Caller ID BedroomPhone™ with Dual-Wake Alarms User's Guide

We bring good things to life.

FCC NUMBER IS LOCATED ON THE CABINET BOTTOM

REN NUMBER IS LOCATED ON THE CABINET BOTTOM

FCC REGISTRATION INFORMATION

Your telephone equipment is registered with the Federal Communications Commission and is in compliance with parts 15 and 68, FCC Rules and Regulations.

1 Notification to the Local Telephone Company

On the bottom of this equipment is a label indicating, among other information, the FCC Registration number and Ringer Equivalence Number (REN) for the equipment. You must, upon request, provide this information to your telephone company.

The REN is useful in determining the number of devices you may connect to your telephone line and still have all of these devices ring when your telephone number is called. In most (but not all) areas, the sum of the RENs of all devices connected to one line should not exceed 5. To be certain of the number of devices you may connect to your line as determined by the REN, you should contact your local telephone company.

Notes

• This equipment may not be used on coin service provided by the telephone company.

• Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone equipment if you are on a party line. Check with your local telephone company.

• Notice must be given to the telephone company upon permanent disconnection of your telephone from your line.

2 Rights of the Telephone Company

Should your equipment cause trouble on your line which may harm the telephone network, the telephone company shall, where practicable, notify you that temporary discontinuance of service may be required. Where prior notice is not practicable and the circumstances warrant such action, the telephone company may temporarily discontinue service immediately. In case of such temporary discontinuance, the telephone company must: (1) promptly notify you of such temporary discontinuance; (2) afford you the opportunity to correct the situation; and (3) inform you of your right to bring a complaint to the Commission pursuant to procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.

The telephone company may make changes in its communications facilities, equipment, operations of procedures where such action is required in the operation of its business and not inconsistent with FCC Rules and Regulations. If these changes are expected to affect the use or performance of your telephone equipment, the telephone company must give you adequate notice, in writing, to allow you to maintain uninterrupted service.

INTERFERENCE INFORMATION

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference; and (2) This device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna (that is, the antenna for radio or television that is “receiving” the interference).

• Reorient or relocate and increase the separation between the telecommunications equipment and receiving antenna.

• Connect the telecommunications equipment into an outlet on a circuit different from that to which the receiving antenna is connected.

If these measures do not eliminate the interference, please consult your dealer or an experienced radio/television technician for additional suggestions. Also, the Federal Communications Commission has prepared a helpful booklet, “How To Identify and Resolve Radio/TV Interference Problems.” This booklet is available from the U.S. Government Printing Office, Washington, D.C. 20402. Please specify stock number 004-000-00345-4 when ordering copies.

HEARING AID COMPATIBILITY

This telephone system meets FCC standards for Hearing Aid Compatibility.

TABLE OF CONTENTS

FCC REGISTRATION INFORMATION .... 2

NTERFERENCE INFORMATION ............ 2

EARING AID COMPATIBILITY ........... 2

BEFORE YOU BEGIN .............................. 4

ARTS CHECKLIST ............................. 4

ODULAR JACK REQUIREMENTS ......... 4

DESKTOP INSTALLATION ......................... 5

OWERING UP ..................................... 6

“N

O WORRY” BATTERY BACKUP ........ 6

SETUP ................................................ 8

ETTING THE TIME AND DATE ............. 8

ETTING THE DISPLAY CONTRAST ........ 9

SETTING YOUR LOCAL AREA CODE ...... 9

ETTING THE LANGUAGE .................. 10

ETTING THE DISPLAY BACKLIGHT ...... 10

ALARM BASICS .................................. 11

ETTING THE ALARM TIME ............... 11

LARM SELECT .............................. 11

TURNING OFF THE ALARMS .............. 11

SING THE SNOOZE TIMER ............... 12

DJUSTING THE SNOOZE TIMER ........ 12

TELEPHONE BASICS ............................. 13

ETTING THE RINGER VOLUME .......... 13

ETTING THE HANDSET VOLUME ....... 13

TONE/PULSE DIALING ...................... 13

EMPORARY TONE .......................... 14

LASH ........................................... 14

REDIAL .......................................... 14

ALLER ID FEATURES .......................... 15

UMMARY SCREEN ......................... 15

RECEIVING AND STORING CALLS ........ 16

EVIEWING CALL RECORDS ............... 16

ELETING CALL RECORDS ................ 17

IALING BACK ................................ 17

IF YOU PROGRAMMED YOUR LOCAL

AREA

CODE IN THE SETUP MENU .. 17

F YOU DID NOT PROGRAM YOUR

LOCAL AREA CODE IN THE

SETUP

MENU ........................... 19

ESSAGE INDICATORS ......................... 20

MEMORY........................................... 21

TORING A NUMBER IN MEMORY ... 21

HANGING A STORED NUMBER ...... 22

ERASING A STORED NUMBER ........ 22

IALING A QUICK DIAL NUMBER .... 22

IALING STORED NUMBERS .......... 23

INSERTING A PAUSE IN THE DIALING

SEQUENCE .............................. 23

HAIN DIALING FROM MEMORY ..... 24

ROUBLESHOOTING TIPS ...................... 25

GENERAL PRODUCT CARE .................... 27

ERVICE ............................................ 27

NDEX ............................................... 28

LIMITED WARRANTY ............................ 30

WARNING: TO PREVENT FIRE

OR ELECTRICAL SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

SEE MARKING ON BOTTOM / BACK OF PRODUCT

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

THE EXCLAMATION POINT WITHIN THE TRIANGLE IS A WARNING SIGN ALERTING YOU OF IMPORTANT INSTRUCTIONS ACCOMPANYING THE PRODUCT.

THE LIGHTNING FLASH AND ARROW HEAD WITHIN THE TRIANGLE IS A WARNING SIGN ALERTING YOU OF "DANGEROUS VOLTAGE" INSIDE THE PRODUCT.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Base

AC power supply

Handset

Line cord

redial storememory

tone oper

tuv

wx yz

pq rs

jkl5mno6ghi

abc2def

abc

flash

alarm

set

alarm off

delete

vip/dial

SNOOZE

review

BEFORE YOU BEGIN

PARTS CHECKLIST

Make sure your package includes the following items:

MODULAR JACK REQUIREMENTS

You need an RJ11 type modular jack, which is the most common type of phone jack and might look like the one pictured here. If you don’t have a modular jack, call your local phone company to find out how to get one installed.

Handset cord

CAUTION: Use only the ATLINKS USA 5-2498 power supply that came with this unit. Using other power supplies may damage the unit.

DESKTOP INSTALLATION

1. Plug the handset cord into the handset. Plug the other end into the jack on the back of the

base.

2. Place the handset in the base.

3. Set the TONE/PULSE switch on the side of the handset to TONE for touch-tone service, or

PULSE for rotary service. If you don't know which type of service you have, check with the phone company.

4. Plug the telephone line cord into the PHONE LINE jack on the back of the base. Plug the

other end into a modular wall jack.

5. Plug the power supply cord into the back of the base. Plug the other end into an AC outlet.

6. Set the RINGER and DISPLAY switches on the side of the base to the desired settings.

7. Set the VOL switch on the side of the handset to the desired setting.

“NO WORRY” BATTERY BACKUP

This clock phone is equipped with a memory holding system that can be powered with a customer-installed 9-volt alkaline battery (not included).

When power is interrupted, or AC line cord is unplugged, the battery will power the clock to keep track of time and alarm settings programmed into memory. When on battery power, the digital display will not light; however, should wake time occur during the power interruption, the alarm will sound if remaining battery power is adequate. Normal operation will resume after AC power is restored.

Install battery as follows:

1. Remove the battery cover located on the bottom of

the base.

2. Connect a fresh 9-volt alkaline battery (not included).

The large and small contacts on the battery clip and the battery will interlock. Once connected, place the battery inside the battery compartment.

3. Replace the battery cover.

POWERING UP

Battery clip

Battery

Battery compartment

NOTE: Alkaline (NEDA 1604A) batteries are recommended. Carbon-zinc (NEDA 1604) batteries may be used but memory holding time will be substantially reduced. Memory holding time for a fresh alkaline battery is approximately 8 hours (if Wake System is not activated), which should take care of short, nuisance-type AC power failures. To preserve battery life, the phone should remain plugged into an AC outlet. As the battery gets older, its voltage will drop and memory may be lost. Be sure to replace the battery periodically. Battery is not included with this clock phone. All memory will be lost if the battery is not installed while the unit is unplugged for more than 60 seconds

IMPORTANT: If storing this unit for more than 30 days, remove the battery.

SETUP

SETTING THE TIME AND DATE

NOTE: The telephone company sends the time and date with the Caller ID information. The unit automatically sets the time and date when the first call is received (if it has not already been set).

TIME

1. Press and release the SET button until

SET REAL

TIME

is displayed.

2. Use the REVIEW buttons to adjust the time. The hours

automatically change when the minutes go higher than 59 or lower than 00.

3. When finished, press SET to confirm. Now you’re

ready to enter the month.

MONTH

1. Use the REVIEW buttons to set the month.

2. When finished, press SET to confirm. Now you’re

ready to change the day.

DAY

1. Use the REVIEW buttons to set the day.

2. When finished, press SET to confirm.

alarm

set

alarm off

delete

vip/dial

SNOOZE

review

SET button REVIEW buttons

SETTING THE DISPLAY CONTRAST

This setting allows you to adjust the display contrast for easier viewing.

1. Press and release the SET button until

SET

CONTRAST

is displayed.

2. Use the REVIEW buttons to select the desired setting

(1-5).

3. When finished, press SET to confirm.

SETTING YOUR LOCAL AREA CODE

1. Press and release the SET button until

SET AREA

CODE

is displayed.

2. Use the REVIEW buttons to select the first digit.

3. Once the first digit is set, press SET.

4. Repeat steps 2-3 until all the digits of the area code

are set.

When finished, press SET to confirm.

alarm

set

alarm off

delete

vip/dial

SNOOZE

review

SET button REVIEW buttons

SETTING THE LANGUAGE

This adjustment changes the prompts to be displayed in English, French, or Spanish.

1. Press and hold the SET button until

SET LANGUAGE

is displayed.

2. Use the REVIEW buttons to select the desired

language.

3. When finished, press SET to confirm.

SETTING THE DISPLAY BACKLIGHT

Set the DISPLAY switch on the side of the base to adjust the backlighting when the unit is plugged into an AC outlet. It can be set to LO or HI.

alarm

set

alarm off

delete

vip/dial

SNOOZE

review

SET button REVIEW buttons

DISPLAY switch

display lo hi

ringer off lo hi

ALARM BASICS

SETTING THE ALARM TIME

1. Press the SET button.

2. Press ALARM 1 or ALARM 2.

3. Use the REVIEW buttons to set the wake time.

4. Press SET to confirm.

ALARM SELECT

1. Press the ALARM 1 or ALARM 2 button to review the

setting.

2. Press and release the desired ALARM button to

choose music, buzzer, or off.

TURNING OFF THE ALARMS

To turn off an alarm after it has come on, press the ALARM OFF button. The alarm setting will remain and come on the next day.

alarm

set

alarm off

delete

vip/dial

SNOOZE

review

SET button

REVIEW buttons

ALARM 1 button

ALARM 2 button

ALARM OFF button

USING THE SNOOZE TIMER

After the wake mode has activated, you can silence it for another 9 minutes by pressing the SNOOZE button.

You can use the SNOOZE feature repeatedly. The alarm will remain on for 30 minutes if SNOOZE is not pressed.

ADJUSTING THE SNOOZE TIMER

1. To set the snooze timer to the desired setting, press

SET and then SNOOZE .

2. Use the REVIEW buttons to set the snooze time.

3. When finished, press SET to confirm.

alarm

set

alarm off

delete

vip/dial

SNOOZE

review

SET button

REVIEW buttons

SNOOZE button

TELEPHONE BASICS

SETTING THE RINGER VOLUME

The RINGER switch is located on the side of the base. Set it to the HI, LO, or OFF.

Remember that the RINGER switch must be set to HI or LO or the phone will not ring for incoming calls.

SETTING THE HANDSET VOLUME

Use the VOL switch on the side of the handset to adjust the handset volume.

TONE/PULSE DIALING

Set the TONE/PULSE switch on the side of the handset to TONE if you have touch-tone service or PULSE for rotary service.

RINGER switch

redial storememory

tone oper

tuv

wx yz

pq rs

jkl5mno

ghi

abc2def

abc

flash

TONE/PULSE switch

VOLUME switch

display lo hi

ringer off lo hi

TEMPORARY TONE

Use the temporary tone feature if you have pulse (rotary) service, and want to access custom calling services that require touch-tone dialing, such as getting information from a local bank or credit card company.

1. Dial the number for the custom calling service.

2. Press the TONE button after you have connected to

the service to enable touch-tone dialing.

3. When you hang up, the phone automatically returns

to pulse dialing mode.

FLASH

Press the FLASH button instead of using the hook switch to activate customer calling services such as call waiting or call transfer, which are provided by your local phone company.

REDIAL

Redial the last number you called by pressing the REDIAL button after you get a dial tone.

NOTE: The Redial feature holds in memory the last phone number you dialed (as many as 32 digits). If you pressed any numbers after dialing the phone number, (for example, when accessing a voice-menu system) those numbers also are redialed.

redial storememory

tone oper

tuv

wx yz

pq rs

jkl5mno

ghi

abc2def

abc

flash

FLASH button

TONE button

REDIAL button

CALLER ID FEATURES

The unit receives and displays information transmitted by your local phone company. This information can include the phone number, date, and time; or the name, phone number, date, and time. The unit can store up to 99 calls for later review.

VERY IMPORTANT: The Caller ID feature of this product requires a subscription to Caller ID service from your telephone company.

SUMMARY SCREEN

The summary screen shows the current time, current date and number of new calls to be reviewed. It is displayed until any button is pressed. Within 10 seconds of receiving a new call, the summary screen is displayed and the

NEW CALL

indicator comes on.

NOTE: Check with your local phone company regarding name service availability.

RECEIVING AND STORING CALLS

This unit receives and displays information transmitted by your local phone company. This information can include the phone number, date, and time; or the name, phone number, date, and time. The unit can store up to 99 calls for later review. When the memory is full, a new call automatically replaces the oldest call in memory.

NEW

will appear in the display for calls received that

have not been reviewed.

REVIEWING CALL RECORDS

• Use the REVIEW buttons to view the newest call

record.

• Press the REVIEW down arrow to scroll through the

call records from the most recent to the oldest.

• Press the REVIEW up arrow to scroll through the call

records from the oldest to the newest.

• When all of the records have been viewed,

START/

END

appears in the display.

alarm

set

alarm off

delete

vip/dial

SNOOZE

review

REVIEW buttons

DELETING CALL RECORDS

• To delete the record shown in the display, press the

DELETE button once.

• To delete all records while reviewing, press and hold

the DELETE button.

DELETE ALL?

appears in the

display. Press DELETE again to complete.

DIALING BACK

When reviewing Caller ID records, you can dialback the numbers shown on the display by pressing the DIAL button.

IF YOU PROGRAMMED YOUR LOCAL AREA

CODE IN THE SETUP MENU

1. Use the REVIEW buttons to display the number you

want to dial.

• If you see a number with 7 digits (i.e. 555-1234), then

the call was received from within your area code. However, this does not guarantee the call is a local call.

• If you see a number with 11 digits (i.e. 1-234-555-1234),

then the call received was not from your area code.

alarm

set

alarm off

delete

vip/dial

SNOOZE

review

DELETE button

REVIEW buttons

DIAL button

2. Press the DIAL button and the display shows

PICKUP

or ADJ

. You have 10 seconds to adjust the number and pickup the handset to dial, otherwise the unit returns to the currently reviewed call.

3. To adjust the phone number, press the DIAL button. Press the DIAL button repeatedly to scroll through the 7, 8,10, and 11-digit numbers.

7-digits:

7-digit telephone number (i.e. 555-5555)

8-digits:

long distance 1+ 7-digit telephone number (i.e. 1-555-5555)

10-digits:

3-digit area code + 7-digit telephone number (i.e. 425-555-5555)

11-digits:

long distance code 1 + 3-digit area code + 7-digit telephone number (i.e. 1-425-555-5555)

4. To dial the displayed number, pick up the handset within 10 seconds.

NOW DIALING

shows in the

display and the number is dialed.

alarm

set

alarm off

delete

vip/dial

SNOOZE

review

DIAL button

+ 42 hidden pages

GE 29292 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
