GE Adora 29, Profile 26, Profile 29 User Manual

GEAppliances.com

Safety Instructions . . . . . . . . . . .2, 3

Operating Instructions

Automatic Icemaker . . . . . . . . . . . . . . .20

Care and Cleaning . . . . . . . . . . . . .21, 22

Control for LCD Models . . . . . . . . . .4–11

Control for Non-LCD Models . . . .12, 13

Crispers and Pans . . . . . . . . . . . . . . . . .18

Dispenser . . . . . . . . . . . . . . . . . . . . . . . . .14

Freezer . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Fresh Food Storage Options . . . .16, 17

Replacing the Light Bulbs . . . . . . . . . .23

Water Filter . . . . . . . . . . . . . . . . . . . . . . . .15

Installation Instructions

Installing the Refrigerator . . . . . .26–34

Installing the Water Line . . . . . . . .35–37

Preparing to Install

Bottom Freezer

the Refrigerator . . . . . . . . . . . . . . . .24, 25

Troubleshooting Tips . . . . . .38–42

Normal Operating Sounds . . . . . . . . . .38

Consumer Sup por t

Consumer Support . . . . . . . .Back Cover

Owner’s Registration

for Canadian Customers . . . . . . . .43, 44

Performance Data Sheet . . . . . . . . . . .47

State of California Water

Treatment Device Certificate . . . . . . .48

Warranty for Canadian

Customers . . . . . . . . . . . . . . . . . . . . . . . . .46

Warranty for U.S. Customers . . . . . . .45

Owner’s Manual and

Installation Instructions

Profile™Models 26, 29,

GE Adora 29

Congélateur inférieur

Réfrigérateurs

Manuel d’utilisation

et d’installation

La section française commence à la page 49

Congelador inferior

Refrigeradores

Manual del

propietario y

instalación

La sección en español empieza en la página 95

Write the model and serial
numbers here:

Model # ____________________
Serial # ____________________

Find these numbers on a label

Refrigerators

on the left side, near the middle
of the refrigerator compartment .

225D2649P006 49-60663 07-11 GE

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

Use this appliance only for its intended purpose as described in this Owner’s Manual.

SAFETY PRECAUTIONS

When using electrical appliances, basic safety precautions should be followed, including the following:

 This refrigerator must be properly installed



and located in accordance with the Installation
Instructions before it is used.

 Do not allow children to climb, stand or hang



on the shelves in the refrigerator. They could
damage the refrigerator and seriously injure
themselves.

 Do not touch the cold surfaces in the freezer



compartment when hands are damp or wet.
Skin may stick to these extremely cold surfaces.

 Do not store or use gasoline or other flammable



vapors and liquids in the vicinity of this or any
other appliance.

 Keep fingers out of the “pinch point” areas;



clearances between the doors and between
the doors and cabinet are necessarily small.
Be careful closing doors when children are
in the area.

 In refrigerators with automatic icemakers,



avoid contact with the moving parts of the
ejector mechanism, or with the heating element
that releases the cubes. Do not place fingers or
hands on the automatic icemaking mechanism
while the refrigerator is plugged in.

 Unplug the refrigerator before cleaning and making



repairs.

NOTE: We strongly recommend that any servicing
be performed by a qualified individual.

 Do not refreeze frozen foods which have thawed



completely.

DANGER! RISK OF CHILD ENTRAPMENT

PROPER DISPOSAL OF THE REFRIGERATOR

Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are
still dangerous…even if they will sit for “just a few
days.” If you are getting rid of your old refrigerator,
please follow the instructions below to help prevent
accidents.

Before You Thr ow Away Your Old
Refrigerator or Freezer:

 Take off the doors.
 Leave the shelves in place so that children may not

easily climb inside.

Refrigerants

All refrigeration products contain refrigerants,
which under federal law must be removed prior
to product disposal. If you are getting rid of an old
refrigeration product , check with the company
handling the disposal about what to do.

USE OF EXTENSION CORDS

Because of potential safety hazards under certain conditions, we strongly recommend against the use
of an extension cord.

However, if you must use an extension cord, it is absolutely necessary that it be a UL-listed (in the United States)
or a CSA certified (in Canada), 3-wire grounding type appliance extension cord having a grounding type plug

2

and outlet and that the electrical rating of the cord be 15 amperes (minimum) and 120 volts.

GEAppliances.com

WARNING!

HOW TO C ONNECT ELECTRICITY

Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
For personal safety, this appliance must be properly grounded.

The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall outlet
to minimize the possibility of electric shock hazard
from this appliance.

Have the wall outlet and circuit checked by
a qualified electrician to make sure the outlet
is properly grounded.

Where a standard 2-prong wall outlet is encountered,
it is your personal responsibility and obligation to
have it replaced with a properly grounded 3-prong
wall outlet.

The refrigerator should always be plugged into its
own individual electrical outlet which has a voltage
rating that matches the rating plate.

This provides the best performance and also prevents
overloading house wiring circuits which could cause
a fire hazard from overheated wires.

Never unplug your refrigerator by pulling
on the power cord. Always grip plug firmly
and pull straight out from the outlet.

Repair or replace immediately all power cords that
have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage
along its length or at either end.

When moving the refrigerator away from the wall,
be careful not to roll over or damage the power cord.

READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.

SAVE THESE INSTRUCTIONS

3

About the 7”control panel for LCD models.

W

12:00 PM

FREEZER

-2

L

OCK

HOLD 3 SECONDS

D

ISPENSER

NOTE: The refrigerator is shipped with protective film covering the temperature controls. If this film was
not removed during installation, remove it now.

The temperature controls are preset in the factory at 38°F for the refrigerator compartment and –2°F
for the freezer compartment. Allow 24 hours for the temperature to stabilize to the preset recommended
settings.

The temperature controls can display both the SET temperature as well as the actual temperature
in the refrigerator and freezer. The actual temperature may vary slightly from the SET temperature based
on usage and operating environment.

W

ATE R

FRESH FOOD

38

S

ETTINGS

ATE R FILTER: GOOD

E

XTRAS

C

ONVERSIONS

N

UTRITION FACTS

P

HOTOS

S

UBSTITUTIONS

Reset the LCD screen at any time by inserting a paper clip into the small hole next to the SD card slot under
the front edge of the dispenser opening.

The Home Screen

The HOME screen is the default display on the refrigerator. From this screen you can change the fresh food and freezer
temperatures, select the desired ice and water dispenser setting and access other functions as listed below. To return
to this screen at any time, press the HOME button in the lower right hand corner of the screen.

Freezer Button: Displays actual
as well as set temperatures in freezer
compartment. When TurboFreeze is
active, it will be displayed.

Feature Lock: Hold for 3 seconds
to prevent accidental use of
the dispenser. The lock will change
from open to closed to indicate
the dispenser and controls have
been locked.

Fresh Food Button: Displays actual as well as set
temperatures in fresh food compartment. When
TurboCool is active, it will be displayed

.

12:47 PM

FREEZER

-2

LOCK

HOLD 3 SECONDS

D

ISPENSER

W

FRESH FOOD

38

SETTINGS

ATE R

Status Bar: Shows status of water filter.

WATE R FILTER: GOOD

EXTRAS

CONVERSIONS

NUTRITION FACTS

PHOTOS

SUBSTITUTIONS

Conversions Tool: Accesses
the conversions function.

Nutrition Facts: Find basic nutrition
information for common food items,
including fruits, vegetables, meats
and cheeses.

Photos: Upload photographs
to your refrigerator. Organize
and arrange photos into
a screensaver or slideshow.

Substitutions Feature: A catalog of
substitutions for common ingredients
which are not readily available.

Dispenser Tab: Select water, crushed ice or cubed
ice. Also access the dispenser light.

4

Settings Menu: Access refrigerator functions
such as TurboCool, Energy Saver and Door Alarm.
Change brightness of the display and replace
the water filter.

This product includes software which is based in
part on the work of the Independent JPEG Group

Screen functions. GEAppliances.com

Home Screen

FREEZER Button

12:00 PM

FREEZER

FREEZER

-2

0

ACTUAL: 0

(R

ECOMMENDED: 0

LOCK

HOLD 3 SECONDS

F

˚

WATE RDISPENSER

F)

˚

Up and Down Arrows
to set temperature

FRESH FOOD

S

ET TEMP

38

SAVE

SETTINGS

SAVE Button

WATER FILTER: GOOD

EXTRAS

CONVERSIONS

NUTRITION FACTS

PHOTOS

SUBSTITUTIONS

FREEZER Temperature:

To change the freezer compartment temperature, press the FREEZER
button and use the UP or DOWN arrow keys until the desired temperature
appears on the screen. Press SAVEto confirm the selection. The control
will display both the actual and set temperature until the set temperature
is reached. The actual temperature may vary slightly from the SET
temperature, based on usage and operating environment.

Each time you adjust the controls, allow 24 hours for the refrigerator
to reach the set temperature.

Up and Down Arrows
to set temperature

12:00 PM

F

REEZER

S

ET TEMP

0

S

AVE

L

OCK

HOLD 3 SECONDS

W

D

ISPENSER

12:00 PM

FREEZER

ATE R

-2

LOCK

D

ISPENSER

HOLD 3 SECONDS

W

ATE R

W

D

ISPENSER

DISPENSER Button
WATER option chosen

ATE R

F

RESH FOOD

F

RESH FOOD

38

38

A

(R

ECOMMENDED: 38

SAVE Button

FRESH FOOD

38

C

RUSHED ICE

FRESH FOOD Button

CTUAL: 38

F

˚

F)

˚

S

ETTINGS

SETTINGS

C

WATER FILTER: GOOD

E

XTRAS

C

N

P

S

WATE R FILTER: GOOD

EXTRAS

CONVERSIONS

NUTRITION FACTS

PHOTOS

SUBSTITUTIONS

UBED ICE

ONVERSIONS

UTRITION FACTS

HOTOS

UBSTITUTIONS

L

Dispenser
LIGHT Button

IGHT

FRESH FOOD Compartment Temperature:
To change the fresh food compartment temperature, press the FRESH

FOOD button and use the UP or DOWN arrow keys until the desired

temperature appears on the screen. Press SAVEto confirm the selection.
The control will display both the actual and set temperature until the set
temperature is reached. The actual temperature may vary slightly from
the SET temperature, based on usage and operating environment.

Each time you adjust the controls, allow 24 hours for the refrigerator
to reach the set temperature.

DISPENSER:

The refrigerator can dispense water, crushed ice or cubed ice through
the dispenser. To make a selection, press the DISPENSER button and
choose WATER, CRUSHED ICE or CUBED ICE. After the selection has
been made, press a glass against the dispenser paddle.

NOTE: The DISPENSER button is available from almost every feature
screen.

Dispenser LIGHT:

The dispenser light default setting is OFF. When the dispenser paddle
is pushed, the light automatically comes on (off after 5 seconds when
pad is released). To turn the light on manually, press the LIGHT button.
The dispenser light will stay on until the LIGHT button is pressed again.

12:00 PM

FREEZER

-2

LOCK

HOLD 3 SECONDS

L

D

ISPENSER

Locked Unlocked

OCKED

FRESH FOOD

38

SETTINGS

LOCK Button
Press and Hold for
3 seconds to Lock
or Unlock

WATE R FILTER: GOOD

EXTRAS

CONVERSIONS

NUTRITION FACTS

PHOTOS

SUBSTITUTIONS

LOCK:

To prevent accidental use of the control or dispenser, the control is
equipped with a lock feature. When locked, the dispenser and LCD
functions are not available. Press and hold the LOCK button for
3 seconds to lock or unlock the dispenser.

This product includes software which is based in
part on the work of the Independent JPEG Group

5

Screen functions.

12:00 PM

FREEZER

-2

LOCK

HOLD 3 SECONDS

D

ISPENSER

C

ONVERSIONS

P

ORTIONS

Half: 3/4 cups

Double: 3 cups

U

NITS

Ounces: 16

Milliliters: 470

D

ISPENSER

12:00 PM

F

REEZER

-2

L

OCK

HOLD 3 SECONDS

W

ATE R

W

ATE R

FRESH FOOD

38

SETTINGS

F

RESH FOOD

38

S

ETTINGS

WATE R FILTER: GOOD

EXTRAS

CONVERSIONS

NUTRITION FACTS

PHOTOS

SUBSTITUTIONS

WATER FILTER: GOOD

1

/

2

1

Cups

Nutrition Facts Button

W

ATER FILTER: GOOD

EXTRAS

C

ONVERSIONS

N

UTRITION FACTS

P

HOTOS

S

UBSTITUTIONS

CONVERSIONS

Press the CONVERSIONS button on the HOME screen to convert from one
unit and/or value to another. Use the UP and DOWN arrow keys to choose
the amount and/or units needed.

Conversions
Button

B

ACK

Choose portion

Choose unit

H

OME

NUTRITION FACTS

Press the NUTRITION FACTSbutton on the HOMEscreen to see nutrition
information. Six options along with an alphabet display are shown on
the screen. Select one of these ingredients or scroll by page or alphabet
character to proceed. The LEFT and RIGHT arrow keys on the display allow
you to scroll left or right on the top or bottom display. To go back
to the HOME screen, press the HOME button.

W

D

ISPENSER

ATE R

Choose ingredient or letter

N

UTRITION FACTS

AVOCADO

BEANS, GREEN

A B C D E F G H I J

W

N

UTRITION FACTS

Apple

Serving Size 138g

Calories 72
Calories from Fat 0

Amount Per Serving %DV*

Total Fat 0g 0%
Sat Fat 0g 0%
Trans Fat 0g 0%
Cholesterol 0g 0%

W

ATE R

6

D

ISPENSER

D

ISPENSER

Scroll Left

APPLE

ATER

ASPARAGUS

BANANA

BEANS, YELLOW

Sodium 1mg 0%
Total Carbs 19g 6%
Dietary Fiber 3 g 12%
Sugars 14 g
Protein 0g

Vitamin A 75
Vitamin C 63
Calcium 8
Iron 0.17

* Percent Daily Values (DV) are
based on a 2,000 calorie diet.

B

ACK

1

PAGE

0F

Page

8

Number

Scroll Page
or Alphabet

H

OME

B

ACK

Scroll Right

H

OME

This product includes software which is based in
part on the work of the Independent JPEG Group

12:00 PM

F

REEZER

-2

L

OCK

HOLD 3 SECONDS

D

ISPENSER

GEAppliances.com

W

F

RESH FOOD

ATE R FILTER: GOOD

E

XTRAS

C

ONVERSIONS

PHOTOS

Use the PHOTOSbutton to upload and display favorite photos that can
be used as a 15-minute slide show or as a screen saver. The screen saver
shows on the LCD screen after 2 minutes of inactivity. After 15 minutes,

N

38

S

ETTINGS

W

ATE R

UTRITION FACTS

P

HOTOS

S

UBSTITUTIONS

the backlight will go out. If the slide show is selected instead of the screen
saver, the photos will scroll through in a slide show for 15 minutes before
the backlight goes out.

Select the PHOTOSbutton on the HOMEscreen to see default photos and
to begin the process of uploading photos.

Speaker Reset

Select
photos

C

ONVERSIONS

P

ORTIONS

Double: 3 cups

U

NITS

Ounces: 16

Milliliters: 470

D

ISPENSER

ALL Button
to Select All
Photos on
SD Card

Selected photo

P

HOTOS

Half: 3/4 cups

W

ATE R

NONE Button
to Deselect
All Photos
on SD Card

Insert
SD Card

Photos
stored in
internal
memory

Photos
Button

Memory Meter:
Total number of
photos available
for upload (Max. 30)

WATER FILTER: GOOD

1

/

2

1

Cups

UPLOAD
Button

Number of pages available

EJECT
Button

UPLOADING PHOT OS

To upload photos, insert an SD card into the slot below the display.
Up to 100 photos (6 per page) from the SD card are displayed as

B

ACK

thumbnails in chronological order. Up to 30 photos can be uploaded.
Photos can be selected one at a time on the screen or by using the
ALL button if all photos (30 max) from the SD card are to be uploaded.
To deselect all photos, select the NONE button. When photos have
been selected, press the UPLOAD button. Uploading 30 photos will
take between 3 and 16 minutes. The CANCEL button can be pressed
at any time to stop the uploading process. When the upload is complete,
the display will show UPLOAD COMPLETE. Select the EJECT button to eject
the SD card and wait to be prompted to remove the card. If the card

H

OME

is removed without pressing the EJECT button, there is the possibility
of damaging the files on the SD card. When the SD card is removed,
the display returns to the PHOTOS screen.

NOTE:The dispenser will not work during photo upload.

SELECTING PHOTOS

B

ACK

1

PAGE

0F

2

The PHOTOS screen will display 6 thumbnail photos or you can
choose the full screen option. Navigate between screens using
the LEFT and RIGHT arrow keys on the sides of the display.
On the thumbnail screen, select photos one at a time by

Arrow
Key

touching that photo, select all of the photos by selecting
the ALL button or deselect all by selecting the NONE button.

S

ELECT

ALL NONE SLIDE SHOW DELETE

D

ISPENSER

ALL Button
to Select
All Photos

D

ISPENSER

P

HOTOS

NONE Button
to Deselect
All Photos

0/12

selected

W

ATE R

SLIDESHOW
Button

W

ATE R

DELETE
Button

DELETE

DELETE
Button

V

IEW

H

OME

View photos
as thumbnails

B

ACK


4

0F

V

IEW

H

OME

12

View
photos
full screen

Number
of photos
available

SLIDESHOW

Select SLIDE SHOW on the PHOTOS screen to view uploaded
photos in a slide show from newest to oldest. (This does NOT set
the slide show as the screen saver. That is done in the SYSTEMS
section.)

DELETING PHOTOS

With photos selected that you want to delete, select the DELETE
button from either the thumbnail screen or the full screen.
The ALL button can be used with the DELETE feature. You
will be given an opportunity to CANCEL the action before
the photos are deleted.

This product includes software which is based in
part on the work of the Independent JPEG Group

7

Screen functions.

12:00 PM

FREEZER

-2

LOCK

HOLD 3 SECONDS

D

ISPENSER

Select an
ingredient

S

UBSTITUTIONS

BAKING POWDER

A B C D E F G H I J

D

ISPENSER

FRESH FOOD

38

L

OCKED

ALLSPICE

BREAD CRUMBS

W

ATER

SETTINGS

WATE R FILTER: GOOD

EXTRAS

CONVERSIONS

NUTRITION FACTS

PHOTOS

SUBSTITUTIONS

SUBSTITUTIONS
Button

APPLE PIE SPICE

BAKING SODA

BROTH

SUBSTITUTIONS

Select the SUBSTITUTIONS button on the HOME screen. The screen
displayed gives tips for using substitutions in recipes. Continue on to
the next screen where 6 ingredients per page are displayed in the upper
section. Select an ingredient or use the LEFT and RIGHT arrow keys
to move from page to page. The lower section is for navigating
alphabetically. Select a letter or use the LEFT and RIGHT arrow keys
to move from page to page.

Once an ingredient has been selected, a list of ingredients and proportions
are listed that can be used as a substitute.

B

ACK

PAGE

0F

1

10

H

OME

12:00 PM

F

REEZER

-2

L

OCK

HOLD 3 SECONDS

D

ISPENSER

S

ETTINGS

D

ISPENSER

W

W

ATE R

ATE R

F

RESH FOOD

38

S

ETTINGS

SETTINGS
Button

REFRIGERATOR
Button

REFRIGERATOR

WATER FILTER

SYSTEM

SCREEN

W

ATE R FILTER: GOOD

E

XTRAS

C

ONVERSIONS

N

UTRITION FACTS

P

HOTOS

S

UBSTITUTIONS

SETTINGS

The SETTINGS feature will give you access to:

 TurboCool™settings



 TurboFreeze™settings



 instructions for changing the water filter



 access to systems such as door alarm



 Metric/English display



REFRIGERAT OR

Press the REFRIGERAT ORbutton to access the TurboCoolsetting
for the fresh food compartment and the TurboFreezesetting for
the freezer. TurboCool rapidly cools the fresh food compartment and

B

ACK

H

OME

TurboFreezerapidly cools the freezer compartment in order to more
quickly cool foods. Use these features when adding a large amount of
food to either compartment, putting away foods after they have been
sitting out at room temperature or when putting away warm leftovers.
It can also be used if the refrigerator has been without power for an
extended period. The compressor and fresh food or freezer fan will run
immediately for up to 3 1/2 hours (fresh food) or 2 1/2 hours (freezer)
and then return to the original setting value.

This product includes software which is based in
part on the work of the Independent JPEG Group

8

R

EFRIGERATOR

T

D

ISPENSER

URBO FREEZE

W

ATE R

T

URBO COOL

TURBO COOL
Button

GEAppliances.com

SETTINGS (cont.)

B

ACK

H

OME

When you press TurboCoolor TurboFreeze, a check mark shows
in the box next to the button showing that it is turned on. It will also be
listed on the HOME screen.

12:00 PM

FREEZER

-2

LOCK

HOLD 3 SECONDS

D

ISPENSER

S

ETTINGS

D

ISPENSER

FRESH FOOD

TURBO COOL

SETTINGS

W

ATE R

TURBO COOL Selected

W

ATER

WATER FILTER Button

REFRIGERATOR

WATER FILTER

SYSTEM

SCREEN

WATE R FILTER: GOOD

EXTRAS

CONVERSIONS

NUTRITION FACTS

PHOTOS

SUBSTITUTIONS

BACK

HOME

WATER FILTER

Select WATER FILTER from the SETTINGS screen. The WATER FILTER
screen displays whether the filter is GOOD, it is time to ORDER a filter,
or it is time to REPLACE the filter. Follow on-screen instructions as shown
in the example to order or replace the water filter. The status of the water
filter can also be found on the HOME screen in the upper right hand
corner when the door is open.

W

ATE R FILTER

FILTER STATUS: GOOD

D

ISPENSER

W

Water Filter Replacement Info: Replace with a
GE “MWF” water filter. In the US go to ge.com
or call 1-800-626-2002.

In Canada consult the yellow pages for the
nearest Mabe Service Center.

R

EMIND LATE R

ATE R

B

ACK

R

EPLACE

H

OME

This product includes software which is based in
part on the work of the Independent JPEG Group

9

Screen functions.

S

ETTINGS

D

ISPENSER

S

YSTEM

D

ISPENSER

ENERGY SAVER
Button

S

YSTEM

D

ISPENSER

S

YSTEM

D

ISPENSER

W

ATER

DOOR
ALARM
Button

D

OOR ALARM

B

UTTON TONES

E

NERGY SAVER

C

OOLING SYSTEM

W

ATER

D

OOR ALARM

B

UTTON TONES

E

NERGY SAVER

C

OOLING SYSTEM

W

ATER

D

OOR ALARM

B

UTTON TONES

E

NERGY SAVER

C

OOLING SYSTEM

W

ATER

Set Time

COOLING
SYSTEM
Button

REFRIGERATOR

WATER FILTER

SYSTEM

SCREEN

SYSTEM
Button

T

IME

U

NITS

E

T

IME

U

NITS

E

T

IME

U

NITS

E

(S

NGLISH

I

CE MAKER

(S

NGLISH

I

CE MAKER

(S

NGLISH

I

CE MAKER

ET TIME

ET TIME

SET TIME
Button

ET TIME

)

M

)

M

)

M

ETRIC

ETRIC

ETRIC

BACK

HOME

BACK

HOME

BACK

HOME

BACK

HOME

SETTINGS (cont.)

SYSTEM
Select the SYSTEM button to have access to:

 DOOR ALARM



 BUTTON TONES



 ENERGY SAVER



 COOLING SYSTEM



 TIME



 UNITS (ENGLISH or METRIC)



DOOR ALARM

There is a check mark beside the button if the DOOR ALARM is ON
(default). To turn it OFF, select the DOOR ALARM button (check will
be gone). The DOOR ALARM will sound if the refrigerator door is open
longer than 3 minutes. The DOOR OPEN alarm screen will be displayed
and a beeper will sound in 1-minute intervals until the door is closed
or the SILENCE button is selected.

BUTTON TONES

Press the BUTTON TONES button to control the sound of the LCD buttons.
When button sound is ON (default), the beeper sounds a tone each time
a button is pressed per audio specifications. To turn it off, select
the BUTTON TONES button (check will be gone). This also activates
or deactivates the Refreshment Center tone.

ENERGY SAVER

This refrigerator is shipped with the ENERGY SAVERfeature ON (check).
Over time, moisture can form on the front surface of the refrigerator
cabinet. If moisture does appear on the front surface of the refrigerator
cabinet, turn OFF the ENERGY SAVERby pressing the button (check
will be gone).

COOLING SYSTEM

This feature turns off the cooling system in the fresh food and freezer
compartments without shutting off the electricity to the refrigerator.
On the SYSTEM screen, select the COOLING SYSTEM button.
To turn COOLING SYSTEM ON or OFF, select COOLING SYSTEM
from the SYSTEM screen.

SET TIME

To set the clock, select the SET TIME button from the SYSTEM screen.
To change the hours and minutes, use the UP and DOWN arrow keys
above and below the numbers. To change from AM to PM, select the
corresponding pad. Select SAVEor CANCEL. You can change the time
to a 24-hour clock by selecting the 24 HR button. Change the hours
and minutes using the UP and DOWN arrow keys above and below
the numbers. Select SAVEor CANCEL.

10

T

IME

12 00

C

ANCEL

FORMAT

12 HR

AM

SAVE or CANCEL

24 HR

PM

S

AVE

This product includes software which is based in
part on the work of the Independent JPEG Group

GEAppliances.com

S

YSTEM

D

OOR ALARM

B

UTTON TONES

E

NERGY SAVER

C

OOLING SYSTEM

D

ISPENSER

12:00 PM

FREEZER

-18

LOCK

HOLD 3 SECONDS

ISPENSER

W

ATER

W

ATE RD

C

FRESH FOOD

3

SETTINGS

T

IME

U

NITS

E

NGLISH

I

C

METRIC
Button

(S

ET TIME

)

M

CE MAKER

ICEMAKER
Button

WATER FILTER: GOOD

EXTRAS

CONVERSIONS

NUTRITION FACTS

PHOTOS

SUBSTITUTIONS

ETRIC

BACK

HOME

SETTINGS (cont.)

UNITS

To change the temperature readings from English units to Metric units,
press the METRIC button. Units shown on the HOME screen will now read
in Celsius instead of Fahrenheit.

ICEMAKER

The unit comes with an icemaker installed. The icemaker rate of 9 cubes
per cycle will depend on freezer compartment temperature, room
temperature, number of door openings and other use conditions. If the
refrigerator is operated before the water connection is made to the
icemaker, press and release the ICEMAKER button on the SYSTEM screen
to disengage the icemaker. When the refrigerator has been connected to
the water supply, press and release the ICEMAKER button on the SYSTEM
screen to engage the icemaker. A newly installed refrigerator may take
12 to 24 hours to begin making ice cubes and the ICEMAKER default is
ON (check).

You will hear a buzzing sound each time the icemaker fills with water.
Throw away the first few batches of ice to allow the water line to clear.
It is normal for several cubes to be joined together. If ice is not used
frequently, old ice cubes will become cloudy, taste stale and shrink.
NOTE:In homes with lower-than-average water pressure, you may
hear the icemaker cycle multiple times when making one batch of ice.
NOTE:Turn OFF the icemaker if the water supply is shut off.

S

ETTINGS

W

CREEN

ATER

D

EFAULT

W

ATER

D

ISPENSER

S

S

CREEN SAVER

B

RIGHTNESS

B

RIGHTNESS

D

ISPENSER

Set Screen Saver and/or
Background

REFRIGERATOR

WATER FILTER

SYSTEM

SCREEN

SCREEN
Button

Set Brightness
of Screen

ENTER

BACK

HOME

BACK

HOME

SCREEN

Select the SCREEN button from the SETTINGS screen to adjust
the BRIGHTNESS of the display and to choose a SCREEN SAVER.

For BRIGHTNESS, use the LEFT and RIGHT arrow keys to dim and
brighten the screen.

For SCREEN SAVER, use the UP and DOWN arrow keys to choose

DEFAUL T, SLIDE SHOW, BACKGROUNDor OFF.
DEFAUL Tgives a slide show of factory pre-loaded pictures at 10-second

intervals. These pictures are not viewable in the PHOTOSscreen and
remain even when all photos are deleted.

SLIDE SHOW takes the most recently selected photo among
user-uploaded pictures and displays this one first, then the remaining
random photos at 10-second intervals for 15 minutes.

BACKGROUND takes the most recently selected photo among
user-uploaded pictures and displays this as a static image.
After 15 minutes of displaying this screen with no activity,
the backlight will go OFF.

OFF sets no BACKGROUND, SCREEN SAVERor SLIDE SHOW.

This product includes software which is based in
part on the work of the Independent JPEG Group

11

About the control with temperature settings for non-LCD models.

Model 26

GE Adora 29

Model 29

ENERGY

SAVER

ADJUST
FREEZER

(Hold 3 sec

for Turbo Freeze)

ICE &

WATE R

(Hold 3 sec

to Reset Filter)

TURBO FREEZE

-2˚ F Recommended

RESET FILTER

CLIMATE KEEPER

˚

F

CUBED CRUSHED

WATER

TURBO COOL

38˚ F Recommended

ICE
OFF

ALARM/

LIGHT

Light ON/OFF

(Hold 3 seconds)

ADJUST

REFRIGERATOR

˚

F

(Hold 3 sec

for Turbo Cool)

ICE OFF/

LOCK

(Hold 3 sec

to Lock Control)

The temperature controls are preset in the factory at 38°F for the refrigerator compartment and -2°F for
the freezer compartment. Allow 24 hours for the temperature to stabilize to the preset recommended settings.

The temperature controls can display both the SET temperature as well as the actual temperature in the
refrigerator and freezer. The actual temperature may vary slightly from the SET temperature based on usage and
operating environment.

A

DJUST

R

EFRIGERATOR

(Hold 3 sec

for Turbo Cool)

A

DJUST

F

REEZER

(Hold 3 sec

for Turbo Freeze)

NOTE: The refrigerator is shipped with protective film covering the temperature controls. If this film was
not removed during installation, remove it now.

Changing the Temperature

To change the temperature, press and
release the ADJUST FREEZERor ADJUST
REFRIGERAT ORpad. The display will

show the actual temperature. To change
the temperature, tap either the ADJUST
FREEZER or ADJUST REFRIGERATOR pad
until the desired temperature is displayed.

Once the desired temperature has been
set, the temperature display will return
to the actual refrigerator and freezer
temperatures after 10 seconds. Several
adjustments may be required.

Each time you adjust controls, allow
24 hours for the refrigerator to reach
the temperature you have set.

12

About TurboCool™and TurboFreeze.

™

(Non-LCD models Only)

GEAppliances.com

A

DJUST

R

EFRIGERATOR

(Hold 3 sec

for Turbo Cool)

A

DJUST

F

REEZER

(Hold 3 sec

for Turbo Freeze)

How it Works

TurboCool rapidly cools the refrigerator

compartment in order to more quickly
cool foods. Use TurboCool when adding
a large amount of food to the refrigerator
compartment, putting away foods after they
have been sitting out at room temperature
or when putting away warm leftovers.
It can also be used if the refrigerator has
been without power for an extended period.

The compressor and fresh food fan will run
immediately for up to 21⁄2 hours and then
return to the original setting value.

How it Works

TurboFreezerapidly cools the freezer

compartment in order to more quickly
cool foods. Use TurboFreezewhen adding
a large amount of food to the freezer
compartment, putting away foods after
they have been sitting out at room
temperature or when putting away
warm leftovers. It can also be used
if the refrigerator has been without
power for an extended period.

The compressor and freezer fan will
run immediately and keep running for
two-and-a-half hours.

How to Use

Press and hold the ADJUST REFRIGERATOR
pad for 3 seconds until you hear the sound
and the displays.

After TurboCool is complete, the refrigerator
compartment will return to the original
setting.

NOTES:

 The refrigerator temperature cannot be



changed during TurboCool.

 The freezer temperature is not affected



during TurboCool.

How to Use

Press and hold the ADJUST FREEZER pad
for 3 seconds until you hear the sound
and the displays.

After TurboFreeze is complete, the freezer
compartment will return to the original
setting.

NOTES:

 The freezer temperature cannot



be changed during TurboFreeze.

 The refrigerator temperature is



not affected during TurboFreeze.

 When opening the freezer door during



TurboFreeze,the fans will turn off when
the door is opened.

13

About the dispenser.

(Non-LCD models Only)

A

E

NERGY

T

URBO FREEZE

S

AVER

A

DJUST

F

REEZER

˚

F

(Hold 3 sec

-2˚ F Recommended

for Turbo Freeze)

I

CE &

TER

W

A

C

UBEDCRUSHED

R

ESET FILTER

(Hold 3 sec

to Reset Filter)

LARM/

T

URBO COOL

L

IGHT

Light ON/OFF

(Hold 3 seconds)

C

LIMATE KEEPER

A

DJUST

R

EFRIGERATOR

˚

F

(Hold 3 sec

38˚ F Recommended

for Turbo Cool)

ICE
OFF

I

CE OFF/

CK

L

O

W

ATER

(Hold 3 sec

to Lock Control)

To Use the Dispenser

Select CUBED , CRUSHED or WATER

by pressing the ICE & WATER pad.

Press the glass gently against the top
of the dispenser cradle.

The spill shelf is not self-draining. To reduce
water spotting, the shelf should be cleaned
regularly.

Spill Shelf

ICE &

WATE R

ICE OFF/

LOCK

(Hold 3 sec

to Lock Control)

To Lock and Unlock the Dispenser

To lock, press and hold the ICE OFF/LOCK
pad for 3 seconds. Repeat this step to unlock
the dispenser.

Important Facts About Your Dispenser

 Do not add ice from trays or bags to the storage drawer.



It may not crush or dispense well.

 Avoid overfilling glass with ice and use of narrow glasses.



Backed-up ice can jam the chute or cause the door
in the chute to freeze shut. If ice is blocking the chute,
poke it through with a wooden spoon.

 Beverages and foods should not be quick-chilled in



the ice storage drawer. Cans, bottles or food packages
in the storage drawer may cause the icemaker or auger
to jam.

If no water is dispensed when the refrigerator
is first installed, there may be air in the water
line system. Press the dispenser arm for at
least two minutes to remove trapped air from
the water line and to fill the water system.
To flush out impurities in the water line, throw
away the first six full glasses of water.

CAUTION:Never put fingers

or any other objects into the ice crusher
discharge opening.

 To keep dispensed ice from missing the glass, put the glass



close to, but not touching, the dispenser opening.

 Some crushed ice may be dispensed even though you



selected CUBED ICE. This happens occasionally when
a few cubes accidentally get directed to the crusher.

 After crushed ice is dispensed, some water may drip from



the chute.
Sometimes a small mound of snow will form on the door





in the ice chute. This condition is normal and usually occurs
when you have dispensed crushed ice repeatedly. The snow
will eventually evaporate.

14

A

LARM/

L

IGHT

Light ON/OFF

(Hold 3 seconds)

ENERGY

SAVER

ICE &

WATE R

(Hold 3 sec

to Reset Filter)

About Door Alarm About Dispenser Light

The door alarm will sound if any door
is open for more than 3 minutes. The beeping
stops when you close the door.

Press and hold the ALARM/LIGHT pad for
3 seconds to turn on the dispenser light.
To turn off, press and hold the pad again
for 3 seconds.

About Energy Saver

This product is equipped with an Energy
Saver feature. The refrigerator is shipped
with the Energy Saver feature on.

Over time, moisture can form on the front
surface of the refrigerator cabinet and cause

See About the Water Filter, Step 7

rust. If moisture does appear on the front
surface of the refrigerator cabinet, turn off
the Energy Saver feature by pressing
and releasing the ENERGY SAVERpad
on the control panel.

About the water filter. GEAppliances.com

Cartridge
Holder

Filter
Bypass
Plug

Water Filter Cartridge

The water filter cartridge is located
in the back upper right corner of
the refrigerator compartment.

When to Replace the Filter

The filter cartridge should be replaced when
indicated on the control panel. The water
filter indicator light shows the following:
Green – Good
Orange – Change soon
Red – Change immediately

Follow the screen instructions shown in
WATER FILTER in theAbout the 7”LCD Control
Panel for LCD Modelssection.

Installing the Filter Cartridge

If you are replacing the cartridge, first
remove the old one by slowly turning
it counterclockwise. A small amount
of water may drip down.

CAUTION: If air has been

trapped in the system, the filter cartridge may
be ejected as it is removed. Use caution when
removing.

Filter Bypass Plug

You must use the filter bypass plug when
a replacement filter cartridge is not available.
The icemaker will not operate without
the filter or filter bypass plug.

Replacement Filters:
To order additional filter cartridges

in the United States, visit our Website,
ge.com or call GE Parts and Accessories,

800.626.2002.

Filter Model MWF
Customers in Canada should consult

the yellow pages for the nearest Mabe
Service Center.

Remove the protective foil from the end
of the cartridge.

Lining up the arrow on the cartridge
and the cartridge holder, place the top
of the new cartridge up inside the holder.
Do not push it up into the holder. Slowly
rotate the cartridge clockwise until it
stops. As you turn the cartridge, it will
automatically raise itself into position.
Cartridge will rotate about 1/4 turn.
Do not overtighten.

Press and hold the ICE & WATER pad for
3 seconds to reset the filter.

Run water from the dispenser for
3 minutes (about 11⁄2 gallons) to clear
the system and prevent sputtering.
See To Use the Dispenser section.

NOTE:A newly installed water filter
cartridge may cause water to spurt
from the dispenser.

15

About the fresh food storage options.

Rearranging the Shelves

Shelves in the refrigerator compartment are adjustable.

To remove:

Remove all items from the shelf.
Tilt the shelf up at the front.
Lift the shelf up at the back and

bring the shelf out.

To replace:

While tilting the shelf up, insert the top

hook at the back of the shelf in a slot

on the track.
Lower the front of the shelf until

the bottom of the shelf locks into place.

Spillproof Shelves

Spillproof shelves have special edges to
help prevent spills from dripping to lower
shelves.

Quick Space Shelf

This shelf splits in half and slides under itself
for storage of tall items on the shelf below.

This shelf can be removed and replaced
or relocated (just like spillproof shelves).

NOTE: The location of the upper Quick Space
Shelf is not adjustable.

Slide-Out Spillproof Shelves

These shelves can be slid out to provide
easy access to items near the back of
the refrigerator and to provide easy cleaning.

16

Non-Adjustable Dairy Bin

To remove: Lift the dairy bin straight up,

then pull out.

Adjustable Bins on the Door

Adjustable bins can easily be carried from
refrigerator to work area.

To remove: Lift bin straight up, then pull out.
To replace or relocate: Slide in the bin just

above the molded door supports, and push
down. The bin will lock in place.

Refreshment
Center Door
(on some
models)

GEAppliances.com

To replace: Engage the bin in the molded

door supports and push down. The bin will
lock in place.

Non-Adjustable Bins on the Door

To remove: Lift the bin straight up, then

pull out.
To replace: Engage the bin in the molded

supports on the door and push down.
It will lock in place.

17

About the crispers and pans.

Deli Panan

Fruit and Vegetable Crisper

Keep fruits and vegetables organized in
separate compartments for easy access.

Excess water that may accumulate
in the bottom of the drawers or under
the drawers should be wiped dry.

Adjustable Deli/Produce Drawer

Lower

Higher

26 Model

Controls
(located

on

right side

of drawer)

29 Model

Controls
(located

on

right side

of drawer)

Deli

29 Adora

Model

The Adjustable Deli/Produce Drawer
is a full-width drawer with adjustable
temperature control. This drawer can
be used for large miscellaneous items.

Control for 26-cu.-ft. models Control for 29-cu.-ft. models

When Produce Drawer is selected,
the temperature of the drawer can be kept
around 38°F (3.2°C).

When Deli Drawer is selected,
the temperature of the drawer can be kept
around 34°F (1°C).

NOTE: Fruits and vegetables may be damaged
using the Deli Drawer setting. Do not store
lettuce or other leafy produce in this drawer.

Adora 29-cu.-ft . models

The Temperature of the Drawer is around
34°F (1°C).

NOTE: Fruits and vegetables may be damaged
using

this pantry. Do not store lettuce or other

leafy produce.

There is a temperature control which can
adjust the amount of cold air allowed into
the drawer.

the temperature of the drawer can be kept
around 41°F (5°C).

When the PRODUCE button is selected, the
temperature of the drawer can be kept
around 37°F (3°C).

When the DELI button is selected, the
temperature of the drawer can be kept
around 34°F (1°C).

NOTE: Fruits and vegetables may be damaged
using the DELI setting. Do not store lettuce or
other leafy produce at the DELI setting.

CAUTION:Do not store glass

bottles at this setting for a long period of time,
If they are frozen, they can break and cause
personal injury.

18

When the CITRUS button is selected,

How to Remove and Replace the Adjustable Deli/Produce Drawer

To remove:

Pull the drawer out to the stop position.
Lift the front of the drawer up and out.

To replace:

Lift the cover up.
Engage the pantry rollers into

the side rails.
Push the drawer inward (until it is

in place).

How to Remove and Replace Drawer Divider

To remove:

Pull the drawer out to the stop position.

Raise the front side of the divider
to unhook it from the rear wall of
the drawer.

To replace:

Hook the back of the divider over the rear
wall of the drawer.

Push the divider down.

About the freezer. GEAppliances.com

Freezer Basket and Drawer

Basket.
Drawer.

Basket Removal

To remove:

Remove Freezer Bin. (See below.)
Pull basket out to the stop position.

Tilt up the rear of the bin.
Lift it out to remove.

Basket Divider Removal/ Adjustment

To replace:

Place the basket into the rail assembly.

To remove:

Pull basket out of the stop position.
Tilt up the rear of the bin.
Remove divider bottom screws.

Lift it out to remove.

Drawer Removal

To remove: Pull the drawer forward and up to

remove it from the rails.
To replace: Place the drawer wheels onto the

rails and push back as you lower the drawer.

Non-Adjustable Bin in the Freezer

To remove: Pull the brackets upward until

you hear a clicking sound and remove
the bin.

To replace:

Hook the top corners of the divider over

the hole of the basket.

Reinstall divider bottom screws.

To replace: Hook the ends of the bin into
both brackets and push down until the bin
locks into place.

19

About the automatic icemaker.

A newly installed refrigerator may take 12 to 24 hours to begin making ice.

Automatic Icemaker

ICE OFF/

LOCK

(Hold 3 sec

to Lock Control)

The unit comes with an icemaker installed.
The icemaker rate of 9 cubes per cycle will
depend on the freezer compartment
temperature, room temperature, number
of door openings and other use conditions.

For Non-LCD Models: If the refrigerator
is operated before the water connection
is made to the icemaker, press and release
the ICE OFF/LOCK pad on the control panel
to disengage the icemaker.

When the refrigerator has been connected
to the water supply, press and release
the ICE OFF/LOCK pad on the control
panel to engage the icemaker.

For LCD Models: If the refrigerator is
operated before the water connection is
made to the icemaker, see ICEMAKER under
the Screen Functions of LCD Operations
section and follow the screen commands
to turn the icemaker OFF.

A newly installed refrigerator may take
12 to 24 hours to begin making ice cubes.

You will hear a buzzing sound each time
the icemaker fills with water.

Throw away the first few batches of ice to
allow the water line to clear.

Be sure nothing interferes with the sweep
of the feeler arm.

When the bin fills to the level of the feeler
arm, the icemaker will stop producing ice.
It is normal for several cubes to be joined
together.

If ice is not used frequently, old ice cubes will
become cloudy, taste stale and shrink.

NOTE:In homes with lower-than-average
water pressure, you may hear the icemaker
cycle multiple times when making one batch
of ice.

NOTE:If the water supply is shut off,
press and release the ICE OFF/LOCK pad
on the control panel of the non-LCD model.
For the LCD model, see ICEMAKER under
the Screen Functions of LCD Operations
section and follow the screen commands
to turn the icemaker OFF.

NOTE:It is normal to hear ice falling into the
ice compartment. It will make a marble-like
sound.

20

Care and cleaning of the refrigerator. GEAppliances.com

Cleaning the Outside

The door handles and trim. Clean with

a cloth dampened with soapy water. Dry
with a soft cloth. Do not use wax on the door
handles and trim.

Keep the outside clean. Wipe with a clean
cloth lightly dampened with kitchen
appliance wax or mild liquid dish detergent.
Dry and polish with a clean, soft cloth.
Use floor protection under the rollers when
moving the refrigerator. This will ensure
there is no floor damage.

Do not wipe the refrigerator with a soiled
dish cloth or wet towel. These may leave
a residue that can erode the paint . Do not
use scouring pads, powdered cleaners,
bleach or cleaners containing bleach
because these products can scratch
and weaken the paint f inish.

The stainless steel panels and door
handles.

Stainless steel (on some models) can be
cleaned with a commercially available
stainless steel cleaner. A spray-on stainless
steel cleaner works best.

NOTE:The protective film may leave a residue
that will need to be cleaned.

Do not use appliance wax, polish, bleach,
abrasive cleaners or other products
containing chlorine on stainless steel. Using
cleaners with chlorine, such as bleach, may
permanently affect the appearance of your
new refrigerator.

Silver-accented plastic parts. Wash parts
with soap or other mild detergents. Wipe
clean with a sponge, damp cloth or paper
towel.

Do not scrub with steel-wool pads or other
abrasive cleaners.

Cleaning the Inside

To help prevent odors,leave an open box

of baking soda in the refrigerator and freezer
compartments.

Unplug the refrigerator before cleaning.

If this is not practical, wring excess moisture
out of sponge or cloth when cleaning around
switches, lights or controls.

Use an appliance wax polish on the inside
surface between the doors.

Use warm water and baking soda solution—
about a tablespoon (15 ml) of baking soda
to a quart (1 liter) of water. This both cleans
and neutralizes odors. Rinse and wipe dry.

After cleaning the door gaskets, apply a thin
layer of petroleum jelly to the door gaskets
at the hinge side. This helps keep the gaskets
from sticking and bending out of shape.

Avoid cleaning cold glass shelves with hot
water because the extreme temperature
difference may cause them to break.
Handle glass shelves carefully. Bumping
tempered glass can cause it to shatter.

Do not wash any plastic refrigerator parts
in the dishwasher.

Silver-accented plastic parts. Wash parts
with soapy water. Wipe clean with a sponge,
damp cloth or paper towel.

Do not scrub with steel-wool pads or other
abrasive cleaners.

21

Care and cleaning of the refrigerator.

Behind the Refrigerator

Be careful when moving the refrigerator
away from the wall. All types of floor
coverings can be damaged, particularly
cushioned coverings and those with
embossed surfaces.

Raise the leveling legs located at the bottom
front of the refrigerator.

Pull the refrigerator straight out and return it
to position by pushing it straight in. Moving
the refrigerator in a side direction may result

Preparing for Vacation

For long vacations or absences, remove
food and unplug the refrigerator. Clean
the interior with a baking soda solution of
one tablespoon (15 ml) of baking soda to one
quart (1 liter) of water. Leave the doors open.

Non-LCD Models: Turn on the Ice Off feature
by pressing and releasing the ICE OFF/LOCK
pad on the control panel (the icon
displays) and shut off the water supply
to the refrigerator.

in damage to the floor covering or
refrigerator.

Lower the leveling legs until they touch
the floor.

When pushing the refrigerator back,
make sure you don’t roll over the power
cord or icemaker supply line (on some
models) and ensure the anti-tip bracket
is engaged (if equipped).

LCD Models: Turn off the icemaker by
following the screen commands shown
in the LCD Controlssection.

If the temperature can drop below freezing,
have a qualified servicer drain the water
supply system (on some models) to prevent
serious property damage due to flooding.

Preparing to Move

Secure all loose items such as base grille,
shelves and drawers by taping them securely
in place to prevent damage.

When using a hand truck to move the
refrigerator, do not rest the front or back
of the refrigerator against the hand truck.
This could damage the refrigerator. Handle
only from the sides of the refrigerator.

Be sure the refrigerator stays in an upright
position during moving.

22

Replacing the light bulbs. GEAppliances.com

Refrigerator Lights

An authorized technician will need to replace
the LED light.

Freezer Light

CAUTION: Light bulbs may

be hot.

Unplug the power cord from the outlet.
Pull drawer out to the stop position.

Push the clips in on each side, and pull
down and forward.

Turn the bulb counterclockwise.
Replace with an appliance bulb

of the same or lower wattage.
Replace the shield.
Plug the refrigerator back in.

NOTE:Appliance bulbs may be ordered from
GE Parts and Accessories, 800.626.2002.

23

Installation

Refrigerator

Instructions

Questions? Call 800.GE.CARES (800.432.2737) or visit our Website at: GEAppliances.com

In Canada, call 1.800.561.3344 or visit our Website at: www.GEAppliances.ca

BEFORE YOU BEGIN

Read these instructions completely and carefully.

•

IMPORTANT — Save these instructions for local

inspector’s use.

•

IMPORTANT — Observe all governing codes and

ordinances.

• Note to Installer – Be sure to leave these instructions with
the Consumer.

• Note to Consumer – Keep these instructions for future
reference.

• Skill level – Installation of this appliance requires basic
mechanical skills.

• Completion time – Refrigerator Installation 20 minutes

Water Line Installation 30 minutes

• Proper installation is the responsibility of the installer.

• Product failure due to improper installation is not covered

under the Warranty.

TOOLS YOU MAY NEED

Adjustable Wrench

1/4” Outer Diameter

Compression Nut

and Ferrule (sleeve)

3/32”, 1/8” and 4 mm

Allen Wrenches

Profile Models 26, 29

10 mm Socket Ratchet/Driver

Phillips-Head Screwdriver

Flat-Head Screwdriver

PREPARATION

MOVING THE REFRIGERATOR INDOORS
If the refrigerator will not fit through a doorway,

the refrigerator door and freezer drawer can be removed.

• To remove the refrigerator door, see the Installing

the Refrigerator section.

• To remove the freezer drawer, see the Removing
the Freezer Drawer section.

WATER SUPPLY TO THE ICEMAKER AND DISPENSER

If the refrigerator has an icemaker, it will have to be
connected to a cold water line. A GE water supply kit
(containing tubing, shutoff valve, fittings and instructions)
is available at extra cost from your dealer, by visiting
our Website at GEAppliances.com (in Canada at
www.GEAppliances.ca) or from Parts and Accessories,

800.626.2002 (in Canada 1.800.661.1616).

1/8” Drill Bit and
Electric or Hand Drill

Pencil

Pliers

Tape Measure

1/4” Nut Driver

Level

24

DIMENSIONS

Installation Instructions

353⁄4”

70”

681⁄2”

355⁄8”

Overall Height 70”
to Top of Hinge
Cover at Max. Height

Height from Floor 69
to Lower Level
of Hinge Cover

Case Depth 29
without Doors

Height to Top 68
of Cabinet

Overall Exterior 35
Case Width

Overall Exterior Depth 35
Bowed Doors/Drawers
with Handles

Case Depth w/o

Height from floor

to hinge cover top

Additional Dimensions

13

1

1

3

5

Doors 291⁄8

13

⁄16”

69

⁄16”

⁄8”

⁄2”

⁄4”

⁄8”

”

225⁄8”

All measurements are given with leveling leg fully retracted.

25

Installation Instructions

INSTALLING THE REFRIGERATOR

REFRIGERATOR LOCATION

• Do not install the refrigerator where the temperature will

go below 60°F (16°C) because it will not run often enough
to maintain proper temperatures.

• Do not install the refrigerator where the temperature will
go above 100°F (37°C) because it will not perform properly.

• Install it on a floor strong enough to support it fully loaded.

CLEARANCES

Allow the following clearances for ease of installation, proper
air circulation and plumbing and electrical connections.

Sides 1/8”(3 mm)
Top 1”(25 mm)
Back 1”(25 mm)

REMOVING THE REFRIGERATOR DOORS

•IMPORTANT NOTE: This refrigerator is 355/8”deep.
Doors and passageways leading to the installation
location must be at least 36”wide in order to leave
the doors and handles attached to the refrigerator
while transporting it into the installation location.
If passageways are less than 36”, the refrigerator
doors and handles can easily be scratched and damaged.
The top cap and doors can be removed to allow the
refrigerator to be safely moved indoors. If passageways
are less then 31”, the leveling legs must be removed as
well. Start with Step 1.

•If it is not necessary to remove doors, skip to Step 11.
Leave tape and all packaging on doors until the
refrigerator is in the final location.

•NOTE: Use a padded hand truck to move this refrigerator.
Place the refrigerator on the hand truck with a side
against the truck. We strongly recommend that
TWO PEOPLE move and complete this installation.

1

REMOVE THE FRESH FOOD
DOOR HANDLE

Handle Design varies based on models, however
Installation is same.

Stainless steel:

A

REMOVING
THE DOOR
HANDLE: Loosen
the set screws with
the 3/32”Allen
wrench
and remove
the handle.

Plastic handle:

A

REMOVING
THE DOOR HANDLE:
Slide the handle up
and off of the
mounting fasteners.

Mounting
Fasteners

NOTE: If the handle mounting fasteners need to be
tightened or removed, use a Phillips-head screwdriver.

2

REMOVE THE FREEZER DOOR HANDLE

Handle Design varies based on models, however
Installation is same.

Stainless steel and plastic handles:

A

Loosen the set screws located on the underside
of the handle with the 1/8”Allen wrench and remove
the handle.

NOTE: If the handle mounting fasteners need to be
tightened or removed, use a Phillips-head screwdriver.

A

Mounting
Fasteners

A

Badge

Badge

26

A

Installation Instructions

3

ATTACH THE FRESH FOOD
DOOR HANDLE

Stainless steel handle:

A

Attach the handle
to the handle
mounting fasteners
and tighten the set
screws with a 3/32”
Allen wrench.

Plastic handle:

A

Attach the handle to the handle mounting fasteners
by aligning the slots with the handle mounting
fasteners.

Slide it down until it is firmly locked into position.

A

Mounting
Fasteners

4

A TTACH THE FREEZER DOOR HANDLE

Stainless steel and plastic handles:

A

Attach the handle firmly to the mounting fasteners
and tighten the set screws on the bottom
of the handle with a 1/8”Allen wrench.

A

A

Slots on back
of handle

A

Mounting
Fasteners

27

Installation Instructions

INSTALLING THE REFRIGERATOR (cont.)

5

REMOVE THE REFRIGERATOR DOORS

5

A

Open the refrigerator doors.
Remove the two front caps with a flat-head screwdriver.

B

Remove the three screws on top with a Phillips-head

C

screwdriver.

D

Disconnect all electrical connectors.

REMOVE THE REFRIGERATOR DOORS (cont.)

Lift the door straight up to remove.

H

Remove the two bolts using a 3/16”Allen wrench

I

and two Phillips-head screws from the center hinge.
Set the hinge, bolts and screw aside.

E

To disconnect the water coupling, push in on the gray
coupling and pull out the tubing.

Gray
Coupling

Remove the two ground wires with a Phillips-head

F

screwdriver, one on each side.

G

Remove three 10 mm hex-head bolts (right and left).

Ground
Wire

6

REPLACING THE REFRIGERATOR DOORS

Install the center hinge on each side.

A

Lower the refrigerator door onto the center hinge pin.

B

Ensure that the plastic hinge pin thimble is on the center
hinge pin or inside door hinge pin hole located in the
bottom of the door.

Securely tape the door shut with masking tape

C

or have a second person support the door.

CAUTION: When the bolts are removed,

the door may fall and cause personal injury and/or
damage to the door itself.

28

Installation Instructions

6

REPLACING THE REFRIGERATOR DOORS

(cont.)

Insert the top hinge pin into the hinge hole on top of the

D

refrigerator door. Make sure the door is aligned with the
cabinet and opposite door. Attach the hinge to the top
of the cabinet. Do not tighten bolts completely.

E

On left-hand doors, pass the wires and water line
through the top hinge pin. Then connect the water line
and door electrical connector.

7

REMOVE THE FREEZER DOOR

A

Pull the freezer door open to full extension.
Remove the freezer bin by pulling both brackets upward

B

at the same time. (See page 19.)

Take out the lower basket by lifting the basket up from

C

the rail system. (See page 19.)

Attach the ground wire with a Phillips-head screwdriver

F

at the right and left hinge.
Make sure the gasket on the door is flush against

G

the cabinet and is not folded. Make sure the door is
straight and the gap between the doors is even across
the front. While holding the aligned door in place,
tighten the top hinge bolts.

Reconnect all connectors at the left and right sides of

H

the top cap. Reattach the three Phillips-head screws
on top.

Ground
Wire

Remove the two 10 mm hex-head bolts from the right

D

and left side.

29

Installation Instructions

INSTALLING THE REFRIGERATOR (cont.)

REMOVE THE FREEZER DOOR

7

Use the tip of a screwdriver to separate the rail from

E

the rail cover. Tilt the front end up and lift the entire
door.

F

Set the door front on a nonscratching surface.

G

Push the rail assemblies back into the cabinet.

(cont.)

CAUTION:Push both sides of the rail

assemblies back at the same time.

REMOVING THE LEVELING LEGS

8

(if applicable) (cont.)

29-cu.-ft. models

Two people are required to complete this procedure.
Gently lean the refrigerator back so the front end is off

A

of the floor.
Remove the 2 bolts securing the leveling leg bracket to

B

the underside of the refrigerator cabinet. Do this on
both sides.

REMOVING THE LEVELING LEGS

8

(if applicable)

26-cu.-ft. models

Remove the 2 bolts securing the leveling leg bracket to
the front of the refrigerator cabinet. Do this on both
sides.

REPLACING THE LEVELING LEGS

9

(if applicable)

26-cu.-ft. models

Replace the 2 bolts to secure the leveling leg bracket to
the front of the refrigerator cabinet. Do this on both
sides.

30
