Page 1
Model number:
28522
DECT 6.0 CORDLESS TELEPHONE
Page 2
Thank you for choosing GE!
Register your product
Please take a moment to register your product online. Just go
to www.gephones.com and click “register here” from the home
page. Provide your email address and receive product updates,
special oers, or discounts on future purchases.
* It will not diminish your warranty rights if you choose not to register.
Assistance and more information
Retain your sales receipt as proof of purchase in the event
warranty service is necessary.
For product assistance or for more information about
accessories, visit our website at www.gephones.com or call our
customer service center at 1-877-394-9775.
Attach your sales receipt here.
Page 3
Table of contents
Getting started
Parts checklist ................................................ 1
Telephone base and charger
installation ....................................................2
Telephone jack requirements .................2
Battery installation.......................................3
Battery charging ........................................... 4
Telephone base layout ...............................5
Handset layout ..............................................6
Screen display icon ...................................... 7
Settings
Dialing mode...................................................8
Programming your area code
(optional) .......................................................8
Reset ................................................................... 8
Registering a handset ................................9
Deregistering a handset ............................ 9
Handset options
Handset name ............................................ 10
Ringer volume ............................................. 10
Ringer tone ................................................... 11
Key tone ......................................................... 11
Display language ....................................... 12
Clock and alarm
Date and time ............................................. 13
Date format .................................................. 13
Time format .................................................. 13
Alarm ............................................................... 14
Alarm melody .............................................. 14
Telephone operation
Make a call .................................................... 15
Predial a call .................................................15
Answer a call ............................................... 15
End a call ....................................................... 15
Speakerphone .............................................15
Volume control ...........................................15
Make a call using the redial
memory ...................................................... 16
Save a number from the redial list to
the phonebook ........................................ 16
Delete a number from the redial
list .................................................................. 16
Mute ................................................................. 16
Call waiting or call waiting with
caller ID service ....................................... 17
Voice mail service ...................................... 17
Using multiple handsets .........................17
Handset locator ......................................... 17
Intercom (for systems with multiple
handsets) ................................................... 18
To answer an incoming call during
intercom ..................................................... 18
To initiate an intercom during a
call ................................................................. 18
Phonebook
Add a phonebook entry .......................... 20
Character table .......................................... 20
To view/call a phonebook entry ......... 21
To search a phonebook entry
alphabetically .......................................... 21
Chain dialing ................................................ 21
Edit a phonebook entry .......................... 22
Delete phonebook entry ......................... 22
Caller ID
Phonebook Caller-ID matching ...........23
Using Caller ID service ............................ 23
Calling from the call log ..........................23
Save a number to the phonebook .....24
Delete caller ID record .............................24
Call log display screen messages ...... 24
Answering system
Telephone base volume .........................25
Outgoing Announcement (OGA) ......... 25
Page 4
Record an outgoing announcement
(OGA) ............................................................ 26
Number of rings before the system
answers ...................................................... 27
Turning the answering system
on/o from a handset..........................27
Call screening .............................................27
Message playback using the
telephone base ....................................... 28
Options during playback ........................28
Message playback using the
handset ....................................................... 28
Delete all messages using the
handset ....................................................... 29
Recording a memo ................................... 29
Security code for remote access........29
Access the answering system
remotely ..................................................... 30
Remote access commands .................. 30
Appendix
Troubleshooting guide ............................ 31
General Product Care .............................. 33
Important Safety Instructions ............. 34
FCC Parts 15, 68 and ACTA ....................38
One Year Limited Warranty .................. 41
Index ................................................................ 43
Remote access operation card ...........45
Page 5
1
Getting started
Parts checklist
Your telephone contains the following items. Save your sales receipt and
original packaging in the event warranty service is necessary.
Charger with adapter
(1 for 28522XE2
2 for 28522XE3
3 for 28522XE4)
Handset
(1 for 28522XE1
2 for 28522XE2
3 for 28522XE3
4 for 28522XE4)
Battery
compartment cover
(1 for 28522XE1
2 for 28522XE2
3 for 28522XE3
4 for 28522XE4)
Battery
(1 for 28522XE1
2 for 28522XE2
3 for 28522XE3
4 for 28522XE4)
Telephone line cord
Telephone base
User’s guide
digital answering system
Model number:
28522
DECT 6.0 CORDLESS TELEPHONE
Page 6
Getting started
2
Telephone base and charger installation
Plug in the telephone line cord and the power adapter as shown below. Make
sure that the electrical outlet is not controlled by a wall switch.
Telephone jack requirements
To use this phone, you need a RJ11C type modular telephone jack, which
might look like the one pictured here, installed in your home. If you do not have
a modular jack, call your local phone company to nd out how to have one
installed.
If you have DSL high speed Internet service, a DSL lter is required (not
included). Contact your DSL service provider for more information about DSL
lter.
DSL lter (not
included) is
required if you
have DSL high
speed Internet
service.
Telephone base installation
Charger
installation
CAUTION:
1. Use only the power adaptor that came with this unit. Using other power adaptors may
damage the unit.
2. To prevent re or electrical shock hazard, do not expose this product to rain or moisture.
Route the cords
through the
tabbed slot.
Page 7
Getting started
3
Battery installation
CAUTION:
1. To reduce the risk of re or personal injury, use only the battery supplied with this product.
2. If the handset will not be used for an extended period of time, unplug the battery and remove
it from the handset to prevent possible leakage.
Please fully charge your handset before use!
For optimum battery performance, charge the battery for 16 hours before rst
use.
NOTE: Use only the supplied rechargeable battery or replacement battery. Visit our website at
www.gephones.com to order a replacement battery if necessary.
1. Plug the battery connector securely into
the socket inside the handset battery
compartment. Make sure that red and
black wires on the plug are properly
inserted into the socket as shown.
2. Place the battery
and the wire
inside the battery
compartment.
red
wire
black
wire
4. Place the handset onto the base (or charger) as
shown. An animated battery icon will display after
a few minutes to show that the handset battery
is successfully being charged. For optimum
performance, please allow the battery to charge
for 16 hours before rst use.
3. Align the cover
against the battery
compartment and
slide it upwards until it
clicks into place.
Animated
charging
indicator
Page 8
Getting started
4
Battery charging
The following table summarizes the battery charge indicators and what actions
need to be taken.
Battery
indicators
Battery status Action
Battery icon is
scrolling.
Battery is charging. Keep the handset in the telephone base or
charger when not in use.
Battery icon is
on steadily.
Battery is completely
charged.
The handset is ready for use.
It will take approximately 2 hours for the
battery icon to indicate a full charge even
if the handset is only removed from the
telephone base or charger for a short time
and replaced. This is a normal operation
and does not indicate a battery issue.
Battery icon is
empty and the
screen shows
LOW BATTERY.
Battery is low. Place the handset in the telephone base or
charger to charge without interruption (at
least 30 minutes) before use.
The screen is
blank.
Battery has no power
while the handset is out
of the telephone base
or charger.
Place the handset in the telephone base
or charger for at least 16 hours without
interruption. See troubleshooting on page
31 for help if the screen remains blank
after charging.
The screen
shows INITIAL.
Battery power is not
enough to power
up the handset, or
the battery is not
connected to the
handset while the
handset is put in the
telephone base or
charger.
Place the handset in the telephone base or
charger to charge without interruption (at
least 30 minutes) before use.
Make sure the battery is securely connected
to the handset (refer to page 3).
Page 9
Getting started
5
Telephone base layout
Volume down
Press to decrease the volume
during playback or call
screening.
Volume up
Press to increase the volume
during playback or call
screening.
Play/Stop
Press to play messages or stop
playback.
Indicates status of the
answering system. Refer to the
table below for details.
Forward
Press to skip to the next
message.
Memo
Press and hold until you hear a
beep sound, then start recording
a memo, press again to stop.
Answer on/o
Press to turn the answering
system on or o.
Find
Press to page all system
handsets.
Repeat
Press to repeat a message
or press twice to play the
previous message.
Delete
Press to delete the message
during playback, or press
and hold to delete all old
messages.
digital answering system
Answering system status
Glows blue Answering system is ON.
No light Answering system is OFF.
Flashes slowly There are new messages.
Flashes rapidly Message capacity is full.
Annc.
Press and hold until you hear a
beep sound, then start recording an
outgoing announcement message,
press again stop.
Page 10
Getting started
6
Handset layout
• Press to review the call
log when the telephone
is not in use.
• While in menu, press to
scroll up.
• During a call, press
to increase the incoming
volume.
ok
Press to select an item, or to
save an entry or setting.
• Press to make or answer
a call.
• During a call, press to
answer an incoming
call if you receive a call
waiting alert (if you
have subscribed to the
call waiting feature
from your service
provider).
menu
Press to show menu.
• Press to change the
telephone number format
(7 digits, 1+, or 1+ area
code) for appropriate
dialing.
Press to mute a call, press again to
resume normal conversation.
• Press to review the
phonebook when the
telephone is not in use.
• While in menu, press to
scroll down.
• During a call, press to
decrease the incoming
volume.
del
• Press to delete the last number or letter
entered.
• While in menu, press to return to the
previous level without making changes.
• During a call, press to
hang up.
• During programming,
press to cancel and exit
without making changes.
redial
Press to review redial list.
• Press to make or
answer a call using the
speakerphone.
• During a call, press to
switch between
speakerphone and normal
handset use.
Press and hold to turn the
ringer o.
int
Press to initiate
an intercom
call or transfer
a call.
Page 11
Getting started
7
Screen display icon
Item Meaning
• Displays when the telephone base is within reception
range.
• Flashes when the telephone base is out of range.
• Displays during review of the phonebook.
• Scrolls to indicate battery charging when handset is in
the telephone base or charger.
• Displays two bars when fully charged.
• Displays one bar when partially charged (out of
telephone base or charger).
• Flashes and empty when battery level is low.
• Flashes when there is an incoming call.
• Displays during a call.
• Flashes when there is a new voice mail message.
(Available only if you have subscribed to voice mail
service from your telephone service provider.)
• Displays when the alarm is set.
• Displays when the ringer is turned o.
• Displays during review of the call log and when there is a
new record in the call log.
• Displays when answering system is on.
• Flashes when there is a new message or when the
answering system is full.
Page 12
8
Settings
Dialing mode
The default dialing mode is TONE for touch tone dialing. If you have pulse or
rotary service, you can change this setting to accommodate your telephone line
service.
1. Press menu.
2. Press / to select SETTINGS and then
press ok.
3. Press / to select DIALING MODE and then
press ok.
4. Press / to select the desired setting and then
press ok to conrm.
Programming your area code (optional)
If you program your area code, the caller ID history displays only seven digits of
the telephone numbers from your area code.
To set the area code:
1. Press menu.
2. Press / to select SETTINGS and then press ok.
3. Press / to select AREA CODE and then press ok.
4. Enter your 3-digit area code and then press ok to
conrm.
Reset
This feature allows you to restore all system settings, except the phonebook, to
default settings. This feature could be useful, for example, if you have forgotten
the security code to access the answering system remotely.
1. Press menu.
2. Press / to select SETTINGS and then press ok.
3. Press / to select RESET and then press ok.
4. Press ok again to conrm.
NOTE: All settings under the ANS. SYSTEM, CLOCK&ALARM, HANDSET OPTS and
SETTINGS menus in the handset will be restored to default settings; the redial list
and call log will also be cleared.
SETTINGS
RESET
RESET
CONFIRM?
SETTINGS
AREA CODE
AREA CODE
_
DIALING MODE
TONE
SETTINGS
DIALING MODE
Page 13
Settings
9
Registering a handset
The telephone system can support up to a total of 4 cordless handsets.
Handsets that were included with your main base are pre-registered. To add or
re-register a handset:
1. Press ok when the handset screen shows PRESS OK KEY
TO REGISTER.
-OR-
Press menu. Select SETTINGS by pressing / and
then press ok twice to enter REGISTRATION.
2. The handset will show HOLD FIND KEY FOR 5SEC.
3. Press and hold the button on the telephone base for 5
seconds. The button will ash.
A beep sounds on the handset when the registration is successful.
NOTES:
1. An error tone will sound if the registration is not successful.
2. This product is compatible with model 28502 accessory handsets only. For information on how to
purchase accessory handsets, please visit our website at www.gephones.com
Deregistering a handset
This feature is intended for base replacement procedures. Handset
deregistration is not recommended for normally functioning systems. For more
information concerning deregistration, visit us online at www.gephones.com
1. Press menu.
2. Press / to select SETTINGS and then press ok.
3. Press / to select DEREGISTER and then press ok.
4. Press / to select the desired handset and then
press ok to conrm.
SETTINGS
REGISTRATION
HOLD FIND
KEY FOR 5SEC
MAIN MENU
SETTINGS
SETTINGS
DEREGISTER
Page 14
10
Handset options
Handset name
Your handsets will be automatically numbered from 1 to 4 depending on
the number of handsets registered to your base unit. You can rename your
handsets for easier identication (e.g. “Kitchen”, “Bedroom”, “Pams room”, etc).
To personalize each handset with a name:
1. Press menu.
2. Press / to select HANDSET OPTS and then press
ok.
3. Press ok again to select HANDSET NAME.
4. Press del to erase each letter of the current name.
5. Enter your desired handset name (up to 10 characters).
Press the key to the corresponding character to display
the correct letter. See the character table on page 20
for more information.
6. Press ok to conrm.
Ringer volume
1. Press menu.
2. Press / to select HANDSET OPTS and then press
ok.
3. Press / to select RINGER&TONES and then
press ok.
4. Press ok again to select RING VOLUME.
5. Press / to select the desired setting and then
press ok to conrm.
NOTE: Press and hold the key to switch the ringer between on and o when the
handset is in idle mode. RINGER OFF and the icon display on the screen when
ringer o feature is activated
HANDSET OPTS
HANDSET NAME
HANDSET NAME
_
HANDSET OPTS
RINGER&TONES
RINGER&TONES
RING VOLUME
Page 15
Handset options
11
Ringer tone
You can select from 10 ringer tones.
1. Press menu.
2. Press / to select HANDSET OPTS and then press
ok.
3. Press / to select RINGER&TONES and then press
ok.
4. Press / to select RING TONE and then press ok.
5. Press / to select the desired setting (RINGER 1
to 10) and then press ok to conrm.
Key tone
The handset can be programmed to emit a tone with each key press. You can
choose to turn this feature on or o. The default setting is ON. To change the
key tone setting:
1. Press menu.
2. Press / to select HANDSET OPTS and then press
ok.
3. Press / to select RINGER&TONES and then
press ok.
4. Press / to select KEY TONE and then press ok.
5. Press / to select ON or OFF and then press ok
to conrm.
HANDSET OPTS
RINGER&TONES
RINGER&TONES
RING TONE
HANDSET OPTS
RINGER&TONES
RINGER&TONES
KEY TONE
KEY TONE
ON
Page 16
Handset options
12
Display language
You can select ENGLISH, ESPAÑOL or FRANCIS as the display language. The
default setting is ENGLISH. To change the display language:
1. Press menu.
2. Press / to select HANDSET OPTS and then press
ok.
3. Press / to select LANGUAGE and then press ok.
4. Press / to select the desired setting and then
press ok to conrm.
MAIN MENU
HANDSET OPTS
HANDSET OPTS
LANGUAGE
Page 17
13
Clock and alarm
Date and time
You can set the date and time of the telephone system as follows.
1. Press menu.
2. Press / to select CLOCK&ALARM and then
press ok.
3. Press ok again to select DATE & TIME.
4. Enter the current year, month and day. For example, May
16, 2010 should be entered as [1], [0], [0], [5], [1], [6].
5. Press ok to conrm.
6. Enter the current hour and minute. For example, 9:30
should be entered as [0], [9], [3], [0]. Press / to
select am or pm and then press ok to conrm.
Date format
The display format of date can either be selected as Month/Day or Day/Month.
The default setting is Month/Day. To change your setting:
1. Press menu.
2. Press / to select CLOCK&ALARM and then press
ok.
3. Press / to select SET FORMAT and then press ok.
4. Press / to select DATE FORMAT and then
press ok.
5. Press / to select the desired setting (MM/DD
or DD/MM) and then press ok to conrm.
Time format
The display format of time can either be selected as 12 hour or 24 hour. The
default setting is 12 hour. To change your setting:
1. Press menu.
2. Press / to select CLOCK&ALARM and then press
ok.
3. Press / to select SET FORMAT and then press ok.
4. Press ok again to select TIME FORMAT.
5. Press / to select the desired setting (12 HOUR or
24 HOUR) and then press ok to conrm.
CLOCK&ALARM
SET FORMAT
SET FORMAT
DATE FORMAT
MAIN MENU
CLOCK&ALARM
CLOCK&ALARM
DATE & TIME
CLOCK&ALARM
SET FORMAT
SET FORMAT
TIME FORMAT
Page 18
Clock and alarm
14
Alarm
The alarm can be programmed to sound once or daily for one minute. The
alarm setting is independent to each handset.
1. Press menu.
2. Press / to select CLOCK&ALARM and then
press ok.
3. Press / to select ALARM and then press ok.
4. Press / to select the desired alarm option and
then press ok.
OFF: The alarm is o (go to step 6).
ONCE: The alarm sounds once at the set time.
DAILY: The alarm sounds daily at the set time.
5. Enter the desired hour and minute and then press / to select am or
pm.
6. Press ok to conrm.
Alarm melody
You can select from 3 alarm melodies
1. Press menu.
2. Press / to select CLOCK&ALARM and then press
ok.
3. Press / to select ALARM MELODY and then press
ok.
4. Press / to select the desired alarm tone and
then press ok to conrm.
NOTE: Press ok or to turn o the alarm when it rings.
CLOCK&ALARM
ALARM
ALARM
ONCE
CLOCK&ALARM
ALARM MELODY
ALARM MELODY
MELODY 1
Page 19
15
Telephone operation
Make a call
1. Press or .
2. Dial the phone number after you hear the dial tone.
Predial a call
1. Dial the phone number using the dial pad keys. If you make an error while
dialing, you can press del to erase the last digit entered.
2. Press or to dial.
Answer a call
Press or to answer an incoming call.
When there is an incoming call, the screen and dial pad backlight will be on.
NOTE: The screen shows the elapsed time as you talk (in hours, minutes and seconds).
End a call
Press or place the handset in the telephone base or charger to end a call.
Speakerphone
During a call, press to switch between speakerphone and normal handset
use. When the speakerphone is active, the handset screen shows SPKR.
NOTE: Using the speakerphone will drain the battery faster than the normal handset use.
Volume control
You can adjust the volume of the handset or speakerphone anytime during a
call.
On the handset, press to increase or to decrease the volume.
NOTE: Only the listening volume can be adjusted.
Page 20
Telephone operation
16
Make a call using the redial memory
The last ve telephone numbers previously dialed are stored in the redial list (up
to 24 digits each).
1. Press redial.
2. Press / to select the desired phone number and then press
or to dial.
Save a number from the redial list to the phonebook
1. Press redial.
2. Press / to select the desired phone number and then press menu.
3. Press ok to select SAVE NUMBER.
4. Enter the name by using the dial pad, and then press ok to save.
Delete a number from the redial list
1. Press redial.
2. Press / to select the desired phone number and then press menu.
3. Press / to select DELETE to remove the selected number, or select
DELETE ALL to remove all numbers in the redial list.
4. Press ok twice to conrm.
Mute
The mute function allows you to turn o the microphone while on a call. You can
hear the other party but the other party cannot hear you.
1. Press during a call.
2. Press again to resume conversation.
NOTE: The screen shows MUTE ON when mute feature is activated.
Page 21
Telephone operation
17
Call waiting or call waiting with caller ID service
To use call waiting, you must subscribe to call waiting service from your
telephone service provider. This feature allows you to receive calls while you are
already talking on the phone. You will hear a call waiting alert tone when there
is a second incoming call. If you subscribe to both caller ID and call waiting with
caller ID services, the second caller’s information is displayed after you hear the
call waiting alert tone.
1. Press to answer the second incoming call.
2. Press to switch between calls.
Voice mail service
The icon ashes on the screen when you have received a new voice mail
message from your service provider.
IMPORTANT: Voice mail service is dierent from the answering system. In order to use the voice mail
service, you must subscribe to it from your telephone service provider.
Using multiple handsets
The system allows a maximum of two handsets to have a conversation with an
outside call at a time. If a handset is already on a call and you would like to join
the call, press or on another handset.
The call will not be terminated until all handsets hang up.
Handset locator
You can locate a misplaced handset by paging it.
1. Press on the telephone base. All registered handsets beep for one
minute.
2. Press on the telephone base or press on any handset to stop paging.
Page 22
Telephone operation
18
Intercom (for systems with multiple handsets)
The system allows an intercom call between two handsets registered to the
same telephone base.
To initiate an intercom call:
1. Press int.
• If your telephone system has only two handsets registered, the intercom
call will be automatically directed to the other system handset.
• If your telephone system has more than two handsets registered,
enter the handset number you want to call by using the dial pad 1 – 4.
• You can page all handsets by pressing .
2. Press or to answer the intercom call on the other handset.
3. To end the intercom call, press .
NOTES:
1) The intercom call can be canceled before it is answered by pressing or int on the originating
handset.
2) If the handset being called does not answer within one minute, the paging will be canceled.
To answer an incoming call during intercom
You will hear an alert tone when you receive an incoming call during intercom.
• Press to answer the incoming call and end the intercom.
• Press int to answer the incoming call and put the intercom on hold. Press
and hold to switch between intercom and the incoming call.
• Press and hold int to conference with both the incoming call and the
intercom.
To initiate an intercom during a call
You can intercom with another system handset during a call, or invite another
system handset to join.
1. Press int during a call.
• If your telephone system has only two handsets registered, the intercom
call will be automatically directed to the other system handset.
• If your telephone system has more than two handsets registered,
you will need to enter the handset number you want to intercom to
by using the dial pad 1 – 4.
• You can page all handset(s) by pressing .
The call is placed on hold while the intercom is established with the other
handset.
Page 23
Telephone operation
19
2. Press or to answer the intercom on the other handset.
NOTE: The intercom call can be canceled before it is answered by pressing int on the originating handset.
3. You can choose from one of the following options for this intercom call.
• Press and hold int to connect both handsets to the call.
• Press and hold on the originating handset to alternate between
the intercom and the call.
• Press on either handset to terminate the intercom on that handset. The
call will continue on the other handset.
Page 24
20
Phonebook
Add a phonebook entry
1. Press menu.
2. Press / to select PHONEBOOK and then press
ok.
3. Press ok again to select NEW ENTRY.
4. Enter the name (max. 12 character). Press the key to the
corresponding character to display the correct letter. See
the character table below for more information.
5. Press ok.
6. Enter the number (max. 24 digits). If you need a pause
between digits, press and hold the until a P appears
in the display. This will insert a 3 second pause in the
dialing sequence.
7. Press ok to save the new entry.
NOTE: The phonebook entries are independent to each handset. Entries stored in
a handset cannot be viewed in another system handset. Each handset holds 30
phonebook entries.
Character table
Use the dial pad and the chart below to enter a name (up to 12 characters).
Each press of a particular key displays the character in the following order:
Dial pad
key
Character by number of key presses
1 2 3 4 5 6
[1] space 1 _ < > *
[2] A B C 2
[3] D E F 3
[4] G H I 4
[5] J K L 5
[6] M N O 6
[7] P Q R S 7
[8] T U V 8 ?
[9] W X Y Z 9
[0] 0 - / ||| # +
NOTE: Press del to correct an error.
MAIN MENU
PHONEBOOK
PHONEBOOK
NEW ENTRY
ADD NAME
_
ADD NUMBER
_
Page 25
Phonebook
21
To view/call a phonebook entry
Records are stored alphabetically in the phonebook. To search the phonebook:
1. Press when handset is not in use.
NOTE: You can also access the phonebook by pressing menu and selecting PHONEBOOK.
2. Press / to nd an entry.
3. Press or to call the displayed entry.
To search a phonebook entry alphabetically
1. Press when the handset is not use.
2. Press the dial pad key (0-9) that corresponds to the rst letter of the entry
you are looking for. The closest match in alphabetical order will appear. You
can then press / to view the next entry.
3. Press ok to view the phone number.
-OR-
4. Press or to call the displayed entry.
Chain dialing
This feature allows you to initiate a dialing sequence from numbers stored in the
phonebook while you are on a call. This feature is useful if you wish to access
another numbers (such as bank account information or access code) from the
phonebook.
To access a number in the phonebook while on a call:
1. Press menu and the phonebook will display.
2. Press / to locate the desired entry.
3. Press to dial the number.
Page 26
Phonebook
22
Edit a phonebook entry
1. Press when the handset is not in use.
2. Press / to locate a desired entry and then press
menu.
3. Press / to select EDIT ENTRY and then press ok.
4. Edit the name by using the del key to erase and backspace, then enter new
characters using the dial pad keys and press ok.
5. Edit the number by using the del key to erase and backspace, then enter
new numbers using the dial pad keys and press ok.
Delete phonebook entry
1. Press when the handset is not in use.
2. Press / to locate a desired entry and then press
menu.
3. Press / to select DELETE to delete the selected
entry, or select DELETE ALL to delete all entries.
4. Press ok twice to conrm.
PHONEBOOK
DELETE
PHONEBOOK
EDIT ENTRY
PHONEBOOK
DELETE ALL
- OR -
Page 27
23
Caller ID
Phonebook Caller-ID matching
If the last seven digits of an incoming telephone number match a telephone
number in your phonebook, the name from this entry will display on the screen.
For example, if Michael Jones calls, and his number is saved in the phonebook
under the name MIKE, the screen displays the name MIKE.
NOTE: The number you see on your caller ID is in the format sent by the telephone service provider. It
usually delivers 10-digit telephone numbers (area code plus telephone number). If the last seven digits of
the incoming telephone number do not match with a number in your phonebook, the name appears as it
is delivered by the telephone service provider.
Using Caller ID service
IMPORTANT: To use the Caller-ID capabilities of this telephone system, you
must subscribe to Caller-ID services from your service provider. Check with your
telephone service provider for details.
Caller ID records are stored in the order that they are received.
Your telephone stores caller ID memory for the 30 most recent calls. When
the 31th call is received, the oldest Caller ID record (rst call) is automatically
deleted.
Calling from the call log
As calls are received and stored, the display is updated to let you know new
calls have been received. To scroll through the caller ID records:
1. Press to display the caller ID list.
2. Press to view from the most recent calls, or to view the
oldest calls.
3. When the desired record is displayed, press or to call.
-OR-
Press repeatedly until the phone number is shown in the desired
format (for example, when 555-5555 is displayed, press to change the
format of the phone number to 555-555-5555, 1-555-555-5555, and back to
555-5555), then press or to call.
Page 28
Caller ID
24
Save a number to the phonebook
1. Press .
2. Press / to locate the desired record and then press
menu.
3. Press / to select SAVE NUMBER and then press ok.
4. Enter the name (by using the dial pad keys if necessary),
and then press ok to save.
Delete caller ID record
1. Press .
2. Press / to locate the desired record and then press
menu.
3. Press / to select DELETE to delete the selected
record, or select DELETE ALL to delete all records.
4. Press ok twice to conrm.
Call log display screen messages
Display When
OUT OF AREA The caller’s name and number are out of area.
PRIVATE The caller is blocking the name, and the number is out
of area.
The caller is blocking the number, and the name is out
of area.
The caller is blocking both the name and number.
MAIN MENU
DELETE
MAIN MENU
DELETE ALL
- OR -
MAIN MENU
SAVE NUMBER
ENTER NAME
_
Page 29
25
Answering system
This section explains how to set up your answering system. Before you begin
the setup process, please make sure that the answering system is on.
Press on the telephone base to turn the answering system on or o. The
button on the telephone base will light when the answering system is
on.
The following table shows the answering system status.
Answering system status
Glows blue Answering system is ON.
No light Answering system is OFF.
Flashes slowly There are new messages.
Flashes rapidly Message capacity is full.
Telephone base volume
Use the button to adjust the playback volume at the telephone base
to a comfortable level (a beep tone will sound when the volume reaches the
maximum or minimum level.)
Outgoing Announcement (OGA)
When the answering system answers a call, the pre-recorded outgoing
announcement is played to the caller unless you have recorded your own
outgoing announcement.
Page 30
Answering system
26
Record an outgoing announcement (OGA)
You can record your own outgoing announcement using the telephone base or
handset.
To record your OGA at the telephone base:
1. Position yourself about 1 foot away from the microphone on
the telephone base, then press and hold annc.
2. Release the button after the beep. Speak clearly towards
the microphone to record your outgoing announcement (2
minutes maximum).
3. Press annc. when nished.
To record your OGA using a handset
1. Press menu.
2. Press ok to select ANS. SYSTEM.
3. Press / to select ANNOUNCEMENT and then press
ok.
4. Press / to select RECORD and then press ok.
5. After a beep sounds, speak into the handset as you
would normally during a call while recording your OGA (2
minutes maximum).
6. Press ok when nished.
If you want to use the pre-recorded outgoing announcement, simply delete
your recorded OGA.
1. Press menu.
2. Press ok to select ANS. SYSTEM.
3. Press / to select ANNOUNCEMENT and then press
ok.
4. Press / to select DELETE and then press ok.
5. The handset plays back the pre-recorded outgoing
announcement.
ANS. SYSTEM
ANNOUNCEMENT
ANNOUNCEMENT
RECORD
ANS. SYSTEM
ANNOUNCEMENT
ANNOUNCEMENT
DELETE
Microphone
digital answering system
Page 31
Answering system
27
Number of rings before the system answers
You can select the number of rings before the answering system answers a call.
1. Press menu.
2. Press ok to select ANS. SYSTEM.
3. Press / to select ANS. SETTING and then press ok.
4. Press ok to select RING DELAY.
5. Press / to select the desired setting and then
press ok to conrm.
NOTE: If you select TOLL SAVER, the system answers after the third ring if there
are new messages, or after the fth ring if there is no new message. This allows
you to check your system to see if there are new messages before incurring toll charges.
Turning the answering system on/o from a handset
1. Press menu.
2. Press ok to enter ANS. SYSTEM.
3. Press / to select ANS. ON/OFF and then press ok.
4. Press / to select ON or OFF, and then press ok.
Call screening
When the answering system answers a call, you can listen at the telephone
base while the caller leaves a message. Use the button to adjust
speaker volume. If the speaker is at the lowest level (o), you will need to
increase the volume when listening to message playback at the telephone base.
If you want to speak to the caller when the answering system is recording
a message, press or on the handset. The answering system will
automatically stop recording when you do so.
ANS. SYSTEM
ANS. SETTING
ANS. SETTING
RING DELAY
ANS. SYSTEM
ANS. ON/OFF
ANS. ON/OFF
ON
Page 32
Answering system
28
Message playback using the telephone base
Options during playback
Key Operation
Press to adjust the listening volume.
Press to playback or stop messages.
Press to repeat a message. Press twice to play the
previous message.
Press to skip to the next message.
del Press during playback to delete the current
message.
Press and hold in idle mode to delete all old
messages.
Message playback using the handset
To listen to messages on a handset:
1. Press menu.
2. Press ok to select ANS. SYSTEM.
3. Press ok again to select PLAY.
4. Press menu during playback then use / to select
from the following message options:
• REPEAT: Repeat the currently playing message.
• PREVIOUS: Listen to the previous message.
• NEXT: Listen to the next message.
• DELETE: Delete the currently playing message.
then press ok.
Your messages will automatically be played back through the handset
speakerphone. Press to listen to your messages privately through the
handset.
ANS. SYSTEM
PLAY
Page 33
Answering system
29
Delete all messages using the handset
1. Press menu.
2. Press ok to select ANS. SYSTEM.
3. Press / to select DELETE ALL.
4. Press ok twice to conrm.
Recording a memo
Memos are your own recorded messages used as reminders for
yourself or others using the same answering system.
1. Position yourself about 1 foot away from the microphone on
the telephone base, then press and hold memo.
2. Release the button after the beep. Speak clearly towards
the telephone base while recording your memo (up to 2
minutes).
3. Press memo to stop recording.
Security code for remote access
You can listen to messages and change answering system settings when you
are away from home.
Your answering system allows you to program a 4-digit security code to get
access to the system through any touch-tone telephone. The default security
code is 0000.
To change the security code:
1. Press menu.
2. Press ok to select ANS. SYSTEM.
3. Press / to select SECURITYCODE and then press
ok. The handset shows the default security code or the
old security code.
4. Press del to delete the shown security code.
5. Use the dial key pad to enter the new security code and then press ok, you
will hear a conrmation tone.
ANS. SYSTEM
DELETE ALL
ANS. SYSTEM
SECURITYCODE
Microphone
digital answering system
Page 34
Answering system
30
Access the answering system remotely
1. Dial your phone number from any touch-tone telephone.
2. Once your answering system takes your call and you hear your outgoing
announcement, press the # key. The answering system will prompt you to
enter your security code.
3. Enter your security code using the numeric keypad on the touch-tone
telephone. The system will start playing messages after you hear a
conrmation tone.
NOTES:
1. If your answering system is o, you will not hear your outgoing announcement. The system will answer
your call after 10 rings and then ask you to enter your security code.
2. If you have entered an incorrect security code, an error tone will sound and the system will ask you to
re-enter the code.
3. If you have forgotten the security code, you will need to reset the system (refer to page 8). The
security code will be restored to its default setting as 0000 after system reset.
Remote access commands
Touch-tone
keys
remote command
1 Replay the current or previous message
2 Play messages
3 Skip to the next message
6 Delete the current message
7 Turn the answering system on
8 Stop message playback
9 Turn the answering system o
A convenient wallet card, with instructions needed to operate your answering
system remotely, can be found on page 45.
Page 35
31
Appendix
Troubleshooting guide
If your telephone system is not operating properly, rst try these general reset
procedures:
1. Unplug all power adapters from the power outlets.
2. Disconnect the telephone line cord from the base or modular jack.
3. Remove the battery compartment covers and unplug all handset battery
packs.
4. After a few minutes, re-install all handset battery packs, making sure that
the connectors are snug and the wires are not pinched before replacing all
battery compartment covers.
5. Plug the power adapters for the base and any chargers back into their
power outlets. Be sure not to use outlets that are controlled by wall switches
or timers.
6. Place all handsets in the telephone base or chargers to charge without
interruption for at least 30 minutes before use.
7. Plug the line cord into the telephone base or modular jack and verify
operation.
For product assistance or for more information about accessories, visit our
website at www.gephones.com or call our customer service center at
1-877-394-9775.
General Performance
Problem Cause/solution
Cannot hear a
dial tone.
• Increase the volume on the handset.
• Disconnect the telephone line cord from the base unit
and connect it to a known working telephone. If the
known working telephone operates properly, contact
our customer support center for warranty information.
Handset does not
ring.
• The ringer may be o. Increase the ringer volume.
• Make sure your handset is charged.
Page 36
Appendix
32
You experience
audible static,
noise, or fading in
and out.
• The handset may be near the end of range limit. Move
the handset closer to the base unit.
• If you are using a line with DSL service, make sure you
have properly installed the DSL lters supplied by your
service provider.
• Try to relocate the base unit and use the handset
away from sources of electrical interference.
Caller ID
Problem Cause/solution
Caller-ID
information is not
displayed.
• You must subscribe to Caller ID service from your
service provider/telephone company.
• Make sure the base unit is plugged directly into a
telephone modular jack. If you are using a line with
DSL service, make sure you have properly installed the
DSL lters supplied by your service provider.
While on a call,
new caller-ID
information is not
displayed.
• You must subscribe to Caller ID with Call Waiting
service from your service provider/telephone
company.
Answering system
Problem Cause/solution
The unit does
not record new
messages.
• Make sure the answering system is on.
• The message memory may be full. Some messages
will need to be deleted.
Cannot access
the answering
system locally
through a system
handset.
• The system may be in use by another party.
• The system is busy recording a message.
Cannot operate
the answering
system remotely.
• You must use a touch-tone telephone for remote
access.
• Make sure you follow the remote access procedures in
this user’s guide.
Page 37
Appendix
33
General Product Care
• Avoid dropping the handset, as well as other rough treatment to the phone.
• Clean the phone only with a dry soft cloth.
• Never use cleaning agents, paint thinner, abrasive powder, alcohol, or other
chemical products to clean the unit. Doing so will damage the unit.
• Retain the original packaging in case you need to ship the phone at a later
date.
Page 38
Appendix
34
Important Safety Instructions
Some of the following information may not apply to your particular product;
however, when using telephone equipment, basic safety precautions should
always be followed to reduce the risk of re, electric shock and injury to
persons, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
4. Telephones should not be used while you are in a bathtub, shower or pool.
Immersion of the telephone or handset in water could cause an electrical
shock.
5. Slots and openings in the cabinet back or bottom are provided for
ventilation, to protect it from overheating. Do not block or cover these
openings. Do not block the openings by placing the product on a bed,
sofa, rug, or other similar surface. Do not place this product in a built-in
installation unless proper ventilation is provided.
6. Only operate this product from the type of power source indicated on the
marking label. If you are not sure of the type of power supply to your home,
consult your dealer or local power company.
7. Plug the adaptor into an easily accessible electrical outlet near the
equipment.
8. Do not allow anything to rest on the power cord. Do not locate this product
where the cord will be abused by persons walking on it.
9. Do not overload wall outlets and extension cords as this can result in the risk
of re or electric shock.
10. Never push objects of any kind into this product through cabinet slots as
they may touch dangerous voltage points or short out parts that could
result in a risk of re or electric shock.
11. Never spill liquid of any kind on the product.
12. To reduce the risk of electric shock, do not disassemble this product.
Opening or removing covers may expose you to dangerous voltages
or other risks. Incorrect reassembly can cause electric shock when the
appliance is subsequently used.
Page 39
Appendix
35
13. Do not expose the product to extreme temperatures such as areas
near a hot radiator, stove or in a hot car. Do not place product upon
other consumer electronic products such as; computer monitors, power
ampliers, etc.
14. Do not place lighted candles, cigarettes, cigars, etc., on or near the
telephone.
15. Never touch uninsulated telephone wires or terminals unless the telephone
line has been disconnected at the network interface.
16. Never install or modify telephone wiring during a lightning storm.
17. Never install jacks or telephones in wet locations.
18. Use caution when installing or modifying telephone lines to prevent
electrical shock and/or re.
19. Under the following conditions, unplug this product from the wall outlet and
refer servicing to qualied service personnel:
A. The power supply cord or plug is damaged or frayed.
B. The product has been exposed to rain or water.
C. The product does not operate normally by following the operating
instructions.
D. The product’s cabinet has been damaged.
E. The product exhibits a distinct change in performance.
20. Avoid using a telephone during an electrical-storm. There may be a remote
risk of electric shock from lightning.
21. Do not use the telephone to report a gas leak in the vicinity of the leak.
22. Do not place this product on an unstable cart, stand, or table. The product
may fall, causing serious damage to the product.
23. Only use attachments/accessories specied by the manufacturer.
24. Unplug this apparatus during lightning storms or when unused for long
periods of time.
IF YOUR PRODUCT UTILIZES BATTERIES, THE FOLLOWING ADDITIONAL
PRECAUTIONS SHOULD BE OBSERVED:
1. Use only the type and size battery(ies) specied in the user’s manual.
2. Do not use this product if the battery door is removed or missing.
Page 40
Appendix
36
3. Replace batteries that appear to be swollen or have damaged wiring.
4. Do not dispose of the battery(ies) in re. They may explode. Check with local
codes for possible special disposal instructions.
5. Do not open or mutilate the battery(ies). Released electrolyte is corrosive and
may cause damage to the eyes or skin. It may be toxic if swallowed.
6. Exercise care in handling battery(ies) in order not to short out the battery(ies)
with conducting materials such as rings, bracelets, and keys. The battery(ies)
or conductor may overheat and cause burns.
7. Do not attempt to recharge the battery(ies) provided with or identied for
use with this product that are not rechargeable. The battery(ies) may leak
corrosive electrolyte or explode.
8. Do not attempt to rejuvenate the battery(ies) provided with or identied for
use with this product by heating them. Sudden release of the battery(ies)
electrolyte may occur causing burns or irritation to eyes or skin.
9. When replacing battery(ies), all batteries should be replaced at the same
time. Mixing fresh and discharged batteries could increase internal cell
pressure and rupture the discharged battery(ies). (Applies to products
employing more than one separately replaceable primary battery.)
10. When inserting battery(ies) into this product, the proper polarity or direction
must be observed. Reverse insertion of battery(ies) may result in leakage or
explosion.
11. When inserting battery(ies) into this product, do not twist or pinch the wires
or allow wires to become pinched in battery door.
12. If storing over 30 days, remove battery(ies) from this product because the
battery(ies) could leak and damage the product.
13. Discard “dead” battery(ies) as soon as possible since “dead” batteries are
more likely to leak in a product.
14. Do not store this product, or the battery(ies) provided with or identied for
use with this product, in high-temperature areas. Batteries that are stored
in a freezer or refrigerator for the purpose of extending shelf life should
be protected from condensation during storage and defrosting. Batteries
should be stabilized at room temperature prior to use after cold storage.
15. If your product uses rechargeable battery(ies), charge the battery(ies) only in
accordance with the instructions and limitation specied in the user’s guide.
Page 41
Appendix
37
16. Battery safety precautions
• Do not burn, disassemble, mutilate, or puncture. Like other batteries of
this type, toxic materials could be released which might cause injury to
persons or property damage.
• To reduce the risk of re or personal injury, use only the supplied battery
or replacement battery.
• Keep batteries out of the reach of children.
• Remove batteries if storing over 30 days.
Use only the supplied rechargeable battery or replacement battery. Visit our
website at www.gephones.com to order a replacement battery if necessary.
SAVE THESE INSTRUCTIONS
Page 42
Appendix
38
FCC Parts 15, 68 and ACTA
This equipment is in compliance with parts 15 and 68, FCC Rules and
Regulations and the Technical Requirements for Telephone Terminal Equipment
published by ACTA.
On the bottom of this equipment is a label indicating, among other information,
the US number and Ringer Equivalence Number (REN) for the equipment. You
must, upon request, provide this information to your telephone company.
The REN is useful in determining the number of devices you may connect to
your telephone line and still have all of these devices ring when your telephone
number is called. In most (but not all) areas, the sum of the RENs of all devices
connected to one line should not exceed 5.
A plug and jack used to connect this equipment to the premises wiring
and telephone network must comply with the applicable FCC Part 68 rules
and requirements adopted by the ACTA. A compliant telephone cord and
modular plug is provided with this product. It is designed to be connected to a
compatible modular jack that is also compliant. See installation instructions for
details.
This equipment is not intended to be used with Party Lines. If your home has
specially wired alarm equipment connected to the telephone line, ensure the
installation of this product does not disable your alarm equipment. If you have
questions about what will disable alarm equipment, consult your telephone
company or a qualied installer.
If this equipment is malfunctioning, it should be unplugged from the modular
jack until the problem is corrected. Repairs to this equipment can only be
made by the manufacturer or its authorized agents. For information on repair
procedures, follow the instructions provided with the limited warranty. Should
your equipment cause trouble on your line which may harm the telephone
network, the telephone company shall, where practicable, notify you that
temporary discontinuance of service may be required. Where prior notice
is not practical and the circumstances warrant such action, the telephone
company may temporarily discontinue service immediately. In case of such
temporary discontinuance, the telephone company must: (1) promptly notify
you of such temporary discontinuance; (2) aord you the opportunity to correct
the situation; and (3) inform you of your right to bring a complaint to the
Commission pursuant to procedures set forth in Subpart E of Part 68, FCC Rules
and Regulations.
The telephone company may make changes in its communications facilities,
equipment, operations or procedures where such action is required in the
Page 43
Appendix
39
operation of its business and not inconsistent with FCC Rules and Regulations. If
these changes are expected to aect the use or performance of your telephone
equipment, the telephone company must give you adequate notice, in writing,
to allow you to maintain uninterrupted service. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference; and (2) This device must accept
any interference received, including interference that may cause undesired
operation. This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
Privacy of Communications may not be ensured when using this product.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna (that is, the antenna for radio or
television that is “receiving” the interference).
• Reorient or relocate and increase the separation between the
telecommunications equipment and receiving antenna.
• Connect the telecommunications equipment into an outlet on a circuit
dierent from that to which the receiving antenna is connected.
If these measures do not eliminate the interference, please consult an
experienced radio/television technician for additional suggestions. The changes
or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Hearing Aid Compatibility (HAC)
This equipment meets FCC standards for Hearing Aid Compatibility
If this product has a memory dialing feature, you may choose to store
emergency phone numbers such as police, re or medical within the memory
locations. If you do store or emergency numbers, we suggest you also write
these numbers down so that you can still dial the number manually if the
memory dialing fails.
Page 44
Appendix
40
This feature is included as a convenience only. The manufacturer assumes no
responsibility for customer reliance on the memory feature of this product.
Testing emergency telephone numbers is not recommended. However, if you
choose to make a test call to an emergency number, you should:
• Remain on the line and provide an explanation for the call before you hang
up.
• Only make a non emergency test call during o-peak hours during early
mornings or late evenings.
To ensure user safety, the FCC has established criteria for the amount of radio
frequency energy that can be safely absorbed by a user or bystander according
to the intended usage of the equipment. This equipment has been tested and
found to comply with the FCC criteria. The handset may be safely held against
the ear of the user. The telephone base should be installed and used such that
parts of the users body other than the handset are maintained at a distance of
approximately 8 inches (20 cm) or more.
THE LIGHTNING
FLASH AND ARROW
HEAD WITHIN
THE TRIANGLE IS
A WARNING SIGN
ALERTING YOU
OF “DANGEROUS
VOLTAGE” INSIDE
THE PRODUCT.
CAUTION
RISK OF ELECTRICAL SHOCK, DO NOT OPEN
CAUTION: TO REDUCE THE
RISK OF ELECTRICAL SHOCK,
DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.
THE EXCLAMATION
POINT WITHIN
THE TRIANGLE IS
A WARNING SIGN
ALERTING YOU
OF IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
WARNING: TO PREVENT
FIRE OR ELECTRICAL
SHOCK HAZARD, DO
NOT EXPOSE THIS
PRODUCT TO RAIN OR
MOISTURE.
This product meets ENERGY STAR program requirements for energy
conservation. Selecting ENERGY STAR products is a responsible way
to save energy and money while protecting our environment.
ENERGY STAR is a U.S. registered mark.
The RBRC seal on the battery used in your product indicates that CCT
is participating in the Rechargeable Battery Recycling Corporation
(RBRC) program to collect and recycle rechargeable batteries. We
encourage you to explore the easy recycling options available to
you in your area. For more information visit www.rbrc.org or call
1-800-8-BATTERY or contact your local recycling center.
In accordance with California Proposition 65, CCT advises that nickel
is a chemical known to the State of California to cause cancer.
Page 45
Appendix
41
One Year Limited Warranty
CCT Tech USA Inc. (CCT), the licensed manufacturer of this GE® branded
product, warrants this product to the original retail purchaser to be free of
material and/or workmanship defects for a period of one year after the date
of original retail purchase. Proof of the original purchase is required to obtain a
remedy under this limited warranty and the product must be returned to CCT at
your expense.
During the limited warranty period, CCT or its authorized service representative
will repair or replace at CCT’s option, without charge, a materially defective
product. We may use new or refurbished replacement parts. If we replace the
product, it may be with a new or refurbished product of same or similar design.
CCT may keep any removed or defective parts, and/or replaced product. The
repaired or replaced product is warranted for the remainder of the original
warranty or 90 days, whichever is greater. Repair or replacement of this product
at CCT’s option is your exclusive remedy.
This limited warranty only applies to products purchased, used and serviced in
the United States and its territories, or Puerto Rico. If you purchased this product
outside of the United States, its territories or Puerto Rico, contact your dealer for
service information.
This is the only warranty applicable to this product. ALL OTHER WARRANTIES
EXPRESS OR IMPLIED INCLUDING ALL IMPLIED WARRANTIES OF
MERCHANTABILITY OF FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY
DISCLAIMED. CCT IS NOT LIABLE FOR ANY INDIRECT, INCIDENTAL,
CONSEQUENTIAL OR SIMILAR DAMAGES INCLUDING, BUT NOT LIMITED TO,
LOST PROFITS OR REVENUE, INABILITY TO USE THE PRODUCT, OR ANY OTHER
ASSOCIATED EQUIPMENT, THE COST OF SUBSTITUTE EQUIPMENT, AND ANY
CLAIMS BY THIRD PARTIES RESULTING FROM THE USE OF THIS PRODUCT.
This warranty gives you specic legal rights, and you may have other rights that
vary from state to state. Some states do not allow the exclusion or limitation
of incidental or consequential damages, so the limitations or exclusions stated
above may not apply.
What Is NOT Covered Under This Limited Warranty
• Normal wear and tear or cosmetic damage.
• Damage due to accidents, misuse, physical force, improper installation or
operation, mishandling, neglect, re, heat, water, humidity, liquids, insect
infestation, or other intrusion.
Page 46
Appendix
42
• Products that have been repaired, altered or modied by anyone other than
CCT or its authorized service representative.
• Problems caused by signal conditions, radio interference, network reliability,
cable or antenna systems.
• Damage caused by use of non CCT accessories or misapplication.
• Products whose serial numbers have been removed, altered or rendered
illegible.
• Products purchased, shipped from, used or serviced outside the United
States.
• Batteries.
• Products used for business, commercial or institutional purposes.
• Damage caused by acts of nature such as, but not limited to, lightning
damage.
• Products returned without valid proof of purchase.
How To Obtain Warranty Service
Call our customer service center at 1-877-394-9775. Our customer service
specialist will assist you in obtaining warranty service. Please have a paper and
pencil handy to write down the warranty service return instructions.
-OR-
You may visit our web site at www.gephones.com for troubleshooting, FAQs,
and information on warranty service.
Accessibility
If you have a disability or questions about how CCT’s products can
accommodate persons with disabilities, please call our customer service center
at 1-877-394-9775. When calling, please let our specialists know that you have
an inquiry about accessibility so your call is routed properly.
Page 47
Appendix
43
A
Alarm 14
Alarm melody 14
Answer a call 15
Answer an incoming call during an
intercom call 18
Answering system 25
Answering system ON/OFF 27
Area code 8
B
Battery charging 4
Battery installation 3
Battery safety precautions 35
C
Caller ID 23
calling from the call log 23
delete a caller ID record 24
display screen messages 24
save a number to the phonebook
24
Call screening 27
Call waiting 17
Chain dial 21
Charger installation 2
D
Date and time 13
Date format 13
Delete message 29
Dialing mode 8
E
End a call 15
F
FCC 38
G
General product care 33
H
Handset deregistration 9
Handset locator 17
Handset name 10
Handset registration 9
I
Important safety instructions 34
Installation
battery 3
charger 2
telephone base 2
Intercom 18
K
Key tone 11
L
Language 12
M
Memo recording 29
Message playback 28
Multiple handsets 17
Mute 16
N
Number of rings 27
Index
Page 48
Appendix
44
O
Outgoing announcement
record an outgoing announcement
26
P
Parts checklist 1
Phonebook
add a number 20
character table 20
delete a phonebook entry 22
edit a phonebook entry 22
search a phonebook entry 21
view a phonebook entry 21
Phonebook caller-ID match 23
Predial a call 15
R
Redial 16
Ringer tone 11
Ringer volume 10
S
Screen display icon 7
Security code 29
Speakerphone 15
T
Telephone base installation 2
Telephone base volume 25
Time format 13
Troubleshooting 31
V
Voice mail 17
Volume control 15
W
Warranty 41
Page 49
Appendix
45
Remote access operation card
The remote access card below lists the commands needed to operate your
answering system remotely from any touch-tone telephone.
Remote access operation card
1. Call your telephone number from a touch-tone
telephone.
2. Press # when you hear your outgoing announcement.
3. Enter your security code (default is 0000).
Security code:
4. After the beep, the system will start playing messages.
NOTE: For more details about remote access operation, refer to
page 30 of the user’s guide.
Remote access commands
Touch-tone
keys
remote command
1 Replay the current or previous message
2 Play messages
3 Skip to the next message
6 Delete the current message
7 Turn the answering system on
8 Stop message playback
9 Turn the answering system o
Cut along dotted line
Fold
here
Page 50
visit our website:
www.gephones.com
is a trademark of General Electric Company and is under license by
CCT Tech USA Inc., Irving, TX 75039
©2011 CCT Tech USA Inc.
Distributed in the U.S.A. by
CCT Tech USA Inc.
Model 28522
P/N: 480-97400-000002
Version 2 01/2011
Printed in China
Loading...
