GFDS170EH/175EH
GE® Series 7.5 Cu. Ft. Capacity Front Load Electric Dryer with Steam and Stainless Steel Drum
Specif ication Revis ed 10/15
For answers to your Mon ogram, GE Prof ile™ Series
or GE® Series appliance que stions, vi sit our website
at geapplian ces.com or cal l GE Answer Center®
service, 800.626.2000.
Dimensions anD installation information (in inches)
exhaust options: 4-way via rear, right,
left and bottom.
circuit requirements: An individual,
properly grounded branch circuit, protected by
a 30-amp circuit breaker or a time-delay fuse,
is required.
note: Dryer wall outlet must be located within 36"
of service cord entry and accessible when dryer is
mounted in position.
instal l ati o n i n f o r m ation : For complete
information, see installation instructions packed
with your dryer.
27
33
39-3/8
4-3/8
5-3/8
electric Dryer rating
120V/240V 5600W, 24A, 60Hz
120V/208V 4400W, 22A, 60Hz
Listed by
Underwriters
Laboratories
GFDS170EH/175EH
GE® Series 7.5 Cu. Ft. Capacity Front Load Electric Dryer with Steam and Stainless Steel Drum
Specif ication Revis ed 10/15
For answers to your Mon ogram, GE Prof ile™ Series
or GE® Series appliance que stions, vi sit our website
at geapplian ces.com or cal l GE Answer Center®
service, 800.626.2000.
3-1/2
24-7/8
50-5/8
39-3/8
3
special installation requirements:
sta cke D in stallation:
Brackets for stacking dryer over washer are not included with
the dryer. Order part no. GEFLSTACK or part no. WE25X10018.
alcove or closet installation:
If your dryer is approved for installation in an alcove or closet, it will be
stated on a label on the dryer back.
The dryer MUST be exhausted to the outside.
Minimum clearances between dryer cabinet and adjacent walls or other
surfaces are: 0" either side, 3" front and rear.
Minimum vertical space from floor to overhead cabinets, ceilings, etc. is 52".
Closet doors must be louvered or otherwise ventilated and must contain a
minimum of 60 sq. in. of open area equally distributed. If this closet contains
both a washer and a dryer, doors must contain a minimum of 120 sq. in. of
open area equally distributed.
No other fuel-burning appliance shall be installed in the same closet with
a gas dryer.
Bathroom or BeDroom installation:
The dryer MUST be exhausted to the outdoors.
The installation must conform with the local codes, or in the absence of
local codes, with the National Electric Code and National Fuel Gas Code,
ANSI Z223 for gas dryers.
minimum clearance other than alcove or closet
instal l ati o n s :
Minimum clearances to combustible surfaces 0" both sides, 3" rear.
for more information on venting kits anD accessories,
please call 1-800-ge-cares.
Listed by
Underwriters
Laboratories
stackeD Dimensions
(in inches)
27
13
28-3/4
peDestal Dimensions
(in inches)
sBsD137hWW - White
This optional 13" pedestal raises
the door opening and height of
the washer or dryer. Feet on 13"
pedestal allow it to adjust to
13-3/8" height.
