GE NEMA Premium Efficient XsD Ultra Instruction Sheet

g
GE Industrial Systems
Installation Instructions
For Inpro™ Seal Kit For Severe Duty Motors Only
GEK-99908 GEK-99908
These instructions do not purport to cover all of the details or variations in equipment nor to provide for every possible contingency to be met in connection with installation, operation, or maintenance. Should further information be desired or should particular problems arise which are not covered sufficiently for the purchaser's purposes, the matter should be referred to the General Electric Company.
© Copyright 1991, 1999 General Electric Company
2

Installation Instructions for Inpro™ Seal Kit

For Severe Duty Motors Only

I. Remove the slinger from the drive
endshield
II. Slide the Inpro Seal over the shaft extension on the drive end until the seal rests firmly against the endshield inside the recessed slinger cavity. The O-ring on the OD of the seal goes against the motor. See Figure 3.
III. If the keyway extends under the O-ring of the Inpro Seal, the gap should be filled with RTV.
IV. RENAMEPLATING
A. Stamp the Inpro Seal identification letters “R2L” directly above the model number on the motor nameplate as illustrated below in Figure 2. On the 182-186 frame motors, the letters will not fit after the model number, so they should be stamped directly above the model number as shown below in Figure 1.
B Stamp your GE buyer identification letters at the far right of the motor nameplate after the date code. To secure your GE buyer identification letters, contact the Fort Wayne Customer Service Center at 1-800-327-4883.
C. Failure to stamp the GE buyer identification letters or the Inpro Seal identification letters on the nameplate VOIDS the warranty on the motor and its components.
R2L
Model 5KS182SE205B HP No AB
Mod GE Buyer
Letters Identification #
Figure 1: 182-286 Frames
Mod GE Buyer
Letters Identification #
Model 5KS324SS204AR2L HP No AB
Figure 2: 324-449 Frames

Figure 3: Inpro Seal Installation

IV. PARTS SUPPLIED

1 Inpro™ Seal
1 Instruction Sheet GEK-99908
GEK-99908
3
GEK-99908
This page left intentionally blank
4
GEK-99908
A
To: GE Industrial Systems
g
General Electric Company
Reader Comments
ttn: Industrial Engineering Technical Publications Editor 2000 Taylor Street Fort Wayne IN 46801-2205 Fax: 1-260-439-3881 (GE Internal DC: 8*380-3881)
We welcome comments and suggestions to make this publication more useful.
Your Name Today’s Date If needed, how can we contact you?
Your Company’s Name and Address Job Site Fax No.
GE Requisition No. Phone No.
Your Job Function / How You Use This Publication Publication No. E-Mail
Publication Issue / Revision Date
Address

General Rating

Contents Organization Technical Accuracy Clarity Completeness Drawings / Figures Tables Referencing Readability
Excellent Good Fair Poor Additional Comments
Specific Suggestions (Corrections, information that could be expanded on, and such.)

Page No. Comments

Other Comments (What you like, what could be added, how to improve, and such.)
Overall Grade (Compared to publications from other manufacturers of similar products, how do you rate this publication?)
Superior Comparable Inferior Do not know Comment
Detach and fax or mail to the address noted above.
5
GEK-99908
……………………………………………….…………………Fold here and close with staple or tape………………………………….………………….
Place
Stamp
Here
GE INDUSTRIAL SYSTEMS INDUSTRIAL ENGINEERING TECHNICAL PUBLICATIONS EDITOR 2000 TAYLOR STREET FORT WAYNE IN 46801-2205 USA
…………………………………………………..………….………………..Fold here first……………………………………………………………….
6
Document Revision History
