R20 Recessed
Light Extender

User’s Manual

Easy 1-2-3 installation

Congratulations on the purchase of

No tools
required

Includes universal
cover ring that
fits all recessed
lighting fixtures up
to 8” openings

UP TO

8”

the Recessed Light Extender. Once
installed, you can provide directed light
to specific areas around your house.

Getting Started…

The 45153 Recessed
Light Extender model
requires a “R20” size
light bulb. You can use
an incandescent, CFL or LED light bulb.
Do not use a halogen light bulb.

The Recessed Light Extender is very
simple to assemble and even easier to install.

The Recessed Light Extender consists of two parts –

1. Light Assembly (ratchet screw base, rocker/swivel

mount and securing collar)

2. Cover Ring (alignment pin holes, snap clip holes)

Assembly

1. Remove the Recessed Light Extender Assembly and

Cover Ring from packaging. Take note of the alignment
pins and snap clips on securing collar.

2. Position the Recessed
Light Extender screw base
through the cover ring hole.
Position the Alignment pins
to the alignment hole on
the cover ring.

3. Firmly push the cover ring
onto the securing collar snap
clips until each clip snaps
into place.

See back for troubleshooting
