GE PVWS936, PVWT936, PVWS930, PVWG936, PVIG940 User Manual
Range Hoods
Vented
www.GEAppliances.ca
Safety Instructions 2, 3
Operating Instructions
Light Controls 4
Vent Controls 4
Care and Cleaning
Grease Filters 5
Hood Lights 6
Hood Surfaces 5
Stainless Steel Surfaces 5
Installation Instructions 7–16
Troubleshooting Tips 18
Consumer Support
Consumer Support Back Cover
Product Registration 19, 20
Warranty 21
............................................
..............................................
....................................................
................................
...........................................
...........................................
..........................................
............................
......................
............................
...................................
..................................
Owner’s Manual and
Installation Instructions
PVWS930
PVWS936
PVWT936
PVWG936
PVIG940
Write the model and serial
numbers here:
Model # ________________
Serial # ________________
You can find them on a label
on the inside of the hood.
350A4502P595 03-07 ATS
LI3FQC Ed. 03/08
SAFETY PRECAUTIONS
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING –
TO REDUCE THE RISK OF
FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING:
A. Use this unit only in the manner intended
by the manufacturer. If you have
questions, contact the manufacturer.
B. Before servicing or cleaning unit, switch
power off at service panel and lock the
service disconnecting means to prevent
power from being switched on
accidentally. When the service
disconnecting means cannot be locked,
securely fasten a prominent warning
device, such as a tag, to the service panel.
C. Do not use this unit with any solid-state
speed control device.
D. This unit must be grounded.
CAUTION–
For general ventilating use
only. Do not use to exhaust hazardous or
explosive materials and vapors.
CAUTION–
To reduce risk of re and to
properly exhaust air, be sure to duct air outside.
Do not vent exhaust air into spaces within walls
or ceilings or into attics, crawl spaces, or
garages.
WARNING–
To reduce the risk of re or
electric shock, DO NOT use this fan with any
solid-state speed control device.
WARNING –
TO REDUCE THE RISK OF
INJURY TO PERSONS IN THE EVENT OF A
RANGE TOP GREASE FIRE, OBSERVE THE
FOLLOWING*:
A. SMOTHER FLAMES with a close-fitting
lid, cookie sheet, or metal tray, then turn
off the burner. BE CAREFUL TO
PREVENT BURNS. If the flames do not go
out immediately, EVACUATE AND CALL
THE FIRE DEPARTMENT.
B. NEVER PICK UP A FLAMING PAN —
You may be burned.
C. DO NOT USE WATER, including wet
dishcloths or towels—a violent steam
explosion will result.
D. Use an extinguisher ONLY if:
1. You know you have a Class ABC
extinguisher, and you already know how
to operate it.
2. The fire is small and contained in the
area where it started.
3. The fire department is being called.
4. You can fight the fire with your back to
an exit.
* Based on “Kitchen Fire Safety Tips
”
published by NFPA.
Consumer Support Troubleshooting Tips
Operating Instructions
Safety InstructionsCare and Cleaning
2
Consumer Support
Troubleshooting Tips
Operating Instructions
Safety Instructions
Care and Cleaning
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
READ AND SAVE THESE INSTRUCTIONS
SAFETY PRECAUTIONS
www.GEAppliances.ca
WARNING –
TO REDUCE THE RISK OF
A RANGE TOP GREASE FIRE:
A. Never leave surface units unattended at
high settings. Boilovers cause smoking and
greasy spillovers that may ignite. Heat oils
slowly on low or medium settings.
B. Always turn hood ON when cooking at
high heat or when flambeing food.
( i.e. Crepes Suzette, Cherries Jubilee, Pepper
corn Beef Flambé).
C. Clean ventilating fans frequently. Grease
should not be allowed to accumulate on
fan or filter.
D. Use proper pan size. Always use cookware
appropriate for the size of the surface
element.
WARNING –
TO REDUCE THE RISK OF
FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING:
A. Installation work and electrical wiring
must be done by qualified person(s) in
accordance with all applicable codes and
standards, including fire-rated
construction.
B. Sufficient air is needed for proper
combustion and exhausting of gases
through the flue (chimney) of fuel
burning equipment to prevent back
drafting. Follow the heating equipment
manufacturer’s guideline and safety
standards such as those published by the
National Fire Protection Association
(NFPA), and the American Society for
Heating, Refrigeration and Air
Conditioning Engineers (ASHRAE), and
the local code authorities.
C. When cutting or drilling into wall or
ceiling, do not damage electrical wiring
and other hidden utilities.
D. Ducted fans must always be vented to the
outdoors.
WARNING –
TO REDUCE THE RISK OF
FIRE, USE ONLY METAL DUCTWORK.
Do not attempt to repair or replace any
part of your hood unless it is specifically
recommended in this guide. All other
servicing should be referred to a qualified
technician.
3
Using the hood controls.
Throughout this manual, features and appearance may vary from your model.
A - MOTORSTOP
B - SPEED DECREASE
D - LED:SPEED 1
F - LED: SPEED 2 AND METAL FILTER SATURATION
(WHEN FLASHING)
C - LED: SPEED 3 AND COAL FILTER SATURATION
(WHEN FLASHING)
E - MOTOR START AND SPEED INCREASE
G - TIMED INTENSIVE SPEED
H - LED TIMED INTENSIVE SPEED
I - “ON-OFF’ LIGHT
- MOTOR OPERATING PERFORMANCE CHECKUP. WHEN ANY OF THE BUTTONS ARE
PRESSED, ALL FOUR LEDS TURN ON TO
INDICATE THAT THE FOUR FAN SPEEDS
OPERATE PROPERLY. IF ONE OF THE LIGHTS
DOES NOT COME ON, IT MEANS THAT THE
SPEED CORRESPONDING TO THAT LIGHT
DOES NOT WORK.
Consumer Support
Troubleshooting Tips Operating Instructions
Safety Instructions
Care and Cleaning
4
Control Device Reset
Grease Filters:
After cleaning the grease filters, press buttons (A)-(E) for
2 seconds until you hear the beep and the LED stops
flashing.
Coal Filter:
After replacing the cartridge, press both buttons (A)-(B)
for 2 seconds until you hear the beep. The LED will stop
flashing.
The coal filter saturation is also indicated when the hood
is used in vented version.
The hood is provided with a storage device which counts
the number of hours of operation and which regulates
the lighting up of the coal filter saturation LEDS.
For the correct operation of this device, it is important
that the hood be switched off by pressing button (A)
before unplugging it for any maintenance work.
ABDFCEGH
I
Filters
To remove the metal grease filter/s:
■ Unplug the hood from the mains
socket.
FOR MODELS PVIG940, PVWG936
■ Press the clips towards the centre and
remove the filters. Fig. 1.
FOR MODELS PVWS930, PVWS936,
PVWT936
■ Press the handles and remove the
filters. Fig. 2.
To replace the metal grease filter/s:
■ Follow the same procedure, but
backwards.
The metal grease filters are manufactured using anodised aluminium and have an unlimited duration.
Fig. 1
Fig. 2
Hood Operation
Turn the fan on for approximately 5 minutes before you
start cooking in order to create some upwards drafts
through the hood.
This causes the heat, smoke, steam, grease and odours
produced during cooking to be pushed outwards, thereby
preventing them from drifting into other rooms.
Use the low speed settings for normal use and the high
speed settings for strong odours or thick smoke.
The presence of drafts in the kitchen or in the hood
reduces the efficiency of the hood. These drafts
should be avoided wherever possible.
Care and cleaning of the vent hood.
www.GEAppliances.ca
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions Care and Cleaning
5
Be sure electrical power is off and all surfaces are cool before cleaning or servicing any part of the vent hood.
Make sure lamps are cold before cleaning the hood.
To clean the filter/s
We recommend you wash the filters at least once a
month, by hand or in the dishwasher. Let the water drip
out of the holes on the edges and leave the filters to dry
completely before reinstalling them.
To clean the hood surface
For general cleaning operations, rub the external part of
the hood made of glass, using soapy water or household
cleaning products, rinsing it thoroughly and drying it
with a soft dry cloth to avoid marks being left by the
water.
Stainless Steel Surfaces
Do not use a steel-wool pad; it will scratch the surface.
Shake bottle well.
Place a small amount of CERAMA BRYTE
®
Stainless
Steel Cleaning Polish and Conditioner on a dry cloth
or dry paper towel.
Clean a small area (approximately 8” x 8” or
20.3 x 20.3 cm), rubbing with the grain of the
stainless steel if applicable.
Dry and buff with a clean, dry paper towel or soft
cloth.
Repeat as necessary.
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Care and Cleaning
6
Care and cleaning of the vent hood.
Be sure electrical power is off and all surfaces are cool before cleaning or servicing any part of the vent hood.
Unscrew the lamp diffusers.
Remove the blown lamp and replace
it with a new 20 Watt (max) 12 Volt
halogen lamp with a G-4 cap. Follow
the instructions given on the lamp
box. Do not touch the lamp with your
bare hands.
Place the lamp diffuser back in place.
Fig. 3
Replacement of lamps
(Models PVWS930, PVWS936, PVWT936, PVWG936, PVIG940)
BEFORE YOU BEGIN
7
Installation
Range Hood
Instructions
Re ad th ese i nstructions c omple tely and carefully .
• IMPORTANT – Save these
instructions for local inspector’s use.
• IMPORTANT – Observe all
governing codes and ordinances.
• Note to Installer – Be sure to leave these
in struc tions with the Con sumer .
• Note to Consumer – Kee p these instructio ns
fo r fut ure reference .
• Skill level – Instal latio n of this vent hood req uires
ba sic m echanical and elec trica l ski lls.
• Completion time – 1 to 3 hours
• Pro per i nstallation is the resp onsib ility of the
in stall er.
• Pro duct failure due t o imp roper installation is n ot
co vered unde r the Wa rrant y.
WARNING – Before beginning the
installation, switch power off at service panel and lock
the service disconnecting means to prevent power
from being switched on accidentally. When the service
disconnecting means cannot be locked, securely
fasten a prominent warning device, such as a tag, to
the service panel.
FOR YOUR SAFETY:
Questions? Call 1-800-561-3344
or Visi t our Website at: www.
GEAppliances.ca
Due to the weight and size of these vent hoods and to
reduce the risk of personal injury or damage to the
pr oduct , TWO PEOPLE ARE REQUIRED FOR
PROPER INSTALLATION
CAUTION:
WARNING: - T O RED UC E THE RI SK OF F IR E, EL EC TR IC SH OC K
OR I NJURY T O PERSO NS , OBS ER VE THE F OLLOWIN G:
A. Installation work and electrical wiring must be
done by
qualified person(s) in accordance with all applicable codes and standards, including fire-rated
construction.
B. Sufficient air is needed for proper combustion
and exhausting of gases through the flue (chimney)
of fuel burning equipment to prevent back drafting.
Follow the heating equipment manufacturers guidline and safety standards such as those published by
the National Fire Protection Association
(NFPA), and the American Society for Heating,
refrigeration and Air Conditioning Engineers
(ASHRAE), and the local code
authorities.
C. When cutting or drilling into wall or ceiling do
not damage electrical wiring and other hidden
utilities.
D. Ducted fans must always be vented to the
outdoors.
WARNING: - T O RED UC E THE RI SK OF F IR E, U SE O NLY
ME TA L DUC TW ORK.
Do not a ttemp t to repair or rep lace any p art of your
ho od un less it is specif icall y rec ommended in t his
gu ide. All other ser vicin g sho uld b e referred t o a
qu alifi ed technician.
CAUTION: - T O RED UC E THE RI SK OF F IR E AND T O PROPE RL Y
EX HA UST A IR .
Be sure to du ct air outsid e- Do not vent exhaust air
in to sp aces within walls or ce iling s or into attics, craw l
sp aces, or g arages.
Installation Instructions
8
PRODUCT DIMENSIONS
1 Ft = 0.3 m
1” = 2.5 cm
MODEL W D H
PVWT936
PVWG936
PVIG940
2.5”
PVWS930
PVWS936
24.8”
12”
5.9”
13.4”
10.8”
PVWG936
15.7”
2.5”
PVWT936
24.8”
12”
5.9”
13.4”
PVIG940
15.7”
10.8”
W
PVWS930/93
30”-36”
36”
36”
39.4”
19.3”
19.3”
19.7”
27.5”
33.3”- 45.7”
38.6”- 55.5”
33.3”- 47.4”
31.5”- 41.5”
H
T
D
T
15.75”
15.75”
17.7”
17.7”
Loading...
