JP3030DJ/TJ
GE® 30" Built-In Knob-Control Electric Cooktop
DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)
IMPORTANT: Requires a 5" free area between the bottom of the cooktop to any combustible material, i.e., shelving. Free area not required when installing wall oven underneath cooktop. Refer to installation instructions. Requires a 15" minimum from cooktop to adjacent overhead cabinets. Units are furnished with a 48" flexible armored cable.
NOTE: 30" Ribbon cooktops are approved for use over select GE 27" and GE 30" Single Wall Ovens and Warming Drawers. Refer to cooktop and wall oven/warming drawer installation instructions packed with product for current dimensional data. If installed with a GE Telescopic Downdraft System, consult both the cooktop and downdraft installation instructions packed with product before installing. Cooktop gas/electric supply may need to be re-routed to install downdraft. The countertop cutout requires 23-1/2" minimum flat countertop surface and 25" minimum total countertop depth. In addition, other clearances to front edge of the countertop must be considered. Before installing, consult installation instructions packed with product for current dimensional data.
CUTOUT FILLER TRIM KIT: A filler trim kit is available for use if your countertop cutout is
larger than the dimension shown, up to 29-13/16" x 20-7/16". Order JXTR32B for black or JXTR32W for white, to reduce the cutout opening for installation of this cooktop. These kits may be ordered from your GE Appliances Dealer.
13" MAX. depth of unprotected
APPROXIMATE COOKING DIMENSIONS overhead cabinets (when no
hood or microwave is installed)
3-1/4" at front of unit and 4" at conduit location
29-3/4" 20-7/8"
Cooktop
19-1/4" 28"
19-5/8" to
19-3/4"
1-3/4" MIN. |
28-1/2" to |
to rear wall |
28-5/8" |
|
2-1/2" MIN.
Required
To insure accuracy, it is best to make a
template when cutting the opening in the counter
30" MIN. from countertop to unprotected cabinet (when no hood or microwave is installed)
Electrical junction box 16" MIN. below countertop
2" MIN. clearance to side wall from cut-out on left sides of unit and
1-1/2" clearance on right side of unit
15" MIN. height from countertop to nearest cabinet (including light rails) on both sides of cooktop
INSTALLATION ABOVE A WALL OVEN
2-1/2" MIN
From front edge of countertop to front
edge of cooktop cutout
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
VOLTAGE (60HZ AC) |
240V |
208V |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CONNECTED LOAD (MAX.) |
7.4kW |
5.6kW |
|||||||
31-1/4" MIN |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CURRENT DRAW (MAX.) |
30.8 Amps |
26.7 Amps |
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RECOMMENDED CIRCUIT BREAKER† |
40 Amps |
30 Amps |
|||||||||
From top surface |
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||
of countertop to |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
top surface of |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
wall oven support |
|
|
|
|
|
|
|
|
|
|
|
|
|
†NOTE: Check local codes for required breaker size. |
|
||||||||||||
platform |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ADA |
Listed by |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Underwriters |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
COMPLIANT |
Laboratories |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
For answers to your Monogram, GE Café™ Series, GE Profile™ Series or |
|
GE Appliances product questions, visit our website at geappliances.com |
|
or call GE Answer Center® Service, 800.626.2000. |
Specification Revised 6/20 |
JP3030DJ/TJ
GE® 30" Built-In Knob-Control Electric Cooktop
FEATURES AND BENEFITS
Four radiant cooking elements
Power Boil elements
Keep warm setting
Melt setting
Hot surface indicator lights
Cooktop "on" indicator light
Fit Guarantee
Model JP3030TJWW – True white
Model JP3030DJBB – Black on black
GUARANTEED FIT
Replacing a similar cooktop from GE Appliances or another brand? GE cooktops are guaranteed for an exact fit or GE Appliances will pay up to $100 toward modifications
Visit geappliances.com for more info
Specification Revised 6/20
