Intertek Project Code: 690 5039 10 000 7 00349
4 CUP
Coffee maker
Model Number:
169184
UPC: 681131691840
Customer Assistance
1 877 207 0923 (US)
1 877 556 0973 (Canada)
done: SP
check: HP
Thank you for purchasing this GE appliance.
In keeping with the GE ecomagination initiative, please consider the option to recycle
the packaging material and donate any appliance you are no longer using.
To read more about GE's ecomagination commitment, visit:
ge.ecomagination.com
Client: PIL (Wal*Mart)
Project: Coffee Maker 169184
Language: EN
Date: 03.04.2008
Version: 04
Page: 1 (of 9 pages)
Page 2
Intertek Project Code: 690 5039 10 000 7 00349
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to
prevent the risk of fire, electric shock, burns, or other injuries or damages.
• Read all instructions before use.
• Do not touch hot surfaces. Use handles or knobs.
• To protect against fire, electrical shock and injury to persons do not immerse cord,
plugs, or the appliance in water or other liquids.
• Close supervision is necessary when any appliance is used by or near children.
• Unplug from outlet when not in use and before cleaning. Allow it to cool before
putting on or taking off parts and before cleaning the appliance.
• Do not operate appliance with a damaged cord or plug, or after the appliance
malfunctions or has been dropped or damaged in any manner. Call our toll-
free customer assistance number for information on examination, repair, or
adjustment.
• The use of accessory attachments not recommended by the appliance
manufacturer may result in fire, electric shock or injuries to persons.
• Do not use outdoors or in a damp area.
• Do not let cord hang over edge of table or counter, or touch hot surfaces.
• Do not place on or near a hot gas or electric burner, or in a heated oven.
• To disconnect the appliance, turn control to “off”, then remove plug from wall
outlet.
• Do not use this appliance for anything other than its intended use.
• Do not touch the warming plate (8) when the coffee maker is on.
• Scalding may occur if the lid (2) is removed during the brewing cycles.
• Never leave the empty carafe (10) on the warming plate (8) when the coffee maker
is on. Otherwise the carafe (10) is liable to crack.
• Do not set a hot container on a cold surface.
• Do not use a cracked container or a container having a loose or weakened handle.
• Do not clean container with cleansers, steel wool pads, or other abrasive material.
• To reduce the risk of fire or electric shock, do not remove the bottom cover on the
appliance. No user serviceable parts inside. Call our toll-free customer assistance
number for repair.
• The container is designed for use with this appliance. It must never be used on a
range top.
done: SP
check: HP
SAVE THESE INSTRUCTIONS!
Client: PIL (Wal*Mart)
Project: Coffee Maker 169184
Language: EN
2
Date: 03.04.2008
Version: 04
Page: 2 (of 9 pages)
Page 3
Intertek Project Code: 690 5039 10 000 7 00349
IMPORTANT SAFEGUARDS
• WARNING: Hot Steam.
• CAUTION: To reduce the risk of scalding, do not open lid when coffee is brewing.
• WARNING: To Reduce the Risk of Fire or Electric Shock, Do Not Remove This Cover.
No User Serviceable Parts Inside. Call our toll – free customer service number for
repair.
• CAUTION: Risk of injury – Replace the carafe within 30 seconds while brewing.
SAVE THESE INSTRUCTIONS!
ADDITIONAL SAFEGUARDS
This appliance is for HOUSEHOLD USE ONLY.
DO NOT OPERATE APPLIANCE IF THE LINE CORD SHOWS ANY DAMAGE OR IF
APPLIANCE WORKS INTERMITTENTLY OR STOPS WORKING ENTIRELY.
EXTENSION CORDS
A short power-supply cord is to be provided to reduce the risk resulting from becoming
entangled in or tripping over a longer cord. Longer detachable power-supply cords or
extension cords are available and may be used if care is exercised in their use. If a longer
detachable power-supply cord or extension cord is used,
1) The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance, and
2) The longer cord should be arranged so that it will not drape over the countertop or
tabletop where it can be tripped over, snagged, or pulled on unintentionally
(especially by children).
done: SP
check: HP
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk
of electric shock, this plug is intended to fit into a polarized outlet only one way. If plug
does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
3
Client: PIL (Wal*Mart)
Project: Coffee Maker 169184
Language: EN
Date: 03.04.2008
Version: 04
Page: 3 (of 9 pages)
Page 4
Intertek Project Code: 690 5039 10 000 7 00349
PARTS
16
15
14
13
12
11
10
1
2
3
4
5
6
7
9
8
done: SP
check: HP
1. Water-level indicator
2. Lid
3. Drip head
4. Water tank
5. Housing
6. Cord storage
7. Power cord with plug
8. Warming plate
Client: PIL (Wal*Mart)
Project: Coffee Maker 169184
Language: EN
9. On/off switch 0/I
10. Carafe
11. Grip handle
12. Carafe lid
13. Drip stop valve
14. Filter basket
15. Permanent filter
16. Measuring spoon
4
Date: 03.04.2008
Version: 04
Page: 4 (of 9 pages)
Page 5
Intertek Project Code: 690 5039 10 000 7 00349
ILLUSTRATIONS
b
d
g
e
h
ca
f
i
done: SP
check: HP
j
Client: PIL (Wal*Mart)
Project: Coffee Maker 169184
Language: EN
5
Date: 03.04.2008
Version: 04
Page: 5 (of 9 pages)
Page 6
done: SP
Intertek Project Code: 690 5039 10 000 7 00349
OPERATION
Before first use
• Remove all packaging materials, labels and stickers from the coffee maker.
• Clean the coffee maker thoroughly before using for the first time (Cleaning).
NOTE: To remove any residues from the coffee maker fill in fresh water (to the maximum
level) and run at least 2 brewing cycles.
Using the coffee maker
Use this coffee maker to brew coffee only.
• Open the lid (2) and place the filter basket (14) in the coffee maker. Make sure the
tab of the filter basket (14) fits in the opening of the coffee maker (ill. a).
• Insert the permanent filter (15) or a number 2 cone filter into the filter basket (14)
(ill. b). Do not use the permanent filter with a paper filter as water will not flow
through the filter basket correctly.
• Add the desired amount of ground coffee into the filter (15) (ill. c). For 4 cups of
coffee add 3 to 4 measuring spoons (16) of coffee into the filter (15), according to
your taste.
• Fill the carafe (10) with the desired amount of water.
• Pour the water from the carafe (10) into the water tank (4) (ill. d). Check the water
level indicator (1) inside the water tank (4) (ill. e). Do not overfill the coffee maker.
• Close the lid (2) and place the carafe (10) on the warming plate (8) (ill. f).
• Remove the power cord from the cord storage (6) and insert the power plug (7) into
a standard 120V AC wall outlet (ill. g). Press the on/off switch 0/I (9) to turn the
coffee maker on (ill. h). The on/off switch 0/I (9) lights blue.
• This coffee maker has a pause and pour function. When removing the carafe (10)
the drip stop valve will prevent coffee from leaking onto the warming plate (8)
(ill. i).
• Hot water continues to flow into the filter basket (14) and may overflow if the
carafe (10) is not returned to the warming plate (8) within 30 seconds. Make sure
the carafe (10) is fully seated on the warming plate (8) or returned to the warming
plate (8) within 30 seconds when using the pause and pour function.
• Brewing process starts automatically. After brewing is finished, the warming plate
(8) will keep the coffee heated.
• Press the on/off switch 0/I (9) to turn the coffee maker off. Unplug the coffee maker
from the wall outlet when not in use.
• After usage store the cord in the cord storage (6).
WARNING: The coffee maker is hot during operation. Handle hot coffee carefully.
WARNING: ALWAYS TURN COFFEE MAKER OFF WHEN NOT IN USE.
check: HP
Client: PIL (Wal*Mart)
Project: Coffee Maker 169184
Language: EN
6
Date: 03.04.2008
Version: 04
Page: 6 (of 9 pages)
Page 7
Intertek Project Code: 690 5039 10 000 7 00349
CLEANING
Proper maintenance will ensure years of service from your appliance. Clean the appliance
after every use. This appliance contains no user serviceable parts and requires little
maintenance. Leave servicing or repairs to qualified personnel.
WARNING: Unplug the appliance and let it cool down completely before cleaning.
CAUTION: Do not immerse the coffee maker, or the power cord with plug (7) into water
or any liquids (ill. j). Do not use abrasive pads or alcohol.
• Remove the carafe (10), the permanent filter (15) and the filter basket (14) from the
coffee maker.
• Clean the housing (5) and warming plate (8) with a clean, damp cloth.
• Use baking soda or a mild cleaning agent to remove stains on the carafe (10). If
stains are hard to remove, fill the carafe (10) with hot water and add 2 tablespoons
of dishwasher detergent. Leave the carafe (10) with the water/detergent mixture
overnight and clean afterwards.
• Make sure all parts are completely dry after washing and before use.
• After cleaning, reassemble the coffee maker.
CAUTION: The carafe (10) is dishwasher-safe. Wash carafe (10), carafe lid (12), filter
basket (14) and permanent filter (15) in hot, soapy water. Rinse and dry.
NOTE: Do not dry the inside of the water tank (4) with a cloth, as lint may remain.
done: SP
check: HP
Client: PIL (Wal*Mart)
Project: Coffee Maker 169184
Language: EN
7
Date: 03.04.2008
Version: 04
Page: 7 (of 9 pages)
Page 8
Intertek Project Code: 690 5039 10 000 7 00349
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
Coffee leaks around
filter basket (14) /
drip stop valve (13)
overflows
Coffee maker does not
brew or heat
Water does not run
through
Water runs through too
quickly
Water not absorbed by
coffee grounds
If additional assistance is needed, please contact our Customer Assistance at
1.877.207.0923 (U.S.) or 1.877.556.0973 (Canada).
Filter basket (14) is not seated
correctly or not tightened
sufficiently
There are coffee grounds on
the edge of filter
Coffee is ground too finely.
This will clog the filter
Power cord (7) is not firmly
plugged into a power outlet
No water in the water tank (4)
The filter is blocked or coffee
grounds are too fine or
tamped down too hard
Coffee grounds too coarse Try finer coffee
Insufficient quantity of
ground coffee
Insert filter basket (14)
correctly
Clean around the filter
Clean the filter. Use
another type of coffee
Insert power plug (7) into
a power outlet
Fill the water tank (4)
Clean the filter and try
coarser coffee
Increase quantity of
ground
done: SP
check: HP
TECHNICAL DATA
Rated voltage: 120V ~60Hz
Rated current: 4.75A
Rated power input: 550W
Client: PIL (Wal*Mart)
Project: Coffee Maker 169184
Language: EN
8
Date: 03.04.2008
Version: 04
Page: 8 (of 9 pages)
Page 9
done: SP
check: HP
Intertek Project Code: 690 5039 10 000 7 00349
CUSTOMER ASSISTANCE
If you have a claim under this warranty, please call our Customer Assistance Number. For faster
service, please have the model number and product name ready for the operator to assist you. This
number can be found on the bottom of your appliance and on the front page of this manual.
Model Number: __________________ Product Name: __________________
Customer Assistance Number 1.877.207.0923 (U.S.) or 1.877.556.0973 (Canada).
Keep these numbers for future reference!
For more information, please visit us at WWW.GEHOUSEWARES.COM
Two-year limited warranty
What does your warranty cover?
• Any defect in material or workmanship.
For how long after the original purchase?
• Two years.
What will we do?
• Provide you with a new one.
• For those items still under warranty but
no longer available, WAL-MART reserves
the right to replace with a similar GE
branded product of equal or greater
value.
How do you make a warranty claim?
• Save your receipt.
• Properly pack your unit. We recommend
using the original carton and packing
materials.
• Return the product to your nearest
WAL-MART store or call Customer
Assistance at 1-877-207-0923 (U.S.)
or 1-877-556-0973 (Canada).
What does your warranty not cover?
• Parts subject to wear, including, without
limitation, glass parts, glass containers,
cutter/strainer, blades, seals, gaskets,
clutches, motor brushes, and/or agitators,
etc.
• Commercial use or any other use not
found in printed directions.
• Damage from misuse, abuse, or
neglect, including failure to clean
product regularly in accordance with
manufacturer's instructions.
is a trademark of General Electric
Company and is used under the
license by Wal-Mart Stores Inc.,
Bentonville, AR 72716
How does state law relate to this warranty?
• This warranty gives you specific legal
rights, and you may also have other
rights which vary from state to state or
province to province.
• This warranty is in lieu of any other
warranty or condition, whether express or
implied, written or oral, including, without
limitation, any statutory warranty or
condition of merchantability or fitness for
a particular purpose.
• WAL-MART, GE and the product
manufacturer expressly disclaim all
responsibility for special, incidental, and
consequential damages or losses caused
by use of this appliance. Any liability is
expressly limited to an amount equal to
the purchase price paid whether a claim,
however instituted, is based on contract,
indemnity, warranty, tort (including
negligence), strict liability, or otherwise.
Some states or provinces do not allow
this exclusion or limitation of incidental
or consequential losses, so the foregoing
disclaimer may not apply to you.
What if you encounter a problem with this
product while using it outside the country of
purchase?
• The warranty is valid only in the country of
purchase and if you follow the
claim procedure as noted.
Marketed in Canada by:
Wal-Mart Canada Corp.
1940 Argentia Road, Mississauga,
Ontario L5N1P9
warranty
Client: PIL (Wal*Mart)
Project: Coffee Maker 169184
Language: EN
Date: 03.04.2008
Version: 04
Page: 9 (of 9 pages)
Loading...
