microwave
oven
700 watts
model SES0732
GEAppliances.com
Safety Instructions . . . . . . . . . . . . . . 2–5
Operating Instructions
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Changing Power Levels . . . . . . . . . . . . . . . . . 7
Time Features . . . . . . . . . . . . . . . . . . . . . . . 7–10
Convenience Features . . . . . . . . . . . . . . 10, 11
Auto Feature . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Other Features . . . . . . . . . . . . . . . . . . . . . . . . 12
Helpful Information
Microwave Terms . . . . . . . . . . . . . . . . . . . . . . 13
Care and Cleaning . . . . . . . . . . . . . . . . . 13, 14
If Something Goes Wrong . . . . . . . . . . . . . . 14
Things That Are Normal . . . . . . . . . . . . . . . . 14
Microwave Oven Warranty . . . . . 15
Consumer Support . . . . . . . back cover
49-40603-1 02-09 JR
2
OPERATING INSTRUCTIONSSAFETY INSTRUCTIONS
IMPORTANT SAFETY INFORMATION.
READ ALL SAFETY INFORMATION BEFORE USING.
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY
For your safety, the information in this manual must be followed
to minimize the risk of fire or explosion, or to prevent property
damage, personal injury or loss of life.
Do Not Attempt to operate this oven with the door open since
open-door operation can result in harmful exposure to
microwave energy. It is important not to defeat or tamper with
the safety interlocks.
Do Not Place any object between the oven front face and the door
or allow soil or cleaner residue to accumulate on sealing surfaces.
Do Not Operate the oven if it is damaged. It is particularly important
that the oven door close properly and that there is no damage to the:
1 door (bent),
2 hinges and latches (broken or loosened),
3 door seals and sealing surfaces.
The Oven Should Not be adjusted or repaired by anyone except
properly qualified service personnel.
WARNING!
To reduce the risk of burns, electric shock, fire, injury
to persons or exposure to excessive microwave energy:
SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should
be followed, including the following:
• Read and follow the specific “Precautions to Avoid Possible
Exposure to Excessive Microwave Energy” above.
• This appliance must be grounded. Connect only to properly
grounded outlet. See Grounding Instructions section on page 4.
• Install or locate this appliance only in accordance with the
provided Installation Instructions.
• This microwave oven is not approved or tested for marine use.
• Be certain to place the front surface of the door three inches or
more back from the countertop edge to avoid accidental tipping
of the appliance in normal usage.
• Do not store anything directly on top of the microwave oven
surface when the oven is in operation.
• Use this appliance only for its intended use as described in this
manual. Do not use corrosive chemicals or vapors in this appliance.
This microwave oven is specifically designed to heat, dry or cook
food and is not intended for laboratory or industrial use.
• Do not operate this appliance if it has a damaged power cord or
plug, if it is not working properly or if it has been damaged or
dropped.
• Do not cover or block any openings on the appliance.
• Do not store this appliance outdoors. Do not use this product near
water—for example, in a wet basement, near a swimming pool,
near a sink or in similar locations.
• Keep power cord away from heated surfaces.
• Do not immerse power cord or plug in water.
• Do not let power cord hang over edge of table or counter.
• To reduce the risk of fire in the oven cavity:
— Do not overcook food. Carefully attend appliance when paper,
plastic or other combustible materials are placed inside the oven
while cooking.
— Remove wire twist-ties and metal handles from paper or plastic
containers before placing them in the oven.
— Do not use the oven for storage purposes. Do not leave paper
products, cooking utensils or food in the oven when not in use.
— If materials inside oven ignite, keep the oven door closed, turn the
oven off and disconnect the power cord, or shut off power at the
fuse or circuit breaker panel. If the door is opened, the fire may
spread.
• See door surface cleaning instructions in the Care and Cleaning
section(s) of this manual.
• GE does not support any servicing of the microwave. We strongly
recommend that you do not attempt to service the microwave
yourself.
• As with any appliance, close supervision is necessary when used
by children.
• This appliance shall not be installed less than 36″ above the floor
to the bottom of the product. A minimum spacing of 3″ must be
maintained between the microwave oven and the sidewalls.
• This appliance must only be serviced by qualified service personnel.
Contact nearest authorized service facility for examination, repair
or adjustment.
SAVE THESE INSTRUCTIONS
SAFETY INSTRUCTIONS
SPECIAL NOTES ABOUT
MICROWAVING
ARCING
If you see arcing, press the CLEAR/OFF pad and correct the problem.
Arcing is the microwave term for sparks in the oven. Arcing is
caused by:
• Metal or foil touching the side of the oven.
• Foil not molded to food (upturned edges act like antennas).
• Metal, such as twist-ties, poultry pins or gold-rimmed dishes,
in the microwave.
• Recycled paper towels containing small metal pieces being used
in the microwave.
FOODS
• Do not pop popcorn in your microwave oven unless in a special
microwave popcorn accessory or unless you use popcorn labeled
for use in microwave ovens.
• Some products such as whole eggs and sealed containers—for
example, closed jars—are able to explode and should not be heated
in this microwave oven. Such use of the microwave oven could result
in injury.
• Do not boil eggs in a microwave oven. Pressure will build up inside
egg yolk and will cause it to burst, possibly resulting in injury.
• Operating the microwave with no food inside for more than a
minute or two may cause damage to the oven and could start
a fire. It increases the heat around the magnetron and can
shorten the life of the oven.
• Foods with unbroken outer “skin” such as potatoes, hot dogs,
sausages, tomatoes, apples, chicken livers and other giblets,
and egg yolks should be pierced to allow steam to escape
during cooking.
SAFETY FACT
SUPERHEATED WATER
Liquids, such as water, coffee or tea are able to be overheated
beyond the boiling point without appearing to be boiling. Visible
bubbling or boiling when the container is removed from the
microwave oven is not always present. THIS COULD RESULT
IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A SPOON OR OTHER UTENSIL
IS INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
— Do not overheat the liquid.
— Stir the liquid both before and halfway through heating it.
— Do not use straight-sided containers with narrow necks.
— After heating, allow the container to stand in the microwave oven
for a short time before removing the container.
— Use extreme care when inserting a spoon or other utensil into the
container.
• Avoid heating baby food in glass jars, even with the lid off. Make
sure all infant food is thoroughly cooked. Stir food to distribute the
heat evenly. Be careful to prevent scalding when warming formula.
The container may feel cooler than the formula really is. Always test
the formula before feeding the baby.
• Don’t defrost frozen beverages in narrow-necked bottles (especially
carbonated beverages). Even if the container is opened, pressure
can build up. This can cause the container to burst, possibly
resulting in injury.
• Hot foods and steam can cause burns. Be careful when opening
any containers of hot food, including popcorn bags, cooking
pouches and boxes. To prevent possible injury, direct steam away
from hands and face.
• Do not overcook potatoes. They could dehydrate and catch
fire, causing damage to your oven.
• Cook meat and poultry thoroughly—meat to at least an INTERNAL
temperature of 160°F and poultry to at least an INTERNAL temperature
of 180°F. Cooking to these temperatures usually protects against
foodborne illness.
MICROWAVE-SAFE COOKWARE
Make sure all cookware used
in your microwave oven is suitable
for microwaving. Most glass casseroles,
cooking dishes, measuring cups, custard
cups, pottery or china dinnerware which
does not have metallic trim or glaze with a metallic sheen can
be used. Some cookware is labeled “suitable for microwaving.”
• If you are not sure if a dish is microwave-safe, use this test: Place
in the oven both the dish you are testing and a glass measuring
cup filled with 1 cup of water—set the measuring cup either in or
next to the dish. Microwave 1 minute at high. If the dish heats, it
should not be used for microwaving. If the dish remains cool and
only the water in the cup heats, then the dish is microwave-safe.
• If you use a meat thermometer while cooking, make sure it is safe
for use in microwave ovens.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
SAVE THESE INSTRUCTIONS
3
4
SAFETY INSTRUCTIONS
SPECIAL NOTES ABOUT
MICROWAVING (cont.)
• Do not use recycled paper products. Recycled paper towels,
napkins and waxed paper can contain metal flecks which may
cause arcing or ignite. Paper products containing nylon or nylon
filaments should be avoided, as they may also ignite.
• Some styrofoam trays (like those that meat is packaged on) have
a thin strip of metal embedded in the bottom. When microwaved,
the metal can burn the floor of the oven or ignite a paper towel.
• Do not use the microwave to dry newspapers.
• Not all plastic wrap is suitable for use in microwave ovens.
Check the package for proper use.
• Paper towels, waxed paper and plastic wrap can be used to cover
dishes in order to retain moisture and prevent spattering. Be sure
to vent plastic wrap so steam can escape.
• Cookware may become hot because of heat transferred from the
heated food. Pot holders may be needed to handle the cookware.
• “Boilable” cooking pouches and tightly closed plastic bags should
be slit, pierced or vented as directed by package. If they are not,
plastic could burst during or immediately after cooking, possibly
resulting in injury. Also, plastic storage containers should be at
least partially uncovered because they form a tight seal. When
cooking with containers tightly covered with plastic wrap, remove
covering carefully and direct steam away from hands and face.
• Use foil only as directed in this manual. TV dinners may be
microwaved in foil trays less than 3/4″ high; remove the top foil
cover and return the tray to the box. When using foil in the
microwave oven, keep the foil at least 1″ away from
the sides of the oven.
• Plastic cookware—Plastic cookware designed for microwave cooking
is very useful, but should be used carefully. Even microwave-safe
plastic may not be as tolerant of overcooking conditions as are glass
or ceramic materials, and may soften or char if subjected to short
periods of overcooking. In longer exposures to overcooking, the food
and cookware could ignite.
Follow these guidelines:
1 Use microwave-safe plastics only and use them in strict compliance
with the cookware manufacturer’s recommendations.
2 Do not microwave empty containers.
3 Do not permit children to use plastic cookware without
complete supervision.
GROUNDING INSTRUCTIONS
WARNING!
Improper use of the grounding plug
can result in a risk of electric shock.
This appliance must be grounded.
In the event of an electrical short circuit,
grounding reduces the risk of electric
shock by providing an escape wire for
the electric current. This appliance is equipped with a power cord
having a grounding wire with a grounding plug. The plug must be
plugged into an outlet
that is properly installed and grounded.
Consult a qualified electrician or service technician if the grounding
instructions are not completely understood, or if doubt exists as to
whether the appliance is properly grounded.
If the outlet is a standard 2-prong wall outlet, it is your personal
responsibility and obligation to have it replaced with a properly
grounded 3-prong wall outlet.
Do not under any circumstances cut or remove the third (ground)
prong from the power cord.
For best operation, plug this appliance into its own electrical outlet
to prevent flickering of lights, blowing of fuse or tripping of circuit
breaker.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
Ensure proper ground exists
before use.
PREFERRED METHOD
SAVE THESE INSTRUCTIONS
5
SAFETY INSTRUCTIONS
ADAPTER PLUGS
Usage situations where appliance’s
power cord will be disconnected
infrequently.
Because of potential safety hazards
under certain conditions, we strongly
recommend against the use of an
adapter plug. However, if you still
elect to use an adapter, where local codes permit, a TEMPORARY
CONNECTION may be made to a properly grounded two-prong wall
receptacle by the use of a UL listed adapter which is available at most
local hardware stores.
The larger slot in the adapter must be aligned with the larger slot
in the wall receptacle to provide proper polarity in the connection
of the power cord.
CAUTION: Attaching the adapter ground terminal
to the wall receptacle cover screw does not ground the appliance unless
the cover screw is metal, and not insulated, and the wall receptacle
is grounded through the house wiring.
You should have the circuit checked by a qualified electrician to make
sure the receptacle is properly grounded.
When disconnecting the power cord from the adapter, always hold the
adapter with one hand. If this is not done, the adapter ground terminal
is very likely to break with repeated use. Should this happen, DO NOT
USE the appliance until a proper ground has again been established.
Usage situations where appliance’s power cord will be disconnected
frequently.
Do not use an adapter plug in these situations because frequent
disconnection of the power cord places undue strain on the adapter
and leads to eventual failure of the adapter ground terminal. You
should have the two-prong wall receptacle replaced with a
three-prong (grounding) receptacle by a qualified electrician
before using the appliance.
EXTENSION CORDS
A short power supply cord is provided to reduce the risks resulting from
becoming entangled in or tripping over a longer cord.
Extension cords may be used if you are careful in using them.
If an extension cord is used—
1 The marked electrical rating of the extension cord should be at least
as great as the electrical rating of the appliance;
2 The extension cord must be a grounding-type 3-wire cord and it
must be plugged into a 3-slot outlet;
3 The extension cord should be arranged so that it will not drape over
the countertop or tabletop where it can be pulled on by children or
tripped over unintentionally.
If you use an extension cord, the interior light may flicker and the blower
sound may vary when the microwave oven is on. Cooking times may be
longer, too.
NOTICE—PACEMAKERS
Most pacemakers are shielded from interference from electronic
products, including microwaves. However, patients with pacemakers
may wish to consult their physicians if they have concerns.
READ AND FOLLOW THIS SAFETY
INFORMATION CAREFULLY.
Ensure proper ground
and firm connection
before use.
TEMPORARY
METHOD
Align large
prongs/slots
(Adapter plugs not
permitted in Canada)
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
SAVE THESE INSTRUCTIONS
6
OPERATING INSTRUCTIONS
Features
(Throughout this manual, features and
appearance may vary from your model.)
1. Door Latches.
2. Window with Metal Shield. Screen
allows cooking to be viewed while
keeping microwaves confined
in the oven.
3. Convenience Guide.
NOTE: Rating plate, oven vent(s) and
oven light are located on the inside walls
of the microwave oven.
4. Touch Control Panel Display.
5. Door Latch Release. Press latch
release to open the door.
6. Removable Turntable. Turntable and
support must be in place when using
the oven. The turntable may be
removed for cleaning.
1
3
Press Enter
TIME COOK Amount of cooking time.
TIME DEFROST (Amount of defrosting time) Amount of defrosting time.
30 SEC. Starts automatically!
POWER LEVEL Power level 1–10
Time Features
Quick Start
(Throughout this manual, features and appearance may vary from your model.)
The Controls on Your Microwave Oven
You can microwave by time or with
the convenience features.
Convenience Features and Auto Feature
5
2
4
Press Enter
POPCORN 3.5-oz. or 3.0-oz. package
BAKED POTATO 1–4 servings
PIZZA 1–4 slices
BEVERAGE 1–4 servings
REHEAT Food type 1–6 + 1–4 serving size
(Not available for Plate option)
VEGETABLE Food type 1–3 + 1–4 serving size
AUTO DEFROST Food weight
6
700 Watts
Time Cook
Power level 10 (High) is automatically set,
but you may change it for more flexibility.
1. Press TIME COOK.
2. Enter cooking time.
3. Change power level if you don’t
want full power. (Press POWER
LEVEL. Select a desired power level
1–10.)
4. Press START/PAUSE.
Time Cook
Allows you to microwave for any time up
to 99 minutes and 99 seconds.
Power level 10 is automatically set, but
you may change it for more flexibility.
You may open the door during Time Cook
to check the food. Close the door and press
START/PAUSE to resume cooking.
7
OPERATING INSTRUCTIONS
Changing Power Levels
The power level may be entered or
changed immediately after entering the
feature time for TIME COOK or TIME
DEFROST. The power level may also be
changed during time countdown.
Variable power levels add flexibility to
microwave cooking. The power levels on
the microwave oven can be compared to
the surface units on a range. Power level
10 or full power is the fastest way to cook
and gives you 100% power. Each power
level gives you microwave energy a
certain percent of the time. Power level 7 is
microwave energy 70% of the time. Power
level 3 is energy 30% of the time.
A high setting will cook faster but food
may need more frequent stirring, rotating
or turning over. Most cooking will be done
on power level 10. A lower setting will cook
more evenly and need less stirring or
rotating of the food.
Some foods may have better flavor, texture
or appearance if one of the lower settings
is used. Use a lower power level when
cooking foods that have a tendency to boil
over, such as scalloped potatoes.
Rest periods (when the microwave energy
cycles off) give time for the food to
“equalize” or transfer heat to the inside of
the food. An example of this is shown with
power level 3—the defrost cycle. If
microwave energy did not cycle off, the
outside of the food would cook before the
inside was defrosted.
Here are some examples of uses for
various power levels:
Power Level Best Uses
High 10 Fish, bacon, vegetables,
boiling liquids.
Med-High 7 Gentle cooking of meat and
poultry; baking casseroles
and reheating.
Medium 5 Slow cooking and
tenderizing such as
stews and less tender
cuts of meat.
Low 2 or 3 Defrosting without cooking;
simmering; delicate sauces.
Warm 1 Keeping food warm without
overcooking; softening
butter.
How to Change the Power Level
The power level may be entered or
changed immediately after entering
the feature time for TIME COOK.
1. Press TIME COOK.
2. Enter cooking time.
3. Press POWER LEVEL.
4. Select desired power level 1–10.
5. Press START/PAUSE.
OPERATING INSTRUCTIONS
Time Features
Vegetable Amount Time Comments
Asparagus
(fresh spears) 1 lb. 7 to 10 min., Med-High (7) In 1
1
⁄2-qt. casserole, place 1/4 cup water.
(frozen spears) 10-oz. package 5 to 8 min. In 1-qt. casserole.
Beans
(fresh green) 1 lb. cut in half 12 to 17 min. In 1
1
⁄2-qt. casserole, place 1/2 cup water.
(frozen green) 10-oz. package 6 to 9 min. In 1-qt. casserole, place 2 tablespoons water.
(frozen lima) 10-oz. package 6 to 9 min. In 1-qt. casserole, place 1/4 cup water.
Beets
(fresh, whole) 1 bunch 18 to 25 min. In 2-qt. casserole, place 1/2 cup water.
Broccoli
(fresh cut) 1 bunch (1
1
⁄4 to 11⁄2 lbs.) 7 to 10 min. In 2-qt. casserole, place 1/2 cup water.
(fresh spears) 1 bunch (1
1
⁄4 to 11⁄2 lbs.) 9 to 13 min. In 2-qt. casserole, place 1/4 cup water.
(frozen, chopped) 10-oz. package 5 to 8 min. In 1-qt. casserole.
(frozen spears) 10-oz. package 5 to 8 min. In 1-qt. casserole, place 3 tablespoons water.
Cabbage
(fresh) 1 medium head (about 2 lbs.) 8 to 13 min. In 1
1
⁄2- or 2-qt. casserole, place 1/4 cup water.
(wedges) 7 to 14 min. In 2- or 3-qt. casserole, place 1/4 cup water.
Carrots
(fresh, sliced) 1 lb. 6 to 9 min. In 1
1
⁄2-qt. casserole, place 1/4 cup water.
(frozen) 10-oz. package 5 to 8 min. In 1-qt. casserole, place 2 tablespoons water.
Cauliflower
(flowerets) 1 medium head 9 to 14 min. In 2-qt. casserole, place 1/2 cup water.
(fresh, whole) 1 medium head 9 to 17 min. In 2-qt. casserole, place 1/2 cup water.
(frozen) 10-oz. package 5 to 8 min. In 1-qt. casserole, place 2 tablespoons water.
Corn
(frozen kernel) 10-oz. package 4 to 8 min. In 1-qt. casserole, place 2 tablespoons water.
Corn on the cob
(fresh) 1 to 5 ears 3 to 5 min. per ear In 2-qt. glass baking dish, place corn. If corn is in husk, use no
water; if corn has been husked, add 1/4 cup water. Rearrange
after half of time.
(frozen) 1 ear 5 to 7 min. Place in 2-qt. glass baking dish. Cover with vented plastic wrap.
2 to 6 ears 2 to 4 min. per ear Rearrange after half of time.
Mixed vegetables
(frozen) 10-oz. package 4 to 8 min. In 1-qt. casserole, place 3 tablespoons water.
Peas
(fresh, shelled) 2 lbs. unshelled 9
to 12 min.
In 1-qt. casserole, place 1/4 cup water.
(frozen) 10-oz. package 4 to 8 min. In 1-qt. casserole, place 2 tablespoons water.
Potatoes
(fresh, cubed, 4 potatoes
11 to 14 min.
Peel and cut into 1-inch cubes. Place in 2-qt. casserole with 1/2 cup
white) (6 to 8 oz. each) water. Stir after half of time.
(fresh, whole, 1 (6 to 8 oz.) 2 to 5 min. Pierce with cooking fork. Place in center of the oven. Let stand
sweet or white) 5 minutes.
Spinach
(fresh) 10 to 16 oz. 5 to 8 min. In 2-qt. casserole, place washed spinach.
(frozen, chopped 10-oz. package 5 to 8 min. In 1-qt. casserole, place 3 tablespoons water.
and leaf)
Squash
(fresh, summer 1 lb. sliced 4 to 7 min. In 1
1
⁄2-qt. casserole, place 1/4 cup water.
and yellow)
(winter, acorn 1 to 2 squash 7 to 11 min. Cut in half and remove fibrous membranes. In 2-qt. glass baking
or butternut)
(about 1 lb. each)
dish, place squash cut-side-down. Turn cut-side-up after 4 minutes.
8
OPERATING INSTRUCTIONS
Time Cook Guide – NOTE: Use power level 10 unless otherwise noted.
Time Features (cont.)
OPERATING INSTRUCTIONS
Food Time Comments
Breads, Cakes
Bread, buns or rolls (1 piece) 1/2 min.
Sweet rolls (approx. 12 oz.) 3 to 5 min. Rearrange after half the time.
Fish and Seafood
Fillets, frozen (1 lb.) 6 to 9 min.
Shellfish, small pieces
(1 lb.)
6 to 9 min. Place block in casserole. Turn over and break up after half the time.
Fruit
Plastic pouch—1 or 2 2 to 6 min.
(10-oz. package)
Meat
Bacon (1 lb.) 4 to 7 min. Place unopened package in oven. Let stand 5 minutes after defrosting.
Franks (1 lb.) 4 to 7 min. Place unopened package in oven. Microwave just until franks can be separated. Let stand
5 minutes, if necessary, to complete defrosting.
Ground meat (1 lb.) 10 to 12 min. Turn meat over after first half of time.
Roast: beef, lamb, veal, pork
9 to 13 min.
per lb. Use power level 1.
Steaks, chops and cutlets 9 to 13 min. per lb. Place unwrapped meat in cooking dish. Turn over after first half of time and shield warm areas with
foil. After second half of time, separate pieces with table knife. Let stand to complete defrosting.
Poultry
Chicken, broiler-fryer, cut up
26 to 32 min.
Place wrapped chicken in dish. Unwrap and turn over after first half of time. After second half
(21⁄2 to 3 lbs.)
of time, separate pieces and place in cooking dish. Microwave 2 to 4 minutes more, if necessary.
Let stand a few minutes to finish defrosting.
Chicken, whole (21⁄2 to 3 lbs.)
26 to 32 min.
Place wrapped chicken in dish. After half the time, unwrap and turn chicken over. Shield warm
areas with foil. To complete defrosting, run cold water in the cavity until giblets can be removed.
Cornish hen 7 to 13 min. per lb. Place unwrapped hen in the oven breast-side-up. Turn over after first half of time.
Run cool water in the cavity until giblets can be removed.
Turkey breast (4 to 6 lbs.) 9 to 14 min. per lb. Place unwrapped breast in microwave-safe dish breast-side-down. After first half
of time, turn breast-side-up and shield warm areas with foil. Defrost for second
half of time. Let stand 1 to 2 hours in refrigerator to complete defrosting.
Time Defrost
Allows you to defrost for a selected length
of time. See the Defrosting Guide for
suggested times (AUTO DEFROST
explained in the Auto Feature section).
1. Press TIME DEFROST.
2. Enter defrosting time.
3. Press START/PAUSE.
4. Turn the food over after half the time.
5. Press START/PAUSE.
Power level is automatically set at 3, but
can be changed. You can defrost small
items quickly by raising the power level
after entering the time. Power level 7 cuts
the total defrosting time in about half;
power level 10 cuts the total time to
approximately 1/3. However, food will need
more frequent attention than usual.
At one half of selected defrosting time, turn
food over and break apart or rearrange
pieces for more even defrosting. Shield any
warm areas with small pieces of foil. The
oven will continue to defrost if you don’t
open the door and turn the food.
A dull thumping noise may be heard
during defrosting. This is normal when
oven is not operating at Hi power.
Defrosting Tips
•
Foods frozen in paper or plastic can be
defrosted in the package. Closed packages
should be slit, pierced or vented AFTER
food has partially defrosted. Plastic storage
containers should be partially uncovered.
• Family-size, prepackaged frozen dinners
can be defrosted and microwaved. If the
food is in a foil container, transfer it to a
microwave-safe dish.
• Foods that spoil easily should not be
allowed to sit out for more than one hour
after defrosting. Room temperature
promotes the growth of harmful bacteria.
• When defrosted, food should be cool
but softened in all areas. If still slightly icy,
return to the microwave very briefly, or
let it stand a few minutes.
Time Features (cont.)
Defrosting Guide
9
10
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
Add 30 Seconds
It will add 30 seconds to the time
counting down each time the pad
is pressed.
Each touch will add 30 seconds, up to
99 minutes and 99 seconds.
The oven will start immediately when
pressed.
Time Features (cont.)
Popcorn
How to Use the Popcorn Feature
1. Follow package instructions. Place
the package of popcorn in the center
of the microwave.
2. Press POPCORN once for a 3.5-ounce
package of popcorn and twice for a
3.0-ounce package. The oven will
start immediately after POPCORN
is touched.
Use only with prepackaged microwave
popcorn weighing 3.0 to 3.5 ounces.
Beverage
The Beverage feature works best for
heating a beverage that is at room
temperature.
Press BEVERAGE once for 8 oz., twice
for 12 oz., three times for 16 oz. and four
times for 4 oz. The oven will start
immediately when BEVERAGE is touched.
Beverages heated with the Beverage
feature may be very hot. Remove the
container with care.
Reheat
The Reheat feature automatically sets the
cooking times and power levels to reheat
a variety of previously cooked foods.
1. Press REHEAT. CodE will be displayed.
2. Select food type 1–6. Serving
Sizes 1–4 will be displayed.
3. Enter Serving Size 1–4.
4. The oven starts automatically.
Food Serving
Code Food Size
1 Pasta 1–4
2 Meats 1–4
3 Veggies 1–4
4 Beverages 1–4
5 Sauces 1–4
6 Plate (of leftovers) 1 only
Convenience Features
Vegetable
The Vegetable feature automatically sets
the cooking times and power levels to cook
fresh, frozen or canned vegetables.
1. Press VEGETABLE. CodE will be displayed.
2. Select food type 1–3. Serving
Sizes 1–4 will be displayed.
3. Enter Serving Size 1–4.
4. The oven starts automatically.
Food Serving
Code Food Size
1 Fresh 1–4
2 Frozen 1–4
3 Canned 1–4
11
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS
Pizza
The Pizza feature is for reheating
1 to 4 slices of pizza.
Press PIZZA once for one slice of pizza,
twice for two slices, three times for three
slices and four times for four slices. The
oven will start immediately after PIZZA
is touched.
Convenience Features (cont.)
Auto Defrost
Use AUTO DEFROST for meat, poultry
and fish. Use TIME DEFROST for most
other frozen foods (TIME DEFROST
explained in the Time Features section).
AUTO DEFROST automatically sets the
defrosting times and power levels to give
even defrosting results for meats, poultry
and fish weighing up to 6 pounds.
1. Press AUTO DEFROST.
2. Using the Conversion Guide below,
enter food weight. For example, press
pads 1 and 2 for 1.2 pounds (1 pound,
3 ounces).
3. Press START/PAUSE.
Defrosting Tips
•
Remove meat from package and place
on microwave-safe dish.
• When the oven signals, turn the food
over. Remove defrosted meat or shield
warm areas with small pieces of foil.
• After defrosting, most meats need to
stand 5 minutes to complete defrosting.
Large roasts should stand for about
30 minutes.
Auto Feature
Baked Potato
The Potato feature cooks up to four 8–10
ounce potatoes.
Baked Potato
Press BAKED POTATO once for one
potato, twice for two potatoes, three
times for three potatoes and four times
for four potatoes. The oven will start
immediately after BAKED POTATO
is touched.
There is a handy guide located on the
inside front of the oven.
Weight of Food in Ounces Enter Food Weight (tenths of a pound)
1–2 0.1
30.2
4–5 0.3
6–7 0.4
80.5
9–10 0.6
11 0.7
12–13 0.8
14–15 0.9
Conversion Guide
If the weight of food is stated in pounds and ounces, the ounces must be converted
to tenths (0.1) of a pound.
Clear/Off
Press once to stop and erase your
cooking settings.
12
OPERATING INSTRUCTIONS
Clock
Press CLOCK to enter the time of day.
1. Press CLOCK.
2. Enter time of day.
3. Press START/PAUSE or CLOCK.
Timer
The Timer operates as a minute timer.
1. Press TIMER.
2. Enter amount of time you want to
count down.
3. Press TIMER. When the time is up,
the timer will signal.
The Timer feature operates without
microwave energy.
To stop the timer, press and hold
TIMER for 3 seconds
NOTE: CLEAR/OFF will not stop the
TIMER.
Child Lock-Out
You may lock the control panel
to prevent the microwave from
being accidentally started or used
by children.
To lock or unlock the controls, press and
hold CLEAR/OFF for about three seconds.
When the control panel is locked, Loc will
appear briefly in the display. When the
control panel is initially unlocked, Unlo
will appear briefly in the display.
Pause
To pause cooking or defrosting, press
START/PAUSE. To continue cooking or
defrosting, press START/PAUSE again.
Other Features
13
HELPFUL INFORMATION
Term Definition
Arcing Arcing is the microwave term for sparks in the oven. Arcing is caused by:
• metal or foil touching the side of the oven.
• foil that is not molded to food (upturned edges act like antennas).
• metal such as twist-ties, poultry pins, gold-rimmed dishes.
• recycled paper towels containing small metal pieces.
Covering Covers hold in moisture, allow for more even heating and reduce cooking time. Venting plastic wrap
or covering with wax paper allows excess steam to escape.
Shielding In a regular oven, you shield chicken breasts or baked foods to prevent over-browning. When
microwaving, you use small strips of foil to shield thin parts, such as the tips of wings and legs on
poultry, which would cook before larger parts.
Standing Time When you cook with regular ovens, foods such as roasts or cakes are allowed to stand to finish
cooking or to set. Standing time is especially important in microwave cooking. Note that a
microwaved cake is not placed on a cooling rack.
Venting After covering a dish with plastic wrap, you vent the plastic wrap by turning back one corner so
excess steam can escape.
Microwave Terms
How to Clean the Inside
Walls, Floor, Inside Window, Metal and
Plastic Parts on the Door
Some spatters can be removed with a
paper towel; others may require a damp
cloth. Remove greasy spatters with a
sudsy cloth, then rinse with a damp
cloth. Do not use abrasive cleaners or
sharp utensils on oven walls. To clean
the surface of the door and the surface
of the oven that come together upon
closing, use only mild, nonabrasive soaps
or detergents using a sponge or soft
cloth. Rinse with a damp cloth and dry.
Never use a commercial oven cleaner
on any part of your microwave.
Removable Turntable and
Turntable Support
To prevent breakage, do not place the
turntable into water just after cooking.
Wash it carefully in warm, sudsy water
or in the dishwasher. The turntable and
support can be broken if dropped.
Remember, do not operate the oven
without the turntable and support
in place.
Helpful Hints
An occasional thorough wiping with
a solution of baking soda and water
keeps the inside fresh.
UNPLUG THE CORD BEFORE CLEANING
ANY PART OF THIS OVEN.
Care and Cleaning
HELPFUL INFORMATION
How to Clean the Outside
Case
Clean the outside of the microwave
with a sudsy cloth. Rinse and then
dry. Wipe the window clean with a
damp cloth.
Control Panel and Door
Wipe with a damp cloth. Dry thoroughly.
Do not use cleaning sprays, large
amounts of soap and water, abrasives
or sharp objects on the panel—they
can damage it. Some paper towels can
also scratch the control panel.
Door Surface
It’s important to keep the area clean
where the door seals against the
microwave. Use only mild, non-abrasive
detergents applied with a clean sponge
or soft cloth. Rinse well.
Power Cord
If the cord becomes soiled, unplug
and wash with a damp cloth. For
stubborn spots, sudsy water may be
used, but be certain to rinse with a
damp cloth and dry thoroughly before
plugging cord into outlet.
Do not use cleaners containing
ammonia or alcohol on the
microwave oven. Ammonia
or alcohol can damage the
appearance of the microwave.
If Something Goes Wrong
Problem Possible Causes What To Do
Oven will not start
A fuse in your home may be
• Replace fuse or reset circuit breaker.
blown or the circuit breaker tripped.
Power surge. • Unplug the microwave oven, then plug it back in.
Plug not fully inserted into wall outlet. • Make sure the 3-prong plug on oven is fully inserted into wall outlet.
Control panel lighted, yet
Door not securely closed. • Open the door and close securely.
oven will not start.
START/PAUSE not pressed after • Press START/PAUSE.
entering cooking selection.
Another selection entered • Press CLEAR/OFF.
already in oven and CLEAR/OFF
not pressed to cancel it.
Cooking time not entered • Make sure you have entered cooking time after pressing TIME COOK.
after pressing TIME COOK.
START/PAUSE was pressed • Reset cooking program and press START/PAUSE.
accidentally.
Food weight not entered after • Make sure you have entered food weight after selecting
selecting AUTO DEFROST. • AUTO DEFROST.
Oven was paused accidentally. • Press START/PAUSE to restart the cooking program.
Things That Are Normal
• Steam or vapor escaping from
around the door.
• Light reflection around door or
outer case.
• Dimming oven light and change in
the blower sound at power levels other
than high.
• Dull thumping sound while oven
is operating.
• TV-radio interference might be noticed
while using the microwave. Similar to
the interference caused by other small
appliances, it does not indicate a
problem with the microwave. Plug the
microwave into a different electrical
circuit, move the radio or TV as far
away from the microwave as possible
or check the position and signal of
the TV/radio antenna.
14
15
WARRANTY
EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclusive remedy is product
repair as provided in this Limited Warranty. Any implied warranties, including the
implied warranties of merchantability or fitness for a particular purpose, are
limited to one year or the shortest period allowed by law.
GE Microwave Oven Warranty
Staple your receipt here.
Proof of the original purchase
date is needed to make a
warranty claim.
For The Period Of: What GE Will Provide:
One Year Replacement unit for any product which fails due to a defect in materials or
From the date of the original purchase workmanship. The exchange unit is warranted for the remainder of your
product’s original one-year warranty period.
What GE Will Not Cover:
• Customer instructions. This owner’s manual provides
information regarding operating instructions
and user controls.
• Improper installation, delivery or maintenance.
• Failure of the product or damage to the product if it is
abused, misused (for example, cavity arcing from wire
rack or metal/foil), or used for other than the intended
purpose or used commercially.
• Replacement of house fuses or resetting of circuit
breakers.
• Damage to the product caused by accident, fire, floods
or acts of God.
• Incidental or consequential damage caused by possible
defects with this appliance.
• Damage caused after delivery.
This warranty is extended to the original purchaser and any succeeding owner for
products purchased for home use within the USA.
Some states do not allow the exclusion or limitation of incidental or consequential
damages. This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state. To know what your legal rights are, consult your
local or state consumer affairs office or your state’s Attorney General.
Exclusion of implied warranties: Except where prohibited or restricted by law, there are
no warranties, whether express, oral or statutory which extend beyond the description
on the face hereof, including specifically the implied warranties of merchantability or
fitness for a particular purpose.
Warrantor: General Electric Company. Louisville, KY 40225
In Order to Make a Warranty Claim:
• Properly pack your unit. We recommend using the
original carton and packing materials.
• Return the product to the retail location where it was
purchased.
• Include in the package a copy of the sales receipt or other
evidence of date of original purchase. Also print your
name and address and a description of the defect.
Printed in China
GE Appliances Website
GEAppliances.com
Have a question or need assistance with your appliance?
Try the GE Appliances Website 24 hours a day, any day of the
year! For greater convenience and faster service, you can now
download Owner’s Manuals, order parts or even schedule
service on-line.
Schedule Service
GEAppliances.com
Expert GE repair service is only one step away from your door.
Get on-line and schedule your service at your convenience
any day of the year! Or call 800.GE.CARES (800.432.2737)
during normal business hours.
Real Life Design Studio
GEAppliances.com
GE supports the Universal Design concept—products, services
and environments that can be used by people of all ages, sizes
and capabilities. We recognize the need to design for a wide
range of physical and mental abilities and impairments. For
details of GE’s Universal Design applications, including kitchen
design ideas for people with disabilities, check out our Website
today. For the hearing impaired, please call 800.TDD.GEAC
(800.833.4322).
Extended Warranties
GEAppliances.com
Purchase a GE extended warranty and learn about special
discounts that are available while your warranty is still in effect.
You can purchase it on-line anytime, or call 800.626.2224 during
normal business hours. GE Consumer Home Services will still be
there after your warranty expires.
Consumer Support
Parts and Accessories
GEAppliances.com
Individuals qualified to service their own appliances can
have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted).
Order on-line today, 24 hours every day or by phone
at 800.626.2002 during normal business hours.
Instructions contained in this manual cover procedures to
be performed by any user. Other servicing generally should
be referred to qualified service personnel. Caution must
be exercised, since improper servicing may cause unsafe
operation.
Contact Us
GEAppliances.com
If you are not satisfied with the service you receive from GE,
contact us on our Website with all the details including your
phone number, or write to:
General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
Register Your Appliance
GEAppliances.com
Register your new appliance on-line—at your convenience!
Timely product registration will allow for enhanced
communication and prompt service under the terms of your
warranty, should the need arise. You may also mail in the
pre-printed registration card included in the packing material.
Loading...
