GE MDS 05-4558A01 User Manual

MDS Mercury

Wireless IP/Ethernet Transceiver

Covering all AP and Remote Units

including Mercury 900, 3650, and Option Set 1 Remotes

Series

™

Start-Up Guide

MDS 05-4558A01, Rev. C

December 2008

Contents

PRODUCT DESCRIPTION .....................................................2

INSTALLATION OVERVIEW ................................................... 2

INSTALLATION STEPS ..........................................................2

Step 1—Mount the Transceiver ...................................................3

Step 2—Install the Antenna ........................................................3

Step 3—Measure & Connect Primary Power ..............................4

Step 4—Review the Transceiver’s Configuration ........................4

Step 5—Connect the Data Equipment ........................................ 7

Step 6—Check for Normal Operation .........................................7

Resetting to Factory Defaults (Use with Care) ............................8

AIMING DIRECTIONAL ANTENNAS ..................................... 8

Procedure ...................................................................................9

TRANSMITTER POWER AND ANTENNA TEST .................10

Procedure .................................................................................10

TROUBLESHOOTING ..........................................................11

SPECIFICATIONS ................................................................ 14

TECHNICAL ASSISTANCE .................................................. 16

FACTORY SERVICE .............................................................16

Copyright Notice

This publication is protected by U.S.A. copyright law. Copyright 2008, GE MDS. All
rights reserved.

The center of this guide contains a chart with a summary of installation
procedures. Refer to the Mercury Reference Manual (05-4446A01) for
additional warnings, cautions, and notes.

05-4558A01, Rev. C MDS Mercury Series Startup Guide

1

PRODUCT DESCRIPTION

MDS Mercury
less network service with long range and secure operation at adaptive
data rates approaching 12 Mbps. The transceiver is ideally suited for
demanding applications in mobile or fixed environments, where reli­ability and range are paramount.

The product is commonly used to send text documents, graphics,
email, video, voice over IP (VoIP), and a variety of other application
data between mobile, fixed-point, and LAN-based entities.

The transceiver comes in two primary models—Access Point and
Remote, each with unique hardware profiles. Both models support
Ethernet and serial services. An Access Point (AP) is a wireless hub
that usually provides connectivity into a wired Ethernet LAN/WAN.
Remotes associate over the air with an Access Point and are typically
connected to an Ethernet or Serial device via a cable.

TM

Series transceivers provide an easy-to-install wire-

INSTALLATION OVERVIEW

There are three main requirements for installing the transceiver—ade­quate and stable primary power, a good antenna system, and the cor­rect interface between the transceiver and the data device. The
Installation Setup Chart (center of this guide) shows a typical Remote
installation. Access Point and mobile Remote stations typically use
omnidirectional antennas whereas fixed-site Remotes typically use
directional antennas such as a Yagi or panel type. Otherwise, both
installations are similar.

INSTALLATION STEPS

A typical shipment consists of a transceiver, a power connector and
this start-up guide. Below are the basic steps for installing a trans­ceiver. Refer to the
tion. You will also find support information at the GE MDS Web site:

www.GEmds.com. Our Technical Services Team is available to assist

with any difficulties that may be encountered. Refer to the back of this
guide for contact information.

It is highly recommended that the Access Point unit be installed
so that you can quickly check the operation of each associated Remote
as it is placed on the air.

2 MDS Mercury Series Startup Guide 05-4558A01, Rev. C

Mercury Reference Manual for detailed informa-

first

Step 1—Mount the Transceiver

Use the supplied 6-32 x 1/4 inch (6 mm) screws to attach the mounting
brackets to the bottom of the radio. Figure 1 shows the mounting
dimensions of the unit. Mount the radio to a stable surface. (Fasteners
not normally supplied.)

Invisible place holder

2.75˝ (7 cm)

8 5/8˝ (21.8 cm)

Figure 1. Transceiver Mounting Dimensions

(Dimensions for AP and Remotes identical)

CAUTION

POSSIBLE

EQUIPMENT

DAMAGE

Use only the supplied mounting bracket screws. Screws
extending farther than 1/4 inch (6 mm) into the case
may cause internal PC board damage.

Step 2—Install the Antenna

To minimize RF interference, the antenna should be mounted at least
nine inches (> 23 cm) from the connected device(s), sensors and other
external components of the system. Additional information on antenna
selection and installation is provided in the

Manual

Install GPS Antenna

.

Install the GPS antenna in accordance with the manufacturer’s instruc­tions, and connect the antenna cable to the SMB-type connector on the
transceiver’s front panel.

05-4558A01, Rev. C MDS Mercury Series Startup Guide

Mercury Reference

3

+

—

Step 3—Measure & Connect Primary Power

The DC input power to the transceiver must be within 10–30 Vdc and
capable of continuously providing at least 2.5 Amperes. A power con­nector with screw-terminals is provided with each unit. Strip the wire
leads to 6 mm (1/4 inch). Be sure to observe proper polarity as shown
in Figure 2 with the positive lead (

) on the left side; negative on the

right side.

Invisible place holder

Figure 2. Power Connector

(Polarity: Left +, Right –)

CAUTION

POSSIBLE

EQUIPMENT

DAMAGE

NOTE:

Typically, it takes about 30 seconds for the transceiver to fully

The transceiver must be used with negative-ground sys­tems only. The power supply should be equipped with
overload protection (NEC Class 2 rating), to protect
against a short circuit between its output terminals and
the radio’s power connector.

power up, and may take several minutes to associate with
another unit, especially if GPS is required for time synchroni­zation.

Step 4—Review the Transceiver’s Configuration

There are two key settings that must be known before placing the unit
into service:

•

Network Name

are part of the same network. The Network Name must be pro­grammed to enable Remote units to associate with the Access
Point unit. (Default name is

•

IP Address

through the

4 MDS Mercury Series Startup Guide 05-4558A01, Rev. C

Common identifier used by all of the units, that

MDS-Mercury

.)

—Must be a unique address to allow for IP access

port or over-the-air. (Default is

LAN

192.168.1.1

)

Other parameters commonly needing review or adjustment are:

RF Output Power Level

•

(AP Only)—Check and adjust as neces­sary for compliance with regulatory limits. (Default power is
+30 dBm for 900 model, +20 dBm for 3650 model.) Note that
Remotes “auto-adjust” power output based on target receive
signal set at the Access Point.

•

Password

Frequency Mode

•

Configuration Menu>Frequency Control

—Used for remote access and Menu System features.

(900 model only)—This is found under

. The following modes

are available:

Single Channel

—Where AP and Remote link up using one fre­quency channel of the 14 possible channels in the 900 Mhz
band. This is the default frequency mode.

Static Hopping

—Where an AP and Remote link up using
FHSS based on a Hop Pattern.

Hopping with Hand-offs

—(Used with Remotes only.) Based on
AP locations file, which contains GPS coordinates to prede­termine or preselect which AP to hop with.

•

Frequency

•

TDD Sync Mode
GPS

(3650 model only)—Operating frequency in MHz.

GPS Required

, and

(AP only)—Selections are:

.

Free Run

,

Prefer

Radio

For single channel operation, the TDD Sync Mode can be set to

Free Run

or

GPS Required

. Using

GPS Required

synchronizes
the AP’s transmissions to the GPS timing. When the frequency
mode is

Required

Free Run

that

Free Run

Static Hopping

the TDD Sync Mode must be set to

.

allows for rapid configuration in most systems. Note

only works on single channel frequency mode (the

GPS

default mode).

GPS Required

is only needed on the 3650 model to synchronize

multiple Access Points.

NOTE:

The default password for all units is
name is

admin

.

. The default user-

admin

A unique IP address and subnet are required to access the Menu
System, either through the

port, or remotely over-the-air.

LAN

A summary of selected operating parameters’ range and default values
is included in the Installation Setup Chart at the center of this guide.

05-4558A01, Rev. C MDS Mercury Series Startup Guide

5

Log-in and Configuration Procedure

The following is an overview of the local log-in and configuration pro­cedure using the
and other methods of control, refer to the

a. Connect a computer’s serial port to the

COM1

serial port. For detailed instructions on this,

Mercury Reference Manual .

COM1

Port of the radio.

b. Launch a terminal communication program, such as Hyper-

Terminal, on the computer. (Configure terminal to: 115,200
bps/8N1/no handshaking/VT100.)

c. Press the

ENTER

key. A login prompt will be displayed that

requires a username and password.

admin

d. Enter the username and password (default entries are

).

e. Change the radio’s network name from the default entry of

MDS-Mercury
tion Menu

. This can be changed under the

for both AP and Remote.

Radio Configura-

f. Review other settings and make changes as necessary, such as

the unit password, IP address, and security.

g. Under the Radio Configuration Menu at the Access Point,

set/verify the following:

Transmit Power

—Settable from: -30 dBm to +30 dBm (AP);

0 dBm to +30 dBm (Remote); +20 dBm for 3650 models.

Receive Power

—Target receive signal of the AP which

Remotes will have to adjust based on distance.

h. Under the

Frequency Control

Menu of the

Radio Configuration

Menu set/verify the following:

Frequency Mode
Single Frequency
Frame Duration

—Single Channel

—Channel (0 to 13)

—for a 1.75 Mhz channel, use either 10 or 20

milliseconds.

i. Ensure that the Remote's radio parameters are consistent with

the AP's network name and the Frequency Control Parameters.

Repeat above steps for each unit in the network.

6 MDS Mercury Series Startup Guide 05-4558A01, Rev. C

NOTE:

Using

Configuration Scripts

under the

Maintenance/Tools

menu will aid in uniformly configuring multiple units. See the

Mercury Reference Manual

for details.

Step 5—Connect the Data Equipment

Connect Ethernet-compatible data equipment to the unit’s

LAN

port
(10/100 BaseT), or one of the serial ports, depending on the capability
of your transceiver.

Use a straight-through Ethernet cable to connect the

LAN

port to a hub
or switch, and a crossover cable to connect it directly to an Ethernet
station (PC, PLC, RTU).

Step 6—Check for Normal Operation

This step verifies the proper operation of wireless communications
between an Access Point and its associated Remotes.

At All Units...

Observe the transceiver’s LED panel (See
for the proper indications. In a normally operating system, the radio
will typically become associated in about two minutes from start-up.

At the Access Point...

a. If the Access Point unit is the first unit you are installing, send

PING

a

command to it through the

LAN

connectivity.

b. If you have already installed a Remote unit, try sending a

to that unit through the Menu System
connected to the unit on the same subnet.

Installation Setup Chart

LAN

port. This verifies basic

PING

utility or a device

)

PING

At Remotes...

a. Look for the

LINK

LED to turn on and stay on. This indicates
the unit has successfully associated with the network’s Access
Point. (The association process may take up to 30 seconds.)

b. Check the

Starting Information

screen for the

Device Status

(also known as Connection Status). It will show one of the fol­lowing:

Initializing

05-4558A01, Rev. C MDS Mercury Series Startup Guide

—This is the first phase after boot-up.

7

Scanning

—The unit is looking for an Access Point beacon signal.

Ranging

Connecting

Authenticating

—Unit is adjusting power, timing, and frequency with an AP.

—Unit has an RF connection with the AP.

—(When Device Authentication is in use) The Remote

is authenticating itself to the network to obtain security clearance.

Associated

—The unit has successfully synchronized and associated

with an Access Point. This is the normal status.

Alarmed—The unit is has detected one or more alarms that have not

been cleared.

c. When the network is operating properly based on observation

of the unit’s LEDs, connect a computer to the transceiver’s
data port that will be used by the local terminal equipment.
Send the

PING command to verify communications link integ-

rity with the Access Point.

d. After the

PING is successful, connect the terminal equipment

to the radio’s data port and verify normal operation.

If all checks are OK, you are finished with the installation at this site.

Resetting to Factory Defaults (Use with Caution)

Selecting Maintenance/Tools>Reset to Factory Defaults sets all trans-
ceiver parameters back to their factory defaults. This may be useful
when several parameters have been modified and there is no track of
changes. It causes the transceiver to return to a known factory state.
Use this function with care, as all user-customized settings will be
cleared.

AIMING DIRECTIONAL ANTENNAS

Directional antennas usually require some fine-tuning of their bearing
to optimize the received signal strength. The unit has a built-in
received signal strength indicator (RSSI) that can be used to optimize
the received signal level. It is available under the

tion

menu.

8 MDS Mercury Series Startup Guide 05-4558A01, Rev. C

Performance Informa-

Flashing....Data Tx/Rx

LINK .....ON ............Default state

Access Point

Flashing....Alarm present

OFF ..........Primary power (DC) absent

Flashing....Data Tx/Rx

OFF ..........Not Associated with AP

LINK  .....ON ............Associated to AP

Remote Gateway

Flashing....Data TX/RX

OFF ..........LAN not detected

OFF ..........No data activity

Flashing....Synchronizing

OFF ..........No satellite fix

PANEL

LED INDICATOR

COM1

SERIAL PORT

LAN PORT

TX/RX1

ANTENNA PORT

PORT

RX2 ANTENNA

CONNECTION

GPS ANTENNA

(10—30 VDC, 2.5A)

DC POWER INPUT

LAN PORTS

USB PORTS

(Mini-A, Type-A)

PANEL

LED INDICATOR

COM1

SERIAL PORT

TX/RX1

ANTENNA PORT

PORT

RX2 ANTENNA

WiFi ANTENNA

GPS ANTENNA

PORT

CONNECTION

(10—30 VDC, 2.5A)

DC POWER INPUT

LED FUNCTIONS & INDICATIONS

PWR .....ON ............Primary power (DC) present

Network

Configuration

Ntwk. Intfc. Config

Ethernet Port Config

Bridge Configuration

SNMP Agent Config. (AP)

AP Location Info (RM)

SNTP Server Config.

LAN ......ON ............LAN detected

COM1 ...Flashing....Data TX/RX Activity

GPS ...ON ............Has satellite fix

Radio

Configuration

Network Name

Transmit Power

Receive Pwr. (AP)

Freq. Control

Adv. Config.

CONNECTORS AND INDICATORS

Standard Unit

Security

Configuration

Device Security

Wireless Security

RADIUS
Configuration

Manage Certif.

Starting Information Screen

(Read-Only Status)

MAIN MENU

Redundancy

Configuration (AP)

Redundancy Config.

Ntwk Event Triggers

Radio Event Triggers

Hdwr Event Triggers

Red. Config. Options

Force Switchover

GPS

Configuration (RM)

Option Set 1

Device

Information

Model

Serial Number

Uptime

Date

Time

Date Format

Console Bd. Rt.

UTC Time Offset

Device Names

Remote

Performance

Information

Event Log

Packet Statistics

GPS Status

Wireless Ntwk Stat.

Intl. Radio Stat. (RM)

Performance Trend

Maintenance/Tools

Reprogramming

Config. Scripts

Ping Utility

Auth. Codes

Reset to Defaults

Radio Test

F/W Versions

F/W Upgrade

NOTES

• Char t shows top-level view only. See Reference Manual for details.

• Not all menu items are-user configurable

• Spacebar is used to make some menu selections

• AP = Access Point Only

• RM = Remote Only

MENU SYSTEM

Flowchart

Stream GPS to Console

Send GPS via UDP

GPS UDP Server IP Address

GPS UDP Server UDP Port

GE MDS
175 Science Parkway
Rochester, NY 14620 USA
www.GEmds.com

Insert to P/N 05-4458A01

INST

INST

ALLA

ALLA

Detailed instructions are contained in the Reference Manual, P/N 05-4446A01

INSTALLATION SUMMARY

Step 1 – Mount the Transceiver

Step 2 – Install the Antennas

Step 3 – Measure & Connect Primary Power

TION REFERENCE CHART

TION REFERENCE CHART

(10–30 Vdc)

ANTENNA
SYSTEM

Step 4 – Review the Transceiver’s Configuration

Network Name—Unique name for each radio network. Required for

Remotes to associate with the Access Point. (Default name is
MDS-Mercury.)

IP Address—Must be a unique number to allow for IP access

through the Ethernet Port.

NOTE: A unique IP address is essential to access the web browser-based

Management System.

RF Output Power—Adjust as necessary for regulatory compliance.
Username/Password—Used for remote access and some Management

System features. (Username and Password default = admin)

Step 5 – Connect the Data Equipment

Connect the data equipment to data port(s):

• LAN—10/100BaseT Ethernet-compatible equipment:
Ethernet PLC (Crossover cable); Ethernet switch (Straight-Through)

• COM1—RS/EIA-232 compatible equipment (Crossover cable to serial

PLC/RTU)

tep 6 – Check for Normal Operation

Observe the transceiver LED status panel for the proper indications. In a normally operating system, the following LED indications s

hould be seen within 30 seconds of power-up:

WR—Lights continuouslyL AN—On or blinks intermittently LINK— On or blinks intermittently (Remotes: if associated)
U se PING command to test basic data link integrity between Access Point and Remotes.
I f the PING command is successful, connect the RTU/data equipment to the data port and verify normal operation.
I f the LINK LED on Remotes is not on after 2 or 3 minutes, the unit has failed to associate with the Access Point. It may be necessary t

o reposition or redirect the radio’s antenna for better reception/signal strength. Check also GPS antenna system.

C heck connected data equipment for normal operation.

RTU/PLC

(Crossover Cable

to Radio)

PC RUNNING
TERMINAL
PROGRAM
(Straight-Through
Cable to Radio)

TO DC POWER SUPPLY

(10–30 Vdc)

TO GPS ANTENNA

(Provides 3.3 Vdc output)

TYPICAL INSTALLATION—Remote Shown

LOW-LOSS FEEDLINE

(To 900 MHz Antenna)

BASIC CONFIGURATION DEFAULTS

The Management System can be accessed through the COM1 Port using a terminal emulator. The basic items listed below, and
many other parameters and tools can be accessed through this tool. HTTP, Telnet access, and changing parameters are controlled

by password.

ITEM MGT SYSTEM MENU

Username/Password Device Information

Network Name Network Configuration

IP Address Network Configuration

RF Output Power Radio Configuration

DEFAULT

admin (lower case)

MDS-Mercury

192.168.1.1

+30 dBm (900 model)
+20 dBm (3650 model)

VALUES/RANGE

•1–8 alphanumeric characters

•Case-sensitive; can be mixed case

• 1–16 alphanumeric characters

• Case-sensitive; can be mixed case

Contact your Network Administrator

AP: -30 to +30 dBm RM: 0 to +30 dBm

In general, signal levels stronger than –80 dBm will provide reliable
communication in the network. RSSI measurements and Wireless
Packet Statistics are based on multiple samples over a period of sev­eral seconds. The average of these measurements is displayed by the
RSSI screen.

In the steps below, the path to the Menu System item is shown in bold
text.

Procedure

1. Verify the Remote is associated with an Access Point unit by
observing the LINK LED. It should be on or blinking.

2. View and record the
rates. This information will be used later.

Main Menu>Performance Information>Packet Statistics

3. Read the RSSI level at the Remote.

Main Menu>Performance Information>Internal Radio Status

4. Optimize RSSI by slowly adjusting the direction of the antenna.
Watch the RSSI indication for several seconds after making each
adjustment so that the RSSI accurately reflects any change in the
link signal strength. The less negative the number, the stronger the
signal.

5. View the

Wireless Packets Dropped and Received Error rates at the

point of maximum RSSI level. They should be the same or lower
than previously noted.

Main Menu>Performance Information>Packet Statistics

Wireless Packets Dropped and Received Error

If the RSSI peak results in an increase in the Packets Dropped and

Received Error numbers, the antenna may be aimed at an undes-

ired signal. Try a different antenna heading.

NOTE: Access Points and Remote stations must use the same antenna

polarity (vertical or horizontal) or signal strengths will be
attenuated by 20 dB or more.

05-4558A01, Rev. C MDS Mercury Series Startup Guide 9

TRANSMITTER POWER & ANTENNA TEST

The following procedure may be used to measure the transmitter’s RF
power output and SWR “match” of the antenna system. A directional
wattmeter is required for the test, such as a Bird Model 43, with an
appropriate element installed.

Before you start, keep in mind that using the Test Mode will disrupt
network operation.

Procedure

1. Connect a directional wattmeter between the ANTENNA port and
the antenna system.

2. Place the transceiver into the Radio Test Mode.

Main Menu>Maintenance/Tools Menu>Radio Test>Radio Mode>Test

NOTE: The Test Mode has a 10-minute timer, after which it will

return the transceiver to normal operation. The Test Mode can
also be terminated manually, via the menu.

3. Set the transmitter RF output power to +28 dBm.

Main Menu>Radio Configuration>Transmit Power

NOTE: The Test Mode RF power setting does not affect the output

level during normal operation

4. Activate (key) the transmitter.

Main Menu>Maintenance/Tools>Radio Test>Test Mode>
TxKey> Enable

Use the spacebar to key and unkey the transmitter ON and OFF
(Enable/Disable).

5. Using the wattmeter, measure the forward and reflected power
into the antenna system and calculate the SWR. The ratio should
be less than 2:1. Higher levels may indicate a problem with the
antenna or feedline.

6. Turn off Test Mode at the Access Point and Remote radio.

Main Menu>Maintenance/Tools>Radio Test>Radio Mode>Normal

10 MDS Mercury Series Startup Guide 05-4558A01, Rev. C

TROUBLESHOOTING

It is best to begin troubleshooting at the Access Point, as the rest of the
system depends on it for network synchronization and configuration.
If the Access Point has problems, the operation of the entire network
will be affected.

All radios in the network must meet these basic requirements:

• Adequate and stable primary power

• An efficient and properly aligned antenna system

• Secure connections (RF, data & power)

• Proper programming of the unit’s operating parameters, espe­cially Frequency Mode Selection, Network Name, and IP
Address

• The correct interface between the radio and the connected data
equipment (proper cable wiring, data format and timing)

Table 1 provides suggestions for resolving common system difficul-

ties using the radio’s LEDs as a guide. Table 2 on Page 13 provides
guidance for using the Menu System as a tool.

If problems cannot be resolved using the guidance provided here,
review the GE MDS web site’s technical support area for recent soft­ware/firmware updates, general troubleshooting help, and service
information. Additional help is available through our Technical Sup­port Department.

Table 1. Troubleshooting Using LEDs

Symptom Problem/Recommended Checks

PWR LED
not lit.

PWR LED is
blinking.

05-4558A01, Rev. C MDS Mercury Series Startup Guide 11

a. Voltage too low—Check for proper supply voltage at

the power connector (10–30 Vdc).

b. Indefinite Problem—Cycle the power and wait

(≈ 30 seconds) for the unit to reboot. Then, recheck for
normal operation.

a. Blinking indicates the presence of an alarm condition.

b. View Current Alarm List and Error Log and correct the

problem if possible.

c. Blinking continues until the fault is corrected, for

example, a valid IP address is entered, etc.

Table 1. Troubleshooting Using LEDs (Continued)

Symptom Problem/Recommended Checks

LINK LED
not lit.

LAN LED not
lit.

GPS LED
not lit

a. Network Names of APs and Remotes do not match.

They must be identical for association to occur—Also,
verify that the system has a unique Network Name.

b. Remote not yet associated with an Access Point with

the same Network Name.

Check the “Status” of the unit’s process of associating
with the Access Point. Use the Menu System.

c. Poor Antenna System—Check the antenna, feedline

and connectors. Reflected power should be less than
10% of the forward power reading (SWR 2:1 or lower).

d. Wrong Frequency Mode parameters where units need

to be time synchronized. Frequency Mode parameters
are channel, bandwidth and pattern offset.

e. Wrong encryption settings—The Encryption Enable

and Encryption Phrase must match on the AP and
Remote.

f. Wrong device authentication settings—Verify settings

match on AP and Remote.

a. Verify the Ethernet cable is connected at both ends.

b. Verify that the appropriate type of Ethernet cable is

used: straight-through, or crossover as required.

c. Verify setting of parameter Eth Port Follows

Association if selected or enabled. If enabled, LED

does not light when Remote is not associated.

Indicates no GPS fix has been obtained. This only applies
when GPS operation is desired.

a. Check connection of GPS antenna cable and the

antenna itself. Is there a clear “view” to satellites?

Note: Blinking LED indicates establishing TDD Sync.

12 MDS Mercury Series Startup Guide 05-4558A01, Rev. C

Table 2. Troubleshooting with the Menu System

Symptom Problem/Recommended System Checks

Cannot Access the
Remote or AP
through COM1

Cannot pass IP
data to WAN.

Excessive Wireless
Retries.

Password
forgotten.

Only occurs in three possible scenarios:

—COM1 is damaged or the Unit is faulty.

—COM1 is being used for Streaming GPS

information to Console terminal.

—COM1 is being used for serial data.

a. Connect to unit via Telnet or Web browser

b. Disable the serial mode for COM1

(Serial Gateway Configuration>Com1 Serial
Data Port>Status>Disabled)

or, if you know the unit’s data configuration...

c. Connect to COM 1 via a terminal set to VT100

and the port's data baud rate to xxxx bps (4800
for GPS) 8N1.

d. Port in Data mode. Enter escape sequence “+++”.

a. Verify your IP settings.

b. Use the PING command to test communication

with units in the local radio system.

c. If successful with local PING, attempt to PING an

IP unit attached to another radio.

d. If successful with the LAN PINGs, try connecting

to a known unit in the WAN.

Possible Radio Frequency Interference (RFI)—

a. If omnidirectional antennas are used, consider

changing to directional antennas. This will often
limit interference to and from other stations.

b. Try skipping channels where persistent

interference is known or suspected.

c. The installation of a filter in the antenna feedline

may be necessary. Consult the factory for further
assistance.

a. Connect to the unit using a terminal through the

COM1 Port.

b. Consult the factory. Get a password-resetting

Authorization Key.

c. Enter the Authorization Key at the login prompt

as a password. Use login name authcode.

05-4558A01, Rev. C MDS Mercury Series Startup Guide 13

SPECIFICATIONS

GENERAL

Temperature Range: –40° C to +70° C (–40° F to 158° F)
Humidity: 95% at +40° C (104° F); non-condensing
Primary Power: 10–30 Vdc
External Power Supply Options: 48 Vdc; 110–120/210–220 Vac
Typical Current Consumption (assumes 1 Watt RF Output):

Mode DC Power 13.8 Vdc 24 Vdc

AP Transmit 25 W 1.8 A 1.0 A

AP Receive 8 W 579 mA 333 mA

RM Transmit 25W 1.8 A 1.0 A

RM Receive 6.5W 471 mA 270 mA

Size (without mtg. hardware): 5.72 H x 20 W x 12.38 D cm

Mounting Options: Flat surface brackets, DIN rail, 19” rack
Weight: 1kg / 2.2 lb.
Case: Die Cast Aluminum

(2.25 H x 7.88 W x 4.88 D in.)

RADIO CHARACTERISTICS

GENERAL:

Frequency Band: Mercury 900: 902–928 MHz

TRANSMITTER:

RF Output @ connector: Mercury 900: –30 to +30 dBm

Duty Cycle: Continuous
Output Impedance: 50 Ohms

RECEIVER:

Type: Double conversion superheterodyne
Sensitivity and Data Rate: Dependent on modulation and bandwidth.

Industrial, Scientific & Medical (ISM) Band

Mercury 3650: 3650–3700 MHz
FCC Registered Band

Mercury 3650: 0 to 20 dBm

Increments of 1.0 dB, set by user

See Reference Manual Specifications.

14 MDS Mercury Series Startup Guide 05-4558A01, Rev. C

PHYSICAL INTERFACE: Ethernet: 10/100BaseT, RJ-45

Serial: (COM1) RS-232, DB-9F

APPROVALS: FCC Part 15.247 (DTS)

CSA

/US Class 1, Div. 2

Industry Canada RS-210

PROTOCOLS: Ethernet: IEEE 802.3, Spanning Tree

(Bridging), VLAN, IGMP

TCP/IP: DHCP, ICMP, UDP, TCP. ARP,
Multicast, SNTP, TFTP

Serial: Encapsulation over IP (tunneling)
for serial async multidrop protocols includ­ing Modbus, DNP.3, DF1, BSAP

MANAGEMENT: HTTP, HTTPS, TELNET, SSH, local

console

SNMPv1/v2/v3, MIB-II, Enterprise MIB,
SYSLOG, MDS NETview MS

TM

compati-

ble

05-4558A01, Rev. C MDS Mercury Series Startup Guide 15

TECHNICAL ASSISTANCE

Technical assistance is available from our Technical Support Depart­ment during business hours (8:30 A.M.–7:00 P.M. Eastern Time).
When calling, please give the complete model number of the radio,
along with a description of the trouble symptom(s) that you are expe­riencing. In many cases, problems can be resolved over the telephone,
without the need for returning the unit to the factory.

Phone: [phone] E-Mail: [e-mail]

FAX: [phone] Web: www.GEmds.com

FACTORY SERVICE

If return of the equipment is necessary, please contact our Technical
Support Team. You will be issued a Service Request Order (SRO)
number. The SRO number will help expedite the repair so that the
equipment can be repaired and returned to you as quickly as possible.
Please be sure to include the SRO number on the outside of the ship­ping box, and on any correspondence relating to the repair. No equip-

ment will be accepted for repair without an SRO number.

A statement should accompany the radio describing, in detail, the
trouble symptom(s), and a description of any associated equipment
normally connected to the radio. It is also important to include the
name and telephone number of a person in your organization who can
be contacted if additional information is required.

The radio must be properly packed for return to the factory. The orig­inal shipping container and packaging materials should be used when­ever possible. All factory returns should be addressed to:

GE MDS
Customer Service Department
(SRO No. XXXX)
175 Science Parkway
Rochester, NY 14620 USA

When repairs are complete, the equipment will be returned by the
same shipping method used to send it to the factory. Please specify if
you wish to make different shipping arrangements. To inquire about
an in-process repair, contact our Product Services Group using the
telephone, Fax, or E-mail information given above

16 MDS Mercury Series Startup Guide 05-4558A01, Rev. C

.

GE MDS, LLC
175 Science Parkway
Rochester, NY 14620

General Business: [phone]

FAX: [phone]

Web: www.GEmds.com
