
(See Fig. 4.7.1-1 and 4.7.1.2)
UPS rating
AC Input Rectifier AC Input Bypass AC Input DC Input
F1
F2
F3
F4
Nom. Max. Nom. Max.
TLE Series 160 202 A 230 A 193 A 202 A 230 A 392 A
TLE Series 200 252 A 285 A 240 A 252 A 285 A 488 A
TLE Series 225 285 A 310 A 271 A 285 A 310 A 545 A
TLE Series 250 315 A 345 A 301 A 315 A 345 A 605 A
TLE Series 300 378 A 430 A 361 A 378 A 430 727 A
TLE Series 400 504 A 555 A 481 A 504 A 569 A 968 A
TLE Series 500 630 A 690 A 601 A 630 A 690 A 1210 A
Critical Power
Modifications reserved
Page 27/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Size of Branch Circuit Over Current Protection - All Models: - "CAUTION - To reduce the risk of fire,
only connect UPS to a circuit provided with (see below) maximum amperes branch circuit over
current protection in accordance with the NEC (National Electric Code), NSI / NFPA 70
UPS rating
F1 - AC Input Rectifier F2 -AC Input Bypass F3 - AC Input F4 - DC Input
80% Rated
100% Rated
80% Rated
100% Rated
80% Rated
100% Rated
80% Rated
100% Rated
TLE Series 160 300 A 250 A 250 A 200 A 300 A 250 A 400 A 400 A
TLE Series 200 350 A 300 A 300 A 250 A 350 A 300 A 500 A 500 A
TLE Series 225 400 A 350 A 350 A 300 A 400 A 350 A 600 A 600 A
TLE Series 250 450 A 350 A 400 A 350 A 450 A 350 A 600 A 600 A
TLE Series 300 600 A 450 A 500 A 400 A 600 A 450 A 800 A 800 A
TLE Series 400 700 A 600 A 600 A 500 A 700 A 600 A 1000 A 1000 A
TLE Series 500 900 A 700 A 800 A 700 A 900 A 700 A 1200 A 1200 A
WIRING
Wire sizing according to:
NEC Section 210-20 (A) Table 310-16.
Use 167°F (75°C) copper or aluminum wire.
Wiring requirements:
AC INPUT RECTIFIER: 3-Phase, 4 wire plus Ground
AC INPUT BYPASS: 3-Phase, 4 wire plus Ground
AC OUTPUT: 3-Phase, 4 wire plus Ground
DC INPUT: 2 wire (positive and negative) plus Ground
Maximum recommended cable size
UPS rating Rectifier Input Bypass Input DC Input AC Output GND
TLE Series 160 2 x 3/0 AWG 2 x 2/0 AWG 2 x 300 kcmil 2 x 2/0 AWG 1 x 3 AWG
TLE Series 200 2 x 4/0 AWG 2 x 3/0 AWG 2x 400 kcmil 2 x 3/0 AWG 1 x 2 AWG
TLE Series 225 2 x 300 kcmil 2 x 2/0 AWG 2 x 600 kcmil 2 x 2/0 AWG 1 x 1 AWG
TLE Series 250 2 x 350 kcmil 2 x 300 kcmil 2 x 600 kcmil 2 x 300 kcmil 1 x 1 AWG
TLE Series 300 3 x 300 kcmil 2x 400 kcmil 3 x 500 kcmil 2x 400 kcmil 1 x 1/0 AWG
TLE Series 400 4 x 4/0 AWG 4 x 3/0 AWG 4 x 400 kcmil 4 x 3/0 AWG 1 x 2/0 AWG
TLE Series 500 4 x 350 kcmil 4 x 300 kcmil 4 x 600 kcmil 4 x 300 kcmil 1 x 3/0 AWG
Critical Power
Modifications reserved
Page 28/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
NEC SECTION 210-20 (A)
Table 310-16. Allowable Ampacities of Insulated Conductors Rated O Through 2000 Volts, 140°F Trough
194°F (60°C Trough 90°C) Not More than Three Current-Carrying Conductors in Raceway, Cable, or Earth
(Directly Buried), Based on Ambient Temperature of 86°F (30°C).
Temperature Rating of Conductor (See table 310-13)
Size
140°F (60°C) 167°F (75°C) 194°F (90°C) 140°F (60°C) 167°F (75°C) 194°F (90°C)
AWG
or
kcmil
Types
TW, UF
Types
FEPW, RH, RHW,
THHW, THW,
THWN, XHHW,
USE, ZW
Types
TBS, SA, SIS, FEP,
FEPB, MI, RHH,
RHW-2, THHN,
THHW, THW-2,
THWN-2, USE-2,
XHH, XHHW,
XHHW-2,ZW-2
Types
TW, UF
Types
RH, RHW,
THHW,
THW, THWN,
XHHW, USE
Types
TBS, SA, SIS,
THHN, THHW,
THW-2,
THWN-2, RHH,
RHW-2, USE-2,
XHH, XHHW,
XHHW-2,
ZW-2
COPPER ALUMINUM or COPPER-CLAD ALUMINUM
18
---
---
14
---
---
---
16
---
---
18
---
---
---
14
20
20
25
---
---
---
12
25
25
30
20
20
25
10
30
35
40
25
30
35 8 40
50
55
30
40
45 6 55
65
75
40
50
60 4 70
85
95
55
65
75 3 85
100
110
65
75
85 2 95
115
130
75
90
100 1 110
130
150
85
100
115
1/0
125
150
170
100
120
135
2/0
145
175
195
115
135
150
3/0
165
200
225
130
155
175
4/0
195
230
260
150
180
205
250
215
255
290
170
205
230
300
240
285
320
190
230
255
350
260
310
350
210
250
280
400
280
335
380
225
270
305
500
320
380
430
260
310
350
600
355
420
475
285
340
385
700
385
460
520
310
375
420
750
400
475
535
320
385
435
800
410
490
555
330
395
450
900
435
520
585
355
425
480
1000
455
545
615
375
445
500
1250
495
590
665
405
485
545
1500
520
625
705
435
520
585
1750
545
650
735
455
545
615
2000
560
665
750
470
560
630
CORRECTION FACTORS
Ambient
Temperature
For ambient temperatures other than 86°F (30°C), multiply the allowable ampacities shown above by the
appropriate factor below
70 – 77°F (21 – 25°C)
1.08
1.05
1.04
1.08
1.05
1.04
79 – 86°F (26 - 30°C)
1.00
1.00
1.00
1.00
1.00
1.00
88 – 95°F (31 - 35°C)
0.91
0.94
0.96
0.91
0.94
0.96
97 – 104°F (36 - 40°C)
0.82
0.88
0.91
0.82
0.88
0.91
106 – 113°F (41 - 45°C)
0.71
0.82
0.87
0.71
0.82
0.87
115 – 122°F (46 - 50°C)
0.58
0.75
0.82
0.58
0.75
0.82
124 – 131°F (51 - 55°C)
0.41
0.67
0.76
0.41
0.67
0.76
Critical Power
Modifications reserved
Page 29/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.7.4 Installation requirements
Typical examples for the connection of the TLE Series 160 - 500.
Single UPS with Common Input Utility for Rectifier & Bypass
Single UPS with Common Input Utility for Rectifier & Bypass, 3-wire distribution (3-phase plus ground)
Single UPS with Dual Input Utility for Rectifier & Bypass
(
Connect a single input Neutral to Bypass Utility (inside the UPS, common Neutral for Bypass and
Rectifier)
Single UPS with Dual Input Utility for Rectifier & Bypass, 3-wire distribution (3-phase plus ground)
Critical Power
Modifications reserved
Page 30/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
UPS Parallel System with Common Input Utility Rectifier & Bypass
UPS Parallel System with Common Input Utility Rectifier & Bypass, 3-wire distribution (3-phase plus
ground)
Critical Power
Modifications reserved
Page 31/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
UPS Parallel System with Dual Input Utility for Rectifier & Bypass
(
Connect a single input Neutral to Bypass Utility (inside the UPS, common Neutral for Bypass and
Rectifier)
UPS Parallel System with Dual Input Utility for Rectifier & Bypass 3-wire distribution (3-phase plus
ground)
Critical Power
Modifications reserved
Page 32/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.8 WIRING CONNECTION
WARNING !
UPS installation and connection must be performed by a GE Service Technician only.
Refer to the “Safety prescriptions - Installation” described on Chapter 1.
In case of UPS equipped with options or customized parts not covered by this
manual, please consult the appropriate technical documentation before proceeding
with electrical connections.
Carefully read the following recommendations before proceeding:
• Ensure that the AC and DC external isolators are Off, and prevent their inadverted operation.
• Do not close any external isolators prior to the commissioning of the equipment.
• The input/output cables must be connected in clockwise phase rotation for both Bypass and
Rectifier Input Bars if separate, taking care to avoid risk of short circuit between different poles.
• The grounding and neutral connection of the electrical system must be in accordance with local
regulations.
• In case of additional cabinets containing batteries, input/ output transformers, etc, their ground
terminals must be connected to the UPS main ground terminal.
• Once the power cables have been connected, re-install the internal safety shields and close the
cabinets by re-installing all external panels.
TLE Series 160 - 200 - 225 - 250 Access to the bus bars for the cable connections
Fig. 4.8-1 TLE Series 160 - 200 - 225 - 250 Access to connection bus bars
To access Input, Output
and Battery connections
proceed as follows:
•
Remove the front
protection panel “A”.
• Bottom entry cables:
remove the plate “B”.
•
Top entry cables:
remove the plate “C”.
NOTE !
For UPS correct operation, the input utility phase rotation must be clockwise.
A
B
Utility mains / Battery / Output load
Bottom entry cables
TLES_UL_225-250_S1_UPS connection_01US-a
Utility mains / Battery / Output load
Top entry cables
Please remove the plates (B & C)
before drilling any wholes
Q1
I ON
0 OFF
1
2
EPO
EPO
-
+
C
Critical Power
Modifications reserved
Page 33/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
TLE Series 300 - 400 - 500 Access to the bus bars for the cable connections
Fig. 4.8-2 TLE Series 300 - 400 - 500 Access to connection bus bars
To access Input, Output and Battery connections
proceed as follows:
• Remove the front protection panel “A”.
• Bottom entry cables: remove the plate “B”.
• Top entry cables: remove the plate “C”.
NOTE !
For UPS correct
operation, the input
utility phase rotation
must be clock-wise.
CAUTION !
Panel “A, B and C” should never be removed or replaced with power applied to the
UPS.
These panels are in close proximity to 480V live buss bars.
Always disconnect the rectifier, bypass, load and battery sources from the UPS
before removing or replacing these panels.
If not serious injury or death could occur!
Q1
I ON
0 OFF
A
B
C
Utility mains / Battery / Output load
Bottom entry cables
TLES_UL_400-500_S2_UPS connection_01US-a
1
2
EPO
EPO
-
+
Utility mains / Battery / Output load
Top entry cables
Please remove
the plates (B & C) before
drilling any wholes
Critical Power
Modifications reserved
Page 34/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
TLE Series 300 - 400 - 500
Connection bus bars configuration for the top cable entry or bottom cable entry
The configuration of the TLE Series 300 - 400 - 500 is with top cable entry as standard (see Fig. 4.8-3).
It is possible to configure the bus bars with bottom cable entry (see Fig. 4.8-4).
Fig. 4.8-3 TLE Series 300 - 400 - 500 Configuration bus bars with top cable entry (standard)
Fig. 4.8-4 TLE Series 300 - 400 - 500 Configuration bus bars with bottom cable entry
Q1
TLES_UL_400-500_S1_UPS connection_Top_01US-a
Utility mains / Battery
Output load
Position of the cover protection for
cables input from the bottom of the UPS
+
-
PE
L3-1
L2-1
L1-1
N
Utility Neutral
Load Neutral
Load
1
Rectifier &
Bypass
Utility
BR2
BR3
BR1
PE
PE Input Utility & PE Load
(Use for top entry cables)
L3
L2
L1
PE
PE Input Utility
PE Load
Attention:
Use only as additional PE
Q1
TLES_UL_400-500_S1_UPS connection_Bottom_01US-a
Position of the cover protection for
cables input from th e bottom of the UPS
Utility mains / Battery
Output load
+
-
L3
L2
PE
L3-1
L2-1
L1-1
(use for bottom entry cables)
PE Input Utility & PE Load
N
Utility Neutral
Load Neutral
Load
L1
1
Rectifier &
Bypass
Utility
BR2
BR3
BR1
PE
Load
(L3 - L2 - L1)
1 - Rectifier & Bypass Utility
(L3-1 - L2-1 - L1-1)
(use for top entry cables)
PE Input Utility & PE Load
PE
PE Input Utility
PE Load
Attention:
Use only as additional PE
Critical Power
Modifications reserved
Page 35/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.8.1 TLE Series 160 - 200 - 225 - 250 Power connection with Common Input Utility
Fig. 4.8.1-1 TLE Series 160 - 200 - 225 - 250 Power connection with Common Input Utility
Power connection cables are connected to bus bars using M10 bolts.
The bolts of the connection cables must be tightened with a torque wrench at 355 Lb-in / 40 Nm.
Common Input Utility - Rectifier / Bypass
L1-1
Rectifier + Bypass Phase A (L1)
L2-1
Rectifier + Bypass Phase B (L2)
N
Neutral
L3-1
Rectifier + Bypass Phase C (L3)
PE
Ground
NOTE !
The interconnection links BR1, BR2 and BR3 on the input bus bars MUST REMAIN
CONNECTED.
Output Load
L1
Load phase A (L1)
L2
Load phase B (L2)
L3
Load phase L3
N
Neutral
Ground
External Battery connection
+ Positive pole of the battery
Before closing the “External Battery Fuses”, verify
for correct polarity of the battery connection.
- Negative pole of the battery
PE Battery cabinet ground
NOTE !
To meet standards concerning electromagnetic compliance, the connection between the
UPS and external Battery must be done by using a shielded cable or suitable shielded (steel)
conduit!
+
-
Typical installation
using common NEMA
two hole lugs
PE
TLES_UL_225-250_S1_UPS connection commo n_01US
1
Rectifier & Bypass
Utility
L1-1
N
Utility Neutral
Load Neutral
Load
L1
L2-1
L2
L3-1
L3
INTERCONNECTIONS LINKS
BR1, BR2 and BR3
MUST REMAIN CONNECTED
Critical Power
Modifications reserved
Page 36/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
NOTE !
This UPS is only designed to operate in a wye-configured electrical system with a
solidly grounded neutral.
The UPS cannot be operated from a mid-point or end-point grounded delta
supply source.
If the UPS is equipped with an input bypass transformer, the secondary of the
transformer must be wye-configured with neutral solidly grounded.
If the Load requires a Neutral, a Bypass Source Neutral MUST BE PROVIDED.
If no Neutral Connection is available with the Bypass Input (3-wire input + ground) and the Load does
not require a Neutral, solidly connect the Output Neutral of the UPS to ground with a ground
bonding jumper.
For single module applications install the ground bonding jumper directly at the UPS output.
Cable size for this connection shall be per National Electric Code and applicable local regulations,
but not less than AWG 1.
ATTENTION !
With this configuration, Load can only be connected phase-phase.
Absolutely no Load Connection permitted to the output Neutral.
DO NOT install both a source Neutral and a bonding jumper!
In a Parallel System configuration, the output
distribution cabinet must contain a Neutral Bus
as per the following Figure 4.8.1-2.
If no Neutral Connection is available with the
Bypass Input (3-wire input + ground) and the
Load does not require a Neutral, solidly connect
the Output Neutral of the UPS to ground in the
Output Distribution Cabinet.
Wire Neutral Conductors from the UPS to the
output distribution cabinet (common point of
connection) and solidly connect to ground with a
ground bonding jumper.
Fig. 4.8.1-2 RPA Parallel System
Cable size for the ground bonding jumper shall be per National Electric Code and applicable local
regulations, but not less than AWG 1.
Please consider the following when applying Ground Fault Circuit Interrupters (GFCIs) in 3-wire
distribution:
• During transfers to and from bypass, circulating current may flow between the two AC sources
(UPS inverter and bypass utility). In 3-wire distribution the current flows through the ground
path. In order to prevent tripping in such circumstances, proper adjustment of the GFCI is
required. Particularly, the time delay should be set to at least 300ms.
• With the Neutral to ground bonding jumper installed, the UPS ground current has been verified
to be less than or equal to 5% of the maximum rated input current of the unit in compliance
with international safety regulations. This shall be accounted for in GFCIs settings
NOTE !
Failure to properly adjust the GFCI settings could compromise the power delivery
to the critical load.
Critical Power
Modifications reserved
Page 37/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.8.2 TLE Series 160 - 200 - 225 - 250 Power connection with Dual Input Utility
NOTE !
Connect a single input Neutral to Bypass Utility (inside the UPS, common Neutral
for Bypass and Rectifier).
Fig. 4.8.2-1 TLE Series 160 - 200 - 225 - 250 Power connection with Dual Input Utility
Power connection cables are connected to bus bars using M10 bolts.
The bolts of the connection cables must be tightened with a torque wrench at 355 Lb-in / 40 Nm.
Dual Input Utility - Rectifier / Bypass
L1-1
Rectifier phase A (L1)
L1-2
Bypass phase A (L1)
L2-1
Rectifier phase B (L2)
L2-2
Bypass phase B (L2)
L3-1
Rectifier phase C (L3)
L3-2
Bypass phase C (L3)
PE
Ground
N
Neutral
NOTE !
The interconnection links BR1, BR2 and BR3 on the input bus bars MUST BE
REMOVED (see Fig. 4.8.2-3).
Output Load
L1
Load phase A (L1)
L2
Load phase B (L2)
L3
Load phase L3
N
Neutral
Ground
External Battery connection
+ Positive pole of the battery
Before closing the “External Battery Fuses”, verify
for correct polarity of the battery connection.
- Negative pole of the battery
PE Battery cabinet ground
NOTE !
To meet standards concerning electromagnetic compliance, the connection between the
UPS and external Battery must be done by using a shielded cable or suitable shielded (steel)
conduit!
+
-
Typical installation
using common NEMA
two hole lugs
PE
TLES_UL_225-250_S1_UPS connection separate_01US
1
Rectifier
Utility
L1-1
N
Utility Neutral
Load Neutral
2
Bypass
Utility
L1-2
Load
L1
L2-1
L2-2
L2
L3-1
L3-2
L3
INTERCONNECTIONS LINKS
BR1, BR2 and BR3
MUST BE REMOVED
(see Fig. 4.8.2-3)
Critical Power
Modifications reserved
Page 38/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
NOTE !
This UPS is only designed to operate in a wye-configured electrical system with a
solidly grounded neutral.
The UPS cannot be operated from a mid-point or end-point grounded delta
supply source.
If the UPS is equipped with an input bypass transformer, the secondary of the
transformer must be wye-configured with neutral solidly grounded.
If the Load requires a Neutral, a Bypass Source Neutral MUST BE PROVIDED.
If no Neutral Connection is available with the Bypass Input (3-wire input + ground) and the Load does
not require a Neutral, solidly connect the Output Neutral of the UPS to ground with a ground
bonding jumper.
For single module applications install the ground bonding jumper directly at the UPS output.
Cable size for this connection shall be per National Electric Code and applicable local regulations,
but not less than AWG 1.
ATTENTION !
With this configuration, Load can only be connected phase-phase.
Absolutely no Load Connection permitted to the output Neutral.
DO NOT install both a source Neutral and a bonding jumper!
In a Parallel System configuration, the output
distribution cabinet must contain a Neutral Bus
as per the following Figure 4.8.2-2.
If no Neutral Connection is available with the
Bypass Input (3-wire input + ground) and the
Load does not require a Neutral, solidly connect
the Output Neutral of the UPS to ground in the
Output Distribution Cabinet.
Wire Neutral Conductors from the UPS to the
output distribution cabinet (common point of
connection) and solidly connect to ground with a
ground bonding jumper.
Fig. 4.8.2-2 RPA Parallel System
Cable size for the ground bonding jumper shall be per National Electric Code and applicable local
regulations, but not less than AWG 1.
Please consider the following when applying Ground Fault Circuit Interrupters (GFCIs) in 3-wire
distribution:
• During transfers to and from bypass, circulating current may flow between the two AC sources
(UPS inverter and bypass utility). In 3-wire distribution the current flows through the ground
path. In order to prevent tripping in such circumstances, proper adjustment of the GFCI is
required. Particularly, the time delay should be set to at least 300ms.
• With the Neutral to ground bonding jumper installed, the UPS ground current has been verified
to be less than or equal to 5% of the maximum rated input current of the unit in compliance
with international safety regulations. This shall be accounted for in GFCIs settings
NOTE !
Failure to properly adjust the GFCI settings could compromise the power delivery
to the critical load.
Critical Power
Modifications reserved
Page 39/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Installation notices in case of power connection with Dual Input Utility
Fig. 4.8.2-3 TLE Series 300 - 400 - 500 Interconnection links BR1, BR2 and BR3
NOTE !
For separate Bypass and Rectifier input configuration, the interconnection links
BR1, BR2 and BR3 MUST BE REMOVED (see Fig. 4.8.2-3).
Q1
TLES_UL_225-250_S1_UPS BR1-2-3_01US-a
Q1
I ON
0 OFF
12
EPO
EPO
-
+
36
BR1
(3x20x1mm / L=220mm)
36
37
BR2
(3x20x1mm / L=220mm)
37
38
BR3
(3x20x1mm / L=220mm)
38
BR1
BR3
BR1, BR2 and BR3
MUST BE REMOVED
BR2
Critical Power
Modifications reserved
Page 40/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.8.3 TLE Series 300 - 400 - 500 Power connection with Common Input Utility
Fig. 4.8.3-1 TLE Series 160 - 200 - 225 - 250 Power connection with Common Input Utility
Power connection cables are connected to bus bars using M10 bolts.
The bolts of the connection cables must be tightened with a torque wrench at 355 Lb-in / 40 Nm.
Common Input Utility - Rectifier / Bypass
L1-1
Rectifier + Bypass Phase A (L1)
L2-1
Rectifier + Bypass Phase B (L2)
N
Neutral
L3-1
Rectifier + Bypass Phase C (L3)
PE
Ground
NOTE !
The interconnection links BR1, BR2 and BR3 on the input bus bars MUST REMAIN
CONNECTED.
Output Load
L1
Load phase A (L1)
L2
Load phase B (L2)
L3
Load phase L3
N
Neutral
Ground
External Battery connection
+ Positive pole of the battery
Before closing the “External Battery Fuses”, verify
for correct polarity of the battery connection.
- Negative pole of the battery
PE Battery cabinet ground
NOTE !
To meet standards concerning electromagnetic compliance, the connection between the
UPS and external Battery must be done by using a shielded cable or suitable shielded (steel)
conduit!
INTERCONNECTIONS LINKS
BR1, BR2 and BR3
MUST REMAIN CONNECTED
Q1
TLES_UL_400-500_S1_UPS connection common_01US-a
+
-
PE
PE
N
Utility Neutral
Load Neutral
Typical installation
using common NEMA
two hole lugs
Load
Typical installation using
common NEMA two hole lugs
PE
PE
(Use for top entry cables)
L3
L2
L1
L3-1
L2-1
L1-1
1
Rectifier &
Bypass
Utility
BR2
BR3
BR1
(Use for bottom entry cables)
PE
Attention:
Use only as additional PE
Position of the cover protection
with top cable entry
Position of the
cover protection with
bottom cable entry
Critical Power
Modifications reserved
Page 41/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
NOTE !
This UPS is only designed to operate in a wye-configured electrical system with a
solidly grounded neutral.
The UPS cannot be operated from a mid-point or end-point grounded delta
supply source.
If the UPS is equipped with an input bypass transformer, the secondary of the
transformer must be wye-configured with neutral solidly grounded.
If the Load requires a Neutral, a Bypass Source Neutral MUST BE PROVIDED.
If no Neutral Connection is available with the Bypass Input (3-wire input + ground) and the Load does
not require a Neutral, solidly connect the Output Neutral of the UPS to ground with a ground
bonding jumper.
For single module applications install the ground bonding jumper directly at the UPS output.
Cable size for this connection shall be per National Electric Code and applicable local regulations,
but not less than AWG 3/0.
ATTENTION !
With this configuration, Load can only be connected phase-phase.
Absolutely no Load Connection permitted to the output Neutral.
DO NOT install both a source Neutral and a bonding jumper!
In a Parallel System configuration, the output
distribution cabinet must contain a Neutral Bus
as per the following Figure 4.8.3-2.
If no Neutral Connection is available with the
Bypass Input (3-wire input + ground) and the
Load does not require a Neutral, solidly connect
the Output Neutral of the UPS to ground in the
Output Distribution Cabinet.
Wire Neutral Conductors from the UPS to the
output distribution cabinet (common point of
connection) and solidly connect to ground with a
ground bonding jumper.
Fig. 4.8.3-2 RPA Parallel System
Cable size for the ground bonding jumper shall be per National Electric Code and applicable local
regulations, but not less than AWG 3/0.
Please consider the following when applying Ground Fault Circuit Interrupters (GFCIs) in 3-wire
distribution:
• During transfers to and from bypass, circulating current may flow between the two AC sources
(UPS inverter and bypass utility). In 3-wire distribution the current flows through the ground
path. In order to prevent tripping in such circumstances, proper adjustment of the GFCI is
required. Particularly, the time delay should be set to at least 300ms.
• With the Neutral to ground bonding jumper installed, the UPS ground current has been verified
to be less than or equal to 5% of the maximum rated input current of the unit in compliance
with international safety regulations. This shall be accounted for in GFCIs settings
NOTE !
Failure to properly adjust the GFCI settings could compromise the power delivery
to the critical load.
Critical Power
Modifications reserved
Page 42/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.8.4 TLE Series 300 - 400 - 500 Power connection with Dual Input Utility
NOTE !
Connect a single input Neutral to Bypass Utility (inside the UPS, common Neutral
for Bypass and Rectifier).
Fig. 4.8.4-1 TLE Series 300 - 400 - 500 Power connection with Dual Input Utility
Power connection cables are connected to bus bars using M10 bolts.
The bolts of the connection cables must be tightened with a torque wrench at 355 Lb-in / 40 Nm.
Dual Input Utility - Rectifier / Bypass
L1-1
Rectifier phase A (L1)
L1-2
Bypass phase A (L1)
L2-1
Rectifier phase B (L2)
L2-2
Bypass phase B (L2)
L3-1
Rectifier phase C (L3)
L3-2
Bypass phase C (L3)
PE
Ground
N
Neutral
NOTE !
The interconnection links BR1, BR2 and BR3 on the input bus bars MUST BE
REMOVED (see Fig. 4.8.4-3).
Output Load
L1
Load phase A (L1)
L2
Load phase B (L2)
L3
Load phase L3
N
Neutral
Ground
External Battery connection
+ Positive pole of the battery
Before closing the “External Battery Fuses”, verify
for correct polarity of the battery connection.
- Negative pole of the battery
PE Battery cabinet ground
NOTE !
To meet standards concerning electromagnetic compliance, the connection between the
UPS and external Battery must be done by using a shielded cable or suitable shielded (steel)
conduit!
+
-
PE
L3-1
L1-2
L2-2
(use for bottom cable entry)
PE
N
Utility Neutral
Load Neutral
Typical installation
using common NEMA
two hole lugs
L3-2
Load
INTERCONNECTIONS LINKS
BR1, BR2 and BR3
MUST BE REMOVED
(see Fig. 4.8.4-3)
2 - Bypass
Utility
1
Rectifier
Utility
Typical installation using
common NEMA two hole lugs
PE
PE
(use for top cable entry)
L3
L2
L1
Q1
TLES_UL_400-500_S1_UPS connect ion separate_01US-a
L2-1
L1-1
Position of the cover protection
with top cable entry
PE
Attention:
Use only as additional PE
Position of the
cover protection with
bottom cable entry
Critical Power
Modifications reserved
Page 43/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
NOTE !
This UPS is only designed to operate in a wye-configured electrical system with a
solidly grounded neutral.
The UPS cannot be operated from a mid-point or end-point grounded delta
supply source.
If the UPS is equipped with an input bypass transformer, the secondary of the
transformer must be wye-configured with neutral solidly grounded.
If the Load requires a Neutral, a Bypass Source Neutral MUST BE PROVIDED.
If no Neutral Connection is available with the Bypass Input (3-wire input + ground) and the Load does
not require a Neutral, solidly connect the Output Neutral of the UPS to ground with a ground
bonding jumper.
For single module applications install the ground bonding jumper directly at the UPS output.
Cable size for this connection shall be per National Electric Code and applicable local regulations,
but not less than AWG 3/0.
ATTENTION !
With this configuration, Load can only be connected phase-phase.
Absolutely no Load Connection permitted to the output Neutral.
DO NOT install both a source Neutral and a bonding jumper!
In a Parallel System configuration, the output
distribution cabinet must contain a Neutral Bus
as per the following Figure 4.8.4-2.
If no Neutral Connection is available with the
Bypass Input (3-wire input + ground) and the
Load does not require a Neutral, solidly connect
the Output Neutral of the UPS to ground in the
Output Distribution Cabinet.
Wire Neutral Conductors from the UPS to the
output distribution cabinet (common point of
connection) and solidly connect to ground with a
ground bonding jumper.
Fig. 4.8.4-2 RPA Parallel System
Cable size for the ground bonding jumper shall be per National Electric Code and applicable local
regulations, but not less than AWG 3/0.
Please consider the following when applying Ground Fault Circuit Interrupters (GFCIs) in 3-wire
distribution:
• During transfers to and from bypass, circulating current may flow between the two AC sources
(UPS inverter and bypass utility). In 3-wire distribution the current flows through the ground
path. In order to prevent tripping in such circumstances, proper adjustment of the GFCI is
required. Particularly, the time delay should be set to at least 300ms.
• With the Neutral to ground bonding jumper installed, the UPS ground current has been verified
to be less than or equal to 5% of the maximum rated input current of the unit in compliance
with international safety regulations. This shall be accounted for in GFCIs settings
NOTE !
Failure to properly adjust the GFCI settings could compromise the power delivery
to the critical load.
Critical Power
Modifications reserved
Page 44/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Installation notices in case of power connection with Dual Input Utility
Fig. 4.8.4-3 TLE Series 300 - 400 - 500 Interconnection links BR1, BR2 and BR3
NOTE !
For separate Bypass and Rectifier input configuration, the interconnection links
BR1, BR2 and BR3 MUST BE REMOVED (see Fig. 4.8.4-3).
+
-
PE
L3-1
L1-2
L2-2
(with bottom cable entry)
PE
N
Utility Neutral
Load Neutral
L3-2
Load
2 - Bypass Utility
1
Rectifier
Utility
PE
PE
(with top cable entry)
L3
L2
L1
Q1
TLES_UL_400-500_S1_UPS BR1-2-3_01US-a
L2-1
L1-1
BR1, BR2 and BR3
MUST BE REMOVED
BR1
BR2
BR3
PE
Attention:
Use only as
additional PE
36
37
38
38
37
36
Critical Power
Modifications reserved
Page 45/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.8.5 Use of TLE Series 160 - 500 in eBoost™ Operation Mode
NOTE !
For systems intended to be operated in eBoost™ Operation Mode, the installation
shall be protected with suitable surge protection devices (SPDs) on the AC bus
feeding the UPSs.
Please contact your GE Service Center for more information.
NOTE !
In eBoostTM Operation Mode the inverter output filter is placed in parallel with the
load, and combined with the load current it contributes to the UPS input
characteristic.
As the inverter output filter exhibits a predominantly capacitive characteristic, it
may provide some degree of reactive power compensation when combined with
lagging power factor loads.
Conversely, depending on the load type and level, the UPS input characteristic
may exhibit a leading power factor in eBoostTM Operation Mode.
Please contact your GE Service Center for more information.
NOTE !
If an emergency generator set supplies the UPS in case of Utility Failure, and the
system is intended to be operated in eBoost™ Operation Mode, eBoost operation
shall be prevented during generator operation.
This can be accomplished by either installing a “GENERATOR ON” signal (refer to
Section 5.2.5) or an “eBoost/IEMi CONTROL” signal (refer to Section 5.2.7).
Please contact your GE Service Center for more information.
Critical Power
Modifications reserved
Page 46/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.8.6 Use of TLE Series 160 - 500 as frequency converter
NOTE !
The UPS needs the connection of the Neutral at the input Bus Bars.
Permanently running the UPS without bypass supply requires a change of
internal wiring to be performed by a GE Service Technician only.
When the TLE Series 160 - 500 is utilized for different output frequency compared to the input
frequency, the Automatic Bypass function is disabled, therefore the Load cannot be transferred to Utility
in case of overload, short circuit, or inverter failure.
In situations where the UPS needs to be powered down for maintenance purposes, the critical Load
must also be powered down during this time.
When the set-up parameters of the UPS are set for frequency converter, the eBoost™ Operation Mode
is automatically disabled.
Fig. 4.8.6-1 TLE Series 160 - 200 - 225 - 250
Interconnection links BR1, BR2 and BR3
Fig. 4.8.6-2 TLE Series 300 - 400 - 500
Interconnection links BR1, BR2 and BR3
In order to avoid improper operation, only the Rectifier input should be powered (L1-1, L2-1 and L3-1
/ Fig. 4.8.2-1 & 4.8.4.1), therefore the interconnection links BR1, BR2 and BR3, on the input bus bars,
MUST BE REMOVED. See pictures above and Fig. 4.8.2-3 and 4.8.4-3.
Special care must be taken in choosing the fuse ratings installed in the output distribution (max.
20% of the UPS rated current).
Avoid high inrush current due to transformer magnetization or motor starting.
NOTE !
Only a GE SERVICE TECHNICIAN may change a unit from frequency converter into
a normal UPS (with bypass) or a normal UPS to a Frequency Converter (with
bypass).
Q1
TLES_UL_225-250_S1_UPS BR1-2-3_01US-a
Q1
I ON
0 OFF
12
EPO
EPO
-
+
36
BR1
(3x20x1mm / L=220mm)
36
37
BR2
(3x20x1mm / L=220mm)
37
38
BR3
(3x20x1mm / L=220mm)
38
BR1
BR3
BR1, BR2 and BR3
MUST BE REMOVED
BR2
+
-
PE
L3-1
L1-2
L2-2
(with bottom cable entry)
PE
N
Utility Neutral
Load Neutral
L3-2
Load
2 - Bypass Utility
1
Rectifier
Utility
PE
PE
(with top cable entry)
L3
L2
L1
Q1
TLES_UL_400-500_S1_UPS BR1-2-3_01US-a
L2-1
L1-1
BR1, BR2 and BR3
MUST BE REMOVED
BR1
BR2
BR3
PE
Attention:
Use only as
additional PE
36
37
38
38
37
36
Critical Power
Modifications reserved
Page 47/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.9 RPA PARALLEL SYSTEM CONNECTION
WARNING !
This operation must be performed by a GE SERVICE TECHNICIAN before the initial
start-up (ensure that the UPS installation is completely POWERED DOWN).
4.9.1 Power wiring of parallel units
To guarantee good Load sharing between the units of a Parallel System, we recommend that the cable
length from the input distribution board (5) to the output distribution board (9) is equal for each unit (a+b
= c+d = e+f = g+h = i+l = m+n = o+p = q+r).
Tolerance: +/-10%.
The AC input power of the Bypass must be the same for all units of the Parallel System - no phase shift
allowed between units.
NOTE !
It is strongly recommended that no transformers, automatic circuit breakers or
fuses should be inserted between the unit’s output and the Load common bus bars.
However, it is recommended that a disconnection or isolation switch is installed in
order to totally isolate a unit if needed.
Verify that power wiring and control wiring run in separate conduits or cable trays.
The power wiring requires two separate conduits: one for input and one for output cables.
Fig. 4.9.1-1 Power wiring of RPA Parallel System
1
=
Rectifier
2 =
Inverter
3 =
Automatic Bypass
4 =
Input Utility Distribution
5 =
Unit Output Load
6 = External Battery MCCB
7 = External Battery
8 =
Common bus bar and
Output Load Distribution
=
UPS number 1
= UPS number 2
= UPS number 3
= UPS number 4
= UPS number 5
= UPS number 6
Critical Power
Modifications reserved
Page 48/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.9.2 Parallel control bus connection
In case of Parallel System, the communication between the units takes place through the Control Bus
Cables.
Each Parallel Unit contains the two boards “P13/P14 – IM0022 – Bus Interface Board” (mounted on top
of the board “P12 – IM0196 – RPA Board”) on which four connectors J1A - J2A and J1B - J2B are
allocated.
All the parallel units are connected to the same control bus.
This connection allows:
• The microprocessors of each unit to communicate with each other.
• The oscillators of each unit to be locked together.
• The regulation loops to compare the output current of each unit in order to equally share the Load
current.
For increased reliability, this connection is made with redundant cables.
In this way, communication is maintained between units in case one of the control cables should fail or
be accidentally damaged or disconnected.
The standard length of the control bus cable between two parallel units is 40 ft / 12m.
The maximal overall length of bus connection, between the first and the last unit, should not exceed 295
ft / 90m.
Verify that control wiring run in an individual separate steel conduit.
NOTE !
Under no circumstance should the control bus cable connecting J1A - J2A (1/2/3/4/5)
and J1B - J2B (1/2/3/4/5) be connected or disconnected after the system has been
powered On.
Fig. 4.9.2-1 RPA System - Control bus connection
It is important to place the units in sequence of their assigned number.
A unit number from 1 to 6 is defined by the setting of parameters and displayed on the panel (1 to 6).
This number is also marked inside and outside the packaging.
J2
J1
J2
J1
B
A
J1A/1
J1B/1
J2
J1
J2
J1
J1A/1
J1B/2÷5
J1B/1
J1A/2÷5
J1A/1 + J1B/1
J2
J1
J2
J1
J1B/5
J1A/5 + J1B/5
J1A/5
UPS 1
UPS 2/3/4/5
UPS 6
TLES_160-400_S1_RPA-IM0222_01GB
B
A
B
A
Critical Power
Modifications reserved
Page 49/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Fig. 4.9.2-2 Bus connection on first and last units
Final units, first and last, of a RPA Parallel System
On the two boards P13/P14 – IM0022 – Bus Interface Board, of the first and last units of a Parallel
System, the switches SW1-1/2/3/4/5/6 MUST BE IN POSITION ON (see Fig. 4.9.2-2).
Fig. 4.9.2-3 Bus connection on intermediate units
Intermediate units of a RPA Parallel System
On the two boards P13/P14 – IM0022 – Bus Interface Board, of the intermediate units of a Parallel
System, the switches SW1-1/2/3/4/5/6 MUST BE IN POSITION OFF (see Fig. 4.9.2-3).
J2
J1
J2
J1
B
A
J1A/1
J1B/1
1
2
3
SW1
4
5
6
ON
TLES_160-400_S1_RPA-IM0222_02
J2
J1
J2
J1
B
A
J1A/1
J1B/2÷5
J1B/1
J1A/2÷5
1
2
3
4
5
6
ON
SW1
TLES_160-400_S1_RPA-IM0222_03
Critical Power
Modifications reserved
Page 50/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.9.3 Control bus cable location
WARNING !
This installation must be verified by trained personnel before the initial start-up.
ENSURE THAT THE UPS INSTALLATION IS COMPLETELY POWERED DOWN.
Keep SELV cables separated from HIGH VOLTAGE cables.
Fig. 4.9.3-1 TLE Series 160 - 200 - 225 - 250
View electronic module on intermediate unit
Fig. 4.9.3-2 TLE Series 300 - 400 - 500
View electronic module on intermediate unit
Access to the control bus connection
The communication bus cable connectors are placed on the two boards “P13/P14 – IM0022 – Bus
Interface Board” (see Fig. 4.9.3-1 and 4.9.3-2).
Fig. 4.9.3-3 View electronic module on intermediate unit
Control bus cables connection
• Plug the cables J1A – J2A (1/2/3/4/5) and J1B –
J2B (1/2/3/4/5) on the connectors J1A – J2A and
J1B – J2B placed on the two boards “P13/P14 –
IM0022 – Bus Interface Board”.
• Fix the communication bus cables J1A – J2A
(1/2/3/4/5) and J1B – J2B (1/2/3/4/5) with the
provided cable clamps “A”.
TLES_UL_225-250_S1_RPA connection_01a
Q1
I ON
0 OFF
1
2
EPO
EPO
-
+
TLES_UL_400-500_S2_RPA connection_01a
Q1
1
2
I ON
0 OFF
EPO
EPO
-
+
J2
J1
J2
J1
B
A
J1A/1
J1B/2÷5
J1B/1
J1A/2÷5
-
+
EPO
EPO
TLES_160-400_S1_RPA connection_02
Critical Power
Modifications reserved
Page 51/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
Fig. 4.9.3-4 TLE Series 160 - 200 - 225 - 250 Control Bus cable routing and connection
Fig. 4.9.3-5 TLE Series 300 - 400 - 500 Control Bus cable routing and connection
Control bus cables routing
Place and fix the cables J1A – J2A (1/2/3/4/5) and J1B – J2B (1/2/3/4/5) inside the UPS cabinets in
the position illustrated in the drawing Fig. 4.9.3-4 and 4.9.3-5.
NOTE !
Pay attention when cabling and routing the communication bus cables J1A – J2A
(1/2/3/4/5) and J1B – J2B (1/2/3/4/5) inside the UPS cabinet.
In case one unit must be removed from the Parallel System, the communication
bus cables must be taken out the UPS cabinet WITHOUT DISCONNECTING THEM
from the two boards “P13/P14 – IM0022 – Bus Interface Board”.
For reliability reasons the cables J1A – J2A (1/2/3/4/5) and J1B – J2B (1/2/3/4/5) connecting the units
should be run in separated protected conduits (as indicated in Fig. 4.9.3-4 and 4.9.3-5) separated
from the power cables.
It is important that the cable J1A – J2A (1/2/3/4/5) must be the same length as cable J1B – J2B
(1/2/3/4/5).
WARNING !
Connection and commissioning of an additional UPS to an existing Parallel System
must be performed by a service engineer from of your GE Service Center.
TLES_UL_225-250_S1_RPA connection_03US-a
Q1
I ON
0 OFF
1
2
EPO
EPO
-
+
1
2
EPO
EPO
-
+
J1B/1
J1A/1
UPS 1
J2
J1
J2
J1
B
A
J1A/1
J1B/2÷5
J1B/1
J1A/2÷5
UPS 2/3/4/5
J2
J1
J2
J1
B
A
J1A/1
J1B/1
UPS 1
J1A/2÷5
UPS 3, 4, 5, 6
J1B/2÷5
Q1
I ON
0 OFF
UPS 3, 4, 5, 6
J1B/2÷5
J1A/2÷5
J2
J1
J2
J1
A
B
J1B/1
J1A/2÷5
J1A/1
J1B/2÷5
UPS 2/3/4/5
J1B/1
J1A/1
J2
J1
J2
J1
A
B
J1B/1
J1A/1
UPS 1
UPS 1
TLES_UL_400-500_S2_RPA connection_03US-a
Q1
12
I ON
0 OFF
EPO
EPO
-
+
Q1
1
2
I ON
0 OFF
EPO
EPO
-
+
UPS 2
Critical Power
Modifications reserved
Page 52/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
4.10 “EPO - EMERGENCY POWER OFF” COMMAND CONNECTION
WARNING !
The connection of an emergency button “EPO - Emergency Power Off” must be
performed by a GE Service Technician only when the UPS is COMPLETELY POWERED
DOWN.
BE AWARE !
The reliability of the system depends on this contact NC (Normally Closed)!
An Emergency button (Normally Closed voltage-free contact) can be connected on terminals XA /
EPO-1, EPO-2. Max. rating XA terminals: 2.5mm2 (AWG/kcmil 14).
Fig. 4.10-1 XA terminal block for “EPO - Emergency Power Off” command connection
When opened, this contact causes
the immediate opening of the
Contactors K6 and K7 as well as
the shut-down of Rectifier, Inverter
and Static-Switch.
NOTE !
This procedure could imply a Load shut-down.
Keep SELV cables separated from
HIGH
VOLTAGE cables.
In a Parallel System a separate NC (Normally Closed) contact must be
connected individually to each unit.
Fig. 4.11-2 XA “EPO - Emergency Power Off” – RPA Parallel System connection schematics
TLES_UL_225-750_S1_Customer interface-XA_01
Customer Interface
1
12
13
14
15
16
17
18
19
20
21
22
2
3
4
5
6
7
8
9
10
11
XA
EPO
EPO
+
-
SGSE_400-500_S3_Terminals XA_01
XA
EPO
EPO
+
-
TLES_UL_400-500_S1_UPS_EPO-RPA connection schematic_GE_01
1
2
-
+
XA
EPO
EPO
+
-
1
2
-
+
EPO
EPO
+
-
1
2
-
+
EPO
EPO
+
-
XA
XA
EPO
Critical Power
Modifications reserved
Page 53/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
NOTE !
To operationalize this function, in case that the UPS was provided with one or
more cards “P4 - Customer Interface” (max. 3 - see Chapter 5), there must be on
each card the following:
- Remove the cable short-circuiting terminals X2 / 1, 2 (see Fig. 4.10-3).
- Remove the Jumper JP2 (see Fig. 4.10-3).
Fig. 4.10-3 X2 terminal block and Jumper JP2 on the P4 – Customer Interface Board
When the “EPO - Emergency Power Off” has been activated, the system must be restored as
follows:
• Realize the push-button “EPO - Emergency Power Off” (contact on
XA / EPO-1, EPO-
2 is closed
again).
• Perform the “Inverter OFF” command from the screen:
Commands 1 / Inverter / OFF.
(see User Manual to Section 6.5).
In case of a Parallel System perform the “Inverter OFF” command from the
screen: “Commands 1 / Inverter / OFF” of each unit connected on the Parallel
Bus and having its output switch Q1 closed.
TLES_UL_225-750_S1_Customer interface-X2 EPO_01.
16
15
4
19
18
17
20
9
8
7
6
5
14
13
12
3
2
1
22
11
21
10
X2
X1
X2
J1
JP2
1 2
8
19 21 2220
10 119
17 181615
7654
12 1413
321
X1
X2
J1
SE_400-500_S1_Customer interface-JP2_01
Critical Power
Modifications reserved
Page 54/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
5 CUSTOMER INTERFACE
Fig. 5-1 TLE Series 160 - 500 Connectivity rack and Serial port J35µP – RS232
TLE Series 160 - 500 has the following equipment’s:
- Serial Port J35µP - RS232 (see Section 5.1).
- Customer Interface board (see Section 5.2).
-
Connectivity rack ready for the installation of four connectivity boards.
Possible connectivity configurations with TLE Series 160 - 500
Fig. 5-2 Connectivity Rack
For a Single UPS it’s possible to install the following
connectivity boards:
- max. 3 “Customer Interface” boards;
-
max. 2 “3-ph SNMP/WEB Plug-in Adapter” boards.
For a Parallel System (max. 6 UPS) it’s possible to install
the following connectivity boards:
- max. 3 “Customer Interface” boards for each UPS;
- max. 2 “3-ph SNMP/WEB Plug-in Adapter” boards for
Parallel System.
ATTENTION !
The installation of any option board must be performed by a GE Service
Technician.
Prior to the installation, connection and cabling of any option board the UPS
must be COMPLETELY POWERED DOWN and all the power sources that will be
connected to the option board must be DE-ENERGIZED.
Option board shall be connected only to Safety Extra Low Voltage circuits (SELV
for IEC-UL-CSA60950-1): voltage up to 30Vac / 42.4Vpk or 60Vdc maximum and
galvanically separated from AC Utility supply.
Keep SELV cables separated from HIGH VOLTAGE cables.
TLE Series 225 & 250
TLE Series 400 & 500
Q1
1
2
I ON
0 OFF
-
+
J35µP
- RS232
Connectivity rack
Q1
I ON
0 OFF
1
2
-
+
J35µP
- RS232
Connectivity rack
J35
µP
- RS232
Connectivity rack
1
2
TLES_UL_225-500_S1_UPS connectivity_01a
TLES_UL_225-750_S1_Connectivity rack_01.
SNMP card
J3
J2
J5
J4
16
15
4
19
18
17
20
9
8
7
6
5
14
13
12
3
2
1
22
11
21
10
Critical Power
Modifications reserved
Page 55/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
5.1 SERIAL PORT J35µP - RS232 (SUB D, FEMALE 9 PIN)
Fig. 5.1-1 Serial Port J35µP – RS232
Serial Port J35µP - RS232
for IMV
protocol
Total remote management of the
system using software GE
iUPSGuard, GE Data Protection or
GE Service Software
for system
protection and management of
the UPS systems.
Connection of a serial printer
From the display panel, it is possible to select
printing of measurements, alarms and parameters
(see
User Manual to Section 6.4 – SETUP / PRINTER).
Fig. 5.1-2 Serial port J35µP connection to PC with RS232 1:1 cable
DB9m – DB9f
The serial port J35µP - RS232 is enabled on all the units of the RPA Parallel
System.
Fig. 5.1-3 Connector J1 – RJ45 8P8C
NOTE !
The serial port J35µP - RS232
is enabled also in case the J1-
RJ45 connector of the “P4 Customer Interface” (see
Section 5.2.1)
is already
connected.
TLE Series 225 & 250
TLE Series 400 & 500
Q1
12
I ON
0 OFF
-
+
J35µP
- RS232
Q1
I ON
0 OFF
12
-
+
J35µP - RS232
J35
µP
- RS232
TLES_UL_225-500_S2_UPS-J35_01a
TLES_UL_225-750_S1_Customer interface-J1-RJ45_01.
16
15
4
19
18
17
20
9
8
7
6
5
14
13
12
3
2
1
22
11
21
10
J1 - RJ45
Critical Power
Modifications reserved
Page 56/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
5.2 CUSTOMER INTERFACE BOARD
Fig. 5.2-1 Customer Interface Board
J1 connector– RJ45 8P8C (see Section 5.2.1)
Pin 5: TX (out)
Pin 6: RX (in)
Pin 4: GND
X1 terminal block – Output signals on voltage free contacts (see Section 5.2.2)
X1 / 1, 2, 3
NO, C, NC
UTILITY FAILURE
(def. Parameter RL=1)
X1 / 4, 5, 6 NO, C, NC LOAD ON INVERTER (def. Parameter RL=3)
X1 / 7, 8, 9
NO, C, NC
STOP OPERATION
(def. Parameter RL=5)
X1 / 12, 13, 14
NO, C, NC
LOAD ON UTILITY
(def. Parameter RL=2)
X1 / 15, 16, 17 NO, C, NC GENERAL ALARM (def. Parameter RL=4)
X1 / 18, 19, 20
NO, C, NC
BUZZER (acoustic alarm)
(def. Parameter RL=6)
The programmable signals on X1 will be disabled with Q1 open, with the
exception of the signals for “16 - MANUAL BYPASS ON” and “26 – EMERGENCY
OFF (EPO)”.
X1 terminal block – Input contacts (see Section 5.2.3)
X1 / 10, 21 NO Programmable
X1 / 11, 22
NO
Programmable / GENERATOR ON
X2 terminal block –“EPO -Emergency Power Off” connection (see Section 5.2.4)
X2 / 1, 2
NC
EPO - Emergency Power Off
Note: to enable this function, remove the Jumper JP2 on “P4 – Customer
Interface” board (see Section 5.2.4).
NO = Normally Open
C = Common
NC = Normally Closed
Output signals on voltage-free contacts
Programmable functions on input contacts
On terminals X1, 6 of the following 27 signals
can be selected
from the display, entering with the appropriate password.
Some UPS functions can be activated with
parameters when an external Normally
Open (NO) contact is closed on:
X1/10, 21 or X1/11, 22
Selectable functions by changing
parameters (password required) are:
0 - NO FUNCTION
1 - INVERTER ON
2 - INVERTER OFF
3 – PRINT ALL
4 - STATUS RELAY
5 - GENERATOR ON
6 - EXTERNAL BYPASS
7 - BATTERY FUSES OR EXTERNAL K3
(See Alarm 4104 - Battery Fuses)
8 - eBoost/IEMi CONTROL
Voltage free contacts:
Max. 24Vac / 1A or 60Vdc / 0,5A
IEC-UL-CSA 60950-1 (SELV circuit)
Min. Signal Level: 5Vdc / 5mA
0- NO SIGNAL
1- BUZZER
2- GENERAL ALARM
3- LOAD ON UTILITY
4- STOP OPERATION
5- LOAD ON INVERTER
6- UTILITY FAILURE
7- DC OVERVOLTAGE
8- LOW BATTERY
9- OVERLOAD
10- OVERTEMPERATURE
11- INVERTER-BYPASS NOT SYNCHR.
12- BYPASS LOCKED
13- BYPASS UTILITY FAILURE
14- RECTIFIER UTILITY FAILURE
15- BATTERY DISCHARGE
16- MANUAL BYPASS ON
17- RECTIFIER ON
18- INVERTER ON
19- BOOST CHARGE
20- BATTERY EARTH FAULT
21- BATTERY FAULT
22- RELAY INPUT 1
23- RELAY INPUT 2
24- RELAY OUTPUT ON
25- RELAY OUTPUT OFF
26- EMERGENCY OFF (EPO)
27- eBoost/IEMi MODE
1 2
8
19 21 2220
10 119
17 181615
7654
12 1413
321
X1
X2
J1
SGSE_400-500_S1_Customer interface_01
Critical Power
Modifications reserved
Page 57/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
5.2.1 Connector J1 – RJ45 8P8C
Fig. 5.2.1-1 Connector J1 – RJ45 8P8C
Total remote management of the system using software GE
iUPSGuard, GE Data Protection or GE Service Software for
system protection and management of the UPS systems.
Fig. 5.2.1-2 RJ45 –RS232 adaptation cable
TLE Series 160 - 500
is supplied with an
adaptation cable for a serial port RS232 /
sub DB9 connection.
Fig. 5.2.1-3 Connector J1 to PC with RJ45 –RS232 adaptation cable
The connector J1 – RJ45 is enabled on all the
units of the Parallel System.
5.2.2 X1 terminal block - Output signals on voltage-free contacts
The Customer Interface board provides 6 voltage free relay contacts giving some UPS critical alarms
and operation mode.
These signals are available on terminal blocks X1. Max. rating terminals: 1mm
2
.
The meaning of the alarms on the free contacts in standard configuration (default) is the following:
X1 / 1, 2, 3
(NO, C, NC)
UTILITY FAILURE
(def. Parameter RL=1)
X1 / 4, 5, 6
(NO, C, NC)
LOAD ON INVERTER
(def. Parameter RL=3)
X1 / 7, 8, 9
(NO, C, NC)
STOP OPERATION
(def. Parameter RL=5)
X1 / 12, 13, 14
(NO, C, NC)
LOAD ON UTILITY
(def. Parameter RL=2)
X1 / 15, 16, 17
(NO, C, NC)
GENERAL ALARM
(def. Parameter RL=4)
X1 / 18, 19, 20
(NO, C, NC)
BUZZER (ACOUSTIC ALARM)
(def. Parameter RL=6)
In case different alarms or operating status are required, they can be configured on the same terminals
via software from the control panel.
The configuration can be changed in parameters mode by a trained operator using the appropriate
password.
NOTE !
The programmable signals on X1 will be disabled with Q1 open, with the exception of
the signals for “16 - MANUAL BYPASS ON” and “26 – EMERGENCY ON (EPO)”.
5.2.3 X1 terminal block - Programmable input free contacts
Some programmable UPS functions (indicated in Section 9.2), can be activated by closing an external
contact, if connected, on:
X1 / 10, 21 User Input 1 (default = Not used)
X1 / 11, 22 User Input 2 (default = GENERATOR ON)
TLES_UL_225-750_S1_Customer interface-J1-RJ45_01.
16
15
4
19
18
17
20
9
8
7
6
5
14
13
12
3
2
1
22
11
21
10
J1 - RJ45
6
9
1
5
2
3
4
7
8
CNT_Cable RJ45-RS232_01
8
1
J1 - RJ45
J1 - RS232
Critical Power
Modifications reserved
Page 58/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
5.2.4 X2 terminal block – “EPO - Emergency Power Off”
NOTE !
If an emergency button “EPO - Emergency Power Off” is installed, the use of the XA
terminals is recommended (see Section 5.10).
Fig. 5.2.4-1 X2 terminals in the P4 – Customer Interface
Fig. 5.2.4-2 Jumper JP2 on the P4 – Customer Interface
NOTE !
To activate the connection of an emergency button “EPO - Emergency Power Off” on
the terminals XA / EPO-1, EPO-2, performed on each card “P4 – Customer Interface”
the following operation:
- Remove the cable short-circuiting terminals X2 / 1, 2 (see Fig. 5.2-4-1).
- Remove the Jumper JP2 (see Fig. 5.2-4-2).
5.2.5 X1 terminal block - Gen Set Signaling (GEN ON)
If an emergency generator set supplies the UPS in case of Utility Failure and the generator is
considerably unstable in frequency, it should be suitable to install the signal “GENERATOR ON” on X1 /
11, 22. See Fig. 5.2-1 / X1.
Since the Parameter for of the reading of the Generator function is password protected, contact your GE
Service Center for it's activation.
When this contact closes, it changes certain (programmable) functions such as:
• Enabling or disabling of synchronization and consequently the Load transfer to generator.
• Reduction or elimination or delay of Battery recharging during the generator operation.
Additionally, when the “GENERATOR ON” input contact is closed, the UPS will inhibit eBoost™ Operation
Mode and revert to double-conversion operation.
It is advised to contact your GE Service Center for further details.
In a Parallel System a separate NO (Normally Open) contact must be connected to
each individual unit.
TLES_UL_225-750_S1_Customer interface-X2 EPO_01.
16
15
4
19
18
17
20
9
8
7
6
5
14
13
12
3
2
1
22
11
21
10
X2
X1
X2
J1
JP2
1 2
8
19 21 2220
10 119
17 181615
7654
12 1413
321
X1
X2
J1
SE_400-500_S1_Customer interface-JP2_01
Critical Power
Modifications reserved
Page 59/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
5.2.6 X1 terminal block - AUX external Maintenance Bypass
If the UPS system is equipped with an external Maintenance Bypass Switch, it is possible to connect a NO
(Normally Open) voltage-free aux. contact from the External Bypass Switch to the programmable input
X1 / 10, 21, making the UPS operate as if the internal switch Q2 has closed.
This function can be activated by changing a dedicated parameter (password required).
When this NO (Normally Open) contact closes, the output Inverter Contactor K7 it is automatically
opened and the Load transfer back to Inverter will be inhibited.
In a Parallel System, the input on the Customer Interface of each unit must be
connected to a separate AUX contact of the External Maintenance Bypass Switch.
5.2.7 X1 terminal block - eBoost/IEMi control signal
The UPS operation in either eBoost or IEMi operating modes can be controlled via an NO (Normally Open)
contact by installing the “eBoost/IEMi CONTROL” signal, routed to the programmable function contacts
(see Section 5.2.3).
When this contact closes, eBoost or IEMi operation mode is inhibited.
The Parameter for the activation of such function is password protected.
Contact your GE Service Center for its activation.
This function is particularly useful for controlling eBoost or IEMi operation following critical conditions on
either the load side or the input utility, including generator operation when the “GENERATOR ON” signal
has not been installed.
When using the “eBoost/IEMi control” function on the programmable user relays of
the Customer Interface X1 terminals in a Parallel System, a separate NO (Normally
Open) contact must be connected to each individual unit.
Critical Power
Modifications reserved
Page 60/60
GE_UPS_ISG_TLE_SUL_M16_M50_2bU_V010.docx
Installation Guide TLE Series 160 - 500 UL S2B
6 NOTES
6.1 NOTES FORM
It is recommended to note in this section Notes, with date and short description all the operations
performed on the UPS, as: maintenance, components replacement, abnormal situations, etc.
Date Description Done by
Loading...
