GE Built-In Side-by-Sides Catalog

• customcool™technology • tall lighttouch!brightspace™interior • turbocool™setting • 2004 contract sales product specifications

GE Profile

™

and GE

Refrigerators

The Ultimate in Refrigeration.

™

Rethought. Reinvented. Revolutionized.

The Ultimate in Refrigeration.

™

GEAppliances.com

GE Profile Arctica®has the freshest ideas in refrigeration, including the

new ClimateKeeper2™dual-evaporator system which carefully controls

humidity to keep foods fresh days longer. The stylish exterior makes

dramatic statement, and the multilevel interior makes versatile

use of every inch of storage space. In the freshfood compartment,

slide-out shelves simplify loading and unloading. In the freezer

compartment, the ice system is uniquely designed to allow more

room for more food. In addition to innovative storage features, both

compartments offer a range of cooling capabilities for the ultimate

in flexibility and performance.

Feature Gallery: Built-In Side-by-Sides

GEAppliances.com

ClimateKeeper™System

Combines electronic touch controls, multiple electronic sensors and a multiflow air system to keep temperatures consistent and help preserve foods.

Soft-touch dispenser

Dispenses water and ice with gentle pressure, complete with safety and convenience features such as a child lock and door alarm, filter replacement indicator light and QuickIce

™

system.

Digital temperature controls

Located on the dispenser to provide easy-access, electronic accuracy in controlling fresh food and freezer compartment temperatures.

Overhead evaporator system

Provides additional freezer space, eliminates shared air and reduces defrosting. Access panel easily lifts out of the way for convenient replacement of the water filter.

ENERGY STAR®-qualified

Reduces energy usage below federal energy standards by 15% or more, for a high-efficiency design that can help lower utility bills.

ClearLook

™

door bins

Holds beverages and condiments securely and stylishly.

Adjustable humidity vegetable/ fruit crispers

Customizes the storage environment to keep fruits and vegetables at their best.

Secure-close door system

Engineered with an advanced hinge system that automatically pulls the door shut when angled at 90° or less.

SmartWater™Plus filtration

Ensures access to clear, better-tasting water and ice with filter change indicator light and simple-to-install Twist and Lock design.

Spillproof glass shelves

Contains spills to keep cleanup to a minimum.

Built-In Side-By-Side Refrigerators

PSB42LSR

GE Profile Arctica

25.2 cu. ft. Refrigerator

• 42" built-in configuration

• ClimateKeeper

™

system

• Electronic dispenser with digital temperature display

• Soft-touch dispenser with child lock and door alarm

• SmartWater

™

Plus filtration system

• FrostGuard

™

technology

• Quick Ice

™

feature

PSB42LSRBV

PSB42LGR

GE Profile Arctica

25.2 cu. ft. Refrigerator

• 42" built-in configuration

• ClimateKeeper

™

system

• Electronic dispenser with digital temperature display

• Soft-touch dispenser with child lock and door alarm

• SmartWater

™

Plus filtration system

• FrostGuard

™

technology

• Quick Ice

™

feature

PSB42LGRWV

PSB42LGRBV

Stainless steel White Blac

GEAppliances.com

PSB42LGRBV

Black dispenser model shown with optional black acrylic panels

PSB42LGRWV

White dispenser model shown with optional white acrylic panels

PSB42LGRWV

White dispenser model shown with optional 1/4" custom wood panels

PSB42LGRBV

Black dispenser model shown with optional 1/4" custom wood panels

PSB42LGRWV

White dispenser model shown with optional 3/4"

custom wood panels

PSB42LGRBV

Black dispenser model shown with optional 3/4"

custom wood panels

Make an impressive design statement, without standing out.

Built-in refrigerators with installed trim accept acrylic panels in white or black which can be ordered from GE. To achieve a custom look, you can order 1/4" or 3/4" wood panels from your cabinetmaker. You’ll discover all kinds of ways to enhance your kitchen. Our trimless unit, which comes in stainless steel, simply slides into the space between cabinets. It instantly looks built-in with nothing to attach or build.

Acrylic Panels

Model No. Black Acrylic Panels White Acrylic Panels

PSB42LGRWV PSPK42DWW PSB42LGRBV PSPK42DBB

PSB42LSRBV

Stainless steel with full-length visor handles

Feature Gallery: Side-by-Sides

GEAppliances.com

Not all features available on all models.

Integrated Ice™system

The ice bucket is integrated into the icemaker, not the freezer door, freeing up valuable storage space. It pulls out and down, providing easy access to cubed ice.

TurboCool

™

feature

Quickly cools the refrigerator after frequent door openings or when hot items are placed inside.

Only GE has it!

QuickSpace™shelf

Quickly slides out of the way to make room for tall items.

Tall LightTouch! dispenser

Accommodates tall glassware and dispenses water and ice at the slightest touch.

ClimateKeeper2™System

Keeps foods fresh longer, while protecting ice from odor transfer, with its unique dual-evaporator system.

It chills!

It thaws!

It preserves!

It fully extends!

It chills!

It preserves!

It fully extends!

It thaws!

Only GE has it!

Slide ’n Store™full-extension freezer baskets

Extend 16" for easy loading and unloading.

Upfront digital controls with temperature readout

Are precise and easy to use.

Full-extension bin with CustomCool

™

technology

Chills in minutes, thaws in hours and helps keep foods fresher, longer. For added convenience, it opens fully to allow easy access.

Limited lifetime warranty* on slides. See written warranty for details.

Only GE has it!

In-the-door beverage rack

Conveniently located inside the refrigerator door to increase flexibility and free up valuable shelf space.

Adjustable ClearLook

™

bins

Hold gallon-size containers with style and ease.

Slide-out, spillproof glass shelves

Simplify loading, unloading and cleaning.

SmartWater

™

filtration system

Delivers clean, great-tasting water and ice through the LightTouch! dispenser.

GE Profile Arctica®and GE CustomStyle™Side-by-Sides

Trimless side-by-side models

Installation made easy: simply slide in.

Trimless CustomStyle units install by simply sliding into—way into—the space between cabinets. They align with counters, instantly look built-in, with nothing to attach or build. (Available in stainless steel, white, bisque and black.)

An impressive design statement, without standing out.

For a built-in look, without the built-in expense, here’s a fitting solution. A GE Profile CustomStyle refrigerator makes the most of your kitchen space by blending in almost seamlessly with surrounding cabinetry. It gives you the style you want and features you need, without the cost and inconvenience of remodeling. For a sleek, modern appearance, choose stainless or acrylic panels. Or, achieve a custom look with cabinet-matching wood panels. Whatever style you prefer, you’ll find a CustomStyle refrigerator that works beautifully with your decor and budget.

Optional collar trim: adding the final touch.

The optional collar trim is just another way GE lets you integrate our CustomStyle refrigerators into your kitchen decor. Available in stainless steel, white, bisque and black, this trim frames the refrigerator facade, adding to the finished look of a built-in, custom kitchen.

Acrylic and Stainless Steel Panels

Black Acrylic White Acrylic Bisque Acrylic Stainless Steel

Model No. Panels Panels Panels Panels

PSI23NCP PSPK23CBB PSPK23CWW PSPK23CCC PSI23MGP PSPK23DBB PSPK23DWW PSPK23DCC PSPK23DSS PSI23NGP PSPK23DBB PSPK23DWW PSPK23DCC PSPK23DSS

Stainless Steel

Model No. Black Collar Trim White Collar Trim Bisque Collar Trim Collar Trim

PSI23NCP TRMBISBB TRMBISWW TRMBISCC TRMBISSS

PSI23SCR TRMBISSS PSI23MGP TRMBISBB TRMBISWW TRMBISCC TRMBISSS PSI23NGP TRMBISBB TRMBISWW TRMBISCC TRMBISSS PSI23SGR TRMBISSS

Collar Trim

Optional Panels

Choose stainless steel panels or acrylic panels in white, bisque or black.

Custom Wood Panels

Make and install your own custom wood panels to accent cabinetry.

Installed-trim side-by-side models

Designed for today’s discriminating consumers.

CustomStyle refrigerators with installed trim accept stainless steel or acrylic panels in white, black or bisque, all of which can be ordered from GE. To achieve a custom look, you can order wood panels from your cabinetmaker. You’ll discover all kinds of ways to enhance your kitchen.

GE Profile CustomStyle extends 26-3/4" from wall

26-3/4"

Saves over 6"

Others extend up to 33" from wall

33"

GEAppliances.com

Not all features available on all models.

Trimless side-by-side models

PSC23SHR

Stainless steel with sculptured stainless steel handles.

PSC23NHP

Available in white, bisque or black.

PSI23SCR

Stainless steel with full-length visor handles.

PSC23NGP/ PSC23MGP

Available in white, bisque or black.

PSC23SGR

Stainless steel with sculptured stainless steel handles.

PSW23PSR

Stainless-wrapped with sculptured stainless steel handles.

PSH23PSR/PSI23SGR

Stainless steel with full-length visor handles.

GSC23LSR

Stainless steel with tubular handles. Available in stainless or white and black as GSC23LGQ.

GSC21KGR

Available in white or black.

Model PSH23PGR is ENERGY STAR®-qualified.

Model PSW23PSR is ENERGY STAR

-qualified.

Model PSH23PSR is ENERGY STAR

-qualified.

Installed-trim side-by-side models

PSH23PGR

Shown with optional black acrylic panels. Available in white, bisque or black.

PSI23NGP

Shown with custom wood panels. Available in white, bisque or black.

PSI23MGP

Shown with custom wood panels. Available in white, bisque or black.

PSI23MGP

Shown with optional white acrylic panels. Available in white, bisque or black.

PSI23NCP

Shown with custom wood panels. Available in white, bisque or black.

PSI23NCP

Shown with optional white acrylic panels. Available in white, bisque or black.

Non-Dispenser Models Non-Dispenser Model

Dispenser Models Dispenser Models

Side-By-Side Refrigerators

Stainless steel White Bisque Black

PSW23PSR

GE Profile Arctica CustomStyle

™

22.6 cu. ft. Stainless-Wrapped Refrigerator

• ClimateKeeper2™system

• CustomCool

™

technology with full-extension drawer

• Upfront electronic touch temperature controls with digital temperature display

• Integrated Ice

™

system

• LightTouch! tall dispenser with child lock and door alarm

• Slide ’n Store

™

full-extension freezer baskets

• FrostGuard

™

technology

PSW23PSRSS

PSH23PSR

GE Profile Arctica CustomStyle

22.6 cu. ft. Refrigerator

• ClimateKeeper2 system

• CustomCool technology with full-extension drawer

• Upfront electronic touch temperature controls with digital temperature display

• Integrated Ice system

• LightTouch! tall dispenser with child lock and door alarm

• Slide ’n Store full-extension freezer baskets

• FrostGuard technology

PSH23PSRSV

trimless

PSH23PGRWW

installed trim

PSH23PGRCC

installed trim

PSH23PGRBB

installed trim

Bold = feature upgrade from previous model.

GEAppliances.com

Stainless steel White Bisque Black

PSI23SGR

GE Profile Arctica CustomStyle

22.6 cu. ft. Installed-Trim Refrigerator

• CustomCool technology with full-extension drawer

• ClimateKeeper

™

system

• Upfront electronic touch temperature controls

with digital temperature display

• Integrated Ice system

• LightTouch! tall dispenser with child lock and door alarm

• Slide ’n Store full-extension freezer baskets

• FrostGuard technology

PSI23SGRSV

PSI23NGPWW

PSI23NGPCC

PSI23NGPBB

PSI23MGP

GE Profile Arctica CustomStyle

22.7 cu. ft. Installed-Trim Refrigerator

• ClimateKeeper system

• Upfront electronic touch temperature controls

• Integrated Ice system

• LightTouch! tall dispenser with child lock and door alarm

• Integrated shelf support system

• FrostGuard technology

• Slide-out spillproof glass shelves

PSI23MGPWW

PSI23MGPCC

PSI23MGPBB

PSI23SCRSV

non-dispenser model

PSI23NCPWW

non-dispenser model

PSI23NCPCC

non-dispenser model

PSI23NCPBB

non-dispenser model

Side-By-Side Refrigerators

PSC23SGR

GE Profile Arctica CustomStyle

™

22.6 cu. ft. Trimless Refrigerator

• CustomCool™technology with full-extension drawer

• ClimateKeeper

™

system

• Upfront electronic touch temperature controls with digital temperature display

• Integrated Ice

™

system

• LightTouch! tall dispenser with child lock and door alarm

• Slide ’n Store

™

full-extension freezer baskets

• FrostGuard

™

technology

PSC23SHRSS black dispenser and refreshment center model

PSC23NHPWW refreshment center model

PSC23NHPCC refreshment center model

PSC23NHPBB refreshment center model

PSC23MGP

GE Profile Arctica CustomStyle

22.7 cu. ft. Trimless Refrigerator

• ClimateKeeper system

• Upfront electronic touch temperature controls

• Integrated Ice system

• LightTouch! tall dispenser with child lock and door alarm

• FrostGuard technology

• Integrated shelf support system

• Slide-out, spillproof glass shelves

PSC23MGPWW

PSC23MGPCC

PSC23MGPBB

PSC23SGRSS

PSC23NGPWW

PSC23NGPCC

PSC23NGPBB

Bold = feature upgrade from previous model.

Stainless steel White Bisque Blac

Bold = feature upgrade from previous model.

GEAppliances.com

Stainless steel White

Black

GSC23LSR

GE CustomStyle 22.7 cu. ft. Trimless Refrigerator

• Upfront electronic touch temperature controls

• Integrated Ice system

• TurboCool

™

setting

• LightTouch! tall dispenser with child lock and door alarm

• SmartWater

™

Plus filtration system

• FrostGuard technology

• QuickSpace

™

shelf

GSC21KGR

GE CustomStyle 21.4 cu. ft. Trimless Refrigerator

• Upfront electronic touch temperature controls

• LightTouch! tall dispenser with child lock

• FrostGuard technology

• Slide-out, spillproof glass shelves

• SmartWater Plus filtration system

• Adjustable humidity vegetable/fruit crisper

• Adjustable gallon door bins

GSC23LSRSS

GSC23LGQWW

GSC23LGQBB

GSC21KGRWW

GSC21KGRBB

Bold = feature upgrade from previous model.

Side-By-Side Refrigerators

PSW26SGR

GE Profile Arctica®25.5 cu. ft. Stainless-Wrapped Refrigerator

• ClimateKeeper™system

• CustomCool

™

technology with full-extension drawer

• Upfront electronic touch temperature controls with digital temperature display

• Integrated Ice

™

system

• LightTouch! tall dispenser with child lock and door alarm

• Slide ’n Store

™

full-extension freezer baskets

• FrostGuard

™

technology

PSW26SGRSS

PSF26NGPWW

PSF26NGPCC

PSF26NGPBB

PSF26NGP

GE Profile Arctica 25.5 cu. ft. High-Gloss Refrigerator

• ClimateKeeper system

• CustomCool technology with full-extension drawer

• Upfront electronic touch temperature controls with digital temperature display

• Integrated Ice system

• LightTouch! tall dispenser with child lock and door alarm

• Contoured doors

• Slide ’n Store full-extension freezer baskets

Stainless steel White Bisque Blac

GEAppliances.com

Stainless steel White Bisque Black

PSS29NHP

GE Profile Arctica 28.7 cu. ft. Refrigerator

• Refreshment Center

• ClimateKeeper system

• CustomCool technology with full-extension drawer

• Upfront electronic touch temperature controls with digital temperature display

• Integrated Ice system

• LightTouch! tall dispenser with child lock and door alarm

• Contoured doors

PSS29NHPWW

PSS29NHPCC

PSS29NHPBB

PSS26SHR

GE Profile Arctica 25.5 cu. ft. Refrigerator

• Refreshment Center

• CustomCool technology with full-extension drawer

• ClimateKeeper system

• Upfront electronic temperature controls with digital temperature display

• Integrated Ice system

• LightTouch! tall dispenser with child lock and door alarm

• Contoured doors

PSS26SHRSS

PSS26NHPWW

PSS26NHPCC

PSS26NHPBB

Bold = feature upgrade from previous model.

Side-By-Side Refrigerators

PSS29NGP

GE Profile Arctica®28.6 cu. ft. Refrigerator

• CustomCool™technology with full-extension drawer

• ClimateKeeper

™

system

• Upfront electronic touch temperature controls with digital temperature display

• Integrated Ice

™

system

• LightTouch! tall dispenser with child lock and door alarm

• Contoured doors

• Slide ’n Store

™

full-extension freezer baskets

PSS26SGR

GE Profile Arctica 25.5 cu. ft. Refrigerator

• CustomCool technology with full-extension drawer

• ClimateKeeper system

• Upfront electronic touch temperature controls with digital temperature display

• Integrated Ice system

• LightTouch! tall dispenser with child lock and door alarm

• Contoured doors

• Slide ’n Store full-extension freezer baskets

PSS29NGPWW

PSS29NGPCC

PSS29NGPBB

PSS26SGRSS

PSS26NGPWW

PSS26NGPCC

PSS26NGPBB

PSS27SGR (not shown)

Similar to the PSS26SGR with 26.5 cu. ft. capacity and is not ENERGY STAR

qualified

PSS27SGRSS

PSS27NGPWW

PSS27NGPCC

PSS27NGPBB

Stainless steel White Bisque Blac

GEAppliances.com

Stainless steel White Bisque Black

PSS26MGP

GE Profile Arctica 25.5 cu. ft. Refrigerator

• ClimateKeeper system

• Upfront electronic touch temperature controls

• Integrated Ice system

• LightTouch! tall dispenser with child lock and door alarm

• FrostGuard

™

technology

• Contoured doors

• Integrated shelf support system

PSS26LSR

GE Profile Arctica 25.6 cu. ft. Refrigerator

• Upfront electronic touch temperature controls

• Integrated Ice system

• TurboCool

™

setting

• LightTouch! tall dispenser with child lock and door alarm

• SmartWater

™

Plus water filtration system

• FrostGuard technology

• Integrated shelf support system

PSS26MSRSS

PSS26MGPWW

PSS26MGPCC

PSS26MGPBB

PSS26LSRSS

PSS26LGRWW

PSS26LGRCC

PSS26LGRBB

Bold = feature upgrade from previous model.

Side-By-Side Refrigerators

GSS25SGR

GE 25.0 cu. ft. Refrigerator

• Upfront electronic touch temperature controls

• Adjustable slide-out, spillproof glass shelves

• LightTouch! tall dispenser with child lock

• SmartWater Plus filtration system

• FrostGuard technology

• Adjustable humidity vegetable/fruit crisper

• Adjustable temperature deli drawer

GSH25SGRSS

GSH25KGRWW

GSH25KGRCC

GSH25KGRBB

GSS25SGRSS

GSH25KGR

GE®25.0 cu. ft. Refrigerator

• Upfront electronic touch temperature controls

• Adjustable slide-out, spillproof glass shelves

• LightTouch! tall dispenser with child lock

• SmartWater

™

Plus filtration system

• FrostGuard

™

technology

• Adjustable humidity vegetable/fruit crisper

• Adjustable temperature deli pan

GSH22SGR (not shown)

Similar to the GSH25SGR with 21.9 cu. ft. capacity

GSH22SGRSS

GSH22KGRWW

GSH22KGRCC

GSH22KGRBB

GSS22SGR (not shown)

Similar to the GSS25SGR with 21.9 cu. ft. capacity

GSS22SGRSS

Stainless steel White Bisque Blac

GEAppliances.com

White Bisque Black

CleanSteelCS

GSL25WGPBS

GSS25WGPWW

GSS25WGPCC

GSS25WGPBB

GSL25WGP

GE 25.0 cu. ft. Refrigerator

• CleanSteel™exterior (GSL25WGP and GSL22WGP only)

• Upfront electronic touch temperature controls

• Adjustable slide-out, spillproof glass shelves

• In-the-door can rack

• LightTouch! tall dispenser

• SmartWater Plus filtration system

• Adjustable humidity vegetable/fruit crisper

GSL22WGP (not shown)

Similar to the GSL25WGP with 21.9 cu. ft. capacity

GSL22WGPBS

GSS22WGPWW

GSS22WGPCC

GSS22WGPBB

GSS25JEPWW

GSS25JEPCC

GSS25JEPBB

GSS25JEP

GE 25.0 cu. ft. Refrigerator

• Upfront electronic temperature controls

• Adjustable spillproof glass shelves

• LightTouch! tall dispenser

• Sealed vegetable/fruit crisper

• Adjustable temperature deli drawer

• Adjustable gallon door bins

• FrostGuard technology

GSS22JEP (not shown)

Similar to the GSS25JEP with 22.0 cu. ft. capacity

GSS22JEPWW

GSS22JEPCC

GSS22JEPBB

Bold = feature upgrade from previous model.

Side-By-Side Refrigerators

GSS25IFP

GE®25.0 cu. ft. Refrigerator

• Upfront electronic temperature controls

• Adjustable glass shelves

• LightTouch! tall dispenser with SmartWater

™

filtration

• Sealed vegetable/fruit crisper

• Sealed deli drawer

• Adjustable gallon door bins

• FrostGuard

™

technology

GSS25IFPWW

GSS25IFPCC

GSS25IFPBB

GSS20IEP

GE 20.0 cu. ft. Refrigerator

• Upfront electronic temperature controls

• Adjustable glass shelves

• LightTouch! tall dispenser

• Sealed vegetable/fruit crisper

• Sealed meat drawer

• Adjustable gallon door bins

• FrostGuard technology

GSS20IEPWW

GSS20IEPCC

GSS20IEPBB

GSS22IFP (not shown)

Similar to the GSS25IFP with 22.0 cu. ft. capacity

GSS22IFPWW

GSS22IFPCC

GSS22IFPBB

White Bisque Blac

GEAppliances.com

White Bisque

GSS22IBPWW

GSS22IBPCC

GSS22IBP

GE 21.9 cu. ft. Refrigerator

• Upfront electronic temperature controls

• Adjustable glass shelves

• Sealed vegetable/fruit crisper

• Sealed meat drawer

• Adjustable gallon door bins

• FrostGuard technology

• Deluxe quiet design

GSS20IBP (not shown)

Similar to the GSS22IBP with 19.9 cu. ft. capacity

GSS20IBPWW

GSS20IBPCC

GSS20DBPWW

GSS20DBPCC

GSS20DBP

GE 19.9 cu. ft. Refrigerator

• Upfront electronic temperature controls

• Sealed vegetable/fruit crisper

• Sealed meat drawer

• Gallon door storage

• FrostGuard technology

• Deluxe quiet design

• NeverClean

™

condenser

Feature Gallery: Bottom-Freezers

GEAppliances.com

Not all features available on all models.

Internal water dispenser

Provides chilled, great tasting filtered water on demand, from inside the refrigerator.

Upfront electronic controls with digital temperature readout

Are precise and easy to use. Take the guesswork out of selecting accurate temperatures.

Slide-out, spillproof glass shelves

Simplify loading, unloading and cleaning.

ClimateKeeper

™

system

Combines upfront electronic touch controls, multiple electronic sensors and a multiflow air system to keep temperatures consistent and help keep foods fresh.

Adjustable temperature deli drawer

Provides a convenient, temperature-controlled place for meats, cheeses and other favorite foods.

Adjustable ClearLook

™

crispers

Provide the ideal storage environment for fruits and vegetables, with humidity controls and transparent fronts.

ENERGY STAR

-qualified

Higher energy efficiency means lower utility bills. 20 and 22 cu. ft. models are 33% better than 2004 ENERGY STAR standards.

QuickSpace

™

shelf

Quickly slides out of the way to make room for tall items.

ClearLook

™

gallon door bins

Hold gallon-size containers with style and ease.

ShelfSaver

™

beverage rack

Provides convenient storage for a 12-pack, two egg cartons or a 9"x 13" casserole dish.

Only GE has it!New!

Bold = feature upgrade from previous model.

PDW22SHR

GE Profile Arctica®22.2 cu. ft. Stainless-Wrapped Drawer Refrigerator

• Internal water dispenser with GE SmartWater™filtration

• Upfront electronic touch temperature controls with digital temperature display

• ClimateKeeper

™

system

• Multi-level Slide ’n Store

™

freezer baskets

• Integrated icemaker

• BrightSpace

™

interior with GE Reveal™lighting

• ShelfSaver

™

beverage rack

Available July 2004

Discontinues July 2004

PDW22SHRSS

Bottom-Freezer Refrigerators

PDW22SCR

GE Profile Arctica 22.2 cu. ft. Stainless-Wrapped Drawer Refrigerator

• Upfront electronic touch temperature controls with digital temperature display

• ClimateKeeper system

• Multi-level Slide ’n Store freezer baskets

• Integrated icemaker with GE SmartWater filtration

• BrightSpace interior with GE Reveal lighting

• ShelfSaver beverage rack

• QuickSpace

™

shelf

PDW22SCRSS

Stainless steel

GEAppliances.com

Stainless steel White Bisque Black

Available July 2004

PDF22MCR

GE Profile Arctica 22.2 cu. ft. High-Gloss Smooth Drawer Refrigerator

• Upfront electronic touch temperature controls with digital temperature display

• ClimateKeeper system

• Multi-level Slide ’n Store freezer baskets

• Integrated icemaker with GE SmartWater filtration

• BrightSpace interior with GE Reveal lighting

• ShelfSaver beverage rack

• QuickSpace shelf

PDF22MCRWW

PDF22MCRBB

PDS22MHR

GE Profile Arctica 22.2 cu. ft. Drawer Refrigerator

• Internal water dispenser with GE SmartWater filtration

• Upfront electronic touch temperature controls with digital temperature display

• ClimateKeeper system

• Multi-level Slide ’n Store freezer baskets

• Integrated icemaker

• BrightSpace interior with GE Reveal lighting

• ShelfSaver beverage rack

PDS22SHRSS

PDS22MHRWW

PDS22MHRCC

PDS22MHRBB

Bold = feature upgrade from previous model.

Bottom-Freezer Refrigerators

PDS22MBR

GE Profile Arctica 22.2 cu. ft. Drawer Refrigerator

• Upfront electronic touch temperature controls with digital temperature display

• ClimateKeeper system

• Multi-level Slide ’n Store freezer baskets

• BrightSpace interior with GE Reveal lighting

• ShelfSaver beverage rack

• QuickSpace shelf

• Self-closing drawer

PDS22SBRSS

PDS22MBRWW

PDS22MBRCC

PDS22MBRBB

PDS22SCR

GE Profile Arctica®22.2 cu. ft. Drawer Refrigerator

• Upfront electronic touch temperature controls

with digital temperature display

• ClimateKeeper

™

system

• Multi-level Slide ’n Store

™

freezer baskets

• Integrated icemaker with GE SmartWater

™

filtration

• BrightSpace

™

interior with GE Reveal™lighting

• ShelfSaver

™

beverage rack

• QuickSpace

™

shelf

PDS22SCRSS

PDS22MCRWW

PDS22MCRCC

PDS22MCRBB

Discontinues July 2004

Stainless steel White Bisque Blac

GEAppliances.com

Stainless steel White Bisque Black

PDS20SCR

GE Profile Arctica 19.5 cu. ft. Drawer Refrigerator

• Upfront electronic touch temperature controls with digital temperature display

• ClimateKeeper system

• Multi-level Slide ’n Store freezer baskets

• Integrated icemaker with GE SmartWater filtration

• BrightSpace interior with GE Reveal lighting

• ShelfSaver beverage rack

• Self-closing drawer

PDS20SCRSS

PDS20MCRWW

PDS20MCRCC

PDS20MCRBB

PDS20SBRSS

non-icemaker model

PDS20MBRWW

non-icemaker model

PDS20MBRCC

non-icemaker model

PDS20MBRBB

non-icemaker model

GBS22KBR

GE®22.3 cu. ft. Door Refrigerator

• Upfront illuminated temperature controls

• Slide ’n Store freezer basket

• Adjustable gallon door bins

• BrightSpace interior with GE Reveal lighting

• Adjustable spillproof glass shelves

• Adjustable humidity vegetable/fruit crispers

• Snack pan

GBS22KBRWW

GBS22KBRCC

GBS22KBRBB

GBS20KBR (not shown)

Similar to the GBS22KBR with 19.5 cu. ft. capacity

GBS20KBRWW

GBS20KBRCC

GBS20KBRBB

Bold = feature upgrade from previous model.

Bottom-Freezer Refrigerators

GBS22HBR

GE 22.3 cu. ft. Door Refrigerator

• Upfront illuminated temperature controls

• Gallon door storage

• BrightSpace interior with GE Reveal lighting

• Adjustable glass shelves

• Snack pan

• Deluxe quiet design

• NeverClean

™

condenser

GBS22HBRWW

GBS22HBRCC

GBS22HBRBB

GBS22HCR

GE®22.3 cu. ft. Door Refrigerator

• Upfront illuminated temperature controls

• Integrated Icemaker

• Gallon door storage

• BrightSpace

™

interior with GE Reveal™lighting

• Adjustable glass shelves

• Snack pan

• Deluxe quiet design

GBS22HCRWW

GBS22HCRCC

GBS22HCRBB

White Bisque Blac

GEAppliances.com

Stainless steel White Bisque Black

GDS18SCR

GE 18.1 cu. ft. Drawer Refrigerator

• Brita®filtered water door module

• Adjustable humidity vegetable/fruit crispers

• Adjustable spillproof glass shelves

• Slide ’n Store

™

freezer basket

• Factory-installed automatic icemaker

• Adjustable gallon door bins

• Snack pan

GBS18HBR

GE 18.1 cu. ft. Door Refrigerator

• Slide ’n Store freezer basket

• Gallon door storage

• Adjustable glass shelves

• Snack pan

• NeverClean

™

condenser

• Deluxe quiet design

• Equipped for optional automatic icemaker

GDS18SCRSS

GDS18LCRWW

GDS18LCRCC

GDS18LCRBB

GBS18HBRWW

GBS18HBRCC

GBS18HBRBB

GDS18SBRSS

non-icemaker model

GDS18LBRWW

non-icemaker model

GDS18LBRCC

non-icemaker model

GDS18LBRBB

non-icemaker model

GE Profile CustomStyle™Top-Freezers

Trimless top-freezer models

Installation made easy: simply slide in.

Trimless CustomStyle units install by simply sliding into—way into—the space between cabinets. They align with counters and instantly look built-in, with nothing to attach or build. (Available in stainless steel, white, bisque and black.)

An impressive design statement, without standing out.

If you want a built-in look, but can’t afford the built-in expense, here’s a fitting solution. A GE Profile CustomStyle refrigerator makes the most of your kitchen space by blending in almost seamlessly with surrounding cabinetry. It gives you the style you want and features you need, without the cost and inconvenience of a kitchen redo. For a sleek, modern appearance, choose stainless or acrylic panels. Or, achieve a custom look with cabinet-matching wood panels. Whatever style you prefer, you’ll find a CustomStyle refrigerator that works beautifully with your decor and budget.

Optional collar trim: adding the final touch.

The optional collar trim is just another way GE lets you integrate our CustomStyle refrigerators into your kitchen decor. Available in stainless steel, white and black, this trim frames the refrigerator facade, adding to the finished look of a built-in, custom kitchen.

Acrylic Panels and Trim

Optional Panels

Choose stainless steel panels or acrylic panels in white or black.

Custom Wood Panels

Make and install your own custom wood panels to accent cabinetry.

Installed-trim top-freezer models

Designed for today’s discriminating consumers.

CustomStyle refrigerators with installed trim accept stainless steel or acrylic panels in white or black, all of which can be ordered from GE. To achieve a custom look, you can order wood panels from your cabinetmaker. You’ll discover all kinds of ways to enhance your kitchen.

Others extend up to 31" from wall

26"

Saves nearly 5"

31"

26"

GE Profile CustomStyle extends 26" from wall

Stainless Stainless

Black Acrylic White Acrylic Steel Black Collar White Collar Steel

Model No. Panels Panels Panels Trim Trim Trim

PTI22MBM PTPK22CBB PTPK22CWW PTPK22CSS TRMBISBB TRMBISWW TRMBISSS

PTI22MFM PTPK22DBB PTPK22DWW PTPK22DSS TRMBISBB TRMBISWW TRMBISSS

Others extend up to 31" from wall

GEAppliances.com

Not all features available on all models.

Installed-trim top-freezer models

Non-Dispenser Models

Dispenser Models

Trimless top-freezer models

PTC22SFM

Stainless steel.

PTC22MFM

Available in white, bisque or black.

PTC22SBM

Stainless steel.

PTC22MBM

Available in white or black.

PTI22SFM

Shown with installed stainless steel panels.

PTI22MFM

Shown with optional white acrylic panels. Available in white or black.

PTI22MFM

Shown with custom wood panels. Available in white or black.

PTI22MBM

Shown with optional stainless steel panels. Available in white or black.

PTI22MBM

Shown with optional black acrylic panels. Available in white or black.

PTI22MFM

Shown with optional stainless steel panels. Available in white or black.

PTI22MBM

Shown with custom wood panels. Available in white or black.

Non-Dispenser ModelsDispenser Models

Feature Gallery: Top-Freezers

GEAppliances.com

Not all features available on all models.

GE SmartWater™and ice filtration

Delivers clean, fresh-tasting water through the internal water dispenser.

Electronic touch controls with digital temperature readout

Precise and easy to use. Take the guesswork out of selecting accurate temperatures.

Only GE has it!

Internal water dispenser

Provides chilled, great tasting filtered water on demand, from inside the refrigerator.

ShelfSaver™beverage rack

Provides convenient storage for a 12-pack, two egg cartons or a 9"x 13" casserole dish.

Only GE has it!

Adjustable temperature deli drawer

Provides a convenient, temperature-controlled place for meats, cheeses and other favorite foods.

Slide-out, spillproof glass shelves

Simplify loading, unloading and cleaning.

Adjustable ClearLook

™

gallon door bins

Hold large containers with style and ease.

Adjustable humidity crispers

Provide the ideal storage environment for fruits and vegetables.

FrostGuard

™

technology

Defrosts only when needed, reducing freezer burn.

Bold = feature upgrade from previous model.

PTI22SFM

GE Profile CustomStyle™21.7 cu. ft. Installed-Trim Refrigerator

• Upfront illuminated temperature controls

• LightTouch! dispenser

• SmartWater

™

filtration

• Factory-installed electronic icemaker

• Adjustable slide-out, spillproof glass shelves

• QuickSpace

™

shelf

• Snack pan

PTC22SFM

GE Profile CustomStyle 21.7 cu. ft. Trimless Refrigerator

• Upfront illuminated temperature controls

• LightTouch! dispenser

• SmartWater filtration

• Factory-installed electronic icemaker

• Adjustable slide-out, spillproof glass shelves

• QuickSpace shelf

• Snack pan

PTI22SFMBS

PTI22MFMWW

PTI22MFMBB

PTC22SFMBS

PTC22MFMWW

PTC22MFMCC

PTC22MFMBB

Top-Freezer Refrigerators

PTI22MBM (not shown)

Similar to the PTI22SFM with 21.9 cu. ft. capacity, except without dispenser and icemaker

PTI22MBMWW

PTI22MBMBB

PTC22SBM (not shown)

Similar to the PTC22SFM with 21.9 cu. ft. capacity, except without dispenser and icemaker

PTC22SBMBS

PTC22MBMWW

PTC22MBMBB

Stainless steel White Bisque Blac

GEAppliances.com

Stainless steel White Bisque Black

PTS25SHR

GE Profile Arctica®24.6 cu. ft. Refrigerator

• Internal water dispenser with SmartWater filtration

• Upfront electronic touch temperature controls with digital temperature display

• ClimateKeeper

™

system

• Factory-installed automatic icemaker

• Adjustable slide-out, spillproof glass shelves

• ClearLook

™

adjustable gallon door bins

• Tilt-out locking freezer door bin

PTS22SCR

GE Profile Arctica 21.7 cu. ft. Refrigerator

• Upfront electronic touch temperature controls with digital temperature display

• ClimateKeeper system

• Factory-installed automatic icemaker

• Adjustable slide-out, spillproof glass shelves

• ClearLook adjustable gallon door bins

• Tilt-out locking freezer door bin

• Pivot-out pan removal system

PTS25SHRBS

PTS25LHRWW

PTS25LHRCC

PTS25LHRBB

PTS22SCRBS

PTS22LCRWW

PTS22LCRCC

PTS22LCRBB

PTS22SHR (not shown)

Similar to the PTS25SHR with 21.7 cu. ft. capacity

PTS22SHRBS

PTS22LHRWW

PTS22LHRCC

PTS22LHRBB

Bold = feature upgrade from previous model.

GTS22WCP

GE®21.7 cu. ft. Refrigerator

• Adjustable slide-out, spillproof lift-off glass shelves

• Upfront illuminated slimline temperature controls

• Factory-installed automatic icemaker

• Adjustable humidity vegetable/fruit crispers

• Spillproof freezer floor

• Adjustable gallon door bins

• Pivot-out pan removal system (GTS22WCP only)

GTH22SHR

GE 21.7 cu. ft. Refrigerator

• Internal water dispenser with GE SmartWater™filtration

• Factory-installed automatic icemaker

• Upfront illuminated slimline temperature controls

• Adjustable spillproof glass shelves

• Adjustable humidity vegetable/fruit crispers

• Adjustable gallon door bins

• Spillproof freezer floor

GTS22WCPWW

GTS22WCPCC

GTS22WCPBB

GTH22SHRBS

Top-Freezer Refrigerators

GTS18WCP (not shown)

Similar to the GTS22WCP with 17.9 cu. ft. capacity

GTS18WCPWW

GTS18WCPCC

GTS22KHPWW

non ENERGY STAR®model

GTS22KHPCC

non ENERGY STAR model

GTS22KHPBB

non ENERGY STAR model

GTS18SHP (not shown)

Similar to the GTS22KHP with 17.9 cu. ft. capacity

GTS18SHPBS

GTS18KHPWW

GTS18KHPCC

GTS18KHPBB

Stainless steel White Bisque Blac

GEAppliances.com

Stainless steel

GTH22SBR

GE 21.7 cu. ft. Refrigerator

• Upfront illuminated slimline temperature controls

• Adjustable spillproof glass shelves

• Adjustable humidity vegetable/fruit crispers

• Adjustable gallon door bins

• Spillproof freezer floor

• Pivot-out pan removal system (21.7 cu. ft. models only)

• NeverClean

™

condenser

GTH22SBRBS

GTH22KBRWW

GTH18KBR (not shown)

Similar to the GTH22KBR with 17.9 cu. ft. capacity

GTH18KBRWW

GTH18KBRCC

GTH18KBRBB

GTS22KBPWW

non ENERGY STAR model

GTS22KBPCC

non ENERGY STAR model

GTS22KBPBB

non ENERGY STAR model

GTS18SBPBS

non ENERGY STAR model

GTS18KBPWW

non ENERGY STAR model

GTS18KBPCC

non ENERGY STAR model

GTS18KBPBB

non ENERGY STAR model

GTS22JCP

GE 21.7 cu. ft. Refrigerator

• Upfront illuminated slimline temperature controls

• Adjustable spillproof glass shelves

• Factory-installed automatic icemaker (GTL22JCP only)

• Sealed vegetable/fruit crispers

• Spillproof freezer floor

• Gallon door storage

• Pivot-out pan removal system

GTL22JCPBS

GTS22JCPWW

GTS22JCPCC

GTL22JBPBS

non-icemaker model

GTS22JBPWW

non-icemaker model

GTS22JBPCC

non-icemaker model

White Bisque Black

CleanSteelCS

Bold = feature upgrade from previous model.

Top-Freezer Refrigerators

GTH18JBRWW

ENERGY STAR

-qualified, non-icemaker model

GTH18JBRCC

ENERGY STAR-qualified, non-icemaker model

GTL18JCP

GE®17.9 cu. ft. Refrigerator

• CleanSteel™exterior (GTL18JCP/GTL18JBP only)

• Upfront illuminated slimline temperature controls

• Adjustable spillproof glass shelves

• Factory-installed automatic icemaker

• Sealed vegetable/fruit crispers

• Spillproof freezer floor

• Gallon door storage

GTL18JCPBS

GTS18JCPWW

GTS18JCPCC

GTL18JBPBS

non-icemaker model

GTS18JBPWW

non-icemaker model

GTS18JBPCC

non-icemaker model

GTL16JBR

GE 15.8 cu. ft. Refrigerator

• CleanSteel exterior (GTL16JBR only)

• Upfront temperature controls

• Spillproof glass shelves

• Adjustable humidity clear vegetable/fruit crispers

• Gallon door storage

• NeverClean

™

condenser

• Deluxe quiet design

GTL16JBRBS

GTS16JBRWW

GTS16JBRCC

GTS16JBRBB

CleanSteelCS

White Bisque Blac

GEAppliances.com

White Bisque Black

GTH18DCR

GE 17.9 cu. ft. Refrigerator

• Upfront temperature controls

• Factory-installed automatic icemaker

• Sealed vegetable/fruit crispers

• Spillproof freezer floor

• Gallon door storage

• Slide-out, slide-over pan removal system

• NeverClean condenser

GTH18DCRWW

GTH18DCRCC

GTH18DCRBB

GTH18DBRWW

non-icemaker model

GTH18DBRCC

non-icemaker model

GTH18DBRBB

non-icemaker model

GTS18DBPWW

GTS18DBPCC

GTS18DBPBB

GTS18DBP

GE 17.9 cu. ft. Refrigerator

• Upfront temperature controls

• Sealed vegetable/fruit crispers

• Spillproof freezer floor

• Gallon door storage

• Slide-out, slide-over pan removal system

• NeverClean condenser

• Deluxe quiet design

GTS18DCPWW

icemaker model

GTS18DCPCC

icemaker model

GTS18DCPBB

icemaker model

Bold = feature upgrade from previous model.

GTR18BBR

GE®17.9 cu. ft. Refrigerator

• Upfront temperature controls

• Recessed handles

• Vegetable/fruit crispers

• Adjustable wire shelves

• Tall bottle door storage

• NeverClean

™

condenser

• Deluxe quiet design

GTR18BBRWW

GTR18BBRCC

Top-Freezer Refrigerators

GTR17BBRWW

GTR17BBRCC

GTR17BBR (not shown)

Similar to the GTR18BBR with 17.2 cu. ft. capacity

GTR15BBRWW

GTR15BBRCC

GTR15BBR (not shown)

Similar to the GTR18BBR with 14.9 cu. ft. capacity

GTS17BCR

GE 17.2 cu. ft. Refrigerator

• Upfront temperature controls

• Factory-installed automatic icemaker

• Two vegetable/fruit crispers

• Adjustable wire shelves

• Tall bottle door storage

• NeverClean condenser

• Deluxe quiet design

GTS17BCRWW

GTS17BCRCC

GTS17BBRWW

non-icemaker model

GTS17BBRCC

non-icemaker model

GTS16BBRWW

GTS16BBRCC

GTS16BBRBB

GTS16BBR (not shown)

Similar to the GTS17BBR with 15.8 cu. ft. capacity

White Bisque Blac

GEAppliances.com

White Bisque Black

GTS15BBR

GE 14.9 cu. ft. Refrigerator

• Upfront temperature controls

• Two vegetable/fruit crispers

• Adjustable wire shelves

• Tall bottle door storage

• NeverClean condenser

• Deluxe quiet design

GTS12BBP

GE 11.9 cu. ft. Refrigerator

• Adjustable wire shelves

• Full-width divided vegetable/fruit crisper

• Tall bottle door storage

• Fixed freezer door shelves

• Equipped for optional automatic icemaker

• Dairy compartment

• Rounded doors

GTS12BBPWW

GTS12BBPCC

GTR11AAP

GE 11.4 cu. ft. Refrigerator

• Adjustable wire shelves

• Recessed handles

• Full-width vegetable/fruit crisper

• Tall bottle door storage

• Fixed freezer door shelves

• Rounded doors

GTR11AAPWW

GTS15BCRWW

icemaker model

GTS15BCRCC

icemaker model

GTS15BBRWW

GTS15BBRCC

GTS15BBRBB

GTH15BBRWW

ENERGY STAR

-qualified, non-icemaker model

GTH15BBRCC

ENERGY STAR-qualified, non-icemaker model

Bold = feature upgrade from previous model.

Manual Defrost Refrigerator, Compact Refrigerators and Wine Cooler

GMS10AAM

GE®9.7 cu. ft. Manual Defrost Refrigerator

• Adjustable wire shelves

• Full-width vegetable/fruit crisper

• Tall bottle storage

GMS10AAMWW

PWR04FAN

GE Profile™4.3 cu. ft. Wine Cooler

• Electronic adjustable controls

• 29 bottle capacity

• Slide-out shelves

• Clear glass door

• Interior light

• Lock

• Contoured door

PWR04FANBS

GE Spacemaker®Compact Refrigerators

• Manual defrost

• Wire cabinet shelves

• Fresh food door shelves

• Ice ’N Easy trays

GMR06AAP

• 6.0 cu. ft. capacity

• Can rack

• Interior light

• Built-in capability

GMR04AAM

• 4.3 cu. ft. capacity

• Can rack

• Recessed handles

GMR02BAN

• 1.7 cu. ft. capacity

• Recessed handles

GMR06AAPWW

GMR06AAPBB*

GMR04AAMWW

GMR04AAMBB

GMR02BANWW

GMR02BANBB

*Optional wood panel trim kit available. (Installation option & model number on page 62.)

Stainless steel White Blac

GEAppliances.com

Upright and Chest Freezers

GE Frost-Free Upright Freezers

• Adjustable temperature control

• Slide-out bulk storage basket

• Interior light

• Lock

• Limited food loss warranty

• Available in white only

GE Manual Defrost Upright Freezers

• Adjustable temperature control

• Interior light*

• Lock*

• Limited food loss warranty

• Available in white only

*Not available on models

FUM14SM or FUM5SN.

*Not available on model FCM15SP. *Not available on model FCM5SM.

GE Manual Defrost Chest Freezers

• Adjustable temperature control

• Upfront defrost water drain

• Interior light*

• Lock*

• Limited food loss warranty

• Available in white only

GE Manual Defrost Chest Freezers

• Adjustable temperature control

• Upfront defrost water drain

• Lock*

• Available in white only

FUF20DPWH

• 20.3 cu. ft. capacity

• 5 cabinet shelves (3 adj.)

• 6 door shelves (2 juice shelves)

FUF17DPWH

• 16.7 cu. ft. capacity

• 4 cabinet shelves (3 adj.)

• 5 door shelves (2 juice shelves)

FUF14DPWH

• 13.7 cu. ft. capacity

• 3 cabinet shelves (2 adj.)

• 5 door shelves (2 juice shelves)

FCM25RMWW

• 25.1 cu. ft. capacity

• 4 lift-out and sliding bulk storage baskets

FCM20DPWH

• 19.7 cu. ft. capacity

• 3 lift-out and sliding bulk storage baskets

FCM15DPWH

• 14.8 cu. ft. capacity

• 2 lift-out and sliding bulk storage baskets

FCM15SPWH

• 14.8 cu. ft. capacity

• 1 lift-out and sliding bulk storage basket

FCM9DMWH

• 8.8 cu. ft. capacity

• 2 lift-out and sliding bulk storage baskets

• Interior light

• Limited food loss warranty

FCM7DNWH

• 7.0 cu. ft. capacity

• 2 lift-out and sliding bulk storage baskets

• Power “On” light

• Limited food loss warranty

FCM5DMWH

• 5.0 cu. ft. capacity

• 2 lift-out and sliding bulk storage baskets

• Power “On” light

FCM5SMWH

• 5.0 cu. ft. capacity

• 1 lift-out and sliding bulk storage basket

FUM21DPWH

• 20.6 cu. ft. capacity

• Slide-out bulk storage basket

• 5 cabinet shelves (1 adj.)

• 6 door shelves

FUM17DPWH

• 17.1 cu. ft. capacity

• Slide-out bulk storage basket

• 4 cabinet shelves (1 adj.)

• 5 door shelves

FUM14DPWH

• 14.1 cu. ft. capacity

• Slide-out bulk storage basket

• 4 cabinet shelves (1 adj.)

• 5 door shelves

FUM14SMWH

• 14.1 cu. ft. capacity

• 3 cabinet shelves

• 5 door shelves

FUM5SNWH

• 5.0 cu. ft. capacity

• 2 cabinet shelves

• 3 door shelves

GE Profile™Built-In Side-by-Side Refrigerators

PSB42LSR PSB42LGR

Stainless steel model ●

Capacity

Total (cu. ft.) 25.2 25.2 Fresh food (cu. ft.) 15.6 15.6 Freezer (cu. ft.) 9.6 9.6 Shelf area (sq. ft.) 23.36 23.36

Fresh Food Features

ClimateKeeper™ system ●●

Multiflow air system ●● Upfront electronic digital display ●● Electronic touch temp. controls Dispenser Dispenser

Electronic sensors ●● SmartWater™ filtration system Plus Plus SoftTouch dispenser Crushed Ice, Cubes, Water Crushed Ice, Cubes, Water

Light ●●

Door alarm ●●

Quick Ice™ feature ●●

Water filter indicator light ●● Cabinet shelves 4 Glass 4 Glass

Adjustable 3 3

Spillproof 4 4 Deli pan Clear Clear Vegetable/fruit crispers 2 Adj. Humidity 2 Adj. Humidity ClearLook™ door bins 4 (3 Adj.) 4 (3 Adj.) Dairy compartment ●● Interior light system Dual-level Dual-level Quiet Design Premium Premium NeverClean™ condenser ●● ENERGY STAR

●●

Freezer Features

FrostGuard™ technology ●● Factory-installed automatic icemaker & bin ●● Wire slide-out baskets 2 2 Wire cabinet shelves 4 4 Fixed door bins 3 3 Interior light Dual Dual

Exterior

Color(s) available* BV WV, BV CustomStyle configuration Trimless Installed Trim Door handles Stainless-look, full-length Stainless-look, full-length Door hinge Hydraulic damper design Hydraulic damper design Adjustable rollers Front Front

Weights & Dimensions

Height to top of hinge (in.) A 83-29/32 83-29/32 Case depth with door handle (in.) B 26-29/32 26-29/32 Width (in.) C 42 42

Approx. shipping weight (lbs.) 627 627 Power/Rating 120V, 60Hz, 15Amps 120V, 60Hz, 15Amps

Accessories

Black acrylic panels N/A PSPK42RBB White acrylic panels N/A PSPK42RWW

*Color(s) available: WV = White dispenser and visor handles, BV = Black dispenser and

visor handles. If installed against a wall, allow clearance of 4" on freezer side to remove bin. Clearance required to remove fresh food full size pan without disassembling is 4".

ALL MODELS AVAILABLE IN U.S. AND CANADA.

GE Profile

Total volume and shelf area are calculated by the Association of Home Appliance Manufacturers’ standards.

Listed by Underwriters Laboratories

Front View

Side-By-Side Refrigerators

Built-In Refrigerators

Top View

GEAppliances.com

GE Profile Arctica®and GE CustomStyle™Side-by-Side Refrigerators

PSH23PSR PSC23SHR PSC23NHP PSI23SCR PSC23MGP GSC23LSR

PSW23PSR PSH23PGR PSC23SGR PSI23SGR PSC23NGP PSI23NGP PSI23NCP PSI23MGP GSC23LGQ GSC21KGR

Stainless steel model ●●/ – ●● ●/ – ● / –

Capacity

Total (cu. ft.) 22.6 22.6 22.7 / 22.6 22.6 22.7 / 22.6 22.6 22.6 22.7 22.7 21.4 Fresh food (cu. ft.)

14.38 14.38 14.41 /14.38

14.38

14.41 /14.38

14.38 14.38 14.38 14.38 13.62 Freezer (cu. ft.) 8.17 8.17 8.17 8.24 8.24 / 8.17 8.24 8.19 8.26 8.26 7.83 Shelf area (sq. ft.) 19.7 19.7 18.6 / 19.7 19.7 18.6 / 19.7 19.7 20.6 19.0 18.5 18.2

Fresh Food Features

Refreshment center ● / – ● / – ClimateKeeper system ClimateKeeper2™ ClimateKeeper2 ●●●●●●

Dual evaporator ●● Multiflow air system ●●●●●●●● Upfront electronic digital display ●●●●●●● Upfront electronic touch temp. controls ●●●●●●●● ● ● Electronic sensors ●●●●●●●●● ● TurboCool™ setting ●●●●●●●● ●

SmartWater filtration system Plus Plus Plus Plus Plus Plus Plus Plus Plus

Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice,

LightTouch! dispenser Cubes, Water Cubes, Water Cubes, Water Cubes, Water Cubes, Water Cubes, Water Cubes, Water Cubes, Water Cubes, Water

Light ●●●●●● ● ● ● Child lock ●●●●●● ● ● ● Door alarm ●●●●●● ●● Quick Ice feature ●●●●●● ● Water filter indicator light ●●●●●● ●● ●

Cabinet shelves 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass

Adjustable 3 3 3 3 3 3 3 3 3 3 Slide-out, spillproof 2 2 2 2 2 2 2 2 2 2

QuickSpace™ shelf ●●●●●●●● ● Integrated shelf support system ●●●●●●●●● ● Snugger™ clip(s) 2 2 1 / 2 2 1 / 2 2 2 2 3-Stack drawer system ●●●●●●●● ● ●

Deli drawer Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Sealed Sealed

Vegetable/fruit crisper Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity

CustomCool™ CustomCool CustomCool CustomCool CustomCool CustomCool CustomCool

Sealed drawer w/full-extension w/full-extension w/full-extension w/full-extension w/full-extension w/full-extension w/full-extension Full-extension ●●

3 (1 Adj.) 3 (1 Adj.)

ClearLook door bins 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) Dairy compartment (removable) ●●●●●●●●● ●

Can storage rack Can storage rack

Beverage rack In-the-door In-the-door In-the-door In-the-door In-the-door In-the-door In-the-door In-the-door Interior light system Tri-level Tri-level Tri-level Tri-level Tri-level Tri-level Tri-level Dual-level Dual-level Dual-level Quiet Design Super premium Super premium Premium Premium Premium Premium Premium Premium Deluxe Deluxe NeverClean condenser ●●●●●●●●● ● ENERGY STAR ●●

Freezer Features

FrostGuard technology ●●●●●●●●● ● Integrated Ice™ system ●●●●●● ● ● Wire slide-out baskets 4 (3 full-ext.) 4 (3 full-ext.) 4 (3 full-ext.) 4 (3 full-ext.) 4 (3 full-ext.) 4 (3 full-ext.) 4 (3 full-ext.) 331 Wire cabinet shelves 2 2 2 (1 slide-out) 2 (1 slide-out) 2 (1 slide-out) 2 (1 slide-out) 2 (1 slide-out) 2 (1 slide-out) 2 (1 slide-out) 2 (1 slide-out) Wire tilt-out door bin(s) 3 (2 Adj.) 3 (2 Adj.) 3 (2 Adj.) 3 (2 Adj.) 3 (2 Adj.) 3 (2 Adj.) 4 (3 Adj.) 3 (2 Adj.) Door shelves 4 (2 Adj.) 3 (2 Adj.) Interior light Dual Dual Dual Dual Dual Dual Dual Dual Dual Single

Exterior

Color(s) available* SS SV / WW, CC, BB SS SV WW, CC, BB WW, CC, BB SV / WW,CC, BB WW, CC, BB SS / WW, BB WW, BB CustomStyle configuration Trimless

Trimless/Install.Trim

Trimless Trimless Trimless Installed Trim

Trimless/Install.Trim Trimless/Install.Trim

Trimless Trimless

Full-length visor/ Full-length visor/ CM Profile/

Sculptured CM Full-length Sculptured CM Full-length CM Full-length CM Full-length Stainless steel/

Door handles* stainless steel visor stainless steel Full-length visor CM Profile visor v isor visor CM CM

Full-wrap Rounded doors/

Exterior design contoured Squared doors Rounded doors Squared doors Rounded doors Squared doors Squared doors Squared doors Rounded doors Rounded doors Textured steel door and case Case only Case only / ● Case only Case only ● Case only Case only ● / Case only Case only / ●● Adjustable rollers All All All All All All All All Front Front

Weights & Dimensions

Height to top of hinge (in.) A 70-1/2 † 69-1/4 69-1/4 69-1/4 69-1/4 69-1/4 69-1/4 69-1/4 69-1/4 69-1/4 Height to top of case (in.) B 70-1/2 68-3/4 68-3/4 68-3/4 68-3/4 68-3/4 68-3/4 68-3/4 68-3/4 68-3/4 Height to top of door trim (in.) 70-1/4 70-1/4 70-1/4 70-1/4 – / 70-1/4 Case depth without door (in.) C 23-7/8 23-7/8 23-7/8 23-7/8 23-7/8 23-7/8 23-7/8 23-7/8 23-7/8 23-7/8 Case depth less door handle (in.) D 31-1/4 31-1/4 26-3/4 26-3/4 26-3/4 26-3/4 26-3/4 26-3/4 26-3/4 26-3/4 Case depth with door handle (in.) E 33-9/16 33-9/16 29-3/16 28-5/16 29-3/16 28-5/16 28-5/16

29-3/16 / 28-5/16

29-3/16 29-3/16

Depth w/fresh food door open 90° (in.) F 50-1/16 50-1/16 45-9/16 45-9/16 45-9/16 45-9/16 45-9/16 45-9/16 45-9/16 45-9/16 Width (in.) G 35-3/4†† 35-3/4 35-3/4 35-3/4 35-3/4 35-3/4 35-3/4 35-3/4 35-3/4 35-3/4 Width w/door open 90°

w/door handle (in.) H 36-1/4 36-1/4 38-3/16 37-5/16 38-3/16 37-5/16 37-5/16

38-3/16 / 37-5/16

38-3/16 38-3/16

Air clearances Each side (in.) 1/8 1/8 1/8 1/8 1/8 1/8 1/8 1/8 1/8 1/8

Top (in.) 1 1 1 1 1 1 1 1 1 1

Back (in.) 1 1 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 Approx. shipping weight (lbs.) 338 338 334 334 334 334 334 334 334 334 Power/Rating 120V, 60Hz, 15Amps

Accessories

Factory trim kit attached N/A N/A / ● N/A N/A N/A ● N/A / ● N/A / ● N/A N/A Black acrylic panels (optional) N/A N/A /PSPK23DBB N/A N/A N/A

PSPK23DBB N/A / PSPK23CBB N/A / PSPK23DBB

N/A N/A

White acrylic panels (optional) N/A N/A / PSPK23DWW N/A N/A N/A

PSPK23DWW N/A / PSPK23CWW N/A / PSPK23DWW

N/A N/A

Bisque acrylic panels (optional) N/A N/A / PSPK23DCC N/A N/A N/A

PSPK23DCC N/A / PSPK23CCC N/A / PSPK23DCC

N/A N/A

Stainless steel panels (optional) N/A N/A / PSPK23DSS N/A N /A N/A

PSPK23DSS N/A N/A / PSPK23DSS

N/A N/A

Black collar trim (optional) N/A TRMBISBB N/A TRMBISBB N/A

TRMBISBB TRMBISBB N/A / TRMBISBB

N/A N/A

White collar trim (optional) N/A TRMBISWW N/A TRMBISWW N/A

TRMBISWW TRMBISWW N/A / TRMBISWW

N/A N/A

Bisque collar trim (optional) N/A TRMBISCC N/A TRMBISCC N/A

TRMBISCC TRMBISCC N/A / TRMBISCC

N/A N/A

Stainless steel collar trim (optional) N/A TRMBISSS N/A TRMBISSS N/A

TRMBISSS TRMBISSS N/A / TRMBISSS

N/A N/A

*Color(s) available: SV = Stainless steel with visor handles, SS = Stainless steel, WW = White on white, CC = Bisque on bisque, BB = Black on black, CM = Color-Matched. †When cap is removed: 69-1/4". ††Width including caps: 36-3/16".

If installed against a wall, allow clearance of 13-15/16" on freezer side to remove bin. Clearance required to remove fresh food full size pan without disassembling is 18-5/8".

ALL MODELS AVAILABLE IN U.S. AND CANADA.

GE Profile

GE Profile Arctica CustomStyle™Side-by-Side Installation Information & Specifications

Create a Custom Look for Your GE Profile CustomStyle Side-by-Side Refrigerator

Still another advantage offered by GE Profile CustomStyle Refrigerators is ease of installation. For a refrigerator that does so much to enhance the beauty of your kitchen, the “behind-the-scenes” preparation and installation are surprisingly simple.

W3624

1/2" to 3/4" Side Panel

Side Tri m

Route

hand slot

before

installing

panel.

Select appropriate size door panel from cabinet line.

T D

M L

Fabricating the Enclosure

• The drawing shows an 84" cabinet elevation. Adjust dimensions accordingly for other cabinet elevations.

• Cabinet pieces to order: (2) side panels and (1) wall cabinet.

• Side panels will typically be attached to adjacent cabinets and/or cleated to rear wall and floor.

• Refer to GE refrigerator installation instructions for proper plumbing, and electrical and air clearances.

• (1) Some framed cabinet lines will make a refrigerator enclosure with a cabinet 12" high x 39" wide with sides and 1-1/2" face frame extended down to floor to create the refrigerator space. This will replace the above construction. (2) A tall cabinet on either side of the refrigerator can replace a side panel.

• Counter overhangs on either side of the refrigerator should have clipped corners to allow for full door swing.

• If the refrigerator has a wall returning beyond the front of the refrigerator on either side, a 2" tall filler will help allow for movement of the door.

Door Panels

• See drawings for exact dimensions of the fresh-food and freezer door panels.

• Refrigerator door fronts from stock and most semi-custom cabinet manufacturers will be supplied as 1/4"-thick panels cut to dimensions, with closest available standard door sizes applied to front.

–This will leave a “reveal” at top/bottom and sides. Width of “reveal” will depend

on manufacturer’s standard door sizes.

–Door will be affixed on the 1/4" panels at factory or in the field by the local

supplier, depending on manufacturer.

• Local shop-built or custom cabinet supplier may fabricate custom 3/4" panels. In this case, edges must be routed.

• Follow notes on drawing to assure room for fingers/hands to open handles.

Standard, New Construction and Replacement Installation

Rough-In Dimensions

• All wall/floor molding should be removed prior to installation.

• Water recess on rear wall recommended to prevent water line damage. 48" minimum length, 1/4"-diameter water line tubing recommended.

• When possible, recess both copper water line and electrical outlet (see local codes).

• Front and rear leveling legs are adjustable for the built-in look (see owner’s manual).

• If optional collar trim kit is to be used or anticipated, see collar trim installation on next page for different rough-in dimensions.

Installation Tips to Maximize the Built-In Look

IMPORTANT: Before finalizing specifications for your GE Profile CustomStyle Refrigerator, please NOTE:

• A minimum width of 36" is required for refrigerator installation

• Be sure to allow for 1/2" or 3/4" side panels in addition to the 36" minimum

8' Ceiling

13" to 14" Cabinet

12" Soffit

70-1/4"*

36"

24"

*The rough-in dimension of 70-1/4" is minimum and is measured from the

finished floor to top of opening (or the underside of the overhead cabinets). For Models with Trim Kit: If frameless style cabinets are planned for above the refrigerator, you may need to consider adding a maximum of 1/4" (70-1/2") to height of opening to allow additional clearance between cabinet doors and top of refrigerator trim when cabinet doors are in open position.

25" Counter Top

ElectricalWater

3/4" Airspace (1/2" Gap + 1/4"

Wall Plates) 24" Cabinet

Recommended water line location using recess in rear wall

Recommended single loop of 1/4" copper water line

Water hook-up on the refrigerator

Rear Wall View

18"

24"

Allow 48" minimum water line to enable refrigerator to be pulled forward

Installation of Water Outlets

Alternate water line location through floor

1/2"

Top View

GEAppliances.com

An enclosure is required to match up to the trim (see Typical Installation). To obtain the most integrated look, the cabinet or soffit above the refrigerator should extend out to the same depth as the side panels. The refrigerator opening must have minimum dimensions of 70-1/4" high x 36-1/8" wide x 24-1/2" deep as shown at right. If there is an overhead cabinet, allow 1" for cabinet door clearance with the top trim piece so the cabinet doors can be opened without hitting the top trim. If 1/2" side panels are used, then side trim and panel will be even. If 3/4" side panels are used, then some of the side panel will extend beyond the trim and must be finished.

Collar Trim Installation

Typical Installation

Shaded areas represent front surfaces of side panels and overhead cabinet or soffit that contacts trim.

Overhead Cabinet

Cabinet Door

Top Trim

Case

Magnetic Tape

3/4" Cabinet Side Panel

1/2" Cabinet Side Panel

Side trim must be installed flush with the gasket contact surface on the case.

Refrigerator Case

Side TrimDoor Gasket

IMPORTANT: Before finalizing specifications for your GE Profile CustomStyle Refrigerator, please NOTE:

• A minimum width of 36-1/8" is required for refrigerator installation with collar

• Be sure to allow for 1/2" or 3/4" side panels in addition to the 36-1/8" minimum

70-1/4"*

36-1/8"

24-1/2"*

1/2" minimum

*The rough-in dimension of 70-1/4" is minimum and is measured from the

finished floor to top of opening (or the underside of the overhead cabinets).

For Models with Trim Kit: If frameless style cabinets are planned for above the refrigerator, you may need to consider adding a maximum of 1/4" (70-1/2") to height of opening to allow additional clearance between cabinet doors and

top of refrigerator trim when cabinet doors are in open position.

Order your own custom wood panels to match cabinetry or other decor.

Panels up to 1/4" thick will fit door frame with no special preparation. Add filler behind material thinner than 1/4" for proper fit.

Weight Limits: Total weight of panels (i.e., both freezer panels)— Fresh Food = 38 lbs., Freezer = 28 lbs.

Note: Panels up to 3/4" will require special routing area around handles. Dimensions may vary depending on depth of panel.

(Fresh Food panel shown) Notch required at top corner as noted.

Door Panel Dimensions

Cut out

1/8 1/8

14-15/32 14-15/32

14-15/32

33-5/8

17-7/8

19-15/32

5/16

Cut out

1/8

5/16 5/16

FRONT

67-9/32 67-9/32

FRONT FRONT

Detail C

5/16"

1/8"

1/4" Max.

Panels 1/4" thick

or less

Freezer Panel without Dispenser

Freezer Panel with Dispenser

Fresh Food Panel

GE Profile Arctica®Side-by-Side Refrigerators

PSS29NHP PSS29NGP PSS27SGR PSS27NGP PSS26SHR PSW26SGR PSS26NHP PSF26NGP

Stainless steel model ●●●

Capacity

Total (cu. ft.) 28.7 28.6 26.5 26.5 25.5 25.5 25.5 25.5 Fresh food (cu. ft.) 17.92 17.85 16.60 16.60 16.02 16.02 16.02 16.02 Freezer (cu. ft.) 10.68 10.68 9.92 9.92 9.48 9.48 9.48 9.48 Shelf area (sq. ft.) 24.0 25.0 23.8 23.8 22.8 23.6 22.8 23.6

Fresh Food Features

Refreshment center ● ●● ClimateKeeper™ system ●●● ●●● ●●

Multiflow air system ●●● ●●● ●● Upfront electronic digital display ●●● ●● ●●● Upfront electronic touch temp. controls ●●● ●● ●●● Electronic sensors ●● ● ●●●● ● TurboCool™ setting ●● ● ●●● ●●

SmartWater™ filtration system Plus Plus Plus Plus Plus Plus Plus Plus

Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice,

LightTouch! dispenser Cubes, Water Cubes, Water Cubes, Water Cubes, Water Cubes, Water Cubes, Water Cubes, Water Cubes, Water

Light ●●● ● ●●● ● Child lock ●●● ●● ●● ● Door alarm ●●● ●●● ●● Quick Ice™ feature ●● ● ●●●● ● Water filter indicator light ●●● ●●● ●●

Cabinet shelves 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass

Adjustable 3 3 3 3 3 3 3 3 Slide-out, spillproof 2 2 2 2 2 2 2 2

QuickSpace™ shelf ●●●● ●●● ● Integrated shelf support system ●●● ●●● ●● Snugger™ clip(s) 2 2 2 2 2 2 2 2 3-Stack drawer system ●● ● ●●● ●●

Deli drawer Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp.

Vegetable/fruit crisper Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity

CustomCool™ CustomCool CustomCool CustomCool CustomCool CustomCool CustomCool CustomCool

Sealed drawer w/full-extension w/full-extension w/full-extension w/full-extension w/full-extension w/full-extension w/full-extension w/full-extension ClearLook™ door bins 3 (1 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 3 (1 Adj.) 4 (3 Adj.) 3 (1 Adj.) 4 (3 Adj.) Dairy compartment (removable) ●● ●● ●●● ● Beverage rack Can storage rack In-the-door In-the-door In-the-door Can storage rack In-the-door Can storage rack In-the-door Interior light system Tri-level Tri-level Tri-level Tri-level Tri-level Tri-level Tri-level Tri-level Quiet Design Premium Premium Premium Premium Premium Premium Premium Premium NeverClean™ condenser ●● ●● ●●● ● 2004 ENERGY STAR

●●●●

Freezer Features

FrostGuard™ technology ●●●●● ●● ● Integrated Ice™ system ●●● ● ●●● ● Wire slide-out baskets 4 (3 full-ext.) 4 (3 full-ext.) 4 (3 full-ext.) 4 (3 full-ext.) 4 (3 full-ext.) 4 (3 full-ext.) 4 (3 full-ext.) 4 (3 full-ext.) Wire cabinet shelves 2 2 2 2 2 2 2 2 Wire tilt-out door bin(s) 3 (2 Adj.) 3 (2 Adj.) 3 (2 Adj.) 3 (2 Adj.) 3 (2 Adj.) 3 (2 Adj.) 3 (2 Adj.) 3 (2 Adj.) Door shelves 1 1 1 1 1 1 1 1 Interior light Dual Dual Dual Dual Dual Dual Dual Dual

Exterior

Color(s) available* WW, CC, BB WW, CC, BB SS WW, CC, BB SS SS WW, CC, BB WW, CC, BB

Color-Matched Color-Matched Sculptured Color-Matched Sculptured Sculptured Color-Matched Color-Matched

Door handle(s) Contoured Profile Contoured Profile Stainless steel Contoured Profile Stainless steel Stainless steel Contoured Profile Contoured Profile

Full-Wrap

Exterior design Contoured Contoured Contoured Contoured Contoured Contoured Contoured High-Gloss Textured steel door and case ●●Case only ● Case only ● Case only Adjustable rollers Front Front Front Front Front Front Front Front

Weights & Dimensions

Height to top of hinge (in.) A 69-1/4 69-1/4 69-1/4 69-1/4 69-1/4 70-1/2†† 69-1/4 69-1/4 Height to top of case (in.) B 68-3/4 68-3/4 68-3/4 68-3/4 68-3/4 70-1/2 68-3/4 68-3/4 Case depth without door(in.) C † 28 28 28 28 28 28-1/2 28 28 Case depth less door handle (in.) D† 33-9/16 33-9/16 32-1/4 32-1/4 32-1/4 32-3/4 32-1/4 32-1/4 Case depth with door handle (in.) E† 36 36 34-11/16 34-11/16 34-11/16 35-3/16 34-11/16 34-11/16

Depth w/fresh food door open 90°(in.) F † 49-11/16 49-11/16 50-1/16 50-1/16 50-1/16 50-9/16 50-1/16 50-1/16

Width (in.) G 35-3/4 35-3/4 35-3/4 35-3/4 35-3/4 35-7/8** 35-3/4 35-3/4 Width w/door open 90°

w/door handle (in.) H 39 39 36-1/4 36-1/4 36-1/4 36-1/4 36-1/4 36-1/4

Air clearances Each side (in.) 1/8 1/8 1/8 1/8 1/8 1/8 1/8 1/8

Top (in.) 1 1 1 1 1 1 1 1

Back (in.) 1 1 1 1 1 1 1 1 Approx. shipping weight (lbs.) 320 320 346 346 346 393 346 365 Power/Rating 120V, 60Hz, 15Amps

*Color(s) available: SS = Stainless steel, WW = White on white, CC = Bisque on bisque, BB = Black on black.

**Width including caps is 36-3/16".

†Water hook-up fits in back air clearance when calculating installation depth. ††When cap is removed: 69-1/4". If installed against a wall, allow clearance of 14-3/16" on 25 cu. ft., 26 cu. ft. and 27 cu. ft. models; 13" on 29 cu. ft. models on freezer side to remove ice bin. To remove fresh food pans, remove door bins. Clearances required to remove fresh food full-size pan without disassembling: 18-15/16" on 25 cu. ft., 26 cu. ft. and 27 cu. ft.; 16-1/4" on 29 cu. ft. Allow additional space for any necessary leveling adjustments.

ALL MODELS AVAILABLE IN U.S. AND CANADA. Energy information available at www.GEAppliances.com

GE Profile

™

GEAppliances.com

PSS26SGR PSS26NGP PSS26MSR PSS26MGP PSS26LSR PSS26LGR

●●●

25.5 25.5 25.5 25.5 25.6 25.6

16.02 16.02 16.02 16.02 16.02 16.02

9.48 9.48 9.48 9.48 9.6 9.6

23.6 23.6 23.7 23.7 23.8 23.8

●●●●

●●

●●●● ● ●

Plus Plus Plus Plus Plus Plus

Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice,

Cubes, Water Cubes, Water Cubes, Water Cubes, Water Cubes, Water Cubes, Water

●●●● ● ●

●●●●

●●●● ● ●

3 Glass 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass

3333 3 3 2222 2 2

●●●● ● ●

2222

●●●● ● ●

Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. ●●

Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity

CustomCool CustomCool

w/full-extension w/full-extension Full-extension Full-extension ●●

4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.)

●●●● ● ●

In-the-door In-the-door In-the-door In-the-door Wine rack Wine rack

Tri-level Tri-level Dual-level Dual-level Dual-level Dual-level

Premium Premium Premium Premium Premium Premium

●●●● ● ●

4 (3 full-ext.) 4 (3 full-ext.) 3 full-ext. 3 full-ext. 3-1/2 3-1/2

2222 2 2

3 (2 Adj.) 3 (2 Adj.) 3 (2 Adj.) 3 (2 Adj.)

1 1 1 1 4 (2 Adj.) 4 (2 Adj.)

Dual Dual Dual Dual Dual Dual

SS WW, CC, BB SS WW, CC, BB SS WW, CC, BB

Sculptured Color-Matched Sculptured Color-Matched Sculptured Color-Matched

Stainless steel Contoured Profile Stainless steel Contoured Profile Stainless steel Contoured Profile

Contoured Contoured Contoured Contoured Contoured Contoured

Case only ● Case only ● Case only ●

Front Front Front Front Front Front

69-1/4 69-1/4 69-1/4 69-1/4 69-1/4 69-1/4 68-3/4 68-3/4 68-3/4 68-3/4 68-3/4 68-3/4

28 28 28 28 28 28

32-1/4 32-1/4 32-1/4 32-1/4 31-1/4 31-1/4

34-11/16 34-11/16 34-11/16 34-11/16 33-9/16 33-9/16

50-1/16 50-1/16 50-1/16 50-1/16 50-1/16 50-1/16

35-3/4 35-3/4 35-3/4 35-3/4 35-3/4 35-3/4

36-1/4 36-1/4 36-1/4 36-1/4 36-1/4 36-1/4

1/8 1/8 1/8 1/8 1/8 1/8

1111 1 1 1111 1 1

347 347 347 338 338

120V, 60Hz, 15Amps

Total volume and shelf area are calculated by the Association of Home Appliance Manufacturers’ standards.

Listed by Underwriters Laboratories

Front View

Side-by-Side Refrigerators

Top View

GE®Side-by-Side Refrigerators

GSH25SGR GSS25SGR GSL25WGP GSS25WGP GSS25JEP GSH22SGR GSS22SGR GSH25KGR GSH22KGR GSL22WGP GSS22WGP GSS22JEP

Stainless steel model ●●

Capacity

Total (cu. ft.) 25.0 / 21.9 25.0 / 21.9 25.0 21.9 25.0 / 21.9 25.0 / 21.9 25.0 / 22.0 Fresh food (cu. ft.) 15.40 / 14.77 15.40 / 14.77 15.40 14.77 15.40 / 14.84 15.40 / 14.84 15.40 / 14.84 Freezer (cu. ft.) 9.56 / 7.14 9.56 / 7.14 9.56 7.14 9.56 / 7.14 9.56 / 7.14 9.56 / 7.14 Shelf area (sq. ft.) 24.3 / 22.4 24.3 / 22.4 24.3 22.4 24.3 / 22.3 24.3 / 22.3 22.3 / 20.3

Fresh Food Features

SmartWater™ filtration system Plus Plus Plus Plus Plus Plus

Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice,

LightTouch! dispenser features Cubes, Water Cubes, Water Cubes, Water Cubes, Water Cubes, Water Cubes, Water Cubes, Water

Light ●●●●●●● Child lock ●●●● Water filter indicator light ●●●●●●

Upfront electronic touch temperature controls ●●●●●●

Upfront electronic temperature controls ●●●●●●● Cabinet shelves 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass

Adjustable 3 3 33333 Slide-out 3 3 3333

Spillproof 3 3 33333 Snugger™ clip 1 1 1111 2-Stack drawer system ●●●●●●●

Deli drawer 1 Adj. Temp. 1 Adj. Temp. 1 Adj. Temp. 1 Adj. Temp. 1 Adj. Temp. 1 Adj. Temp. 1 Adj. Temp.

Vegetable/fruit crisper 1 Adj. Humidity 1 Adj. Humidity 1 Adj. Humidity 1 Adj. Humidity 1 Adj. Humidity 1 Adj. Humidity 1 Sealed Snack pan ●●●●1 Adj. Humidity 1 Adj. Humidity

4 (2 Adj. w/ 4 (2 Adj. w/ 4 (2 Adj. w/ 4 (2 Adj. w/ 4 (2 Adj. w/ 4 (2 Adj. w/ 4 (2 Adj. w/

Adjustable door bins gallon storage) gallon storage gallon storage) gallon storage) gallon storage) gallon storage) gallon storage) Dairy compartment ●●●●●●● Can storage rack (door) ●● Interior light system Dual-level Dual-level Dual-level Dual-level Dual-level Dual-level Single-level Quiet Design Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe NeverClean™ condenser ●●●●●●● ENERGY STAR

●●●

Freezer Features

Factory-installed icemaker and bin ●●●●●●● FrostGuard™ technology ●●●●●●● Wire cabinet shelves 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) 4 (3 Adj.) Storage basket(s) 1 slide-out 1 slide-out 1 slide-out 1 slide-out 1 slide-out 1 slide-out 1 bin Door shelves 5 5 55555 Interior light ●●●●●●●

Appearance

Color(s) available* SS SS WW, CC, BB WW, CC, BB CleanSteel

™

WW, CC, BB WW, CC, BB Deluxe door handle(s)* Stainless Steel Stainless Steel CM Premium CM Premium Black CM Profile CM Premium Textured steel door and case Case only Case only ●●Case only ●● Adjustable rollers Front Front Front Front Front Front Front

Weights & Dimensions

Height to top of hinge (in.) A 69-3/4 / 67-1/2 69-3/4 / 67-1/2 69-3/4 67-1/2 69-3/4 / 67-1/2 69-3/4 / 67-1/2 69-3/4 / 67-1/2 Height to top of case (in.) B 68-3/4 / 66-1/2 68-3/4 / 66-1/2 68-3/4 66-1/2 68-3/4 / 66-1/2 68-3/4 / 66-1/2 68-3/4 / 66-1/2 Case depth without door (in.) C† 28 28 28 28 28 28 28 Case depth less door handle (in.) D† 31-1/4 31-1/4 31-1/4 31-1/4 31-1/4 31-3/4 31-1/4 Case depth with door handle (in.) E† 33-9/16 33-9/16 33-9/16 33-9/16 33-9/16 33-9/16 33-9/16 Depth with fresh food door

open 90° (in.) F† 49-3/8 49-3/8 49-3/8 49-3/8 49-3/8 49-3/8 49-3/8 Width (in.) G 35-3/4 / 33-1/2 35-3/4 / 33-1/2 35-3/4 33-1/2 35-3/4 / 33-1/2 35-3/4 / 33-1/2 35-3/4 / 33-1/2 Width w/door open 90°

w/door handle (in.) H 38-3/16 / 35-15/16 38-3/16 / 35-15/16 38-3/16 35-15/16 38-3/16 / 35-15/16 38-3/16 / 35-15/16 38-3/16 / 35-15/16

Air clearances Each side (in.) 1/8 1/8 1/8 1/8 1/8 1/8 1/8

Top (in.) 1 1 1 1111

Back (in.) 1 1 1 1111 Approx. shipping weight (lbs.) 338 / 334 338 / 334 338 315 338 / 315 338 / 315 338 / 321 Power/Ratings 120V, 60Hz, 15Amps

*Color(s) available: SS = Stainless steel, WW = White on white, CC = Bisque on bisque, BB= Black on black, CM = Color-Matched, CleanSteel= Stainless appearance. †Water hook-up fits in back air clearance when calculating installation depth.

If installed against a wall, allow clearance of 10-3/4" on 20 cu. ft. and 22 cu. ft. models; 14-3/16" on 25 cu. ft. models on freezer side to remove bin. Clearances required to remove fresh food full-size pan without disassembling: 13-1/2" on 20 cu. ft.; 15" on 22 cu. ft.; and 18-15/16" on 25 cu. ft. Allow additional space for any necessary leveling adjustments.

ALL MODELS AVAILABLE IN U.S. AND CANADA.

GE “K” Series GE “W” Series GE “J” Series

Total volume and shelf area are calculated by the Association of Home Appliance Manufacturers’ standards.

Listed by Underwriters Laboratories

Front View

Side-By-Side Refrigerators

Top View

GEAppliances.com

GSS25IFP GSS22IBP GSS22IFP GSS20IEP GSS20IBP GSS20DBP

Capacity

Total (cu. ft.) 25.0 / 22.0 20.0 21.9 / 19.9 19.9 Fresh food (cu. ft.) 15.48 / 14.84 12.87 14.87 / 12.87 12.87 Freezer (cu. ft.) 9.56 / 7.14 7.14 7.04 7.04 Shelf area (sq. ft.) 22.3 / 20.3 17.3 21.1 / 18.0 18.1

Fresh Food Features

SmartWater filtration system ●

Crushed Ice, Crushed Ice,

LightTouch! dispenser features Cubes, Water Cubes, Water

Light ●● Upfront electronic temperature controls ●●● ● Cabinet shelves 3 glass 3 glass 3 glass 3 wire Everwhite

Adjustable 3 3 3 3 Meat drawer 1 sealed 1 sealed 1 sealed 1 sealed opaque Vegetable/fruit crisper 1 sealed 1 sealed 1 sealed 1 sealed opaque

4 (2 adj. w/ 4 (2 w/ 4 (2 w/ 4 (2 w/

Door bins gallon storage) gallon storage) gallon storage) gallon storage) Dairy compartment ●●● ● Interior light system Single-level Single-level Single-level Single-level Quiet Design Deluxe Deluxe Deluxe Deluxe NeverClean condenser ●●● ●

Freezer Features

Factory-installed icemaker and bin ●●Opt. (IM5SS) Opt. (IM5SS) FrostGuard technology ●●● ●

5 (4 adj.)

Wire cabinet shelves 3 (2 adj.) 3 (2 adj.) 4 (3 adj.) 4 (3 adj.) Storage basket(s) 1 bin 1 bin 1 bin 1 bin Door shelves 5 5 6 6 Interior light ●●● ●

Appearance

Color(s) available* WW, CC, BB WW, CC, BB WW, CC WW, CC Deluxe door handle(s)* CM CM CM CM Textured steel door and case ●●● ● Adjustable rollers Front Front Front Front

Weights & Dimensions

Height to top of hinge (in.) A 69-3/4 / 67-1/2 67-1/2 67-1/2 67-1/2 Height to top of case (in.) B 68-3/4 / 66-1/2 66-1/2 66-1/2 66-1/2 Case depth without door (in.) C† 28 28 28 28 Case depth less door handle (in.) D† 31-1/4 31-1/4 31-1/4 31-1/4 Case depth with door handle (in.) E† 33-9/16 33-9/16 33-9/16 33-9/16 Depth with fresh food door

open 90° (in.) F† 49-3/8 47-3/8 49-3/8 / 47-3/8 47-3/8 Width (in.) G 35-3/4 / 33-1/2 31-1/2 33-1/2 / 31-1/2 31-1/2 Width w/door open 90°

w/door handle (in.) H 38-3/16 / 35-15/16 33-15/16 35-15/16 / 33-15/16 33-15/16

Air clearances Each side (in.) 1/8 1/8 1/8 1/8

Top (in.) 1 1 1 1

Back (in.) 1 1 1 1 Approx. shipping weight (lbs.) 344 / 321 306 321/ 306 306 Power/Ratings 120V, 60 Hz, 15Amps

*Color(s) available: WW = White on white, CC = Bisque on bisque, BB= Black on black, CM = Color-Matched. †Water hook-up fits in back air clearance when calculating installation depth.

ALL MODELS AVAILABLE IN U.S. AND CANADA.

GE “I” Series GE “D” Series

Total volume and shelf area are calculated by the Association of Home Appliance Manufacturers’ standards.

Listed by Underwriters Laboratories

Front View

Side-By-Side Refrigerators

Top View

GE Profile™and GE®Bottom-Freezer Refrigerators

Front View Top View

Bottom-Freezer Refrigerators

PDW22SHR PDS22SHR PDS22MHR PDS22SCR PDS20SCR PDS20MCR GBS22KBR GBS22HCR PDW22SCR PDF22MCR PDS22SBR PDS22MBR PDS22MCR PDS20SBR PDS20MBR GBS20KBR GBS22HBR

Stainless steel model ●●●/ – ●

Capacity

Total (cu. ft.) 22.2 22.2 22.2 22.2 22.2 19.5 19.5 22.3 / 19.5 22.3 Fresh food (cu. ft.) 15.21 15.21 15.21 15.21 15.21 13.21 13.21 15.21 / 13.21 15.22 Freezer (cu. ft.) 7.04 7.04 7.04 7.04 7.04 6.31 6.31 7.05 / 6.32 7.09 Shelf area (sq. ft.) 27.66 27.66 27.66 27.66 27.66 24.44 24.44 23.99 / 21.43 24.27

Fresh Food Features

Cabinet shelves 4 Glass 4 Glass 4 Glass 4 Glass 4 Glass 4 Glass 4 Glass 4 Glass 3 Glass

Adjustable 4 Split 4 Split 4 Split 4 Split 4 Split 4 Split 4 Split 4 Split 2 Split, 1 F/W Slide-out 2 2 2 2 2 2 2 Spillproof 4 4 4 4 4 4 4 4

QuickSpace shelf ● ● ●● ●●● Internal water dispenser ● / – ● / – ● / – GE SmartWater™ filtration ●●●/ – ● / – ●●/ – ● / – ShelfSaver™ rack ● ● ●● ●●● Vegetable/fruit crisper(s) 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Clear Deli drawer Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Adj. Humidity Clear Clear Pivot-out pan removal system ● ● ●● ●● ●●● ClearLook™ adjustable gallon door bins 4 4 4 4 4 4 4 4 opaque Snugger™ clip ●● ●● ●● ●

1 F/W w/ 1 F/W w/ 1 F/W w/ 1 F/W w/ 1 F/W w/ 1 F/W w/ 1 F/W w/ 1 F/W w/ 2 F/W w/

Fixed door bins gallon storage gallon storage gallon storage gallon storage gallon storage gallon storage gallon storage gallon storage gallon storage Dairy compartment ● ● ●●●● ● ●● Interior light (GE Reveal™) Dual Dual Dual Dual Dual Dual Dual Dual Dual Quiet Design Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe NeverClean™ condenser ● ● ●● ●●● ●● 2004 ENERGY STAR

●● ●● ●● ● ●●

Freezer Features

Integrated Integrated Integrated Integrated ●

Factory-installed icemaker & bin Integrated Integrated Opt. (IM4A) Opt. (IM4A) Integrated Opt. (IM4A) Opt. (IM4A) Opt. (IM4A) Opt. (IM4A) Ice ’N Easy trays – / 2 – / 2 – / 2 – / 2 2 – / 2 Full slide-out wire basket(s) 2 F/W, 1 Split 2 F/W, 1 Split 2 F/W, 1 Split 2 F/W, 1 Split 2 F/W, 1 Split 2 F/W, 1 Split 2 F/W, 1 Split 1 F/W, 1 Split 1 F/W Wire compartment shelves 1 F/W Door shelves 1 Split 1 Split Interior light (GE Reveal) ● ● ●● ●● ●●●

Exterior

Color(s) available* SS WW, BB SS WW, CC, BB SS / WW, CC, BB SS WW, CC, BB WW, CC, BB WW, CC, BB

Sculptured

Door handle(s) Sculptured Color-Matched Sculptured Color-Matched Color-Matched Sculptured Color-Matched Color-Matched Color-Matched Customer installed handles ●● ●● ●● ● ●●

Full-wrap Contoured

Exterior design contoured High-Gloss Contoured Doors Contoured Doors Contoured Doors Contoured Doors Contoured Doors Contoured Doors Contoured Doors Door stops ● ● ●● ●●● ●● Reversible doors ●●– / ●●●● Choose left or right door opening Right only ●●/ – ● Adjustable rollers Front Front Front Front Front Front Front Front Front

Weights & Dimensions

Height to top of hinge (in.) A 68-5/8 68-5/8 68-5/8 68-5/8 68-5/8 68 68 68-5/8 / 68 68-5/8 Height to top of case (in.) B 70 67-7/8 67-7/8 67-7/8 67-7/8 67-1/4 67-1/4 67-7/8 / 67-1/4 67-7/8 Case depth without door (in.) C 28-1/2 28-1/4 28-1/4 28-1/4 28-1/4 28-1/4 28-1/4 28-1/4 28-1/4 Case depth less door handle (in.) D 32 31-3/4 31-3/4 31-3/4 31-3/4 31-3/4 31-3/4 31-3/4 31-3/4 Case depth with door handle (in.) E 34-1/4 33-7/8 33-7/8 33-7/8 33-7/8 33-7/8 33-7/8 34-1/8 34-1/8 Depth w/fresh food door open 90° (in.) F 59-1/4 62 62 62 62 59 59 62 / 59 62 Width (in.) G 33 32-7/8 32-7/8 32-7/8 32-7/8 29-7/8 29-7/8 32-7/8 / 29-7/8 32-7/8 Width with door open 90°

w/door handle (in.) H 36-3/4 36-1/4 36-1/4 36-1/4 36-1/4 33-1/4 33-1/4 36-1/2 / 33-1/2 36-1/2

Air clearances Each side (in.) 1/8 1/8 1/8 1/8 1/8 1/8 1/8 1/8 1/8

Top (in.) 1 1 1 1 1 1 1 1 1

Back (in.) 1 1 1 1 1 1 1 1 1 Approx. shipping weight (lbs.) 337 287 287 287 287 265 265 287 / 265 287 Power/Ratings 120V, 60Hz, 15Amps

*Color(s) available: SS = Stainless steel, WW = White on white, CC = Bisque on bisque, BB = Black on black.

ALL MODELS AVAILABLE IN U.S. AND CANADA.

GE Profile GE

Total volume and shelf area are calculated by the Association of Home Appliance Manufacturers’ standards.

Listed by Underwriters Laboratories

GEAppliances.com

GE Bottom-Freezer Refrigerators

Front View Top View

Bottom-Freezer Refrigerators

Total volume and shelf area are calculated by the Association of Home Appliance Manufacturers’ standards.

Listed by Underwriters Laboratories

GDS18SCR GDS18LCR GDS18SBR GDS18LBR GBS18HBR

Stainless steel model ●●

Capacity

Total (cu. ft.) 18.1 18.1 18.1 18.1 18.1 Fresh food (cu. ft.) 13.44 13.44 13.44 13.44 13.44 Freezer (cu. ft.) 4.64 4.64 4.64 4.64 4.64 Shelf area (sq. ft.) 21.0 21.0 21.0 21.0 22.2

Fresh Food Features

Brita®Filtered Water Door Module ●●●● Cabinet shelves 4 Glass 4 Glass 4 Glass 4 Glass 3 Glass

Adjustable 4 Split 4 Split 4 Split 4 Split 2 Split, 1 F/W Slide-out 2 2 2 2

Spillproof 4 4 4 4 ShelfSaver rack ●● ●● Vegetable/fruit crisper(s) 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Clear Snack pan Clear Clear Clear Clear Clear

Slide over, Slide over, Slide over, Slide over, Slide over,

Pivot-out pan removal system slide out slide out slide out slide out slide out Adjustable gallon door bins 3 3 3 3 Snugger clip ●●●●

1 F/W w/ 1 F/W w/ 1 F/W w/ 1 F/W 2 F/W w/

Fixed door bins gallon storage gallon storage gallon storage w/gallon storage gallon storage Dairy compartment ●●●●● Interior light Dual Dual Dual Dual Dual Quiet Design Deluxe Deluxe Deluxe Deluxe Deluxe NeverClean condenser ●●●●● 2004 ENERGY STAR ●●●●●

Freezer Features

Factory-installed icemaker & bin ●●Opt. (IM4A) Opt. (IM4A) Opt. (IM4A) Ice ’N Easy trays 2 2 2 Ice storage bin ●● ● Full slide-out wire basket(s) 1 F/W, 2 Split 1 F/W, 2 Split 1 F/W, 2 Split 1 F/W, 2 Split 1 F/W Wire compartment shelves 1 F/W Interior light ●● ●●●

Exterior

Color(s) available* SS WW, CC, BB SS WW, CC, BB WW, CC, BB Door handle(s) SS Tubular Color-Matched SS Tubular Color-Matched Color-Matched Exterior design Rounded Doors Rounded Doors Rounded Doors Rounded Doors Rounded Doors Door stops ●●●●● Reversible doors ●●● Choose left or right door opening ●● Adjustable rollers Front Front Front Front Front

Weights & Dimensions

Height to top of hinge (in.) A 66-1/4 66-1/4 66-1/4 66-1/4 66-1/4 Height to top of case (in.) B 65-3/4 65-3/4 65-3/4 65-3/4 65-3/4 Case depth without door (in.) C 25-1/4 25-1/4 25-1/4 25-1/4 25-1/4 Case depth less door handle (in.) D 28 28 28 28 28 Case depth with door handle (in.) E 30-3/8 30-3/8 30-3/8 30-3/8 30-3/8 Depth w/fresh food door open 90° (in.) F 57-3/4 57-3/4 57-3/4 57-3/4 57-3/4 Width (in.) G 31 31 31 31 31 Width with door open 90°

w/door handle (in.) H 33-1/2 33-5/8 33-1/2 33-5/8 33-5/8

Air clearances Each side (in.) 0 0 0 0 0

Top (in.) 1 1 1 1 1

Back (in.) 1/2 1/2 1/2 1/2 1/2 Approx. shipping weight (lbs.) 257 257 257 257 262 Power/Ratings 120V, 60Hz, 15Amps

*Color(s) available: SS = Stainless steel, WW = White on white, CC = Bisque on bisque, BB = Black on black.

ALL MODELS AVAILABLE IN U.S. AND CANADA.

GE Profile CustomStyle™Top-Freezer Refrigerators

PTC22MBM PTC22MFM PTC22SBM PTC22SFM PTI22MBM PTI22MFM PTI22SFM

Stainless steel model ●● ●

Capacity

Total (cu. ft.) 21.9 21.7 21.9 21.7 21.9 21.7 21.7 Fresh food (cu. ft.) 15.4 15.4 15.4 15.4 15.4 15.4 15.4 Freezer (cu. ft.) 6.5 6.3 6.5 6.3 6.5 6.3 6.3 Shelf area (sq. ft.) 22.4 20 22.4 20 22.4 20 20

Fresh Food Features

SmartWater™ filtration system ●●●●

Crushed Ice, Crushed Ice, Crushed Ice, Crushed Ice,

LightTouch! dispenser Cubes, Water Cubes, Water Cubes, Water Cubes, Water Upfront illuminated temperature controls ●●● ●●● ● Cabinet shelves 4 Glass 4 Glass 4 Glass 4 Glass 4 Glass 4 Glass 4 Glass

Adjustable 4 Split 4 Split 4 Split 4 Split 4 Split 4 Split 4 Split

Slide-out, spillproof 3 3 3 3 3 3 3 Snugger™ clip ●●● ●●● ● QuickSpace™ shelf ●●●● ●● ● Meat pan Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Vegetable/fruit crisper(s) 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity Slide-out, spillproof crisper cover ●●● ●●● ● ClearLook™ adjustable gallon door bins 4 4 4 4 4 4 4 Fixed door bins 1 F/W tall bottle 1 F/W tall bottle 1 F/W tall bottle 1 F/W tall bottle 1 F/W tall bottle 1 F/W tall bottle 1 F/W tall bottle Slide-out, slide-over pan removal system ●●●●● ● ● Dairy compartment ●●● ●● ● ● Wine rack ●●●● ●● ● Interior light system Dual Dual Dual Dual Dual Dual Dual Quiet Design Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe NeverClean™ condenser ●●● ●● ● ●

Freezer Features

Factory-installed icemaker & bin Opt. (IM4A) ● Opt. (IM4A) ● Opt. (IM4A) ●● Ice ’N Easy trays 3 3 3 Ice storage bin ●● ● Wire compartment shelf(s) 2 Split (Adj.) 1(Adj.) 2 Split (Adj.) 1(Adj.) 2 Split (Adj.) 1(Adj.) 1(Adj.)

2 Adj., 2 Adj., 2 Adj.,

Door bins 1 F/W fixed 2 fixed 1 F/W fixed 2 fixed 1 F/W fixed 2 fixed 2 fixed Interior light ●●●●●● ●

Exterior

Color(s) available* WW, BB WW, CC, BB BS BS WW, BB WW, BB BS CustomStyle configuration Trimless Trimless Trimless Trimless Installed Trim Installed Trim Installed Trim

Stainless Steel

Premium door handles* CM Deluxe CM Deluxe Black Deluxe Black Deluxe CM Full-Length CM Full-Length Appearance Choose right or left door opening ●●● ●●● ● Reversible doors ● Exterior design Rounded Doors Rounded Doors Rounded Doors Rounded Doors Squared Doors Squared Doors Squared Doors Adjustable rollers All All All All All All All

Weights & Dimensions

Height to top of hinge (in.) A 69-7/8 69-7/8 69-7/8 69-7/8 69-7/8 69-7/8 69-7/8 Height to top of case (in.) B 68-3/4 68-3/4 68-3/4 68-3/4 68-3/4 68-3/4 68-3/4 Height to top of door trim (in.) 70-1/2 70-1/2 70-1/2 Case depth without door (in.) C 23-3/4 23-3/4 23-3/4 23-3/4 23-3/4 23-3/4 23-3/4 Depth less door handle (in.) D 26-3/4 26-3/4 26-3/4 26-3/4 26-3/4 26-3/4 26-3/4 Depth with door handle (in.) E 28-5/8 28-5/8 28-5/8 28-5/8 28-3/8 28-3/8 28-5/8 Depth with fresh food door

open 90° (in.) F 61 61 61 61 61 61 61 Width (in.) G 35-3/4 35-3/4 35-3/4 35-3/4 35-3/4 35-3/4 35-3/4 Width with door open 90°

w/door handle (in.) H 38-1/4 38-1/4 38-1/4 38-1/4 38 38 38

Air clearances Each side (in.) 1/8 1/8 1/8 1/8 1/8 1/8 1/8

Top (in.) 1 1 1 1 1 1 1

Back (in.) 1/2 1/2 1/2 1/2 1/2 1/2 1/2 Approx. shipping weight (lbs.) 300 324 300 324 300 324 360 Power/Ratings 120V, 60Hz, 15Amps

Accessories

Black acrylic panels (optional) N/A N/A N/A N/A PTPK22CBB PTPK22DBB N/A White acrylic panels (optional) N/A N/A N/A N/A PTPK22CWW PTPK22DWW N/A Stainless steel panels (optional) N/A N/A N/A N/A PTPK22CSS PTPK22DSS N/A Black collar trim (optional) N/A N/A N/A N/A TRMBISBB TRMBISBB N/A White collar trim (optional) N/A N/A N/A N/A TRMBISWW TRMBISWW N/A Bisque collar trim (optional) N/A N/A N/A N/A N/A N/A N/A Stainless steel collar trim (optional) N/A N/A N/A N/A TRMBISSS TRMBISSS TRMBISSS

*Color(s) available: BS = Black case with stainless steel doors, WW = White on white, CC = Bisque on bisque, BB = Black on black, CM = Color-Matched.

ALL MODELS AVAILABLE IN U.S. AND CANADA.

GE Profile

™

Total volume and shelf area are calculated by the Association of Home Appliance Manufacturers’ standards.

Listed by Underwriters Laboratories

Front View

Top-Freezer No-Frost Refrigerators

Top View

GEAppliances.com

GE Profile CustomStyle Top-Freezer Refrigerators Installation Information & Specifications

Standard, New Construction and Replacement Installation

Rough-In Dimensions

• All wall/floor molding should be removed prior to installation.

• Water recess on rear wall recommended to prevent water line damage. 48" minimum length, 1/4"-diameter water line tubing recommended.

• When possible, recess both copper water line and electrical outlet (see local codes).

• Front and rear leveling legs are adjustable for the built-in look (see owner’s manual).

Handle Side Clearance

• At least 2-5/8" (67mm) on the handle side for fingertip clearances.

Top and Bottom Clearance

• At least 3/16" (4.75mm) at the top and bottom edges to allow for trim flange.

Hinge Side Clearance

• A 3/4" (19mm) -thick door panel may strike the adjacent countertops when

the door is fully opened. Therefore, the hinge side clearance to raised panel will vary according to the installation situation. –Allow 1-3/4" (44mm) clearance when installation does not include side panels. –The installation of 3/4" (19mm) -thick side panels requires less clearance

because the space between the door and adjacent countertop is wider.

• To avoid door contact to countertop, consider:

–Mitering the corner of the adjacent countertops 45°, or –Pulling the refrigerator forward enough to avoid contact.

Stability Leg

• The top-freezer refrigerator is the first cabinet-depth top-freezer. This means depth is more shallow than conventional models and the width is larger. The stability leg gives the unit extra support.

Installation Tips to Maximize the Built-In Look

25" Counter Top

ElectricalWater

3/4" Airspace (1/2" Gap + 1/4" Wall Plates)

24-1/2"* Side panels

24" Cabinet

For 22 cu. ft. models only.

8' Ceiling

13" to 14" Cabinet

12" Soffit

70-1/4"*

36"

24"

8' Ceiling

13" to 14" Cabinet

12" Soffit

70-1/4"*

36-1/8"

24-1/2"

Door Panel Dimensions

Order your own custom wood panels to match cabinetry or other decor.

Fresh Food Freezer Panel Freezer Panel Panels Without Dispenser With Dispenser

B-42-1/4" A-24-1/16" D-24-1/16"

22 cu. ft. C-35-3/4" C-35-3/4" C-35-3/4"

Panels up to 1/4" thick will fit door frame with no special preparation. Add filler behind material thinner than 1/4" for proper fit.

Note: Panels up to 3/4" will require special routing area around handles. Dimensions may vary depending on depth of panel.

IMPORTANT: Before finalizing specifications for your GE Profile CustomStyle Refrigerator, please NOTE:

• A minimum width of 36" is required for refrigerator installation

• Be sure to allow for 1/2" or 3/4" side panels in addition to the 36" minimum

*22" depth applies to the refrigerator opening,

not the actual cabinet depth.

Collar Trim Installation

Freezer Panel

Without Dispenser

Fresh Food Panel

2-5/8 Clearance Handle Side (Detail A)

Hinge Side Clearance (See Notes)

3/16

Detail B Detail B

Freezer Panel

With Dispenser

2-5/8 Clearance Handle Side (Detail A)

Hinge Side

Clearance

(See Notes)

3/16

3-15/16

15-7/16

3/16

14-7/8

1/8

5/16

Detail B

1/8

5/16

Detail B

1/8

1-3/4

2-5/8

1/4

Detail A

Area to be routed out on handle side of panel

*The rough-in dimension of 70-1/4" is minimum and is measured from the

Installation without collar trim

Installation with collar trim

Rough-In Dimensions Collar Trim Installation

GE Profile Arctica®Top-Freezer Refrigerators

PTS25SHR PTS25LHR PTS22SHR PTS22LHR PTS22SCR PTS22LCR

Stainless steel model ●●●

Capacity

Total (cu. ft.) 24.6 24.6 21.7 21.7 21.7 21.7 Fresh food (cu. ft.) 17.51 17.51 15.35 15.35 15.35 15.35 Freezer (cu. ft.) 7.08 7.08 6.35 6.35 6.35 6.35 Shelf area (sq. ft.) 29.1 29.1 26.3 26.3 26.3 26.3

Fresh Food Features

Internal water dispenser ●● ●● ClimateKeeper™ system ●● ●●● ●

Multiflow air system ●● ●●● ● Upfront electronic

touch temperature controls ●● ●●● ●

Electronic sensors ●●● ●● ● GE SmartWater™ filtration ●● ● ● Cabinet shelves 4 Glass 4 Glass 4 Glass 4 Glass 4 Glass 4 Glass

Adjustable 4 Split 4 Split 4 Split 4 Split 4 Split 4 Split

Slide-out, removable 3 3 3 3 3 3

Spillproof 4 4 4 4 4 4 ShelfSaver™ rack ●●●●● ● Deli pan Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Adj. Temp. Vegetable/fruit crisper(s) 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity Pivot-out pan removal system ●●●●● ● ClearLook™ adjustable gallon door bins 4 4 4 4 4 4 Snugger™ clip(s) 2 2 2 2 2 2 Fixed door bins 1 (Tall Bottle) 1 (Tall Bottle) 1 (Tall Bottle) 1 (Tall Bottle) 1 (Tall Bottle) 1 (Tall Bottle) Dairy compartment ●● ● ●● ● Interior light system Dual Dual Dual Dual Dual Dual Quiet Design Premium Premium Premium Premium Premium Premium NeverClean™ condenser ●● ● ●● ● 2004 ENERGY STAR

●●● ●● ●

Freezer Features

Factory-installed icemaker and bin ●● ●●● ● Multiflow air system (freezer) ●●● ●● ● FrostGuard™ technology ●●● ●●● Spillproof freezer floor ●● ● ●●● Wire freezer 1 full-width 1 full-width 1 full-width 1 full-width 1 full-width 1 full-width

compartment shelves (2 pos.) (2 pos.) (2 pos.) (2 pos.) (2 pos.) (2 pos.) Freezer door bins 2 (1 Adj.) 2 (1 Adj.) 2 (1 Adj.) 2 (1 Adj.) 2 (1 Adj.) 2 (1 Adj.) Tilt-out locking freezer door bin ●●● ●● ● Interior light ●● ● ●● ●

Exterior

Color(s) available* BS WW, CC, BB BS WW, CC, BB BS WW, CC, BB Deluxe door handle(s) Black Color-Matched Black Color-Matched Black Color-Matched Customer installed handles ●● ●●● ● Exterior design Rounded Doors Rounded Doors Rounded Doors Rounded Doors Rounded Doors Rounded Doors Reversible doors ●● ●●● ● Adjustable rollers Front Front Front Front Front Front

Weights & Dimensions

Height to top of hinge (in.) A 68-5/8 68-5/8 67-1/2 67-1/2 67-1/2 67-1/2 Height to top of case (in.) B 67-7/8 67-7/8 66-7/8 66-7/8 66-7/8 66-7/8 Case depth without door (in.) C 27-5/8 27-5/8 27-5/8 27-5/8 27-5/8 27-5/8 Case depth less door handle (in.) D 31-5/8 31-5/8 31-5/8 31-5/8 31-5/8 31-5/8 Case depth with door handle (in.) E 33-5/8 33-5/8 33-5/8 33-5/8 33-5/8 33-5/8 Depth w/fresh food door open 90° (in.) F 66 66 63 63 63 63 Width (in.) G 35 7/8 35-7/8 32-7/8 32-7/8 32-7/8 32-7/8 Width w/door open 90°

w/door handle (in.) H 38 38 35 35 35 35

Air clearances Each side (in.) 1/8 1/8 1/8 1/8 1/8 1/8

Top (in.) 1 1 1 1 1 1

Back (in.) 1 1 1 1 1 1 Approx. shipping weight (lbs.) 310 310 260 260 260 260 Power/Ratings 120V, 60Hz, 15Amps

*Color(s) available: BS = Black case with stainless steel doors, WW = White on white, CC = Bisque on bisque, BB = Black on black.

ALL MODELS AVAILABLE IN U.S. AND CANADA.

GE Profile

Total volume and shelf area are calculated by the Association of Home Appliance Manufacturers’ standards.

Listed by Underwriters Laboratories

Front View

Top-Freezer No-Frost Refrigerators

Top View

GE®Top-Freezer Refrigerators

GEAppliances.com

Total volume and shelf area are calculated by the Association of Home Appliance Manufacturers’ standards.

Listed by Underwriters Laboratories

Front View

Top-Freezer No-Frost Refrigerators

Top View

GTH22SBR GTH22KBR GTH18KBR GTS18SBP

GTS22WCP GTS18WCP GTH22SHR GTS22KHP GTS22KBP GTS18KBP GTS18KHP GTS18SHP

Capacity

Total (cu. ft.) 21.7 17.9 21.7 21.7 21.7 17.9 17.9 17.9 Fresh food (cu. ft.) 15.35 12.87 15.35 15.35 15.35 12.87 12.87 12.87 Freezer (cu. ft.) 6.35 4.98 6.35 6.35 6.35 4.98 4.98 4.98 Shelf area (sq. ft.) 24.9 22.0 25.3 24.9 25.3 22.4 22.4 22.4

Fresh Food Features

Upfront temperature controls Illuminated Illuminated Illuminated Illuminated Illuminated Illuminated Illuminated Illuminated Cabinet shelves 4 Glass (Lift-off) 4 Glass (Lift-off) 4 Glass 4 Glass 4 Glass 4 Glass 4 Glass 4 Glass

Adjustable 4 Split 4 Split 4 Split 4 Split 4 Split 4 Split 4 Split 4 Split

Spillproof 4 4 4 4 4 4 4 4 Internal water dispenser – / ●● ●– / ● GE SmartWater filtration – / ●● ●– / ●

2 Adj. Humidity 2 Adj. Humidity

Vegetable/fruit crisper(s) window window 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity 2 Adj. Humidity Snack pan ●●●● ● ●● ●

Slide over, Slide over, Slide over, Slide over,

Pivot-out pan removal system ● Slide out ●● ●Slide out Slide out Slide out Adjustable gallon door bins 3 3 3 3 3 3 3 3 Fixed door bins 1 (Tall Bottle) 1 (Tall Bottle) 1 (Tall Bottle) 1 (Tall Bottle) 1 (Tall Bottle) 1 (Tall Bottle) 1 (Tall Bottle) 1 (Tall Bottle) Dairy compartment ●● ●●● ●● ● Interior light system Dual Dual Dual Dual Dual Dual Dual Dual Quiet Design Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe NeverClean condenser ●● ●●● ●● ● ENERGY STAR ●●/ – ● / –

Freezer Features

Factory-installed icemaker and bin ●●Opt. (IM4A) / ●● Opt. (IM4A) Opt. (IM4A) ● Opt. (IM4A) / ● Ice ’N Easy trays 2 / – 2 2 2 / – FrostGuard technology ●●/ – Spillproof freezer floor ●●●● ● ●● ● Wire freezer compartment shelves 1 F/W (2 pos.) Step 1 F/W (2 pos.) 1 F/W (2 pos.) 1 F/W (2 pos.) Step Step Step Adjustable door bins 1 1 1 1 Fixed door bins 1 Split (1 F/W) 2 Split (1 F/W) 1 Split (1 F/W) 1 Split (1 F/W) 1 Split (1 F/W) 2 Split (1 F/W) 2 Split (1 F/W) 2 Split (1 F/W) Interior light ●● ●● ● ●● ●

Exterior

Color(s) available* WW, CC, BB WW, CC BS WW, CC, BB WW / WW, CC, BB WW, CC, BB WW, CC, BB BS Door handle(s)* CM CM Black CM CM CM CM Black Customer installed handles ●●●● ● ●● ● Exterior design Rounded Doors Rounded Doors Rounded Doors Rounded Doors Rounded Doors Rounded Doors Rounded Doors Square Doors Reversible doors ●●●● ● ●● ● Adjustable rollers Front Front Front Front Front Front Front Front

Weights & Dimensions

Height to top of hinge (in.) A 67-1/2 66-5/8 67-1/2 67-1/2 67-1/2 66-5/8 66-5/8 66-5/8 Height to top of case (in.) B 66-7/8 66-1/8 66-7/8 66-7/8 66-7/8 66-1/8 66-1/8 66-1/8 Height to mid-freezer (in.) 54-1/2 53-15/16 54-1/2 54-1/2 54-1/2 53-15/16 53-15/16 53-15/16 Case depth without door (in.) C 27-5/8 27-1/2 27-5/8 27-5/8 27-5/8 27-1/2 27-1/2 27-1/2 Case depth less door handle (in.) D 31-5/8 30-1/4 31-5/8 31-5/8 31-5/8 30-1/4 30-1/4 30-1/4 Case depth with door handle (in.) E 33-5/8 32-1/8 33-5/8 33-5/8 33-5/8 32-1/8 32-1/8 32-1/8 Depth w/fresh food door open 90° (in.) F 63 58-1/8 63 63 63 58-1/8 58-1/8 58-1/8 Width (in.) G 32-7/8 29-1/2 32-7/8 32-7/8 32-7/8 29-1/2 29-1/2 29-1/2 Width w/door open 90°

w/door handle (in.) H 35 32 35 35 35 32 32 32

Air clearances Each side (in.) 1/8 1/8 1/8 1/8 1/8 1/8 1/8 1/8

Top (in.) 1 1 1 1 1 1 1 1

Back (in.) 1 1 1 1 1 1 1 1 Approx. shipping weight (lbs.) 260 233 255 260 255 231 231 231 Power/Ratings 120V, 60Hz, 15Amps

*Color(s) available: BS = Black case with Stainless steel doors, WW = White on white, CC = Bisque on bisque, BB = Black on black, CM = Color-Matched.

ALL MODELS AVAILABLE IN U.S. AND CANADA.

GE “W” Series GE “K” Series

Note: All Top-Freezer No-Frost Right-Hand Refrigerator Doors: As you face the front

of the refrigerator, the handle is on your left and the hinges are on your right. All Top-Freezer No-Frost Left-Hand Refrigerator Doors: As you face the front of the refrigerator, the handle is on your right and the hinges are on your left.

GE®Top-Freezer Refrigerators

GTL22JBP GTS22JBP GTL18JBP GTH18JBR GTH18DCR GTH18DBR GTL22JCP GTS22JCP GTL18JCP GTS18JCP GTS18JBP GTL16JBR GTS16JBR GTS18DCP GTS18DBP

Capacity

Total (cu. ft.) 21.8 21.8 17.9 17.9 17.9 15.8 15.8 17.9 17.9 Fresh food (cu. ft.) 15.47 15.47 12.89 12.89 12.89 11.69 11.69 12.89 12.89 Freezer (cu. ft.) 6.37 6.37 5.03 5.03 5.03 4.11 4.11 5.03 5.03 Shelf area (sq. ft.) 25.4 /25.1 25.4 /25.1 22.6 22.2 22.6 22.2 22.6

Fresh Food Features

Upfront temperature controls Illuminated Illuminated Illuminated Illuminated Illuminated ●●Illuminated Illuminated Cabinet shelves 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass 3 Glass 2 Wire, 1 Glass 2 Wire, 1 Glass

1 F/W, 1 Split wire 1 F/W, 1 Split wire

Adjustable 2 Split, 1 F/W 2 Split, 1 F/W 2 Split, 1 F/W 2 Split, 1 F/W 2 Split, 1 F/W 2 Split, 1 F/W 2 Split, 1 F/W 1 Split glass 1 Split glass

Spillproof ●●●●●●● Vegetable/fruit crisper(s) 2 Clear 2 Clear 2 Clear 2 Clear 2 Clear 2 Adj. Humidity 2 Adj. Humidity 2 White 2 White Snack pan Clear Clear Clear Clear Clear Clear Clear White White

Slide-out, Slide-out, Slide-out, Slide-out, Slide-out, Slide-out, Slide-out,

Pivot-out pan removal system ●●Slide over Slide over Slide over Slide over Slide over Slide over Slide over

2 F/W 2 F/W, 1 w/ 2 F/W 2 F/W 2 F/W

Fixed door bins w/gallon storage gallon storage w/gallon storage w/gallon storage w/gallon storage

1/2 1/2 1/2 1/2 1/2 2 F/W 2 F/W 1 Split w/gallon, 1 Split w/gallon,

Door shelves w/gallon storage w/gallon storage w/gallon storage w/gallon storage w/gallon storage w/gallon storage w/gallon storage 2 F/W w/gallon 2 F/W w/gallon Dairy compartment ●●●●●●●●● Interior light system Dual Dual Dual Dual Dual Single Single Single Single Quiet Design Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe NeverClean™ condenser ●●●●●●●●● ENERGY STAR

● / – ● / – ● / –

Freezer Features

Factory-installed icemaker & bin Opt. (IM4A) / ● Opt. (IM4A) / ● Opt. (IM4A) / ●● Opt. (IM4A) Opt. (IM4A) Opt. (IM4A) ● Opt. (IM4A) Ice ’N Easy trays 2 / – 2 / – 2 / – 2 2 2 2 Spillproof freezer floor ●●●●●●●●● Wire freezer compartment shelves 1 F/W (2 pos.) 1 F/W (2 pos.) Step Step Step Step Step Step Step Fixed door shelves 2 Full-width 2 Full-width 2 Full-width 2 Full-width 2 Full-width 2 Full-width 2 Full-width 2 2

Exterior

Color(s) available* CleanSteel™ WW, CC CleanSteel WW, CC WW, CC CleanSteel WW, BB, CC WW, CC, BB WW, CC, BB Door handle(s)* Black CM Black CM CM Black CM CM CM Customer installed handles ●●●●● ●● Exterior design Rounded Doors Rounded Doors Rounded Doors Rounded Doors Rounded Doors Square Doors Square Doors Rounded Doors Rounded Doors Reversible doors ●●●●●●●●● Choose right or left door opening ●● Adjustable rollers Front Front Front Front Front Front Front Front Front

Weights & Dimensions

Height to top of hinge (in.) A 67-1/2 67-1/2 66-5/8 66-5/8 66-5/8 64-3/4 64-3/4 66-5/8 66-5/8 Height to top of case (in.) B 66-7/8 66-7/8 66-1/8 66-1/8 66-1/8 64-1/4 64-1/4 66-1/8 66-1/8 Height to mid-freezer (in.) 54-1/2 54-1/2 53-15/16 53-15/16 53-15/16 54-3/8 54-3/8 53-15/16 53-15/16 Case depth without door (in.) C 27-5/8 27-5/8 27-1/2 27-1/2 27-1/2 25-7/8 25-7/8 27-1/2 27-1/2 Case depth less door handle (in.) D 31-5/8 31-5/8 30-1/4 30-1/4 30-1/4 29-1/8 29-1/8 30-1/4 30-1/4 Case depth with door handle (in.) E 33-5/8 33-5/8 32-1/8 32-1/8 32-1/8 31 31 32-1/8 32-1/8 Depth w/fresh food door open 90° (in.) F 63 63 58-1/8 58-1/8 58-1/8 54-7/8 54-7/8 58-1/8 58-1/8 Width (in.) G 32-7/8 32-7/8 29-1/2 29-1/2 29-1/2 28 28 29-1/2 29-1/2 Width w/door open 90°

w/door handle (in.) H 35 35 32 32 32 30-1/2 30-1/2 32 32

Air clearances Each side (in.) 1/8 1/8 1/8 1/8 1/8 1/8 1/8 1/8 1/8

Top (in.) 1 1 1111111

Back (in.) 1 1 1111111 Approx. shipping weight (lbs.) 255 /260 255/ 260 231 226 226 166 166 228 223 Power/Ratings 120V, 60Hz, 15Amps

*Color(s) available: WW = White on white, CC = Bisque on bisque, BB = Black on black, CM = Color-Matched, CleanSteel™= Stainless appearance.

ALL MODELS AVAILABLE IN U.S. AND CANADA.

GE “J” Series GE “D” Series

Total volume and shelf area are calculated by the Association of Home Appliance Manufacturers’ standards.

Listed by Underwriters Laboratories

Front View

Top-Freezer No-Frost Refrigerators

Top View

Note: All Top-Freezer No-Frost Right-Hand Refrigerator Doors: As you face the front

GEAppliances.com

GE Top-Freezer Refrigerators

GTS17BBR GTS15BBR

GTR18BBR GTS17BCR GTR17BBR GTS16BBR GTH15BBR GTS15BCR GTR15BBR GTS12BBP GTR11AAP

Capacity

Total (cu. ft.) 17.9 17.2 17.2 15.8 14.9 14.9 14.9 11.9 11.44 Fresh food (cu. ft.) 13.62 13.05 13.05 11.69 10.77 10.77 10.77 8.94 8.45 Freezer (cu. ft.) 4.01 3.86 3.86 3.86 3.86 3.86 3.86 2.95 2.99 Shelf area (sq. ft.) 18.0 17.5 /16.7 17.5 17.2 17.2 16.4 17.2 12.1 13.4

Fresh Food Features

Upfront temperature controls ●●●●●●● Cabinet shelves 2 Wire 2 Wire 2 Wire 2 Wire 2 Wire 2 Wire 2 Wire 2 Wire 2 Wire

Adjustable 2 F/W 2 F/W 2 F/W 2 F/W 2 F/W 2 F/W 2 F/W 2 F/W 2 F/W Vegetable/fruit crisper(s) 2 2 2 2 2 2 2 1 F/W Divided 1 F/W Door shelves 2 (Tall Bottle) 2 (Tall Bottle) 2 (Tall Bottle) 2 (Tall Bottle) 2 (Tall Bottle) 2 (Tall Bottle) 2 (Tall Bottle) 2-1/2 (1 Tall Bottle) 4 (1 Tall Bottle) Dairy compartment ●●●●●●●● Interior light system Single Single Single Single Single Single Single Single Single Quiet Design Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe Deluxe Standard Standard NeverClean condenser ●●●●●●● ENERGY STAR – / ●

Freezer Features

Factory-installed icemaker & bin Opt. (IM4A) Opt. (IM4A) / ● Opt. (IM4A) Opt. (IM4A) Opt. (IM4A) ● Opt. (IM4A) Opt. (IM4A) Ice 'N Easy trays 2 2 / – 2 2 2 2 1 2 Wire freezer compartment shelves 1 F/W Fixed door shelves 2 2 2 2 2 2 2 2 2

Exterior

WW, CC, BB

Color(s) available* WW, CC WW, CC WW, CC WW, CC, BB WW, CC WW, CC WW, CC WW, CC WW Door handle(s)* CM Recessed CM CM Recessed CM CM CM CM Recessed CM CM Recessed Exterior design Square Doors Square Doors Square Doors Square Doors Square Doors Square Doors Square Doors Rounded Doors Contoured Doors Reversible doors ●●●●●●●●● Choose right or left door opening ●● ●●●● ● Adjustable rollers Front Front Front Front Front Front Front

Weights & Dimensions

Height to top of hinge (in.) A 67-3/8 67-3/8 67-3/8 64-1/4 61-3/4 61-3/4 61-3/4 60-1/2 57-7/8 Height to top of case (in.) B 66-7/8 66-7/8 66-7/8 64-3/4 61-1/4 61-1/4 61-1/4 60 57-3/8 Height to mid-freezer (in.) 57 57 57 54-3/8 51-3/8 51-3/8 51-3/8 52 50 Case depth without door (in.) C 26-3/4 26-3/4 26-3/4 25-7/8 25-7/8 25-7/8 25-7/8 27-3/4 28-1/4 Case depth less door handle (in.) D 30-1/2 30 30 29-1/8 29-1/8 29-1/8 29-1/8 30-5/8 31-1/8 Case depth with door handle (in.) E 30-1/2 31-7/8 30 31 31 31 29-1/8 32-3/8 31-1/8 Depth w/fresh food door open 90° (in.) F 56-3/8 55-3/4 55-3/4 54-7/8 54-7/8 54-7/8 54-7/8 51-5/8 52-3/4 Width (in.) G 28 28 28 28 28 28 28 23-7/8 23-7/8 Width w/door open 90°

w/door handle (in.) H 28-7/8 30-1/2 28-5/8 30-1/2 30-1/2 30-1/2 28-5/8 26-1/2 25-1/8

Air clearances Each side (in.) 3/4 3/4 3/4 3/4 3/4 3/4 3/4 1 1

Top (in.) 1 1 1 1 1 1 1 4 4

Back (in.) 1 1 1 1 1 1 1 2 3 Approx. shipping weight (lbs.) 178 179 / 184 178 166 166 171 165 170 163 Power/Ratings 120V, 60Hz, 15Amps

*Color(s) available: WW = White on white, CC = Bisque on bisque, BB = Black on black, CM = Color-Matched.

ALL MODELS AVAILABLE IN U.S. AND CANADA.

GE “B” Series GE “A” Series

Total volume and shelf area are calculated by the Association of Home Appliance Manufacturers’ standards.

Listed by Underwriters Laboratories

Front View

Top-Freezer No-Frost Refrigerators

Top View

Note: All Top-Freezer No-Frost Right-Hand Refrigerator Doors: As you face the front

GE Profile™Wine Cooler

GE Spacemaker

Compact Refrigerators

GE®Manual Defrost Refrigerator

GMS10AAM

Capacity

Total (cu. ft.) 9.7 Fresh food (cu. ft.) 8.74 Freezer (cu. ft.) .97* Shelf area (sq. ft.) 9.88

Features

Ice ’N Easy trays 2 Freezer chiller tray with baffle ● Cabinet shelves 2 Adj. Vegetable/fruit crisper 1 F/W Door shelves 5 (2 Egg w/Pockets) Tall bottle storage on door ● Dairy compartment(s) 1 Freezer compartment shelf(s) 1 F/W

Economical/Quiet

Cabinet/door insulation Foam Cabinet/door liner Plastic

Appearance

Color(s) available White Door handle(s) Black Right or left door opening ●

Weights & Dimensions

Height to top of hinge (in.) A 58 Height to top of case (in.) B 57-9/16 Case depth without door (in.) C 21 -3/8 Case depth with door less handle (in.) D 23 -1/2 Case depth with door handle (in.) E 24 -13/16 Depth with door open 90°

less door handle (in.) F 44-13/16 Width (in.) G 23 Width w/door open 90°

less door handle (in.) H 23 -1/2

Air clearances Each side (in.) 5/8

Top (in.) 2 Back (in.) 1

Approx. shipping weight (lbs.) 135

Front View Top View

Manual Defrost Single-Door Refrigerator

GE Profile

PWR04FANBS

Capacity

Total (cu. ft.) 4.3 Bottle capacity 29

Features

Electronic touch controls ● Adjustable temperature control (45-65°F) ● See-through door ● Door design Contoured Pull-out and adjustable racks Chrome wine rack Multiple shelf liner positions 5 full-width, 1 display Interior light ● Interior light timer (60 min. delay) ● Lock ●

Appearance

Color(s) available Black case and Stainless trim Door handle Recessed Free-standing ● Meets California Energy Commission

(CEC) requirements ● Cabinet liner color Black Reversible door ●

Weights & Dimensions

Height (in.) A 33-1/2 Width (in.) B 20-1/8 Depth with handle (in.) C 22-3/4 Depth with door open 90° (in.) D TBD

Air clearances Each side (in.) 1-1/2

Top (in.) 2 Back (in.) 2

Approx. shipping weight (lbs.) 97

Top View

GMR06AAP GMR04AAM GMR02BAN

Capacity

Total (cu. ft.) 6.0 4.3 1.7 Fresh food (cu. ft.) 5.51 3.26 1.49 Freezer (cu. ft.) .49** .42** .16** Shelf area (sq. ft.) 8.8 6.0 2.9

Features

Ice ’N Easy trays 2 Mini 1 Mini 1 Mini Manual defrost ●● ● Cabinet shelves (wire) 2 (1 Adj.) 2 1 Can rack ●● Door shelves 1 F/W, 2 half-width 2 F/W, 1 half-width 1 F/W, 1 half-width Interior light ●

Economical/Quiet

Cabinet/door insulation Foam Polystyrene Foam Cabinet/door liner HIPS ABS ABS

Appearance

Color(s) available* WW, BB WW, BB WW, BB

White Visor/ Color-Matched Color-Matched

Door handles Black Visor Recessed Recessed Rounded doors ●● Reversible doors ●

Weights & Dimensions

Height (in.) A 34 -1/4 32-1/8 18-15/16 Width (in.) B 23 -5/8 20-1/16 17-1/2 Depth with handle (in.) C 25-7/8 21-7/8 19-1/4 Depth with door open 90° (in.) D 47 -1/2 39-1/4 35-1/2

Air clearances Each side (in.) 0† 1/2 1/2

Top (in.) 0 2 2 Back (in.) 0 2 2

Approx. shipping weight (lbs.) 88 77 51

Accessories

Custom trim (optional) TPK6 (black only)

*Color(s) available: WW = White on white, BB = Black on black.

**Compartment for short-term storage of frozen food. The frozen food compartment of this refrigerator

will make ice, and pre-frozen foods can be stored for about two weeks. It will not effectively freeze fresh foods or provide long-term storage for meats, poultry, or fish.

† If installed against a wall, allow 1 -1/4" on hinge side to allow for proper door opening.

Front View

Spacemaker Compact Refrigerators/ Wine Coolers

*Compartment for short-term storage of frozen

food. The frozen food compartment of this refrigerator will make ice, and pre-frozen foods can be stored for about two weeks. It will not effectively freeze fresh foods or provide long-term storage for meats, poultry, or fish.

GEAppliances.com

GE Chest Freezers

Side View

Front View

GE Upright Freezers

Front View

Top View

Frost-Free Manual Defrost

FUF20DP FUF17DP FUF14DP FUM21DP FUM17DP FUM14DP FUM14SM FUM5SN

Capacity

Total volume (cu. ft.) 20.3 16.7 13.7 20.6 17.1 14.1 14.1 5.0 Shelf area (sq. ft.) 23.9 18.4 14.3 25.3 19.1 17.9 15.0 6.0

Features

Temperature control Adj. Adj. Adj. Adj. Adj. Adj. Adj. Adj. Limited food loss warranty* ●●●●●●●● Door shelves (total) 6 5 5 65553 Defrost water drain ●●●● Interior light ●●●●●● Lock ●●●●●● Cabinet shelves (total) 5 (3 Adj.) 4 (3 Adj.) 3 (2 Adj.) 5 (1 Adj.) 4 (1 Adj.) 4 (1 Adj.) 3 2 Slide-out bulk storage basket 1 1 1 1 1 1

Economical/Quiet

Defrost Frost-Free Frost-Free Frost-Free Manual Manual Manual Manual Manual Magnetic door gasket ●●●●●●●●

Baked Baked Baked Baked Baked Baked Baked

Cabinet liner enamel-on-steel enamel-on-steel enamel-on-steel enamel-on-steel enamel-on-steel enamel-on-steel enamel-on-steel Polystyrene Wraparound condenser ●●●●●●●●

Appearance

Color available White White White White White White White White Door handle Recessed Recessed Recessed Recessed Recessed Recessed Recessed Recessed Textured steel case/door ●●●●●●●●

Weights & Dimensions

Height (in.) A 70 64-1/2 59 70 64-1/2 59 59 33-1/2 Width (in.) B 32 32 28 32 32 28 28 21-3/8 Depth (in.) C 28 -1/2 26-1/2 28-1/2 28 -1/2 26-1/2 28-1/2 28 -1/2 26-1/8 Depth with door open 90° (in.) D 59-1/8 57 -1/8 55-1/8 59-1/8 57-1/8 55-1/8 55 -1/8 45-3/4

Air clearances Each side (in.) 3 3 3 3 3 3 3 1

Top (in.) 3 3 3 33334 Back (in.) 3 3 3 3 3 3 3 4

Approx. shipping weight (lbs.) 235 213 186 224 200 177 177 80

*See written warranty for complete details.

FCM25RM FCM20DP FCM15DP FCM15SP FCM9DM FCM7DN FCM5DM FCM5SM

Capacity

Total volume (cu. ft.) 25.1 19.7 14.8 14.8 8.8 7.0 5.0 5.0

Features

Manual defrost ● ●●●●●●● Temperature control Adj. Adj. Adj. Adj. Adj. Adj. Adj. Adj. Power “ON” light ●● Wraparound condenser ●●●●●●●● Wraparound evaporator ●●●●●●●● Limited food loss warranty* ● ●●●●● Upfront defrost water drain ● ●●●●●●● Interior light ●●● ● Lock ●●● ●●● Lift-out and sliding

bulk storage basket(s) 4 3 2 1 2 2 2 1

Economical/Quiet

Insulation (cabinet and lid)–Foam ● ●●●●●●●

Steel Steel Steel Steel Steel Textured Textured Textured

Cabinet liner Epoxy-Coated Epoxy-Coated Epoxy-Coated Epoxy-Coated Epoxy-Coated Aluminum Aluminum Aluminum

Appearance

Color available White White White White White White White White Handle ● Recessed Recessed Recessed ● Recessed Recessed Recessed Textured steel case and lid ●●●●●

Weights & Dimensions

Height (in.) A 35 35 35 35 34-1/4 33-1/8 33 33 Width (in.) B 73 -7/8 61-1/4 48 48 41 38 29-1/8 29-1/8 Depth (in.) C 28-3/4 29 -1/2 29-1/2 29 -1/2 23-1/4 22-3/8 22-3/16 22-3/16 Height with lid open (in.) D 59-3/4 60 -3/4 60-3/4 60-3/4 54-1/4 53-1/4 53-3/16 53-3/16

Air clearances Each side (in.) 3 3 3 3 3 3 3 3

Back (in.) 3 3 3 3 3 3 3 3

Approx. shipping weight (lbs.) 245 195 161 161 127 126 101 101

*See written warranty for complete details.

GE Appliances web site — 16 million visitors a year! Visit us at GEAppliances.com

Everything you need to know about GE products is here. Access up-to-date information, find out “what’s new,” obtain dimensions, get installation tips and more. Extremely user-friendly, this one-stop site lets you research by brand, category or model number and even buy online through a local GE dealer.

GE Answer Center®saves you time. 800.626.2000

This 24-hour-a-day, 7-day-a-week service provides answers on product features, installation, service and more.

For more than a century, GE has been committed to producing innovative products

that change the way people live. The result of thorough research and rigorous testing,

GE appliances are designed for years of dependable performance.

Today, the GE tradition of quality and innovation continues.

A Century of Quality and Innovation

Answers that click!

GE puts everything you need at your fingertips.

GE Appliances

GEAppliances.com

GE Consumer & Industrial GE Company Louisville, Kentucky 40225

GE has a policy of continuous improvement of its products and reserves the right to change materials and specifications without notice.

Pub. No. 24-C194 PC37324

Before purchasing an appliance, read important information about its estimated annual energy consumption or energy efficiency rating that is available from your retailer or GEAppliances.com

GE Built-In Side-by-Sides Catalog

Specifications and Main Features

Frequently Asked Questions

User Manual
