Mentor
Visual iQ

™

Put the power of productivity
in your hands.

Introducing the portable,
connected VideoProbe™ from
GE with 3D Phase Measurement.

The most
precise
detection.
Faster.

Today’s aerospace, power generation, and oil
and gas industries depend on precise critical
inspections to keep aircraft flying, power plants
online, refineries running and wells producing.
Visual inspections can detect indications that
help asset owners make better decisions about
planned downtime and repairs, resulting in
improved performance and reduced chances
of serious equipment failures.

At GE, we understand the value of uptime and provide experts with
a better video borescope choice—the Mentor Visual iQ VideoProbe™.
With state-of-the-art 3D Phase Measurement and analysis, it
accurately detects visual indications such as corrosion, blockages
and cracking. Its superior image quality and faster, more precise
detection is forever changing the inspection landscape.

Collaboration

Connect in real time, get inspections
done in no time.

When expert advice or a second opinion is needed during
an inspection, you need to collaborate instantly. Today’s
Mentor Visual iQ is built for real time collaboration, with
Bluetooth keyboard and headset, and Wi-Fi connectivity that
allow inspectors of all levels to work together on the fly. And
soon, inspectors will have the capability to share screens,
share images, gather opinions and even make notes in real
time with Inspection Connect. This can be a lifesaver when
confined spaces or difficult inspecting conditions make access
a challenge, or when collaborating across continents or over
oceans. With expert advice on hand, the Mentor Visual iQ
reduces downtime so you have more uptime.

Expertise In Hand

Intuitive innovation. Mentor Visual iQ’s interface makes sense
right out of the box. Menu Directed Inspection (MDI) guides
users through the inspection process and organizes results for
simplified reporting. The easy-to-use touchscreen interface,
on-screen keyboard and ergonomic buttons reduce inspection
time. Create and customize profile setups for multiple users or
applications, and access on-device manuals and context-based
inspection support files. And with advanced file management,
it’s easier to store, organize and report large volumes of
inspection data.

Innovative Design

Performance meets portability. Mentor
Visual iQ combines the portability you want
with the powerful processing you need. On­demand 3D Phase Measurement helps you
make better asset decisions. Meet a variety
of inspection needs with interchangeable
probes and tip optics, as well as custom
profiles. The touchscreen interface enables
faster navigation, precise cursor placement,
and on-screen typing and annotation to
speed up inspections. Designed and tested
to recognized civilian and military standards
(IP55, MIL-STD-810G and MIL-STD-461F),
the device is dependable in the field. And at
just 6.75lbs with a lithium-ion battery, the
aircraft compliant Mentor Visual iQ stores in
overhead compartments for easy mobility.

The power of connectivity

Bluetooth and Wi-Fi enabled
for easy collaboration

Crisp image quality

High-intensity light source and
advanced image processing
for clearer, sharper video and
still image quality

Flexible solutions

Interchangeable probes and
tip optics to meet the toughest
inspection challenges

Advanced detection & analysis

Innovative 3D Phase
Measurement and cutting­edge MDI data management

Collaboration

Connect in real time, get inspections
done in no time. When expert advice or

a second opinion is called for during an
inspection, you need answers fast. That’s
why Mentor Visual iQ is built for real­time collaboration. With Wi-Fi enabled
Bluetooth keyboard and headset,
inspectors of all levels can work together
instantly. Inspectors will be able to share
screens and images, gather opinions
and even make notes in real time with
Inspection Connect—no matter the
environment or distance between them.

Greater mobility

Portable, ergonomic 6.75lb
design with aircraft compliant
lithium-ion battery

Easy to use

Intuitive touchscreen interface
and individual user profiles,
with context-based inspection
support preloaded on the device

Rugged durability

Designed to IP55, MIL-STD-810G
and MIL-STD-461F standards
to withstand the toughest
inspection environments

Reducing downtime for more uptime.

Aerospace

• Extreme image quality and lighting enhances Probability of Detection (PoD) in
all turbine stages

• 3D Phase Measurement surface
scanning and analysis for fast and accurate Go/No-Go’s

• Menu Directed Inspection (MDI) stores AMM workflows, catalogs images, and
generates reports on demand

• Share inspection analysis easily with remote experts to significantly reduce AOG
and inspection time

• Create user-defined profile setups based
on specific inspector preferences, airframe or power plant type

• Lightweight, ergonomic IP55, MIL-STD-810G and MIL-STD-461F design improves
the shop and flightline inspection process

Oil & Gas

• Designed to IP55 specifications with durability to stand up to the toughest field
conditions on a rig, column or turbine unit

• Superior image quality and illumination to inspect large areas such as tanks,
headers, vessels and meter tubes

• Interchangeable probes with multiple lengths and diameters allow for FFP/BOP
inspections of a variety of assets

• 3D Phase Measurement surface scanning and analysis helps determine accurate
indication depth and size

• Remote collaboration for inspection advice in confined spaces or remote areas

• Streamlined service means more uptime when it counts

Power Generation

• Handheld portability makes inspections in difficult access areas faster and easier

• Menu Directed Inspection (MDI) enables faster, more accurate compilation of
inspection data and reports

• User-defined profile setups accommodate specific inspector preferences, or
inspections by plant type

• IP55-designed durability for rugged inspection conditions

• Crisp image quality improves Probability of Detection (PoD) of FAC, pitting, cracking,
wear and tip rub

• Touchscreen interface and 3D Phase Measurement allow for faster, more precise
inspection analysis

General Inspection

• Faster, more accurate inspections for pumps, motors, generators, pulp and paper
rollers, gear boxes, pipes, tubes, purity pipes, turbines, compressors, large pistons,
chillers, valves, gun barrels, mortar tubes, Homeland Security, and maritime surveying

• IP55, MIL-STD-810G and MIL-STD-461F designed for durability in any work environment

• Interchangeable probes with multiple lengths and diameters allow for more
inspection areas with a single system

• Touchscreen interface for intuitive operation, with extreme image quality for
enhanced Probability of Detection (PoD)

• Menu Directed Inspection (MDI) holds RVI workflows, catalogs the inspection
images and generates reports on demand

• Remote collaboration for inspection advice in confined spaces or remote areas

Streamlined Service

Downtime is costly, and when it strikes you need instant access to the repair experts
who will get your asset up and running again. Our streamlined repair service allows
for fast diagnosis and expedited repair so that the Mentor Visual iQ is back where you
need it—in your hands.

Another Example of How GE Works

The Mentor Visual iQ from GE combines intelligent machines, data and people to
deliver more productivity. This industry-changing video borescope provides the
portability, powerful features and collaboration needed for faster, more accurate
decisions. Internet connectivity will allow you to connect remotely and share images
and data on the job site or around the world.

Contact your sales representative for a demo.
