GE SCB2001K User Manual
SCB2001K
Cutout width
28-1/2"
30
Required
cutout location
36-3/4"
minimum
from floor
Junction
box
location
4-3/16
21"
Cutout height
A
B
19"
Cutout depth
29-25/32
21-7/8
15-27/32"
Excluding
Handle
Construct Solid
Bottom Min.
3/8" Plywood
Supported by
2 x 4 or 1 x 2
Runners, all
Four Sides.
(Must Support
150 lbs.)
Conduit
(48-1/2"
long)
GE Profile Advantium® Wall Oven
Dimensions and Installation Information (in inches)
A
B
Allow 1" overlap of oven over top and bottom edges of cutout
Allow 11/16"-3/4" for overlap of oven over side edges of cutout
Note: Cabinets installed adjacent to wall ovens must have an
adhesion spec of at least a 194°F temperature rating.
Most 30" Wall Cabinets can be used with this unit.
Note: 2" minimum between cutouts when installed above
warming drawer or single wall oven.
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
ge.com or call GE Answer Center® service,
800.626.2000.
Specification Revised 2/07
Listed by
Underwriters
Laboratories
240440
SCB2001K
36-3/4 Min.
Required
30
19
Min
Construct Solid
Bottom Min. 3/8"
Plywood
Supported by
2 x 4 or 1 x 2
Runners, all
Four Sides
28-1/2
21
36-3/4 Min.
30
24
Min.
Construct Solid
Bottom Min. 3/8"
Plywood
Supported by
2 x 4 or 1 x 2
Runners, all
Four Sides
2 Min.
Install
2 x 4 or 2 x 2
Runners or
Solid Bottom,
Must Support
100 lbs.
28-1/2
21
9-1/4
*45-1/
4
30
24
Min.
Construct Solid
Bottom Min. 3/8"
Plywood
Supported by
2 x 4 or 1 x 2
Runners, all
Four Sides
2 Min.
Per Oven
Requirement
28-1/2
21
GE Profile Advantium® Wall Oven
Dimensions and Installation Information (in inches)
Order a 30” wide single oven cabinet or cut the
opening in a wall to dimensions shown.
Note: The rough opening must be:
• Depth – 19” Min.
• Width – 28-1/2” Min.
• Height – 21” Min.
• 36-3/4” from the floor to the cutout is required.
• These ovens require 3/4” overlap on each side,
top and bottom of the cutout.
• Oven overlaps will conceal cut edges on all sides
of the opening.
Note: For installation above a warming drawer
additional clearance between the two cutouts
may be required. Check to be sure the oven
supports above the Warming Drawer location
do not obstruct the required interior 23-1/2” depth
and 9-1/4” height.
Installation Information: Before installing, consult
installation instructions packed with product for
current dimensional data.
Single
Speedcook Installation
Speedcook Oven Installation
above a GE Warming Drawer
Speedcook Oven Installation
above a single GE Built-In Wall Oven
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
ge.com or call GE Answer Center® service,
800.626.2000.
Listed by
Underwriters
Laboratories
Specification Revised 2/07
240440
