GE Refrigerators
GE
LARGE FREEZER/
REFRIGERATOR
OPERATIONS GUIDE
MODEL NAMES/HOME APPLIANCE
TFJ20JR
TFJ30PR
TPJ24BR
TFJ22PR
TFJ25PR
TFJ28PR
TPJ24PR
TFJ30PF
TFJ28PF
TPJ24PF
Table of Contents
Instructions for Safe Operation . . . . . . . . . . . . . . . .1–7
Part Names . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8, 9
Specifications—External Dimensions . . . . . . . . .10–12
Instructions for Installation . . . . . . . . . . . . . . . . . . . .13
Instructions for Operation . . . . . . . . . . . . . . . . . . . . .14
Operation of Refrigerator:
Operation of Temperature Control Dials . . . . .15
Interior Temperature Control . . . . . . . . . . .16–18
Operation of Custom Dispenser . . . . . . . . .19–21
Utilizing the Interior Space . . . . . . . . . . . .22–26
Electronic Monitor & Diagnostic System . .27–29
Storage of Food . . . . . . . . . . . . . . . . . . . . . . . .30
What To Know About Frozen Foods . . . . . . . . . . . . .31
Care and Cleaning of Refrigerator . . . . . . . . . . . . . . .32
Self-Diagnosis of Refrigerator . . . . . . . . . . . . . . . . . .33
Warranty and After-Service . . . . . . . . . . . . . . . . .34, 35
• Thank you very much for purchasing the
GE Large Freezer/Refrigerator.
• Please read and completely understand this
Operations Guide before use to ensure accurate
and safe operation of this appliance.
• After reviewing, retain this guide for future reference.
• Be sure to obtain the “Warranty Note.”
For Safety
Read Before
Using
OperationCare, Cleaning
& Self-Diagnosis
Warranty &
After-Service
Part No. 162D9792P002
Pub No. 49-6896
12-96
Examples of Pictorial Signs
Indicates caution (including danger, warning). Details of WARNING
(caution) are posted inside or near the illustration in pictures or words.
Indicates this action is not to be done. Details of such actions
are posted inside or near the illustration in pictures or words.
Indicates forced action (must do). Details of forced actions
are posted inside or near the illustration in pictures or words.
INSTRUCTIONS FOR SAFE OPERATION
• Please read these safety cautions carefully and operate the refrigerator correctly.
• Please make sure to heed the safety cautions listed here, for they contain important information.
DANGER
This sign indicates that there is a high probability of causing death
or serious injury to the operator, if mishandled.
WARNING
This sign indicates that there is a possibility of causing death or
serious injury to the operator, if mishandled.
CAUTION
This sign indicates that there is a possibility of causing bodily
injury to the operator or material damage*, if mishandled.
Caution indicators and their meanings are as follows:
* Material damage includes damage to house, furniture, pets or bedding.
“WARNING: ELECTRIC SHOCK”
“DO NOT DISASSEMBLE”
“UNPLUG”
WARNING
Do not store flammable substances
such as ether, benzene, alcohol, drugs,
LP gas (cartridge for lighters).
SPRAY
LP GAS
THINNER
GLUE
ETHER
• DANGER OF EXPLOSION.
DO NOT
Do not hang on or sit on glass shelf.
• DANGER OF INJURY
DUE TO DOOR FALLING
OR PINCHING HAND.
DO NOT
For Safety
1
INSTRUCTIONS FOR SAFE OPERATION (continued)
WARNING
Under no circumstances should you
disassemble, repair, or modify
anything.
• DANGER OF STARTING
FIRE (OR MAY CAUSE
ABNORMAL OPERATION).
DO NOT DISASSEMBLE
Use regulation 15A only for dedicated
wall outlet for the refrigerator.
• DANGER OF FIRE
FROM OVER-HEATING
IF OUTLET IS SHARED
WITH OTHER
APPLIANCES.
DEDICATED OUTLET
When cleaning, unplug the power plug
from the wall outlet.
• DO NOT HANDLE PLUG
WITH WET HANDS.
• DANGER OF ELECTRIC
SHOCK, SHORT CIRCUIT,
OR INJURY.
UNPLUG
Do not press power plug with the back
of refrigerator.
• DANGER OF FIRE FROM
OVER-HEATING BYA
DAMAGED PLUG.
DO NOT PRESS
When the refrigerator/freezer is out of
order, stop operation by disconnecting
the power plug.
• OPERATING THE
APPLIANCE WHEN
SOMETHING IS
ABNORMAL COULD
RESULT IN AN ELECTRIC
SHOCK OR FIRE.
UNPLUG
The metal prongs or the prong
attachment of power plug should be
wiped clean with a dry cloth.
• WIPE PLUG CLEAN
WHEN DIRTY.
• MAY BECOME A SOURCE
OF FIRE.
CLEAN PLUG
For Safety
2
Power
source
AC 100V
Standard 15A
wall outlet
“Humming
Noise”
“Sparkle”
INSTRUCTIONS FOR SAFE OPERATION (continued)
For Safety
WARNING
Connect grounding wire.
• DANGER OF
MALFUNCTION OR
SHORT CIRCUIT.
• PLEASE CONSULT
DEALERSHIP WHEN
CONNECTING
GROUNDING.
CONNECT GROUNDING
Do not install in a location where
freezing is possible.
• DANGER OF RUPTURED
HOSES, PIPES, VALVES,
ETC., LEAKING WATER.
DO NOT INSTALL
Do not store medicines or scientific
specimens in refrigerator.
• SUBSTANCES REQUIRING
STRICT TEMPERATURE
CONTROL SHOULD NOT
BE STORED IN A HOME
REFRIGERATOR.
DO NOT STORE
In the event of a city gas leak, provide
good ventilation by opening the doors.
Do not touch refrigerator or wall
outlet.
• POSSIBILITY OF FIRE
LEADING TO AN
EXPLOSION.
VENTILATE
Discard foods which are discolored or
foul smelling due to malfunctioning of
the refrigerator.
• SPOILED FOOD CAN BE
HARMFUL.
DISCARD SPOILED FOODS
Do not splash water outside and/or
inside the refrigerator.
• DANGER OF ELECTRIC
SHOCK OR SHORT
CIRCUIT.
DO NOT SPLASH WATER
3
Confirm the
ground wire
INSTRUCTIONS FOR SAFE OPERATION (continued)
WARNING
Do not use flammable sprays (hair
spray, insecticide, etc.) near
refrigerator.
• DANGER OF FIRE BY
IGNITION.
DO NOT USE
Do not place heavy objects on top of
refrigerator.
• DANGER OF INJURY
CAUSED BY FALLING
OBJECTS WHEN DOOR IS
OPENED AND CLOSED.
DO NOT
Do not place a container with water on
top of refrigerator.
• DANGER OF FIRE
CAUSED BY SHORT
CIRCUIT DUE TO
DETERIORATION
OF ELECTRICAL
INSULATION BY
SPILLED WATER.
DO NOT
When disposing of a refrigerator,
remove door gasket.
• IT IS DANGEROUS IF A
CHILD IS TRAPPED
INSIDE.
REMOVE GASKET
Unplug power plug when replacing
interior light bulb.
• POSSIBILITY OF
ELECTRIC SHOCK.
UNPLUG
Do not touch the ice-making part of
the automatic icemaker.
• INJURY COULD
RESULT WHEN ICE
TRAY ROTATES.
• HEATER BECOMES
HOT AND COULD
CAUSE BURNS.
DO NOT TOUCH
For Safety
4
INSTRUCTIONS FOR SAFE OPERATION (continued)
For Safety
WARNING
CAUTION
Secure the refrigerator in place to
prevent it from toppling over during an
earthquake.
• COULD RESULT IN
INJURIES IF THE
REFRIGERATOR
TOPPLES OVER.
PREVENT FROM
TOPPLING OVER
The adjustable shelves and baskets
should be attached securely to
designated points in the refrigerator.
• DANGER OF CAUSING
INJURIES DUE TO
SHELVES COMING LOOSE
AND FALLING IF NOT
SECURELY ATTACHED.
ATTACH SHELVES
SECURELY
Piping for the icemaker should be
installed in accordance with the wiring
and piping schematics.
• UNIT MAY LEAK IF NOT
INSTALLED CORRECTLY.
INSTALLATION WARNING
A 100V alternating current power
source is to be used for the wall outlet.
• POSSIBILITY OF FIRE OR
ELECTRIC SHOCK.
100V ONLY
Do not pull cord when disconnecting
power plug.
• UNPLUG BY HOLDING
THE POWER PLUG.
• ELECTRIC SHOCK OR
SHORT CIRCUIT COULD
RESULT.
DO NOT PULL
5
Use 100 VAC
INSTRUCTIONS FOR SAFE OPERATION (continued)
CAUTION
Do not use a damaged cord, power
plug, or loose wall outlet.
• POSSIBILITY OF
ELECTRIC SHOCK,
SHORT CIRCUIT,
OR FIRE.
DO NOT USE
Do not damage the electric
power cord.
• DO NOT DAMAGE, BREAK,
ALTER, FORCIBLY BEND,
PULL, TWIST, OR BUNDLE THE
ELECTRIC POWER CORD. DO
NOT PLACE A HEAVYOBJECT
ON IT, CRIMPIT, OR ALTER IT
IN ANYWAY.
• A BROKEN CORD MAY CAUSE
FIRE OR ELECTRIC SHOCK.
DO NOT DAMAGE
Install the refrigerator in a location
away from excess moisture or where
water may be present.
• INSULATION WILL
DETERIORATE AND
CAUSE ASHORT CIRCUIT.
KEEP DRY
Unplug the power plug from wall
outlet when the refrigerator will not be
used for an extended period of time.
• DETERIORATING
INSULATION COULD
CAUSE AN ELECTRIC
SHOCK OR SHORT
CIRCUIT.
UNPLUG
Do not store bottles or cans in freezer
compartment.
CRACK!
• CONTENTS WILL FREEZE
CAUSING THE BOTTLES
TO EXPLODE WHICH
MAY CAUSE INJURIES.
NO BOTTLES
Close the refrigerator door by holding
the door handle.
• DANGER OF INJURYTO
FINGERS IF THE DOOR
HANDLE IS NOT USED
WHEN CLOSING DOOR.
USE DOOR HANDLE
For Safety
6
NO!
INSTRUCTIONS FOR SAFE OPERATION (continued)
CAUTION
Hire professional movers to move the
refrigerator, because it is heavy and
dangerous to move.
• DANGER OF INJURIES BY
ATTEMPTING TO MOVE THE
REFRIGERATOR YOURSELF.
• CONSULT YOUR DEALERSHIP
OR APROFESSIONAL MOVER
TO TRANSPORTTHE
REFRIGERATOR.
EMPLOY
PROFESSIONAL MOVERS
Do not touch food or containers
(metallic) inside the freezer
compartment with wet hands.
• FREEZING
TEMPERATURES MAY
CAUSE FREEZER BURN.
DO NOT TOUCH
Install refrigerator on a sturdy
flat floor.
Straight!
• INSTALLING ON AN
UNSTEADY FLOOR
COULD CAUSE THE
REFRIGERATOR TO
TOPPLE WHEN OPENED
AND CLOSED AND COULD
CAUSE INJURY.
DO NOT INSTALL
Do not put hands under the
refrigerator.
• METALPLATES AND
ROTATING PARTS
LOCATED UNDER THE
REFRIGERATOR MAY
CAUSE INJURY.
DO NOT TOUCH
Do not re-freeze foods after they have
been thawed.
Frozen Food
• CONSUMING SPOILED
FOODS IS HARMFUL.
FOOD POISONING
WARNING
If you resell or give away this
appliance, provide the new owners
with this Operations Guide.
Operations
Guide
• THE NEW OWNER WILL
NEED THIS OPERATIONS
GUIDE FOR SAFE AND
CORRECT USE.
PROVIDE
OPERATIONS GUIDE
7
For Safety
PART NAMES
Read Before
Using
TFJ28PF,TFJ30PF,TPJ24PF
Freezer Compartment
Icemaker Compartment
(with inspection door)
(built-in icemaker)
Compartment Shelves
(3 levels)
Large Freezer Basket
Door Pockets (4 levels)
Custom Dispenser
(back side) (ice cold
water dispenser)
Refrigerator Compartment
Temperature Control Dial
Internal Lamps
Quick-Serve Shelf (with 2
or 4 serving dishes)
Internal Shelf (3 levels)
Wine Rack
Airtight Snack Case
High Humidity Vegetable
Compartment
Chilling/Vegetable
Compartment
Astro-Door (flip door)
Type Utility Compartment
Refrigerator Mini Door
Jumbo Door Pocket
(4 levels)
Four Wheel Castors
Front Grille
Utility Box (can be used as
egg case also)
1
3 5
7
9
1
3
5
9
7
TFJ22PR,TFJ25PR,TFJ28PR,TFJ30PR, TPJ24BR,TPJ24PR
Freezer Compartment
Icemaker Compartment
(with inspection door)
(built-in icemaker)
Compartment Shelves
(3 levels)
Large Freezer Basket
Door Pockets (4 or 5 levels)
Custom Dispenser
(back side) (ice cold
water dispenser)
Refrigerator Compartment
Temperature Control Dial
Internal Lamps
Internal Shelf (3 levels)
Wine Rack
Airtight Snack Case
High Humidity Vegetable
Compartment
Chilling/Vegetable
Compartment
Astro-Door (flip door)
Type Utility Compartment
Door Pockets (4 levels)
Four Wheel Castors
Front Grille
Utility Box (can be used as
egg case also)
1
3 5
7
9
1
3
5
9
7
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
18
19
17
17
19
18
1
1
2
2
3
3
4
4
5
5
1
2
3
4
5
6
6
7
7
7
8
8
9
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
7
8
9
10
11
12
13
14
15
16
6
7
8
9
8
PART NAMES (continued)
9
TFJ20JR
Freezer Compartment
Icemaker Compartment
(with inspection door)
(built-in icemaker)
Compartment Shelves
(3 levels)
Large Freezer Basket
Door Pockets (5 levels)
Custom Dispenser (back
side) (ice cold water
dispenser)
Refrigerator Compartment
Temperature Control Dial
Internal Lamps
Internal Shelf (3 levels)
High Humidity Vegetable
Compartment
Chilling/Vegetable
Compartment
Astro-Door (flip door)
Type Utility Compartment
Door Pockets (4 levels)
Four Wheel Castors
Front Grille
Utility Box (can be used as
egg case also)
10
10
11
11
12
12
13
13
14
15
15
14
1
1
2
2
3
3
4
4
5
5
6
6
7
7
7
8
8
9
9
Read Before
Using
SPECIFICATIONS
Read Before
Using
10
UNITS TFJ30PF TFJ30PR TFJ28PF TFJ28PR TFJ25PR TPJ24PF TPJ24PR/BR TFJ22PR TFJ20JR
USEFUL TOTAL (L) 806 806 764 764 686 630 630 588 531
VOLUME FREEZER (L) 301 301 284 284 243 229 229 175 175
FRESH FOOD (L) 505 505 480 480 443 401 401 413 356
ELECTRICAL VOLTAGE (V) SINGLE PHASE 100/100
POWER FREQUENCY (Hz) 50/60
SOURCE MOTORS (W) 247/238 247/238 247/238 247/238 252/245 248/233 248/233 243/231 241/228
HEATERS (W) 675/675 675/675 675/675 675/675 675/675 675/675 675/675 595/595 595/595
AVG MONTHLYELECTRICAL 86/89 81/81 81/80 71/73 77/78
CONSUMPTION (KWH/MON)
COOLING METHOD AND COLD AIR CIRCULATION TYPE (INDIRECT COOLING)
FREEZER CODE
CONDENSER COOLING FORCED AIR (FAN COOLED CONDENSER)
DEFROST CONTROL AUTO START - AUTO STOP
DEFROST WATER REMOVAL FORCED AIR EVAPORATION
AUTOMATIC ICEMAKER YES
MOBILITY WHEELS ATTACHED
BUILT-IN POSSIBLE
DOOR REVERSIBILITY ELECTRICAL RATING (A) 15
WEIGHT (Kg) 168 168 163 163 143 159 159 132 123
CORD LENGTH (M) 2.2
* Values for useful internal volume and the Electrical Standard Values are based on the Japanese Industry Standard
(JIS C9607).
* Values separated by “/” indicate 50 Hz on left and 60 Hz on right. Others indicate common 50 Hz
and 60 Hz.
•
Freezer Performance
This freezer/refrigerator is “Four Star” coded.
Performance of freezer is classified by codes.
Each code indicates the performance capability according to the regulation
delineated in the Japanese Industry Standard (JIS C9607). The regulation
defines the test conditions for measuring the freezing-load temperature
(food temperature). The following table shows the test results:
CODE FREEZING-LOAD TEMP. FROZEN FOOD PRESERVATION
(FOOD TEMPERATURE) ESTIMATED TIME
Below -6°C. Approx. 1 week
Below -12°C. Approx. 1 month
or Below -18°C. Approx. 3 months
EXTERNAL DIMENSIONS
11
TFJ30PF
TFJ30PR
(Units: mm)
Top
View
Side
View
TFJ28PF
TFJ28PR
(Units: mm)
Top
View
Side
View
TPJ24PF
TPJ24PR
TPJ24BR
(Units: mm)
Top
View
Side
View
Read Before
Using
915
905
155
750
1775
295
385
1150
1290
875
825
710
115
50
915
870
120
750
1775
295
385
1150
1290
830
780
710
70
50
915
765
120 645
1775
295
385
1045
1185
725
675
605
70
50
Read Before
Using
12
EXTERNAL DIMENSIONS (continued)
TFJ22PR
(Units: mm)
Top
View
Side
View
TFJ20JR
(Units: mm)
Top
View
Side
View
TFJ25PR
(Units: mm)
Top
View
Side
View
915
875
150
725
1775
280
470
1150
1290
845
795
725
70
50
850
840
115
725
1720
270
470
1065
1278
840
795
725
70
45
800
830
105 725
1720
270
400
1065
1227
840
795
725
70
45
13
Read Before
Using
If the refrigerator is installed
directly on carpet or other mats, the
compressor under the refrigerator
may touch the mat, causing
discoloration of the mat, or may
interfere with the cooling capability
by reducing air flow.
INSTRUCTIONS FOR INSTALLATION
Refrigerator should be installed on a firm and
level floor.
1
Install in a low-humidity location.
5
Place a firm board under the refrigerator when
installing it on a weak floor, on a tatami, or on
a carpet.
2
If the refrigerator is tilted, adjust with leveling
screws under the front end. The front end of the
refrigerator should be slightly higher so the door will
close when lightly pushed.
3
To avoid electric shock, ground the refrigerator.
7
Install away from heat sources.
4
Do not put anything in front of the grille.
8
If the floor is not firm, noise
or vibration may occur. When
opening and closing the door,
the refrigerator may topple and
cause injuries.
An electrical short circuit or rusting may occur. If it is necessary
to install in a washroom or on a damp floor, be sure to provide
gaps by placing the refrigerator on some sort of blocks.
CAUTION: This type of refrigerator uses
forced fan cooling. Therefore, to prevent
reduction in the cooling capacity, place the
refrigerator on top of a firm board before
placing it on blocks. Do not place the
refrigerator directly on top of the blocks.
Avoid locations in direct sunlight
or near heat-producing appliances
(range, heater, etc.). Cooling
efficiency may be lowered or
external color changes may result.
Straight!
Consult dealer for grounding
installations. (Fee will be charged
for grounding installations.)
NOTE: A grounding wire is
attached to this refrigerator.
Please connect these grounding
terminals correctly.
Since air is suctioned in from
the front of the grille, obstructing
the grille could lower the cooling
capacity.
Leveling Screws
Rotate
clockwise
to raise
Rotate
clockwise
to raise
Allow sufficient space around the refrigerator as
shown in diagrams below.
6
Units: mm
Wall Outlet
Icemaker
50~100
X = 16 (TFJ20/22/25), = 3 (TPJ24, TFJ28/30)
Y = 25 (TFJ20/22/25), = 13 (TPJ24, TFJ28/30)
Z = 25 (TFJ20/22/25, TPJ24), = 3 (TFJ28/30)
50~100
50~100
Y
50
Y
Z
X X
X X
Stop Valve
for Icemaker
if installed
Stop Valve for
Icemaker
If Icemaker is installed
Read Before
Using
14
INSTRUCTIONS FOR OPERATION
CAUTIONS WHEN DISCARDING
3
To prevent a child from being locked inside, take the
following measures when disposing of a used refrigerator
or freezer:
1. Do not discard a refrigerator or a freezer in a location
where children might play.
2. Hinges should be destroyed to prevent an airtight seal.
3. Remove door and gasket.
CAUTION DURING POWER OUTAGE
1
CAUTIONS DURING EXTENDED SHUTDOWN
2
Sudden interruption of electricity
• Limit the frequency of opening and closing the door. If the
door is kept closed, the refrigerator should maintain its
temperature for approximately 2 hours and the freezer for
approximately 1 hour.
For expected outage
• Accumulate a lot of ice. The refrigerator can be maintained
by cooling with ice.
• The refrigerator can be maintained longer if it is cooled for
2–3 hours prior to a blackout by setting the temperature
control dial to the HIGH cooling position.
• Store as little food as possible. Fresh foods should be
consumed first.
When the refrigerator will not be used for an extended period
of time, follow the procedures outlined below to prevent odor
and mildew:
1. Remove all foods.
2. Clean out refrigerator and keep the door open for a few
days to dry out inside.
15
Operation
OPERATION OF TEMPERATURE CONTROL DIALS
SET AT POSITION “5” FOR NORMAL USE
1
FREEZER COMPARTMENT
2
The freezer temperature is adjusted by moving the dials as
shown in the diagrams.
Set dial at “5” for normal operation.
If the dial is set at “1,” temperature of the freezer is
increased.
If the dial is set at “9,” temperature of the freezer is decreased.
CAUTION: If the dial is set at “0,” the refrigerator
will shut off regardless of the position of the
refrigerator compartment dial.
1
3 5
7
9
1
3
5
9
7
REFRIGERATOR COMPARTMENT
3
Set the refrigerator temperature control dial to “5” for normal
operation. If the dial is turned toward “1,” the refrigerator
temperature becomes high and, if turned toward “9,”
temperature becomes low.
Dial Setting Temperature Operations
1 HIGH For storage of
3 foods at higher
temperatures.
5 MEDIUM Normal
7 LOW For storage of
9 foods at lower
temperatures.
Dial Setting Temperature Operations
1 HIGH Food is to be
3 stored for
shorter periods
of time.
5 MEDIUM Normal
7 LOW Food is to be
9 stored for
longer periods
of time.
Refrigerator
Compartment
Warm
Cold
Freezer
Compartment
(or)
Operation
INTERIOR TEMPERATURE CONTROL
NOTICE: NEW FREEZING ROOM TEMPERATURE FEATURE
YOUR REFRIGERATOR HAS BEEN DESIGNED TO INCLUDE A FEATURE THAT WILL
PREVENT THE CONTENTS OF THE REFRIGERATOR COMPARTMENT FROM FREEZING,
EVEN IF THE ROOM TEMPERATURE IS BELOW FREEZING. THIS IS ATOTALLY
AUTOMATIC SYSTEM AND WILL REQUIRE NO ACTION ON YOUR PART. THIS SYSTEM
PROVIDES THIS FEATURE BY PERIODICALLYTURNING THE LIGHTS IN THE
REFRIGERATOR COMPARTMENT ON AND OFF. THE WARMTH FROM THESE LIGHTS
WILL AUTOMATICALLY KEEP THE FOOD FROM FREEZING. THIS SYSTEM OPERATES
AT ROOM TEMPERATURES FROM 15°C. TO -5°C. THE SYSTEM WILLTURN ON THE
LIGHTS ONLY WHEN NEEDED. IF YOU SHOULD NOTICE THAT THE REFRIGERATOR
LIGHTS ARE ON, EVEN THOUGH THE DOOR IS CLOSED, THIS IS THE SYSTEM AT
WORK, KEEPING YOUR FRESH FOOD FROM FREEZING.
How to Prevent Freezing
NOTE: IF YOU EXPECT THE ROOM TEMPERATURE TO FALL BELOW FREEZING,
AND YOUR REFRIGERATOR HAS THE ICE/WATER DISPENSER FEATURE
BUILT INTO THE FREEZER DOOR, OR HAS AN ICEMAKER, THEN YOU
SHOULD PERFORM THE FOLLOWING STEPS. THIS DEACTIVATES THE
ICE/WATER SYSTEM AND WILL PREVENT THE EXTERNAL WATER LINES
FROM FREEZING.
1.Disconnect power to the refrigerator.
2.Close valve on water line connecting refrigerator to main water supply.
3.Position a container under the refrigeration connection to collect any spillage and disconnect inlet
water supply line from refrigerator. Also collect water from the inlet supply line.
4.Position the container under the plastic outlet tube that supplies the icemaker (on Refrigerator
side) to collect any water spillage and disconnect the tube.
5.Position the container under the plastic outlet tube that supplies the water tank (on Freezer side)
to collect any water spillage and disconnect the plastic outlet tube.
6.Reconnect the icemaker and water tank tubes to the water inlet valve.
7.Turn off the icemaker (inside freezer) by moving sensor arm to the “UP” locked position.
8.Remove the front grille.
9.Position a container under the water line connectors located under the freezer, to collect any
spillage, and disconnect the two ends of the water line.
10. Allow water to drain from the two ends.
11. Reconnect the two ends of the water line.
12. Install the front grille.
13. Reconnect power to the refrigerator.
How to Restore to Normal Condition
NOTE: WHEN THE ROOM TEMPERATURE RISES ABOVE FREEZING, YOU CAN
REACTIVATE YOUR ICE/WATER DISPENSER SYSTEM BY PERFORMING
THE FOLLOWING STEPS:
1.Disconnect power to the refrigerator.
2.Reconnect the inlet water supply line to the refrigerator.
3.Open the valve on water line connecting refrigerator to main water supply.
4.Turn on the icemaker (inside freezer) by moving sensor arm to the “DOWN” unlocked position.
5.Reconnect power to the refrigerator.
6.Dispense water from freezer door. Throw away the first few glasses.
7.Check all connections for leaks. Tighten as necessary.
16
INTERIOR TEMPERATURE CONTROL (continued)
17
NORMAL OPERATION
1
For normal operation, set the dials as shown below:
ADDITIONAL COOLING ON REFRIGERATOR COMPARTMENT SIDE
2
Use this setting when food is to be stored at low
temperatures. This setting is likely to be frequently used
during warmer months. Temperature dials should be set at
7–9, as needed.
FREEZER REFRIGERATOR
COMPARTMENT COMPARTMENT
1
3 5
7
9
1
3
5
9
7
FREEZER REFRIGERATOR
COMPARTMENT COMPARTMENT
Refrigerator
Compartment
Freezer
Compartment
(or)
1
3 5
7
9
1
3
5
9
7
(or)
Refrigerator
Compartment
Freezer
Compartment
Operation
Operation
18
INTERIOR TEMPERATURE CONTROL (continued)
ADDITIONAL COOLING ON FREEZER COMPARTMENT SIDE
3
Use this setting when food is to be stored for longer periods
of time.
FREEZER REFRIGERATOR
COMPARTMENT COMPARTMENT
Refrigerator
Compartment
Freezer
Compartment
(or)
(or)
A SMALL AMOUNT OF FOOD IS STORED
4
Use this setting when food is to be stored at warmer
temperatures.
FREEZER REFRIGERATOR
COMPARTMENT COMPARTMENT
Refrigerator
Compartment
Freezer
Compartment
1
3 5
7
9
1
3
5
9
7
1
3 5
7
9
1
3
5
9
7
OPERATION OF THE CUSTOM DISPENSER
(1)
OPERATION OF TFJ30PF, TFJ28PF & TPJ24PF TYPE CUSTOM DISPENSER
When the Touch Key Sign is lightly pushed, a green light will
come on with a “beep” sound. Large ice cubes (half-moon
shape) are dispensed by pushing the pad with a glass.
Operation
19
The custom dispenser is a unique GE feature that allows dispensing of ICE CUBES, CRUSHED ICE,
and COLD WATER by touch key or by a pad switch without the door being opened.
1. DISPENSING ICE CUBES
When the Touch Key Sign is lightly pushed, a green light will
come on with a “beep” sound. Crushed ice is dispensed by
pushing the pad with a glass.
2. DISPENSING CRUSHED ICE
When the Touch Key Sign is lightly pushed, a green light will
come on with a “beep” sound. Cold water is dispensed by
pushing the pad with a glass.
NOTE: DO NOT OBSTRUCT THE CRUSHED ICE OR
ICE CUBE CHUTE WITH YOUR FINGER OR ANY
KIND OF OBJECT.
3. DISPENSING COLD WATER
1.Normally, when the pad is pushed to dispense ice or cold
water, the light comes on. When the pad is released, the
light goes off.
2.The light may be turned on by setting the switch to “ON.”
• USING THE LIGHT SWITCH
Push the
Pad
Light
Switch
Pad
Light
Switch
Pad
Push the
Pad
(THE CUSTOM DISPENSER REQUIRES A WATER SUPPLY PIPING SYSTEM INSTALLATION.)
Operation
20
OPERATION OF THE CUSTOM DISPENSER (continued)
(2)
TFJ30PR, TFJ28PR, TFJ25PR, TPJ24PR, TPJ24BR, TFJ22PR, TFJ20JR
TYPE CUSTOM DISPENSER
Large ice cubes (half-moon shape) are dispensed by setting
the lever to the right and pushing the pad in the center with a
glass or other type of container.
1. DISPENSING ICE CUBES
Crushed ice is dispensed by setting the lever to the center and
pushing the pad in the center with a glass or other type of
container.
2. DISPENSING CRUSHED ICE
Cold water is dispensed by setting the lever to the left and
pushing the pad in the center with a glass or other type of
container.
NOTE: DO NOT OBSTRUCT THE CRUSHED ICE OR
ICE CUBE CHUTE WITH YOUR FINGER OR ANY
KIND OF OBJECT.
3. DISPENSING COLD WATER
1.The light is kept off by positioning the lever to the left.
Even when the lever is set to “OFF,” the light will come on
and go off whenever the ice and cold water dispensing pad
is pushed or released.
2.To turn the light on, set lever to the right.
4. USING THE LIGHT LEVER
Selector
Switch
Light Lever
Water
OPERATION OF THE CUSTOM DISPENSER (continued)
(3)
OPERATION OF ICEMAKER (AUTOMATIC ICE-MAKING APPARATUS)
GE Icemaker (automatic ice-making apparatus) does not
require manual water supply. Following completion of
installation of the water supply piping system, lower the
feeler arm switch to “ON.” Ice is now automatically made
and the icemaker will automatically shut off when the bucket
is filled with set amount of ice.
Operation
21
1.While holding bottom of the icemaker compartment cover,
gently push upward.
2.Pull forward to remove the icemaker compartment cover
and ice bucket together.
To replace ice bucket, push it straight back until it clicks in
place. If the ice bucket does not seat completely due to an
interference of the rotating wing on the back wall, pivot the
rotating wing by hand approximately 1/3 turn and retry.
1. REMOVING THE ICE BUCKET
Any spilled ice or water will evaporate naturally from the
bottom of the custom dispenser. If juice or other liquid is
spilled, however, residues will remain even if the water has
evaporated. Remove the recess cover and wipe with a warm,
damp cloth.
2. CLEANING THE CUSTOM DISPENSER
Feeler Arm
Switch
ON
Ice Bucket
Wing
Recess
Cover
Operation
22
UTILIZING THE INTERIOR SPACE
REFRIGERATOR COMPARTMENT SHELVES
1
Each shelf is adjustable, enabling space to be utilized
without waste.
1.To remove shelf, lift the front end slightly, while
unhooking it from the slot in the back.
2.To install shelf, lift the front end and insert the
hooks into the slots at desired height, and lower
front end to lock in securely.
FREEZER COMPARTMENT SHELF
2
To remove shelf, pull forward and lift slightly.
Unhook
2
Insert Hooks
1
Lift Up
1
Lower Front
2
(or)
AIRTIGHT SNACK CASE (or) MEAT/SNACK CASE
3
Unwrapped foods can be stored in the airtight snack
case without losing the unique moisture of food.
For example, the snack case is best suited for storing
foods such as cheese, bacon, hors d’oeuvres, jam,
paste, etc.
• When the lever is set on high humidity, the case
becomes airtight, preventing moisture from
escaping into the refrigerator compartment. The
airtight case allows food to be stored for relatively
long periods of time without losing moisture
content.
• When the lever is set on low humidity, the vent
between the case and the refrigerator compartment
opens, allowing air circulation. On this setting,
foods can become dry. Therefore, this setting is
appropriate for foods that do not require moisture.
(or)
Push down on tab
while lifting up on shelf.
1
Rotate shelf up,
then pull to the right.
2
Icons
Lever
High Humidity Low Humidity
Icons
UTILIZING THE INTERIOR SPACE (continued)
23
HIGH HUMIDITY VEGETABLE COMPARTMENT
4
This compartment is designed to maintain good internal
airtightness, allowing vegetables to be stored without losing
freshness. It is normal for water to accumulate in the
compartment due to differences in temperature and vegetable
moisture content. Vegetables should be stored in plastic or
paper wrappings to prevent water accumulation.
To prevent vegetables from spoiling, drain water and wipe
compartment dry if water accumulates.
Operation
Meat/Snack Case
High Humidity
Vegetable
Compartment
Temperature
Control Lever
Chilling/Vegetable
Compartment
When lever is set on high humidity, the case
becomes airtight, preventing moisture from
escaping into the refrigerator compartment. The
airtight case allows foods to be stored for
relatively long periods of time without losing
moisture content.
When lever is set on low humidity, the vent
between the case and the refrigerator compartment
opens, allowing air circulation. On this setting,
foods can become dry. Therefore, this setting is
appropriate for foods that do not require moisture.
(or)
(or)
Icons
Icons
Lever
High Humidity
Low Humidity
Lever
High Humidity
Low Humidity
UTILIZING THE INTERIOR SPACE (continued)
Operation
24
CHILLING/VEGETABLE COMPARTMENT
5
For use as a chilling compartment, set lever to the
lower position. Cold air will circulate from the
freezer compartment and will be suitable for
storing food at a lower temperature.
For use as a vegetable compartment, set lever to
the upper position. Cold air from the freezer
compartment will not circulate into this
compartment and vegetables can be stored.
Set control to the upper position if room
temperature is below 10°C. to prevent water
dispenser tank from freezing.
Frost may form if the lever is set at the lower
position for a long period of time.
ADJUSTABLE HEIGHT DOOR POCKET
6
Both large and small items can be stored in this box-type
shelf. The container can be removed from the door and
conveniently carried to a table or counter.
(or)
Icons Icons
UTILIZING THE INTERIOR SPACE (continued)
25
QUICK-SERVE SHELF WITH SERVING DISHES
7
The 4 serving dishes with transparent lids are part of the
quick-serve shelf and can be used to store cooked foods
directly in the refrigerator or freezer compartment.
The serving dishes are microwave- and dishwasher-safe.
NOTE: Some models are equipped with only 2 dishes.
WINE RACK
8
Mount the wine rack on refrigerator shelf and cool your
favorite wine.
REMOVAL OF AIRTIGHT SNACK CASE AND REPLACING THE INTERIOR LIGHT BULB
9
1.To remove the airtight snack case:
• Pull the case forward, lifting slightly.
2. To replace the interior light bulb:
• Remove the glass shelf above the airtight snack case by
pulling it forward and unhooking it from the adjustable
height fixtures.
• Remove the lamp cover on back of snack case. Remove
lamp cover by lifting the insertion lip on the upper part of
lamp cover, then pulling the lower insertion lip out.
• Replace one or both interior light bulbs that are burned out.
• Use only a 40W bulb.
Operation
UTILIZING THE INTERIOR SPACE (continued)
Operation
26
REFRIGERATOR COMPARTMENT MINI-DOOR
(TFJ30PF, TFJ28PF, TPJ24PF ONLY)
10
The refrigerator mini-door allows drinks to be removed from
the refrigerator without opening the main door. It also serves
as a service counter for glasses or small dishes.
The energy saving design prevents cold air from escaping
from the refrigerator.
• The refrigerator compartment mini-door becomes a
convenient and simple food preparation counter when
opened by pulling the handle forward while lifting up.
• The refrigerator mini-door allows a small amount of cold
air to flow from the freezer compartment through a small
hole to cool stored foods.
• There is a lid inside the mini-door (inside refrigerator door)
to prevent cold air from escaping.
• Foods that require frequent retrieval (such as juice) should
be stored in the door pocket provided.
• The door pocket of the refrigerator mini-door may be
removed; be certain however, to return it to the designated
position (highest hook) when reattaching.
Freezer Air
Lift to
Access
Lower When
Finished
Insert in
Top Slot
ELECTRONIC MONITOR & DIAGNOSTIC SYSTEM
DOOR-LEFT-OPEN MONITOR
1
• If the freezer or the refrigerator compartment door is left open more than 6 mm, a red
light will flash until the door is completely closed.
Operation
(TFJ30PF, TFJ28PF, TPJ24PF)
Light will flash if any door is left open.
Light will come on when the system is set to sound
an alarm if a door is left open more than 30
seconds.
Light will come on and warn if the temperature in
the freezer compartment rises higher than normal.
Light will come on if the diagnostic system
determines there is no problem.
The diagnostic codes displayed below will flash to
indicate the following warnings:
“FF” Check food stored in the freezer compartment.
“PF” Power failure.
“CI” Icemaker malfunction.
“dE”Defrosting system malfunction.
To perform the 4 coded performance tests, push this
key lightly.
These keys allow the following selections:
COLD WATER CRUSHED ICE ICE CUBES
REFRIGERATOR INTERIOR TEMPERATURE MONITOR
3
• If the interior temperature of the freezer compartment remains unusually high for a
long period of time (1–4 hours), a red light will come on. This red light will go off
when interior temperature returns to normal.
CAUTION: When the refrigerator is first plugged in, the red light will stay on for
several hours until the interior temperature goes down. This is not a malfunction. In
order to allow the temperature to cool faster, do not open the door. In addition, the red
light may come on if the freezer door is left open and the interior temperature goes
up. If this occurs, and in order to lower the interior temperature as quickly as possible,
do not open the door.
KEY TO SET “DOOR-LEFT-OPEN WARNING”
2
• To set the “DOOR-LEFT-OPEN” warning, push key lightly. Agreen light will come
on accompanied by a “beep” to indicate that the warning is set.
• If the freezer or the refrigerator compartment door is left open more than 30 seconds
while this warning is set, a continuous “beep” will sound until the door is completely
closed.
• To stop the warning sound, push the key once to release setting. The green light will
also go out.
27
1
2
3
4
5
6
7 7
1
2
3
4
5
6
7
Operation
28
ELECTRONIC MONITOR & DIAGNOSTIC SYSTEM
INDICATOR LIGHT FOR NORMAL OPERATION
4
• A green light indicates normal operation of refrigerator.
• If a malfunction occurs, the normal operation indicator light will go off and one of the
malfunction diagnosis codes (FF, PF, CI, dE) will start flashing in one of the 5
malfunction diagnosis code display windows.
(TFJ30PF, TFJ28PF, TPJ24PF)
MALFUNCTION DIAGNOSIS CODE DISPLAY WINDOW
5
• If a malfunction occurs, the electronic monitor will automatically detect and diagnose,
and the appropriate malfunction diagnosis code green light will flash. (The first 6
blinkings will be accompanied by a beeping, warning sound.)
• If more than one malfunction occurs simultaneously, the malfunction indicator code
for the most serious malfunction will flash. When this light goes off, the next most
serious malfunction indicator code will start flashing.
• The malfunction diagnosis codes are as follows:
“FF” FREEZER MALFUNCTION
“PF” POWER SOURCE MALFUNCTION
“CI” ICEMAKER MALFUNCTION
“dE” DEFROSTER MALFUNCTION
SELECTION TOUCH KEY
7
• This unique GE custom dispenser feature allows ice cubes and crushed ice to be
dispensed without opening the door.
• When the appropriate key for ice cubes, crushed ice, or cold water is lightly pushed,
the selected sign will be lighted with a green light, accompanied by a beeping sound.
• When the button switch (pad) is pushed with a glass, the selected ice cubes, crushed
ice, or cold water will be automatically dispensed.
SYSTEM CHECK/RESET KEY
6
• By pushing this key, all 4 malfunctions can be checked in the order of seriousness.
• If this key is pushed while one of the malfunction codes is flashing, the malfunction
code will disappear and the system will automatically check for other malfunctions.
(Flashing of the second malfunction indication code will also be accompanied by 6
beeping, warning sounds, as mentioned above.)
• If no other malfunction is found, the system will continue checking until key is reset.
ICE
CUBES
CRUSHED
ICE
COLD
WATER
ELECTRONIC MONITOR & DIAGNOSTIC SYSTEM
Operation
(TFJ30PF, TFJ28PF, TPJ24PF)
29
DEFINITIONS OF MALFUNCTION DIAGNOSIS CODES AND
CORRESPONDING CORRECTIVE MEASURES
• If the FF code flashes with a green light, this indicates that the freezer compartment interior
temperature has been unusually high for some time (2–6 hours). Check the following items
immediately:
• Check for objects that may prevent the freezer or the refrigerator compartment door from closing
completely.
• Minimize opening and closing of door to lower the interior temperature of the freezer compartment
quickly. If the reset key is pushed the FF light will go out and the diagnostic system will continue
checking for any other malfunctions. If the normal operation code key is pushed and the PF code light
comes on but the normal operation code light does not, there may be a power failure or another
temporary interruption of power source.
• Wait until it is cool to call for service (may take several hours).
(1)
FREEZER COMPARTMENT MALFUNCTION: “FF”
• If the PF code flashes with a green light, this indicates that the electricity has been interrupted for more
than 2 seconds. The freezer and refrigerator compartments should be checked. If the reset key is
pushed, the PF light will go out and a diagnosis can be made whether there are any other malfunctions
present. PF is not a mechanical malfunction.
(2)
POWER SOURCE MALFUNCTION: “PF”
• If the dE code flashes with a green light, this indicates that the defrosting operation has not been
performed during the past 64 hours.
• If this code flashes, a service call is needed for repair work.
(4)
DEFROSTING MALFUNCTION: “dE”
• If the CI code flashes with a green light, this indicates that the automatic icemaker is malfunctioning.
Check the following items immediately:
• Is arm switch of the icemaker blocked by ice cubes? (Remove the ice).
• Is dedicated icemaker water supply valve open? (Open valve.)
• Is icemaker arm switch in the “ON” position with the water supply piping connection not properly
installed? (Set to “OFF.”)
• Is thickness of ice more than 1.2 cm? (If thickness of ice is less, open the valve wider to increase the
water supply.)
• If the reset key is pushed, the CI light goes out and a check can be made whether there are any other
malfunctions. If the CI light flashes again, a service call is needed.
(3)
ICEMAKER MALFUNCTION (AUTOMATIC ICEMAKER): “CI”
Operation
30
STORAGE OF FOOD
When storing foods, place items requiring colder temperatures (meats, cakes, etc.) near the cold air
inlet, while placing items which are not to be subjected to dewing or icing (vegetables, fruit, etc.) in
the lower areas.
Beer and juices should be stored in the door pockets, while butter and cheeses should be stored in the
upper portion of the door (astro-door type utility compartment) where the temperature is relatively high.
1.Bottles should not be stored inside the freezer because they may break.
2.Do not store plasma or vaccines in this refrigerator. In addition, volatile or
flammable substances should never be stored in refrigerators.
3.Avoid leaving the door open. Do not open and close the door unnecessarily.
4.Do not store hot foods without cooling them first.
5.Do not store ice cream in the door pocket.
(1)
STORAGE OF FOOD
(2)
WARNINGS ABOUT FOOD STORAGE
1.Provide space
between items in the
refrigerator. Packing
items too densely will
reduce circulation of
cold air, reducing
cooling.
2.If foods stored in the
freezer are not sealed
airtight, water
condensation could
occur on the surface
of the refrigerator’s
cold walls and
dampen contents by
dewing. Therefore,
when storing, use
airtight containers or
plastic wrap.
DANGER WARNING WARNING CAUTION
Do not store bottles
or cans in freezer
compartment.
Flammable ether, benzene,
alcohol, medicine, LP gas,
etc., should not be stored.
Do not store medicine or
scientific specimens in
refrigerator.
Do not store hot foods.
Cool them first.
CRACK!
SPRAY
LP GAS
THINNER
GLUE
ETHER
• Contents will
freeze and
broken glass may
cause injuries.
• Danger of
explosion.
• Items requiring
strict temperature
control should
not be stored in a
household
refrigerator.
NO
BOTTLES
DON’T
STORE
DON’T
STORE
FOODS
SHOULD BE
COOLED FIRST
WHAT TO KNOWABOUT FROZEN FOODS
(1)
METHODS OF SELECTING AND USING STORE-BOUGHT FROZEN FOODS
There are approximately 3,000 varieties of frozen food on the market
at the present time. Store-bought frozen foods are wholesome, high
in nutritional value and easy to prepare. Spoilage or food poisoning
are of no concern. The most attractive feature of frozen food is its
longevity (1–3 months). As long as you have frozen items on
hand in the freezer, it is easy to prepare a splendid meal on short
notice, with minimal concern should unexpected guests drop in.
1.Select items preserved in a showcase, indicating a temperature
below -18°C.
2.Select items with an approval label from the Japan Frozen Food
Association.
3.Select items with the latest manufacturing date.
4. Select items with proper shape and that are frozen hard.
5.Select items without torn wrappings.
6. Avoid items with obscured view of contents due to excessive
frosting. They may have been re-frozen.
(2)
BASIC THINGS TO KNOW ABOUT HOME FREEZING
1.Food items should be fresh. Freshness is most important to
ensure tasty frozen food.
2.Cool food before freezing. If a hot item is placed inside the
freezer, the freezer will warm up, affecting other food items.
3.Always seal products in an airtight container or wrapping in
order to prevent changes in food. In addition, liquids should be
stored in containers with extra volume to accommodate
expansion.
4.Freeze single servings measured according to the size of your
family.
5.Arrange in thin packages and freeze quickly. The trick for good
home freezing is “quick freezing,” which is why packaging
should be thin.
6.Set freezer dial to HIGH cooling (9). Return dial to original
(normal) setting after freezing is complete.
7.Door should be kept closed as much as possible.
Operation
• TIPS FOR SELECTION
1.Thaw only the amount needed. Only the needed portion should
be thawed by breaking the selection into small pieces or cutting
it with a saw.
2.Do not thaw completely. The correct stage for cooking is
reached when edges become soft but the core is still frozen.
3.Food should be cooked as soon as it is thawed.
4.Use the appropriate thawing method prescribed for each
particular food.
• TIPS FOR THAWING
• THE FUNDAMENTALS OF FREEZING
31
Seal
CARE AND CLEANING OFREFRIGERATOR
Care, Cleaning
& Self-Diagnosis
Parts that can be removed should be washed. Dry parts before
returning. Use a small amount of mild detergent if needed.
(Detergent should be wiped clean.)
CAUTION: Use mild detergent and warm water to
avoid damaging paint or plastic.
(1)
REFRIGERATOR INTERIOR
MILD
DETERGENT
Wipe off whenever exterior surfaces are dirty or wet. Apply
suitable wax to the refrigerator exterior several times a year.
(2)
REFRIGERATOR EXTERIOR
The door gasket will deteriorate quickly if liquid food or juice are
spilled on it. Clean the door gasket in the same way as
refrigerator interior.
(3)
DOOR GASKET
FREEZER COMPARTMENT
Remove the lamp cover before replacing the bulb.
NOTE: On some models, a screw must be removed
before removing the lamp cover.
REFRIGERATOR COMPARTMENT (upper light bulb)
1.Pull out the 2 knobs
or dials.
2.Remove cover by
turning it upward or
by pulling it outward.
3.Turn lamp to the left to
remove and replace it.
4.Use only a 40W bulb.
A B C D E
Freezer Control
C is Initial Setting
E is Coldest
OFF 13579
(5)
REPLACING THE LIGHT BULB
Remove front grille when adjusting height of refrigerator or when
cleaning the condenser.
1.To remove the grille, hold the bottom of grille and pull
forward.
2.To install the grille, hold both ends of grille and push prongs
into holes.
Vacuum once or twice a year, since dirt on the condenser will
decrease efficiency, increase electricity consumption, and reduce
cooling capacity of the refrigerator.
(4)
CONDENSER
32
Condenser
Grille
Grille
Prong
Grille
Hole
SELF-DIAGNOSIS
Care, Cleaning
& Self-Diagnosis
• Is the floor firm?
If the floor is unsteady, noise level will increase.
• Are there any trays leaning against the side of the
refrigerator? These trays may produce a resounding noise.
• Are there any food items with high water content?
Refer to page 30 for food storage.
(4)
WATER ACCUMULATION INSIDE
• Is interior of the refrigerator clean?
A dirty interior is the main source of odor.
• Are there any foods with a strong odor?
These can produce a bad combination odor with other food odors.
(5)
BAD ODOR
• Is the setting of the temperature control dial correct?
Refer to page 15.
• Are foods stored properly?
If cold air hits them directly, some
foods may freeze.
(6)
FOODS FREEZE IN REFRIGERATOR
• Is the air flow to the condenser adequate?
If the air flow is inadequate, cooling will not occur.
• Is the door opened/closed frequently?
Cold air will escape if door openings/closings are frequent.
• Is the temperature control dial set correctly?
Refer to page 15.
★ Is interior fan of the refrigerator working?
If the fan is not working, cold air will not circulate and
cooling will not occur.
★ Is there a gap in the door?
If a gap exists, cold air will escape and cooling will not occur.
★ Is frost built up too thick?
★ Is refrigerator being defrosted?
If timer is set to defrost, cooling will not occur.
“Let’s Find Out On Our Own”
★ Indicates that the item’s self-diagnosis is
difficult. To clarify, consult dealership where
the unit was purchased.
33
(1)
NO COOLING
(3)
NOISY
• Is the electricity on?
1. Is power cord plugged in?
2. Is fuse (breaker) blown?
3. Is there a blackout?
★ Is the compressor working?
(2)
POOR COOLING
WARRANTYAND AFTER-SER VICE
(PLEASE READ CAREFULLY)
Warranty &
After-Service
34
A WARRANTY GUIDE, THE “WARRANTY NOTE,” FOR THE GE
FREEZER/REFRIGERATOR WHICH YOU HAVE JUST PURCHASED IS ATTACHED
AS ASEPARATE BOOKLET TO THIS OPERATIONS GUIDE.
SINCE IT IS AN IMPORTANT BOOKLET FOR AFTER-SERVICE, ETC., KEEPIT IN
A SAFE PLACE ALONG WITH THIS BOOKLET.
• WARRANTY PERIOD—One year from the date of purchase.
If the malfunction cannot be corrected after following the instructions on page
33, a service call for repair work should be placed to the dealership where the
unit was purchased. Warranty applies only to repair of the appliance hardware
itself and to no other items such as food, etc.
• DURING WARRANTY PERIOD:
Please present the “WARRANTY NOTE” when repair work is performed. In
accordance with the “WARRANTY NOTE,” the dealership where the unit
was purchased will dispatch a repairman for the job. If you do not contact the
dealership, please contact GE APPLIANCES JAPAN, INC.
The following information is to be reported to the dealer or to this company:
1.Customer’s name, address and telephone number
2.Model of refrigerator
3.Details of problem
Refer to the chapter on “Self-Diagnosis” in this OPERATIONS GUIDE and
provide answers to the serviceman’s questions.
When a serviceman visits, show him the “WARRANTY NOTE” attached to
this guide.
The minimum warranty period (for parts that are required to maintain
performance function) is 9 years from the last manufacturing date.
This period is established in accordance with MITI directives.
The freezer cycle coolant system has a five-year warranty.
REQUESTING
REPAIR WORK
MINIMUM
WARRANTY PERIOD
FOR FUNCTIONMAINTENANCE
PARTS
LARGE ELECTRICAL
APPLIANCES
“WARRANTY NOTE”
WARRANTYAND AFTER-SER VICE
(PLEASE READ CAREFULLY)
THIS MARKING ON AREFRIGERATOR DENOTES THAT IT IS A
“PRODUCT THAT MEETS THE ‘96 SPECIFIED FREON REGULATION.”
Refrigerators use Freon for their freezing apparatus and heat insulators. Freon is
non-flammable and not harmful to the human body directly. Furthermore, it
possesses excellent properties which have made it one of the most useful chemical
substances and contributed to the development of modern civilization.
In its capacity as a cleaning agent, propellant, and for its use in refrigerators,
however, it is thought to have caused the depletion of the atmospheric ozone layer.
The decision was made to cease worldwide production of this substance completely
and to switch to a substance which has less impact on the ozone layer.
‘96 SPECIFIED FREON
REGULATION
REFRIGERATOR
LOVING CARE
INSPECTION
• INSPECTION OF OLDER MODEL REFRIGERATORS
Are these
symptoms
present?
• Unusually hot power cord
and plug
• Damaged power cord
• Burning smell
• Accumulation of water
under refrigerator
• Electric shock
• Other malfunction and
breakdown
Request
Unplug the
power plug to
prevent
breakdown or
accident and
consult the
dealership
where the unit
was purchased
for inspection
or repair.
¹
USEFUL
INFORMATION
FOR
REQUESTING
SERVICE
Date Purchased
Dealership
Year Month Day Model #
Phone ( )
TFJ30PF
TFJ28PR
TPJ24PR
TFJ20JR
TFJ30PR
TFJ25PR
TPJ24BR
TFJ28PF
TPJ24PF
TFJ22PR
WARRANTY BUSINESS INFORMATION CENTER IN JAPAN
GE APPLIANCES JAPAN, INC.
Marusukomamachi Bldg. 4F
3-3 Komamachi, Chiyoda-Ku
Tokyo, Japan 102
TEL: (03) 3265-5570 (Main)
FAX: (03) 3265-5131
DEALERSHIP
162D9792P002 49-6896
35
Warranty &
After-Service
Loading...
