GE GHD1106, GSD1005, GSD1103, GSD2422, GSD2432 User Manual

...

GE Appliances

Dishwashers

165D4700P222 49-5896

9-00 JR

GHD1106 GSD1005 GSD1103 GSD2422 GSD2432 GSDL112 GSDL622 GSDL632

Owner’s Manual

www.GEAppliances.com

Congratulations! You Are Now Part of the GE Family.

Welcome to the GE family. We’re proud of our quality products and we are committed to providing dependable service. You’ll see it in this easy-to-use Owner’s Manual and you’ll hear it in the friendly voices of our customer service department.

Best of all, you’ll experience these values each time you use your dishwasher. That’s important, because your new dishwasher will be part of your family for many years. And we hope you will be part of ours for a long time to come.

We thank you for buying GE. We appreciate your purchase, and hope you will continue to rely on us whenever you need quality appliances for your home.

Important!

Fill out and return the Consumer Product Ownership Registration card that is packed with this product. If you cannot find it, please send in the duplicate card printed in the back of this manual.

Write the model and serial numbers here.

You can find them on the tub wall just inside the door.

Staple sales slip or cancelled check here.

Proof of the original purchase date is needed to obtain service under the warranty.

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

GE & You, A Service Partnership.

Inside you will find many helpful hints on how to use and maintain your dishwasher properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your dishwasher.

Read this Manual

Ask any GE appliance owner and they will tell you we stand behind our products with unmatched quality service. However, did you know that most questions result from simple problems that you can easily fix yourself in just a few minutes? This Owner’s Manual can tell you how.

You’ll find many answers to common problems here. If you review our chart of Troubleshooting Tips first, you may not need to call for service at all.

Review the Section on Troubleshooting Tips

If you do need service, you can relax knowing help is only a phone call away. A list of toll-free customer service numbers is included in the back section.

Visit our Website at

www.GEAppliances.com

If You Need Service

Safety Information . . . . . . .4–7

Operating Instructions

Control Panels . . . . . . . . . . . .8, 9

Control Settings . . . . . . . . . . . . .9

Dial Cycles . . . . . . . . . . . . .10, 11

Using the Dishwasher . . . .12, 13

Loading the

Dishwasher Racks . . . . . . .14, 15

Care and Cleaning . . . . . . . . . .16

Optional Accessories . . . .17, 18

Troubleshooting Tips

Before You

Call For Service . . . . . . . . .19–24

Customer Service

Product Registration . . . . .25, 26

Warranty . . . . . . . . . . . . . . . .27

Service Telephone

Numbers . . . . . . . . . .Back Cover

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

For your safety, the information in this manual must be followed to minimize the risk of fire, explosion, electric shock, or to prevent property damage, personal injury, or loss of life.

Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE.

If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by turning on all hot water faucets and allow them to run for several minutes. Do this before using any electrical appliance which is connected to the hot water system. This simple procedure will allow any built-up hydrogen gas to escape. Since the gas is flammable, do not smoke or use an open flame or appliance during this process.

WATER HEATER SAFETY

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

Use your dishwasher only for its intended purpose as described in this Owner’s Manual.

This dishwasher must be properly installed and located in accordance with the Installation Instructions before it is used. If you did not receive an Installation Instructions sheet with your dishwasher, you can receive one by calling us toll-free at the GE Answer Center

, 800.626.2000.

■ Connect to a grounded

metal, permanent wiring system; or run an equipmentgrounding conductor with the circuit conductors and connect to the equipmentgrounding terminal or lead of the appliance.

■ Improper connection of

the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service representative if you are in doubt whether the appliance is properly grounded.

■ Dispose of discarded

appliances and shipping or packing material properly.

■ Do not attempt to repair

or replace any part of your dishwasher unless it is specifically recommended in this manual. All other servicing should be referred to a qualified technician.

■ To minimize the possibility

of electric shock, disconnect this appliance from the power supply before attempting any maintenance.

NOTE:

Turning the dishwasher off does not disconnect the appliance from the power supply. We recommend having a qualified technician service your appliance.

PROPER INSTALLATION AND MAINTENANCE

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING.

DO NOT…

■ Do not tamper with controls.

■ Do not abuse, sit on, or stand

on the door or dish rack of the dishwasher.

■ Do not discard a dishwasher

without first removing the door of the washing compartment.

■ Do not store or use

combustible materials, gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

■ Do not allow children to

play inside, on or with this appliance or any discarded appliance.

WARNING!

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

WHEN USING YOUR DISHWASHER

■ Use only powder, tabs or

liquid detergents or wetting agents recommended for use in a dishwasher and keep them out of the reach of children. Cascade® Automatic Dishwashing Detergent has been approved for use in all GE dishwashers.

■ Locate sharp items so that

they are not likely to damage the door seal.

■ Load sharp knives with the

handles up to reduce the risk of cut-type injuries.

■ Do not wash plastic items

unless marked

dishwasher

safe

or the equivalent. For plastic items not so marked, check the manufacturer’s recommendations.

■ Non-Dishware Items: Do not

wash items such as electronic air cleaner filters, furnace filters and paint brushes in your dishwasher. Damage to dishwasher and discoloration or staining of dishwasher may result.

■ Do not touch the heating

element during or immediately after use.

■ Do not operate your

dishwasher unless all enclosure panels are properly in place.

■ Close supervision is necessary

if this appliance is used by or near children.

■ Load light plastic items

so they will not become dislodged and drop to the bottom of the dishwasher— they might come into contact with the heating element and be damaged.

READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.

SAVE THESE INSTRUCTIONS

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

About the dishwasher control panel.

You can locate your model number on the tub wall just inside the door.

Throughout this manual, features and appearance may vary from your model.

GSDL112

GHD1106, GSD1005 and GSD1103

START

RINSE ONLY

DRYING

(HEATED DRY OFF)

OFF

HEATED

DRY

NORMAL WASH

HEAVY WASH

SHORT WASH

RINSE ONLY

PLATE WARMER

(HEATED DRY OFF)

(HEATED DRY ON)

OFF

HEATED

DRY

GSD2422 and GSD2432

START

RINSE ONLY

DRYING

(HEATED DRY OFF)

OFF

HEATED

DRY

HI TEMP WASH

ON OFF

GSDL622 and GSDL632

HEAVY WASH

CYCLES

NORMAL

WASH

HI TEMP WASH

ON OFF

OFF

HEATED

DRY

ENERGY OPTIONS

RINSE ONLY

PLATE WARMER

SHORT WASH

(HEATED DRY OFF)

(HEATED DRY ON)

START

OFF

Energy Options

HI TEMP Provides extra heat for the best performance. It is used best with

WASH heavily-soiled dishes.

HEATED DRY Turns the drying heater on for fast drying. This cycle will extend the time

ON to your wash cycle. Available on all wash cycles except

RINSE ONLY

. Adds

approximately 31 minutes to the cycle.

HEATED DRY Shuts off the drying heat options. Dishes air dry naturally and energy is saved.

OFF

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

Control Settings–

Make sure the Dial is at the OFF position

Cycles

HEAVY WASH

9.5 gal., 62 min. Rinse Rinse Rinse Main Wash Rinse Rinse Rinse

For heavily soiled dishes or cookware with dried-on or baked-on soils. Everyday dishes may be included. This cycle will not remove burned-on foods.

NORMAL WASH

8.0 gal., 62 min. Rinse Rinse Main Wash Rinse Rinse Rinse

For loads of everyday dishes, glasses and cookware with medium soils.

NOTE:

Many dishes have lighter soil than normal. Choosing a cycle other

than

NORMAL WASH

will save energy and water.

SHORT WASH

6.6 gal., 52 min. Rinse Main Wash Rinse Rinse Rinse

For quickly washing loads of everyday dishes with medium soils that have not dried on, such as loads consisting mostly of glasses.

RINSE ONLY

3.9 gal, 12 min. Rinse Rinse Rinse

For rinsing partial loads that will be washed later.

Do not use detergent.

PLATE WARMER For warming clean dishes and serving plates. This cycle will take

approximately 31 minutes.

Start

On some models—

Latch the door and slowly turn the Dial to the

START

position.

Don’t turn it past the

START

position, or you could accidentally miss a rinse.

On some models—

Slowly turn Dial to the desired cycle and latch door to start.

Don’t turn it past the desired wash cycle, or you could accidentally miss a rinse.

There is a time delay between start-up and water fill so you will not hear any wash action right away.
