JVE40ST
1/2
10
3-1/4
5-3/4
Center
line of hood
1-1/4
1-1/4
Optional power
supply connection
1-1/8" Ty p.
7-3/4
1-3/8" Ty p.
8-1/4" Typ.
Center
line of hood
1-1/4
1-1/4
Optional power
supply connection
1-1/8" Ty p.
7-3/4
1-3/8" Ty p.
8-1/4" Typ.
GE® 30" ENERGY STAR® Qualified Ventilation Hood
Dimensions and Installation Information (in inches)
Amp Rating
120V 1.0
WB02X11537 replacement grease filter and WB02X11000
replacement charcoal filter are available for additional
cost. Call toll-free 800.626.2000.
JXHC1 Cord Kit: Allows a receptacle in the cabinet over
the range to accommodate either an over-the-range
microwave oven or a standard hood.
Installation Information: Before installing, consult
installation instructions,packed with product, for current
dimensional data.
12
5-15/16
Exhaust outlet connects to 3-1/4"
x 10" rectangular duct. Vent top or
rear. Includes rectangular damper.
29-15/16
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000
19-1/2
Listed by
Underwriters
Laboratories
Specification Revised 11/11
321455
JVE40ST
GE® 30" ENERGY STAR® Qualified Ventilation Hood
Features and Benefits
• ENERGY STAR qualified - Meets or exceeds federal guidelines for
energy efficiency for year-round energy and money savings
• Convertible venting - Hood designed to accommodate a vented
configuration, which channels exhaust outside of the home, or a nonvented configuration, which filters and returns the air into the kitchen
• Vertical and rear exhaust - Hood design gives installers total flexibility
to connect the exhaust vent to your home’s duct work from either the
top or rear of the unit
• 2 Fan Speed Selections
• Cooktop light - Enjoy the convenience of light under the hood to help
you better see your cooking surface
• Removable grease filter - Durable grease filter collects the grease that
builds up from cooking and removes quickly and easily for cleaning
• Rectangular ducting - Designed to fit standard rectangular duct work
for quick and simple installation
• Rectangular damper included - Included damper keeps the vent
sealed when it is not in use, so your home’s heat doesn’t escape
• Model JVE40STSS – Stainless steel
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000
CFM/Sones Ratings
Rear Exhaust High Speed (HS) 240/5.5
Rear Exhaust Working Speed (WS) 120/1.2
Top Exhaust (HS) 210/6.0
Top Exhaust (WS) 110/1.3
*Not ENERGY STAR qualified if hood is installed in a non-vented configuration
Specification Revised 11/11
321455
