ge.com
Chest—Manual
Defrost Models:
FCM5
FCM7
FCM9
Owner’s Manual &
Installation Instructions
Food Freezers
197D3355P005 49-60518 05-07 JR
Safety Information
How to Connect Electricity . . . . . . 4
Proper Disposal . . . . . . . . . . . . . . . .3
Safety Precautions . . . . . . . . . . . . . 2
Use of Extension Cords . . . . . . . . . 3
Operating Instructions
Care and Cleaning . . . . . . . . . . . .8, 9
Defrosting Instructions . . . . . . . . . .7
Features . . . . . . . . . . . . . . . . . . . .5, 6
Starting the Freezer . . . . . . . . . . . . .5
Installation Instructions
Preparing to Install the Freezer . . 10
Troubleshooting Tips
Before You Call For Service . . .11, 12
Normal Operating
Characteristics . . . . . . . . . . . . . . . .11
Consumer Support
Consumer Support . . . . . Back Cover
Production Registration . . . . . 13, 14
Warranty . . . . . . . . . . . . . . . . . . . . 15
Write the model and serial numbers here:
Model # __________________________
Serial # __________________________
You can find them on a plate on the
top-center on the back of the unit.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
Use this appliance only for its intended purpose as described in this Owner’s Manual.
SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
■
■ This freezer must be properly installed and
located in accordance with the Installation
Instructions before it is used.
■
■ Do not allow children to climb, stand or hang
on the shelves in the freezer. They could damage
the freezer and seriously injure themselves.
■
■ After your freezer is in operation, do not touch
the cold surfaces, particularly when hands are
damp or wet. Skin may stick to these extremely
cold surfaces.
■
■ Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
■
■ Unplug the freezer before cleaning, making
repairs or changing the light bulb.
NOTE: We strongly recommend that any servicing be
performed by a qualified individual.
■
■ Turning the control to the OFF position does
not remove power to the light circuit on models
with interior light.
■
■ Do not refreeze frozen foods which have
thawed completely.
■
■ The maximum amount of food your freezer is
designed to freeze at one time is approximately
3 pounds (1.5 kg) per cubic foot of freezer
capacity. In normal position, your freezer’s
temperature control will maintain sufficiently
low temperatures in the freezer to freeze
recommended quantities of food.
■
■ Caution should be used when removing the door
of a freezer. Particular caution should be used
when removing the lid of a Chest freezer, as most
Chest freezer lids are under spring tension.
Contact the manufacturer’s representative for
a method of safe removal.
Consumer Support
Troubleshooting Tips
Operating Instructions Safety InstructionsInstallation Instructions
2
3
Consumer Support
Troubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
USE OF EXTENSION CORDS
Because of potential safety hazards under certain conditions, we strongly recommend against
the use of an extension cord.
However, if you must use an extension cord, it is absolutely necessary that it be a UL-listed (in the United
States) or a CSA-listed (in Canada), 3-wire grounding type appliance extension cord having a grounding
type plug and outlet and that the electrical rating of the cord be 15 amperes (minimum) and 120 volts.
ge.com
DANGER! RISK OF CHILD ENTRAPMENT
PROPER DISPOSAL OF THE FREEZER
When using electrical appliances, basic safety precautions should be followed, including the following:
Child entrapment and suffocation are not
problems of the past. Junked or abandoned
refrigerators and freezers are still dangerous…even
if they will sit for “just a few days.” If you are getting
rid of your old refrigerator or freezer, please follow
the instructions below to help prevent accidents.
Before You Throw Away Your Old
Refrigerator or Freezer:
■ Take off the doors.
■ Leave the shelves in place so that children may
not easily climb inside.
Refrigerants
All refrigeration products contain refrigerants,
which under federal law must be removed prior to
product disposal. If you are getting rid of an old
refrigeration product, check with the company
handling the disposal about what to do.
4
Consumer Support
Troubleshooting Tips
Installation Instructions Safety InstructionsOperating Instructions
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
For personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall outlet
to minimize the possibility of electric shock
hazard from this appliance.
Have the wall outlet and circuit checked by a
qualified electrician to make sure the outlet is
properly grounded.
If the outlet is a standard 2-prong wall outlet, it
is your personal responsibility and obligation to
have it replaced with a properly grounded 3-prong
wall outlet.
The freezer should always be plugged into its own
individual electrical outlet which has a voltage
rating that matches the rating plate.
This provides the best performance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
Never unplug your freezer by pulling on the power
cord. Always grip plug firmly and pull straight out
from the outlet.
Repair or replace immediately all power cords that
have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage
along its length or at either end.
When moving the freezer away from the wall, be
careful not to roll over or damage the power cord.
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
Consumer Support
Troubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
About the operation of your freezer.
ge.com
Starting the Freezer
Clean the inside of the freezer with a mild solution of baking soda and water (see Care and Cleaning).
Connect cord to power outlet.
On models with a Temperature Monitor or High-Temp Alarm Switch, set the switch to the OFF position.
Make sure the temperature control is set at 4.
Allow freezer to operate for at least four hours before placing food inside.
On models with a Temperature Monitor or High-Temp Alarm Switch, set the switch to the ON position.
6
5
4
3
2
1
5
Temperature Control
Freezing temperature selection is made by
setting the control from 1 to 7 (coldest).
If you want colder or warmer temperatures,
adjust the control one step at a time.
Allow several hours after each one-step
adjustment for the freezer temperature
to stabilize.
Turning the control to the OFF position
stops the cooling process but does not
shut off power to the freezer.
Consumer Support
Troubleshooting Tips
Installation Instructions Safety InstructionsOperating Instructions
About the operation of your freezer.
6
Key-Ejecting Lock (on some models)
The key for the spring-loaded lock is
automatically ejected—key will not
remain in lock in either the open or
closed position.
Keep the key out of reach of children and away from
the freezer.
Power-On Light (on some models)
The Power-On Light indicates that the
freezer is properly connected to the
electrical power.
The light glows even when the temperature
control is turned off.
Consumer Support
Troubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
In most climates, defrosting will be
necessary only about twice a year.
To have your freezer operate most efficiently,
do not permit more than 1/2 ″ (13 mm) of
frost to accumulate on the shelves.
To remove frost, scrape with a plastic or
wood spatula or scraper.
Do not use an ice pick or sharp-edged
instrument as it may damage or scratch the freezer.
Do not use any electrical device in defrosting
your freezer.
For Complete Defrosting
Turn the temperature control to the
OFF position and unplug the freezer.
Remove all food and place it in
corrugated boxes, insulated bags,
picnic coolers, etc. Use towels and
newspapers for insulation as needed.
With the door/lid open, use pans of
hot water to speed loosening of frost.
Remove large pieces before they melt.
Chest models have a defrost water drain
at the front.
NOTE: Water may drip from the back flange of
the lid cover during defrosting. This is normal.
Ice builds up in the lid insulation when the lid is
open for adding or removing food, and melts
during the defrosting operation.
Sponge excess water from the bottom
of the freezer as it collects to prevent
overflowing.
After defrosting, clean the inside of the
freezer (see Care and Cleaning).
Replace the drain plug inside the
cabinet and the cap on the defrost
drain. Fold over and dry the gasket
on the hinge side of the lid.
Plug in the freezer. Return the
temperature control to its previous
position and return food to the freezer.
7
6
5
4
3
2
1
7
Defrosting instructions. ge.com
Consumer Support
Troubleshooting Tips
Installation Instructions Safety InstructionsOperating Instructions
Care and cleaning of the freezer.
Cleaning Your Freezer
■ Outside. Protect the paint finish. The
finish on the outside of the freezer is
a high quality, baked-on paint finish.
With proper care, it will stay new-looking
and rust-free for years. Apply a coat of
appliance polish wax when the freezer
is new and then at least twice a year.
Appliance polish wax also works well
to remove tape residue from freezer
surfaces.
Keep the finish clean. Wipe with a clean
cloth lightly dampened with appliance
polish wax or mild liquid dishwashing
detergent. Dry and polish with a clean,
soft cloth. Do not wipe the freezer with
a soiled dishwashing cloth or wet towel.
Do not use scouring pads, powdered
cleaners, bleach or cleaners containing
bleach.
CAUTION: Care should be taken in moving the
freezer away from the wall. All types of floor
coverings can be damaged, particularly cushioned
coverings and those with embossed surfaces.
■ Inside. Clean the inside of your freezer at
least once a year. We recommend that the
freezer be unplugged before cleaning. If
this is not practical, wring excess moisture
out of sponge or cloth when cleaning in
the vicinity of switches, lights or controls.
Use warm water and baking soda
solution—about a tablespoon of baking
soda to a quart of water. Rinse thoroughly
with water and wipe dry. Do not use
cleaning powders or other abrasive
cleaners.
An open box of baking soda in the
freezer will absorb stale freezer odors.
Change the box every three months.
8
Consumer Support
Troubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
9
ge.com
Preparing for Vacation
To maintain freezer in operation during
vacations, be sure your house power is not
turned off. For sure protection of freezer
contents, you may want to ask a neighbor
to check the power supply and freezer
operation every 48 hours.
For extended vacations or absences, you
may prefer to move your frozen foods to a
storage locker temporarily. If your freezer is
to be left empty, disconnect power cord
plug from wall outlet. To prevent formation
of odors, place open box of baking soda in
freezer and leave freezer door/lid open.
When the freezer is not operating, it can be
left in an unheated house or room without
damage to cabinet or mechanism.
Preparing to Move
Disconnect the power cord plug from
the wall outlet. Remove foods, defrost
and clean the freezer.
Secure all loose items such as grille and
shelves by taping them securely in place
to prevent damage.
Be sure freezer stays in upright position
during actual moving and in van. The
freezer must be secured in van to prevent
movement. Protect outside of freezer with
blanket.
In Case of Extended Power Failure
■ Keep freezer door/lid closed. Your
freezer will keep food frozen for 24 hours
provided warm air is not admitted.
■ If freezer is out of operation for 24 hours
or more, add dry ice. Leave ice in large
pieces. Add more ice as required.
WARNING: Handling of dry ice can cause freezing
of the hands—gloves or other protection is
recommended.
■ If dry ice is not available, move food to
a frozen food locker temporarily—until
power is restored.
Consumer Support
Troubleshooting Tips
Installation Instructions Safety InstructionsOperating Instructions
Preparing to install the freezer.
Read these instructions completely and carefully.
Freezer Location
Your freezer should be conveniently located for
day-to-day use in a dry, well-ventilated room.
Do not install the freezer where the temperature
will go below 0°F or above 110°F, because it will
not maintain proper temperatures.
Be sure to install your freezer on a floor strong
enough to support it when it is fully loaded.
The freezer must be solidly positioned on the floor
if it is to function at its best. Shims may be used to
accomplish this wherever the floor is too uneven.
If the place selected for the freezer is damp or
moist, place 2 X 4’s (51 mm X 102 mm) under its
entire length to assure adequate support.
Clearances
On all models, allow 3″ (76 mm) on top, back
and sides for proper air circulation.
10
Consumer Support
Troubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
11
Normal operating characteristics. ge.com
These things are normal and
do not indicate a need for service.
■ A warm cabinet exterior as the refrigeration system transfers heat from the inside to the outside through
the exterior cabinet walls.
■ The sound of the high-efficiency compressor motor.
Before you call for service…
Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.
Problem Possible Causes What To Do
Freezer does not Temperature control • Move the control to a temperature setting.
operate or Power-On in OFF position.
Light is not on
Freezer is unplugged. • Push the plug completely into the outlet.
The fuse is blown/circuit • Replace fuse or reset the breaker.
breaker is tripped.
Freezer starts/stops Door/lid left open. • Check to see if package is holding door/lid open.
too frequently
Too frequent or too long
door/lid openings.
Temperature control • See About the operation of your freezer.
set too cold.
Freezer operates Door/lid left open. • Check to see if package is holding door/lid open.
too long
Too frequent or too long
door/lid openings.
Temperature control • See About the operation of your freezer.
set too cold.
Inadequate air circulation •See Preparing to install the freezer.
space around cabinet.
Fast Freeze switch is in the • See About the operation of your freezer.
ON position (on some models)
Noisy operation Floor may be weak, causing • Placing 2 X 4’s (51 mm X 102 mm) under the length of
or cabinet vibrates freezer to vibrate when the freezer will help support it and may reduce vibration.
compressor is on.
Cabinet is not positioned •See Preparing to install the freezer. Or use shims for
solidly on floor. uneven floor.
Freezer temperature Door/lid left open. • Check to see if package is holding door/lid open.
too warm
Too frequent or too long
door/lid openings.
Consumer Support
Troubleshooting Tips
Installation Instructions Safety InstructionsOperating Instructions
Before you call for service…
12
Problem Possible Causes What To Do
Foods defrosting Temperature control • Move the control to a temperature setting.
in OFF position.
Freezer is unplugged. • Push the plug completely into the outlet.
The fuse is blown/circuit • Replace fuse or reset the breaker.
breaker is tripped.
Door/lid left open. • Check to see if package is holding door/lid open.
Too frequent or too long
door/lid openings.
Freezer temperature Temperature control • See About the operation of your freezer.
too cold set too cold.
Fast Freeze switch is in the • See About the operation of your freezer.
ON position or has run for too
long (on some models)
Moisture forms on Not unusual during • Wipe surface dry.
outside of cabinet periods of high humidity.
Interior light does No power at outlet. • Replace fuse or reset the breaker.
not work
Freezer is unplugged. • Push the plug completely into the outlet.
(on some models)
Light bulb burned out. • Replace bulb.
Door/lid won’t fully Package holding door/lid open.
close by itself
Slow starting time Built-in overload protection.
after being off
Excessive frost Door/lid left open. • Check to see if package is holding door/lid open.
buildup
Too frequent or too long
door/lid openings.
Not unusual during
periods of high humidity.
NOTE: Do not return the freezer to the store where you purchased it. The freezer is eligible for in-home service. For warranty service,
contact us at ge.com, or call 800.GE.CARES (U.S.), or 1.800.561.3344 (Canada).
General Electric Company
Warranty Registration Department
P.O. Box 32150
Louisville, KY 40232-2150
GE Service Protection Plus
™
GE, a name recognized worldwide for quality and dependability, offers you
Service Protection Plus
™
—comprehensive protection on all your appliances—
No Matter What Brand!
Benefits Include:
• Backed by GE
• All brands covered
• Unlimited service calls
• All parts and labor costs included
• No out-of-pocket expenses
• No hidden deductibles
• One 800 number to call
You will be completely satisfied with our service protection or you may request your money back
on the remaining value of your contract. No questions asked. It’s that simple.
Protect your refrigerator, dishwasher, washer and dryer, range, TV, VCR and much more—any brand!
Plus there’s no extra charge for emergency service and low monthly financing is available. Even icemaker
coverage and food spoilage protection is offered. You can rest easy, knowing that all your valuable
household products are protected against expensive repairs.
Place your confidence in GE and call us in the U.S. toll-free at 800.626.2224
for more information.
*All brands covered, up to 20 years old, in the continental U.S.
We’ll Cover Any Appliance.
Anywhere. Anytime.*
Please place in envelope and mail to:
✁
Cut here
13
Consumer Product Ownership Registration
Im
p
o
rta
n
t
M
a
il
T
o
d
a
y!
First
Name
Mr. ■■ Ms. ■■ Mrs. ■■ Miss ■■
Street
Address
City
State
Date Placed
In Use
Month
Day
Year
Zip
Code
Apt. #
Last
Name
Phone
Number
_
_
Consumer Product Ownership Registration
Dear Customer:
Thank you for purchasing our product and thank you for placing your confidence in us.
We are proud to have you as a customer!
Follow these three steps to protect your new appliance investment:
Important: If you did not get a registration card with your
product, detach and return the form below to
ensure that your product is registered, or register
online at ge.com.
1
23
Model Number Serial Number
✁
Cut here
Complete and mail
your Consumer
Product Ownership
Registration today.
Have the peace of
mind of knowing we
can contact you in
the unlikely event of
a
safety modification.
After mailing the
registration below,
store this document
in a safe place. It
contains information
you will need should
you require service.
Our service number is
800 GE CARES
(800.432.2737).
Read your Owner’s
Manual carefully.
It will help you
operate your new
appliance properly.
Model Number Serial Number
E-mail Address
14
* Please provide your e-mail address to receive, via e-mail, discounts, special offers and other important
communications from GE Appliances (GEA).
■■ Check here if you do not want to receive communications from GEA’s carefully selected partners.
FAILURE TO COMPLETE AND RETURN THIS CARD DOES NOT DIMINISH YOUR
WARRANTY RIGHTS.
For information about GEA’s privacy and data usage policy, go to ge.com and click on “Privacy
Policy” or call 800.626.2224.
GE Consumer & Industrial
Appliances
General Electric Company
Louisville, KY 40225
ge.com
Consumer Support
Troubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
15
Freezer Warranty.
■ Service trips to your home to teach you how to use
the product.
■ Improper installation, delivery or maintenance.
■ Failure of the product if it is abused, misused, or used for
other than the intended purpose or used commercially.
■ Loss of food due to spoilage.
■ Damage caused after delivery.
■ Replacement of house fuses or resetting of circuit
breakers.
■ Damage to the product caused by accident, fire, floods
or acts of God.
■ Incidental or consequential damage caused by possible
defects with this appliance.
■ Product not accessible to provide required service.
What GE Will Not Cover:
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home
use within the USA and Canada. If the product is located in an area where service by a GE Authorized Servicer
is not available, you may be responsible for a trip charge or you may be required to bring the product to an
Authorized GE Service location for service. In Alaska, the warranty excludes the cost of shipping or service
calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives
you specific legal rights, and you may also have other rights which vary from state to state. To know what your
legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
Mabe Canada Inc., Suite 310, 1 Factory Lane, Moncton, N.B. E1C 9M3
For The Period Of: GE Will Replace:
One Year Any part of the freezer which fails due to a defect in materials or workmanship. During this
From the date of the limited one-year warranty, GE will also provide, free of charge, all labor and related service to
original purchase replace the defective part.
All warranty service provided by our Factory Service Centers,
or an authorized Customer Care
®
technician. To schedule service,
on-line, 24 hours a day, contact us at ge.com, or call 800.GE.CARES
(U.S.), 1.800.561.3344 (Canada). Please have serial number and
model number available when calling for service.
Staple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.
EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclusive remedy is product repair as provided in this
Limited Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a
particular purpose, are limited to one year or the shortest period allowed by law.
Consumer Support.
GE Appliances Website
ge.com
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day,
any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals,
order parts or even schedule service on-line. In Canada: www.geappliances.ca
Schedule Service ge.com
Expert GE repair service is only one step away from your door. Get on-line and schedule your service at
your convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal
business hours. In Canada, call 1.800.561.3344
Real Life Design Studio ge.com
GE supports the Universal Design concept—products, services and environments that can be used by
people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and
mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen
design ideas for people with disabilities, check out our Website today. For the hearing impaired, please call
800.TDD.GEAC (800.833.4322).
In Canada, contact: Manager, Consumer Relations, Mabe Canada Inc.
Suite 310, 1 Factory Lane
Moncton, N.B. E1C 9M3
Extended Warranties ge.com
Purchase a GE extended warranty and learn about special discounts that are available while your warranty
is still in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours.
GE Consumer Home Services will still be there after your warranty expires. In Canada, call 1.888.261.2133
Parts and Accessories ge.com
Individuals qualified to service their own appliances can have parts or accessories sent directly to their
homes (VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or
by phone at 800.626.2002 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally
should be referred to qualified service personnel. Caution must be exercised, since improper servicing may cause
unsafe operation.
Customers in Canada should consult the yellow pages for the nearest Mabe service center, or call 1.800.661.1616.
Contact Us ge.com
If you are not satisfied with the service you receive from GE, contact us on our Website with all the details
including your phone number, or write to: General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
In Canada, www.geappliances.ca, or write to: Director, Consumer Relations, Mabe Canada Inc.
Suite 310, 1 Factory Lane
Moncton, N.B. E1C 9M3
Register Your Appliance ge.com
Register your new appliance on-line—at your convenience! Timely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise. You may also
mail in the pre-printed registration card included in the packing material. In Canada: www.geappliances.ca
Printed in China
Loading...
