Built-In Cooking Products

The maximum in cooking performance and versatility.

2003 product specifications

™

convection system •

Trivection™technology

Wall ovens and slide-in ranges with

Trivection

™

technology combine thermal,

convection and microwave heat sources to

produce delicious results up to five times

faster than a traditional thermal oven.*

Cooktops

Our gas and electric cooktops offer

features and options that are

indispensable in the kitchen. From high

output burners to warming zones to

one-touch controls, GE puts advanced

performance at your fingertips.

Built-in wall ovens

Built-in wall ovens

make a dramatic design

statement. Installed in a

wall, under a counter or

in a cabinet, these ovens

integrate beautifully

into any kitchen.

Warming drawers

GE’s essential warming

drawer helps you keep

just-cooked foods warm

while you’re waiting

for guests or preparing

other dishes.

Advanced technology

comes to the kitchen.

2

*Pending final substantiation.

With more convenience, performance and style, GE

built-in products are changing the way the modern

family cooks. And Trivection™technology is leading

the charge. It has the ability to produce optimal food

quality, up to five times faster than a traditional oven!*

The amazing Precise Air™convection system bakes

more evenly than any other convection wall oven.*

And when it comes to style, we feature more

choices

to complement any

taste or preference. With self-clean

models, extra-large capacities and

multi-dimensional features, GE offers

innovative built-in products

designed for today’s lifestyles.

3

GEAppliances.com

GE Profile™Built-In Ovens Featuring Trivection™technology

Not all features available on all models.

4

GE Profile wall ovens and slide-in ranges with exclusive Trivection™technology achieves the delicate balance of heat and time by combining thermal,
Precise Air™convection and microwave heating methods. The result is mouth-watering foods up to five times faster than a traditional oven.*

Using pre-determined settings, customized by food type, Trivection
technology automatically delivers the ideal combination of heating
energy to produce optimal texture, crispness, moistness and browning.

From angel food cake to casseroles to salmon, Trivection technology
ensures delicious and succulent results.

It’s all about great food. Speed seals the deal.

Trivection technology combines the best qualities of three heat sources.

Thermal Heating

Traditional bake and broil elements provide dry heat from above and
below the food, while helping maintain consistent oven temperature.

Precise Air™Convection

An innovative fan reverses direction for optimal air and heat circulation,
providing even cooking, faster roasting speeds and multi-rack baking
capability. Ideal for accelerated browning.

Microwave Energy

Electromagnetic waves excite molecules in food and help accelerate
the cooking process, ensuring faster cooking speeds.

*Pending final substantiation.

5

GEAppliances.com

A dash of thermal. A pinch of convection. A hint of microwave.

Chef’s Guide™Controls make cooking a snap.

Lasagna

A lasagna is usually a large and dense with a high moisture content that
benefits from high levels of all three energies. The thermal and convection
energies will provide ideal browning, while the microwave will help to
quickly bring the middle of the lasagna up to proper baking temperature.

A traditional oven cooks a lasagna in one hour using only
thermal energy. A Trivection technology oven cooks a lasagna in
15 minutes* using thermal, convection and microwave energies
continuously throughout the cooking cycle.

With easy step-by-step instructions, the Chef’s Guide controls help take you through the cooking experience. Program the oven in three simple steps:

Step 1: Select the cooking method and type of food
Step 2: Enter the traditional recipe temperature
Step 3: Enter the traditional cooking time

Once the oven is programmed, it automatically adjusts the ideal heating combination and the cooking time to the food type selected—delivering
exceptional results.

Turkey (22-pound)

Poultry, which has a large amount of surface area, has a tendency to dry
out during cooking. To combat this, the thermal and convection energies
will help brown the outside to seal in the juices, while the microwave
energy will speed up the cooking process to prevent moisture loss.

A traditional oven cooks a 22 lb. turkey in four hours using only
thermal energy. A Trivection technology oven cooks the same
turkey in two hours* using thermal and convection energies
continuously and microwave energy for 80% of the cooking cycle.

6

Not all features available on all models.

GE Profile

™

30" Built-In Double Oven
with Trivection Technology

JT980SH Stainless steel

• Stainless steel oven doors • Stainless-look
sculptured handles

Trivection/Convection Upper Oven

• Speed baking mode • Speed broiling mode

• Five embossed rack positions

Convection Lower Oven

• Seven embossed rack positions

GE Profile

30" Built-In Double Oven
with Trivection Technology

JT980WH White on white

• Frameless glass oven doors • Sculptured handles

JT980CH Bisque on bisque (not shown)
JT980BH Black on black (not shown)

GE Profile

30" Built-In Single Oven with
Trivection Technology

JT930SH Stainless steel

• Speed baking mode • Speed broiling mode • Five
embossed rack positions • Stainless steel oven door

• Stainless-look sculptured handle

JT930WH White on white (not shown)

• Frameless glass oven door • Sculptured handle

JT930CH Bisque on bisque (not shown)
JT930BH Black on black (not shown)

Built-In Double and Single Ovens: 30" Electric with Trivection™technology

These models include • Trivection technology • Precise Air

™

convection system • Single-rack and multi-rack convection bake • Convection

roast • TrueTemp

™

system • Self-clean oven with light self-clean option • Chef’s Guide™glass touch controls • Auto Recipe™conversion • Proof

mode • Warm mode • Defrost mode • Three heavy-duty racks • Two halogen interior oven lights • Big View window • Certified Sabbath mode

• Trivection cookbook

Note: bold = feature upgrade from previous model

Precise Air convection uses an
innovative fan that reverses
direction for optimal air and
heat circulation.

Chef’s Guide controls make
oven programming quick
and easy.

TrueTemp technology provides
even heat distribution and
maximum control.

Trivection/Convection Upper, Convection Lower

Trivection/Convection Upper,
Convection Lower Trivection/Convection

Trivection technology delivers
the ideal combination of three
different heating technologies.

GEAppliances.com

Not all features available on all models.

GE Profile

30" Slide-In Range
with Trivection Technology

JS998SH Stainless steel

• Speed baking mode • Speed broiling mode

• Patterned black ceramic glass cooktop

• Frameless stainless steel oven door

• Stainless-look sculptured handle

GE Profile

30" Slide-In Range
with Trivection Technology

JS998TH True white

• True white ceramic glass cooktop • Frameless
glass oven door • Sculptured handle

JS998KH True bisque (not shown)

• True bisque ceramic glass cooktop

GE Profile

30" Slide-In Range
with Trivection Technology

JS998BH Black on black

• Patterned black ceramic glass cooktop

Slide-In Range: 30" Electric with Trivection technology

This model includes • Trivection technology • Precise Air convection system • Single-rack and multi-rack convection bake • Convection

roast • TrueTemp system • Chef’s Guide glass touch controls • Auto Recipe conversion • Self-clean oven with light self-clean option • Proof mode

• Warm mode • Defrost mode • Three heavy-duty racks • Dual 6"/9" heating element • 8" ribbon heating element • Two 6" ribbon heating
element • Two halogen interior oven lights • Big View window • Certified Sabbath mode

Note: bold = feature upgrade from previous model

Speed modes cook foods up
to five times faster than a
traditional thermal oven.*

Provides ideal convection baking
for multiple racks of food.

A smooth ceramic-glass
CleanDesign cooktop makes
cleaning quick and easy.

7

*Pending final substantiation.

Optional backguard kit attaches
to the back of range when unit
is installed into a free-standing
cutout.

GE Profile™wall ovens

perform beautifully

in any kitchen.

GE Profile wall ovens have improved

upon true European convection with

the Precise Air™convection system,

which uses an innovative fan that

reverses direction. The result is

uniform heating throughout, and an oven

that bakes more evenly than any other

convection wall oven.* The largest** oven

capacity in America and multiple rack

positions give you the flexibility to cook

more food at once. Among the many

convenient features is the proof setting

for rising dough, Sabbath mode for

preparing foods in accordance with kosher

law, warm mode for keeping foods at

serving temperature and the option

of closed door broiling.

GE®Built-In Single and Double Wall Ovens

*Among leading manufacturers’ brands.

**Among leading manufacturers’ brands,

except 30" convection ovens.

8

Versatility extends to installation, as well. GE wall ovens go wherever they’re needed: in a wall, cabinet or under a counter.
These wall ovens fit into common cutouts, making it easy to upgrade or replace an older GE wall oven. And the flush installation
appearance makes the most of your kitchen space.

The versatile design works with every cooking style, every kitchen.

Not all features available on all models.

9

GEAppliances.com

Convection options

GE Profile wall ovens use True European convection, now delivered
through the Precise Air

™

convection system. Meats are beautifully
browned, yet tender and juicy inside and breads and desserts are
baked to golden perfection.

Conventional
Baking

Conventional Broil
(variable temp)

Conventional Broil
(variable temp)

Convection
Bake

GE Profile™Wall Ovens

Not all features available on all models.

GE flexibility gives you more ways to cook great food!

29455

Largest** capacity

GE wall ovens now feature the largest** capacity wall ovens in
America. Great for holiday meals and dinner parties, you have
greater flexibility to cook more food at once!

Auto Recipe™conversion

Auto Recipe eliminates guesswork by automatically converting
standard recipe temperatures to proper convection settings. Simply
set the control according to recipe instructions and the oven
automatically adjusts for convection baking.

Precise Air convection system

This exclusive system uses an innovative fan that rotates one way,
then reverses direction for optimal air and heat circulation. Plus, a
third heating element surrounds the fan and delivers consistent heat.
These ovens bake more evenly than any other convection wall oven.*

*Among leading manufacturers’ brands.

**Among leading manufacturers’ brands, except 30" convection ovens.

10

Convection
Roast

The maximum in cooking performance and versatility.

Heavy-duty racks

The durable construction of the heavy-duty racks provides additional
support for large cooking needs, such as that Thanksgiving turkey.

Eight-pass bake element*

With eight turns of the powerful heating element, heat is distributed
more evenly providing complete coverage throughout the oven cavity.

Innovative design

The glass touch controls, combined with a digital timer and large
easy-to-read graphics, offer a clean and sophisticated look. The
frameless oven aligns nearly flush with cabinetry for a smooth and
integrated design.

Multiple cooking modes

A variety of flexible cooking modes help make cooking convenient.
The proof mode allows dough to rise properly. The warm mode
keeps meals warm and ready to serve. And the certified Sabbath
mode keeps food warm in accordance with kosher law.

*Six-pass on 27" models.

11

GEAppliances.com

12

Convection Self-Clean Upper/
Self-Clean Lower

Convection Self-Clean Upper/
Self-Clean Lower

Built-In Double Ovens: 30" Electric

These models include

• The largest* capacity wall
oven in America! • Flush
appearance installation

• Fits most 30" cabinets

• TrueTemp

™

system

• Light self-clean

• Certified Sabbath mode

• Control lock capability

• Big ClearView

™

windows

• Optional closed door
broiling

Note: bold = feature upgrade
from previous model

Precise Air™convection uses an
innovative fan that reverses
direction for optimal air and
heat circulation.

CleanDesign oven interiors have
a hidden bake element and
a smooth, seamless surface,
making cleanup easier than ever.

GE Profile

™

30" Built-In Double Oven

JT955SF Stainless steel

• Bakes more evenly than any other convection
wall oven**

• Electronic glass touch controls

• CleanDesign oven interior/hidden bake element

• Stainless steel oven doors •

Halogen oven light

• Convection cookbook

Convection Upper Oven

• Extra-large 4.1 cu. ft. self-clean oven

• Precise Air

™

convection system • Single-rack and

multi-rack convection bake

• Convection roast

• Auto Recipe

™

conversion • Proof mode • Warm

mode

• Three heavy-duty oven racks • Eight-pass
bake element • Oven meat probe • Seven
embossed rack positions

Thermal Lower Oven

• Extra-large 4.4 cu. ft. self-clean oven • Two
heavy-duty oven racks

GE Profile

30" Built-In Double Oven

JT955CF Bisque on bisque

• Frameless glass oven doors

JT955WF White on white (not shown)
JT955BF Black on black (not shown)

GE Profile

30" Built-In Double Oven

JT952BF Black on black

• Bakes more evenly than any other convection wall
oven**

• Electronic oven controls • CleanDesign

oven interior/hidden bake element

• Convection

cookbook

Convection Upper Oven

• Extra-large 4.1 cu. ft. self-clean oven • Precise Air
convection system • Convection bake • Convection
roast • Auto Recipe conversion • Three heavy-duty
oven racks • Eight-pass bake element • Oven meat
probe • Seven embossed rack positions

Thermal Lower Oven

• Extra-large 4.4 cu. ft. self-clean oven

• Two heavy-duty oven racks

JT952SF Stainless steel (not shown)
JT952WF White on white (not shown)
JT952CF Bisque on bisque (not shown)

Convection Self-Clean Upper/Self-Clean Lower

Eight-pass power bake
exemplifies the ultimate in
heating performance with
complete coverage.

Not all features available on all models.

* Among leading manufacturers’ brands

except 30" convection ovens.

** Among leading manufacturers’ brands.

13

GEAppliances.com

Self-Clean (Both Ovens)

GE

®

30" Built-In Double Oven

JTP50SH Stainless steel

• Stainless steel oven doors • Two extra-large

4.4 cu. ft. self-clean ovens with delay self-clean

• Interior oven light • Six-pass bake element

• Two oven racks (each oven) • Six embossed
rack positions • Audible preheat signal

GE
30" Built-In Double Oven

JTP48SF Stainless steel with black accents

• Stainless steel oven doors

• Two extra-large

4.4 cu. ft. self-clean ovens with delay self-clean

• Interior oven light • Six-pass bake element

• Two oven racks (each oven) • Six embossed
rack positions • Audible preheat signal

JTP48WF White on white (not shown)

• Frameless glass oven doors

JTP48CF Bisque on bisque (not shown)
JTP48BF Black on black (not shown)

Self-Clean (Both Ovens)

GE
30" Built-In Double Oven

JTP28BF Black on black

• Frameless glass oven doors • Two oven racks (each oven)

• Six embossed rack positions • Audible preheat signal

Upper Oven

• Extra-large 4.4 cu. ft. self-clean oven with delay self-clean

• Electronic oven controls • Delay bake • Interior oven light

Lower Oven

• Extra-large 4.4 cu. ft. standard-clean oven • Rotary controls

JTP28SF Stainless steel (not shown)

• Stainless steel oven door

JTP28WF White on white (not shown)
JTP28CF Bisque on bisque (not shown)

Self-Clean Upper/Standard Lower

Certified Sabbath mode keeps
food warm in accordance with
kosher law.

TrueTemp

™

technology provides
even heat distribution and
maximum control.

The largest* capacity wall oven
in America gives you flexibility
to cook more at once.

14

Not all features available on all models.Not all features available on all models.

Microwave Upper/Convection Lower

GE Profile

™

30" Built-In Double Oven

JT965SF Stainless steel

• Fits most 30" cabinets

Microwave Upper Oven

• 1.6 cu. ft. cavity • Sensor cooking controls for
Auto Cook and Reheat • Turntable • 1000 watts

Convection Lower Oven

• Extra-large 4.1 cu. ft. self-clean oven • CleanDesign
oven interior/hidden bake element

• Exclusive Big

ClearView

™

window • True European convection

system • Convection bake • Convection roast • Three
heavy-duty oven racks • Oven meat probe • Eight-pass
power bake element • Halogen interior oven lights

• Seven embossed rack positions

JT965BF Black on black (not shown)
JT965WF White on white (not shown)
JT965CF Bisque on bisque (not shown)

GE

®

30" Built-In Double Oven

JTP86WF White on white

• Fits most 30" cabinets • Upfront interior
oven lights

Microwave Upper Oven

• 1.6 cu. ft. cavity • Sensor cooking controls for
Auto Cook and Reheat • Turntable • 1000 watts

Lower Oven

• Extra-large 4.4 cu. ft. self-clean oven with Delay
Clean option • Two oven racks • Six embossed
rack positions • Big ClearView window

JTP86SH Stainless steel (not shown)
JTP86CF Bisque on bisque (not shown)
JTP86BF Black on black (not shown)

True European convection
ovens provide even cooking
and superior baking results.

Microwave Upper/Self-Clean Lower Microwave Upper/Self-Clean Lower

Built-In Double Combination Ovens: 30" and 27" Electric

Electronic controls are simple to
understand and easy to use.
Just read and touch.

Sensor microwave cooking
controls take the guesswork out
of cooking your favorite foods.

GE
27" Built-In Double Oven

JKP86BF Black on black

• Fits most 27" cabinets • Upfront interior
oven lights

Microwave Upper Oven

• 1.6 cu. ft. cavity • Auto Roast • Auto Cook

• Turntable • 1000 watts

Lower Oven

• Extra-large 3.9 cu. ft. self-clean oven with Delay
Clean option • Big ClearView window • Two
oven racks

JKP86SH Stainless steel (not shown)
JKP86WF White on white (not shown)
JKP86CF Bisque on bisque (not shown)

These models include

• Flush appearance
installation • Frameless
glass oven doors

• Electronic controls

• TrueTemp

™

system

• Control lock capability

• Variable broil • Optional
closed door broil

Note: bold = feature upgrade
from previous model

15

GEAppliances.com

Not all features available on all models.

* Among leading manufacturers’ brands.

**Among leading manufacturers’ brands except 30" convection ovens.

CleanDesign oven interiors have
a hidden bake element and a
smooth, seamless surface, making
cleanup easier than ever.

The largest** capacity wall oven
in America gives you flexibility
to cook more at once.

Precise Air™convection uses an
innovative fan that reverses
direction for optimal air and
heat circulation.

GE Profile

27" Built-In Double Oven

JK955SF Stainless steel

• Electronic glass touch controls • CleanDesign
oven interior/hidden bake element • Stainless steel
oven doors • Halogen oven light

Convection Upper Oven

• Extra-large 3.9 cu. ft. self-clean oven

• Precise Air™convection system • Single-rack and
multi-rack convection bake • Convection roast

• Auto Recipe

™

conversion • Proof mode • Warm

mode • Three heavy-duty oven racks

• Six-pass

bake element

• Oven meat probe

Thermal Lower Oven

• Extra-large 3.9 cu. ft. self-clean oven

• Two heavy-duty oven racks

Convection Upper/Self-Clean Lower

Built-In Double Ovens: 27" Electric

GE Profile

27" Built-In Double Oven

JK955CF Bisque on bisque

• Frameless glass oven doors

GE Profile

27" Built-In Double Oven

JK955BF Black on black
JK955WF White on white (not shown)

These models include

• Bakes more evenly than
any other convection wall
oven* • The largest**
capacity wall oven in
America! • Flush
appearance installation

• Fits most 27" cabinets

• TrueTemp

™

system

• Light self clean

• Certified Sabbath mode

• Control lock capability

• Big ClearView
windows • Variable broil

• Convection cookbook

Note: bold = feature upgrade
from previous model

16

Not all features available on all models.

*Among leading manufacturers’ brands

except 30" convection ovens.

The largest* capacity wall oven
in America gives you flexibility
to cook more at once.

GE

®

27" Built-In Double Oven

JKP50SH Stainless steel

• Two extra-large 3.9 cu. ft. self-clean ovens
with delay self-clean • Electronic oven controls

• Four embossed rack positions • Two oven
racks (each oven)

Self-Clean (Both Ovens)

Built-In Double Ovens: 27" Electric

TrueTemp™technology provides
even heat distribution and
maximum control.

GE
27" Built-In Double Oven

JKP48BF Black on black

• Two extra-large 3.9 cu. ft. self-clean ovens with
delay self-clean

• Electronic oven controls • Four
embossed rack positions • Two oven
racks (each oven)

JKP48CF Bisque on bisque (not shown)
JKP48WF White on white (not shown)

Self-Clean (Both Ovens) Self-Clean Upper/Standard Lower

GE
27" Built-In Double Oven

JKP28WF White on white

• Two oven racks (each oven)• Audible preheat
signal

Upper Oven

• Extra-large 3.9 cu. ft. self-clean oven with Delay
Clean option • Electronic controls • Delay bake

Lower Oven

• Extra-large 3.9 cu. ft. standard-clean oven

• Rotary control

JKP28BF Black on black (not shown)

These models include • The largest* capacity wall oven in America! • Flush appearance installation • Fits most 27" cabinets

• TrueTemp

™

system • Certified Sabbath mode • Control lock capability • Frameless glass oven doors • Big ClearView™windows

• Variable broil

Note: bold = feature upgrade from previous model

Six-pass power bake provides
unparalleled baking throughout
the oven interior. The results are
succulent, evenly cooked food.

Not all features available on all models.

GEAppliances.com

Built-In Single Ovens: 30" Electric

GE Profile

™

30" Built-In Single Oven

JT915SF Stainless steel

• Extra-large 4.1 cu. ft. self-clean oven with Delay
Clean option • Precise Air

™

convection system

• Single-rack and multi-rack convection bake

• Convection Roast • Auto Recipe™conversion

• Proof mode • Warm mode • Eight-pass bake
element • Three heavy-duty oven racks

• Electronic glass touch controls • CleanDesign
oven interior/hidden bake element • Stainless steel
oven door

• Halogen oven light • Oven meat probe

• Seven embossed rack positions

Self-Clean Convection

These models include • Bakes more evenly than any other convection wall oven* • The largest** capacity wall oven in America! • Flush

appearance installation • Fits most 30" cabinets • TrueTemp

™

system • Light self clean • Certified Sabbath mode • Control lock capability

• Big ClearView window • Variable broil •

Convection cookbook Note: bold = feature upgrade from previous model

Precise Air™convection uses an
innovative fan that reverses
direction for optimal air and
heat circulation.

Installation
Flexibility

30" wall ovens can be
installed in a wall or
most 30" cabinets, or
undercounter installation
with either a gas or
electric cooktop above.
Refer to specifications
page for approved
cooktop use.

GE Profile

30" Built-In Single Oven

JT915WF White on white

• Frameless glass oven door

JT915CF Bisque on bisque (not shown)
JT915BF Black on black (not shown)

GE Profile

30" Built-In Single Oven

JT912BF Black on black

• Extra-large 4.1 cu. ft. self-clean oven with Delay
Clean option

• Precise Air™convection system

• Convection bake • Convection roast • Auto Recipe
conversion • Eight-pass bake element • Three
heavy-duty oven racks

• Electronic oven controls

• CleanDesign oven interior/hidden bake element

• Frameless glass oven door • Interior oven light

• Oven meat probe • Seven embossed rack positions

JT912SF Stainless steel (not shown)
JT912WF White on white (not shown)
JT912CF Bisque on bisque (not shown)

CleanDesign oven interiors have
a hidden bake element and a
smooth, seamless surface, making
cleanup easier than ever.

29459

Cook more at once! Take
advantage of more oven
capacity with the versatility
of multiple rack positions.

ONLY GE HAS IT!

17

* Among leading manufacturers’ brands.

**Among leading manufacturers’ brands

except 30" convection ovens.

18

Not all features available on all models.

*Among leading manufacturers’ brands

except 30" convection ovens.

The largest* capacity wall oven
in America gives you flexibility
to cook more at once.

Built-In Single Ovens: 30" Electric

These models include • The largest* capacity wall oven in America! • Flush appearance installation • Fits most 30" cabinets

• TrueTemp™system • Electronic oven controls • Certified Sabbath mode • Control lock capability • Big ClearView™window

• Upfront interior oven light • Variable broil Note: bold = feature upgrade from previous model

GE
30" Built-In Single Oven

JTP20SF Stainless steel with black accents

• Stainless steel oven door • Extra-large 4.4 cu. ft.
self-clean oven with light self-clean option

• Two oven racks • Six embossed rack positions

• Six-pass bake element

Self-Clean

Self-Clean

GE
30" Built-In Single Oven

JTP20BF Black on black

• Frameless glass oven door

JTP20CF Bisque on bisque (not shown)
JTP20WF White on white (not shown)

Self-Clean

GE

®

30" Built-In Single Oven

JTP25SH Stainless steel

• Stainless steel oven door • Extra-large

4.4 cu. ft. self-clean oven with light self-clean
option • Two oven racks • Six embossed rack
positions • Six-pass bake element

Installation
Flexibility

30" wall ovens can be
installed in a wall or
most 30" cabinets, or in an
undercounter installation
with either a gas or
electric cooktop above.
Refer to specifications
page for approved
cooktop use.

TrueTemp™technology provides
even heat distribution and
maximum control.

19

GEAppliances.com

Not all features available on all models.

* Among leading manufacturers’ brands.

**Among leading manufacturers’ brands

except 30" convection ovens.

The durable construction of
the heavy-duty racks provides
additional support for large
cooking needs.

Built-In Single Ovens: 27" Electric

These models include • Bakes more evenly than any other convection wall oven* • The largest** capacity wall oven in America! • Flush

appearance installation

• Fits most 27" cabinets • Electronic oven controls • Certified Sabbath mode • Big ClearView window • Variable broil

• Control lock capability (except model JKS06) Note: bold = feature upgrade from previous model

GE
27" Built-In Single Oven

JKP20CF Bisque on bisque

• Extra-large 3.9 cu. ft. self-clean oven with light
self-clean option

• Two oven racks • Four

embossed rack positions

JKP20WF White on white (not shown)
JKP20BF Black on black (not shown)
JKS06BF Black on black (not shown)

• Extra-large 3.9 cu. ft. standard-clean oven

GE
27" Built-In Single Oven

JKP25SH Stainless steel

• Extra-large 3.9 cu. ft. self-clean oven with light
self-clean option • Two oven racks • Four
embossed rack positions

Self-Clean/Standard Clean

Self-Clean Convection Self-Clean Convection

GE Profile

27" Built-In Single Oven

JK915WF White on white

• Frameless glass oven door

JK915CF Bisque on bisque (not shown)
JK915BF Black on black (not shown)

Installation
Flexibility

27" wall ovens can be
installed in a wall or
27" cabinet, or in an
undercounter installation
with either a gas or
electric cooktop above.
Refer to specifications
page for approved
cooktop use.

GE Profile

™

27" Built-In Single Oven

JK915SF Stainless steel

• Extra-large 3.9 cu. ft. self-clean oven with Delay
Clean option

• Precise Air™convection system • Single­rack and multi-rack convection bake • Convection
roast • Auto Recipe

™

conversion • Electronic glass
touch controls • Proof mode • Warm mode • Six-pass
bake element • Three heavy-duty oven racks

• Convection cookbook • CleanDesign oven interior/
hidden bake element • Stainless steel oven door

• Halogen oven light • Oven meat probe

Self-Clean

Certified Sabbath mode keeps
food in accordance with
kosher law.

20

Not all features available on all models.

SmartSet electronic controls are
simple to understand and easy
to use. Just read and touch.

GE
24" Built-In Single Oven

JRP15WW White on white

• Self-clean oven with Delay Clean option

• Control lock capability

• Delay Bake option

with Cook & Hold

JRP15BW Black on black (not shown)
JRS04BW Black on black (not shown)

• Standard-clean oven • Delay Bake option with
Cook & Hold

GE
24" Built-In Single Oven

JGRP17WEW White on white

• Self-clean oven with Delay Clean option

• Control lock capability • In-oven broiling

• Storage drawer

JGRP17BEW Black on black (not shown)

GE
24" Built-In Single Oven

JGRS14BEW Black on black

• Standard-clean oven • Separate broiler drawer

These models include

• Fits most 24" cabinets

• SmartSet electronic
controls • Frameless glass
oven doors • Designer­style handles • Two oven
racks (each oven)

• Variable broil

Note: bold = feature upgrade
from previous model

GE

®

24" Built-In Double Oven

JRP24BD Black on black
Upper Oven

• Self-clean oven with Delay Clean option

• Control lock capability • Delay Bake option
with Cook & Hold

Lower Oven

• Standard-clean oven • Rotary controls

These models include

• Fits most 24" cabinets

• SmartSet electronic
controls • Electronic
pilotless ignition

• Frameless glass oven door

• Designer-style handle

Note: bold = feature upgrade
from previous model

Built-In Double and Single Ovens: 24" Electric

Built-In Single Ovens: 24" Gas

Self-clean ovens provide easy
clean convenience. Simply set
the controls and the oven
cleans itself.

GEAppliances.com

Not all features available on all models.

These models include • Flush appearance installation • Temperature control with proof and variable settings • Crisp/Moist humidity

control • ON/OFF switch • “ON” indicator light • One-half rack • Frameless drawer front • Profile handle • Removable stainless steel drawer
pan • Commercial pan set or wood panel kit

(available at additional cost)

Built-In Warming Drawers: 30" and 27" Electric

Half rack provides even heat
distribution and allows extra
space to keep food warm and
tasty before serving.

Optional wood panel kit
available for a custom
built-in appearance.

Hidden temperature control has
proof and variable settings for
warming flexibility.

Warming drawer keeps plates
warm, ready and waiting to serve
that special meal.

GE Profile

™

Built-In Warming Drawer

JTD915SF Stainless steel

• 30" width

JKD915SF Stainless steel (not shown)

• 27" width

GE Profile

Built-In Warming Drawer

JTD915WF White on white

• 30" width

JKD915WF White on white (not shown)

• 27" width

JTD915CF Bisque on bisque (not shown)

• 30" width

JKD915CF Bisque on bisque (not shown)

• 27" width

GE Profile

Built-In Warming Drawer

JTD915BF Black on black

• 30" width

JKD915BF Black on black (not shown)

• 27" width

21

22

Not all features available on all models.

Built-In Cooktops

GE Profile™and GE®cooktops

make a dramatic difference

in the kitchen, both in terms of

appearance and performance.

Distinguished by a continuous,

smooth surface, these cooktops

add immediate visual interest.
High-tech features include the

Precise Digital Control System,™an

electronic sensor that automatically

adjusts the size of the element to

fit the pan, a sensor that indicates

when an element is left on, and two

convenient dual-size elements.

GE caters to today’s busy cooks with a wide variety of cooktop options.

Now you can enjoy the superior

performance of gas, along with

ease of cleaning.

Thanks to GE innovation, serious

cooks can make gas cooktops a

prominent part of their kitchens without

the usual worry about cleanability.

High-output or simmer burners give

you precise control over heat intensity,

while the smooth, sealed surface

beneath these burners lets you control

spills and messes. Professional-style

continuous burner grates allow easy

pot movement. And every model wipes

clean, whether it’s the deep recessed

cooktop or the gas-on-glass style.

23

GEAppliances.com

Electric cooktops offer an array of
convenient extras.

Two dual elements let you match the element
size to the size of the pan. Models with
electronic controls also feature a cooking
timer and lockout option. Models with a
bridge element allow you to combine two
elements into one large cooking surface.

Gas cooktops provide outstanding
performance.

When it comes to power, our gas cooktops
go to extremes. The 15,000-BTU burner
supplies intense heat needed for sautéing
and stir-frying. Gas cooktops also provide
precise temperature control and consistent,
gentle simmering.

24

GE Profile

™

36" Electronic Touch Control Cooktop

JP969BH Black on black

• Frameless cooktop

• Precise Digital Control

System

™

• Pan presence sensor • Pan size sensor

• Control lockout • Kitchen timer

• Five ribbon

heating elements: two 6",

one 7" with warmer,

one dual (6"/9") and one dual (5"/8") element

JP969SH Stainless steel (not shown)
JP969WH White on white (not shown)
JP969CH Bisque on bisque (not shown)

These models include • Smooth frameless ceramic-glass CleanDesign cooktop • Flush-mount installation capability (except Stainless steel models)

• Fingerprint- and scratch-resistant patterned glass cooktop • Hot surface indicator lights

Note: bold = feature upgrade from previous model

GE Profile

36" Electric CleanDesign Cooktop

JP961TH True White

• Frameless true bisque cooktop • Five ribbon
heating elements: two 6", one 7", one dual
(6"/9") and one dual (5"/8") element

JP961SH Stainless steel (not shown)
JP961KH Tru e Bisque (not shown)
JP961BH Black on black (not shown)

Built-In Cooktops: 36" and 30" Electric CleanDesign

GE Profile

36" Electric CleanDesign Cooktop

JP960SC Stainless steel

• Frameless cooktop • Five ribbon heating
elements: one 6", one 7". one dual (6"/9")
and two 7" with connecting bridge element

JP960BC Black on black (not shown)
JP960TC True white (not shown)
JP960KC Tr ue bisque (not shown)

GE Profile

30" Electronic Touch Control Cooktop

JP939WH White on white

• Frameless cooktop

• Precise Digital Control
System • Pan presence sensor • Pan size
sensor • Control lockout • Kitchen timer

• Four ribbon heating elements: one 6",
one dual (6"/9"), one 7" and one dual (5"/8")
element • Four hot surface indicator lights

JP939SH Stainless steel (not shown)
JP939CH Bisque on bisque (not shown)
JP939BH Black on black (not shown)

A convenient kitchen timer
lets you set a reminder at the
appropriate cooking time,
making precision cooking easy.

The Precise Digital Control System

™

is simple to understand and easy
to operate. Just read and touch.

Helps protect your family with
control lock capability.

Pan presence sensor reminds
you when an element is left on
and automatically shuts it off
when not in use.

Not all features available on all models.

25

GEAppliances.com

GE

®

30" Electric CleanDesign Cooktop

JP340WC White on white

• Frameless cooktop • Four ribbon heating
elements: two 6" and two 8" • Hot surface
indicator light

JP340BC Black on black (not shown)
JP340CC Bisque on bisque (not shown)

GE Profile

30" Electric CleanDesign Cooktop

JP931SH Stainless steel

• Frameless cooktop • Four ribbon heating
elements: one 6", one 8", one dual (6"/9")
and one dual (5"/8") element • Four hot
surface indicator lights

JP931TH True white (not shown)
JP931KH True bisque (not shown)
JP931BH Black on black (not shown)

GE Profile

30" Electric CleanDesign Cooktop

JP350KC True bisque

• Frameless cooktop • Four ribbon heating
elements:

one dual (6"/9"), two 8" and

one 6"

• Four hot surface indicator lights

JP350SC Stainless steel (not shown)
JP350TC True white (not shown)
JP350WC White on white (not shown)
JP350BC Black on black (not shown)

GE Profile

30" Electric CleanDesign Cooktop

JP930TC True white

• Frameless cooktop • Four ribbon heating
elements: one 6", one dual (6"/9") and

two 7" with connecting bridge element

• Four hot surface indicator lights

JP930SC Stainless steel (not shown)
JP930KC True bisque (not shown)
JP930BC Black on black (not shown)

Flush-mount trim kit creates a
stunning visual effect.

(Not available on stainless steel models)

Energy-efficient pan size sensor
selects a 6" or 9" element to
match the pan you are using.

Bridge element for total
cooking flexibility.

Dual element allows consumers
the choice of using a 6" or 9"
element.

26

GE

®

36" Electric Coil Cooktop

JP626WF White on white

• One-piece chrome drip bowls • Upfront
color-matched glass control panel

JP626CF Bisque on bisque (not shown)

GE
30" Electric Coil Cooktop

JP328SF Stainless steel

• One-piece chrome drip bowls • Upfront
color-matched glass control panel

JP328BF Black on black (not shown)
JP328WF White on white (not shown)
JP328CF Bisque on bisque (not shown)

GE
21" Electric Coil Cooktop

JP201CB Stainless steel

• One 8" and one 6" plug-in heating element

• Infinite heat rotary controls • Removable
one-piece chrome drip bowls • Heating element
“ON” indicator light

JP202D White on white (not shown)

These models include • Porcelain-enameled lift-up cooktop • Two 8" and two 6" plug-in heating elements

• Infinite heat rotary controls

Note: bold = feature upgrade from previous model

Built-In Cooktops: 36" and 30" Electric Coil

Built-In Cooktops: 21" Compact

Cooktop filler trim kit available
to fill in oversized cutout left by
an older cooktop.

Not all features available on all models.

27

GEAppliances.com

GE Profile

™

30" Electric Downdraft Cooktop

JP989SD Stainless steel
JP989TD True white (not shown)
JP989BD Black on black (not shown)

GE Profile

30" Electric Downdraft Cooktop

JP989KD True bisque

GE Profile

30" Gas Downdraft Cooktop

JGP989TC True white
JGP989KC True bisque (not shown)

Built-In Cooktops: 30" Electric Downdraft

These models include • Smooth frameless ceramic-glass CleanDesign cooktop • Four ribbon heating elements: one 6",

one dual (6"/9") and two 7" with connecting bridge element • Four hot surface indicator lights • Powerful 400-CFM downdraft
venting system • Three-speed fan • Upfront controls

Built-In Cooktops: 30" Gas Downdraft

These models include • Ceramic-glass cooktop • Four sealed gas burners • Continuous cast-iron grates • Electronic pilotless ignition

• Powerful 400-CFM downdraft venting system • Three-speed fan • Upfront controls

Note: bold = feature upgrade from previous model

GE Profile

30" Gas Downdraft Cooktop

JGP989BC Black on black

28

These models include • Sealed burners • Electronic pilotless ignition Note: bold = feature upgrade from previous model

GE Profile

36" Deep Porcelain Gas Cooktop

JGP963BEC Black on black

• Deep porcelain cooktop • Continuous

deluxe cast-iron grates • Five sealed gas
burners

• 15,000 BTU Power Boil

burner

• Two Precise Simmer burners

• Dishwasher-safe grates

JGP963WEC White on white (not shown)
JGP963CEC Bisque on bisque (not shown)

GE Profile

36" Gas on Glass Cooktop

JGP962SEC Stainless steel

• Gas on glass ceramic cooktop • Continuous
deluxe cast-iron grates

• Five sealed gas

burners

• 15,000 BTU Power Boil

burner

• Two Precise Simmer burners

• Dishwasher-safe grates

JGP962TEC True white (not shown)
JGP962KED True bisque (not shown)
JGP962BEC Black on black (not shown)

GE Profile

™

36" Deep Stainless Gas Cooktop

JGP963SEF Stainless steel

• Deep stainless cooktop • Continuous

deluxe cast-iron grates • Five sealed gas
burners • 15,000 BTU Power Boil

™

burner • Two Precise Simmer burners

• Dishwasher-safe grates

Precise Simmer burner keeps
delicate foods like sauces and
gravies at a low setting.

Power Boil

™

burner 15,000 BTU
burner heats up fast with high
power for skillets, woks or
large pots.

GE glass cooktops are sleek
and easy to clean. The flat
surface and sealed burners
make cleanup a snap.

Built-In Cooktops: 36" Gas

Not all features available on all models.

29

GEAppliances.com

GE

®

36" Gas Cooktop

JGP960SED Stainless steel

• Tempered glass cooktop • Deluxe cast-iron
grates • Five sealed gas burners • Two Precise
Simmer burners • 12,000 BTU High Output
burner

GE
36" Deep Porcelain Gas Cooktop

JGP628CEC Bisque

• Deep porcelain cooktop • Precise Simmer
burner • Continuous grates

JGP628WEC White on white (not shown)
JGP628BEC Black on black (not shown)

GE
36" Gas Cooktop

JGP636CED Bisque

• Tempered glass cooktop • Deluxe cast-iron
grates • Five sealed gas burners • Two Precise
Simmer burners • 12,000 BTU High Output
burner

JGP636WED White on white (not shown)
JGP636BED Black on black (not shown)

30

GE Profile

™

30" Deep Stainless Gas Cooktop

JGP933SEF Stainless steel

• Deep stainless cooktop • Continuous

deluxe cast-iron grates • Four sealed gas
burners • 15,000 BTU Power Boil
burner • Precise Simmer burner

• Dishwasher-safe grates

JGP933WEC White on white (not shown)

• Deep porcelain cooktop

JGP933CEC Bisque on bisque (not shown)
JGP933BEC Black on black (not shown)

GE Profile

30" Gas on Glass Cooktop

JGP932KED True bisque

• Gas on glass ceramic cooktop • Continuous
deluxe cast-iron grates • Four sealed gas
burners • 15,000 BTU Power Boil
burner • Precise Simmer burner

• Dishwasher-safe grates

JGP932TEC True white (not shown)

GE Profile

30" Gas on Glass Cooktop

JGP932BEC Black on black

• Gas on glass ceramic cooktop • Continuous
deluxe cast-iron grates

• Four sealed gas

burners

• 15,000 BTU Power Boil

burner

• Precise Simmer burner

• Dishwasher-safe grates

JGP932SEC Stainless steel (not shown)

These models include • Sealed burners (except JGP320) • Electronic pilotless ignition Note: bold = feature upgrade from previous model

Built-In Cooktops: 30" Gas

Precise Simmer burner keeps
delicate foods like sauces and
gravies at a low setting.

Power Boil

™

burner 15,000 BTU
burner heats up fast with high
power for skillets, woks or
large pots.

GE glass cooktops are sleek
and easy to clean. The flat
surface and sealed burners
make cleanup a snap.

GE

®

30" Gas Cooktop

JGP930SED Stainless steel

• Tempered glass cooktop • Deluxe cast-iron
grates • Four sealed gas burners • Precise
Simmer burner • 12,000 BTU High Output
burner

Not all features available on all models.

31

GEAppliances.com

GE
30" Deep Porcelain Gas Cooktop

JGP328BEC Black on black

• Deep porcelain cooktop • Four sealed

gas burners • Precise Simmer burner

• Continuous grates

JGP328WEC White on white (not shown)
JGP328CEC Bisque on bisque (not shown)

GE
30" Gas Cooktop

JGP326WEF White on white

• Four sealed gas burners • Precise
Simmer burner

JGP326CEF Bisque on bisque (not shown)
JGP326BEF Black on black (not shown)

GE
30" Gas Cooktop

JGP320EV White or black

• Lift-up cooktop • Glass control panel

• Standard porcelain-steel grates • Four
standard gas burners

GE
30" Gas Cooktop

JGP336WED White on white

• Tempered glass cooktop • Deluxe cast-iron
grates • Four sealed gas burners • Precise
Simmer burner

• 12,000 BTU High Output

burner

JGP336CED Bisque on bisque (not shown)
JGP336BED Black on black (not shown)

32

These models include • Infinite heat rotary controls • Powerful 400-CFM downdraft venting system

• Heating element “ON” indicator light

Note: bold = feature upgrade from previous model

Built-In Cooktops: Downdraft Electric Select-Top™Modular

Not all features available on all models.

GE

®

30" Dual Modular Cooktop

JP389WD White on white

• Three-speed fan • Porcelain-enameled cooktop

• Both sides accept optional cooking modules

Shown with optional Ribbon module JXDR50VW and Grill module JXDL44N.

GE
30" Dual Modular Cooktop

JP389BD Black on black

• Three-speed fan • Porcelain-enameled cooktop

• Both sides accept optional cooking modules

Shown with optional Ribbon modules JXDR50VB.

Optional Modules

Models
(available at additional cost) JP389WD JP389BD
Coil Module JXDC44RWH JXDC43RBL
Ribbon Module JXDR50VW JXDR50VB
Grill Module JXDL44N JXDL44N
Griddle Accessory JXDD44R JXDD44R
Grill Cover JXDM3 JXDM2

Grill Module

Front and rear controlled
heating element for
more cooking flexibility
and energy savings.
One-piece grill grate and
porcelain-enameled
reflector pan can be
removed for cleaning in
sink or dishwasher.

Griddle Accessory

(For use with optional
grill module) Place over
heating element and
reflector pan from
optional grill module.
Griddle accessory has a
non-stick coating and is
self-draining.

Ribbon Module

Patterned glass top with
one 8" and one 6"
ribbon heating element.

Coil Module

One 8" and one 6"
plug-in coil heating
element with removable
one-piece drip bowls.

Grill Cover

Covers grill area when
not in use. Available in
Black on black and
White on white.

Optional Select-Top™Modules (available at additional cost)

33

GEAppliances.com

Common Cutouts—30" Cooktops
Dimensions (W x D) Model # Description

28-1/2" x 19-5/8" JP939 CleanDesign

JP931 CleanDesign
JP930 CleanDesign
JP350 CleanDesign
JP340 CleanDesign
JP328 Calrod

®

JGP933–Gas Sealed Burner
JGP932–Gas Sealed Burner
JGP930–Gas Sealed Burner
JGP336–Gas Sealed Burner
JGP328–Gas Sealed Burner
JGP326–Gas Sealed Burner
JGP320–Gas Standard Burner

28-7/8" x 20-5/8" JP989 Electric Downdraft

JP389 Modular Downdraft
JGP989–Gas Gas Downdraft

29" x 21" JGP979–Gas Modular Downdraft

Common Cutouts—36" Cooktops
Dimensions (W x D) Model # Description

33-7/8" x 19-1/8" JP969 CleanDesign

JP961 CleanDesign
JP960 CleanDesign
JP626 Calrod

®

JGP963–Gas Sealed Burner
JGP962–Gas Sealed Burner
JGP960–Gas Sealed Burner
JGP636–Gas Sealed Burner
JGP628–Gas Sealed Burner

Common Cooktop Cutouts

GE Profile

™

30" Single Modular Gas Cooktop

JGP979SEF Stainless steel

Shown with optional Grill module JXGG79.
Note: Unit not LP convertible.

Optional Modules

(available at additional cost)

Two-burner gas module

JXGB79W—White on white
JXGB79B—Black on black

Gas grill module

JXGG79

Griddle for use with
optional Grill module

JXGL79

Grill Cover

JXGC89W—White on white
JXGC89B—Black on black

Grill and griddle feature
Excalibur®non-stick finish.

Built-In Cooktops: 30" Downdraft Gas Modular

These models include • Gas cooktop burner module (right side) • Left side accepts optional cooking modules • Powerful downdraft

venting • Electronic pilotless ignition • Upfront controls

Note: bold = feature upgrade from previous model

Not all features available on all models.

GE Profile

30" Single Modular Gas Cooktop

JGP979WEF White on white

Shown with optional Grill module JXGG79.

JGP979BEF Black on black (not shown)

Note: Unit not LP convertible.

GE®Slide-In and Drop-In Ranges

33501

GE slide-in and drop-in ranges give the effect of added

space, opening up kitchens and making them more inviting.

The perfect fit.

GE slide-in and drop-in ranges fit every kitchen decor and cooking style. Slide-in ranges are available in electric or gas

configurations and they install nearly flush with surrounding cabinetry and counters, creating a dramatic effect. Accenting

the contemporary design is the sleek stainless exterior, which complements just about any color or wood finish.

34

Versatile features are the key ingredients to our slide-in and drop-in ranges.

Precise Air™convection

This exclusive system uses an innovative fan that rotates one way,
then reverses direction for optimal air and heat circulation. Plus, a
third heating element surrounds the fan and delivers consistent heat
for true European convection.

Electric cooktop versatility

Innovative heating elements make cooktop cooking easy. Combine
two separate elements into one large bridge element, adjust a dual
element to 6" or 9", or use a convenient fifth warming element for
keeping foods warm and ready to serve.

Electronic control panel

The electronic control panel is innovatively styled with glass touch
controls, a digital display and sleek, easy-turn dials. Plus, it’s
ergonomically angled for optimal, user-friendly operation.

Gas cooktop versatility

Four convenient burner sizes satisfy every cooktop need from boiling
to simmering. The continuous grate surface makes it easy to slide
pans between burners.

35

Not all features available on all models.

GEAppliances.com

36

Not all features available on all models.

GE Profile

™

30" Slide-In CleanDesign Convection Range

JS968SF Stainless steel

• Precise Air

™

convection system • Single-rack and

multi-rack convection bake

• Convection Roast

• Auto Recipe

™

conversion • Proof mode • Warm

mode • Stainless steel oven door with window

• Three heavy-duty racks • Halogen interior oven
light • Electronic glass touch controls

• Two 7"
ribbon heating elements with connecting bridge
element

• One dual (6"/9") and one 6" ribbon

heating element

• Fifth element warming zone

•

CleanDesign oven interior/hidden bake element

GE Profile

30" Slide-In CleanDesign Convection Range

JS968TF True white
JS968KF True bisque (not shown)
JS968BF Black on black (not shown)

GE Profile

30" Slide-In CleanDesign Electric Range

JSP47CF Bisque on bisque

• Electronic controls

• Two 8", one 6" and

one dual (6"/9") ribbon heating element

• Frameless glass oven door

JSP47WF White on white (not shown)
JSP47BF Black on black (not shown)

Slide-In Ranges: 30" Electric

These models include • TrueTemp

™

system • Big ClearView™window • Four hot surface indicator lights • Fingerprint- and scratch-resistant

patterned ceramic-glass CleanDesign cooktop • Optional closed door broiling • Certified Sabbath mode • Extra-large self-clean oven with Delay
Clean option

• Control lock capability • Custom built-in look with simple slide-in installation Note: bold = feature upgrade from previous model

The warming zone is a great
way to keep food warm and
ready to enjoy or melt butter
or chocolate.

Bridge element for total
cooking flexibility.

Fast and easy cleanup is
made possible through our
CleanDesign oven interior/
hidden bake element.

Optional backguard kit attaches
to the back of range when unit
is installed into a free-standing
cutout.

37

GEAppliances.com

GE

®

30" Slide-In Electric Coil Range

JSP34WD White on white

• Electronic controls • Self-clean oven with
Delay Clean option • Frameless glass oven
door with designer-style handle • Control
lock capability

JSP34CD Bisque on bisque (not shown)
JSP34BD Black on black (not shown)

GE
30" Slide-In Electric Coil Range

JSS26BD Black on black

• Standard-clean oven

• Frameless glass oven door

with designer-style handle

JSS16PD White or Bisque (not shown)

• Standard-clean oven • Color-matched oven door

• Visor handle

GE
30" Slide-In Electric Coil Range

JSP26BD White or Bisque

• Electronic controls • Self-clean oven with Delay
Clean option • Control lock capability

• Frameless

glass oven door with designer-style handle

Optional backguard kit for use
with or without countertop
backsplash.

Optional end cap kit for use
when countertop has been
notched for end caps.

Vertical side trim kit to close
gap between range and
adjacent base cabinet.

These models include • Lift-up overhanging porcelain-enameled cooktop • Two 8" and two 6" plug-in Calrod

®

heating elements

• Electronic clock and kitchen timer • Custom built-in look with simple slide-in installation

Note: bold = feature upgrade from previous model

Slide-In Ranges: 30" Electric

Not all features available on all models.

38

Not all features available on all models.

Slide-In Ranges: 30" Dual-Fuel

GE Profile

™

30" Slide-In Dual-Fuel Range

J2S968SH Stainless steel

• Precise Air electric convection system • Electric
Convection Bake • Electric Convection Roast

• Auto Recipe™conversion • Warm mode

• Proof mode • Gas on glass cooktop • Stainless
steel oven door with Big ClearView

™

window

• Oven meat probe

GE Profile

30" Slide-In Dual-Fuel Range

J2S968KH True bisque
J2S968TH True white (not shown)

GE Profile

30" Slide-In Dual-Fuel Range

J2S968BH Black on black

• Frameless glass oven door with Big
ClearView

™

window • Glass touch controls

These models include • Gas cooktop • Precise Air

™

electric convection system •TrueTemp™system • Electronic controls • Extra-large

self-clean oven • Electronic clock and automatic oven timer • Sealed burners • Continuous grates • Power Boil

™

15,000 BTU burner

• Precise Simmer burner • High Output burner • Three oven racks • Six embossed rack positions • In-oven broiling • Extra-large broiler
pan with grid • Interior oven light • Electronic pilotless ignition • Certified Sabbath mode

Note: bold = feature upgrade from previous model

Precise Air™convection uses an
innovative fan that reverses
direction for optimal air and
heat circulation.

Power Boil™burner with 15,000
BTU, provides maximum output
for fast heat-up and boiling.

Precise Simmer burner allows
for low, even heat distribution
for delicate foods and sauces.

Upfront glass touch controls look
great and are easy to clean.

39

GEAppliances.com

Not all features available on all models.

Sealed burner design helps
contain spills from dripping
beneath cooktop for easy
cleaning.

Extra-large capacity allows you
to cook more at once.

Models shown with required filler
strip provided.

Slide-In Ranges: 30" Gas

GE Profile

30" Slide-In Gas Range

JGS968TH True white

•

Power Boil™burner • High Output burner

• Precise Simmer burner • Sealed burners

• Continuous grates • Gas on glass cooktop

• Convection bake • Convection roast • Auto
Recipe

™

conversion • Warm mode • Proof mode

• Glass touch controls

• TrueTemp system

JGS968KH True bisque (not shown)
JGS968SH Stainless steel (not shown)
JGS968BH Black on black (not shown)

GE Profile

30" Slide-In Gas Range

JGSP48BH Black on black

• Two High Output burners • Precise Simmer
burner • Sealed burners • Continuous grates

• Gas on glass cooktop

• Electronic oven controls

• TrueTemp system • Self-clean oven with light
self-clean option • Frameless glass oven door with
Big ClearView window • Control lock capability

• Certified Sabbath mode

JGSP48CH Bisque on bisque (not shown)
JGSP48WH White on white (not shown)

GE
30" Slide-In Gas Range

JGSS05BEH Black on black

• Extra-large standard-clean oven • Black porcelain­enameled lift-up cooktop • Separate broiler drawer
with extra-large broiler pan and grid • Standard
porcelain-steel grates

GE

®

30" Slide-In Gas Range

JGSP23WEY White on white

• SmartSet electronic controls • Sealed burners

• Standard Simmer burner • Self-clean oven

• Control lock capability • Standard-cast grates

JGSP23BEY Black on black (not shown)
JGSP23CEY Bisque on bisque(not shown)

These models include • Electronic pilotless ignition • Frameless glass oven door with window • Interior oven light • Broiler pan with grid

Note: bold = feature upgrade from previous model

High Output burner supplies the
intense heat needed for boiling
and sautéing.

40

Not all features available on all models.

These models include • SmartSet electronic controls • Self-clean oven with delay option • Control lock capability

Note: bold = feature upgrade from previous model

Drop-In Ranges: 30" Electric

Electronic controls are simple to
understand and easy to operate.
Just read and touch.

The warming zone is a great
way to keep food warm and
ready to enjoy.

Bridge element for total
cooking flexibility.

Fast and easy cleanup is made
possible through our CleanDesign
oven interior/hidden bake
element.

GE Profile

™

30" Drop-In Convection Range

JD968SF Stainless steel

• Precise Air™convection system • Single-rack and
multi-rack convection bake • Convection roast

• Auto Recipe

™

conversion • Electronic glass touch
controls • Proof mode • Warm mode • Stainless
steel oven door with window • Three heavy-duty
racks • Halogen interior oven light

• Certified Sabbath

mode

• Two 7" ribbon heating elements with

connecting bridge element

• One dual (6"/9")

and one 6" ribbon heating element

• Fifth element
warming zone • CleanDesign oven interior/hidden
bake element

GE Profile

30" Drop-In Electric Range

JDP47CF Bisque on bisque

• Extra-large self-clean oven with Delay Clean option

• Two 8", one 6" and one dual (6"/9") ribbon
heating element • Four hot surface indicator lights

• Fingerprint- and scratch-resistant ceramic-glass
CleanDesign cooktop • Frameless glass oven
door with Big ClearView

™

window • Certified

Sabbath mode

JDP47WF White on white (not shown)
JDP47BF Black on black (not shown)

GE Profile

30" Drop-In Convection Range

JD968TF True white
JD968KF True bisque (not shown)
JD968BF Black on black (not shown)

41

GEAppliances.com

GE
30" Drop-In Electric Range

JDP36BW White

• Lift-up overhanging cooktop • Two 8" and two 6"
plug-in heating elements • Removable one-piece drip
bowls • Frameless glass oven door with window

• Designer-style handle

JDP36BD Bisque (not shown)
JDS26BW White (not shown)

• Standard-clean oven

JDS26BD Bisque (not shown)

• Standard-clean oven

GE

®

30" Drop-In Electric Range

JDP39BW Black on black

• Lift-up overhanging cooktop • Two 8" and two 6"
plug-in heating elements • Removable one-piece
drip bowls • Frameless glass oven door with window

• Designer-style handle

JDP39WW White on white (not shown)

42

Not all features available on all models.

Drop-In Spacemaker™Ranges: 27" Electric

These models include • Lift-up overhanging porcelain-enameled cooktop • One 8" and three 6" plug-in Calrod

®

heating elements

• Frameless glass oven door • Big View window • Chrome drip bowls

Note: bold = feature upgrade from previous model

Optional
Backguards

White or black painted
finish is available at
additional cost for all
models.
JX27RWH – White,
JX27RBK – Black

Electronic oven control provides
convenient cooking functions.

Calrod®heating elements unplug
for easy removal of one-piece
drip bowls for cleaning and
access to the subtop.

GE

®

27" Drop-In Electric Range

JMP28BC White

• Self-clean oven with automatic oven door lock

• Electronic clock and minute timer • Auto oven
shut-off

JMP28BD Bisque (not shown)
JMS08BD White or Bisque (not shown)

• Standard-clean oven

GE Profile

™

27" Drop-In Electric Range

JMP31WC White on white

• Self-clean oven with automatic oven
door lock • Electronic clock and
kitchen timer • Auto oven shut-off

• Sure Grip designer-style handle

GEAppliances.com

Not all features available on all models.

These models include • Four-speed fan control • Two halogen cooktop lights (20 watts each) • Night light setting • Vertical exhaust

(600-CFM) • Seven Sones rating • 7" round duct

Optional chimney cover available
to cover exposed duct from the
hood to the ceiling.

Commercial filter kit available for
30" and 36" designer hoods.

Venting Options: Designer Hoods

GE Profile

Designer Hoods

JV966DSS Stainless steel

• 36" width

JV936DSS Stainless Steel

(not shown)

• 30" width

These models include

• See-through glass visor
slides in and out • 300-CFM
performance with variable­speed fan control • Auto
heat sensor • Compact
housing leaves ample shelf
space behind cabinet doors

• Vertical exhaust with
3-1/4" x 10" rectangular
duct • Cooktop light

GE Profile

36" Slide-Out Hood

JV960SC Brushed aluminum

30" Slide-Out Hood

JV930SC Brushed aluminum

(not shown)

GE Profile

36" Slide-Out Hoods

JV696S Bisque on bisque
JV695S White on white (not shown)
JV694S Black on black (not shown)

30" Slide-Out Hoods

JV396S Bisque on bisque (not shown)
JV395S White on white (not shown)
JV394S Black on black (not shown)

Venting Options: Slide-Out Hoods

43

44

Not all features available on all models.

Venting Options: Telescopic Downdraft Systems

GE Profile

Telescopic
Downdraft Systems

JVB37HBB

Black on black

• 30" width

JVB37HWW

White on white

(not shown)

JVB37HCC

Bisque on bisque

(not shown)

GE Profile

Telescopic
Downdraft Systems

JVB67HWW

White on white

• 36" width

• Separate
remote switch to raise/
lower vent

JVB67HCC

Bisque on bisque

(not shown)

JVB67HBB

Black on black (not shown)

Separate remote switch to raise/
lower vent provides installation
flexibility and convenience of
operation (only available on
JVB98 and JVB67).

GE Profile

Telescopic
Downdraft Systems

JVB98SH Stainless steel

• 36" width • Separate
remote switch to raise/
lower vent

JVB94SH Stainless steel

(not shown) • 30" width

Note: Approved for use with all GE Profile
and GE electric and sealed burner gas
cooktops. Not approved for use with
standard burner gas cooktops.

These models include • 500-CFM fan • Upfront variable-speed fan with slide control • Raises to 8-3/4" over cooktop surface • Retracts

when not in use • Ideal for island or peninsula installations • Use optional GE accessory cover (JXBC67) for outdoor installation of blower or
the indoor blower mounting kit (JXRB67) for indoor remote mounting of the blower

Note: bold = feature upgrade from previous model

Note: Cooktops sold separately.

45

GEAppliances.com

Not all features available on all models.

Light bulbs not included.

GE
Standard Hoods

JV338H White (shown) or Bisque

• 3-1/4" x 10" rectangular duct

• Rectangular damper included

JN327H White, Bisque or Almond (not shown)

• Non-vented
JXDA22

round damper accessory, available at additional

cost (Models JV367/347/338).

JXHC1 cord kit allows a receptacle in the cabinet over the

range to accommodate either an over-the-range microwave
oven or a standard hood.

GE Profile

High-Performance Hood

JV666H Stainless steel

• 36" width • Four-speed fan control • Two halogen cooktop lights
(50 watts each) • Night light setting • Vertical (round 410 CFM, rectangular
380 CFM) or rear (390 CFM) exhaust • 3-1/4" x 10" rectangular duct
(convertible to 7" round duct)

JV665H White on white, Bisque on bisque or Black on black (not shown)

GE Profile

Performance Hoods

JV565H White on white (shown), Bisque on bisque or Black on black

• 36" width

• Two-speed fan control • Vertical (round 250 CFM, rectangular
240 CFM) or rear (240 CFM) exhaust • Two halogen cooktop lights
(50 watts each)

• Convertible exhaust options (7" round, rectangular or

non-vented) • Rectangular damper included

JV566H Stainless steel (not shown)
JV535H White on white, Bisque on bisque, or Black on black (not shown)

• 30" width

JV536H Stainless steel (not shown)

JXDA22 round damper accessory, available at additional cost

(Models JV666/665/636/635/566/565/536/535).

GE Profile

High-Performance Hood

JV635H Black on black (shown), Bisque on bisque or White on white

• 30" width • Four-speed fan control • Two halogen cooktop lights
(50 watts each) • Night light setting

• Vertical (round 410 CFM, rectangular

380 CFM) or rear (390 CFM) exhaust

JV636H Stainless steel (not shown)

Note: bold = feature upgrade from previous model

GE

®

Deluxe Hoods

JV367H White on white (shown), Bisque on bisque

or Black on black

• 36" width

• Rotary control • Three-speed fan

• Convertible exhaust (shipped in non-vented
configuration, convertible to 7" round or rectangular
exhaust)

• Rectangular damper included

JV347H White on white, Bisque on bisque or

Black on black

• 30" width

Venting Options: High-Performance, Performance, Deluxe and Standard Hoods

46

30" Built-In Double and Single Ovens
with Trivection

™

Technology

30" Slide-in Electric Range
with Trivection Technology

GE ProfileGE Profile

™

GE Profile

JS998SH
JS998TH
JS998KH
JS998BH

Features

Oven Trivection™/Convection
Oven capacity 4.3 cu. ft.
Trivection™ technology ●

Speed baking ●
Speed broiling ●

Precise Air™ Convection System ●

Multi-rack convection bake ●
Single rack convection bake ●
Convection roast ●

Auto Recipe™ Conversion ●
Self-clean oven w/Delay clean option ●
Light self-clean option ●
Automatic self-clean oven door lock ●
Oven racks 3 Heavy-Duty
TrueTemp™ system ●
Variable broil/Six-pass broil element ●
Dual power bake element ●

Patterned Black

True White

True Bisque

Ceramic-glass cooktop Patterned Black
Overhanging cooktop ●
Dual 6"/9" heating element 1 Ribbon (2500W)
8" heating elements 1 Ribbon (2000)
6" heating elements 2 Ribbon (1500W)
Infinite heat controls ●
Chef’s Guide™ controls Glass touch

Programmable recipe recall ●

Proof mode ●

Warm mode ●

Defrost mode ●

Help mode ●

Optional closed door broiling ●

Temperature display ●

Delay Bake option w/Cook & Hold ●

C° or F° programmable ●

Audible preheat signal ●

Auto oven shut-off w/override ●

Control lock capability ●

Electronic clock/kitchen timer ●
Hot surface indicator lights 4
Heating element “ON” indicator light ●
Certified Sabbath mode ●
Interior oven lights 2 Halogen

Stainless

White

Bisque

Storage drawer Black
Extra-large broiler pan with grid ●
Roasting rack ●
Trivection cookbook ●

Appearance

SS

WW

CC

Color appearance* BB

Stainless steel

White

Bisque

Frameless glass oven door Black
Big View window ●

Stainless look

White

Bisque

Sculptured handle Black

Weights & Dimensions

Overall oven interior dimensions
(WxHxD in inches) 24 x 17-1/2 x 17-1/2

Approx. shipping weight (lbs.) 252

Power/Ratings

KW rating @ 240V 12.8

208V 9.6

Amps @ 240V 40

208V 40
Convection Wattage 2500
Broiler/Bake Wattage 2500/2500

*SS = Stainless steel, WW = White on white, CC = Bisque on bisque,

BB = Black on black.

JT930SH

JT930WH

JT930CH
JT930BH

Features

Oven Trivection™/Convection
Oven capacity 4.3 cu. ft.
Trivection™ technology ●

Speed baking ●
Speed broiling ●

Precise Air™ Convection System ●

Multi-rack convection bake ●
Single-rack convection bake ●
Convection roast ●

Auto Recipe™ Conversion ●
Self-clean oven w/Delay Clean option ●
Automatic self-clean oven door lock ●
Light self-clean option ●
TrueTemp™ System ●
Variable broil/Six-pass broil element ●
Dual power bake element ●
Chef’s Guide™ controls Glass touch

Programmable recipe recall ●

Proof mode ●

Warm mode ●

Defrost mode ●

Help mode ●

Optional closed door broiling ●

Temperature display ●

Delay Bake Option ●

C° and F° programmable ●

Audible preheat signal ●

Auto oven shut-off w/override ●

Electronic clock and kitchen timer ●

Control lock capability ●

Oven lights 2 Halogen

Certified Sabbath Mode ●
Oven racks 3 Heavy-duty
Embossed rack positions 5
Roasting rack ●
Extra-large broiler pan with grid ●
Trivection cookbook ●

Appearance

SS

WW

CC

Color appearance* BB

Stainless steel

White Glass

Bisque Glass

Frameless oven doors Black Glass
Big View window ●

Stainless look

White

Bisque

Sculptured handle Black
Undercounter installation ●

Weights & Dimensions

Approx. shipping wt. (lbs.) 195
Oven cabinet width required (in.) 30
Overall dimensions (WxHxD in inches) 29-3/4 x 28-1/4 x 23-1/2
Overall oven Interior dimensions

(WxHxD in inches) 24 x 17-1/2 x -17-1/2

Power/Ratings

KW rating @ 240V 5.9

208V 4.4

Amps @ 240V 30

208V 30
Convection wattage 2500
Broiler/bake wattage 2500/2500

*SS = Stainless steel, WW = White on white, CC = Bisque on bisque,

BB = Black on black.

JT980SH
JT980WH
JT980CH
JT980BH

Features

Upper Trivection™/Convection
Oven Lower Convection
Oven capacity 4.3 upper/4.1 lower
Trivection™ technology ●

Speed baking Upper
Speed broiling Upper

Precise Air™ Convection System ●

Multi-rack convection bake ●
Single-rack convection bake ●
Convection roast ●

Auto Recipe™ Conversion ●
Self-clean oven w/Delay Clean option ●
Automatic self-clean oven door lock ●
Light self-clean option ●
TrueTemp™ System ●
Variable broil/Six-pass broil element ●
Dual power bake element ●
Chef’s Guide™ controls Glass touch

Programmable recipe recall ●

Proof mode ●

Warm mode ●

Defrost mode ●

Help mode ●

Optional closed door broiling ●

Temperature display ●

Delay Bake Option ●

C° and F° programmable ●

Audible preheat signal ●

Auto oven shut-off w/override ●

Electronic clock and kitchen timer ●

Control lock capability ●

Oven lights 2 Halogen

Certified Sabbath Mode ●

Upper 3 Heavy-duty
Oven racks Lower 3 Heavy-duty
Embossed rack positions 5 Upper/7 Lower
Roasting rack ●
Extra-large broiler pan with grid ●

Appearance

SS

WW

CC

Color appearance* BB

Stainless Steel

White Glass

Bisque Glass

Frameless oven doors Black Glass
Big View window ●

Stainless look

White

Bisque

Sculptured handles Black
Trivection cookbook ●

Weights & Dimensions

Approx. shipping wt. (lbs.) 322
Oven cabinet width required (in.) 30
Overall dimensions (WxHxD in inches) 29-3/4 x 52-7/8 x 23-1/2
Overall oven Interior Upper 24 x 17-1/2 x 17-1/2
dimensions (WxHxD in inches) Lower 24 x 16-1/4 x 18-1/4

Power/Ratings

KW rating @ 240V 8.9

208V 6.7

Amps @ 240V 40

208V 40
Convection wattage 2500
Broiler/bake wattage 2500/2500

*SS = Stainless steel, WW = White on white, CC = Bisque on bisque,

BB = Black on black.

47

GEAppliances.com

30" Built-In Double Oven Dimensions (in inches)
Model JT980

30" Built-In Single Oven Dimensions (in inches)
Model JT930

21" minimum

Door Opening

Allowance

B

B

A

A

Cutout height
51-13/16" MIN.
51-15/16" MAX.

Minimum cutout location
12" from the floor.

Cutout width
28-1/2’’ MIN.
28-5/8’’ MAX.

21

Cabinet

width

30"

C

E

D

MOST 30’’ WALL CABINETS CAN BE USED WITH THIS UNIT.

THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2’’ WIDE.

CUTOUT DEPTH

23-1/2’’ MIN.

C

L

Suitable
bracing

to support

runners

18"

Over centerline

of cabinet

2" x 4" or
equivalent
runners

Cabinet 30"

A – Overlap of Oven

Over Side Edges
of Cutout 11/16" – 3/4"

B – Overlap of Oven

at Top and Bottom
of Cutout 1"

Oven

C – Overall Depth 23-1/2"
D – Overall Height 52-7/8"
E – Overall Width 29-3/4"

(Must support 275 LBS.)

Installation Information:

Before installing, consult installation instructions packed with product for current

dimensional data or download from GEAppliances.com.

Note: Cabinets installed adjacent to wall ovens must have an adhesion spec of at least 194° F temperature rating.

No change in cutout
dimensions. Junction box
may require relocation.

No change in cutout
dimensions. Junction box
may require relocation.

Electric wall ovens are not approved for installation with a plug and receptacle. They must be hard wired in
accordance with installation instructions.

R

Listed by
Underwriters
Laboratories

Bottom of

Cutout

Acceptable
junction box
location area
DWO

32"

25"

7"

Note: These ovens are not approved for
stackable or side-by-side installations.

Most 30" Wall Cabinets can be used with this unit. The opening
between the inside walls must be at least 28-1/2” wide.

29-3/4

28-1/4

30

Minimum

cutout location

32-1/2"

from floor

21

Allow minimum of 21’’ for clearance
to adjacent corners, drawers, walls, or etc.

A=Allow 1" overlap of oven over top and bottom edges of cutout.
B=Allow 11/16"-3/4" for overlap of oven over side edges of cutout.

27-1/4’’ MIN.
27-5/16’’ MAX.
Cutout height

A

B

23-1/2’’ MIN.
Cutout depth

Cutout width
28-1/2’’ MIN.
28-5/8’’ MAX.

(Must support 200 LBS.)

C

L

Suitable
bracing

to support

runners

18"

Over centerline

of cabinet

2" x 4" or
equivalent
runners

Bottom of

Cutout

Acceptable
junction box
location area
SWO

18"

12"

3-1/2"

10-3/4

"

All GE ranges are equipped
with an Anti-Tip device.
The installation of this
device is an important,
required step in the
installation of the range.

Note: Cabinets installed adjacent to slide-in electric ranges must
have an adhesion spec of at least a 194°F temperature rating.

Note: All 30" Slide-In Ranges conform to U.L. requirements for 0"
spacing from range to adjacent walls below countertop. To reduce
possibility of scorching the side walls above the countertop when
no load is present on burners, it is recommended that a minimum
6" spacing from adjacent side wall be allowed for possible extended
high-heat element operation.

Receptacle Locations: For all 30" Slide-in Ranges locally approved
flexible service cord or conduit must be used because terminals
are not accessible after range installation. See shaded area in
drawing for location of electrical outlet box. Recommended outlet
locations allow range to be installed directly against rear wall.

Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.

30" Slide-In Range Dimensions (in inches)
Model JS998

2-7/8"

To Front
Surface Of
Countertop

20-5/8" Door
Clearance
From Front
Surface of
Countertop

31-1/4

30

27-1/2

4

Accessory
Backguard

Acceptable

Electrical

Outlet Area

30" Min.

30" Min.

Shave Raised Edge To Clear
31-1/8" Wide Control Panel

36

6" Min.

From Walls

23-3/16

15" Min.

13" Max.

2-1/2

30

25

9/16

7-1/2

2-1/2

Accessory Backguards (Shown above)
(Attaches to the back of range as a backguard when unit
is installed in 30” free-standing cutout)
JXS37WW—White, JXS37CC—Bisque,
JXS37BB—Black/Stainless

48

JT955SF JT952SF

JTP48SF JTP28SF JT965SF JTP86SH

JT955WF JT952WF JTP48WF JTP28WF JT965WF JTP86WF

JT955CF JT952CF JTP48CF JTP28CF JT965CF JTP86CF
JT955BF JT952BF JTP50SH JTP48BF JTP28BF JT965BF JTP86BF

Features

Upper Convection/Self-Clean Convection/Self-Clean Self-Clean Self-Clean Self-Clean Microwave Microwave
Oven Lower Thermal/Self-Clean Thermal/Self-Clean Self-Clean Self-Clean Standard Convection/Self-Clean Self-Clean
Cleaning time Variable Variable Variable Variable Variable (upper) Variable (lower) Variable (lower)
Automatic self-clean oven door lock ●●●●Upper Lower Lower
Self-clean oven w/Delay Clean option ●●●●Upper Lower Lower
Light self-clean option ●●●●Upper
TrueTemp™ System ●●●●Upper Lower Lower
CleanDesign oven interior/hidden bake ●● Lower
Variable broil/Six-pass broil element ●● ●●●Lower Lower
Eight-pass bake element ●● Lower
Precise Air™ Convection System Upper Upper

Convection bake Multi/Single-rack Upper Upper Lower
Convection roast Upper Upper Lower
Auto Recipe™ Conversion Upper Upper

SmartSet controls Glass Touch ●●●Upper ●●

Proof Mode Upper
Oven meat probe Upper Upper Lower
Warm Mode Upper
Optional closed door broiling ●●●●●Lower Lower
Temperature display ●●●●Upper Lower Lower
Delay Bake Option ●●●●Upper Lower Lower
C° and F° programmable ●●●●Upper Lower Lower
Audible preheat signal ●●●●Upper Lower Lower
Auto oven shut-off w/override ●●●●Upper Lower Lower
Electronic clock and kitchen timer ●●●●Upper Lower ●
Control lock capability ●●●●Upper Lower Lower
Oven light Halogen ● ●●●Halogen (lower) Lower
Certified Sabbath Mode ●●●●Upper

Microwave Oven Features:

Microwave cooking timer 99-Min./99-Sec. 99-Min./99-Sec.
Microwave power levels 10 10
Sensor functions 63
Electronic MWO touch controls ●●
Microwave oven cavity (cu. ft.) 1.6 1.6
MWO power output watts 1000 1000
Turntable ●●

Upper 3 Heavy-duty 3 Heavy-duty 2 2 2
Oven racks Lower 2 Heavy-duty 2 Heavy-duty 2 2 2 3 Heavy-duty 2
Embossed rack positions 7 Upper/6 Lower 7 Upper/6 Lower 6 Upper/6 Lower 6 Upper/6 Lower 6 Upper/6 Lower 7 Lower 6 Lower
Roasting rack Upper Lower
Broiler pan with grid Upper Upper Upper Upper Upper Lower Lower

Appearance

SS SS SS SS SS SS

WW WW WW WW WW WW

CC CC CC CC CC CC

Color appearance* BB BB SS BB BB BB BB

Stainless Steel

Stainless Steel

Stainless Steel Stainless Steel Stainless Steel Stainless Steel

White Glass White Glass White Glass White Glass White Glass White Glass

Bisque Glass Bisque Glass Bisque Glass Bisque Glass Bisque Glass Bisque Glass

Frameless oven doors Black Glass Black Glass Stainless Steel Black Glass Black Glass Black Glass Black Glass
Big ClearView™ windows ●● ●●●Lower Lower

Sculptured Stainless-look

Sculptured Stainless-look Black Black Sculptured Stainless-look Stainless look

Sculptured White Sculptured White White White Sculptured White White

Sculptured Bisque Sculptured Bisque Bisque Bisque Sculptured Bisque Bisque

Oven door handles Sculptured Black Sculptured Black Stainless look Black Black Sculptured Black Black
Flush appearance installation ●●●●● ●●
Convection cookbook ●● ●

Weights & Dimensions

Approx. shipping wt. (lbs.) 260 260 260 260 260 177 177
Oven cabinet width required (in.) 30 30 30 30 30 30 30
Overall dimensions (WxHxD in inches) 29-3/4 x 52-7/8 x 23-1/2 29-3/4 x 52-7/8 x 23-1/2 29-3/4 x 52-7/8 x 23-1/2 29-3/4 x 52-7/8 x 23-1/2 29-3/4 x 52-7/8 x 23-1/2 29-3/4 x 43-1/4 x 23-1/2 29-3/4 x 43-1/4 x 23-1/2

Overall oven
Interior dimensions Upper 24 x 16-1/4 x 18-1/4 24 x 16-1/4 x 18-1/4 24 x 17-1/2 x 18-1/4 24 x 17-1/2 x 18-1/4 24 x 17-1/2 x 18-1/4 16-1/4 x 9-5/8 x 15-3/4 16-1/4 x 9-5/8 x 15-3/4

(WxHxD in inches) Lower 24 x 16-1/4 x 18-1/4 24 x 16-1/4 x 18-1/4 24 x 17-1/2 x 18-1/4 24 x 17-1/2 x 18-1/4 24 x 17-1/2 x 18-1/4 24 x 16-1/4 x 18-1/4 24 x 17-1/2 x 18-1/4

Power/Ratings

KW rating @ 240V 7.2 7.2 7.2 7.2 8.8 6.6 6.6

208V 5.4 5.4 5.4 5.4 6.6 5.3 5.3

Amps @ 240V 40 40 40 40 40 30 30

208V 30 30 30 30 30 30 30
Convection wattage 2500 2500 2500
Broiler/bake wattage 3600/2700 3600/2700 3600/3410 3600/3410 3600/3410 3600/2700 3600/3410

*SS = Stainless steel, WW = White on white, CC = Bisque on bisque, BB = Black on black.

30" Built-In Double Ovens

Convection Double Ovens Microwave Double OvensDouble Ovens

GE

®

GE Profile

™

GE Profile GE

R

Listed by
Underwriters
Laboratories

49

GEAppliances.com

Installation Information: Before installing, consult installation instructions packed
with product for current dimensional data.

Cabinet 30"

A – Overlap of Oven Over Side Edges of Cutout 11/16"
B – Overlap of Oven at Bottom of Cutout 1"
C – Overlap of Oven at Top of Cutout 1/2"

Oven

D – Overall Depth 23-1/2"
E – Overall Height 43-1/2"
F – Overall Width 29-3/4"

Cabinet 30"

A – Overlap of Oven Over Side Edges of Cutout 11/16" – 3/4"
B – Overlap of Oven at Top and Bottom of Cutout 1"

Oven

C – Overall Depth 23-1/2"
D – Overall Height 52-7/8"
E – Overall Width 29-3/4"

C

L

2 x 4 or
equivalent
runners

Suitable

bracing

to support

runners

21-5/8"

over centerline

of cabinet

Note: Cabinets installed adjacent to wall ovens must have
an adhesion spec of at least a 194°F temperature rating.

Note: Cabinets installed adjacent to wall ovens must have
an adhesion spec of at least a 194°F temperature rating.

20''

28''

21''

A

F

A

B

C

CONDUIT

(48'' LONG)

CUTOUT

HEIGHT
42-3/16'' MIN.
42-1/4'' MAX.

CUTOUT

WIDTH
28-1/2'' MIN.
28-5/8'' MAX.

Minimum

cutout location

21-5/8''

from the floor

21" Minimum

Door Allowance

JUNCTION BOX

LOCATION

CABINET

WIDTH

30''

DOOR MUST BE

REMOVED BEFORE

INSTALLATION

MOST 30'' WALL CABINETS CAN BE USED WITH THIS UNIT.

THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2'' WIDE.

D

CUTOUT DEPTH

23-1/2'' MIN.

E

21" minimum

Door Opening

Allowance

B

B

A

A

Cutout height
51-13/16" MIN.
51-15/16" MAX.

Minimum cutout location
12" from the floor.

Cutout width
28-1/2’’ MIN.
28-5/8’’ MAX.

21

Cabinet

width

30"

C

E

D

MOST 30’’ WALL CABINETS CAN BE USED WITH THIS UNIT.

THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2’’ WIDE.

CUTOUT DEPTH

23-1/2’’ MIN.

30" Built-In Double Oven Dimensions (in inches)
Models JT955, 952, JTP50, 48, 28

30" Built-In Microwave Double Oven Dimensions (in inches)
Models JT965, JTP86

(Must support 275 lbs.)

C

L

2 x 4 or
equivalent
runners

Suitable

bracing

to support

runners

21-5/8"

over centerline

of cabinet

(Must support 275 lbs.)

Electric wall ovens are not approved for installation with a plug and receptacle.
They must be hard wired in accordance with installation instructions.

50

30" Built-In Single Ovens

30" Built-In Single Oven Dimensions (in inches)
Single Oven Wall-Mount or

Cabinet Installation
(in inches)

Note: These ovens are not approved for stackable or
side-by-side installations.

Most 30" Wall Cabinets can be used with this unit.

Cutout width
28-1/2'' MIN.
28-5/8'' MAX.

29-3/4

28-1/4

30

Recommended

cutout location

32-1/2"

from floor

21

Junction
box
location

Allow minimum of 21'' for clearance
to adjacent corners, drawers, walls, or etc.

A=Allow 1" overlap of oven over top and bottom edges of cutout.
B=Allow 11/16"-3/4" for overlap of oven over side edges of cutout.

Conduit

(48" long)

5

27-1/4'' MIN.
27-5/16'' MAX.
Cutout height

A

B

23-1/2'' MIN.
Cutout depth

22'' MIN.

JT915SF JT912SF JTP20SF

JT915WF

JT912WF JTP20WF
JT915CF JT912CF JTP20CF
JT915BF JT912BF JTP25SH JTP20BF

Features

Oven Convection/Self-Clean Convection/Self-Clean Self-Clean Self-Clean
Cleaning time Variable Variable Variable Variable
Automatic self-clean oven door lock ●●●●
Self-clean oven w/Delay Clean option ●●●●
Light self-clean option ●●●●
TrueTemp™ System ●●●●
CleanDesign oven interior/hidden bake ●●
Variable broil/Six-pass broil element ●●●●
Eight-pass bake element ●●
Precise Air™ Convection System ●●

Convection bake Multi/Single-rack ●
Convection roast ●●
Auto Recipe™ Conversion ●●

SmartSet controls Glass touch ●●●

Proof Mode ●
Warm Mode ●
Oven meat probe ●●
Optional closed door broiling ●●●●
Temperature display ●●●●
Delay Bake Option ●●●●
C° and F° programmable ●●●●
Audible preheat signal ●●●●
Auto oven shut-off w/override ●●●●
Electronic clock and kitchen timer ●●●●
Control lock capability ●●●●
Oven light Halogen ●●●
Certified Sabbath Mode ●●●●

Oven racks 3 Heavy-duty 3 Heavy-duty 2 2
Embossed rack positions 7 7 6 6
Roasting rack ●
Broiler pan with grid ●●●●
Convection cookbook ●●

Appearance

SS SS SS

WW WW WW

CC

CC CC

Color appearance* BB BB SS BB

Stainless steel

Stainless steel Stainless steel

White Glass

White Glass White Glass

Bisque Glass Bisque Glass Bisque Glass

Frameless oven doors Black Glass Black Glass Stainless Steel Black Glass
Big ClearView™ window ●●●●

Sculptured Stainless-look Sculptured Stainless-look Black

Sculptured White Sculptured White White

Sculptured Bisque Sculptured Bisque Bisque

Oven door handle Sculptured Black Sculptured Black Stainless-Look Black
Flush appearance installation ●●●●
Undercounter installation ●●●●

Weights & Dimensions

Approx. shipping wt. (lbs.) 135 135 133 130
Oven cabinet width required (in.) 30 30 30 30
Overall dimensions (WxHxD in inches) 29-3/4 x 28-1/4 x 23-1/2 29-3/4 x 28-1/4 x 23-1/2 29-3/4 x 28-1/4 x 23-1/2 29-3/4 x 28-1/4 x 23-1/2
Overall oven Interior dimensions

(WxHxD in inches) 24 x 16-1/4 x 18-1/4 24 x 16-1/4 x 18-1/4 24 x 17-1/2 x 18-1/4 24 x 17-1/2 x 18-1/4

Power/Ratings

KW rating @ 240V 3.6 3.6 3.6 3.6

208V 2.7 2.7 2.7 2.7

Amps @ 240V 20 20 20 20

208V 20 20 20 20
Convection wattage 2500 2500
Broiler/bake wattage 3600/2700 3600/2700 3600/3410 3600/3410

*SS = Stainless steel, WW = White on white, CC = Bisque on bisque, BB = Black on black.

Convection Single Ovens Single Ovens

GE Profile

™

GE

®

Note: Cabinets installed adjacent to wall ovens must have

an adhesion spec of at least a 194°F temperature rating.

C

L

2 x 4 or
equivalent
runners

Suitable

bracing

to support

runners

21-5/8"

over centerline

of cabinet

(Must support 275 lbs.)

R

Listed by
Underwriters
Laboratories

51

GEAppliances.com

Undercounter Installation (in inches)

5

24

25

Gas or electric cooktops may be installed over
this oven. See cooktop installation instructions
for cutout size. See label on top of oven for
approved cooktop models.

Gas (including the pressure regulator) and
electrical connections for gas cooktop must
be located in an adjacent accessible location
to the right. For a 36" gas cooktop, the
connections may be made to the left.

120 Volt
Outlet

Gas
connection

Junction box
location
240/208V

36'' MIN.

4'' To 4-1/2 '' Toe kick allowable

Match toe kick height
front and two sides

22'' MIN. above
support platform

Top and/or side
fillers may be
necessary if unit
is positioned
between
existing cabinets

28-1/2'' MIN.
28-5/8'' MAX.

27-1/4'' MIN.
27-5/16'' MAX.
Cutout height

3/4'' Support
platform required

23-1/2" MIN.
Cutout depth

Allow 11/16''
overlap over side
edges of cutout

1-1/2"
Countertop

This installation is to achieve minimum gap between bottom of countertop and control panel.

Note: For this installation, the bottom trim will not be flush with a typical 4" toe kick.

Note: Cabinets installed adjacent to wall ovens must have an adhesion spec of at least

a 194°F temperature rating.

Note: For standard or sealed burner cooktop installation information over the
30" wall oven, refer to 27" wall oven installation, page 49.

5-9/16"

Reference dim. for

MAX. support height

with typical 36" countertop

height

36" Typical
Countertop height

Power cord

Reference
5-9/16

30-7/16

Free space

1-1/2" MIN.

1-1/2" Typical countertop

Side View

22

27-5/16" MAX.

Cutout height

27-1/4" MIN.

Junction box(s) for

oven & radiant

cooktop 22" from

floor

Add suitable filler

to match adjacent

cabinets when needed

to maintain toe kick

alignment

Optional Undercounter Installation With 36" Gas Cooktop
(in inches)

Power cord
for counter unit

Junction box
for oven

Junction box in
adjacent cabinet
for counter unit
hook-up

2 (two) 90°elbows &
sufficient pipe to
connect in adjacent
cabinet

Right cabinet side

3/4" Support

Shut-off

valve

Pressure
regulator

1/2" Black

iron pipe

Union

Conduit

(48" long)

30" built-in

oven

3-1/2" MIN.
Free space

4" To 4-1/2"

3-1/4

22

19-1/16" Cutout depth

Side View

Optional Undercounter Installation With
30" CleanDesign or Sealed Burner Gas Cooktop (in inches)

Note: 36" ribbon cooktops (excluding JP960) are

approved for use over GE 30" single wall ovens only.
30" ribbon cooktops are approved for use over GE
30" and GE 27" single wall ovens. Refer to cooktop
and wall oven installation information packed with
products for current dimensional data.

Installation Information: Before installing, consult
installation instructions packed with product for current
dimensional data and for alternate installation options.

Installation Information: Before installing, consult installation instructions packed
with product for current dimensional data.

Electric wall ovens are not approved for installation with a plug and receptacle.
They must be hard wired in accordance with installation instructions.

52

JK955SF JKP86SH

JK955WF JKP48WF JKP86WF

JK955CF JKP48CF JKP28WF

JKP86CF

JK955BF JKP50SH JKP48BF JKP28BF JKP86BF JRP24BD

Features

Upper Convection/Self-Clean Self-Clean Self-Clean Self-Clean Microwave Self-Clean
Oven Lower Thermal/Self-Clean Self-Clean Self-Clean Standard Self-Clean Standard
Cleaning time Variable Variable Variable Variable (upper) Variable (Lower) Variable (upper)
Automatic self-clean oven door lock ●●●Upper Lower Upper
Self-clean oven w/Delay Clean option ●●●Upper Lower Upper
Light self-clean option ●●●Upper
TrueTemp™ System ●●●Upper Lower
CleanDesign oven interior/hidden bake ●
Variable broil ● ●●●Lower Upper
Precise Air™ Convection System Upper

Multi-rack convection bake Upper
Single-rack convection bake Upper
Convection roast Upper
Auto Recipe™ Conversion Upper

SmartSet Controls Glass touch ●●Upper Lower Upper

Proof Mode Upper
Warm Mode Upper
Oven meat probe Upper
Optional closed door broiling ● ●●●Lower
Temperature display ●●●Upper ● Upper
Delay Bake Option ●●●Upper Lower Upper
C° and F° programmable ●●●Upper Lower Upper
Audible preheat signal ●●●Upper Lower ●
Auto oven shut-off w/override ●●●Upper Lower Upper
Electronic clock and kitchen timer ● ●●●●●
Control lock capability ●●●Upper Lower Upper
Oven light Halogen ●●●Lower ●
Certified Sabbath Mode ●●●Upper

Microwave Oven Features:

Microwave cooking timer 99-Min./99-Sec.
Microwave power levels 10
Sensor functions 3
Electronic MWO touch controls ●
Microwave oven cavity (cu. ft.) 1.6
MWO power output watts 1000
Turntable ●

Upper 3 Heavy-duty 2 2 2 2
Oven racks Lower 2 Heavy-duty 2 2 2 2 2
Embossed rack positions 4 Upper/4 Lower 4 Upper/4 Lower 4 Upper/4 Lower 4 Upper/4 Lower 4 Lower 2 Upper/2 Lower
Roasting rack Upper
Broiler pan with grid Upper Upper Upper Upper Lower ●
Convection cookbook ●

Appearance

SS SS

WW WW WW

CC

CC WW

CC

Color appearance* BB SS BB BB BB BB

Stainless steel

Stainless Steel

White Glass

White Glass

White Glass

Bisque Glass Bisque Glass White Glass Bisque Glass

Frameless oven doors Black Glass Stainless Steel Black Glass Black Glass Black Glass Black Glass
Big ClearView™ windows ● ●●●Lower ●

Sculptured Stainless-look Stainless-Look

Sculptured White

White White

Sculptured Bisque Bisque White Bisque

Oven door handles Sculptured Black Stainless-Look Black Black Black Black
Flush appearance installation ● ●●●●

Weights & Dimensions

Approx. shipping wt. (lbs.) 162 160 157 157 155 135
Oven cabinet width required (in.) 27 27 27 27 27 24
Overall dimensions (WxHxD in inches) 26-5/8 x 51 x 23-5/8 26-5/8 x 51 x 23-5/8 26-5/8 x 51 x 23-5/8 26-5/8 x 51 x 23-5/8 26-5/8 x 42-1/2 x 23-5/8 23-3/4 x 48-5/8 x 23-1/8
Overall oven Interior

dimensions Upper 21-1/2 x 17 x 18-1/4 21-1/2 x 17 x 18-1/4 21-1/2 x 17 x 18-1/4 21-1/2 x 17 x 18-1/4 16 x 11-1/8 x 13-3/8 17 x 15 x 18-1/2
(WxHxD in inches) Lower 21-1/2 x 17 x 18-1/4 21-1/2 x 17 x 18-1/4 21-1/2 x 17 x 18-1/4 21-1/2 x 17 x 18-1/4 21-1/2 x 17 x 18-1/4 17 x 15 x 18-1/2

Power/Ratings

KW rating @ 240V 6.8 6.8 6.8 7.1 6.4 7.1

208V 5.1 5.1 5.1 5.3 5.1 5.3

Amps @ 240V 30 30 30 30 30 30

208V 30 30 30 30 30 30
Convection wattage 2500
Broiler/bake wattage 3400/2650 3400/2650 3400/2650 3400/2650 3400/2650 3400/2600

*SS = Stainless steel, WW = White on white, CC = Bisque on bisque, BB = Black on black.

27" and 24" Built-In Double Ovens

27" Microwave
Double Ovens

27" Convection
Double Ovens

27" Double Ovens

GE Profile

™

GE

®

24" Double Oven

R

Listed by
Underwriters
Laboratories

53

GEAppliances.com

27" Built-In Microwave Double Oven Dimensions (in inches)
Model JKP86

27"/24" Built-In Double Oven Dimensions (in inches)

Oven Support
For 27" Models

Oven Support
For 24" Models

E

Minimum
cutout location
from floor

Allow minimum of
20" for clearance
to adjacent corners,
drawers, walls, etc.

20

2" X 4" or
equiv. runners

Conduit

(49" long)

Allow 3/4" for overlap
of oven over all
edges of cutout

10

A

D

Recommended
junction box
locations.
Locate junction
box either 5" MIN.
below cutout
floor or 48" MIN.
above cutout
floor

C

B

F

G

H

Cabinet 27"

A – Cabinet Width Required 27" min.
B – Minimum Cabinet Depth 23-5/8"
C – Opening Width 25" min. - 25-1/4 max.
D – Opening Height 41-1/4" max.
E – Minimum Cutout Location from Floor 22"

Oven

F – Overall Depth 23-5/8"

w/o trim 41-3/8"
G – Overall Height with trim 42-1/8"
H – Overall Width 26-5/8"

10

Locate
junction box

for 27"models
either 5" MIN.

below cutout
floor or 44"
MIN. above
cutout floor

Allow 3/4"
for overlap
over all edges
of cutout

A

Minimum
cutout location
from floor

D

E

2" X 4" or
equiv. runners
(cutout floor)

20" MIN.
door opening
allowance

B

C

H

F

G

Locate
junction box

for 24"models

56" MIN. above
cutout floor

Conduit

(49" Long)

Cabinet JK955/JKP50/48/28 JRP24

A – Cabinet Width Required 27" min. 24" min.
B – Minimum Cabinet Depth 23-5/8" 23-1/2"
C – Opening Width 25" min. - 25-1/4 max. 22-1/2"
D – Opening Height 50-1/8" max. 48-1/8" min.
E – Recommended Minimum

Cutout Location from Floor 13-1/4" 14"

Oven

F – Overall Depth 23-5/8" 23-1/8"

w/o trim 50-1/4" 48-1/8"
G – Overall Height with trim 51" 49-1/4"
H – Overall Width 26-5/8" 23-3/4"

C

L

Suitable
bracing

to support

runners

18"

Over centerline

of cabinet

2" x 4" or
equivalent
runners

C

L

Suitable
bracing

to support

runners

18"

Over centerline

of cabinet

2" x 4" or
equivalent
runners

(Must support 275 lbs.)

(Must support 275 lbs.)

(Must support 275 lbs.)

Note: Cabinets installed adjacent to wall ovens must have an adhesion spec of at
least a 194°F temperature rating.

Note: If marks, blemishes or the cutout opening is visible above the installed oven,
it may be necessary to add wood shims under the runners and front trim until the
marks or openings are covered.

Note: If marks, blemishes or the cutout opening is visible above the installed oven,
it may be necessary to add wood shims under the runners and front trim until the
marks or openings are covered.

Note: Cabinets installed adjacent to wall ovens must have an adhesion spec of at
least a 194°F temperature rating.

C

L

2 x 4 or
equivalent
runners

Suitable

bracing

to support

runners

21-5/8"

over centerline

of cabinet

Installation Information: Before installing, consult installation instructions packed
with product for current dimensional data.

Electric wall ovens are not approved for installation with a plug and receptacle.
They must be hard wired in accordance with installation instructions.

54

27" and 24" Built-In Single Ovens

JK915SF
JK915WF JKP20WF
JK915CF JKP20CF JRP15WW
JK915BF JKP25SH JKP20BF JKS06BF JRP15BW JRS04BW

Features

Convection/

Oven Self-Clean Self-Clean Self-Clean Standard-Clean Self-Clean Standard
Cleaning time Variable Variable Variable Variable
Automatic self-clean oven door lock ●●● ●
Self-clean oven w/Delay Clean option ●●● ●
Light self-clean option ●●●
TrueTemp™ System ●●●●
CleanDesign oven interior/hidden bake ●
Variable broil ●●●●●●
Precise Air™ Convection System ●

Multi-rack convection bake ●
Single-rack convection bake ●
Convection roast ●
Auto Recipe™ Conversion ●

SmartSet Controls Glass touch ●●●●●

Proof Mode ●
Warm Mode ●
Oven meat probe ●
Optional closed door broiling ●●●●
Temperature display ●●●●●●
Delay Bake Option ●●●●●●
C° and F° programmable ●●●●●●
Audible preheat signal ●●●●●●
Auto oven shut-off w/override ●●●●●●
Electronic clock and kitchen timer ●●●●●●
Control lock capability ●●● ●
Oven light Halogen ●●●●
Certified Sabbath Mode ●●●●

Oven racks 3 Heavy-duty 2 2 2 2 2
Embossed rack positions 4 4 4 4
Roasting rack ●
Broiler pan with grid ●●●●●●
Convection cookbook ●

Appearance

SS

WW WW

CC

CC WW

Color appearance* BB SS BB BB BB BB

Stainless Steel

White Glass

White Glass

Bisque Glass Bisque Glass White Glass

Frameless oven doors Black Glass Stainless Steel Black Glass Black Glass Black Glass Black Glass
Big ClearView™ windows ●●●●Standard Standard

Sculptured

Stainless-look

Sculptured White

White

Sculptured Bisque Bisque White

Oven door handles Sculptured Black Stainless-Look Black Black Black Black
Flush appearance installation ●●●●
Undercounter installation ●●●●

Weights & Dimensions

Approx. shipping wt. (lbs.) 98 96 93 91 114 82
Oven cabinet width required (in.) 27 27 27 27 24 24
Overall dimensions 26-5/8 x 26-5/8 x 26-5/8 x 26-5/8 x 23-3/4 x 23-3/4 x

(WxHxD in inches) 29 x 23-5/8 29 x 23-5/8 29 x 23-5/8 29 x 23-5/8 28-3/16 x 23-1/8 28-3/16 x 23-1/8
Overall oven Interior dimensions 21-1/2 x 21-1/2 x 21-1/2 x 21-1/2 x 17 x 17 x

(WxHxD in inches) 17 x 18-1/4 17 x 18-1 17 x 18-1/4 17 x 18-1/4 15 x 18-1/2 15 x 18-1/2

Power/Ratings

KW rating @ 240V 3.4 3.4 3.4 3.4 3.4 3.4

208V 2.6 2.6 2.6 2.6 2.6 2.6

Amps @ 240V 20 20 20 20 20 20

208V 20 20 20 20 20 20
Convection wattage 2500
Broiler/bake wattage 3400/2650 3400/2650 3400/2650 3400/2000 3400/2600 3400/2000

*SS = Stainless steel, WW = White on white, CC = Bisque on bisque, BB = Black on black.

27" Convection
Single Ovens

27 " Single Ovens 24" Single Ovens

GE

®

GE Profile

™

R

Listed by
Underwriters
Laboratories

27"/24" Built-In Single Oven Dimensions (in inches)

2" x 4"
or equiv.
runners

B MIN.

C MIN.

Conduit 49" long

32-1/2

D

10

A

Allow 3/4"
for overlap
over all edges
of cutout

Locate
junction box
either 5" MIN.
below cutout
floor or 44"
MIN. above
cutout floor

Minimum
cutout location
from floor

(Minimum 15-5/8"
from floor when
installed below built-in
microwave oven)

E

G

F

20

Note: Models JKS06, JRP15, JKP20, JKP25, JK915 and JRS04
are

not approved for stackable or side-by-side installations.

Note: Models JK915 and JKP20, JKP25 can be installed
side-by-side in separate enclosures, with no less than 30"
distance between center-to-center of each oven.

Note: Cabinets installed adjacent to wall ovens must have an

adhesion spec of at least a 194°F temperature rating.
Note: For 27" built-in single ovens, if marks, blemishes or the cutout

opening is visible above the installed oven, it may be necessary to
add wood shims under the runners and front trim until the marks or
openings are covered.

Oven Support
For 27" Models

Oven Support
For 24" Models

(Must support 275 lbs.)

(Must support 275 lbs.)

C

L

2 x 4 or
equivalent
runners

Suitable

bracing

to support

runners

21-5/8"

over centerline

of cabinet

C

L

Suitable
bracing

to support

runners

18"

Over centerline

of cabinet

2" x 4" or
equivalent
runners

Cabinet JK915/JKP25, 20,

JKS06 JRP15, JRS04

A – Cabinet Width Required 27" min. 24" min.
B – Minimum Cabinet Depth 23-5/8" 23-1/2"
C – Opening Width 25" min. - 25-1/4 max. 22-1/2"

27-5/8" min. -

D – Opening Height 28-1/8" max. 27-5/8" min.

Oven

E – Overall Depth 23-5/8" 23-1/8"

w/o trim 28-1/4" 27-1/2"
F – Overall Height with trim 29" 28-3/16"
G – Overall Width 26-5/8" 23-3/4"

55

GEAppliances.com

Undercounter Installation Dimensions (in inches)
Models JK915, JKP25, 20 and JKS06

Sealed Burner Gas Cooktop
Installation Dimensions (in inches)

Standard Burner Gas Cooktop
Installation Dimensions (in inches)

25

Gas or electric cooktops may be installed over this
oven. See cooktop installation instructions for cutout size.
See label on top of oven for approved cooktop models.

Gas or electric connections
for gas cooktop must be
located in an adjacent
accessible location to the right

5

240V / 208V
Junction Box
Location

36"
Typical
Countertop
Height

24

Allow 1"
unit overlap
all edges

25" MIN.
25 1/4" MAX.

27 5/8" MIN.
28 1/8" MAX.

3/4" Support
Platform Required

Must Support 150 Lbs.

22" MIN.
Above
Support
Platform

90° Street el

45° Elbow

Cabinet sides

2" Diameter hole (20-7/8"
from front of countertop
to hole center)

5" To center of 2" diameter
hole from countertop

90° Street el

45° Elbow

To center of 2" diameter
hole from countertop

Cabinet sides

3-7/16"

2" MIN. diameter hole
(23-1/4" from front
surface of countertop)

Note: Cabinets installed adjacent to wall ovens must have an adhesion spec
of at least a 194°F temperature rating.

Note: Oven is rated for use only under 30" standard or sealed burner gas
and selected 30" CleanDesign and Calrod

®

electric cooktops.

Electric wall ovens are not approved for installation with a plug and receptacle.
They must be hard wired in accordance with installation instructions.

Note: 36" ribbon cooktops (excluding JP960) are

approved for use over GE 30" single wall ovens
only. 30" ribbon cooktops are approved for use
over GE 30" and GE 27" single wall ovens. Refer
to cooktop and wall oven installation information
packed with products for current dimensional data.

24" Built-In Gas Ovens

JGRP17WEW

JGRP17BEW JGRS14BEW

Features

Oven interior Self-Clean Standard
Automatic self-clean oven door lock ●
Delay Clean option ●
In-oven broiling ●
Separate broiler drawer ●
Storage drawer ●
SmartSet controls ●●

Temperature display ●●
Start pad ●●
Delay Bake option w/Cook & Hold ●●
C° or F° programmable ●●
Audible preheat signal ●●
Auto oven shut-off w/override ●●
Electronic clock and kitchen timer ●●
Control lock capability ●
Oven light pad ●●

Oven racks 2 2
Broiler pan with grid ●●
Electronic pilotless ignition ●●

Appearance

WW

Color appearance* BB BB

White Glass

Frameless oven door Black Glass Black Glass
Oven door with window ●●
Designer-style handle ●●

Weights & Dimensions

Approx. shipping weight (lbs.) 144 139
Oven cabinet width required (in inches) 24 24
Overall dimensions

(WxHxD in inches)

23-3/4 x 38-3/8 x 23

Overall oven interior dimensions
(WxHxD in inches)

17 x 15 x 18-7/8

Power/Ratings

Gas oven electrical rating 120V, 60Hz, 5A 120V, 60Hz, 15A

14.5 - Oven

Oven /broiler burners (000’s BTU’s) 13.0 - Broil 14.5

*WW = White on white, BB = Black on black.
Factory set for natural gas.

GE

Built-In Gas Oven Dimensions (in inches)

Installation Information: Before

installing, consult installation
instructions packed with product
for current dimensional data.

38

22-3/16

7-1/2

22" MIN.
28" MAX.

24

38-3/8

23-3/4

23

14-1/2" MIN.
20-1/2" MAX.

120V
Conv.
outlet

Gas
connection

Power Cord
48" long

2-1/2" MIN.

23-5/8

24 min.

C

L

2 x 4 or
equivalent
runners

11"

over centerline

of cabinet

(Must support 275 lbs.)

56

30" and 27" Warming Drawers

JTD915SF JKD915SF

JTD915WF JKD915WF

JTD915CF JKD915CF
JTD915BF JKD915BF

Features

Temperature control ●●

Proof (80°F) ●●
Low (140°F) ●●
Medium (170°F) ●●
High (210°F) ●●

Humidity control Crisp/Moist Crisp/Moist
Hidden control ●●
ON/OFF switch ●●
“ON” indicator light ●●
Half rack ●●
Full extension drawer glide ●●
Removable stainless steel pan ●●

Appearance

SS SS

WW WW

CC CC

Color appearance* BB BB

Stainless Steel

Stainless Steel

White glass White glass

Bisque glass Bisque glass

Frameless drawer front Black glass Black glass

Stainless-look

Stainless-look

White

White

Bisque Bisque

Sculptured handle Black Black

Weights & Dimensions

Interior dimensions (WxHxD in inches) 23-7/8 x 6-1/4 x 22-1/16 20-7/8 x 6-1/4 x 22-1/16
Cutout dimensions (WxHxD in inches) 28-1/2 x 9-1/4 x 23-1/2 25-1/2 x 9-1/4 x 23-1/2
Approx. shipping weight (lbs.) 65 59

Power/Ratings

KW rating @ 120V .45 .45
Amps @ 120V 15 15
Element wattage 450 450

Accessories

1/4" panel kit capability ZXD30B ZXD27B
Pan set (2 pans with lids) JXPN2 JXPN2

*SS = Stainless Steel, WW = White on white, CC = Bisque on bisque, BB = Black on black.

30" Warming Drawers 27" Warming Drawers

GE Profile

™

Optional Accessory: Pan Set For Warming Drawer – JXPN2

2x4 or 2x2

runners or Solid

Bottom

Install
2x4 or 2x2
Anti-Tip
Block 9"
From Floor
to Bottom
of Block

9

(Must Support 150 lbs.)

Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.

R

Listed by
Underwriters
Laboratories

A

9-1/4

Locate
electrical
outlet in
adjacent
cabinet
16" from
left side
or 42"
from right
side.

B

10-1/2

24"
recommended
from floor
for under
countertop
installation

23-1/4

23-1/2" Min.

Inside

A

9-1/4

Locate electrical
outlet in adjacent
cabinet no further
than 16" from
left side or 42"
from right side.

B

10-1/2

23-1/4

23-1/2" min.

inside

1" Min.
above
toekick
or adjust
to oven
installation
height

2" min.
between
cutouts

Warming Drawer Dimensions (in inches)

Under Oven Installation (in inches) Undercounter Installation (in inches)

Electrical
outlet 16" max.
from left side

23-1/2" min.

25

1-1/2" Cabinet top

36"
Countertop
height

2" Min. *

A

9-1/4

Electrical outlet 42" max.
from right side.

Electrical outlet
flush with side
of cabinet 7" max.

9

Install
2x4 or 2x2
anti-tip block
against rear
cabinet wall
9" from floor
to bottom
of block

7

Note: When installing warming drawer
with a cooktop, allow a 2" minimum from
cooktop burner box bottom to top of cutout.

AB

30" Models 28-1/2 30
27" Models 25-1/2 26-3/4

Dimensions (in inches)

AB

30" Models 28-1/2 30
27" Models 25-1/2 26-3/4

Dimensions (in inches)

57

GEAppliances.com

Built-In CleanDesign Cooktops

JP350SC

JP969SH JP961SH JP960SC JP939SH JP931SH JP930SC JP350TC

JP969WH JP961TH JP960TC JP939WH JP931TH JP930TC JP350WC JP340WC

JP969CH JP961KH JP960KC JP939CH JP931KH JP930KC JP350KC JP340CC
JP969BH JP961BH JP960BC JP939BH JP931BH JP930BC JP350BC JP340BC

Features

Patterned Black

Patterned Black

Patterned Black Patterned Black Patterned Black Patterned Black Patterned Black True White

Patterned White T

rue White True White Patterned White True White True White Patterned White Patterned White

Patterned Bisque True Bisque True Bisque Patterned Bisque True Bisque True Bisque True Bisque Patterned Bisque

Ceramic-glass surface Patterned Black Patterned Black Patterned Black Patterned Black Patterned Black Patterned Black Patterned Black Patterned Black
Number of elements 5 Ribbon 5 Ribbon 5 Ribbon 4 Ribbon 4 Ribbon 4 Ribbon 4 Ribbon 4 Ribbon
Dual 6"/9" heating elements 1 Ribbon (2500W) 1 Ribbon (2500W) 1 Ribbon (2500W) 1 Ribbon (2500W) 1 Ribbon (2500W) 1 Ribbon (2500W) 1 Ribbon (2500W)
Dual 5"/8" heating elements 1 Ribbon (2200W) 1 Ribbon (2200W) 1 Ribbon (2200W) 1 Ribbon (1900W)
8" heating elements 1 Ribbon (2000W) 2 Ribbon (2000W) 2 Ribbon (2000W)

1 Ribbon w/Warmer

7" heating element (1500W) 1 Ribbon (1500W) 1 Ribbon (1500W) 1 Ribbon (1500W)
7" heating elements 2 Ribbon (1800W) 2 Ribbon (1800W)

Bridge element 1 Ribbon (800W) 1 Ribbon (800W)

Total wattage 4400W 4400W
6" heating elements 2 Ribbon (1200W) 2 Ribbon (1200W) 1 Ribbon (1200W) 1 Ribbon (1200W) 1 Ribbon (1200W) 1 Ribbon (1200W) 1 Ribbon (1200W) 2 Ribbon (1200W)
Hot surface indicator lights 5 5 5 4 4 4 4 1
Precise Digital Control System™ ●●

Pan presence sensor ●●

Pan size sensor ●●

Kitchen timer ●●

Control lock capability ●●

Appearance

SS

SS SS SS SS SS SS WW

WW

WW WW WW

WW WW WW WW

CC CC CC CC CC CC CC CC

Color appearance* BB BB BB BB BB BB BB BB
Frameless ●●●●●●●●

Weights & Dimensions

Cooktop width (in inches) 36 36 36 30 30 30 30 30
Approx. shipping weight (lbs.) 45 44 44 38 38 38 38 35

Power/Ratings

KW rating @ 240V 8.6 9.6 9.6 7.4 7.6 8.1 7.7 6.4

208V 6.5 7.2 7.2 5.6 5.7 6.1 5.8 4.8

Amps @ 240V 36 40 40 31 32 40 40 30

208V 31 40 40 27 27 30 30 30

*SS = Stainless Steel, WW = White on white, CC = Bisque on bisque, BB = Black on black.

Counter Installation Dimensions
(in inches)

Electrical junction
box 16" MIN.
below countertop

30" MIN. to
unprotected
cabinet

Cut should not interfere
with cabinet structure
at front

1-3/4" MIN.

clearance to

side wall

from cut-out

1-1/2" MIN.

clearance to

side wall

from cut-out

18" MIN.
to cabinet

1-3/4" to
rear wall

13" MAX.
depth

H

Cooktop

G

Required

E

F

W

D

To Edge
of Front
Counter

Overall Cutout (Min.)

Model W D H E F G
JP969WH/CH/BH 36 20-3/8 3-1/4* 33-7/8 19-1/8 2-1/2
JP961TH/KH/BH 36 20-3/8 3-1/4* 33-7/8 19-1/8 2-1/2
JP960TC/KC/BC 36 20-3/8 3-1/4* 33-7/8 19-1/8 2-1/2
JP939WH/CH/BH 29-3/4 20-7/8 3-1/4* 28-1/2 19-5/8 2-1/2
JP931TH/KH/BH 29-3/4 20-7/8 3-1/4* 28-1/2 19-5/8 2-1/2
JP930TC/KC/BC 29-3/4 20-7/8 3-1/4* 28-1/2 19-5/8 2-1/2
JP350TC/WC/KC/BC 29-3/4 20-7/8 3-1/4* 28-1/2 19-5/8 2-1/2
JP340WC/CC/BC 29-3/4 20-7/8 3-1/4* 28-1/2 19-5/8 2-1/2

*Depth of unit at conduit connection location (rear) is 6-1/4" on models JP969/939

and 4-5/8" on models JP961/960/931/930/350/340.

Cooktop Dimensions (in inches)

To Edge
of Front
Counter

Overall Cutout (Min.)

Model W D H E F G
JP969SH 36-1/8 21 3-1/4* 33-7/8 19-1/8 2-1/2
JP961SH 36-1/8 21 3-1/4* 33-7/8 19-1/8 2-1/2
JP960SC 36-1/8 21 3-1/4* 33-7/8 19-1/8 2-1/2
JP939SH 29-7/8 21-1/2 3-1/4* 28-1/2 19-5/8 2-1/2
JP931SH 29-7/8 21-1/2 3-1/4* 28-1/2 19-5/8 2-1/2
JP930SC 29-7/8 21-1/2 3-1/4* 28-1/2 19-5/8 2-1/2
JP350SC 29-7/8 21-1/2 3-1/4* 28-1/2 19-5/8 2-1/2

*Depth of unit at conduit connection location (rear) is 6-1/4" on models JP969/939

and 4-5/8" on models JP961/960/931/930/350.

Stainless Steel Cooktop Dimensions (in inches)

Cooktop Dimensions (in inches)

GE Profile GE

®

Filler Trim Kit

When replacing an old GE 30" cooktop (with larger
opening) with Models JP939/931/930/350/340, use the
following one-piece trim kit to fill in the over-size hole.
Available at additional cost.
JXTR31W (True White)
JXTR31C (True Bisque)
JXTR31B (Black—use with black glass cooktops with
a white, bisque or black pattern)

Flush Mount Installation Kit

Accommodates both 30" and 36" installations. Not for
use with stainless steel models.

JXFLMTW (True White)
JXFLMCC (True Bisque)
JXFLMBB (Black—use with black glass cooktops with
a white, bisque or black pattern)

Optional Accessory

ZX375GRD Universal Griddle is non-stick and fits all
electric smooth top ranges, cooktops, electric bridge
elements and gas ranges.

Installation Information:

Before installing, consult installation instructions packed
with product for current dimensional data.

Built-In CleanDesign Cooktops

Requires a 5" free area between the bottom of the cooktop to any combustible
material, i.e., shelving. Free area not required when installing wall oven
underneath cooktop. Refer to installation instructions. Requires an 18"
minimum from cooktop to adjacent overhead cabinets. Units are furnished
with a 48" flexible armored cable.

36" Ribbon cooktops (excluding JP960) are approved for use over GE 30" Single
Wall Ovens and Warming Drawers. 30" Ribbon cooktops are approved for use
over GE 30" Single Wall Ovens and Warming Drawers. Refer to cooktop and wall
oven installation instructions packed with product for current dimensional data.

Notes: If installing with a GE Profile Telescopic
Downdraft System, consult both cooktop and
downdraft installation instructions packed with
product before installing. Cooktop gas/electric supply
may need to be re-routed to install downdraft.

The countertop must be at least 26" deep with a flat
surface area of 23-1/2" or more, front to back.
JGP939S, JGP930S, JP350S and JGP932S require
23-5/8" flat surface area. In addition, other clearances
to the front edge of the countertop must be considered.

Note: Consult cabinet and countertop manufacturer’s
specs for flush mount installation prior to install.

58

Electrical junction box 12" MIN.
below countertop

30" MIN. to
unprotected
cabinet

Cut should
not interfere
with cabinet
structure at front

L MIN.

clearance to

side wall

from cut-out

R MIN.

clearance to

side wall

from cut-out

18" MIN.
to cabinet

C to

rear wall

13" MAX.
depth

Built-In Electric Cooktops

JP328SF

JP328WF
JP626WF JP328CF
JP626CF JP328BF JP201CB JP202D

Features

Stainless Steel
Porcelain-Enameled
Porcelain-Enameled

Cooktop surface Porcelain-Enameled Porcelain-Enameled Stainless Steel Porcelain-Enameled
Lift-up cooktop with support rod ●●
8" heating elements 2 Plug-In 2 Plug-In 1 Plug-In 1 Plug-In
6" heating elements 2 Plug-In 2 Plug-In 1 Plug-In 1 Plug-In
One-piece removable

chrome drip bowls ●●●●
Infinite heat rotary controls ●●●●
Control panel location Upfront Upfront Upfront Upfront

Black Glass
White Glass

White Glass Bisque Glass

Control panel Bisque Glass Black Glass
Surface element “ON” indicator light ●●●●

Appearance

SS

WW

WW

CC

Color appearance* CC BB SS WW

Weights & Dimensions

Cooktop width (in inches) 35-1/2 30-1/4 21-1/4 21-1/4
Approx. shipping weight (lbs.) 38 36 18 18

Power/Ratings

KW rating @ 240V 7.4 7.4 3.4 3.4

208V 5.6 5.6 2.5 2.5

Amps @ 240V 40 40 20 20

208V 30 30 20 20

*SS = Stainless Steel, WW = White on white, CC = Bisque on bisque, BB = Black on black.

To Edge

Minimum Spacing of Front

To Nearest Counter

Overall Cutout Combustible Wall (Min.)

Model W D A B C R L F
JP626 35-1/2 21 33-7/8 19-1/8 2-1/2 3-3/4 3-3/4 2-1/2
JP328 30-1/4 21-1/4 28-1/2 19-1/2 1-3/4 2 5-1/2 2-1/2
JP202 21-1/4 16-5/8 20-1/8 16-1/8 2 2 2 2-3/4
JP201 21-1/4 16-5/8 20-1/8 16-1/8 2 2 2 2-3/4

Counter Installation Dimensions (in inches)

Filler Trim Kit—When replacing an old GE 30" cooktop

(with larger opening) with Models JP328WF, JP328CF,
JP328BF, JP328SF, use the following one-piece trim kits
to fill in the over-size hole. Available at additional cost.
JXTR31W (White)
JXTR31C (Bisque)
JXTR31B (Black)

Installation Information:

Before installing, consult installation instructions
packed with product for current dimensional data.

Dimensions (in inches)

Built-In Electric Cooktops

Required free area between the bottom of the cooktop
and any combustible material, i.e., shelving is 5"
minimum on models JP626/328 and 1-1/2" minimum
on models JP201/202. Free area not required when
installing wall oven underneath. Requires an 18"
minimum from cooktop to adjacent overhead cabinets.
Units are furnished with a 48" flexible armored cable.

Cooktop model JP328 is approved for use over select
GE 27" or 30" Single Wall Ovens. JP626 is approved
for use over GE 30" Single Wall Ovens only. Refer to
cooktop and wall oven installation instructions packed
with product for current dimensional data.

Cooktop models JP201CB and JP202D are approved for
use over GE undersink dishwasher model GSM2100.
Refer to cooktop installation instructions packed with
product for current dimensional data.

Built-In Cooktop Dimensions (in inches)

GE

®

Cooktop

F

(min.)

A

B

W

D

H

Note: The countertop must be at least 26" deep with
a flat surface area of 23-1/2" or more, front to back.
In addition, other clearances to the front edge of the
countertop must be considered.

Note: If installing with a GE Profile Telescopic
Downdraft System, consult both cooktop and
downdraft installation instructions packed with
product before installing. Cooktop gas/electric supply
may need to be re-routed to install downdraft.

59

GEAppliances.com

Built-In Electric Downdraft Cooktops

JP989TD

JP989SD JP989KD JP989BD

Features

Downdraft exhaust (CFM) 400 400 400
Three-speed downdraft

vent fan ●●●

T

rue White

Ceramic-glass surface Black True Bisque Black
Number of elements 4 4 4
Dual 6"/9" heating elements 1 Ribbon (2500W) 1 Ribbon (2500W) 1 Ribbon (2500W)
7" heating elements 2 Ribbon (1800W) 2 Ribbon (1800W) 2 Ribbon (1800W)

Bridge element 1 Ribbon (800W) 1 Ribbon (800W) 1 Ribbon (800W)
Total wattage 4400W 4400W 4400W

6" heating elements 1 Ribbon (1500W) 1 Ribbon (1500W) 1 Ribbon (1500W)
Infinite heat controls ●●●
Hot surface indicator lights 4 4 4
Heating element “ON”

indicator light ●●●

Appearance

WW

Color appearance* SS CC BB
Frameless ●●●

Weights & Dimensions

Cooktop width (in inches) 30 30 30
Overall dimensions

(WxD in inches)

29-7/8 x 21-7/8

Approx. shipping weight (lbs.) 72 72 72

Power/Ratings

KW Rating @ 240V 8.8 8.8 8.8

208V 6.7 6.7 6.7

Amps @ 240V 40 40 40

208V 40 40 40

*SS = Stainless steel, WW = White on white, CC = Bisque on bisque, BB = Black on black.

GE Profile

™

Built-In Gas Downdraft Cooktops

GE Profile

25

1-7/8"

MIN. Required*

20-5/8

28-7/8

*U.L. Requirement.

Built-In Electric and Gas Cutout Dimensions (in inches)

Note: These cooktops

are approved for
indoor use only.

Note: A 5" minimum spacing to adjacent side wall is required on JGP989.

A 6" minimum spacing to adjacent side wall is required on JP989.

Built-In Electric and Gas Downdraft Cooktops Dimensions (in inches)

Receptacle Location

Install an approved junction box within shaded area
shown in diagram. Junction box must be at least
10-1/2" below top of cabinet.

Preparing the Cabinet for Installation

In some cabinets, the sides may need to be scooped

or cut down 5-3/4" as shown (right) and the corner

braces removed in order to accommodate the cooktop.

Built-In Electric and Gas Cabinet Dimensions (in inches)

21-7/8

6

21-7/8

6"

Dia.

20-1/2

28-3/4

29-7/8

6

20

9

4

10-1/2

16

C
L

5-3/4"

Approx.

5-3/4" Approx. for
European cabinets

JGP989TC JGP989KC JGP989BC

Features

Cooktop burners Sealed Sealed Sealed
Electronic pilotless ignition ●●●
Ceramic-glass surface True White True Bisque Black
Burner grates 2 2 2
Downdraft exhaust (CFM) 400 400 400

Appearance

Color appearance* WW CC BB
Frameless ●●●

Weights & Dimensions

Cooktop width (in inches) 30 30 30
Overall dimensions

(WxD in inches)

29-7/8 x 21-7/8

Approx. shipping weight (lbs.) 90 90 90

Power/Ratings

Gas cooktop electrical rating 120V 120V 120V
Burners (000’s/BTU’s)** (2) 9.1/8.5 (2) 9.1/8.5 (2) 9.1/8.5

Natural Gas/LP Gas (1) 11.5/11.0 (1) 5.5/5.5 (1) 11.5/11.0 (1) 5.5/5.5 (1) 11.5/11.0 (1) 5.5/5.5
*WW = White on white, CC = Bisque on bisque, BB = Black on black.

**A set of LP orifices is included with each cooktop for LP conversion. Factory set for natural gas.

60

Between the Floor Joists

Through the Cabinet Toe Space

Inside Wall

Through Roof

Direct to Outside

Straight Duct

Note: Ductwork must be vented to outside. Do not vent into a wall, ceiling, crawl space, attic or any concealed
space. Always use an appropriate roof or wall cap with damper.

Laundry-type wall caps should never be

used.

For maximum efficiency use the shortest and straightest duct run possible, with as few fittings as
possible. For satisfactory performance the duct run should not exceed 100 feet equivalent length. Refer
to the table of equivalent lengths (shown in installation instructions) for various duct configurations.

Built-In Electric and Gas Downward Venting (in inches) Built-In Electric and Gas Rear Wall Venting (in inches)

9-1/8

18-3/4

10-1/8

6-1/8

in inches)

Installing the Ductwork
Use galvanized or aluminum duct in 6" round or 3-1/4" x 10" size, or combination of both. PVC duct or
locally approved piping should be used if installing under a poured concrete slab.

Local building code

must be followed in specifying type and schedule of all duct used.

Built-In Electric and Gas Downdraft Cooktop Venting Options

Wall Installation

Wall installations require 25" countertop depth. When cabinet is flush against the
wall, the fan housing can be rotated to the horizontal position for direct venting
through rear wall. Make a countertop cutout in the range cabinet according to
unit dimensions and installation type. Duct hole is positioned in back of cabinet
for through-the-wall ducting. Requires special offset adapter JXRW89.

Peninsula or Island Installation

For peninsula/islands a minimum 26" countertop depth is suggested. Blower
should be in vertical position. Island or peninsula cabinets may require
adjustment in cutout depth and/or location within the width dimensions. Duct
hole is positioned in bottom of cabinet for island or peninsula installation.

Slab Installation
For peninsula or island installation and rear wall ducting, 6" PVC duct or locally

approved piping should be used if installing under a poured concrete slab.

Note:

Electrical cable is not supplied with unit

JXRW89 Rear Wall Installation Kit

Optional accessories may be ordered for installation on rear wall.

JXCK89 Electrical Connection Kit

Optional accessory kit for JP989 electric downdraft cooktop only,
includes junction box and conduit.

Installation Information: Before installing, consult installation instructions
packed with product for current dimensional data.

Built-In Electric and Gas Downdraft Cooktops (continued)

61

GEAppliances.com

Minimum Spacing To Edge

To Nearest of Front

Overall Cutout Combustible Wall Counter
Model W D H A B C L R F
JGP963 36 21 3-3/16 33-7/8 19 -1/8 2 -1/4 3-3/4 3-3/4 2-1/2
JGP933 30 21 3-3/16 28 -1/2 19-5/8 2 -1/4 3-3/4 3-3/4 2-1/2
JGP962 36 20-7/16 3-1/16 33 -7/8 19 -1/8 2 -1/4 3-3/4 3-3/4 2-1/2
JGP932 29-3/4 21 3-3/16 28 -1/2 19 -5/8 2 -1/4 3-3/4 3-3/4 2-1/2
JGP960 36 21 3-1/16 33-7/8 19 -1/8 2 -1/4 3-3/4 3-3/4 2-1/2
JGP636 36 21 3-1/16 33-7/8 19 -1/8 2 -1/4 3-3/4 3-3/4 2-1/2
JGP628 36 21 3-3/16 33-7/8 19 -1/8 2 -1/4 3-3/4 3-3/4 2-1/2
JGP930 30 21 2-1/2 28 -1/2 19 -5/8 2 -1/4 3-3/4 3-3/4 2-1/2
JGP336 30 21 2-1/2 28 -1/2 19 -5/8 2 -1/4 3-3/4 3-3/4 2-1/2
JGP328 30 21 3-3/16 28-1/2 19 -5/8 2 -1/4 3-3/4 3-3/4 2-1/2
JGP326 30 21 2-1/2 28 -1/2 19-5/8 2 -1/4 3-3/4 3-3/4 2-1/2
JGP320 30 -1/4 21-1/4 3-9/32 28 -1/2 19 -5/8 1-3/4 3 3 3 -1/4

*Allow 5-3/4" depth at rear for electrical and gas connections.

Built-In Gas Cooktops

Cooktop Dimensions (in inches) Counter Installation Dimensions (in inches)

Dimensions (in inches)

Installation Information: Before installing, consult installation

instructions packed with product for current dimensional data.

Installation With Single Wall Oven Information:

30" Gas Cooktops are approved for use over GE 27" Wall Ovens. 36" and 30" Gas Cooktops are
approved for use over 30" Wall Ovens. Refer to cooktop and wall oven installation instructions
packed with product for current dimensional data.

Optional Gas Range Wok Accessory (Available at additional cost)
JXWK = Wok accessory holder sits on top of maximum burner grate to hold a

round-bottom wok.

For use with JGP960/930/636/336 models only.
JXWK2 = Wok accessory holder sits on top of maximum burner grate to hold a

round-bottom wok.

For use with JGP963/933/962/932 models only.

Note: All gas cooktop models require 7/16" free area below cooktop height to
combustible material. 0" clearance is required between left and right sides of cooktop
below countertop. Requires 18" minimum from countertop to adjacent overhead cabinets.*
*AGA requirement.

Electrical
cord

Electrical
outlet

Shut-off

valve

Pressure
regulator

1/2" pipe

Coupling

Electrical
cord

45°

Electrical
outlet

Shut-off

valve

Pressure
regulator

1/2" pipe
Coupling

Gas Connection
Models JGP963/962/636/628

Gas Connection
Models JGP933/932/336/328/326/320

Note: If installing with a GE Profile Telescopic Downdraft System, consult both cooktop

and downdraft installation instructions packed with product before installing. Cooktop
gas/electric supply may need to be re-routed to install downdraft.

JGP963SEF JGP962SEC JGP933SEF JGP932SEC

JGP963WEC

JGP962TEC JGP933WEC JGP932TEC JGP636WED JGP336WED JGP628WEC JGP328WEC JGP326WEF
JGP963CEC JGP962KED JGP933CEC JGP932KED JGP636CED JGP336CED JGP628CEC JGP328CEC JGP326CEF
JGP963BEC JGP962BEC JGP933BEC JGP932BEC JGP960SED JGP636BED JGP930SED JGP336BED JGP628BEC JGP328BEC JGP326BEF JGP320EV

Features

Cooktop burners 5 Sealed 5 Sealed 4 Sealed 4 Sealed 5 Sealed 5 Sealed 4 Sealed 4 Sealed 4 Sealed 4 Sealed 4 Sealed 4 Standard
Power Boil burner ●●●●
High Output burner ●●●●
Precise Simmer burner(s) 2 2 ●● 22●●●●●
Electronic pilotless ignition ●●●●●●●●●●●●

Stainless Stainless Tempered Tempered Tempered Tempered Porcelain- Porcelain- Porcelain- Porcelain-

Cooktop surface Porcelain Ceramic-Glass Porcelain Ceramic-Glass Glass Glass Glass Glass Enameled Enameled Enameled Enameled

Continuous Continuous Continuous Continuous

Cooktop grates Deluxe Cast Deluxe Cast Deluxe Cast Deluxe Cast Deluxe Cast Deluxe Cast Deluxe Cast Deluxe Cast Continuous Continuous Medium Cast Standard Steel
One-piece drip pans Porc.-Enam. Porc.-Enam. Porc.-Enam. Porc.-Enam. Porc.-Enam. Porc.-Enam. Porc.-Enam. Chrome

Stainless

Stainless Stainless

Stainless

White True White

White True White White White White White White

Bisque True Bisque

Bisque True Bisque Bisque Bisque Bisque Bisque Bisque

Control panel Black Black Black Black Black Black Black Black Black Black Black White/Black
Controls Upfront Upfront Right Side Right Side Upfront Upfront Right Side Right Side Upfront Right Side Right Side Right Side

Appearance

SS SS

SS SS

WW WW WW WW WW WW WW WW WW

CC CC CC CC CC CC CC CC CC

Color appearance* BB BB BB BB SS BB SS BB BB BB BB WH/BL

Weight & Dimensions

Cooktop width (in inches) 36 36 30 30 36 36 30 30 36 30 30 30
Approx. shipping weight (lbs.) 54 59 44 49 38 38 30 30 51 44 44 31

Power/Ratings

Gas cooktop electrical rating 120V, 60Hz, 5A

(1) 15.0/14.0 (1) 15.0/14.0 (1) 15.0/14.0 (1) 15.0/14.0
(1) 11.0/10.0 (1) 11.0/10.0 (1) 11.0/10.0 (1) 11.0/10.0 (1) 12.0/9.4 (1) 12.0/9.4 (1) 12.0/9.4 (1) 12.0/9.4

Burners Nat. Gas/ (1) 9.1/8.1 (1) 9.1/8.1 (1) 9.1/8.1 (1) 9.1/8.1 (2) 9.5/7.0 (2) 9.5/7.0 (2) 9.5/7.0 (2) 9.5/7.0 (3) 9.1/8.1 (3) 9.1/8.1 (3) 9.1/8.1
(000’s/BTU’s): LP Gas

†

(2) 6.0/6.0 (2) 6.0/6.0 (1) 6.0/6.0 (1) 6.0/6.0 (2) 5.0/4.0 (2) 5.0/4.0 (1) 5.0/4.0 (1) 5.0/4.0 (1) 6.0/6.0 (1) 6.0/6.0 (1) 6.0/6.0 (4) 9.1/8.0

*SS = Stainless Steel, WW = White on white, CC = Bisque on bisque, BB = Black on black, WH = White, BL = Black.

†

A set of LP orifices is included with each cooktop for LP conversion. Factory set for natural gas.

GE

®

GE Profile

™

W

Cooktop

D

H

B

A

F

(min.)

13" MAX.
depth

30" MIN. to
unprotected
cabinet

C to

rear wall

L MIN.

clearance to

side wall

from cut-out

Electrical junction box 12" MIN.
below countertop

18" MIN.

to cabinet

R MIN.

clearance to

side wall

from cut-out

Cut should
not interfere
with cabinet
structure at front

62

Select-Top™Modular Downdraft Cooktops

JP389WD

JP389BD

Features

Configuration Dual Modular

White Por

c.-Enam.

Cooktop finish Black Porc.-Enam.
Infinite heat controls Rotary
Heating element “ON” indicator light ●
Downdraft exhaust (CFM) 400
Single-speed downdraft vent fan
Three-speed downdraft vent fan ●

Appearance

WW

Color appearance* BB

Weights & Dimensions

Cooktop width (in inches) 30
Approx. shipping weight (lbs.) 72

Power/Ratings

Amps @ 240V 40
KW rating @ 240V 8.0

Accessories

Ribbon heating elements JXDR50VW
(one 8" and one 6") JXDR50VB

Coil heating elements
(one 6", one 8" element with JXDC44RWH
removable one-piece bowls) JXDC43RBL

Grill Module

†

JXDL44N

Griddle Accessory JXDD44R

JXDM3

Grill Cover JXDM2

*WW = White on white, BB = Black on black.

†

Grill Module includes coil heating element, one-piece grill grate, and
porcelain reflector pan.

Dual Modular

Cooktop Options

GE lets you customize your cooktop with flexible modules to suit your taste. These optional
versatile modules—

Grill, Coil, Ribbon, Griddle Opening Accessory and Grill Cover—are available

at additional cost.

Simply plug the modules you want into either side of the cooktop (single modular

cooktops accept modules on left side only) and unplug them for easy cleaning and storage.

Grill Module, JXDL44N

Includes front/rear controlled heating element, one-piece grill grate,
and porcelain-enameled reflector pan.

Griddle Accessory, JXDD44R (Use with optional Grill Module.)

Place over heating element and reflector pan from optional grill module.
Griddle accessory has a non-stick coating and is self-draining.

Ribbon Modules

Patterned glass top with one 8" and one 6" ribbon heating element
JXDR50VW—White on white, JXDR50VB—Black on black

Coil Modules

One 8" and one 6" plug-in heating element with one-piece bowls
JXDC43RBL—Black porcelain-enameled, JXDC44RWH—White porcelain-enameled

JXCK89 Electrical Connection Kit

Optional accessory kit for JP389 downdraft cooktop only, includes junction box and conduit.

Wall Installation

Wall installations require 25" countertop depth. When cabinet is flush against the wall, the fan
housing can be rotated to the horizontal position for direct venting through rear wall. Make a
countertop cutout that is centered in the range cabinet according to unit dimensions and
installation type. Duct hole is positioned in back of cabinet for through-the-wall ducting.

Peninsula or Island Installation

For peninsula/islands a minimum 26" countertop depth is suggested. Blower should be in
vertical position. Island or peninsula cabinets may require adjustment in cutout depth and/or
location within the width dimensions. Duct hole is positioned in bottom of cabinet for island
or peninsula installation.

Slab Installation

For peninsula or island installation and rear wall ducting, PVC duct or locally approved
piping should be used if installing under a poured concrete slab.

25

1-7/8"

MIN. Required*

20-5/8

28-7/8

*U.L. Requirement.
Note: A 6" minimum spacing to adjacent side wall is required

Cutout Dimensions (in inches)

Note: These cooktops are U.L. approved for

indoor use only. Model JP380BV is
U.L. approved for outdoor use only.

GE

®

Built-In Downdraft Cooktops Dimensions (in inches)

Receptacle Location

Install an approved junction box
within shaded area shown in
diagram. Junction box must be at
least 10-1/2" below top of cabinet.

Preparing the Cabinet for
Installation

In some cabinets, the sides may
need to be scooped or cut down
2" as shown (right) and the corner
braces removed in order to
accommodate the cooktop.

Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.

Cabinet Dimensions (in inches)

21-9/16

3

19

6"

Dia.

20-1/2

28-7/8

27-1/2

29-7/8

12-1/4

6

20

9

4

10-1/2

16

C
L

2" Approx.

5" Approx.

for European

cabinets

63

GEAppliances.com

Between the Floor Joists

Through the Cabinet Toe Space

Venting Options

Inside Wall

Through Roof

Direct to Outside

Straight Duct

Installing the Ductwork

Use minimum 26-gauge galvanized or 24-gauge aluminum duct in 6" round
or 3-1/4" x 10" size, or combination of both.

PVC duct or locally approved

piping should be used if installing under a poured concrete slab.

Note:

Ductwork must be vented to outside. Do not vent into a wall, ceiling, crawl space, attic or any concealed

space. Always use an appropriate roof or wall cap with damper.

Laundry-type wall caps should never be

used.

For maximum efficiency use the shortest and straightest duct run possible, with as few fittings as
possible. For satisfactory performance the duct run should not exceed 100 feet equivalent length. Refer
to the table of equivalent lengths (shown in Pub. No. 49-8552) for various duct configurations.

Downward Venting (in inches) Rear Wall Venting (in inches)

9-3/8

15-3/4

Rear wall

(in inc

9-3/8

7-9/16

ownward venting

(in inches)

Built-In Downdraft Gas Modular Cooktops

Installation Information (in inches)

Tie down bolt

on each end

Select appropriate
duct cutout
(see ducting installation instructions.)

Pressure regulator

Wiring box cover
Grease
container

9-3/8

29

21

1-7/8"
Min.

15/16"

Min. clearance

Blower assembly
clearance 15-5/8"

2" minimum
clearance
required
between
cooktop
and each
side wall

Blower can be swiveled 90°

13

7-9/16

30

21-3/4

Grill and griddle feature Excalibur®non-stick finish.
Installation Information: Before installing, consult installation

instructions packed with product for current dimensional data.

Optional Modules (Available at additional cost)
Two-Burner Gas Module

(sealed burners)—
JXGB79W—White on white
JXGB79B—Black on black

Grill Cover—
JXGC89W—White on white
JXGC89B—Black on black

Gas Grill Module—JXGG79
Griddle—JXGL79
(use with optional
Grill module)

JGP979SEF

JGP979WEF

JGP979BEF

Features

Configuration Single modular

Stainless steel

Porcelain

Cooktop surface Porcelain

Black porcelain-coated

Cooktop grates cast iron
Accepts modules Left side
Gas cooktop burner module (right side) 2 Sealed
Electronic pilotless ignition ●
Downdraft vent fan ●
Downdraft exhaust (CFM) 375

Appearance

Stainless steel

White on white

Color appearance Black on black
Upfront controls ●

Weight & Dimensions

Cooktop width (in inches) 30
Overall dimensions (W x D in inches) 30 x 21-3/4
Approx. shipping weight (lbs.) 76

Power/Ratings

Gas cooktop electrical rating 120V, 60Hz, 15A
BTU’s (000’s) Right side (burners) 10.0
Natural gas* Grill Unit 8.0

*JGP979 cooktop is factory set for natural gas. It is not LP convertible.
Note: Shipped with sealed gas burner module, right side. Left side

accepts optional modules that must be ordered and are available at
additional cost.

GE Profile

™

Venting Options

64

30" Slide-In Electric Ranges

Installation Information: Before installing,
consult installation instructions packed
with product for current dimensional data.

GE Profile

™

GE

®

All GE ranges are equipped
with an Anti-Tip device.
The installation of this
device is an important,
required step in the
installation of the range.

JS968SF
JS968TF

JSP47WF JSP34WD
JS968KF JSP47CF JSP34CD JSS26BD
JS968BF JSP47BF JSP34BD JSP26BD JSS16PD

Features

Self-clean oven w/Delay clean option ●●●●Standard Clean
Light self-clean option ●●
Variable cleaning time ●●●●
Automatic self-clean oven door lock ●●●●
Oven racks 3 Heavy-Duty 2 2 2 2
CleanDesign oven interior/hidden bake ●
TrueTemp™ system ●●
Variable broil/Six-pass broil element ●●

Patterned Black

True White

Patterned White

True Bisque

Patterned Bisque

Ceramic-glass cooktop Patterned Black Patterned Black
Overhanging cooktop ●●●●●
Dual 6"/9" heating element 1 Ribbon (2500W) 1 Ribbon (2500W)
8" heating elements 2 Ribbon (2000W)
7" heating elements 2 Ribbon (1800W)

Bridge element 1 Ribbon (800W)
Total wattage 4400W

6" heating element 1 Ribbon (1500W) 1 Ribbon (1500W) 2 Plug-In 2 Plug-In 2 Plug-In

Warming zone 1 Ribbon (120W)

Infinite heat controls ●●●●●
Precise Air™ Convection System ●

Convection bake Multi/Single-rack
Convection roast ●
Auto Recipe™ Conversion ●

SmartSet controls Glass touch ●●●

Proof mode ●
Warm mode ●
Oven meat probe ●
Optional closed door broiling ●●
Temperature display ●●●●
Start pad ●●●●
Delay Bake option w/Cook & Hold ●●●●
C° or F° programmable ●●●●
Audible preheat signal ●●●●
Auto oven shut-off w/override ●●●●
Control lock capability ●●●●
Electronic clock/kitchen timer ●●●●●

Hot surface indicator lights 4 4
Heating element “ON” indicator light ●●●●●
Certified Sabbath mode ●●
Interior oven light Halogen ●●●●

Stainless

White White White
Bisque Bisque Bisque Black

Storage drawer Black Black Black CM* CM*
Broiler pan with grid ●●●●●
Roasting rack ●
Convection cookbook ●

Appearance

SS

WW WW WW

CC CC

CC BB

Color appearance* BB BB BB WH/CT WH/CT

Stainless

White White White
Bisque Bisque Bisque Black

Frameless glass oven door* Black Black Black CM* Painted
Oven door with window Big ClearView™ Big ClearView™ ●●●

Sculptured

Stainless-look

Sculptured White Sculptured White

White

Sculptured Bisque Sculptured Bisque Bisque Black

Oven door handle Sculptured Black Sculptured Black Black Black Painted

Weights & Dimensions

Overall oven interior dimensions
(WxHxD in inches) 24 x 16-1/4 x 18-1/8 24 x 17-1/2 x 18-1/4 22-3/4 x 15-3/4 x 17 22-3/4 x 15-3/4 x 17 22-3/4 x 15-3/4 x 17

Approx. shipping weight (lbs.) 205 200 175 175 160

Power/Ratings

KW rating @ 240V 12.1 11.6 10.8 10.8 10.8

208V 9.1 8.7 8.1 8.1 8.1

Amps @ 240V 40 40 40 40 40

208V 40 40 40 40 40
Convection Wattage 2500
Broiler/Bake Wattage 3600/2700 3600/3400 3400/2585 3400/2585 3400/2585

*SS = Stainless steel with black accents, WW = White with white glass door, CC = Bisque with bisque glass door, BB = Black with black glass door, WH = White with black

glass door, CT = Bisque with black glass door, CM = Color-Matched indicates color of drawer matches range cooktop (either white or bisque)

Note: Cabinets installed adjacent to
slide-in electric ranges must have an
adhesion spec of at least a 194°F
temperature rating.

Note: All 30" Slide-In Ranges conform
to U.L. requirements for 0" spacing from
range to adjacent walls below countertop.
To reduce possibility of scorching the side
walls above the countertop when no load
is present on burners, it is recommended
that a minimum 6" spacing from adjacent
side wall be allowed for possible extended
high-heat element operation.

Receptacle Locations: For all 30" Slide-In
Ranges locally approved flexible service
cord or conduit must be used because
terminals are not accessible after range
installation. See shaded area in drawing
for location of electrical outlet box.
Recommended outlet locations allow
range to be installed directly against
rear wall.

R

Listed by
Underwriters
Laboratories

65

GEAppliances.com

30" Slide-In Range Dimensions (in inches)
Models JSP34/26 and JSS26/16

28-1/4*

36

Maintain

at least 6"

distance from

nearest

combustible surface.

Acceptable

Electrical

Outlet Area

45-1/8

2-1/4

5

6

4-1/2

30

30 Min.

15 Min.

6

closed door handle

on model JSP34

28" on models
JSP26/JSS26/16

30

30-3/4

23-3/16

30

If you are NOT using the
optional Filler or Backguard:

30

If you are using the
optional Filler or Backguard:

25

23-3/16

30

If you are NOT using the
optional Filler or Backguard:

30

If you are using the
optional Filler or Backguard:

25

Accessory Backguards

(Attaches to the back of range as a
backguard when unit is installed in
30" free-standing cutout)

JXS37WW—White
JXS37CC—Bisque
JXS37BB—Black/Stainless

Body Sides

(Slide-in ranges are sold without sides
installed. Can be installed on either left or
right when unit has one exposed side [no
cabinet adjacent]. Kit contains 1 body side)

JXS76WW—White
JXS76CC—Bisque
JXS76BB—Black

Vertical Side Trim Kits

(If cabinet cutout width is more than 30",
a vertical side trim kit may be used to close
the gap between the range and cabinet)

JXS86WW—White
JXS86CC—Bisque
JXS86BB—Black

Optional Lower Trim Kits

(If counter height is greater than 36.5",
a lower trim kit is recommended to
extend the useful height to 38" maximum)

JXS56WW—White
JXS56CC—Bisque
JXS56BB—Black

Optional Top Filler Kits

JXS66BB—Black
JXS66CC—Bisque
JXS66WW—White

Optional Kits for Slide-In Electric Ranges
(Models JSP34/26 and JSS26/16)

(Available at additional cost)

Models shown are shipped with rear filler strip kit.
Rear Filler Strip Kit

JXS28—Rear Filler Strip Kit
(Brushed-chrome)

Accessory Backguards

JXS31—White Accessory Backguard
JXS32—

Brushed-Chrome Accessory Backguard
JXS34—Black Accessory Backguard
JXS35—Bisque Accessory Backguard

Endcap Kit

JXS40—Endcap kit to accommodate replacement

where countertop may already be notched.

Lower/Side Trim Kits

(If countertop height is greater than 37", it is
recommended to use a lower trim kit.)

JXS52BB—Lower trim (Black)
JXS53WW—Lower trim (White)
JXS55CC—Lower trim (Bisque)

Pub. No. 3-A040—Vertical Side Trim Kit
(Brushed-Chrome)

Optional Kits for Slide-In Electric Ranges (Models JS968 and JSP47)

(Available at additional cost)

Note: Range may be placed with 0" clearance (flush) at the back wall and side walls
below countertop if the range side trims above the countertop extend beyond the cabinet
fronts at least 1/4" (self-clean models only). Maintain at least 6" distance from nearest
combustible surface.

2-7/8"

To Front

Surface Of

Countertop

20-5/8" Door
Clearance
From Front
Surface of
Countertop

31-1/4

30

27-1/2

4

Accessory
Backguard

30" Slide-In Range Dimensions (in inches)
Models JS968 and JSP47

Acceptable

Electrical

Outlet Area

30" Min.

30" Min.

Shave Raised Edge To Clear
31-1/8" Wide Control Panel

36

6" Min.

From Walls

23-3/16

15" Min.

13" Max.

2-1/2

30

25

9/16

7-1/2

2-1/2

66

30" Slide-In Gas Ranges

Dual-Fuel Gas Gas Gas Gas
J2S968SH

JGS968SH
J2S968TH JGS968TH JGSP48WH JGSP23WEY
J2S968KH

JGS968KH JGSP48CH JGSP23CEY
J2S968BH JGS968BH JGSP48BH JGSP23BEY JGSS05BEH

Features

Self-clean oven
w/Delay clean option ●●● ●Standard-Clean

Light self-clean option ●●●
Variable cleaning time ●●● ●
Automatic self-clean oven door lock ●●● ●
Oven racks 3 Heavy-Duty 3 Heavy-Duty 2 Heavy-Duty 2
CleanDesign oven interior/

hidden bake ●
TrueTemp™ system ●●●

Black Glass Black Glass

True White Glass

True White Glass Patterned White Glass

True Bisque Glass

True Bisque Glass Patterned Bisque Glass White Porc. Enamel Black

Cooktop Black Glass Black Glass Black Glass Black Porc. Enamel Porcelain Enamel
Overhanging cooktop ●●●
Cooktop burners Sealed Sealed Sealed Sealed Sealed

(1) 15,000 BTU/ (1) 15,000 BTU/

Power Boil™ Burner 180° Simmer 180° Simmer

(1) 11,000 BTU/ (1) 11,000 BTU/ (2) 11,000 BTU/

High Output burner (Nat.) 150° Simmer 150° Simmer 150° Simmer

(1) 6,000 BTU/ (1) 6,000 BTU/ (1) 6,000 BTU/

Precise Simmer burner (Nat.) 140° Simmer 140° Simmer 140° Simmer

(1) 9,100 BTU/ (1) 9,100 BTU/ (1) 9,100 BTU/

All-purpose burners (Nat.) 150° Simmer 150° Simmer 150° Simmer

Matte Black Hvy-Cast

Matte Black Hvy-Cast

Grey Hvy-Cast Grey Hvy-Cast Grey

Taupe Hvy-Cast Taupe Hvy-Cast Taupe Grey Standard Cast Black Standard

Cooktop grates Shiny Black Hvy-Cast Shiny Black Hvy-Cast Shiny Black Black Standard Cast Porcelain Steel
Continuous grates ●●●
One-piece drip pans Porc.-Enameled
Ignition system Electronic Electronic Electronic Electronic Electronic
Infinite heat controls ●●
Precise Air™ convection system ●

Convection bake Single-/Multi-Rack ●
Convection roast ●●
Auto Recipe™ conversion ●●

Electronic controls Glass touch Glass touch ●●

Proof mode ●●
Warm mode ●●
Oven Meat probe ●●
Optional closed door broiling ●
Temperature display ●●● ●
Delay Bake option ●●● ●
C° or F° programmable ●●● ●
Audible preheat signal ●●● ●
Auto oven shut-off w/override ●●● ●
Control lock capability ●●●

Electronic clock/kitchen timer ●●● ●
Certified Sabbath mode ●●●
Interior oven light Halogen Halogen ●●●

Stainless Steel Stainless Steel

White White White White

Bisque Bisque Bisque Bisque

Storage drawer Black Black Black Black
Slide-out broiler drawer ●
Broiler pan ●●● ● ●
Roasting rack ●●
Convection cookbook ●

Appearance

Color appearance SS/WW/ CC/ BB SS /WW/ CC/ BB WW /CC/ BB WW /CC /BB BB

Stainless Steel

Stainless Steel

White Glass

White Glass

White Glass White Glass

Bisque Glass Bisque Glass Bisque Glass Bisque Glass

Frameless oven door Black Glass Black Glass Black Glass Black Glass Black Glass
Oven door with window Big ClearView™ Big ClearView Big ClearView ●●
Sculptured oven door handle ●●●

Weights & Dimensions

Overall oven interior dimensions
(WxHxD in inches) 24 x 16-1/4 x 18-1/4 24 x 16-1/4 x 18-1/4 22-3/4 x 13 x 17 22-3/4 x 13 x 17 24 x 17 x 19

Approx. shipping weight (lbs.) 225 220 215 192 165

Power/Ratings

(1) 15.0/13.0 (1) 15.0/13.0

(1) 11.0/9.1 (1) 11.0/9.1 (2) 11.0/9.1
Top burners (1) 6.0/6.0 (1) 6.0/6.0 (1) 6.0/6.0 (3) 9.5/7.0
(000’s BTU’s) Nat/LP (1) 9.1/8.0 (1) 9.1/8.0 (1) 9.1/8.0 (1) 5.0/4.0 (4) 9.0/8.0

Range electrical rating 240v/208v, 60Hz/40A 120v, 60Hz, 5A 120v, 60Hz, 5A 120v, 60Hz, 5A 120v, 60Hz, 5A
Convection Wattage 2,500
Broiler/Bake Wattage/BTU 3,600/2,700 watts 12,000/15,000 BTU 12,000/15,000 BTU 16,000/16,000 BTU 16,000/16,000 BTU
LP conversion kit (included) ●● ● ●●

SS = Stainless steel with black accents, WW = White with white glass door, CC = Bisque with bisque glass door, BB = Black with black glass door
Factory set for Natural Gas. A set of LP orifices is included with each range for LP conversion.

You must use the rear filler strip kit shipped with the
range or the optional accessory backguard

(JXS31,

JXS32, JXS33, JXS34) when installing these ranges.

Counter Cutout Dimensions (in inches)
Models J2S968, JGS968, JGSP48
and JGSP23

Note: Cabinets installed adjacent to slide-in ranges must

have an adhesion spec of at least 194°F temperature rating.

Optional Kits for Slide-In Gas Ranges:

(Available at additional cost on all models
except JGSS05)

Rear Filler Strip Kits

Model JGSP23 is shipped with required “vented”
rear filler strip.

Lower/Side Trim Kits

JXS52BB—Lower Trim Kit (Black)
JXS53WW—Lower Trim Kit (White)
JXS55CC—Lower Trim Kit (Bisque)

Accessory Backguards

JXS31—White Accessory Backguard
JXS32—Brushed-Chrome Accessory Backguard
JXS34—Black Accessory Backguard
JXS35—Bisque Accessory Backguard

Endcap Kit

JXS40—Endcap kit to accommodate replacement
where countertop may already be notched.

Optional Gas Range Wok Accessory

(Available at additional cost)
JXWK = Wok accessory holder sits on top of burner
grate to hold a

round-bottom wok.

GE Profile

™

GE

®

00

2" MIN. to
nearest
sidewall
(both sides)

35-7/8" MIN.

38" MAX.

18" MIN.*

30

30" MIN. clearance to cabinets

above cooktop

*ANSI Requirement

R

Listed by
Underwriters
Laboratories

All GE ranges are equipped
with an Anti-Tip device.
The installation of this
device is an important,
required step in the
installation of the range.

23-3/16

30

If you are NOT using the
optional Filler or Backguard:

30

If you are using the
optional Filler or Backguard:

25

67

GEAppliances.com

30" Slide-In Gas Range Dimensions (in inches)
Model JGSS05

Models J2S968, JGS968 and JGSP48

24

30

8

4

9

2

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for
120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Recommended common
area for gas outlet and
electrical outlet

36

46-3/8

30

36 ±1/4

*Depth to front of closed oven door

28-1/4" depth including handle
25-1/4" depth to front top edge of cooktop

26-1/8*

Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.

Model A* B C** D E
J2S968 30 38 28 44-3/4 35-3/4 to 36-1/2
JGS968 30 38 28 44-3/4 35-3/4 to 36-1/2
JGSP48 30 38 28 44-3/4 35-3/4 to 36-1/2
JGSP23 30 36-1/4 28-7/8 45-1/8 35-7/8 to 38

*Cooktop width including overhang 30-3/4".

**Depth including handle:

25-1/2"—Wall to front of closed oven door
26-1/4"—Depth to front top edge of control panel

Dimensions (in inches)

B

C

D

A

E

30" Slide-In Gas Ranges Dimensions (in inches)
Models J2S968, JGS968, JGSP48 and JGSP23

Model JGSP23

C

L

C

L

2-1/2

1-1/2

2-1/2

20

10

18

2-1/2

7-1/2

Recommended area
for 120V outlet on
rear wall and area
for through-the-wall
connection of
pipe stub and
shut-off valve

Recommended area
for through-the-floor
connection of pipe stub
and shut-off valve

7

12-1/2

Acceptable
Gas Line &

Electrical

Outlet Area

Max. depth of

cord, plug,

receptacle box

& gas hookup

3-1/2 to prevent

interference

with drawer

30 Min.

30 Min.

Shave Raised Edge To Clear
31-1/8 Wide Control Panel

36

4 Min.

From W alls

23-3/16

18 Min.

13 Max.

3

29-15/16 Min.
30-1/16 Max.

25

9/16

7

12

15

68

Countertop Cutout—Top View
Models JDP39/36 and JDS26

30" Exact

smooth cut

Front
Face of
Cabinet

Overhang

If countertop edge is formed, this

dimension must extend to flat area

3" MIN.
(Both sides)

Adjoining
vertical
cabinet
or wall
above
countertop

Inside back wall of cabinet
or rear wall

1-1/2" MIN.

5/16" MIN. Flat

29-1/4"

Exact

smooth cut

3/8

22-13/16

1-1/8

Optional Kits For JD968/JDP47 Electric Ranges

(Available At Additional Cost)

Maintop Filler (JD968/JDP47)

(Fills gap between cooktop and wall when unit is
installed in 30" free-standing cutout)

JXS66WW—White
JXS66CC—Bisque
JXS66BB—Black

Accessory Backguards (JD968/JDP47)

(Attaches to the back of range as a backguard when
unit is installed in 30" free-standing cutout)

JXS37WW—White
JXS37CC—Bisque
JXS37BB—Black/Stainless

Lower Trim Kits

(When a drop-in is installed in an existing cutout greater
than 27-1/4" from the counter to the cabinet cross-rail, a
lower trim kit should be used to fill the gap at the bottom
of the range)

JXS96WW—White
JXS96CC—Bisque
JXS96BB—Black

Note: Cabinets installed adjacent to drop-in electric
ranges must have an adhesion spec of at least a 194°F
temperature rating.

Note: All 30" Drop-In Radiant Ranges conform to U.L.
requirements for 0" spacing from range to adjacent walls
below countertop. To reduce possibility of scorching the
side walls above the countertop when no load is present on
burners, it is recommended that a minimum 6" spacing
from adjacent side wall be allowed for possible extended
high-heat element operation.

Installation Information: Before installing, consult
installation instructions packed with product for
current dimensional data.

IMPORTANT: 30" DROP-IN RANGES ARE DESIGNED
TO HANG FROM THE COUNTERTOP. IT DOES NOT
REST ON THE FLOOR. FOR INSTALLATION
ALTERNATIVES, REFER TO INSTALLATION
INSTRUCTIONS PACKED WITH PRODUCT.

30" Drop-In Electric Ranges

GE Profile

™

GE

®

All GE ranges are equipped
with an Anti-Tip device.
The installation of this
device is an important,
required step in the
installation of the range.

JD968SF
JD968TF JDP47WF
JD968KF

JDP47CF JDP39WW JDP36BW JDS26BW

JD968BF JDP47BF JDP39BW JDP36BD JDS26BD

Features

Self-clean oven w/Delay clean option ●●●●Standard-clean
Light self-clean option ●●
Variable cleaning time ●●●●
Automatic self-clean oven door lock ●●●●
Oven racks 3 Heavy-Duty 2 2 2 2
CleanDesign oven interior/hidden bake ●
TrueTemp™ system ●●
Variable broil/Six-pass broil element ●●

Patterned Black

True White

Patterned White

True Bisque

Patterned Bisque

Ceramic-glass cooktop Patterned Black Patterned Black
Dual 6"/9" heating element 1 Ribbon (2500W) 1 Ribbon (2500W)
8" heating elements 2 Ribbon (2000W) 2 Plug-In 2 Plug-In 2 Plug-In
7" heating elements 2 Ribbon (1800W)

Bridge element 1 Ribbon (800W)
Total wattage 4400W

6" heating element 1 Ribbon (1500W) 1 Ribbon (1500W) 2 Plug-In 2 Plug-In 2 Plug-In

Warming zone 1 Ribbon (120W)

Infinite heat controls ●●●●●
Precise Air™ convection system ●

Multi-rack convection bake ●
Single rack convection bake ●
Convection roast ●
Auto Recipe™ conversion ●

SmartSet controls Glass Touch ●●●●

Proof mode ●
Warm mode ●
Oven meat probe ●
Temperature display ●● ●●●
Delay Bake option ●● ●●●
C° or F° programmable ●●●●●
Audible preheat signal ●●●●●
Auto oven shut-off w/override ●●●●●
Control lock capability ●●●●●
Electronic clock/kitchen timer ●●●●●

Hot surface indicator lights 4 4
Heating element “ON” indicator light ●●●●●
Certified Sabbath mode ●●
Interior oven light Halogen ●●●●
Broiler pan with grid ●●●●●
Roasting rack ●

Appearance

SS

WW

WW

CC

CC WW WH WH

Color appearance* BB BB BB CT CT

Stainless

White White

Bisque Bisque White

Frameless glass oven door* Black Black Black Black Black
Oven door with window Big ClearView™ Big ClearView ●●●

Sculptured

Stainless-look

Sculptured White Sculptured White

Sculptured Bisque Sculptured Bisque

White

Oven door handle Sculptured Black Sculptured Black Black Black Black
Convection cookbook ●

Weights & Dimensions

Overall oven interior dimensions
(WxHxD in inches) 24 x 16-1/4 x 18-1/4 24 x 17-1/2 x 18-1/4 22-3/4 x 15-3/4 x 17 22-3/4 x 15-3/4 x 17 22-3/4 x 15-3/4 x 17

Approx. shipping weight (lbs.) 175 170

Power/Ratings

KW rating @ 240V 12.1 11.6 11.6 11.6 11.6

208V 9.1 8.7 8.7 8.7 8.7

Amps @ 240V 40 40 40 40 40

208V 40 40 40 40 40
Convection Wattage 2500
Broiler/Bake Wattage 3600/2700 3600/3400 3400/2585 3400/2585 3400/2585

**SS = Stainless steel with black accents, WW = White with white glass door, CC = Bisque with bisque glass door, BB = Black with black glass door,

WH = White with black glass door, CT = Bisque with black glass door

R

Listed by
Underwriters
Laboratories

Drop-In ranges are not approved for installation
with a plug and receptacle. They must be hard wired
in accordance with installation instructions.

69

GEAppliances.com

30" Drop-In Range Dimensions (in inches)
Models JDP39/36 and JDS26

Counter overhang
(1-1/4" Standard)

4" x 4"

Junction box

in adjoining

cabinet or under

cabinet floor

Base panel

30" to

bottom of

cabinet

over

range

30"

Exact

between

cabinets

26"

(To front of

door handle)

30

(To front
edge of
door
excluding
handle)

18-3/4

24-3/4

30-1/2

30-1/4

23-3/16"

MIN.

For best fit

30

18" MIN. to bottom

of cabinet

22" MIN.

flat counter

Countertop
If necessary, build up
sides to 1-1⁄2" thick to
provide screw anchor
surface and
countertop support

These screws are anti-tip
devices and must be
installed in the front and rear

Range side

support

Important: This range
is designed to hang
from the countertop.
It does not rest on
the floor.

Acceptable Electrical

Outlet Area Also In Adjacent

Cabinet Or Under Floor

Shave Raised Edge To Clear
31-1/8" Wide Control Panel

9/16

30" Min.

30" Min.

15" Min.

6" Min.

from walls

7-1/2

30

36

27-1/4

25

23-3/16

If necessary,
build upsides
to 1-1/4" thick
to provide
countertop
support

2-7/8"
To Front Surface
of Countertop

31-1/4

26-1/2

27

20-5/8" Door

Clearance

From Front

Surface of
Countertop

30" Drop-In Range Dimensions (in inches)
Models JD968 and JDP47

70

Spacemaker™27" Drop-In Electric Ranges

JMP28BC

JMP31WC JMP28BD JMS08BD

Features

Oven cleaning Self-Clean Self-Clean Standard Clean
Variable cleaning time ●●
Automatic self-clean oven door lock ●●
Oven racks 2 2 2

White White Porc.-Enam. White or Bisque

Lift-up overhanging cooktop Porcelain-Enameled Bisque Porc.-Enam. Porcelain-Enameled
8" heating elements 1 1 1
6" heating elements 3 3 3
Plug-in Calrod®heating elements ●●●
Infinite heat controls ●●●
Removable one-piece drip bowls Chrome Chrome Chrome
Electronic clock and kitchen timer ●●
Delay Bake option ●●
Auto oven shut-off ●●
Electronic oven control ●●
Heating element “ON” indicator light ●●●
Interior oven light ●●●
Broiler pan with grid ●●●

Appearance

WH

Color appearance* WW CT WH/CT
Frameless oven door White Glass Black Glass Black Glass
Oven door with window Big View Big View Big View
Lift-off oven door ●●●
Designer-style handle Sure Grip ●●

Weights & Dimensions

Overall oven interior dimensions
(WxHxD in inches)

19 x 15 x 18

Approx. shipping weight (lbs.) 119 119 119

Power/Ratings

KW rating @ 240V 9.8 9.8 10.1

208V 7.3 7.3 7.6

Amps @ 240V 40 40 40

208V 40 40 40

*WW = White with white glass door, WH = White with black glass door, CT = Bisque with black glass door

GE Profile

™

GE

®

Important: This range is designed to hang from the
countertop. It does not rest on the floor.

;

;;;

;;;;

;;;;;

;;;;;

;;;;;

;;

;

;;

Countertop
If necessary, build up
sides to 1-1⁄2" thick to
provide screw anchor
surface and
countertop support

These screws are anti-tip
devices and must be
installed in the front and rear

Locate junction box

anywhere in shaded area

;;

;

Door

clearance

30" MIN. to

bottom of

cabinet

over

range

18

Range side

support

Back of range

to front of

closed door

Trim section for
countertop with

post formed or

raised front

edge

2

27-1/8

24-3/16
22-3/16

28-7/16

28-1/2"

MIN.

27" Between

cabinets

20"

22-3/16"

13/32

27" Drop-In Range Dimensions (in inches)

Countertop Cutout—Top View

Note: All 27" Drop-In Electric Ranges conform to U.L.

requirements for minimum spacing between range and side
wall below countertop.

Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.

Optional Backguard

(Available at additional cost)
JX27RBK = Black
JX27RWH = White

Inside back wall of cabinet
or rear wall

Adjoining
vertical
cabinet
or wall
above
countertop

3" MIN.
(Both sides)

26-1/4" MAX.

Smooth cut

22-7/8"

Cutout

23-3/8" MIN.*
Flat
counter

3/8" MIN. Flat

1-1/2" MIN.

Clearance

21-3/4" cabinet
face to rear
of cutout

Note: Cabinets installed adjacent to
drop-in electric ranges must have an
adhesion spec of at least a 194°F
temperature rating.

*If countertop edge is formed, this

dimension must extend to flat area.

In replacement installation, use
JX27R optional backguard, if required.

R

Listed by
Underwriters
Laboratories

71

GEAppliances.com

Slide-Out Hoods

JV960SC JV930SC JV696S JV695S JV694S JV396S JV395S JV394S

Features

Variable-speed fan control ●●●●●●●●
Auto heat sensor ●●●●●●●●
Vertical exhaust (CFM) 300 300 300 300 300 300 300 300
Sones rating: Top exhaust 4.5 4.5 4.5 4.5 4.5 4.5 4.5 4.5
Removable grease filter* ●●●●●●●●
Filter size (sq. in.) 147 147 147 147 147 147 147 147
Cooktop light ●●●●●●●●
3-1/4" x 10" rectangular duct ●●●●●●●●

Appearance

Color appearance** BA BA CC WW BB CC WW BB

Weights & Dimensions

Width (in inches) 36 30 36 36 36 30 30 30
Approx. shipping weight (lbs.) 43 40 43 43 43 40 40 40

Power/Ratings

Current rating amps @ 120V 3.7 3.7 3.7 3.7 3.7 3.7 3.7 3.7

*Has washable one-piece smoke/grease filter.

**WW = White on white, BB = Black on black, CC = Bisque on bisque, BA = Brushed Aluminum.

Note: These vented hoods include an installed damper.
Note: The unit is ducted vertically. Horizontal ducting can be accomplished as shown.
Note: Remove glass visor from unit before installing hood in cabinet to protect visor from damage.
Installation Information: Before installing, consult Use & Care/installation instructions packed with

product for current dimensional data.

12-1/8

10-1/2

24-1/8

9-1/4

6

30
36

1

3-1/4

10

4-1/4

1-5/8–30"
7-5/8–36"

11"

MIN.

(inside)

Flush bottom cabinet

18" MIN.

11"

MIN.

(inside)

Recessed bottom cabinet

18" MIN.

Dimensions (in inches)

GE Profile

Installation Information
(in inches)

R

Listed by
Underwriters
Laboratories

72

Approved for use with the following GE Profile and GE cooktops—
36" and 30" electric models, 36" and 30" gas sealed burner models
and 36" and 30" induction models.

Not approved for use with standard burner gas cooktops.

Note:

Dimensions shown are for reference only. Before cutting out

countertop, refer to instructions packed with

downdraft and cooktop.

Note: The countertop must be at least 26" deep with a flat surface

area of 23-1/2" or more, front to back. In addition, other clearances
to the front edge of the countertop must be considered.

Note: Installation in cabinets/countertops against the wall will
not be possible in most applications. Against the wall installations
are limited to dimension requirements. Refer to installation
instructions packed with product for further details.

Overall Dimensions (in inches)
Model JVB98/67

Venting Options (Through the Floor) In Cabinet Discharge (Down)

In Cabinet Discharge (Right) In Cabinet Discharge (Left)

Blower Position

2-1/4

6-3/8

3-1/4

33-7/8

36

17-1/8
20-5/8

12-1/8

7-1/4

7-1/2

8-1/2

27

C

L

2-1/4

6-3/8

3-1/4

30" Unit

30

28-3/8

14-3/8
17-7/8

12-1/8

7-1/4

7-1/2

8-1/2

27

C

L

JXBC67 Outdoor Cover. Optional accessory may be ordered for
installation of motor and blower assembly on outside wall.

JXRB67 Indoor Remote Accessory. Optional accessory may be
ordered for installation of motor and blower assembly in an
indoor remote location.

Note: Telescopic downdraft vents are not recommended to be installed
with cooktops that are flush mounted.

30˚

Blower

Rotation

From Any Position

3-1/2

Left-Right

Adjustment

Telescopic Downdraft Systems

Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.

JVB67HWW

JVB37HWW

JVB67HCC JVB37HCC

JVB98SH JVB94SH JVB67HBB JVB37HBB

Features

Upfront variable-speed fan
w/slide control ●●●●

Separate remote raise/lower switch ●●
Blower rating (CFM) 500 500 500 500
Optional blower mount capabilities ●●●●
3-1/4" x 10" rectangular duct ●●●●
Minimum 6" round duct capability ●●●●
Removable grease filters ●●●●

Appearance

WW WW

CC CC

Color appearance* SS SS BB BB

White

White

Bisque Bisque

Cover plate SS SS Black Black
Telescopic snorkel assembly Black Black Black Black

Weights & Dimensions

Width (in inches) 36 30 36 30
Approx. shipping weight (lbs.) 76 72 76 72

Power/Ratings

Current rating amps @ 120V 4.0 4.0 4.0 4.0

*SS = Stainless steel, WW = White on white, CC = Bisque on bisque, BB = Black on black.

Note: Approved for use with GE Profile and GE®electric and sealed burner gas cooktops.

GE Profile

™

Model JVB94/37

73

GEAppliances.com

Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.

Optional Kits for 30" Designer Hoods

JXBF30SS—30" Commercial Filter
JXCHSS—Stainless Chimney Kit
JXDW1—7" round to 3-1/4" x 10" rectangular
duct transition for rear wall discharge.

GE Profile

™

36" and 30" Designer Hoods

JV966D JV936D

General

Width 36" 30"
Height 18" 18"

Features

Ducting Vertical Only Vertical Only
Duct size 7" round 7" round
CFM rating 600 600
Sones rating 7 7
Filters ●●
Filter cleaning Dishwasher-Safe Dishwasher-Safe
Lighting Dual Halogen Dual Halogen
Control type Manual Manual
Control location Hidden Hidden
Four-speed fan control ●●
Light settings Off/High/Night Off/High/Night
Blower/light switch color Black Black

Appearance

Color appearance* SS SS

Weights & Dimensions

Approx. shipping weight (lbs.) 77 68

Power/Ratings

Current rating Amps @ 120V 3.9 3.9

Accessories/Kits

Baffle filter kit ●●
Optional chimney kit ●●

*SS = Stainless steel.

Telescopes for

9' and 10'

ceilings

Hood

Installation

Height

(24" to 36")

18

21

30

36

42" min.

52" max.

11

12

Telescopes for

9' and 10'

ceilings

Hood

Installation

Height

(24" to 36")

18

36

30

42" min.

52" max.

21

11

12

Installed Above a Range (Shown with Optional Chimney Kit)
Dimensions (in inches)

Installed Above a Cooktop (Shown with Optional Chimney Kit)
Dimensions (in inches)

Optional Kits for 36" Designer Hoods

JXBF36SS—36" Commercial Filter
JXCHSS—Stainless Chimney Kit
JXDW1—7" round to 3-1/4" x 10" rectangular
duct transition for rear wall discharge.

R

Listed by
Underwriters
Laboratories

74

30" JV347H JV338H JN327H
36" JV367H

Features

Two-speed fan control ●●
Three-speed fan control ●
Vertical exhaust (CFM) 200 170
Rear exhaust (CFM) 180 160
Damper included (rectangular) ●●
Optional damper accessory (round) JXDA22 JXDA22
Sones rating:

Top exhaust 6.0 5.5
Rear exhaust 7.0 7.0

Disposable Disposable

Removable grease filters 1-Pc. Filter

†

1

†

1-Pc. Filter

†

Filter size (sq. in.) 90 90 90
Cooktop light(s)* 1 1 1
3-1/4" x 10" rectangular duct ●●
7" round duct ●●
Non-vented ●

Appearance

Color appearance** WW/CC/BB WW/CC WW/CC/AA

Weights & Dimensions

Approx. shipping weight (lbs.) 20 17 19

Power/Ratings

Current rating amps @ 120V 2.5 2.5 2.5

*Light bulbs not furnished.

**WW = White on white, CC = Bisque on bisque, BB = Black on black, W = White, C = Bisque,

A = Almond.

†

WB02X9381 replacement grease filter and WB02X10700 replacement charcoal filter are
available for additional cost. Call toll-free 800.626.2002 (Models JV367/347/338 and
JN327).

Width

Deluxe Standard

GE

®

Hoods

Model A B C D
JV666/JV665 7-1/4 35-7/8 20 12
JV636/JV635 7-1/4 29-7/8 20 12
JV536/JV535 7-1/4 29-7/8 20 12
JV566/JV565 7-1/4 35-7/8 20 12
JV367 5-1/2 35-7/8 17-1/2 12
JV347 5-1/2 29-7/8 17-1/2 12
JV338 5-1/2 29-7/8 17-1/2 12
JN327 5-1/2 29-7/8 17-1/2 12

Dimensions (in inches)

A

B

C

D

JXHC1 Cord Kit

Allows a receptacle in the cabinet over the range to
accommodate either an over-the-range microwave
oven or a standard hood.

30" JV636H JV635H JV536H JV535H
36" JV666H JV665H JV566H JV565H

Features

Two-speed fan control ●●
Four-speed fan control ●●●●
Damper included (rectangular) ●●●● ●●
Optional damper accessory (round) JXDA22 JXDA22 JXDA22 JXDA22 JXDA22 JXDA22
CFM/Sone rating:

Back rectangular 390/7.5 390/7.5 390/7.5 390/7.5 240/4.5 240/4.5
Top round 410/7.0 410/7.0 410/7.0 410/7.0 250/4.5 250/4.5

Top rectangular 380/7.5 380/7.5 380/7.5 380/7.5 240/5.0 240/5.0

Removable grease filters 2

†

2

†

2

†

2

†

2

††

2

††

2 Halogen 2 Halogen 2 Halogen 2 Halogen 2 Halogen 2 Halogen

Cooktop light(s)* (50 watt) (50 watt) (50 watt) (50 watt) (50 watt) (50 watt)
Night light position on light switch ●●●●
3-1/4" x 10" rectangular duct ●●●● ●●
7" round duct ●●●● ●●
Non-vented ●●

Appearance

Color appearance** SS WW/CC/BB SS WW/CC/BB SS WW/CC/BB

Weights & Dimensions

Approx. shipping weight (lbs.) 35 35 30 30 30 30

Power/Ratings

Current rating amps @ 120V 2.5 2.5 2.5 2.5 1.4 1.4

*Light bulbs not furnished.

**SS = Stainless steel, WW = White on white, CC = Bisque on bisque, BB = Black on black.

†WB02X11011 (30") or WB02X11012 (36") removable grease filter is available for additional cost (Models JV666, 665, 636, 635).

††WB02X11000 (30") or WB02X11001 (36") removable charcoal filter is available for additional cost (Models JV566, 565, 536, 535).

Call toll-free 800.626.2002.

Width

High-Performance Performance

GE Profile

75

GEAppliances.com

Hood Dimensions (in inches)

Models JV367H,
JV347H and JV338H*

Models JV367H,*
JV347H and JV338H

Model
JN327H

Installation Information: Before installing, consult installation

instructions packed with product for current dimensional data.

*JV367H, JV347H and JV338H—
Refer to this drawing for round
exhaust option. Refer to drawing
2 for rectangular exhaust option.

Exhaust outlet connects to 7"
diameter duct. Vent top only.
Round damper accessory,
JXDA22, available at
additional cost.

Exhaust outlet connects to
3-1/4" x 10" duct (vertically or
horizontally) and 7" round (vertically).
Includes rectangular damper and 7"
round damper adapter.

Round damper accessory, JXDA22
available at additional cost.

*JV367H, JV347H and JV338H—
Refer to this drawing for rectangular
exhaust option. Refer to drawing
3 for round exhaust option.

Exhaust outlet connects to
3-1/4" x 10" rectangular duct.
Vent top or rear. Includes
rectangular damper.

1

2

3

4

Models JV666H,
JV665H, JV636H,
JV635H, JV536H,
JV535H,JV566H
and JV565H

9

12

1-1/4

4-3/4

12-9/16

1-9/1 6

5

1-1/2

3/8

R

Listed by
Underwriters
Laboratories

(Models JV347,
JV367, and
JV338 only)

5-3/4

Center
line of hood

1-1/4

1-1/4

Optional power
supply connection

1-1/8" Typ.

7-3/4

1-3/8" Typ.

8-1/4" Typ.

1/2

10

3-1 /4

Center
line of hood

1-1/4

1-1/4

Optional power
supply connection

1-1/8" Typ.

7-3/4

1-3/8" Typ.

8-1/4" Typ.

Center

line of hood

1-1/4

1-1/4

Optional power
supply connection

Exhaust outlet

1-1/8" Typ.

7-3/4

1-3/8" Typ.

8-1/4" Typ.

GE Appliances

GEAppliances.com

GE Consumer Products
General Electric Company
Louisville, Kentucky 40225

GE has a policy of continuous improvement of its products
and reserves the right to change materials and specifications
without notice.

© 2003 General Electric Company

Pub. No. 3-S143 PC35936

hea

Answers that click!
GE puts everything you need at your fingertips.

GE Appliances web site — 16 million visitors a year!
Visit us at GEAppliances.com

Everything you need to know about GE products is here. Access up-to-date information, find out
“what’s new,” obtain dimensions, get installation tips and more. Extremely user-friendly, this
one-stop site lets you research by brand, category or model number and even buy online
through a local GE dealer.

GE Answer Center®saves you time.

800.626.2000

This 24-hour-a-day, 7-day-a-week service provides answers
on product features, installation, service and more.

For more than a century, GE has been committed to producing innovative products
that change the way people live. The result of thorough research and rigorous testing,
GE appliances are designed for years of dependable performance.
Today, the GE tradition of quality and innovation continues.

A Century of Quality and Innovation
