Decorative Post Top Lighting
GE Edison™ V (EDVX & EDVF)
imagination at work
Product Features
GE offers a variety of decorative Post Top and Pendant Mount Lighting solutions that range from the nostalgic looks
of yesterday to the sleek, modern designs of today, providing style and elegance to downtown areas, commercial
developments, parks and residential communities.
Applications
• Residential roadways and walkways
• Shopping centers, malls and plazas
Housing
• Ornamental heavy gauge die cast aluminum base
Finish
• Powder coat paint available in 188 RAL colors
Rating
• Suitable for Wet Locations
Unique Features
• GE designed and built ballast with proven long life
and reliability
• Terminal Board standard for simplified wiring
• Twist Lock photoelectric receptacle available
• Crowns, ribs and finials available
• E39 Mogul base socket standard where lamp is
available in mogul base (E26 Medium base socket
otherwise)
• Luminaire shipped as components: Base, Optical
• Removable aluminum ballast canister with key slots
and electrical disconnect which provides easy access
to the ballast, capacitor and plug-in ignitor
• Easily removable door for access to terminal board
and PE receptacle
• Accepts 8” globes
Ordering Number Logic
GE Edison™ V (EDVX & EDVF)
_ _ _ _ - _ _ - _ - _ - _ - _ - _ _ _ - _ - _ _ _ _
PROD. ID
EDVX= 8”
Edison
Luminaire
EDVF = 8”
Edison
Luminaire
Finial Ready*
*Order Finial
Separately
WATTAGE
05 = 50
07 = 70
10 = 100
15 = 150
(55V)
LIGHT
SOURCE
S = HPS
P = PMH
Standard: Lamp
not included.
VOLTAGE
60Hz
0 = 120/208/
240/277
Multivolt
1 = 120
5 = 480
D = 347
F = 120X347
BALLAST TYPE
SELECTION
See Ballast and
Photometric
Selection Table
A = Autoreg
H = HPF Reactor
or Lag
N = NPF Reactor
or Lag
PE
FUNCTION
1 = None
2 = PE
Receptacle
GLOBE
TYPE**
1AC = Traditional Prismatic
(Polycarbonate &
Acrylic) 1BC =
Colonial Prismatic
(Polycarbonate & Acrylic)
1CB = Traditional Standard
(Polycarbonate)
1DA = Colony (Acrylic with
spun aluminum top)
1KD = 18” Impression (White
Polycarbonate)
1PB = Revival (Polycarbonate)
1MA = Colony with crown and
ribs installed
(Acrylic with spun
aluminum top)
Ballast Selection Table
All light sources are clear unless otherwise indicated.
Light 347,
Wattage Source 120 120X347** Multivolt 480 120X240
50 HPS H, N H, N H, N N/A N/A
70 HPS A, H, N H, N H, N H, N N/A
100 HPS A, H, N H, N H, N H, N N/A
150(55V) HPS A, H, N H, N H, N H, N N/A
70 PMH H, N H, N H, N H, N N/A
100 PMH H, N H, N N H, N N/A
150 PMH H, A H N/A N/A A , H
NOTE: N/A = Not Available
Ballast Type/Voltage
60Hz
IES DISTRIBUTION
TYPE
See Ballast
and Photometric
Selection Tables
A = Asymmetric
S = Symmetric
COLOR
ALUM = Aluminum
BLCK = Black
BRWN = Brown
CHGR = Charcoal
Gray
DKBZ = Dark
Bronze
FGRN = Forest
Green
GRAY = Gray
WHTE = White
Photometric Selection Table
Light
Wattage Source LNA MN2 MN3 MN4 MS2 MS5 SN1 XN5 XS5
178232
452154
452210
452023 452226
50 HPS 452182 452337 451369 - - 452325 - 452240 452288
452155
452211
452227
452024 452241
70 HPS 452183 452338 – - 451370 452326 - 452351 452289
452156
452212
452228
452025 452339 452242
100 HPS 452184 454263 451365 - - 452327 - 452352 452290
452157
452213
452229
452243
150 HPS 452185 452340 – 452026 - 452328 - 452353 452291
452150
452206
452222
50 PMH 452178 – – - - – - 452236 –
452151
452207
452223
70 PMH 452179 – – - - – - 452237 452284
452152
452208
452224
452180 452238
100 PMH 452370 – – - 451440 – 454176 452349 452285
IES Distribution
Type
Product Dimensions
TRADITIONAL
STANDARD 1CB
Asymmetrical
and Symmetric
Distribution
available
35.5 in.
(900 mm)
*3.5 in. (92 mm) MAX DIA POLE OD
*2.7 in. (69 mm) MIN DIA POLE OD
COLONY 1DA, 1MA
Asymmetrical
and Symmetric
Distribution
available
13.0 in.
(330 mm)
3.0 in. (76 mm)
15.0 in.
(380 mm)
16.0 in.
(400 mm)
TRADITIONAL
PRISMATIC 1AC
Asymmetrical
and Symmetric
Distribution
available
REVIVAL 1PB
Symmetric
Distribution only
39.0 in.
(990 mm)
35.5 in.
(900 mm)
13.0 in.
(330 mm)
16.0 in.
(400 mm)
15.5 in.
(400 mm)
COLONIAL
PRISMATIC 1BC
Asymmetrical
and Symmetric
Distribution
available
IMPRESSION 1KD
(18”) Symmetric
Distribution
only
33.0 in.
(840 mm)
30.0 in.
(760 mm)
13.0 in.
(330 mm)
15.5 in.
(390 mm)
18.0 in.
(460 mm)
13.0 in.
(330 mm)
13.0 in.
(330 mm)
• Approximate Net Weight: 21-25 lbs (10-11 kgs)
• Suggested Mounting Height: 10-16 ft. (3-5 M)
DATA
• Effective Projected Area: 1.6 sq. ft. max. (0.15 sq. M max.)
13.0 in.
(330 mm)
GE Lighting Solutions • 1-888-MY-GE-LED • www.gelightingsolutions.com
1 - 8 8 8 - 6 9 - 4 3 - 5 3 3
GE Lighting Solutions, LLC is a subsidiary of the General Electric Company. The GE brand and logo are trademarks of the General Electric Company.
© 2012 GE Lighting Solutions, LLC. Information provided is subject to change without notice. All values are design or typical values when measured under laboratory conditions.
OLP-2966 (Rev. 06/19/12)
