GE WCSE3100, EWA2500, WBB3300 User Manual
www.GEAppliances.com
WBSE2090
WBXE2070
WCSE3100
WCSE4230
WJSE3110
WWSE3160
EWA2500
WBB3300
Owner’s Manual
Washer
175D1807P342 49-90081 12-00 JR
Safety Information . . . . . . . .2, 3
Operating Instructions
Control Panels . . . . . . . . . .4–5, 7
Control Settings . . . . . . . . . . .6, 8
Features . . . . . . . . . . . . . . . . .9, 10
Loading and Using
the Washer . . . . . . . . . . . . . .11, 12
Troubleshooting Tips
Before You Call
For Service . . . . . . . . . . . . . .13–15
Consumer Support
Consumer Support . .Back Cover
Product Registration . . . . .17, 18
Warranty . . . . . . . . . . . . . . . . . . .19
Write the model and serial
numbers here:
Model # ____________________
Serial # ______________________
You can find them in the upper
right corner on the back of your
washer.
■Install or store where it will not be exposed to
temperatures below freezing or exposed to
the weather.
■Properly ground washer to conform with all
governing codes and ordinances. Follow details
in Installation Instructions.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
2
WARNING!
For your safety, the information in this manual must be followed to
minimize the risk of fire or explosion, electric shock, or to prevent
property damage, personal injury, or loss of life.
WATER HEATER SAFETY
Under certain conditions hydrogen gas may be produced in a water heater that has not been used for
two weeks or more. Hydrogen gas can be explosive under these circumstances.
If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by
turning on
all hot water faucets and allowing them to run for several minutes. Do this before using any
electrical appliance
which is connected to the hot water system. This simple procedure will allow any
built-up hydrogen gas to escape. Since the gas is flammable, do not smoke or use an open flame or
appliance during this process.
PROPER INSTALLATION
This washer must be properly installed and located in accordance with the Installation Instructions before
it is used. If you did not receive an Installation Instructions sheet, you can receive one by calling, toll-free,
the
GE Answer Center®, 800.626.2000.
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
■Keep the area underneath and around your
appliances free of combustible materials such
as lint, paper, rags, chemicals, etc.
■Close supervision is necessary if this appliance
is used by or near children. Do not allow
children to play on, with, or inside this or
any other appliance.
YOUR LAUNDRY AREA
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
■Never reach into washer while it is moving.
Wait until the machine has completely
stopped before opening the lid.
■Do not mix chlorine bleach with ammonia or
acids such as vinegar and/or rust remover.
Mixing different chemicals can produce a
toxic gas which may cause death.
■Do not wash or dry articles that have been
cleaned in, washed in, soaked in, or spotted
with combustible or explosive substances
(such as wax, oil, paint, gasoline,
degreasers,
dry-cleaning solvents, kerosene, etc.) which
may ignite or explode. Do not add these
substances to the wash water. Do not use or
place these substances around your washer
or dryer during operation.
■
The laundry process can reduce the flame
retardancy of fabrics. To avoid such a result,
carefully follow the garment manufacturer’s
wash and care instructions.
■To minimize the possibility of electric shock,
unplug this appliance from the power supply
or disconnect the washer at the household
distribution panel by removing the fuse or
switching off the circuit breaker before
attempting any maintenance or cleaning.
NOTE:
Pressing PAUSE does
NOT
disconnect
the appliance from the power supply.
■Never attempt to operate this appliance
if it is damaged, malfunctioning, partially
disassembled, or has missing or broken parts,
including a damaged cord or plug.
WHEN USING THE WASHER
■Turn off water faucets to relieve pressure on
hoses and valves and to minimize leakage if
a break or rupture should occur. Check the
condition of the fill hoses; they may need
replacement after 5 years.
■Before discarding a washer, or removing it
from service, remove the washer lid to prevent
children from hiding inside.
■Do not attempt to repair or replace any
part of this appliance unless specifically
recommended in this Owner’s Manual, or
in published user-repair instructions that you
understand and have the skills to carry out.
■Do not tamper with controls.
WHEN NOT IN USE
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
3
Use this
appliance
only for its
intended
purpose as
described in
this Owner’s
Manual.
www.GEAppliances.com
About the washer control panel.
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
Quick Start Guide
4
Model WBSE2090
Model WBXE2070
Model WCSE3100
• Add detergent
• Add diluted fabric
softener
• Add clothes
• Select load size and
other wash options
• Select wash cycle
• Close lid
• Push
START
NOTE:
When making a selection with any knob, simply point the knob anywhere within the shaded range for that setting.
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
5
www.GEAppliances.com
Model WCSE4230
Model WJSE3110
Model WWSE3160
Model EWA2500
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
6
About the control settings.
Load Size
Loosely load clothes no higher than the top row of holes in the washer tub. The water level should
just cover the clothes.
Custom Care Wash/Spin Speeds (on some models)
The agitator moves clothes around for a cleaner wash; the basket spins later in the cycle to release
water from the load. The Wash/Spin Speed dial sets the speed of both the agitator and the basket.
With Normal wash speed, the agitator will move at a high speed for the first few minutes, then it steps
down to a moderate speed. This reduces the wear on your clothing. Use for cottons, denims and play
clothes.
With Gentle wash speed, the agitator moves slower. Use for delicate and knit items.
The Fast spin speed is for durable items.
The Slow spin speed is for delicate items like sweaters and lingerie. When using Slow spin speed,
clothes will be less dry than when using Fast spin speed.
Temperature
Select the water temperature for the wash and rinse cycles. Always follow fabric manufacturer’s care
label or instructions when laundering.
Wash Cycle
The wash cycle controls the length of the washing process. The knob can be turned in either direction.
Turning the Cycle Selector knob after starting a cycle will stop the washer and reset the cycle to the new
selection. Press START to begin the new cycle selection.
The Cycle Indicator Lights show what stage the washer is in. The wash time is the length of the wash
agitation. The 6 MIN light will remain lit during drain and spin. When the Selector knob is set to a new
cycle the Indicator Lights will flash momentarily, showing what stages the cycle will go through.
On models without an Auto Soak option, the
SOAK
light will not light up.
The chart below will help you match the wash cycle setting with your clothing.
COTTONS For heavy to lightly soiled cottons, household linens, work and play clothes.
EASY CARE For wrinkle-free and permanent press items, and knits.
DELICATES For lingerie and special-care fabrics with light soils. Provides periods of agitation and soak during wash
and rinse.
EXTRA HEAVY For heavily soiled and heavy-duty fabrics. This cycle provides a longer agitation.
15 MIN/30 MIN For heavily soiled clothes. Begins with a brief agitation, soaks for a specified period of time, then moves
AUTO SOAK through the rest of the cycle automatically.
START
Press START to begin the cycle. Pressing START again or raising the lid will PAUSE the cycle and
the Cycle indicator light will blink.
REMEMBER: When
choosing the cycle, the
Cycle Selector knob can
be pointed anywhere
within the shaded range
for the cycle setting.
