GE Industrial
Sensing
Druck DPI 104
Digital pressure indicator
User manual - K394
99 Washington Street
Melrose, MA 02176
Fax 781-665-0780
TestEquipmentDepot.com
A1.1 A1.2
1
A2
2
3
6
5
4
A1.3
B1
B2
7
8
9
10
A2
13 11
14
15
12
16
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
FAX 781.665.0780 - TestEquipmentDepot.com
Table of Contents
Introduction ......................................................................... 1
Safety .................................................................................... 1
Marks and symbols on the DPI 104 ....................................... 1
To Start ................................................................................. 2
Location of items ........................................................................... 2
Items on the display ..................................................................... 2
Prepare the instrument ............................................................... 2
Power on or off ................................................................................ 2
Menu operation ............................................................................... 3
Installation ........................................................................... 4
Battery .................................................................................................. 4
Position ................................................................................................ 4
Pressure connections ................................................................... 4
Electrical connections .................................................................. 4
Operation ............................................................................. 5
Menu: Set units ................................................................................ 5
Menu: Set tare .................................................................................. 5
Menu: Monitor maximum/minimum ..................................... 5
Menu: Monitor a pressure switch ............................................ 6
Menu: Calibration ........................................................................... 6
Menu: Set low/high alarm .......................................................... 6
Menu: Supply voltage output (Vout) ...................................... 6
Menu: Set Vout scale factor ...................................................... 7
Menu: Set automatic power OFF ............................................. 7
Menu: Set lock code ....................................................................... 7
Menu: Set scan rate ....................................................................... 7
Menu: Monitor external IDOS .................................................... 7
Menu: Set FSO low/high registers ........................................... 8
Set up a DPI 104 network ........................................................... 8
Error indications .............................................................................. 8
Maintenance ........................................................................ 9
Replace the batteries .................................................................... 9
Restore the original configuration .......................................... 9
Calibration ............................................................................ 9
Equipment and conditions ......................................................... 9
Procedures ......................................................................................... 9
Specification data ............................................................. 11
General ............................................................................................. 11
Pressure measurement ............................................................ 11
Electrical .......................................................................................... 11
Customer service ............................................... Back cover
© 2005 General Electric Company. All rights reserved.
Trademarks
All product names are trademarks of their respective companies.
Introduction
The Druck DPI 104 is a digital pressure indicator that
measures the pressure of liquid, gas or vapour and shows
the pressure value on a liquid crystal display (LCD). It also
has the Intelligent Digital Output Sensor (IDOS) technology
to use data from a Universal Pressure Module (UPM).
The DPI 104 includes these functions:
Function
* Measure pressure - Accuracy: 0.05% full scale (FS)
Large 5-digit main display with 11 pressure units
Adjustable Full Scale Output (FSO)
20 segment analogue dial in increments of 5% FSO
(large division marks = 10% increments).
2.5 digit percentage indicator (0 -100% FSO)
8-pin connector port: For RS232, **IDOS UPM, external power
supply
Alarm output for high/low pres sure conditions
Switch input to monitor an external pressure switch
Analogue voltage output (Vout): 0 - 5 Vdc
Other functions: Maximum/minimum, tare, Vout scale factor,
automatic power off
* Refer to “Specification data”.
** Optional item
Safety
Before you use the DPI 104, make sure that you read and
understand all the related data. This includes: all local
safety procedures, and this publication.
• Some liquid and gas mixtures are dangerous. This
includes mixtures that occur because of
contamination. Make sure that the DPI 104 is safe to
use with the necessary media.
• It is dangerous to ignore the specified limits for the
DPI 104 or to use the DPI 104 when it is not in its
normal condition. Use the applicable protection and
obey all safety precautions.
• To prevent a dangerous release of pressure, isolate
and bleed the system before you disconnect a
pressure connection.
• Do not use the DPI 104 in locations with explosive
gas, vapour or dust. There is a risk of an explosion.
Before you start an operation or procedure, make sure
that you have the necessary skills (if necessary, with
qualifications from an approved training establishment).
Follow good engineering practice at all times.
Safety - Marks and symbols on the DPI 104
Complies wi th European Union di rectives
WARNING
K394 Issue 1
[EN] English - 1
To Start
To start - Location of items
Item Description
1. 8-pin connector for external power supplies,
2.
3. In menu mode:
4. Pressure sensor and connector with 320° of turn:
5.
6. Display bezel with 348° of turn.
7. O-ring.
8. Battery connector
9. Battery: 9 V Alk aline (supplied but not installed). R efer
10. Battery clamp with tw o screws.
RS232/UPM connections an d signal input/output.
Power on button
•
Menu mode: Press for 2 seconds to show the first
•
menu option. To move down the menu structure,
press again and again, or press and hold.
Reject or stop the change to a value.
•
In Maximum/minimum mode. Press to show the
•
maximum and minimum values since the last reset.
= maximum = minimum
- On/OFF selection
- Increase/decrease a value
- Move the decimal left/right
gauge (g), absolute (a) or Sealed gauge (sg). Refer to
“Specification data”.
In menu mode:
•
- Accepts a menu selection
- Shows the next menu level
- Accepts a value
In Tare mode: Tare the pressure value on the display.
•
In Maximum/minimu m mode. Reset the
•
maximum/minimum values.
to “Installation”.
To start - Items on the display
Item Description
11. 5-digit main display .
12. 2.5-digit percentage indicator (0-100% FSO).
%FSO = [ Applied Pressure/ (FSOHigh —FSO Low)] * 100
13. 20 segment analogue dial in increments of 5% FSO
(large division marks = 10% increments).
%FSO = [ Applied Pressure/ (FSOHigh —FSO Low)] * 100
14.
The units of meas urement: kPa, MPa, kg/cm2, psi,
mbar, bar, mmHg, mmH2O, mH2O, inH2O, inHg
A1
A2
Continued
Item Desc ription
15. Mode indication.
Voltage output (V out) mode - On.
RS232 connectio n. The data transmit/receive function
is active.
Switch mode - On. To monitor an external pressure
switch.
= switch closed = switch open
Menu Lock mode - On. To restrict access to the menu
function s.
Alarm mode - On. The symbol flashes when the
measured value satisfies one of the alarm conditions.
= High alarm = Low alarm
Maximum/minimum mode - On.
IDOS UPM mode - On. To monitor pressure from a UPM
16. Low battery power indication: Battery life ≤ 15%.
To start - Prepare the instrument
Before you use the instrument for the first time:
• Make sure that there is no damage to the instrument,
and that there are no missing items.
• Install the battery (refer to “Installation”). Then
re-attach the display bezel [A1: item 6].
To start - Power on or off
Press the buttons in the sequence shown below.
•Power on sequence:
1
First display =
FS limit
Then:
Normal output
• Power off sequence:
Normal output 1 Menu: 2
OFF
(For 2 sec onds)
When the power is of f, the last set of c onfiguration options
stays in memory.
Note: The DPI 104 uses a small quantity of power while it is
OFF. If you put it into storage for a long period, disconnect
the battery (refer to “Installation”).
2 - [EN] English
K394 Issue 1
