GE Druck DPI 610, Druck DPI 615 User Manual

GE

Sensing

Druck DPI 610/615

Portable Pressure Calibrator Series

User manual - K415

Language

To select the manual in an available language go to:

//www.gesensing.com/toolsupport/manuals.htm

Français

Pour choisir le manuel dans une langue disponible allez:

//www.gesensing.com/toolsupport/manuals.htm

Deutche

Um das Handbuch in einer vorhandenen Sprache vorzuwählen gehen Sie:

//www.gesensing.com/toolsupport/manuals.htm

Italiano

Selezionare il manuale in una lingua disponibile vada:

//www.gesensing.com/toolsupport/manuals.htm

Español

A seleccionar el manual en una lengua disponible vaya:

//www.gesensing.com/toolsupport/manuals.htm

Português

Para selecionar o manual em uma língua disponível vá:

//www.gesensing.com/toolsupport/manuals.htm

i K415 Issue No. 1

Safety

The manufacturer has designed this equipment to be safe when operated using the
procedures detailed in this manual. Do not use this equipment for any other purpose
than that stated.
This publication contains operating and safety instructions that must be followed to
ensure safe operation and to maintain the equipment in a safe condition. The safety
instructions are either warnings or cautions issued to protect the user and the equipment
from injury or damage.
Use suitably qualified * technicians and good engineering practice for all procedures in
this publication.

Pressure

Do not apply pressures greater than the safe working pressure to this equipment.

Maintenance

The equipment must be maintained using the procedures in this publication. Further
manufacturer’s procedures should be carried out by authorized service agents or the
manufacturer’s service departments.

www.gesensing.com

For technical advice contact the manufacturer.

* A qualified technician must have the necessary technical knowledge,

documentation, special test equipment and tools to carry out the required work on
this equipment.

Symbols

This equipment meets the requirements of all relevant European safety
directives. The equipment carries the CE mark.

This symbol, on the instrument , indicates that the user should refer to
the user manual. This symbol, in this manual, indicates a hazardous
operation.

This symbol, on the instrument , indicates do not throw-away in
domestic bin, hazardous material, dispose correctly in accordance with
local regulations.

K415 Issue No. 1 ii

Specification

Safe working pressure

20 bar range (300 psi) 1.75 x full-scale
350 bar range (5000 psi) 1.2 x full-scale
400 bar range (6000 psi) 1.5 x full-scale
All other ranges 2 x full-scale

Accuracy

Combined non-linearity, hysteresis and repeatability

±70 mbar range (2 inHg) 0.05% F.S.
up to ±150 mbar (4.4 inHg) 0.05% span
200 mbar to 20 bar (3 psi to 300 psi) [Calibrator]): 0.025% F.S.
35 bar to 700 bar (500 psi to 10000 psi) [Indicator] 0.025% F.S.
70 bar to 400 bar (1000 psi to 6000 psi) [Hydraulic] 0.025% F.S.

Pressure Ranges

Refer to the pressure range matrix in the data sheet.

Temperature Effects

±0.004% of reading/°C (averaged over -10° to +40°C w.r.t. 20°C)
±0.002% of reading/°F (averaged over +14° to 104°F w.r.t. 68°F)

Power supply

Batteries 6 x 1.5 V C cells, alkaline (up to 60 hours nominal use at 20°C)
Rechargeable NiCad battery pack (20 hours nominal use) supplied with charger/
adaptor, supplies power to instrument while charging batteries.

Voltage Inputs

Range: ±50V
Accuracy ±0.05% rdg, ±0.004% F.S.
Resolution 100µV max

Voltage Outputs

Range: ±10V
Accuracy ±0.1%
Load 10mA

Range: ±24V
Accuracy ±5%
Load 26mA

Current Inputs

Range: ±55mA
Accuracy ±0.05% rdg, ±0.004% F.S.
Resolution 1µA max

Current Output

Range: 24mA
Accuracy ±0.05% rdg, ±0.01% F.S.
Resolution 1µA max

iii K415 Issue No. 1

Display

Size: 60 x 60 mm (2.36” x 2.36”) LCD Graphics
Reading ±99999, update rate 2 readings/sec

Environment

Operating Temperature: -10°C to 50°C (+14°F to 122°F)
Calibrated Temperature: -10°C to 40°C (+14°F to 104°F)
Storage Temperature: -20°C to 60°C (-4°F to 140°F)
Calibration Temperature: 21°C ±2°C (70°F ±4°F)

Sealing

Physical

Size: 300 x 170 x 140 mm (11.8” x 6.7” x 5.5”)
Weight: 3 kg (6.6lb)

Specification (contd.)

Sealed to IP54 (NEMA 4)

K415 Issue No. 1 iv

Introduction

General

Description of Procedures 1

Summary of Functions

Using the Guide 2

Getting Started

Fitting Batteries 7
Switching On 7
Change Pressure Units 8
Voltage and Current Measurement 8
Typical Calibration Set-up (Pressure to Voltage) 9
Zero Display Reading 9

OPERATOR CONTROLS 3
DISPLAY 3
HARD KEY FUNCTIONS 4
SOFT KEYS 5
CURSOR KEYS 5
ELECTRICAL CONNECTIONS 6

Task Selection

Task Key 10
Using Task Functions 10
Set Units 10
Set 24 Volts 10
Cal Mode (DPI 615 versions only) 11
Basic Mode (Task BASIC) 11

Taking Measurements

Pressure Transmitter (P-I) Task 12
Voltage Output Pressure Transmitter (P-V) Task 12
Pressure Converter (P-P) Task 13
Current to Pressure Converter (I-P) Task 14
Pressure Switch Test (P-Switch) Task 14
Pressure Switch Testing with Contact Resistance Measurement 15
Pressure to Display (P-Display) Task 16
Leak Test (Leak Test) Task 17
Transmitter Simulator (TX SIM) Task 18
Relief Valve Test (REL VALVE) Task 19

v K415 Issue No. 1

Advanced Task

Electrical Outputs (Loop Power) 25

General 20
Select Input 20
Ambient Temperature Measurement 20
Process Functions 21
Tare Process Function 22
Min/Max Process Function 23
Filter Process Function 23
Flow Function 24
% Span 24
Select Output 25

mA Step 26
mA Ramp 27
mA Value 28
24 Volt 28
Define New Task 29
Clear Task 29

Memory Operations

Saving Display or Data Log 30
Store Operations (Screen Snapshots) 30
Recalling Stored Data (Screen Snapshots) 30
Datalog Operations 31

Using Set-up

General 37
Store Mode 37
Contrast 37
Settings - Select Set-up Option 38

Auto Log (Timer) 31

Manual Logging 31
Recall Data Log Files 32
Uploading Data Log Files 33
Delete Data Log and Procedure Files 33
Downloading Procedure Files (DPI 615 versions only) 34
Running Procedure Files (DPI 615 versions only) 35
Recalling Data Files 36

Units 38

Define Special Units 38

Language 39

RS232 39

Powerdown 40

K415 Issue No. 1 vi

Calibration 40

Date and Time (Real Time Clock) 41

Date Format 41

Set Date 41

Set Time 41

Backlight 42

Calibration

General 43
Calibration Check 43
Calibration Adjustment 43
General Procedures 44
Using The Calibration Menu 45
Change PIN 45
Pressure 46
Voltage Input Range (5 Volts) 47
Voltage Input Range (50 Volts) 49
Current Input Range (55 mA) 51
Current Output Range (24 mA) 53
Temperature 56
External Pressure Range 57
Add External Sensor 58

Hydraulic Calibrator Versions

Introduction 61
Safety Instructions 62
Preparation for Use 62
Bleeding the System 63
Draining the Hydraulic Fluid 64
Flushing, Replenishing or Changing the Hydraulic Fluid 65

Low Pressure Calibrator Versions

Introduction 69
Preparation for Use Low Volume Systems 70
Method of Testing with Low Volume Systems 70
Preparation for Use Larger Volume Systems 72
Method of Testing with Larger Volume Systems 74
Calibration 75
Calibrate Internal Pressure Range 75

Appendix 1 - Datalog File Example

Typical Uploaded Datalog File (DPI 610) 79
Typical Uploaded Procedure Data File (DPI 615) 80

vii K415 Issue No. 1

K415 Issue No. 1 viii

+

-

INTRODUCTION Summary of Functions

General

The versions of the DPI 610 and DPI 615 instruments are: pneumatic indicator, pneumatic
calibrator, hydraulic calibrator and low pressure pneumatic calibrator. All instruments
measure and display pneumatic and hydraulic pressure applied to the test port or to an
externally connected pressure sensor. Pressure measurement can be absolute, gauge
and sealed gauge and in ranges from 2.5 mbar to 700 bar (1.0 inH

The calibrator versions of this instrument contain pneumatic or hydraulic pressure
generation components to produce pneumatic pressure ranges between -1 to 20 bar
(-14.5 psi to 300 psi) and hydraulic pressure ranges up to 400 bar (6000 psi).
The electrical connections, on the front of the instrument, enable the instrument to
measure ±50 volts d.c. and ±55 mA and produce 10 volts d.c. or 24 volts d.c. and a
maximum of 24 mA. An integral sensor provides measurement of ambient temperature.
Additional sensors (option B1) connect to an external connector and extend the pressure
measurement range and include differential pressure measurement. The instrument has
an RS232 connector to enable uploading of test data to a compatible documenting
system. The DPI 615 has the ability to download, from a PC, pre-defined calibration and
test routines. Six alkaline C size batteries or (option A) rechargeable batteries with a
charger/adaptor, power the instrument.

Important Notice

Zinc-carbon and zinc-chloride cells should NOT be used in this instrument.

Use only the battery types as shown in the table on page 7.

O to 10000 psi).

2

Description of Procedures

In the procedures outlined in this user guide, hard (fixed function) and soft (variable
function) key operations are shown in bold type (e.g.) TASK and F1. These statements
mean press the TASK key and press the F1 key. Soft key operations can be allocated to
both the F1 and F2 keys. Where a specific soft function is referred to it is written in bold
italics (e.g.) PROCESS.
This instrument has a number of operating modes that are described in a simplified form
in the following sections. Diagrams accompanying the procedures give typical selection
sequences and shaded controls indicate that this control key should be pressed in the
appropriate sequence. Diagrams should be read from left to right, top to bottom where
appropriate. A shaded display soft box indicates that the function key immediately
below that soft box should be pressed (either F1 for the left hand soft box or F2 for the
right).

FCT.: STANDARD

COURANT

UNITES

V

bar

CHOIX UNITES
DE PRESSION

inHg

bar

hPa
Pa

SELECTIONNER

UNITES

In the above diagram the following key sequence is indicated.
(a) Press the F2 key (the key immediately below the

(b) Use the

shaded, use all these keys to select or enter data).

Up

and

Down

cursor keys (only) to select the required option. (If all keys

PRESSURE UNITS

soft box).

(c) Press the ENTER key.

1 K415 Issue No. 1

INTRODUCTION Summary of Functions

Using this guide

The following key symbols are used in the procedure diagrams that follow:

SELECT VALUE

Shaded cursor keys indicate that a combination of these four keys, Up,
Down, Left and Right should be used to (e.g.) enter an alpha numeric
value or to select a function.

Indicates the ENTER key. Used to confirm an operation or a selection.
Shading indicates key operation.

Exit key, used to clear current menu selection and return to next menu
level above current level. Used as an escape key from current operation.
Shading indicates key operation.

Hardkey (total 7). Legend beside key symbol indicates function. Shading
indicates key operation.

Maximum Instrument Ratings

The following table shows the maximum measurement input ratings of the instrument
that should not be exceeded.

PRESSURE 120% FULL SCALE

VOLTAGE 50 V d.c.

CURRENT 55 mA d.c.

Note 1: The display flashes if the input pressure, voltage or current overrange.

Note 2: Max applied voltage for external loop supply = 30V dc (see page 8).

K415 Issue No. 1 2

+

-

INTRODUCTION Summary of Functions

OPERATOR CONTROLS (Figure 1 and 2)

These divide into two groups, the operator/display controls (Figure 1) and the pressure/
vacuum generation components (Figure 2). The operator controls and a typical display,
common to all instrument versions, is shown below.

1

FCT.: STANDARD

V

bar

COURANT

UNITES

PRESSION

F2F1

2

3

4

5

8

7

6

1 Display 2 Electrical Input Sockets 3 Electrical Output Sockets 4 Cursor
5 Enter Key 6 On/Off Key 7 Function (soft) Keys 8 Hard Keys

Figure 1 - DPI 610/615 Key-pad

Display

The display section of the instrument basically divides into four distinct sections. The two
main sections of the display are used to display a input and an output. The remaining
sections show the status display area and define the soft key functions. A typical display
is shown below:

Status display

Input

Output display

Soft boxes

Ligne Etat

Affichage Measurand

(INPUT)

Affichage Source

(OUTPUT)

Cases Programmables

FCT.: STANDARD

COURANT

V

bar

UNITES

PRESSION

3 K415 Issue No. 1

INTRODUCTION Summary of Functions

HARD KEY FUNCTIONS (Figure 1)

Key Function

I/O

SETUP*

ZERO

INPUT*

TASK

OUTPUT*

This key is used to turn the instrument ON and OFF. 7

The

SETUP

key provides access to the instrument’s general
configuration parameters that are set up to certain default
parameters on delivery.

The

ZERO

key can be used to zero either the selected input or output
display, if the display reading is within 5% of zero. Attempts to zero a
larger offset result in an error message,

The

INPUT

key is used to select the input parameter to be displayed. 20, 21

The

TASK

key is used as a means of rapidly configuring the instrument
for a number of different types of external device calibration. There
are twenty task configurations available, eleven of which are pre­programmed and nine are user definable

The

OUTPUT

key is used to select output parameter to be displayed. 25-28

Zero too large.

Page

reference

37

9

10

STORE*

RECALL*

ENTER

EXIT

Depending upon how the instrument’s
is used either to store up to 20 display screens (in
to manually log a screen in

This key is used to recall a previously stored screen to the display.
Depending on the
either the snapshot of a previously stored screen or datalog file. In

STORE

mode, selection displays the last screen stored. By using the
cursor keys, the operator can scroll either forward or back through
memory locations.

The

ENTER

key is used either to enter data (accept entered data), or, in

conjunction with the soft keys, to accept a given selection.

The

EXIT

key operates in conjunction with all the other hard and soft
keys to exit from the current screen or menu level, to the level
immediately preceding it. To quit completely from any menu level,
press

EXIT

until the

STORE

MEASURE/SOURCE

DATALOG

mode set-up, operation of this key recalls

STORE

mode.

screen is displayed.

* These key functions are not available in BASIC mode

mode is setup, this key

SNAPSHOT

mode), or

30-36

30, 32-36

2

2

K415 Issue No. 1 4

INTRODUCTION Summary of Functions

SOFT KEYS (Figure 1)

Three soft keys, designated F1, EXIT and F2, are situated immediately below the display
as shown below. These keys have their function allocated by the instrument software
which is indicated in the bottom of the display (Voltage for F1 and Units for F2 in this
example). They are used to select menu (program) options and are fully described under
the appropriate section headings.

CURSOR KEYS (Figure 1)

The cursor keys consist of a block of four keys, designated up , down , left and
right . In programs where options need to be selected from a list, (e.g.) the TASK

selection program, the up and down cursor keys are used to highlight one of the
options, from which it can be selected by the ENTER key. In TAS K mode, where more

than one page of options are provided, the left and right cursor keys will switch
between pages.

2

3

5

1

12

7

8

9

11

1 Test port, connect to unit under test 2 Hard keys
3 Cover (external interfaces) 4 Electrical inputs
5 Electrical outputs 6 Cursor keys
7 Function (soft) keys 8 Release valve (releases pressure through 9)
9 Vent port 10 Select positive or negative pressure
11 Pump 12 Fine pressure adjuster

10

Figure 2 - DPI 610/615 Calibrator Controls

4

5

6

5 K415 Issue No. 1

INTRODUCTION Summary of Functions

ELECTRICAL CONNECTIONS

1

1 Cover, closed when

not using connectors
2 External transducer
3 RS232 connector
4Temperature sensor

2

5DC power input

3

4

5

Figure 3 - Electrical System Connections

Measurement inputs and Source outputs are made via the control panel sockets as
shown below.

12

FCT. : STANDARD

INPUTS

V

OUTPUTS

bar

COURANT

UNITES

PRESSION

F2F1

1 Status display 2 Input display 3 Electrical input sockets
4 Electrical output sockets 5 Output display

Figure 4 - Electrical Measurement Inputs/Outputs

3

4

5

K415 Issue No. 1 6

Getting Started

Fitting Batteries

1 Cover fixing screws.

2 Rechargeable NiCad pack Part no.

191-126

3 Six alkaline C-cells Type no. LR14.

1

2

3

Caution: Old batteries can leak and cause corrosion. Never leave

discharged batteries in the instrument.

Note: After fitting a rechargeable NiCad battery pack the display may show the battery

low indication caused by the battery pack not being fully charged. Use the power
adaptor/charger to fully charge the pack.

Switching On

Press the I/O switch on the front panel and proceed as follows.

The first time the instrument powers up, it will be in BASIC mode with the main screen
displaying voltage in the input display area and pressure in the output display area. To
switch to CURRENT as input, press F1 as shown. Similarly, F1 to return to VOLTAGE.

Note: No other keys are active in this mode and the instrument can only be reconfigured

by pressing the TASK key and selecting another mode.

7 K415 Issue No. 1

+

-

Getting Started

Change Pressure Units

To change the pressure units proceed as follows. If the four units displayed are not the
units required, press TASK and select any task, other than BASIC, press SETUP and
proceed as detailed on page 37. To return to BASIC mode, press TASK and select BASIC.

FCT.: STANDARD

V

CHOIX UNITES

DE PRESSION

inHg

bar

hPa
Pa

SELECTIONNER

UNITES

COURANT

In BASIC mode, the instrument is configured to carry out basic Pressure to Voltage (P to
V) or Pressure to Current (P to I) tests, a typical test procedure follows.

Voltage and Current Measurement

Connect the electrical input sockets as follows for voltage and current measurements.
Use the test leads provided and DO NOT push bare wires into the sockets.

Note: Maximum applied voltage = 50V dc,. Maximum input current = 55mA dc

max 50V

CAT II

+

V

Vin

-

mA in

mA Sink

mA out 10V out

24V out

Xmtr

UNITES

55mA

max

max 50V

CAT II

Vin

mA in

mA Sink

mA out 10V out

24V out

Xmtr

55mA

max

max 50V

CAT II

Vin

mA in

mA Sink

mA out 10V out

24V out

Xmtr

55mA

max

bar

-

+

Note: Maximum applied voltage for external loop supply = 30V dc

K415 Issue No. 1 8

Getting Started

Typical Calibration Set-up (Pressure to Voltage)

Connect a device under test to the instrument as shown below:

A

B

DPI 615

TASK: BASIC

-

P

+

V

-+

+

C

-

CURRENT

PRESSURE

UNITS

F2F1

V

bar

A - External pressure source (indicator instruments only) B - Pressure regulator
C - Excitation 10V

General procedure

• Use the hand-pump to pressurize the system to the required level as indicated on the

display. Allow the display to settle and screw the volume adjuster in or out as a fine

adjustment to the required pressure. Record the input (e.g.) Voltage, reading at each

applied pressure.

Zero Display Reading

Both the input and output readings can be set to zero using the ZERO key and if the
displayed reading is within 5% of zero. To zero either the INPUT or OUTPUT displays,
proceed as follows:

FCT.: STANDARD FCT.: STANDARD

ZERO

V

V

ZERO

ZERO

ENTRÉE

FCT.: STANDARD FCT.: STANDARD

ZERO

SORTIE

bar

TENSION A ZERO ?

OUI

V

ZERO

ENTRÉE

ZERO

SORTIE

bar

CAPTEUR INTERNE A ZERO ?

OUI

9 K415 Issue No. 1

bar

NON

V

bar

NON

Task Selection

TASK key

The TASK key is used to set-up the instrument for a number of specific types of test.
There are two modes BASIC and ADVANCED and nine other specific types of test that
automatically configure the instrument on selection from the TASK menu. The tasks
available under the TASK menu are held on three pages shown below. To select a task
from the menu, press the TASK key, position the cursor over the required task and press
the ENTER key as shown below. Use the right/left cursor keys to switch between pages.

Courant (Page 2) (Page 3)

FONCTIONS

STANDARD

P-I
P-P
P-V
I-P

FONCTIONS

P - VALEUR

P - PRESSOS

TESTFUITE

TRANSM

SOUPAPE

FONCTIONS

CONFIG.
UTILISATEUR

Using Task Functions

Specific tasks are selected as shown above. The following diagrams show how to
connect the unit under test (UUT) for each task selectable under the TASK menu.

Input and output units, where applicable, can be selected by pressing either the INPUT or
OUTPUT keys as shown below. The output key also provides the facility of turning the 24V
output supply ON and OFF. When not in use, the 24V supply output should be turned OFF
to conserve battery power.

Set Units

OUTPUT

SELECTIONNER

FONCTION

UNITES

24 VOLT

OFF

SELECTIONNER

FONCTION

CHOIX UNITES

DE PRESSION

inHg

bar

hPa
Pa

ON

SELECTIONNER

UNITES

Note: If the four units displayed are not the units required, press SETUP, select SETTINGS

and refer to page 38.

Set 24 Volts

SELECTIONNER

FONCTION

OUTPUT

UNITES

24 VOLT

K415 Issue No. 1 10

OFF

SELECTIONNER

FONCTION

SELECTIONNER

FONCTION

UNITES

24 VOLT

SELECTIONNER

MARCHE/ARRET

ON

ON

Task Selection

Cal mode (DPI 615 versions only)

Cal mode, which is available in tasks P-I, P-P, P-V, P-P, P-DISPLAY and P-SWITCH, provides
a method of setting-up test parameters manually. Downloaded test procedures can also
automatically set-up and turn on the Cal Mode function. The method of turning on and
setting-up Cal Mode is shown below for a P-I task. The method is similar for all the other
tasks available in Cal Mode.

FCT.: P-I

ENREG DONNEES

24V OFF 24V OFF

SELECTIONNER

VALEUR

FCT.: P-I

ENREG DONNEES

COURANT

PRESSION INT

RENTRER EN
MODE CALIB.

SORTIE LINEAIRE
MAX. ERROR
TYPE D'ERREUR

CHANGER

VALEUR

%ECH.

% ECH. REFUSE

SORTIR DU

MODE CALIB.

Pressing the F1 key (TURN ON CAL MODE), provides the set-up screen for the CAL mode.
Initially, the cursor is placed in the UUT SPAN field to allow the required span range to be
entered. The corresponding values for the UUT output parameter (current) are then set,
followed by the maximum error value and error type (% rdg or % span). When all test
parameters have been set-up, the screen changes to display the input and output and
the test results. The test result can only be displayed to within a range of ±9.99%. If the
test result is outside this range, either the left pointing (-ve error) or right pointing (+ve
error) chevrons are displayed. Within this error band, the actual tolerance value is
displayed. Test results can either be stored as snapshots or logged as datalog files,
depending upon how the instrument has been set-up.

Basic Mode (Task BASIC)

This instrument powers up in this mode the first time that it is used. To select BASIC from
any other task, press the TASK key and select BASIC and press the ENTER key. BASIC
mode is fully described in the Getting Started, section (see page 7).

11 K415 Issue No. 1

Taking Measurements

Pressure Transmitter (P-I) Task

Select the P-I task from the task menu and connect the Unit Under Test (UUT) to the
calibrator as shown below.

mA

bar

C

P

+ (24V)

I

-

A

B

DPI 615

FCT. : P-I 24V OFF
MODE ENREG. RAPIDE

F2F1

A - External pressure source (indicator instruments only) B - Pressure regulator
C - Pressure to current 24V device

• If required, select the output units as described on page 10.

• If applicable, turn on Cal Mode and set-up test parameters as detailed on page 11.

Voltage Output Pressure Transmitter (P-V) Task

Select the P-V task from the task menu and connect the UUT to the calibrator as shown
below. Voltage output transducers with a 10 V supply and outputs of ±10 V can be
calibrated using the 10V output sockets (supply) and the transducer output connected to
a voltmeter (refer to Method on page 13 for a test procedure).

A

P

-

+

V

-+

B

DPI 615

TASK: BASIC

+

-

C

CURRENT

PRESSURE

UNITS

F2F1

V

bar

A - External pressure source (indicator instruments only) B - Pressure regulator
C - Excitation 10V

• If required, select the output units as described on page 10.

• If applicable, turn on Cal Mode and set-up test parameters as detailed on page 11.

K415 Issue No. 1 12

Taking Measurements

Pressure Converter (Pressure to Pressure) Task

Select the P-P task from the task menu and connect the UUT to the calibrator as shown
below. Testing a converter requires one pressure to be applied to the unit under test
(UUT) and another (converter output) to be measured. The additional measurement is
provided by the external transducer option.

Method

• Connect the UUT to the calibrator and plug the external transducer into the

calibrator as shown below.

C

A

D

B

E

A - External pressure source (indicator instruments only)
B - Pressure regulator C - External pressure supply
D - Pressure to pressure device E - External transducer

• Press the TASK key and select the P-P task. Providing the external transducer has

been calibrated and its parameters stored in the calibrator, the display shows

External pressure in the input window and calibrator Output pressure in the output

window. If an error message “NO SENSOR OR CAL INVALID” is displayed, this

indicates that the external transducer has not been entered and/or calibrated with

the calibrator. Refer to page 45 for details of adding an external transducer. If an

external transducer change is made, switch the calibrator off and then on to load

new transducer data.

• If required, select the input and output units as described on page 10.

• If applicable, turn on Cal Mode and set-up test parameters as detailed on page 11.

Note: Match pressure ranges to give required accuracy and avoid overpressure. If

external pressure is required as the output and internal pressure the input, use
ADVANCED mode for this set-up.

13 K415 Issue No. 1

Taking Measurements

Current to Pressure Converter (I-P) Task

DPI 615

FCT. : I-P 24V OFF
MODE ENREG. RAPIDE

A

+ (24V)

P

I

B

-

SORTIE

NOUV VAL

bar

OK

mA

F2F1

A - External pressure supply B - Pressure to current device (24V)

•Use the up and down cursor keys to adjust the loop current to the required

value. Alternatively, press ENTER and use cursor keys to enter a finite value. Cursor

keys can then be used to nudge the output either up or down. If required, change

pressure units with INPUT key.

Pressure Switch Test (P-SWITCH) Task

A

C

B

DPI 615

FCT.: P-PRESSOS 24V OFF
MODE ENREG.RAPIDE

ETATCONTACT

A - External pressure source (indicator instruments only)
B - Pressure regulator C - Pressure switch under test

• Contact state will be shown on display. When contacts close, buzzer sounds.

• To run switch test, close vent valve and press the RUN (F1) key.

• Using the hand-pump, increase the applied pressure to just below the switch

operating point. Screw the volume adjuster in until the switch operates (the display

then shows the operating pressure of the switch).

• Reduce pressure until the switch releases (indicated by the switch symbol). The

display then shows the release pressure and the hysteresis value.

K415 Issue No. 1 14

DEMARRER

bar

F2F1

Connect Vin +, SW + and
mA in

+ together.

Connect switch test leads
across switch

symbol.

Open circuit test leads

Press ENTER to continue.

Switch Resistance input
now

ready for use.

Press ENTER to continue.

Open circuit test leads.

Now short test leads.

Press ENTER to continue.

Taking Measurements

Pressure Switch Testing with Contact Resistance Measurement

A

C

B

DPI 615

FCT.: P-PRESSOS 24V OFF
MODE ENREG.RAPIDE

ETATCONTACT

DEMARRER

F2F1

bar

A - External pressure source (indicator instruments only)B - Pressure regulator
C - Pressure switch under test

To perform switch test with contact resistance measurement, select P-SWITCH and
proceed as follows:

SELECTIONNER

ZERO

INPUT

SELECTIONNER

FONCTION

RESIST

ZERO

OFF

SELECTIONNER

RESISTANCE

SELECTIONNER

FONCTION

RESIST

ON

ZERO

To ensure accurate measurements it is recommended that the zero procedure (that
compensates for the resistance of the test leads) is carried out before performing this
test.

Note: Allow sufficient time after contact closure for the resistance to stabilize.

24V OFF

bar

Connect Vin +, SW + and
mA in + together.

Connect switch test leads
across switch symbol.

Open circuit test leads

Press ENTER to continue.

Now short test leads.

Press ENTER to continue.

Switch Resistance input
now ready for use.

Open circuit test leads.

Press ENTER to continue.

TASK : P-SWITCH
SNAPSHOT MODE

CONTACT STATE

RUN

The switch test is performed in the same way as the previous
section, except that the contact resistance is measured and
displayed with the results.

FCT.: P-PRESSOS
MODE ENREG. RAPIDE

ETAT CONTACT

FERME A
bar
OUVERT A
bar
HYSTERESIS 1.001

24V OFF

15.060

14.059

bar

DEMARRER

15 K415 Issue No. 1

Taking Measurements

Pressure to Display (P - Display) Task

P-Display is a special application of Datalog. To use this mode, select Datalog from the
Store Mode menu as detailed on page 37. Connect the UUT to the instrument as shown
below and, if required, turn on and set-up Cal Mode (see page 11).

A

B

C

DPI 615

FCT. : P-AFFICHAGE 24V OFF
FICHIER : AUCUN

AFFICHAGE

CHANGER

VALEUR

bar

F2F1

A - External pressure source (indicator instruments only) B - Pressure regulator
C - Dial gauge under test

• Press

TASK

and select

P-DISPLAY

. If required, use

OUTPUT

key to change pressure units.

• Set-up a data log file as detailed on page 31.

Note: TRIGGER field, automatically set to KEYPRESS, cannot be changed.

• Apply a series of test pressures to the device under test. Enter displayed reading at

each pressure and log each point:

FCT.: P-VALEUR
FICHIER: A1

24V OFF 24V OFF 24V OFF

FCT.: P-VALEUR
FICHIER: A1

ENTRER VALEUR

FCT.: P-VALEUR
FICHIER: A1

VALEUR

CHANGER

VALEUR

bar

• After logging final test point , terminate as

follows:

K415 Issue No. 1 16

VALEUR

CHANGER

+

VALEUR

STORE

bar bar

VALEUR

ENREGISTRER

MAINTENANT

ARRETER

ENREGISTREM.

DERNIER POINT

FCT.: P-AFFICHAGE 24V OFF

FICHIER

:A1

STORE

AFFICHAGE

ENREGISTRER

MAINTENANT

bar

ARRETER

ENREGISTREM.

Taking Measurements

Leak Test (LEAK TEST) Task

A

C

B

DPI 615

FCT. : TESTFUITE 24V OFF
MODE ENREG. RAPIDE

ATTENTE
DUREE

DEMARRER
PRESS. FIN

FUITE
TAUX FUITE

CHANGER

VALEUR

3

1

DEMARRER

F2F1

bar

min
min

Bar
bar

bar
bar/m

A - External pressure source (indicator instruments only) B - Pressure regulator
C - Unit/system under test

• If required, use the INPUT key to change pressure units.

• Set-up the leak test WAIT and DURATION times to the required values as shown

below. Recommended minimum wait period - 3 minutes.

FCT. : TESTFUITE
MODE ENREG. RAPIDE

PRESSION INT

ATTENTE
DUREE

CION

DEMARRER
PRESS. FIN

FUITE

TAUX FUITE

CHANGER

VALEUR

24V OFF 24V OFF

bar

min

3

1

min

bar
bar

bar
bar/m

DEMARRER

REGLER
PERIODE
ATTENTE

FCT. : TESTFUITE
MODE ENREG. RAPIDE

PRESSION INT

ATTENTE
DUREE

CION

DEMARRER
PRESS. FIN

FUITE

TAUX FUITE

CHANGER

VALEUR

3

1

DEMARRER

bar

min
min

bar
bar

bar
bar/m

REGLER

DUREE

• Close the vent valve and pressurize the unit/system to the required LEAK TEST

pressure.

•Press the RUN (F2) key to start the leak test. When completed, the beeper sounds

and the leak test results are written to the display.

17 K415 Issue No. 1

Taking Measurements

Transmitter Simulation (TX SIM) Task

Provides a current output proportional to the calibrator’s measured output pressure
(indicated pressure on indicator only version). Select task TX SIM. Press EXIT to skip set­up screen if parameters are correct.

TRANSMETTEUR

VALEUR MINIMUM

kPa0.000
mA4.000

REGLER VALEUR

TRANSMETTEUR

VALEUR MINIMUM

kPa0.000
mA4.000

REGLER VALEUR

VALEUR MAXIMUM

20.000

20.000

CHANGER

VALEUR

kPa
mA

TRANSMETTEUR

VALEUR MINIMUM

kPa0.000
mA4.000

VALEUR MAXIMUM

20.000

20.000

CHANGER

VALEUR

kPa
mA

REGLER VALEUR

VALEUR MAXIMUM

20.000

20.000

CHANGER

VALEUR

kPa
mA

TRANSMETTEUR

VALEUR MINIMUM

kPa0.000
mA4.000

VALEUR MAXIMUM

20.000

20.000

CHANGER

VALEUR

kPa
mA

On completion of TX SIM set-up, the display is configured as follows:

TASK : TX SIM
SNAPSHOT MODE

24 V OFF

REGLER VALEUR

PRESSURE INT

CURRENT OK

CHANGE

VALUE

bar

mA

Set-up the output loop as detailed on page 25 and, if necessary, turn on the internal
electrical supply.

To subsequently change any of the TX SIM scaling parameters, press CHANGE VALUE
(F1) to obtain the TX Simulation display.

To change the pressure units, press INPUT and select the required scale units. If the
required scale units are not listed, press SETUP, select SETTINGS and proceed as detailed
on page 38.

K415 Issue No. 1 18

Taking Measurements

Relief Valve Test (REL VALVE) Task

To carry out a relief valve test, press TAS K and select REL VALVE. Connect the output
pressure port of the instrument to an external system as shown below:

C

A

B

DPI 615

FCT. : SOUPAPE 24V OFF
MODE ENREG. RAPIDE

MAXIMUM

MINIMUM

RESET

MAX/MIN

bar

bar

F2F1

A - External pressure source (indicator instruments only) B - Pressure regulator
C - Relief valve under test

• To change the pressure units, if required, press INPUT and select the required
units using the cursor keys.

• If necessary, turn on the 24 Volt internal supply by pressing OUTPUT, select 24
VOLT and switch ON with the right cursor button and press ENTER.

• Close the vent valve and, using the hand-pump or external pressure supply, apply
pressure to the relief valve under test.

• When the relief valve operates, the maximum recorded pressure indicates the
operating point of the valve.

Note: The STORE key can be used for this purpose. Use right cursor key initially,

followed by up/down keys to enter Snapshot text).

• Record the test results.

• Open vent valve to release test pressure.

Note: If using external pressure supply, isolate supply before opening the vent

valve.

19 K415 Issue No. 1

Advanced Task Select Input

General

Advanced task allows the user to configure the instrument to monitor one of a number of
different input measurements and outputs (sources). Additionally, five process functions,
Tare, Max/Min, Filter, Flow and % Span can be applied to the input functions.

Select Input

To display an input channel, select ADVANCED task from the task menu. The display
shows the list of the input selections and, if available, the PROCESS soft box (F1) and the
UNITS soft box (F2).
The following procedure shows the method of input channel selection and the method of
changing units:

INPUT

SELECTIONNER

ENTREE

SELECT ENTREE

PRESSION INT

PRESSION

TENSION
COURANT

TEMPERATURE

PROCESS UNITES

EXT

CHOIX UNITES
DE PRESSION

inHg

bar

hPa
Pa

SELECTIONNER

UNITES

INPUT

SELECTIONNER

ENTREE

SELECT ENTREE

PAS D'ENTREE

PROCESS

UNITES

Note: Left/right arrow keys function as page up/down keys.

Refer to pages 21 to 24 for details of process functions.

Ambient Temperature Measurement

To set-up the instrument to read ambient temperature, proceed as follows:

INPUT

SELECTIONNER

ENTREE

SELECT ENTREE

PRESSION INT
PRESSION

EXT

TENSION

COURANT

TEMPERATURE

PROCESS UNITES

SELECTIONNER
UNITES DE
TEMPERATURE

CELSIUS

FAHRENHEIT

SELECTIONNER

UNITES

Note: Make sure the temperature reading has stabilized.

K415 Issue No. 1 20

Advanced Task Process Functions

Process Functions

If required, the following process functions are available on the input display but only in
ADVANCED task. If the instrument is in any other mode i.e. BASIC or any other task
mode, the input and output displays must first be configured in ADVANCED task.

Note: PROCESS functions are not available to the output channel.

A summary of the process functions follows:

Tare Allows either the current display value or a manually

entered value to be tared off display parameter reading.

Max/Min Displays running Max/Min and present display values

simultaneously. Resettable via F1 key.

Filter Applies low pass filter function to displayed parameter.

Filter characteristics (Settling time and Band) are user
programmable.

Flow Applies square root function to displayed parameter.

% Span Converts displayed parameter reading to a percentage of

span. Span definable via the F1 key.

Following selection of ADVANCED from the task menu, press the INPUT key. Use the up

or down cursor keys to select the required input. Press the PROCESS (F1) key and

use the left or right cursor keys to enable the process on/off:

INPUT

SELECTIONNER

TRAITEMENT

SELECT. ENTREE

PRESSION INT

PRESSION EXT
TENSION

COURANT

TEMPERATURE

PROCESS UNITES

ENTR. PROCESS

TARE ON

MAX/MIN OFF
FILTRE OFF
DEBIT OFF
% ECH OFF

PARAMETRAGES

VALIDER

TRAITEMENT

Press ENTER to switch the process ON with existing settings or F1 to change process
settings (where applicable).

21 K415 Issue No. 1

Advanced Task Process Functions

Tare Process Function

To set-up a Tare function, enable TARE from the process menu and press F1 to
enter the Tare SETTINGS functions.

Disable TARE by entering process menu and turning the function OFF.

Note: Last TARE setting is retained and will be applied when function is next

enabled.

Tare Current Input Reading To tare off the current display reading, proceed as
follows:

TASK : ADVANCED
SNAPSHOT MODE

VOLTAGE

PRESSURE INT

MAKE READING

ZERO

24V OFF

V

bar

TARE OFF

A VALUE

Tare Off An Entered Value To tare off an entered value, proceed as follows:

Note: Display shows the last entered Tare value.

FCT. : CONFIG.

MODE ENREG. RAPIDE

24V OFF

FCT. : CONFIG.

MODE ENREG. RAPIDE

V

TASK : ADVANCED
SNAPSHOT MODE

VOLTAGE

PRESSURE INT

24V OFF

V

24V OFF

T

V

bar

ENTRER VALEUR

bar

TARER A ZEROVAL

ACTUELLE

VALUER

DE TARER

K415 Issue No. 1 22

VALEUR: 10.000
NOUV VAL: _

bar

Advanced Task Process Functions

Max/Min Process Function

To set-up an input display to show max/min and present input reading, enable
MAX/MIN from the process menu and press F1 (SETTINGS) to provide RESET
function. The display now shows the max/min values as follows:

FCT. : CONFIG

MODE ENREG. RAPIDE

ACTUEL

24V OFF

Reset Max/Min display at any time by pressing the
F1 key.

To quit max/min, press INPUT, select MAX/MIN
from process menu and switch the function off.

RESET

MAX/MIN

Filter Process Function

To apply the low pass filter to a selected input, enable FILTER from the process
menu and press F1 (SETTINGS) to provide access to the filter parameters. Two
settings are required, Time to Settle and Band.
To examine the current filter settings and exit without change, press the EXIT key.

The set-up procedure is as follows:

SELECTIONNER

CONFIG.FILTRE CONFIG.FILTRE

PERIODE
HEURE =

2 Seconds

VALEUR

PERIODE

HEURE = 2 Seconds

SELECTIONNER

VALEUR

BANDE = AMPLITUDE MAX
QUI DOIT FILTREE VARIATIONS
SUPERIEURESA LA BANDE DU
FILTRE

BANDE = 1.5 % FS

CHANGER

VALEUR

BANDE = AMPLITUDE MAX
QUI DOIT FILTREE VARIATIONS
SUPERIEURESA LA BANDE DU
FILTRE

1.5

BANDE =

CHANGER

VALEUR

%FS

23 K415 Issue No. 1

Advanced Task Process Functions

Flow Function

To apply the flow function to a selected input, enable FLOW from the process
menu and press ENTER. The square root symbol is displayed beside the input
value to indicate that the FLOW function is active:

FCT. : CONFIG. 24V OFF

MODE ENREG. RAPIDE

To cancel FLOW, press INPUT and turn function

V

OFF at the process menu.

bar

%Span

To convert a selected input display from a numerical value to a percentage of
full-scale reading, enable SPAN from the process menu and press F1 (SETTINGS)
to provide access to the span definition parameters. Two span definitions are
required, Zero and Full Scale.

To leave span at current setting, press EXIT.

To define zero and full-scale settings, proceed as follows:

DEFINE ECH.

VALEUR AFFICHEE

LECTURE

ACTUELLE

V

0% =

100% =

ENTER UNE VALEUR OU F2
POUR SELECTIONNERVALEUR
ACTUELLE OU EXIT POUR
QUITTER SANS MODIFICATIONS

CHANGER

VALEUR

_

50.000 V

SELECTIONNER

VALEUR

DEFINE ECH.

VALEUR AFFICHEE

0.0000% =

100% =

ENTER UNE VALEUR OU F2
POUR SELECTIONNERVALEUR
ACTUELLE OU EXIT POUR
QUITTER SANS MODIFICATIONS

CHANGER

VALEUR

_

LECTURE

ACTUELLE

V
V

SELECTIONNER

VALEUR

To cancel %SPAN, press INPUT and turn function OFF at the process menu.

K415 Issue No. 1 24

Advanced Task Select Output

Select Output

To display an output channel, select ADVANCED mode from the task menu. The display
shows the list of output selections and, if available, the UNITS soft box (F2).

The following procedure shows the method of output channel selection from two pages
of options. The second page can be obtained directly from the first by pressing the right

cursor key:

SELECTIONNER

SORTIE

OUTPUT

SELECT SORTIE

PRESSION INT

PRESSION EXT
PAS mA
RAMPE mA
VALEUR mA

UNITES

Note: Left and right keys function as page up/down keys.

To change the output units (pressure channels only), select the channel with the cursor
keys and press F2 before pressing ENTER.

SELECT SORTIE

PAS DE SORTIE

24 VOLT OFF

Electrical Outputs (Loop Power)

For all the electrical outputs, the output loop can be powered either by the instrument’s
internal 24V supply (sourcing) or alternatively, from an external supply (current sinking).
To conserve battery power, the 24V internal supply should be switched off (even when
not being used to power an external loop).

External connections to the front panel of the instrument are shown below for both
sourcing and sinking applications:

Ext. d.c. Supply
(30V Max)

LOAD

LOAD

CURRENT SOURCING
(24V ON)

CURRENT SINKING
(24V OFF)

25 K415 Issue No. 1

Advanced Task Select Output

mA Step

To select one of the electrical output programs, press the OUTPUT key and proceed as
follows:

SELECTIONNER

SORTIE

PAS m A

LINEAIRE 4-20

LINEAIRE
RAC CARR
RAC CARR
VANNES

0-20
4-20
0-20
4-20

mA

mA
mA
mA
mA
mADCS 4-20

OUTPUT

SELECT SORTIE

PRESSION INT
PRESSION EXT

INT

PAS m A

RAMPE mA
VALEUR mA

UNITES

On selection of (e.g.) Linear, the output display window changes to show the selected
program of output currents:

SELECTIONNER

PROGRAMME

ARRET

24V OFF

bar

mA

FCT. : CONFIG.

MODE ENREG. RAPIDE

LINEAIRE 4-20 mA PAS

481216 20

EN COURS

ARRET

24V OFF

bar

mA

FCT. : CONFIG.

MODE ENREG. RAPIDE

LINEAIRE 4-20 mA PAS

4 812 16 20

DEMARRER

• For current sourcing applications, turn on the 24V supply as shown on page 28. For

current sinking applications, connect an external supply as shown on page 25 and
leave the 24V supply switched OFF.

•Press RUN (F1) to run program. A flashing status display CHECK LOOP indicates a

fault in the external loop i.e. supply fault or open circuit.

Note: The dwell time at each step is approximately 10 seconds.

•Press STOP (F1) when running to stop at any point. Press RUN (F1) to resume.

K415 Issue No. 1 26

Advanced Task Select Output

mA Ramp

Press the OUTPUT key and select mA RAMP as shown previously in mA Step.

• Define ramp required by entering START and END current values as shown below:

FCT. : CONFIG.

MODE ENREG. RAPIDE

DEBUT
SORTIE
FIN

DEBUT

24V OFF 24V OFF

ENTRER VALEUR

ARRET

bar

mA

FCT. : CONFIG.

MODE ENREG. RAPIDE

DEBUT
SORTIE
FIN

DEBUT

ARRET

bar

mA

ENTRER VALEUR

• For current sourcing applications, turn on the 24V supply as shown on page 28. For

current sinking applications, connect an external supply as shown on page 25 and
leave the 24V supply switched OFF.

•Press START (F1) to run the program. A status display CHECK LOOP indicates a fault

in the external loop i.e. supply fault or open circuit.

Note: The ramp cycle (min to max or max to min), is approximately 60 seconds.

FCT. : CONFIG.
MODE ENREG. RAPIDE

24V OFF

FCT. : CONFIG.
MODE ENREG. RAPIDE

24V OFF

DEBUT
SORTIE
FIN

DEBUT

ARRET

bar

mA

ENTRER VALEUR

DEBUT
SORTIE
FIN

ARRET

EN COURS

bar

mA

ENTRER VALEUR

•Press STOP (F1) when running to stop at any point. Press CONTINUE (F1) to resume

from point of pause or RESET (F2) to return to start point.

FCT. : CONFIG.
MODE ENREG. RAPIDE

DEBUT
SORTIE
FIN

ARRET

ARRET

24V OFF 24V OFF

bar

ENTRER VALEUR

mA

FCT. : CONFIG.
MODE ENREG. RAPIDE

DEBUT
SORTIE
FIN

CONTINUE RESET

PAUSED

bar

mA

ENTRER VALEUR

27 K415 Issue No. 1

Advanced Task Select Output

mA Value

Press the OUTPUT key and select mA VALUE from the output menu. The procedure is
shown below:

OK

24V OFF

bar

REGLER NIVEAU

mA

SELECT SORTIE

CHOISIR SORTIE

FCT. : CONFIG.
MODE ENREG. RAPIDE

PRESSION INT
PRESSION EXT
PAS mA
RAMPE mA

VALEUR mA

SORTIE

NOUV VAL

• For current sourcing applications, turn on the 24V supply as shown below. For

current sinking applications, connect an external supply as shown on page 25 and
leave the 24V supply switched OFF.

•Use up and down cursor keys to adjust output current level. While the loop is

made, a status display indicates OK. A status display CHECK LOOP indicates a fault
in the external loop i.e. supply fault or open circuit.

24 Volt

Press the OUTPUT key and select 24 VOLT from the Output menu. The procedure is
shown below:

Note: The 24V selection is located on the second page of output functions.

VALIDER

OUTPUT

SELECTIONNER

SORTIE

SELECT SORTIE

24 VOLT

PAS DE SORTIE

OFF

Note: To conserve battery power, keep the 24V supply switched off when not in use (even

if the output is unloaded).

SORTIE

SELECT SORTIE

24 VOLT

PAS DE SORTIE

ON

K415 Issue No. 1 28

Advanced Task Task Set-up/Removal

Define New Task

To define a new task, proceed as follows.

• Select ADVANCED from TASKS menu.

•Using the INPUT key, select the required input for the input display and set-up any

process functions required.

•Using the OUTPUT key, select the required output for the output display.

•Press TASK and select free. Enter new task name as follows:

TASK

FONCTIONS

CONFIG..

UTILISATEUR

SELECTIONNER

UTILISATEUR

FONCTIONS

LIBRE

LIBRE
LIBRE
LIBRE
LIBRE

SAUVE GARDER

NOUV. FONCT.

FONCTIONS

CO2INLET
LIBRE

LIBRE
LIBRE
LIBRE

ENTRER NOM

FONCTION

UTILISATEUR

CO2INLET

FCT. : CO2INLET
MODE ENREG. RAPIDE

24V OFF

libre

NOUVELLE FONCTION SAUV

EXIT

V

libre

SAUVEGARDER

NOUV.

EFFACER
FONCTION

bar

On completion of this procedure, the display reverts to newly set-up task as
shown:

Clear Task

To clear a user defined task, select TASK and proceed as follows:

TASK

SELECTIONNER

OPTION

UTILISATEUR

LIBRE

CO2INLET

VALVE234
VALVE773
LIBRE

SAUVEGARDER

NOUV. FONCT.

SUPPRIMER

FONCTION

UTILISATEUR

LIBRE

CO2INLET

VALVE234
VALVE773
LIBRE

SUPPRIMER FONCTION?

OUI NON

EXIT

29 K415 Issue No. 1

Memory Operations Store

Saving Display or Data Log

In Store Mode three memory operations can be set-up: None, Snapshot and Data Log.
Refer to Using Setup for details.

Store Operations (Screen Snapshots)

To store any display (menu displays excepted), press the STORE key. This saves the
current display to the next available location. Supporting text (10 characters) may be
appended. Twenty memory locations are available on a cyclic buffer. When all 20 have
been used, store operations overwrite existing locations, starting at Location 1.

FCT.: CONFIG.
MODE ENREG. RAPIDE

24V OFF 24V OFF

V

STORE

bar

FCT.: CONFIG.
MODE ENREG. RAPIDE

ENREG. RAPIDE 19

VOLTAGE

TEXTE :

ENTRER TEXTE

V

bar

Recalling Stored Data (Screen Snapshots)

To recall a previously stored display, press the RECALL key. This recalls the last display
saved. Press the left or right cursor keys to recall the previous or next locations

respectively. To exit RECALL, press the EXIT key:

SELECTIONNER
EMPLACEMENT

RECALL

FCT.: CONFIG.

2 TEST19ENREG. ECRAN

24V OFF

V

K415 Issue No. 1 30

bar

EXIT

Memory Operations Data Log

Data Log Operations

Data Log is a special application of store mode that enables the calibrator to either
automatically log displays at preset time intervals or to manually log a display on
operation of the STORE key. Logged data is written to a user specified file.

To set-up a Data Log file, proceed as follows:

• Select a task, other than BASIC. If using ADVANCED, set-up required output

parameters.

•Use SETUP to select Data Log from the Store Mode Menu (see page 37).

Auto Log (Timer)

Press STORE and set up the Data Log file parameters as shown below. Use CHANGE
VALUE (F1) followed by cursor keys to set field values. For Auto Log, set TRIGGER field to
PERIODIC.

STORE

DATA LOGGING

FILENAME :
DATE :
TIME :
TRIGGER:
PERIOD :
POINTS :

CHANGE

VALUE

21/02/99
12:29
PERIODIC
00:05
10

START

LOGGING

ENTER VALUE

DATA LOGGING

CHANGE

VALUE

LOGFILE2

21/02/99
12:29
PERIODIC
00:05
10

FILENAME :
DATE :
TIME :
TRIGGER :
PERIOD :
POINTS :

START

LOGGING

TASK : CO2INLET
POINT 10 OF 10

VOLTAGE

PRESSURE INT

24 V OFF

CLEAR

(ANY KEY)

V

bar

Manual Logging

Enter the file details as shown above and select KEYPRESS for TRIGGER field. Screen
reverts to displayed parameters showing set-up file as shown below:

DATA LOGGING

FILENAME :
DATE :
TIME :
TRIGGER :
PERIOD :
POINTS :

CHANGE

VALUE

LOGFILE3
21/02/99
12:29

KEYPRESS

START

LOGGING

DATA LOGGING

FILENAME :
DATE :
TIME :
TRIGGER :
PERIOD :
POINTS :

CHANGE

VALUE

LOGFILE3
21/02/99
12:29

KEYPRESS

START

LOGGING

TASK: ADVANCED
LOG FILE : LOGFILE3

VOLTAGE V

PRESSURE INT bar

24 V OFF

Use a combination of STORE and LOG NOW (F1) to log events as follows:

TASK: ADVANCED

24 V OFF

TASK: ADVANCED
LOG FILE : LOGFILE3LOG FILE : LOGFILE3

24 V OFF

STORE

VOLTAGE

PRESSURE INT bar

LOG

NOW

STOP

LOGGING

V

VOLTAGE V

PRESSURE INT bar

ENTER VALUE

31 K415 Issue No. 1

Memory Operations Data Log

Recall Data Log Files

To recall a Data Log file to the display, ensure that DATA LOG is selected from the SETUP
menu and proceed as follows:

SELECTIONNER

FICHIER

SOMMAIRE FICH

NOM FICH: TEST5
DATE:
HEURE:
MODE:
FORMAT:

TEXTE

06/11/99
15:58
MANUEL
886 bytes

GRAPHES

SOMMAIRE FICH

NOM FICH: TEST5
DATE:
HEURE:
MODE:
FORMAT:

REVOIR

DONNEES

06/11/99
15:58
MANUEL
886 bytes

TRANSMETTRE

FICHIER

RECALL

MEMOIRE UTILISEE

FEEDPRESS11
G3459
TEST1
TEST2

TEST5

FICHIER 1 de 9
DATE: 04/11/99 HEURE 10:58

EFFACER

Data Log files can be displayed either as text (stored screens) or in graphical form. To
display as text, proceed as follows from the File Summary menu. Select Auto Step to

automatically review each screen at 1 second intervals or use the left or right
cursor keys to manually review.

SOMMAIRE FICH

NOM FICH: TEST5
DATE:
HEURE:
MODE:
FORMAT:

REVOIR

DONNEES

06/11/99
15:58
MANUEL
886 bytes

TRANSMETTRE

FICHIER

FCT. : P-V
DATALOG

PAS

AUTOMATIQUES

24V OFF

POINT

1DE11

REVUE

MANUELLE

To display logged data in graphical form, on screen, proceed as follows from the File
Summary menu:

SOMMAIRE FICH

NOM FICH: TEST5
DATE:
HEURE:
MODE:
FORMAT:

TEXTE

06/11/99
15:58
MANUEL
886 bytes

GRAPHES

mA v t

barvt
mA v bar
Erreur v bar

TEST5

SELECTIONNER AXES

DE GRAPHIQUES

20.007

mA

3.902
15:58:55

TEST5

heure

16:18:23

K415 Issue No. 1 32

Memory Operations Data Log

Uploading Data Log Files

Connect the RS232 socket of the instrument to either the COM1 or COM2 port of the PC.
Ensure that the RS232 parameters at the PC end match those of the instrument. The
RS232 parameters of the instrument can be checked as detailed on page 39. Set-up a
file on the PC to receive the data, (e.g.) in the Windows® Terminal program.

To upload a file, proceed as follows. Appendix 1 give details of a typical uploaded data
log file.

SELECTIONNER

FICHIER

SOMMAIRE FICH

NOM FICH: TEST5
DATE:
HEURE:
MODE:
FORMAT:

TEXTE

06/11/99
15:58
MANUEL
886 bytes

GRAPHES

SOMMAIRE FICH

NOM FICH: TEST5
DATE:
HEURE:
MODE:
FORMAT:

REVOIR

DONNEES

06/11/99
15:58
MANUEL
886 bytes

TRANSMETTRE

FICHIER

RECALL

MEMOIRE UTILISEE

FEEDPRESS11
G3459
TEST1

TEST2

TEST5

FICHIER 1 de 9
DATE: 04/11/99 HEURE 10:58

EFFACER

Delete Data Log and Procedure Files

To delete a Data Log file, or a procedure file (DPI 615 only), proceed as follows.
Alternatively, to delete all logged files simultaneously, select ERASE ALL FILES (F2) at the
erase screen.

33 K415 Issue No. 1

Memory Operations Data Log

Downloading Procedure Files (DPI 615 instruments only)

Complete test procedures may be downloaded from a PC to the DPI 615 instrument via
the RS232 port. A procedure consists of a number of Druck Universal Command
Interface (DUCI) commands that are usually assembled by a linking management
software application (e.g.) Druck Intecal.

Before downloading a procedure, the instrument must be in the REMOTE mode. To place
the instrument into REMOTE mode, proceed as follows:

• Connect the instrument’s RS232 port to a free COM port on a PC.

• Ensure that the COMMS parameters of the PC match those of the instrument (refer to
page 39).

• Ensure that the instrument is not already running a procedure. If it is, quit the
procedure.

• Download the procedure. Procedures are stored in the Data Log directory.

The following sequence shows a typical download sequence that starts with the
instrument in LOCAL mode.

After the procedure file has been downloaded, the instrument is usually returned to the
LOCAL mode by the last command in the procedure file. If the instrument remains in
REMOTE mode, switch it OFF and ON to reset it.

K415 Issue No. 1 34

Memory Operations Data Log

Running Procedure Files (DPI 615 instruments only)

To run a procedure, make sure the instrument is set to the Store mode, Data Log (see
page 37), and proceed as follows:

RECALL

MEMORY USED

FEEDPRESS11

G3459
TEST1
TEST2
TEST5

FILE 1 of 9
DATE: 04/11/99 TIME 10:18

ERASE

SELECT FILE

FEEDPRESS11

DEVICE UNDER TEST

I/P LOW:
I/P HIGH
O/P LOW:
O/P HIGH

MAX PRESS:
POINTS:
MAX. ERROR:

RUN

PROCEDURE

0 BAR

20 BAR

0 VOLTS

10 VOLTS

22
5 UP/DOWN

0.1% SPAN

REVIEW

LOGGED FILE

After selecting F1, proceed by entering the User ID and Serial Number and then select F1
(Continue) and follow the on-screen procedural instructions:

LOG

NOW

..........

%span PASS

FEEDPRESS11

GO TO 0.000 bar

0.04

V

bar

FEEDPRESS11

GO TO 0.000 bar

..........

DATA POINT LOGGED

%span PASS

24V OFF24V OFF

FEEDPRESS11

GO TO 5.000 bar

V

0.04

bar

LOG

NOW

..........

24V OFF

%span PASS

V

bar

SETUP & LOG POINT 1 SETUP & LOG POINT 2 etc.POINT 1 STORED

When the test procedure for a given UUT has been completed, the result of running the
first test is stored as an AS FOUND file. This file cannot be overwritten. Any subsequent
tests on the device are stored as an AS LEFT file that is overwritten each time the
procedure on this device is run.

When recalling the results of a procedure, the choice of AS FOUND or AS LEFT is provided
(refer to page 36).

35 K415 Issue No. 1

Memory Operations Data Log

Recalling Data Files (DPI 615 instruments only)

Data or results files generated by running procedures are stored in the instrument’s Data
Log directory. To recall a data file to the display, ensure that DATA LOG is selected from
the SETUP menu and proceed as follows:

Use the cursor keys to select either the AS FOUND option or the AS LEFT option for
display. AS FOUND is the result of the first run of a procedure and AS LEFT is the result of
the last time the procedure was run.
Procedure data files can be displayed either as text (stored screens) or in graphical form.
To display as text, select the TEXT option (F1) from the directory and proceed as follows
from the File Summary menu. Select AUTO STEP (F1) to automatically review each screen

at 1 second intervals or use the left or right cursor keys to manually review.

FEEDPRESS11

TASK:P-V
DATA LOG

24V OFF

MANUAL REVIEW

USER ID:
SERIAL No.

RESULTS

MAX PRESS:
POINTS:
MAX. ERROR:

REVIEW

LOGGED DATA

CLIFF
99127007

FAIL

20
5 UP/DOWN

0.1% SPAN

TRANSMIT

FILE

. %span FAIL

AUTO
STEP

DATA POINT

V

bar

5OF10

To transmit the selected logged data via the RS232 interface, connect the instrument to
a free port on an external PC, ensure that the instrument’s RS232 parameters match
those of the PC.

To display logged data in graphical form, on screen, select GRAPH (F2) from the directory
and proceed as follows:

DIRECTORY

AS FOUND

AS LEFT

TEXT

GRAPH

10.007

V

0

15:58:55

FEEDPRESS11

time

16:18:23

K415 Issue No. 1 36

Using Set-up

General

SETUP mode is available in all modes except BASIC and permits the changing of the

following instrument parameters.

• Store Mode - None, Snapshot, Data Log.

•Contrast.

• Settings - Units, Language, RS232 parameters, Powerdown and Calibration Routines
(Refer to page 43 for Calibration details).

• Date and Time (Real Time Clock).

• Backlight Management - On, Off and Timed.

Store Mode

Select STORE MODE from the Set-up menu and select required mode as follows:

SELECTIONNER

OPTION

SETUP

CONFIGURATION
MODE ENREG.
CONTRASTE

PARAMETRAGES

DATE & HEURE
RETROECLAIRAG

NIVEAU PILES

MODE ENREG.

AUCUN

ENREG. RAPIDE

ENREG. DONNEES

Contrast
Select CONTRAST from the Set-up menu and proceed as follows:

37 K415 Issue No. 1

Using Set-up

Settings - Select Setup Option
To select one of the SETTINGS options from the set-up menu, proceed as follows:

SELECTIONNER

OPTION

PARAMETRAGES

UNITES

CALIBRATION

LANGAGE
RS232

ARRET

CALIBRATION

SETUP

CONFIGURATION

MODE ENREG.

CONTRASTE

PARAMETRAGES

DATE & HEURE
RETROECLAIRAG

NIVEAU PILES

Units
Select UNITS from the SETTINGS menu and proceed as follows:

SELECTIONNER

UNITE A

SUPPRIMER

CHOIX UNITES

USUELLES

mbar inHg

bar

Pa

mmH O

hPa

kPa

mPa

mmHg

cmHg

mHg

ENLEVER

kg/cm

kg/m

cmH O

mH O

torr
atm

lb/ft

2

inH2O

2

inH2O

2

inH2O
ftH O

2
2

ftH O
ftH2O

psi

SELECTIONNER

2

4
20

60

4

2

20

2

60

UNITE A

AJOUTER

CHOIX UNITES

USUELLES

mbar

kg/cm

bar

Pa

mmH O

hPa

kPa

cmH O

mPa

mmHg

cmHg

mHg

SELECTIONNER

inHg

kg/m

mH O

torr

atm

psi

lb/ft

2

inH2O

2

inH2O

2

inH2O
ftH O

2
2

ftH O
ftH2O

2

4
20
60

4

2

20

2

60

SELECTIONNER

OPTION

Define Special Units

Select UNITS from the SETTINGS menu and select SPECIAL UNITS and proceed as
follows:

K415 Issue No. 1 38

Using Set-up

Language
Select the LANGUAGE version required from the SETTINGS menu and proceed as follows:

LANGAGE

ANGLAIS

FRANCAIS
ALLEMAND
ITALIEN
PORTUGAIS
ESPAGNOL

SELECTIONNER

OPTION

RS232
Select RS232 from the SETTINGS Menu and proceed as follows:

Note: Communications default settings are shown above.

39 K415 Issue No. 1

Using Set-up

Powerdown
Select POWERDOWN from the SETTINGS menu and proceed as follows:

POWERDOWN

TIMEOUT MODE

OFF

TIMEOUT = 10 Seconds
INSTRUMENT WILL TURN

OFF AFTER TIMEOUT
PERIOD OF INACTIVITY.
ONLY VALID IN TIMER
MODE OF OPERATION

CHANGE

VALUE

POWERDOWN POWERDOWN

TIMEOUT MODE

TIMER

TIMEOUT =

INSTRUMENT WILL TURN
OFF AFTER TIMEOUT
PERIOD OF INACTIVITY.
ONLY VALID IN TIMER
MODE OF OPERATION

CHANGE

VALUE

10 Seconds

SELECT OPTION SELECT PERIOD

POWERDOWN

TIMEOUT MODE

TIMER

TIMEOUT = 10 Seconds

INSTRUMENT WILL TURN
OFF AFTER TIMEOUT
PERIOD OF INACTIVITY.
ONLY VALID IN TIMER
MODE OF OPERATION

CHANGE

VALUE

SELECT VALUE

TIMEOUT MODE

TIMER

TIMEOUT =

INSTRUMENT WILL TURN
OFF AFTER TIMEOUT
PERIOD OF INACTIVITY.
ONLY VALID IN TIMER
MODE OF OPERATION

CHANGE

VALUE

30

If selected to TIMER mode, following a period of inactivity, the instrument automatically
powers off after the preset TIMER period.

If selected OFF, auto power off is inhibited and once switched on, the instrument
remains ON until it is manually switched OFF.

Calibration

Refer to page 43 for a full description of the calibration procedures.

K415 Issue No. 1 40

Using Set-up

Date and Time (Real Time Clock)

Date Format

To set-up the real time clock, select DATE & TIME from the set-up menu and, using the
key, set the required date format:

SELECT OPTION CHANGE FORMAT

SETUP

SETUP

STORE MODE
CONTRAST

SETTINGS

DATE & TIME

FORMAT:

CALIBRATION

DATE:

TIME:

DD/MM/YY

07/08/99
06:20:27

DRY CELL LEVEL

CHANGE DATE
FORMAT

Set Date

Select DATE from the DATE & TIME menu and, using the cursor keys, change the date as
shown below. The up and down keys change the numerical value of the selected
digit (indicated by the underline cursor) and the left and right keys select the
required digit position.

SET DATE

FORMAT:

CALIBRATION

DATE:

TIME:

CHANGE DATE
FORMAT

DD/MM/YY

07/08/99
06:20:27

SELECT OPTION

FORMAT:

DATE:

TIME:

CHANGE DATE

DD/MM/YY

07/08/99
06:20:27

Set Time

Select TIME from the DATE & TIME menu and, using the cursor keys, change the time as
shown below. The up and down keys change the numerical value of the selected
digit (indicated by the underline cursor) and the left and right keys select the
required digit position.

SELECT OPTION

SET TIME

FORMAT:

CALIBRATION

DATE:

TIME:

CHANGE DATE
FORMAT

DD/MM/YY

07/08/99
06:20:27

FORMAT:

DATE:

TIME:

CHANGE TIME

DD/MM/YY

07/08/99
06:20:27

41 K415 Issue No. 1

Using Set-up

Backlight
Select BACKLIGHT from the set-up menu and proceed as follows:

RETROECLAIRAG

MODE OPERATOIRE MODE OPERATOIRE

OFF

DUREE = 10 Seconds

RETRO ECLAIRAGE
SERACOUPE SI
DEPASSEMENT

CHANGER

VALEUR

RETROECLAIRAG

MODE OPERATOIRE

CHRONO

DUREE =

RETRO ECLAIRAGE
SERACOUPE SI
DEPASSEMENT

CHANGER

VALEUR

10

Seconds

SELECTIONNER

OPTION

RETROECLAIRAG

MODE OPERATOIRE

CHRONO

CHANGER

VALEUR

30

DUREE =

RETRO ECLAIRAGE
SERACOUPE SI
DEPASSEMENT

RETROECLAIRAG

CHRONO

DUREE = 10 Seconds

RETRO ECLAIRAGE
SERACOUPE SI
DEPASSEMENT

CHANGER

VALEUR

SELECTIONNER

VALEUR

SELECTIONNER

EXIT

PERIODE

RETROECLAIRAG

MODE OPERATOIRE

CHRONO

DUREE =

RETRO ECLAIRAGE
SERACOUPE SI
DEPASSEMENT

30

SAUVER MODIFICATION ?

OUI

NON

If TIMER mode is selected, any key press switches on the backlight for the TIMER period.

If ON is selected, the backlight remains on permanently and, if OFF is selected, the
backlight remains permanently off.

K415 Issue No. 1 42

Calibration

General

The instrument is supplied by the manufacturer, complete with calibration certificate(s). A
calibration period of 12 months is recommended. The actual calibration interval
depends on instrument usage and the total measurement uncertainty acceptable for the
specified application.

The DPI 610 and DPI 615 are very precise measuring instruments and the test equipment
and conditions of test must be suitable for the type of work. A Class A compensated
deadweight tester must be used. The calibration check and calibration adjustment
should be carried out in a controlled environment by a calibration technician*.

The manufacturer offers a comprehensive and, if required, UKAS or NIST accredited
calibration service.

* A calibration technician must have the necessary technical knowledge,

documentation, special test equipment and tools to carry out the calibration work
on this equipment.

Calibration Check

At the chosen calibration interval, the instrument readings should be compared with a
known pressure standard.
The recommended method starts at 0, increasing in 20% steps to 100% full-scale and
then decreasing in 20% steps to 0.
Note any deviations between the instrument and the pressure standard and consider
traceability (accuracy to a National Standard).
If, after a calibration check, the results exceed the tolerance in the specification (or other
suitable performance standard), carry out a calibration adjustment.

Calibration Adjustment

If the instrument is operating correctly, only zero and full-scale calibration will vary. Any
excessive non-linearity or temperature effects indicate a fault. The instrument should be
returned to a qualified service agent.

Guide to Calibration Procedures

• Use high quality Repeatable and Linear pressure sources and allow adequate

thermal stabilization time before calibration (minimum 1 hour).

• Conduct the calibration in a temperature controlled and preferably, humidity
controlled environment. Recommended temperature is 21°C, ±2°C (70°F, ±4°F).

• Use deadweight testers carefully and away from draughts.

• Review and become familiar with the whole calibration procedure before
commencing the calibration process.

• The calibration routines cannot be accessed when the instrument is in BASIC mode.
Use the TASK key to select another mode (e.g.) ADVANCED before accessing the
CALIBRATION mode.

43 K415 Issue No. 1

Calibration

Test Equipment

The calibration procedures require the following test equipment.

Calibration

Test Equipment and Instrument Parameter/Range

Digital Voltmeter - 5V input ±30 *ppm ±1 digit ±10 *ppm ±5µV

Digital Voltmeter - 50V input ±45 *ppm ±1 digit ±11 *ppm ± 110 µV

Digital milliammeter - 55mA input ±150 *ppm ±4 digit ±100 *ppm ± 1nA

Digital milliammeter - 24mA output ±150 *ppm ±4 digit ±160 *ppm ± 1nA

Precision thermometer - ambient temperature ±0.2°C ± 0.1°C ±1 digit

Deadweight tester - pressure internal/external Class A deadweight <0.025%

Equipment

Accuracy

Calibration

Uncertainty

*ppm = parts per million

Table 1 Internal/External Pressure Transducer Verification

Permissible deviation

Nominal applied value as a% of

±full-scale

0% (10% for absolute ranges) ± 0.025% FS ± 0.05% span

20% ± 0.025% FS ± 0.05% span
40% ± 0.025% FS ± 0.05% span
60% ± 0.025% FS ± 0.05% span
80% ± 0.025% FS ± 0.05% span

100% ± 0.025% FS ± 0.05% span

80% ± 0.025% FS ± 0.05% span
60% ± 0.025% FS ± 0.05% span
40% ± 0.025% FS ± 0.05% span
20% ± 0.025% FS ± 0.05% span

0% (10% for absolute ranges) ± 0.025% FS ± 0.05% span

PC*, HC* and Indicator

Versions

LP* Versions and

external LPE 9400

sensors

PC* = Pressure Calibrator HC* = Hydraulic Calibrator LP* = Low Pressure Calibrator

K415 Issue No. 1 44

Calibration

Using the Calibration Menu

The calibration routines are selected from the Settings menu as detailed on page 38.
Enter the calibration PIN number, initially set to 4321, press and the display shows
the Calibration Menu.

PIN security

To prevent unauthorised access, it is recommended that the PIN number be changed as
soon as possible.

CALIBRATION

INT RANGES
EXT SENSORS

CHANGE PIN

Change PIN

To change the PIN code, select CHANGE PIN from the calibration menu and proceed as
follows:

Note: To set and verify a new PIN, the new PIN code must be entered twice.

SELECT OPTION

SET NEW PIN AGAIN

Vvt

Enter New PIN

5432

SET NEW PIN

Enter New PIN

• If the second code entered differs from the first, the new PIN will not be set.

ATTENTION

CODE NON VALIDE

Calibrate Internal Ranges

CALIBRATION

GAMMES INTER

CAPTEURS EXT
MODIFIE CODE

SELECTIONNE

OPTION CAL

Select the INT RANGES from the menu as shown above and follow the calibration
procedure on the display.

45 K415 Issue No. 1

Calibration

Internal Pressure Range

Use the following procedure for calibrating the internal pressure range.

Note: If calibrating the hydraulic calibrator version, the calibrator must first be primed as

detailed on pages 59 to 66.

(1) Connect the outlet port of the instrument to a pressure standard.
(2) Allow the instrument’s temperature to stabilize for a minimum of 1 hour.
(3) Switch the instrument on, enter CALIBRATION mode and select INT RANGES from

the CALIBRATION menu and then PRESSURE INT.

VOLTAGE IN

(4) Apply zero pressure and store the zero point:

CALIBRE PRESSION INT
GAMME 20.000 bar g

Memoriser point PE ?

OUI NON

CALIBRE PRESSION INT

GAMME 20.000 bar g

m = 2.784670e-04
c = -1.459980e+02

Applique Mesure

0.0000 524293

20.000 704637

RESULTATS

Calibration Terminee

App ENTER pour continuer

(5) Close the vent valve, apply full-scale pressure and store the full-scale point:

(6) Press the ENTER key to accept the calibration. Press the EXIT key four times to

quit CALIBRATION and SETUP modes.

(7) Check calibration by applying test pressures in Table 1, page 44.

K415 Issue No. 1 46

Calibration

Voltage Input Range (5 Volts)

Use the following procedure for calibrating the internal 5 Volt range.
(1) Switch the instrument on, enter CALIBRATION mode and select INT RANGES from

the CALIBRATION menu as shown on page 45.

(2) Select 5V range for calibration:

CALIBRATION

PRESSION INT

TENSION

ENTR. COURANT
SORT. COURANT
TEMPERATURE

SELECTIONNER

OPTION CAL

SELECT. GAMME

5 VOLTS

50 VOLTS

(3) Link the voltage input terminals with a short lead and enter the zero point:

SELECTIONNER

OPTION CAL

(4) Remove the shorting link from the voltmeter terminals, connect the Vin terminals

of the instrument to a variable voltage source and connect a digital voltmeter
across the source:

47 K415 Issue No. 1

Calibration

(5) Set the variable supply voltage to 5V ± 0.1V and enter the measured full-scale

voltage applied:

(6) Press the ENTER key to accept the calibration. Press the EXIT key once to return

to the calibration menu or four times to quit the CALIBRATION and SETUP modes.

(7) Verify the instrument calibration by applying the test voltages given in Table 2

(page 50), to the voltmeter (after both voltage ranges have been calibrated).

(8) Disconnect the calibration/test equipment.

K415 Issue No. 1 48

Calibration

Voltage Input Range (50 Volts)

Use the following procedure for calibrating the internal 50 Volt range.
(1) Switch the instrument on, enter CALIBRATION mode and select INT RANGES from

the CALIBRATION menu as shown on Page 45.

(2) Select 50V range for calibration:

(3) Link the voltage input terminals with a short lead and enter the zero point:

(4) Remove the shorting link from the voltmeter terminals, connect the Vin terminals

of the instrument to a variable voltage source and connect a digital voltmeter
across the source:

49 K415 Issue No. 1

Calibration

(5) Set the variable supply voltage to 50V ± 0.1V and enter the measured full-scale

voltage:

REGLER VALEUR

CALIBRE TENSION

GAMME +/- 50V

Appliquer PE nominale

App sur ENTER quand
la valeur est stable

CALIBRE TENSION

GAMME +/- 50V

Entrer val appliquee:

CHANGER

VALEUR

CALIBRE TENSION

GAMME +/- 50V

Memoriser point PE ?

OUI NON

DEMARRER

CALIBRE TENSION

GAMME +/- 50V

RESULTATS

m = 1.395879e-05
c = -7.128004e+00

Applique Mesure

0.0000 526380

49.984 873988

Calibration Terminee

App ENTER pour continuer

CALIBRE TENSION

GAMME +/- 50V

Enter val appliquee:

CHANGER

VALEUR

DEMARRER

(6) Press the ENTER key to accept the calibration. Press the EXIT key four times to

quit the CALIBRATION and SETUP modes.

(7) Verify the instrument calibration by applying the test voltages given in Table 2 to

the voltmeter (after both voltage ranges have been calibrated).

(8) Disconnect the calibration/test equipment.

Voltage Calibration 50V Range Verification Tolerances Voltage Calibration 5V Range Verification Tolerances

Applied Voltage Permissible Deviation Applied Voltage Permissible Deviation

-50 ± 0.05% rdg, ± 0.004% FS -5 ± 0.05% rdg, ± 0.004% FS

-40 ± 0.05% rdg, ± 0.004% FS -4 ± 0.05% rdg, ± 0.004% FS

-30 ± 0.05% rdg, ± 0.004% FS -3 ± 0.05% rdg, ± 0.004% FS

-20 ± 0.05% rdg, ± 0.004% FS -2 ± 0.05% rdg, ± 0.004% FS

-10 ± 0.05% rdg, ± 0.004% FS -1 ± 0.05% rdg, ± 0.004% FS
0 ± 0.05% rdg, ± 0.004% FS 0 ± 0.05% rdg, ± 0.004% FS

10 ± 0.05% rdg, ± 0.004% FS 1 ± 0.05% rdg, ± 0.004% FS
20 ± 0.05% rdg, ± 0.004% FS 2 ± 0.05% rdg, ± 0.004% FS
30 ± 0.05% rdg, ± 0.004% FS 3 ± 0.05% rdg, ± 0.004% FS
40 ± 0.05% rdg, ± 0.004% FS 4 ± 0.05% rdg, ± 0.004% FS
50 ± 0.05% rdg, ± 0.004% FS 5 ± 0.05% rdg, ± 0.004% FS

Table 2 Electrical Voltage Input Calibration Tolerances

K415 Issue No. 1 50

Calibration

Current Input Range (55 mA)

Use the following procedure for calibrating the current input range.
(1) Switch the instrument on, enter CALIBRATION mode and select INT RANGES from

the CALIBRATION menu as shown on Page 45.

(2) Select CURRENT IN range for calibration:

(3) Open circuit the mA in terminals and enter the zero point:

(4) Connect the mA in terminals of the instrument to a variable current source and

connect a digital milliammeter in series with the supply:

MILLIAMPEREMETRE

51 K415 Issue No. 1

Calibration

(5) Set the input current to 55 ± 0.1mA and enter the measured full-scale input

current:

(6) Press the ENTER key to accept the calibration. Press the EXIT key four times to

quit the CALIBRATION and SETUP modes.

(7) Verify the instrument calibration by applying the test currents given in Table 3 to

the milliammeter.

(8) Disconnect the calibration/test equipment.

Current Calibration, 55mA Range Verification Tolerances

Applied Current (mA) Permissible Deviation

-55 ± 0.05% rdg ± 0.004% FS

-45 ± 0.05% rdg ± 0.004% FS

-35 ± 0.05% rdg ± 0.004% FS

-25 ± 0.05% rdg ± 0.004% FS

-15 ± 0.05% rdg ± 0.004% FS

-5 ± 0.05% rdg ± 0.004% FS
0 ± 0.05% rdg ± 0.004% FS
5 ± 0.05% rdg ± 0.004% FS

15 ± 0.05% rdg ± 0.004% FS
25 ± 0.05% rdg ± 0.004% FS
35 ± 0.05% rdg ± 0.004% FS
45 ± 0.05% rdg ± 0.004% FS
55 ± 0.05% rdg ± 0.004% FS

Table 3 Electrical Current Input Calibration Tolerances

K415 Issue No. 1 52

Calibration

Current Output Range (24 mA)

Use the following procedure for calibrating the current output range.

(1) Switch the instrument on, enter CALIBRATION mode and select INT RANGES from

the CALIBRATION MENU as shown on page 45.

(2) Select CURRENT OUT range for calibration:

(3) Connect a digital milliammeter to the instrument as shown below.

Note: On standard instruments, during a current out calibration routine, the 24V

dc output is automatically turned on.

mA

53 K415 Issue No. 1

Calibration

(4) Measure the 10% full-scale output current and enter the value measured on the

external milliammeter:

(5) Measure the 90% full-scale output current and enter the value measured on the

external milliammeter

Store Cal point?

YES NO

Measure 90% FS - output

Press ENTER key when
applied value is stable

Enter Measured Current:

:

RUN

(6) Press the ENTER key to accept the calibration. Press the EXIT key four times to

quit the CALIBRATION and SETUP modes.

(7) Verify the instrument’s output current calibration by setting up the loop test

currents as shown in Table 4 and checking the set values against the
milliammeter standard.

(8) Press the OUTPUT key, select 24 VOLT and turn the 24V supply to ON. Proceed as

follows:

K415 Issue No. 1 54

Calibration

(9) Set the loop output current to 5 mA as shown below and check that the output

current, measured on the milliammeter standard is within the limits given in
Table 4.

(10) Repeat (9) for all output values given in Table 4.

Current Output Calibration, 24mA Range Verification

Tolerances

Applied Current (mA) Permissible Deviation

0 ± 0.05% rdg ± 0.01% FS
5 ± 0.05% rdg ± 0.01% FS

10 ± 0.05% rdg ± 0.01% FS
15 ± 0.05% rdg ± 0.01% FS
20 ± 0.05% rdg ± 0.01% FS
24 ± 0.05% rdg ± 0.01% FS
20 ± 0.05% rdg ± 0.01% FS
15 ± 0.05% rdg ± 0.01% FS
10 ± 0.05% rdg ± 0.01% FS

5 ± 0.05% rdg ± 0.01% FS
0 ± 0.05% rdg ± 0.01% FS

Table 4 Electrical Current Output Calibration Tolerances

(11) Disconnect the calibration/test equipment.

55 K415 Issue No. 1

Calibration

Ambient Temperature Channel

Use the following procedure for calibrating the ambient temperature measurement
channel.
(1) Switch the instrument on, enter the CALIBRATION mode and select

TEMPERATURE:

(2) Allow the instrument’s temperature to stabilize in the calibration environment for

at least one hour.

(3) Read the environmental temperature on a calibrated digital thermometer and

enter the recorded value as shown below. Example shown for a measured
ambient temperature of 21.5° Celsius.

Note: Only one temperature point is required.

CALIBRE TEMP AIR

-10 à 40°C

Entrer val appliquee:

CALIBRE TEMP AIR

-10 à 40°C

Entrer val appliquee:

+

CHANGER

VALEUR

CALIBRE TEMP AIR

-10 à 40°C

Etalonnage Accepte ?

OUI NON

DEMARRER

CHANGER

VALEUR

CALIBRE TEMP AIR

-10 à 40°C

RESULTATS

m = 2.49000e-04
c = -1.359980e+02

Applique Mesure

21.5 623298

Calibration Terminee

App ENTER pour continuer

CHANGER VALEUR

(4) Press the ENTER key to accept the calibration. Press the EXIT key once to return

to the calibration menu or four times to quit the CALIBRATION and SETUP modes.

K415 Issue No. 1 56

Calibration

Calibrate External Sensors

Use the following procedure for calibrating external pressure sensors.

(1) Connect the required external transducer to the EXT TRANSDUCER socket located

on the rear of the instrument.

(2) Allow the instrument’s temperature and the temperature of the external

transducer to stabilize in the calibration environment for a minimum of 1 hour.

(3) Switch the instrument on, enter CALIBRATION mode and select EXT SENSORS

from the CALIBRATION menu:

INT RANGES

EXT SENSORS

CHANGE PIN

(4) Select the transducer to be calibrated from the transducer menu using the

cursor keys and press ENTER:

If the sensor to be calibrated is not in the directory, or no sensors are listed in the
directory, press the F1 key (ADD NEW SENSOR). This will place the sensor in the
directory, allowing it to then be selected.

(5) Connect the pressure standard to the inlet of the external transducer, apply the

zero point pressure and store the zero point:

CAPTEURS EXT

N/S GAMME

bar

TYPE

CAPTEURS EXT CAPTEURS EXT

N/S GAMME

1154737 20.000 9

bar

TYPE

N/S GAMME

1154737 20.000 9

bar

TYPE

AJOUTER

NOUVEAU CAPT.

AJOUTER

NOUVEAU CAPT.

57 K415 Issue No. 1

EDITION

ENLEVER

MODIFIER

DETAILS

(6) Apply the full-scale pressure to the external transducer and store the full-scale

(FS) point.

CHANGE VALUE

CALIBRATING PRESSURE EXT

RANGE 20000 kPa g

Apply nominal FS value

Press ENTER key when
applied value is stable

CALIBRATING PRESSURE EXT

RANGE 20000 kPa g

CALIBRATING PRESSURE EXT

RANGE 20000 kPa g

+

(7) Release the applied pressure and disconnect the pressure reference. Press the

ENTER key to accept the calibration. Press the EXIT key once to return to the
calibration menu or four times to quit the CALIBRATION and SETUP modes.

(8) Check the calibration of the external transducer by applying the test pressures as

detailed in Table 1, page 44.

Add External Sensor

To add an external sensor to the directory of external sensors, proceed as follows:

• Connect the required external transducer to the EXT TRANSDUCER socket
located on the rear of the instrument.

Digitally compensated transducers will be downloaded into the directory as soon as the
F1 key is operated. Data for other types can be edited by selecting EDIT (F2). If the data
cannot be edited a warning message (INVALID ACTION) is displayed.

K415 Issue No. 1 58

Hydraulic Calibrator Versions

59 K415 Issue No. 1

This page intentionally left blank

K415 Issue No. 1 60

Hydraulic Calibrator Versions Operation

Introduction (Figure A1)

These versions of the DPI 610 and DPI 615 Calibrators provide manual generation of
hydraulic pressure and consist of a screw-press with a priming pump and isolation valve.

7

6

5

2

4

5

1

3

1 Isolation valve 2 Priming port 3 Bleed hose assembly 4 Priming pump
5 Screw-press 6 Bonded seal 7 UUT/system under test

Figure A1 - DPI 610/615 HC Connections

The internal hydraulic parts are brass, stainless steel, copper, nylon and fluorocarbon
rubber (Viton). The hydraulic fluid can be either demineralized water or one of the
hydraulic fluids listed below:

Caution: Only use the recommended hydraulic fluids.

DO NOT mix hydraulic fluids.

ISO 3448

Viscosity

grade

VG10 5W Tellus R10 Nuto H10 Velocite No. 6
VG15 Tellus T15

VG22 Tellus 22

VG32 10W Tellus V32 Nuto H32 DTE Oil Light

VG37 Tellus 37

Approx. SAE

Viscosity

Classification

Shell

Tellus V15

Tellus R22

Tellus R37

Tellus T37

Tellus V37

Esso

(Exxon)

Nuto H15

Nuto H22 DTE 22

Mobil

DTE 24

Table A1 - Recommended Hydraulic Fluids

61 K415 Issue No. 1

Hydraulic Calibrator Versions Operation

Safety Instructions
WARNING
HYDRAULIC FLUID IS INJURIOUS. OBSERVE RELEVANT HEALTH AND SAFETY

PRECAUTIONS. USE APPROPRIATE PROTECTIVE BARRIERS AND EYE
PROTECTION.

BEFORE APPLYING PRESSURE, EXAMINE ALL FITTINGS AND EQUIPMENT FOR
DAMAGE AND ENSURE THAT ALL EQUIPMENT IS TO THE CORRECT PRESSURE
RATING.

DO NOT EXCEED THE MAXIMUM WORKING PRESSURE OF THE INSTRUMENT
(INDICATED ON START-UP SCREEN AT SWITCH-ON).

Caution: Observe absolute cleanliness when using the instrument.

Severe damage can be caused if equipment connected to this
instrument is contaminated. Connect only clean equipment to
the instrument. To avoid any contamination, an external filter
is recommended.

Preparation for Use (Figure A1)

• Use an appropriate seal and connect the bleed hose assembly (3) to the priming port.

• Make sure that the screw-press (5) is wound fully in (clockwise).

• Make sure that the isolation valve (1) is open (fully counter clockwise).

• Use a bonded seal (6) and connect the unit or system under test (7) to the pressure
port.

WARNING

MAKE SURE THAT THE CONNECTING LINE TO THE EXTERNAL DEVICE OR
SYSTEM IS CAPABLE OF WITHSTANDING THE LINE PRESSURE TO BE APPLIED.

Note: A bleed point must be provided on the external device.

K415 Issue No. 1 62

Hydraulic Calibrator Versions Operation

4

1

3

2

1 Bleed hose assembly 2 Priming pump 3 Screw-press
4 UUT/system under test 5 UUT bleed valve 6 Isolation valve
O - Open C - Closed

Figure A2 - Priming/Test Set-up

Bleeding the System (Figure A2)

Before any measurements can be made, the hydraulic system needs to be primed and
bled free of air. During the following operations, prepare for fluid spillage and provide a
suitable receptacle for collecting the spillage.

1. Prepare for use as detailed on page 62.

2. Fill a suitable container with clean hydraulic fluid and place the bleed hose assembly

(1) connected to the priming port into the fluid.

3. Open the UUT bleed valve (5) and, if possible, fit a hose to the bleed point and locate

the hose end in a container of the same hydraulic fluid.

4. Use the priming pump (2), to pump hydraulic fluid into the instrument and the

connected system. Monitor the hydraulic fluid level, ensuring that the bleed hose
assembly (1) stays below the fluid level and is not allowed to suck in air. Top-up
hydraulic fluid level as necessary.

63 K415 Issue No. 1

Hydraulic Calibrator Versions Operation

5. Continue use of the priming pump (2) until only hydraulic fluid and no air is expelled

from the bleed point.

6. Close the UUT bleed valve (5) when the priming pump (2) is at the bottom of its stroke

(fully pushed in) and slowly wind out the screw-press (3) to its fullest extent to draw

3

in further hydraulic fluid (approx. 7cc or 0.43 in

7. Switch the instrument ON and, still using the priming pump (2), pressurize the

system to approximately 2 bar (30 psi).

8. Close the isolation valve (6) disconnect the bleed hose assembly (1) from the priming

port.

Operation

To obtain a pressure reading, proceed as follows.

1. Switch the instrument ON and select the required TASK.

2. Rotate the screw-press clockwise to increase the applied pressure.

).

Note: When hydraulic fluid is compressed and flows through a restriction, there is an

increase in temperature that affects the pressure. Allow sufficient time for this
pressure reading to stabilize before recording or logging a reading.

3. After testing, reduce the pressure in the system to zero by turning the screw-press

counter clockwise. Before disconnecting the UUT, open the isolation valve.

4. Remove the connection to the UUT and fit a blanking plug into the instrument’s

pressure port. Clean any spilt fluid off the instrument case.

Draining the Hydraulic Fluid (Figure A3)

To drain the hydraulic fluid from the instrument, proceed as follows:

1. Turn the isolation valve (4) fully counter clockwise. Turn the instrument onto the left

hand side (pressure port nearest to the work bench). Place receptacle below the
pressure port to collect hydraulic fluid.

2. Drain the system by slowly winding in the screw-press (3) and then depressing the

priming pump (2) plunger to expel any fluid remaining in the instrument.

3. If necessary, apply an air line to the priming port to clear any remaining fluid out of

the instrument.

K415 Issue No. 1 64

Hydraulic Calibrator Versions Operation

Flushing - Replenishing or Changing the Hydraulic Fluid (Figure A3)

If necessary, to remove any contaminants, flush out the hydraulic system as follows.

a. Connect the bleed hose assembly (1) to the priming port and a bleed hose to the

pressure port as shown below:

4

1

3

2

1 Bleed hose assembly 2 Priming pump 3 Screw-press 4 Isolation valve
O - Open C - Closed

Figure A3 - Flushing/Filling Connections

b. Fill the priming fluid container with clean hydraulic fluid of the required type. Use

the priming pump (2), to pump fresh hydraulic fluid through the system until clean
hydraulic fluid, free of air bubbles, emerges into the container at the output port.
Discard the contaminated fluid expelled during this process.

c. Remove the bleed hose assembly (1) located to the output port and, to prevent

the ingress of any contaminant, fit a blanking plug in its place.

d. Close the isolation valve (4) and remove the bleed hose assembly (1) from the

priming inlet.

e. Clean off any surplus oil that may have spilled onto the instrument casing.

The instrument is now ready for operation or storage. If storing, apply a label detailing
the type of hydraulic fluid contained in the instrument. For long term storage, it is

recommended that the instrument be drained and stored empty.

65 K415 Issue No. 1

This page intentionally left blank

K415 Issue No. 1 66

Low Pressure Calibrator

Versions

67 K415 Issue No. 1

This page intentionally left blank

K415 Issue No. 1 68

Low Pressure Calibrator Versions

Introduction (Figure B1)

These versions of the DPI 610 and DPI 615 Calibrator measure and display low
differential pneumatic pressures applied to the pressure port. The differential pressure
measurement ranges can be: 2.5, 12.5, 25, 50, 75 or 150 mbar (1.0, 5.0, 10.0, 20.0, 30.0
and 60.0 inH

For low volume external systems or devices, test pressures are generated by an integral
two-stage (coarse/fine) volume adjuster. For larger volume external systems or devices,
test pressures are generated by an external, hand-operated, pneumatic pump.
An internal pressure limiter operates at 120% of the full-scale, positive or negative test
pressure. If this over-pressure remains for more than approximately 1 second, a valve
within the calibrator opens, directly connecting the positive and negative pressure ports
together, to release the excess pressure. When the pressure decreases to within the
operational limits, the valve automatically closes to allow normal operation to restart.

This section should be read in conjunction with the operation and calibration sections of
this manual. All the operational features described for the standard calibrator are
available on this low pressure version of the calibrator.

O).

2

1

6

2

5

3

4

1 Control panel 2 Vent valve 3 Positive pressure output port
4 Volume adjuster (fine) 5 Volume adjuster (coarse) 6 Reference port

Figure B1 - Calibrator Controls

69 K415 Issue No. 1

Preparation for Use Low Volume Systems

Caution: This calibrator can produce a maximum differential pressure of 120%

full-scale. Make sure any component connected to this calibrator can
withstand this maximum differential pressure.

 Use the TASK key to set-up the calibrator for an appropriate test:

Example:

P-DISPLAY.

 To record test data for other tasks, set-up the calibrator to either Data log or

Snapshot as required, refer to pages 30 or 31.

 Fit an appropriate pressure fitting to both the positive (+) and negative (-) ports

using a bonded seal as shown in Figure B2. Ensure that both fittings are tight.

 To generate pressure, start with the volume adjuster wound fully out.

To generate vacuum, start with the volume adjuster wound fully in.

 Ensure that the vent valve is open (fully counter-clockwise).

 Connect the device or system under test to both the reference (-) and the

pressure port (+). Connect the ribbed arm of the double tubing to the high (+)
pressure input of the device under test.

Note: To minimize temperature effects, always use double tubing, separating the
arms of the tubing only by the minimum amount necessary to make the pressure
connections. A typical application, P-DISPLAY, showing test connections to a
Magnehelic pressure gauge are shown in Figure B2.

Method of Testing with Low Volume Systems



Connect the device under test to the calibrator and prepare for test as detailed
above.

 Close the vent valve (turn fully clockwise).

 Zero the calibrator by pressing the ZERO key as in the sequence below:

TASK: P-DISPLAY

DISPLAY

24V OFF

TASK: P-DISPLAY

ZERO

DISPLAY

24V OFF

TASK: P-DISPLAY

DISPLAY

24V OFF

CHANGE

VALUE

K415 Issue No. 1 70

mbar

ZERO INTERNAL SENSOR ?

mbar

YES

NO

PLEASE WAIT . . .

mbar

Low Pressure Calibrator Versions

C- Closed O- Open

Figure B2 - Test Connections

71 K415 Issue No. 1

Method of Testing with Low Volume Systems (continued)

 Turn the volume adjuster coarse control clockwise (counter-clockwise for

vacuum) to set-up the required test pressure. Use the volume adjuster fine
control to adjust the test pressure of the calibrator to exactly the required value.

 Use the TASK key to set-up the calibrator for an appropriate test:

Example:

P-DISPLAY

 To record test data for other tasks, set-up the calibrator to either Data log or

Snapshot as required (refer to pages 30 or 31). If required, and for DPI 615
calibrators only, switch on Cal Mode (refer to pages 11, 34 and 35).

 Turn the volume adjuster clockwise to set-up any additional test pressures

required. The recommended method starts at 0, increasing to 10%, 25%, 50%,
75% and 100% full-scale and then decreasing to 75%, 50%, 25%, 10% and 0.

Note: To release the output pressure at any point during a test or series of tests,

open the vent valve. Allow sufficient time for the connected system to vent
(very important when connected to larger system volumes, >0.25 litres [15
cubic inches]).

Preparation for Use with Larger Volume Systems

 Set-up the calibrator to record the test data, using either Data log or Snapshot

facilities refer to pages 30 or 31. If required, and for DPI 615 calibrators only,
switch on Cal Mode (refer to pages 11, 34 and 35).

 Fit the appropriate pressure fitting to both the positive (+) and negative (-) ports

using a bonded seal as shown in Figure B3. Make sure that both pressure fittings
are tight.

 Turn the volume adjuster (counter-clockwise) to approximately half-way

(approximately 30mm (1”) of thread showing).

 Make sure that the vent valve is open (fully counter-clockwise).

 Connect the hand-pump and tee-piece as shown in Figure B3. Connect the

device or system under test to both the reference (-) and the pressure port (+) as
shown. Connect the ribbed arm of the double tubing to the high (+) pressure input
of the device under test.

Note: To minimize temperature effects, always use double tubing, separating the

arms of the tubing only by the minimum amount necessary to make the
pressure connections. See Figure B3.

K415 Issue No. 1 72

Low Pressure Calibrator Versions

1

+

.

1 - To device/system under test C - Closed
2 - Tee-piece inserted in positive output line O - Open

2

Figure B3 - Hand-pump Connections

73 K415 Issue No. 1

Method of Testing with Larger Volume Systems

 Connect the device or external system under test to the calibrator and prepare

for test as detailed on Page 72.

Note: To apply a negative differential pressure, connect the tee piece (refer to

Figure B3), to the negative port and use the hand-pump to apply a positive
pressure to the negative port.

 Close the vent valve (turn fully clockwise).

 Zero the calibrator by pressing the ZERO key as in the sequence below:

TASK: P-DISPLAY

DISPLAY

CHANGE

VALUE

24V OFF

mbar

ZERO

TASK: P-DISPLAY

DISPLAY

ZERO INTERNAL SENSOR ?

YES

24V OFF

mbar

NO

TASK: P-DISPLAY

DISPLAY

PLEASE WAIT . . .

24V OFF

mbar

CAUTION:TO AVOID THE APPLICATION OF TRANSIENT OVER-PRESSURE PULSES TO

SENSITIVE EXTERNAL SYSTEMS, SQUEEZE THE HAND-PUMP SLOWLY.

 Close the pump valve and operate the hand-pump to pressurize or depressurize

the device or system under test to just above/below the required level.

 Adjust the output pressure to the required level by using the volume adjuster as a

fine adjustment. Allow a short period for the pressure to stabilize before fine
trimming.

Note: The larger the external volume, the less effect the volume adjuster will have

on the output pressure.

 Record the test result using either data log or snapshot facility as required.

 Use the pump and volume adjuster to set-up any additional test pressures

required. The recommended method starts at 0, increasing to 10%, 25%, 50%,
75% and 100% full-scale and then decreasing to 75%, 50%, 25%, 10% and 0.
Record the results for each test pressure.

Note: To release the output pressure at any point during a test or series of tests,

open the vent valve. Allow a few seconds for the connected system to vent.
With larger volume systems connected, first disconnect both the reference
and positive pressure lines from the calibrator and then reconnect before
zeroing.

K415 Issue No. 1 74

Low Pressure Calibrator Versions

Calibration

The calibration routines for the DPI 610 and DPI 615 Low Pressure calibrators are as
described in calibration page 43, with the exception of the internal pressure range. The
calibration procedure for the internal pressure range requires the application of five test
pressures as detailed below.

Note: Refer to page 43 for the general procedures of calibrating the instrument. Refer to

Table 1, page 44 for the transducer verification.

Calibrate Internal Pressure Range

To calibrate the internal pressure range:

 Connect the outlet port of the instrument to a pressure standard.

 Switch the instrument ON.

 Allow at least one hour for the temperature of the instrument to stabilize.

 Select SETUP and enter the SETTINGS menu.

Note: SETUP cannot be selected from BASIC mode.

 Select CALIBRATION from the SETTINGS menu and enter the calibration PIN

number (refer to page 45 for PIN number details).

 Select PRESSURE INT from the CALIBRATION menu (refer to page 46).

 Apply negative full-scale pressure to the instrument. Store the negative full-scale

point:

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

Appliquer valeur -ve PE

App sur ENTER quand la

la valeur est stable

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

Entrer val appliquee:

CHANGER

VALEUR

REGLER VALEUR

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

Valider point -ve P.E.?

OUI

NON

 Apply negative, half full-scale pressure to the instrument and store the negative

half full-scale point:

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

Appliquer 50% valeur -ve

App sur ENTER quand la

la valeur est stable

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

Entrer val appliquee:

REGLER VALEUR

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

CHANGER

VALEUR

Valider 50% point -ve?

OUI

75 K415 Issue No. 1

NON

 Apply a nominal zero pressure to the instrument and store the zero point:

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

REGLER VALEUR

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

Appliquer zero nominale

App sur ENTER quand la

la valeur est stable

Entrer val appliquee:

CHANGER

VALEUR

Memoriser point ?zero

OUI

NON

 Apply the positive, half full-scale pressure to the instrument and store the

positive, half full-scale point:

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

Appliquer 50% valeur +ve

App sur ENTER quand la

la valeur est stable

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

Entrer val appliquee:

CHANGER

VALEUR

REGLER VALEUR

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

Valider 50% point +ve?

OUI

NON

 Apply positive full-scale pressure to the instrument and store the full-scale point:

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

Appliquer PE nominale

App sur ENTER quand la

la valeur est stable

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

Entrer val appliquee:

REGLER VALEUR

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

CHANGER

VALEUR

Memoriser point P.E.?

OUI

NON

 After application of the final calibration pressure, the calibration results are

displayed as shown below. To view the second page of calibration data press
MORE (F1). Press ENTER to complete the pressure calibration procedure.

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

a= 1.47115e-14
b= -7.546076e-06
c= 3.808651e+00
Applique Mesure

-2.5000 865995

-1.2500 694638

0.0000 523166

POURSUIVRE POURSUIVRE

RESULTATS

Calibration Terminee

App ENTER pour continuer

CALIBRE PRESSION INT

GAMME 2.5000 mbar L

a= 1.632719e-13
b= -7.546076e-06
c= 3.915159e+00
Applique Mesure

0.0000 523166

1.2500 354205

2.5000 182699

RESULTATS

Calibration Terminee

App ENTER pour continuer

K415 Issue No. 1 76

Appendix 1

DATA LOG FILE EXAMPLE

77 K415 Issue No. 1

This page intentionally blank

K415 Issue No. 1 78

Typical Uploaded Data log File (DPI 610)

The following gives details of a typical data file upload.

FILENAME: TEST 5
DATE: 05/11/1999
TIME: 15:58
TRIGGER: KEYPRESS
AMBIENT TEMP : 24.1 C

NO. OF POINTS 11
RECORD TYPE 0
CURRENT mA PRESSURE INT bar

3.902 0.008 -0.65 %span 05/11/1999 15:58:55

6.076 2.311 1.42 %span 05/11/1999 16:00:03

7.598 4.404 0.47 %span 05/11/1999 16:00:57

8.085 5.023 0.41 %span 05/11/1999 16:01:45

9.949 7.249 0.94 %span 05/11/1999 16:02:42

13.002 11.300 -0.23 %span 05/11/1999 16:03:30

17.005 16.102 0.77 %span 05/11/1999 16:05:00

17.766 17.106 0.51 %span 05/11/1999 16:06:07

17.812 17.105 0.80 %span 05/11/1999 16:07:49

18.532 17.965 1.00 %span 05/11/1999 16:16:35

20.007 20.212 -1.02 %span 05/11/1999 16:18:23

The Record Type number contained in the header is a 16-bit field, with the individual bits
representing result formats as detailed below.
Record Type 1 P-Display
Record Type 2 Switch Test
Record Type 4 Leak Test
Record Type 8 Input channel: Min/Max ON
Record Type 120 Combination of all input process functions
Record Type 896 Combination of all output process functions
Record Type 1024 mA step mode
Record Type 2048 mA value mode
Record Type 4096 mA ramp mode
Record Type 8192 no input selected
Record Type 16384 no output selected

79 K415 Issue No. 1

Typical Uploaded Procedure Data File (DPI 615)

The following gives details of a typical data file upload.

FILENAME: TEST 6
DATE: 05/11/1999
TIME: 15:58
TRIGGER: KEYPRESS
AMBIENT TEMP : 24.1 C

NO. OF POINTS 11
RECORD TYPE 0
CURRENT mA PRESSURE INT bar

3.902 0.008 -0.65 %span PASS 05/11/1999 15:58:55

6.076 2.311 1.42 %span FAIL 05/11/1999 16:00:03

7.598 4.404 0.47 %span PASS 05/11/1999 16:00:57

8.085 5.023 0.41 %span PASS 05/11/1999 16:01:45

9.949 7.249 0.94 %span PASS 05/11/1999 16:02:42

13.002 11.300 -0.23 %span PASS 05/11/1999 16:03:30

17.005 16.102 0.77 %span PASS 05/11/1999 16:05:00

17.766 17.106 0.51 %span PASS 05/11/1999 16:06:07

17.812 17.105 0.80 %span PASS 05/11/1999 16:07:49

18.532 17.965 1.00 %span PASS 05/11/1999 16:16:35

20.007 20.212 -1.02 %span FAIL 05/11/1999 16:18:23

The Record Type number contained in the header is a 16-bit field, with the individual bits
representing result formats as detailed below.
Record Type 1 P-Display
Record Type 2 Switch Test
Record Type 4 Leak Test
Record Type 8 Input channel: Min/Max ON
Record Type 120 Combination of all input process functions
Record Type 896 Combination of all output process functions
Record Type 1024 mA step mode
Record Type 2048 mA value mode
Record Type 4096 mA ramp mode
Record Type 8192 no input selected
Record Type 16384 no output selected

K415 Issue No. 1 80
