Page 1
GE Profile™ and GE® CustomStyle™ Side-by-Side Refrigerators
dreams come true
The built-in look you’ve dreamed of
without the built-in expense
Page 2
Panel-ready refrigerators*—23 cu. ft. capacity
Cutout dimensions 69-1/4" H x 23-7/8" D x 35-3/4" W
Handle/Dispenser color Model/Feature pack!** Panel choices
White Stainless steel, White, Bisque or Black
Bisque Stainless steel, White, Bisque or Black
Black Stainless steel, White, Bisque or Black
■ PSH23PGS
■ PSI23NGR
■ PSI23MGR
■ PSI23NCR
(non-dispenser model)
■ PSI23NGR
■ PSH23PGS
■ PSI23NGR
■ PSI23MGR
†
acrylic panels from GE® or custom-made
panels in cabinet-matching wood or any
material and color you care to dream up.
Ask your sales associate about
ordering custom-made panels in
cabinet-matching wood or any material
and color you care to dream up.
acrylic panels from GE or custom-made
panels in cabinet-matching wood or any
material and color you care to dream up.
acrylic panels from GE or custom-made
panels in cabinet-matching wood or any
material and color you care to dream up.
■ PSI23NCR
(non-dispenser model)
Ask your sales associate about
ordering custom-made panels in
cabinet-matching wood or any material
and color you care to dream up.
Panel-ready refrigerators*—25 cu. ft. capacity
Cutout dimensions 72" H x 23-7/8" D x 35-3/4" W
Handle/Dispenser color Model/Feature pack!**
Black
■ PSH25NGS
■ PSH25MGS
†
†
Panel choices
Ask your sales associate about
ordering custom-made panels in
cabinet-matching wood or any material
and color you care to dream up.
*Panels sold separately.
** Color code indicates feature pack. See far right page for details. ■ = K- and L-Series ■ = M-Series ■ = N- and S-Series ■ = P-Series
†ENERGY STAR®-qualified
Page 3
No-panel refrigerators—23 cu. ft. capacity
Cutout dimensions 69-1/4" H x 23-7/8" D x 35-3/4" W
Exterior color Handle style Model/Feature pack!**
Stainless
Steel
Stainless Steel
sculptured handle
Full-length
visor handle
Stainless Steel
tubular handle
P
N
M
■ PSC23PSS
■ PSW23PSS† (stainless-wrapped)
■ PSC23SHR (refreshment center model)
■ PSC23SGR
■ PSH23PSS
■ PSI23SGR
■ PSI23SCR (non-dispenser model)
■ GCL22KGR (GE CleanSteel™)
■ GSC23LSR (GE)
†
†
White
Bisque
Color-matched
sculptured handle
Color-matched
full-length handle
Color-matched
sculptured handle
■ PSC23NGS
■ PSC23MGS
■ GSC23LGR (GE)
■ GSC22KGR (GE)
■ PSC23NGS
■ PSC23MGS
Black
** Color code indicates feature pack. See far right page for details. ■ = K- and L-Series ■ = M-Series ■ = N- and S-Series ■ = P-Series
†ENERGY STAR-qualified
Color-matched
sculptured handle
Color-matched
full-length handle
■ PSC23NGS
■ PSC23MGS
■ GSC23LGR (GE)
■ GSC22KGR (GE)
Page 4
No-panel refrigerators—25 cu. ft. capacity
Cutout dimensions 72" H x 23-7/8" D x 35-3/4" W
Exterior color Model/Feature pack!**
Stainless
Steel
White
Handle style
Stainless Steel
sculptured handle
Full-length
visor handle
Color-matched
sculptured handle
■ PSC25PSS
■ PSC25SGS
■ PSC25MSS
■ PSH25PSS
■ PSH25SGS
■ PSH25MSS
†
†
†
†
†
†
■ PCF25PGS† (high-gloss finish)
■ PSC25MGS
†
Black
Color-matched
sculptured handle
** Color code indicates feature pack. See far right page for details. ■ = K- and L-Series ■ = M-Series ■ = N- and S-Series ■ = P-Series
†ENERGY STAR-qualified
■ PCF25PGS† (high-gloss finish)
■ PSC25NGS
■ PSC25MGS
†
†
Page 5
K-Series, L-Series feature pack includes:
SmartWater™ filtration system • LightTouch! tall dispenser with child lock • FrostGuard™ technology
GE models: GCL22KGR, GSC22KGR, GSC23LSR, GSC23LGR
M-Series feature pack includes:
K, L features PLUS:
Slide-out, spillproof glass shelves
Simplify loading, unloading and cleaning
ClimateKeeper™ system
Combines electronic touch controls and
sensors to keep temperatures consistent
Integrated Ice™ system
The ice bucket is integrated into the
icemaker. It pulls out and down,
providing easy access to cubed ice.
Slide-out, spillproof glass shelves
Integrated Ice system
GE Profile™ models: PSC25MSS, PSH25MSS, PSC25MGS, PSH25MGS, PSC23MGS, PSI23MGR
N-Series, S-Series feature pack includes:
K, L, M features PLUS:
CustomCool™ technology
Chills in minutes, thaws in hours, and
helps keep foods fresher, longer
Digital temperature display
Takes the guesswork out of setting
accurate temperatures
Slide ‘n Store™ full-extension
freezer baskets
Extends 16" for easy loading
and unloading
It chills!
CustomCool technology
It thaws!
Digital temperature display
GE Profile models: PSC25SGS, PSH25SGS, PSC25NGS, PSH25NGS, PSC23SHR, PSC23SGR,
PSI23SGR, PSI23SCR, PSC23NGS, PSI23NGR, PSI23NCR
P-Series feature pack includes:
K, L, M, N, S features PLUS:
ClimateKeeper2™ system
Unique dual-evaporator system keeps
foods garden fresh longer and protects
ice from odor transfer
Beverage Center
Keeps beverages icy cold and
easily accessible
LED lighting
Provides long-lasting illumination for
the LightTouch! tall dispenser
ClimateKeeper2 system
Beverage Center
GE Profile models: PSC25PSS, PSH25PSS, PCF25PGS, PSC23PSS, PSH23PSS, PSH23PGS, PSW23PSS*
*PSW23PSS has a stainless-wrapped case
Refer to GE Retail Catalog of Appliances for a complete list of features.
Page 6
How to realize your dream
Top View
35-3/4" width 35-3/4" width
Top View
69-1/4"
height
72"
height
23-7/8"
depth
to case
27-1/8"
depth
to door
23-7/8"
depth
to case
26-3/4"
depth
to door
Top View
69-1/4"
height
23-7/8"
depth
to case
26-3/4"
depth
to door
Panels or no panels? What’s your size?
25 cu. ft. capacity
Design options to suit your style
The look you want is easy to achieve with CustomStyle
side-by-side refrigerators. Choose from models designed
to accept stainless steel or
acrylic panels, or cabinet-
23 cu. ft. capacity
matching, custom-made
wood panels. In fact, panels
can be made from any
material you care to dream
up—and easily slide into place.
If you prefer, stylish no-panel models are available in a
choice of colors, including stainless steel, and a variety
of handle styles. Both panel-ready and no-panel models
are available in 23 and 25 cu. ft. sizes.
By deciding whether you prefer a CustomStyle refrigerator
with panels or without, you’ve narrowed the choices down.
A few simple steps make your dreams come true
Choosing your CustomStyle refrigerator is easy. First, a
tape measure will determine which model size fits the
existing opening in your kitchen. Height makes the
difference. The width and case depth on 23 and 25 cu. ft.
models are identical, but the 25 cu. ft. model is slightly taller.
Now all that’s left is for you to choose your favorite color,
handle style, and your must-have list of features. The
remaining pages of this brochure will guide you to the final
selection of the CustomStyle side-by-side refrigerator that
makes your dream kitchen a reality.
Page 7
Your dream kitchen starts with
a CustomStyle™ refrigerator.
With custom panels Without panels
This is the stuff dreams are made of.
GE Profile™ and GE® CustomStyle
side-by-side refrigerators grace your
kitchen with the look of built-in styling
without the expense of a built-in.
Counter-depth styling allows
CustomStyle refrigerators to blend in
almost seamlessly with surrounding
cabinetry. These units simply slide into
the space between cabinets, for the
built-in look you envisioned.
With counter-depth styling, GE’s
CustomStyle refrigerator makes
your kitchen new! While your old
refrigerator extended up to 33" from
the wall, protruding more than 6"
beyond the depth of countertops and
cabinets, the CustomStyle side-by-
side extends just 26-3/4" from the
wall.* It slides right into the same
opening as your old refrigerator,
and thanks to that 6 inches saved,
fits almost completely flush with
surrounding cabinetry. Just one
simple step, and your new
CustomStyle refrigerator updates
your kitchen, giving you the sleek,
built-in look you’ve dreamed of…
without the expense of a built-in.
*for 23 cu. ft. models
Most
refrigerators
extend up to
33" from
the wall
CustomStyle
refrigerators
extend just
26-3/4" from
the wall,
saving you
six inches!*
Page 8
From old to new
Your dream kitchen is born
It’s like a one-step kitchen renovation!
Simply replace your old refrigerator
with a GE® or GE Profile CustomStyle™
side-by-side. In an instant you have
the built-in look you’ve dreamed of,
without the expense of a built-in.
ENERGY STAR
®
As an ENERGY STAR partner, GE has
determined that the appliances marked
with the ENERGY STAR logo meet the
ENERGY STAR guidelines for
energy efficiency.
Acrylic and stainless steel
panel options
Optional collar trim:
adding the final touch
The optional collar trim is another way
GE lets you integrate our CustomStyle
side-by-sides into your kitchen décor.
Available in stainless steel, white,
bisque and black, this trim frames
the refrigerator façade, adding to the
finished look of a built-in, custom kitchen.
The following models are ENERGY STAR-qualified:
25 Series:
PSH25NGS
PSH25MGS
PSH25MSS
PCF25PGS
Side-by-side Black acrylic White acrylic Bisque acrylic Stainless steel
Model no. panels panels panels panels
PSI23MGR PSPK23DBB PSPK23DWW PSPK23DCC PSPK23DSS
PSI23NGR PSPK23DBB PSPK23DWW PSPK23DCC PSPK23DSS
PSH23PGS PSPK23DBB PSPK23DWW PSPK23DCC PSPK23DSS
Collar trim
Side-by-side Black White Bisque Stainless steel
Model no. collar trim collar trim collar trim collar trim
PSI23NCR TRMBISBB TRMBISWW TRMBISCC –
PSI23SCR – – – TRMBISSS
PSI23MGR TRMBISBB TRMBISWW TRMBISCC –
PSI23NGR TRMBISBB TRMBISWW TRMBISCC –
PSI23SGR – – – TRMBISSS
PSH23PSS – – – TRMBISSS
PSH23PGS TRMBISBB TRMBISWW TRMBISCC –
PSH25MSS – – – TRM25BISSS
PSH25NGS TRM25BISBB TRM25BISWW TRM25BISCC –
PSH25SGS – – – TRM25BISSS
PSH25MGS TRM25BISBB TRM25BISWW TRM25BISCC –
PSH25PSS – – – TRM25BISSS
PSC25PSS
PSC25NGS
PSC25MGS
PSC25SGS
PSC25MSS
PSH25PSS
PSH25SGS
23 Series:
PSH23PGS
PSW23PSS
PSC23PSS
PSH23PSS
©2005 GE Company
Pub. No. 2-X115-1 PC42214
