GE Healthcare
Features
• Enhanced monitor integration capabilities with our
Datex-Ohmeda Anesthesia Monitor and Compact
Anesthesia monitor
• Lightweight and compact for easy maneuverability
• Optional integrated auxiliary O
2
flowmeter and
suction control
Advanced Breathing System (ABS™)
• One step bag/vent switch turns the ventilator on/off
• Minimal number of parts and tube connections greatly
reduces the potential for leaks and misconnects
• Ease of disassembly (no tools)
• Fully autoclavable and latex-free
7100 Ventilator
• Volume and Pressure modes with electronic PEEP
• Exhaled volume, airway pressure and inspired oxygen
monitoring capabilities
• Direct access to ventilator parameter settings
• Smart alarms direct user to specific problems and
affected parameters
• Pressure bar graph for visual reference on a breath-bybreath basis (optional pressure waveform available)
Improved low flow/reduced life cycle costs
• Only one scheduled maintenance check per year
• Fresh gas flow compensation – automatically
(available with tidal volume compensation option)
• Minimum O
2
flow of 50 mL
• Dual air flow tubes standard for higher resolution
of low flows
Aespire 7100
Essential performance
Compact design
Aespire®7100 shown with Datex-Ohmeda
Cardiocap
™
/5 monitor and Tec®7 Vaporizers
Physical Specifications
Dimensions
Height: 134.5 cm/52.9 in
Width: 72 cm/28.3 in
Depth: 73 cm/28.7 in
Weight: Approximately 108 kg/238 lb
Top shelf
Weight limit: 34 kg/75 lb
Width: 66 cm/26 in
Depth: 40 cm/15.75 in
Work surface
Height: 81.7 cm/32.2 in
Size: 2160 cm
2
/334 in
2
DIN rail
Side of machine: 34.5 cm/13.6 in
Drawers (internal dimensions)
Height: 17.5 cm/6.9 in
Width: 33 cm/13 in
Depth: 26.5 cm/10.4 in
Absorber bag arm (optional)
Arm length: 30.5 cm/12 in
Bag arm height
(adjustable): 87 cm/34.3 in
104 cm/40.9 in
Casters
Diameter: 12.5 cm/5 in
Brakes: Individual locking front casters
Ventilator Operating Specifications
Positive End Expiratory Pressure (PEEP)
Type: Integrated, electronically
controlled
Range: OFF, 4 to 30 cm H
2
O
(increments of 1 cm H2O)
Ventilator monitored values
Tidal volume: 5 to 1500 mL, 1 mL resolution
Minute volume: 0 to 99.9 L/min,
0.1 L/min resolution
Breathing rate: 0 to 65 breaths per minute,
1 breath per minute resolution
Oxygen percentage: 5% to 110%, 1% resolution
Airway pressure: -9 to 99 cm H
2
O,
1 cm H2O resolution
Alarm settings
Tidal volume (VTE): Low: OFF, 5 to 1500 mL
High: 20 to 1600 mL, OFF
Minute volume (V
E
): Low: OFF, 0.1 to 10 L/min
High: 0.5 to 30 L/min, OFF
Inspired oxygen (FiO
2
): Low: 18 to 100%
High: 21 to 100%, OFF
Apnea alarm: Mechanical ventilation ON:
< 5 mL breath measured
in 30 seconds
Mechanical ventilation OFF:
< 25 mL breath measured
in 30 seconds
Low airway pressure: Change of < 4 cm H
2
O
above PEEP
Pressure (P
limit
) range: 12 to 99 cm H2O
(increments of 1 cm H2O)
Sustained airway
pressure: 6 to 30 cm H
2
O + PEEP
(adjusted based on
ventilator settings)
Subatmospheric
pressure: Paw < -10 cm H
2
O
Alarm silence
countdown timer: 120 to 0 seconds
Modes of ventilation
Volume Control mode
With tidal volume compensation (optional)
Pressure mode (optional)
Ventilation parameters
Tidal volume range: 45 to 1500 mL
(Volume Control mode)
Incremental settings: 45 to 100 mL
(increments of 5 mL)
100 to 300 mL
(increments of 10 mL)
300 to 1000 mL
(increments of 25 mL)
1000 to 1500 mL
(increments of 50 mL)
Pressure (P
Inspired
) range: 5 to 50 cm H2O
(increments of 1 cm H2O)
5 to 1500 mL
volume delivery
Rate: 4 to 65 breaths per minute
(increments of 1 breath
per minute)
Inspiratory/
expiratory ratio: 2:1 to 1:6
(increments of 0.5)
Inspiratory pause adjust: 5% to 60% of inspiratory time
(increments of 5%)
Optional pressure waveform shown
Ventilator Accuracy
Delivery/monitoring accuracy
Volume delivery: > 200 mL = better than ±10%
Set TV
75 to 200 mL = better than ±20 mL
< 75 mL = better than ±15 mL
Pressure (P
Inspired
)
delivery repeatability: ±2 cm H2O
PEEP delivery
repeatability: ±2 cm H
2
O
Volume monitoring: > 200 mL = better than ±10%
75 to 200 mL = better than ±20 mL
< 75 mL = better than ±15 mL
Pressure monitoring: Better than ±2 cm H
2
O and ±5%
of reading (whichever is greater)
Ventilator Components
Flow transducer
Type: Variable orifice flow sensor
Dimensions: 22 mm OD and 15 mm ID
Location: Inspiratory outlet and
expiratory inlet
(Optional autoclavable sensor available)
Oxygen sensor
Type: Galvanic fuel cell
Ventilator pneumatics
Pressure range at inlet: 240 kPa to 700 kPa/
35 psig to 100 psig
Peak gas flow: 70 L/min + fresh gas flow
Flow range: 2 to 70 L/min
Flow compensation
range: 200 mL/min to 15 L/min
Ventilator screen
Display size: 120 mm x 92 mm
Display density: 1/4 VGA standard
Battery backup
Backup power: Demonstrated battery time
under typical operating
conditions is 90 + minutes
when fully charged. Battery
time under extreme conditions
is 30 minutes.
Battery type: Internal rechargeable sealed
lead acid
Communication port
Serial interface: Isolated RS-232C
compatible port
Anesthetic Agent Delivery
Delivery
Vaporizers: Tec 5, Tec 6 Plus, Tec 7
Number of positions: 2
Mounting: Tool-free installation Selectatec
®
manifold interlocks and
isolates vaporizers
N
O
O
U
T
P
U
T
W
A
R
M
U
P
A
L
A
R
M
B
A
T
T
E
R
Y
L
O
W
U
S
E
O
N
L
Y
D
E
S
F
L
U
R
A
N
E
L
O
W
A
G
E
N
T
O
P
E
R
A
T
I
O
N
A
L
R
e
f
e
r
t
o
m
a
n
u
a
l
b
e
f
o
r
e
u
s
e
.
C
a
l
i
b
r
a
t
e
d
f
o
r
u
s
e
a
t
f
l
o
w
s
o
f
0
.
2
t
o
1
0
L
/
m
i
n
.
a
n
d
a
t
a
m
b
i
e
n
t
t
e
m
p
e
r
a
t
u
r
e
s
o
f
1
8
C
t
o
3
0
C
a
t
1
0
1
3
m
b
.
W
a
r
n
i
n
g
H
i
g
h
v
a
p
o
r
i
z
e
r
s
e
t
t
i
n
g
s
w
i
t
h
l
o
w
g
a
s
f
l
o
w
s
m
a
y
l
e
a
d
t
o
h
y
p
o
x
i
c
m
i
x
t
u
r
e
s
w
i
t
h
i
n
t
h
e
b
r
e
a
t
h
i
n
g
c
i
r
c
u
i
t
.
O
h
m
e
d
a
s
t
r
o
n
g
l
y
r
e
c
o
m
m
e
n
d
s
t
h
e
u
s
e
o
f
o
x
y
g
e
n
m
o
n
i
t
o
r
i
n
g
.
W
arning
• Keep u
pright at all times.
• D
o not autoclave.
• N
ot fo
r use in the prescence o
f
flam
m
able anaesthetic agents.
• O
nly to be used in
conlunction
with an O
monitor.
Se
e m
anual for
• O
perational Instructions.
• Factors a
ffectin
g perform
ance.
• Service a
nd m
aintenance
recom
m
enda
tions.
N
e
x
t
s
e
r
v
i
c
e
d
a
t
e
L
o
c
k
b
e
f
o
r
e
u
s
e
1
23
4
5
6
7
8
1
0
1
2
1
4
1
6
1
8
T
e
c
6
P
lu
s
U
s
e
o
n
l
y
D
e
s
f
l
u
r
a
n
e
Tec 6 Plus vaporizer
Tec 7 vaporizer
Electrical Specifications
Current leakage
100/120 V: < 300µA
Power
Power input: 100-120 Vac, 50/60 Hz
Power cord: Length: 5 m/16.4 ft
Rating: 15A @ 120 Vac
Inlet/outlet modules (120 V)
System circuit breakers: 15A
Outlets (optional): 4 outlets on back, 3-2A,
1-3A individual breakers,
optional isolation transformer
Pneumatic Specifications
Auxiliary common gas outlet
Connector: ISO 22 mm OD and 15 mm ID
Gas supply
Pipeline input range: 240 kPa to 600 kPa/
35 psig to 88 psig
Pipeline connections: DISS-male, DISS-female,
DIN 13252, AS4059, S90-116
or NIST (ISO 5359). All fittings
available for O
2
, N2O, and Air,
and contain pipeline filter and
check valve.
Cylinder input: Pin indexed in accordance
with CGA-V-1 or DIN (nut and
gland); contains input filter and
check valve
Note: Maximum 3 cylinders;
two inboard mounted,
one outboard mounted.
Primary regulator
diaphragm minimum
burst pressure: 2758 kPa/400 psig
Primary regulator
nominal output: < 338 kPa/49 psig
Pin indexed cylinder connections
< 407 kPa/59 psig
DIN cylinder connections
O2controls
Method: Proportionate decrease of N2O
with reduction in O2pressure
Supply failure alarm: Range: 193 kPa to 221 kPa/
28 psig to 32 psig
Sounds at maximum volume
every 10 seconds
O
2
flush: Range: 25 to 75 L/min
Flowmeters
O2ranges: 0.05 to 0.95 L/min and
1 to 15 L/min;
Minimum O
2
flow:
50 mL/min ±25 mL
N
2
O ranges: 0 to 0.95 L/min and 1 to 10 L/min
Air range: 0 to 0.95 and 1 to 15 L/min
Calibration: Percent of Accuracy
full scale flow (% of flowrate)
100 ±2.5%
90 ±2.5%
80 ±2.6%
70 ±2.7%
60 ±2.9%
50 ±3.1%
40 ±3.4%
30 ±4.0%
20 ±5.0%
10 ±8.1%
Calibration conditions:* 20°C/68°F, 101.3 kPa/760 mmHg
* Different breathing circuit pressures, barometric pressures
or temperatures change flowtube accuracy.
Hypoxic guard system
Type: Mechanical Link-25
™
Range: Provides a nominal minimum
25% concentration of oxygen in
O2/N2O mixture
Materials
All materials in contact with patient breathing gases are free
of natural rubber latex.
Environmental Specifications
System operation
Temperature: 10° to 40°C/50° to 104°F
Humidity: 15 to 95% relative humidity
(non-condensing) per IEC 68-2-3
Altitude: -440 to 3565 m/
500 to 800 mmHg
System storage
Temperature: -15° to 50°C/-5° to 122°F
Humidity: 10 to 95% relative humidity
(including condensing)
per IEC 68-2-3
Altitude: -440 to 5860 m/
375 to 800 mmHg
Oxygen cell storage: -15° to 50°C/5° to 122°F
10 to 95% relative humidity
500 to 800 mmHg
Electromagnetic compatibility
Immunity: Complies with all requirements
of EN 60601-1-2
Emissions: CISPR 11 group 1 class B
Approvals: UL 2601-1,
CSA C22.2 #601.1
EN/IEC 60601-1
CE 0197
Breathing Circuit Specifications
Operational modes
Breathing circuit is circle mode only
Carbon dioxide absorbent canister
Absorbent capacity: 800 g
Integrated expiratory limb water reservoír
Ports and connectors
Exhalation: 22 mm OD ISO 15 mm
ID taper
Inhalation: 22 mm OD ISO 15 mm
ID taper
Bag port: 22 mm OD
Pressure gauge
Scale range: 0 to 10 kPa/-20 to 100 cm H20
Bag-to-Ventilator switch
Type: Bi-stable
Control: Controls ventilator and direction
of breathing gas within the circuit
Integrated Adjustable Pressure Limiting (APL) valve
Range: 0.8 to 70 cm H2O
Tactile knob indication at: 30 cm H
2
O and above
Adjustment range
of rotation: 0.8 to 30 cm H
2
O (0 to 230°)
30 to 70 cm H2O (230 to 330°)
Materials
All materials in contact with exhaled patient gases are autoclavable,
except disposable flow sensors and O2cell. (Autoclavable flow sensors optional).
All materials in contact with patient gas are free of natural rubber latex.
Breathing circuit parameters
Compliance: Bag mode: 1.82 mL/cm H2O
Mechanical mode: Automatically compensates for
compression losses within the
absorber and bellows assembly
Circuit volume: 2.7 L Vent Mode
1.2 L Bag Mode
Expiratory
resistance: P
exp
Bag Mode P
exp
Vent Mode
Flow rate Pressure drop Pressure drop
10 L/min 0.78 cm H2O 0.77 cm H2O
30 L/min 1.59 cm H
2
O 1.71 cm H2O
60 L/min 3.48 cm H
2
O 3.88 cm H2O
Note: With patient circuit and wye piece add +0.89 cm H2O
Anesthetic gas scavenging
Type Hospital system Machine connection
required
Active low flow: High vacuum 36 L/min DISS evac
(300 mmHg) @ 12 in Hg
Passive: Passive or externally 30 mm/0.5 in
attached active system M ISO taper
Active adjustable flow: > 30L/min
GE Healthcare
P.O. Box 7550
Madison, WI 53707-7550
USA
www.gehealthcare.com
For more than 100 years, healthcare providers
worldwide have relied on GE Healthcare for medical
technology, services, and productivity solutions. So
no matter what challenges your healthcare system
faces, you can always count on GE to help you
deliver the highest quality healthcare. For details,
please contact your GE representative today.
© 2005 General Electric Company – All rights reserved.
GE and GE Monogram are trademarks of
General Electric Company.
Aespire, Cardiocap, ABS, Tec, Mechanical Link-25 and
Selectatec are trademarks of Datex-Ohmeda, Inc.
Datex-Ohmeda, Inc., a General Electric company,
going to market as GE Healthcare.
AN3969-B 11/05
Loading...
