GE Interlogix BusSecure User Manual

BusSecure
Mobile Digital Video Recorder
© 2003 Kalatel, a GE Interlogix company
All Rights Reserved.
This document contains proprietary information that is protected by copyright. No part of this document may be reproduced or transmitted in any form or by any means without the prior written permission of GE Interlogix, Kalatel division.
The information contained in this document is subject to change without notice. GE Interlogix, Kalatel division, in keeping pace with technological advances, is a company of product innovation. Therefore, it is difficult to ensure that all information provided is entirely accurate and up-to-date. GE Interlogix, Kalatel division, accepts no responsibility for inaccuracies or omissions and specifically disclaims any liabilities, losses, or risks, personal or otherwise, incurred as a consequence, directly or indirectly, of the use or application of any of the contents of this document.
For the latest product specifications, visit GE Interlogix, Kalatel division, online at www.kalatel.com or contact your GE Interlogix, Kalatel division, sales representative.
For technical support before and after installation, call 800­469-1676.
Technical support is available 24 hours a day, 7 days a week.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
You are cautioned that any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Call: Tech Support 800-469-1676 (6 A.M. – 5 P.M. PST Monday through Friday) Tech Support 541-740-3589 (all other times) Main 800-343-3358 or 541-754-9133 Fax: Tech Support 541-752-9096 (available 24 hours a day) Main 541-754-7162 Web: www.kalatel.com
0150-0263A / May 2003
BusSecure User Manual Table of Contents
TABLE OF CONTENTS
BEFORE YOU BEGIN ..........................................................................................................4
1 THEORY OF OPERATIONS .............................................................................................5
1.1 DIGITAL VIDEO RECORDING..........................................................................................................5
1.2 VIEWING AND RETRIEVING IMAGES ................................................................................................5
1.3 FEATURES OF A BUSSECURE SYSTEM ........................................................................................... 6
2 HARDWARE INSTALLATION ...........................................................................................7
2.1 TOOLS NECESSARY FOR INSTALLATION..........................................................................................7
2.2 DETERMINING A SYSTEM LAYOUT..................................................................................................8
2.3 RUNNING CAMERA CABLES ..........................................................................................................9
2.4 INSTALLING CAMERA ASSEMBLIES ...............................................................................................10
2.4.1 Installing Surface-Mount Camera Assemblies............................................................... 10
2.4.2 Installing Flush-Mount Camera Assemblies...................................................................11
2.4.3 Adjusting Cameras for Functional Field of View.............................................................12
2.5 INSTALLING THE IMPACT SENSOR (OPTIONAL)...............................................................................14
2.6 INSTALLING THE PANIC BUTTON (OPTIONAL).................................................................................15
2.7 INSTALLING THE MICROPHONE (OPTIONAL)...................................................................................15
3 DVR INSTALLATION AND WIRING................................................................................16
3.1 MOUNTING THE DVR................................................................................................................. 16
3.2 WIRING THE DVR......................................................................................................................17
3.2.2 Alarm and Trigger Inputs...............................................................................................19
3.2.3 Status Output Connections........................................................................................... 20
3.2.4 Audio Connections........................................................................................................21
3.2.5 Input Power Connections..............................................................................................21
4 BUSSECURE CONFIGURATION ....................................................................................22
4.1 CONFIGURATION .......................................................................................................................23
4.1.1 Configure Network........................................................................................................24
4.1.2 Configure Cameras....................................................................................................... 25
4.1.3 Configure Inputs........................................................................................................... 26
4.1.4 Configure System.........................................................................................................27
4.2 SOFTWARE UPGRADE ................................................................................................................ 28
5 TROUBLESHOOTING ...................................................................................................29
APPENDIX A. CAMERA MOUNTING PLATE TEMPLATE ........................................................32
APPENDIX B. INSTALLATION CHECK SHEET.......................................................................33
APPENDIX C. DVR CONFIGURATION WORKSHEET .............................................................34
WARRANTY AND RETURN INFORMATION ..............................................................................................36
0150-0263A / May 2003 3
Before You Begin BusSecure User Manual
***
BEFORE YOU BEGIN
Read these instructions before installing or operating this product.
Note: This installation should be made by a qualified service person and should conform to local codes.
This manual provides installation and operation information. To use this document, you must have the following minimum qualifications:
Ÿ A basic knowledge of CCTV systems and components Ÿ A basic knowledge of electrical wiring and low-voltage electrical hookups
Intended use
Use this product only for the purpose for which it was designed; refer to the product specification and user documentation.
Customer Support
For assistance in installing, operating, maintaining, and troubleshooting this product, refer to this document and any other documentation provided. If you still have questions, please contact GE Interlogix, Kalatel division Technical Support and Sales:
Kalatel, a division of GE Interlogix, Inc. Call: 800-469-1676
Fax: 541-752-9096
Note: you should be at the equipment and ready with details before calling Technical Support.
Conventions Used in this Manual
Boldface or button icons highlight command entries. The following WARNING, CAUTION, and Note
statements identify potential hazards that can occur if the equipment is handled improperly:
WARNING:
Improper use of this equipment can cause severe bodily injury or equipment damage.
CAUTION:
Improper use of this equipment can cause equipment damage.
Note: Notes contain important information about a product or procedure.
* This symbol indicates electrical warnings and cautions. ** This symbol indicates general warnings and cautions.
4 0150-0263A / May 2003
BusSecure User Manual Theory of Operations
1 THEORY OF OPERATIONS
BusSecure is an industry-specific security camera system developed to help solve problems experienced by fleet operators. It is a digital video recording system that can support up to four cameras in a mobile environment and store captured images in a vehicle-mounted digital video recorder (DVR). Images can then be viewed and examined later.
1.1 DIGITAL VIDEO RECORDING
The central component of the BusSecure system is a high-quality DVR, which records images from up to four cameras (monochrome or color, NTSC or PAL) with single-channel audio and information such as the time, date, and vehicle number. Image storage capacity can be adjusted by recording speed, selected resolution, and drive size.
The DVR begins capturing images as soon as the vehicle’s engine is started and continues to record as long as the vehicle is running. When the available storage capacity is full, the DVR will automatically purge the oldest image data to make room for new image data. Tagged images (images recorded because of alarm activation) can be protected from being overwritten for a user-designated period of time (the default setting is 30 days) or can be protected from being over written at all.
1.2 VIEWING AND RETRIEVING IMAGES
The captured digital images are stored as monochrome or color files, and are taken from the DVR and downloaded to a computer with the BusSecure WaveReaderTM software. The DVR connects through an Ethernet connection to a standard desktop PC or Laptop installed with a Windows 98/2000/NT/XP
operating system. When the DVR is connected to a PC or Laptop with the WaveReader software, images can be viewed and transferred to long-term storage media such as DAT tapes, floppy disks, or recordable CDs.
0150-0263A / May 2003 5
Theory of Operations BusSecure User Manual
1.3 FEATURES OF A BUSSECURE SYSTEM
A BusSecure system consists of the required equipment and the accessories shown in Figure 1.
Figure 1. Required and optional features of a BusSecure system
Aluminum housing Microphone Camera Panic Button Up to four cameras per system Impact Sensor RG179 Siamese coaxial cable DVR assembly
6 0150-0263A / May 2003
BusSecure User Manual Hardware Installation
2 HARDWARE INSTALLATION
The BusSecure/DVR digital video recording system supports up to four cameras, and an optional impact sensor, panic button, and microphone.
Note: Most BusSecure products are not supplied with mounting hardware. Exceptions are noted in the appropriate sections of the manual.
2.1 TOOLS NECESSARY FOR INSTALLATION
Ÿ Laptop / viewing station Ÿ Electrical volt meter Ÿ BNC crimper Ÿ Molex pin crimper Ÿ Riv-nut gun Ÿ Socket set up to 5/8 in. Ÿ Wrenches up to 5/8 in. Ÿ Phillips and flathead screwdrivers Ÿ Solder gun with solder Ÿ Wire strippers Ÿ Drill Ÿ Drill bits up to 5/8 in. Ÿ Hole saws up to 1 1/8 in.
Ÿ Locktite (blue) Ÿ Torx bit secured #10 Ÿ Wire snake Ÿ Extension cords Ÿ 8-in. tie wraps Ÿ Electrical tape Ÿ Heat shrink Ÿ Spare BNCs Ÿ Molex pins and 4-pin housing Ÿ Electrical connections (ends, lugs, etc.) Ÿ P1, and P2 terminal blocks Ÿ General tools
0150-0263A / May 2003 7
Hardware Installation BusSecure User Manual
2.2 DETERMINING A S YSTEM LAYOUT
Figure 2 is an example camera layout for a bus application.
Note: For installation of these cameras, see their respective manuals.
Note: Camera layout and fields of view will vary from vehicle to vehicle, and each customer will determine camera names or
descriptions. Camera types, fields of view, and cable lengths will be determined by the customer-specific system layout.
The Front Door camera is located at the front of the bus over the driver’s head, looking at the front
passenger entry.
The Forward Facing camera is located in the front of the bus, looking in front of the bus. The Front to Rear camera is located in the front of the bus, looking down the center aisle to the rear of the bus. The Rear Facing camera is located at the back of the bus, looking behind the bus.
Figure 2. Typical camera placement and fields of view
8 0150-0263A / May 2003
BusSecure User Manual Hardware Installation
2.3 RUNNING CAMERA CABLES
CAUTION
When installing cables, follow these guidelines:
Avoid excessive lengths of cable at the control and device end. Excess cable should be pulled back to a
duct area where it can be folded and secured. Leave a service loop as directed for specific devices.
Cables should not come into contact with bare metal edges, light ballasts, or magnetic speaker coils. If
ballasts and speaker coils cannot be avoided, cross them perpendicularly.
Cables that are secured with cable-ties should not be tightened to the extent that the cable is
compressed or damaged. The cables should not be crimped, crushed, or severely bent.
When passing cables through tapping plates or metal side walls of the vehicle, insert grommets in the
holes to protect the cable, if possible This may not be feasible in a retrofit situation. If it is not feasible, make sure that the protective outer CL2 jacket is maintained when passing cable through hole.
When pulling cable through the conduit, do not jerk or over-pull the cables. These actions will stretch
and damage the cable. Attach a pull-line to the cable jacket, not to the connectors.
1) Route cables from each camera location to the DVR location as determined by your customer­specific system layout. Figure 3 shows an example system layout.
2) If cables must be pulled through vehicle walls with limited access or conduit, attach pull lines to the cables jackets, and gently pull cables through the appropriate routing paths.
3) After reaching camera locations, leave enough cable for a 6-inch service loop at each location.
4) Pull any excess cable back into the duct area where it can be folded and secured.
DVR Location
Figure 3. Typical camera cabling layout
4
0150-0263A / May 2003 9
Hardware Installation BusSecure User Manual
2.4 INSTALLING CAMERA ASSEMBLIES
The BusSecure system will support up to four cameras (color and/or monochrome). Cameras supported by the BusSecure system can provide a 1.0 V pk-pk composite analog video signal, either NTSC or PAL, at 75 ohm (CCTV standard).
2.4.1 INSTALLING SURFACE-MOUNT CAMERA ASSEMBLIES
Surface-mount camera housings are typically mounted to the ceiling, but can be mounted to any flat vehicle surface.
Note: In some installations, it is necessary to use a metal tapping plate behind the mounting surface. If a tapping plate is used, prepare it in the same way as the mounting surface (i.e., drill a cable entry hole and mounting holes in the appropriate locations).
1) Use the template in Appendix A to mark the location of the cable-entry hole and two mounting holes. See Figure 4.
2) Using a 3/16-inch (5 mm) (drill bit, drill the two mounting holes.
3) Using a 1-inch (25.4 mm) drill bit, drill the cable entry hole.
4) Install a 3/4-inch (20 mm) (interior diameter) grommet on
the cable entry hole, or where feasible.
5) Connect the video and power cables to the camera, and feed the excess cable into the vehicle’s duct area.
6) Mount the camera and mounting plate to the vehicle surface (and tapping plate, if used). See Figure 5.
7) Refer to section 2.4.3 to align the camera’s field of view to the appropriate angle.
8) Secure the surface-mount housing to the mounting plate with the four 3/8-inch tamper-resistant tamper-torque machine screws provided, using a bit of blue locktite. See Figure 6.
Cable entry hole Mounting holes
Figure 4. Mounting hole locations
Figure 5. Mounting plate installation
10 0150-0263A / May 2003
Figure 6. Surface-mount housing installation
BusSecure User Manual Hardware Installation
2.4.2 INSTALLING FLUSH-MOUNT CAMERA ASSEMBLIES
There are two types of flush-mount cameras—square and angled. Flush-mount camera assemblies are mounted flush with the side panels of the vehicle.
Note: The square bezel that holds the glass camera cover has countersunk holes in the back side that cover the two housing screws. The housing and bezel screws are separate to allow access to the camera for focusing and adjusting while the housing is held firmly in place.
1) Verify that there is at least 6 inches (153 mm) of clearance behind the mounting location.
2) Cut a 3.4- by 3.4-inch (81 mm) hole in the appropriate location on the mounting surface.
3) Using the housing as a template, mark the location of the mounting holes.
4) Using a 3/16-inch (5 mm) drill bit, drill the mounting holes.
5) Connect the video and power cables to the camera assembly.
6) Mount the camera assembly to the vehicle surface using two fasteners screwed into panel nuts.
See Figure 7 or 8 (depending on the type of camera assembly being installed).
Figure 7. Angled flush-mount housing installation Figure 8. Square flush-mount housing installation
7) Refer to section 2.4.3 Adjusting Cameras for Functional Field of View to align the camera’s field of view according to the appropriate angle.
8) Attach the cover plate to the housing. If you are installing a square housing, you must drill two additional mounting holes for the cover plate. See Figure 9 or 10.
0150-0263A / May 2003 11
Hardware Installation BusSecure User Manual
Figure 9. Angled flush-mount housing cover Figure 10. Square flush-mount housing cover
2.4.3 ADJUSTING CAMERAS FOR FUNCTIONAL FIELD OF VIEW
Depending on location, the camera’s position might have to be adjusted to provide the best field of view. Adjusting the camera positioning might include altering the position of the camera and, for surface-mount cameras, using a spacer.
To adjust the angle of the camera, see Figure 11 and perform the following:
1) Loosen the camera’s pivot screws.
2) Rotate the camera to the correct
angle.
3) Retighten the pivot screws.
Surface-mount cameras are configured at the factory to be installed onto the ceiling of the vehicle. If you are installing a surface-mount camera on the side of the vehicle, see Figure 12 and perform the following to rotate the camera lens:
Figure 11. Adjusting the camera angle
CAUTION
Over-tightening the set and pivot screws can damage the camera’s lens.
1) Loosen the setscrew on the top of the camera assembly.
2) Rotate the camera assembly 90°.
3) Retighten the setscrew.
Figure 12. Rotating the camera
12 0150-0263A / May 2003
