Page 1
ADA-compliant
dishwashers
Contract Sales
New product introduction — April 2006
GE® ADA-compliant dishwashers
Page 2
GE® ADA-compliant dishwashers quick pitch
34"
ADA-compliant design
GE offers a dishwasher with the capacity, flexibility
and reliability in a size suitable for the lower counters
required by the Americans with Disabilities Act. GE is the
only American-branded leading manufacturer to offer
an ADA-compliant dishwasher.
Handsome appearance
It’s an attractive choice inside and out. The interior
is bright stainless steel to resist stains and corrosion.
Outside is the same sleek control panel as found on
the exterior of GE tall-tub dishwashers.
Excellent flexibility
Loading is easy with the deluxe lower rack and super
upper rack. On top are flip-down utility shelves for
extra space and the StemSafe™ feature to securely
hold stemware.
2
Quiet operation
An extra blanket of insulation keeps wash sounds inside
the dishwasher, where they belong.
Page 3
ge.com
GE® reliable service
You can rely on an ADA-compliant
dishwasher that’s backed by the
dependability of GE.
Stainless steel interior
Choose the luster and resilience of
an annealed, stainless steel interior in
a dishwasher that can fit under a 34"
countertop.
Height flexibility
While this dishwasher meets the
guidelines of the ADA by fitting under
a 34" countertop, height adjustable
legs allow this unit to fit under a
standard 36" countertop height
with ease.
GLDA696MSS shown
ADA-compliant dishwashers:
GLDA696MSS-Stainless steel
GLDA690MWW-White on white
GLDA690MBB-Black on black
Available July 2006
6-level towerless wash system
The towerless six-level wash system
provides extra performance, getting
dishes clean without prerinsing.
Color choices
Designed to fit virtually any décor,
the dishwasher is available in
stainless steel, white-on-white or
black-on-black exterior.
Features include:
• Super nylon upper rack and deluxe
nylon lower rack
• 2-digit countdown display
• Pots and Pans cycle
• 2/4/8-hour Delay Start
• HotStart
™
option
• Three-piece silverware basket
• Utility shelf in upper rack
• StemSafe
™
in upper rack
3
Page 4
GE® ADA-compliant dishwashers
24
24
MAX.
20-1/2
4
4 (Adjustable)
32-1/3" MIN.
adj. to 34-1/2"
25-5/8
22
GE
ENERGY STAR
GLDA696MSS
GLDA690MWW
Features
ADA-compliant ●
Tub and door liner Stainless steel
Front appearance Flat door
Full-length door design ●
Wash arms 3 direct-feed
Wash levels 6 – towerless
Water filtration 100% triple filtration
Dual pumps and motors ●
Manual clean filter ●
Rinse aid dispenser w/indicator and adjustment
Control type Electronic
Cycle progress indicator(s) Countdown display w/1 “Clean”
Touchpads 9
Cycles/Options 4/4
Last cycle memory ●
Cycles
Pots & Pans ●
Normal Wash ●
Light Wash ●
Rinse Only ●
Options
Delay Start 2/4/8-hour
Heated Dry ●
Hot Start ●
Hot Wash ●
Child lock ●
Racking Nylon
Upper rack Super
Lower rack Deluxe
Utility shelves 2 w/1 StemSafe™
Silverware basket Deluxe
Hard countertop installation ●
Latch ●
DryIndex
Calrod heating element Dual-wattage
Quiet
Sound insulation package QuietPower
Tub insulation Full wrap blanket
Door insulation Mastic and sound coat
QuietPower motor ●
Tub collar trim ●
Appearance
Colors available** SS, WW, BB
Weights & Dimensions
Height w/legs retracted (in.) 32-1/3
Overall width (in.) 24
Overall depth (in.) 24
Approx. shipping weight (lbs.) 132
** Sens or controlled
** SS = Stainless steel, WW = White on white, BB = Black on black
GLDA690MBB
3
Dishwasher Dimensions
(in inches)
A century of quality and innovation
For more than a century, GE has been committed to producing innovative products
that change the way people live. The result of thorough research and rigorous testing,
GE appliances are designed for years of dependable performance.
Today, the GE tradition of quality and innovation continues.
GE has a policy of continuous improvement of
its products and reserves the right to change
materials and specifications without notice.
© 2006 GE Company
Pub. No. 24-C566 PC43814
