GE 25893 User Manual

5.8 GHz Cordless Call Waiting Caller ID Telephone/ Answering System User’s Guide

25893

We bring good things to life.

EQUIPMENT APPROVAL INFORMATION

Your telephone equipment is approved for connection to the Public Switched Telephone Network and is in compliance with parts 15 and 68, FCC Rules and Regulations and the Technical Requirements for Te lephone Terminal Equipment published by ACTA.

1 Notification to the Local Telephone Company

On the bottom of this equipment is a label indicating, among other information, the US number and Ringer Equivalence Number (REN) for the equipment. You must, upon request, provide this information to your telephone company.

The REN is useful in determining the number of devices you may connect to your telephone line and still have all of these devices ring when your telephone number is called. In most (but not all) areas, the sum of the RENs of all devices connected to one line should not exceed 5. To be certain of the number of devices you may connect to your line as determined by the REN, you should contact your local telephone company.

A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. See installation instructions for details.

Notes

• This equipment may not be used on coin service provided by the telephone company.

•Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone equipment if you are on a party line. Check with your local telephone company.

• Notice must be given to the telephone company upon permanent disconnection of your telephone from your line.

• If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this product does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer.

2 Rights of the Telephone Company

Should your equipment cause trouble on your line which may harm the telephone network, the telephone company shall, where practicable, notify you that temporary discontinuance of service may be required. Where prior notice is not practicable and the circumstances warrant such action, the telephone company may temporarily discontinue service immediately. In case of such temporary discontinuance, the telephone company must: (1) promptly notify you of such temporary discontinuance; (2) afford you the opportunity to correct the situation; and (3) inform you of your right to bring a complaint to the Commission pursuant to procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.

The telephone company may make changes in its communications facilities, equipment, operations or procedures where such action is required in the operation of its business and not inconsistent with FCC Rules and Regulations. If these changes are expected to affect the use or performance of your telephone equipment, the telephone company must give you adequate notice, in writing, to allow you to maintain uninterrupted service.

INTERFERENCE INFORMATION

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference; and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna (that is, the antenna for radio or television that is “receiving” the interference).

•Reorient or relocate and increase the separation between the telecommunications equipment and receiving antenna.

• Connect the telecommunications equipment into an outlet on a circuit different from that to which the receiving antenna is connected.

If these measures do not eliminate the interference, please consult your dealer or an experienced radio/ television technician for additional suggestions. Also, the Federal Communications Commission has prepared a helpful booklet, “How To Identify and Resolve Radio/TV Interference Problems.” This booklet is available from the U.S. Government Printing Office, Washington, D.C. 20402. Please specify stock number 004-000-00345-4 when ordering copies.

FCC RF EXPOSURE REQUIREMENTS

This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.

HEARING AID COMPATIBILITY

This telephone system meets FCC standards for Hearing Aid Compatibility.

FCC NUMBER IS LOCATED ON THE CABINET BOTTOM REN NUMBER IS LOCATED ON THE CABINET BOTTOM

TABLE OF CONTENTS

EQUIPMENT APPROVAL INFORMATION ................. 2

INTERFERENCE INFORMATION ............................ 3

FCC RF EXPOSURE REQUIREMENTS ................. 3

HEARING AID COMPATIBILITY............................ 3

INTRODUCTION .............................................. 6

BEFORE Y OU BEGIN ....................................... 7

PARTS CHECKLIST ...................................... 7

TELEPHONE JACK REQUIREMENTS ................. 7

HANDSET AND BASE LAYOUT ........................... 8

INSTALLATION ................................................ 9

IMPORTANT INSTALLATION GUIDELINES .......... 9

INSTALLING THE PHONE ............................. 10

WALL MOUNTING .................................... 11

ANSWERING SYSTEM SETUP .......................... 11

VOICE T IME/DAY STAMP ............................ 11

SPEAKER VOLUME ................................... 12

VOICE INSTRUCTIONS ............................... 12

RECORDING THE OUTGOING ANNOUNCEMENT 13

REVIEWING THE ANNOUNCEMENT ................ 13

RING SELECT .......................................... 13

ANSWERING SYSTEM OPERATION ................... 13

MESSAGES INDICATOR .............................. 13

SCREENING CALLS FROM THE BASE ............. 14

MESSAGE PLAYBACK ................................ 14

MEMORY FULL ........................................ 14

ERASING MESSAGES ................................ 14

LEAVING A MEMO ................................... 15

TELEPHONE SET UP ..................................... 15

PROGRAMMABLE MENUS .......................... 15

DISPLAY LANGUAGE ................................. 15

LOCAL AREA CODE .................................. 15

TONE/PULSE ........................................... 16

FACTORY DEFAULT ................................... 16

TELEPHONE OPERATION ................................ 17

MAKING A CALL ...................................... 17

ANSWERING A CALL ................................. 17

IN USE INDICATOR ................................... 17

REDIAL .................................................. 17

FLASH ................................................... 17

VOLUME ................................................ 18

EXIT ...................................................... 18

MUTE .................................................... 18

RINGER SWITCH ...................................... 18

PAGING THE HANDSET .............................. 18

CALLER ID (CID) ........................................ 18

CALL W AITING CALLER ID ........................ 19

RECEIVING AND STORING CALLS ................. 19

REVIEWING CID RECORDS ........................ 19

DELETING A CID RECORD .................... 20

DELETING ALL CID RECORDS .............. 20

STORING CID RECORDS IN MEMORY .......... 20

STORING A REDIAL NUMBER ..................... 20

DIALING A CID NUMBER .......................... 21

CHANGING THE NUMBER FORMAT ............... 21

MEMORY .................................................... 22

STORING A NAME AND NUMBER

IN MEMORY ................................ 22

CHANGING A STORED NUMBER .................. 22

DIALING A STORED NUMBER ..................... 23

CHAIN DIALING FROM MEMORY ................. 23

INSERTING A PAUSE IN THE DIALING

SEQUENCE ................................. 24

(Table of Contents continued on the following page.)

CAUTION:

RISK OF ELECTRIC SHOCK

WARNING: TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

DO NOT OPEN

THE LIGHTNING FLASH AND ARROW HEAD WITHIN THE TRIANGLE IS A WARNING SIGN ALERTING YOU OF “DANGEROUS VOLTAGE” INSIDE THE PRODUCT.

SEE MARKING ON BOTTOM / BACK OF PRODUCT

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

THE EXCLAMATION POINT WITHIN THE TRIANGLE IS A WARNING SIGN ALERTING YOU OF IMPORTANT INSTRUCTIONS ACCOMPANYING THE PRODUCT.

REVIEWING AND DELETING STORED

ADVANCED FEATURES ................................... 24

REMOTE ACCESS ......................................... 25

BELT CLIP AND OPTIONAL HEADSET ................ 27

CHANGING THE BATTERY ............................... 28

NUMBERS .................................. 24

TEMPORARY T ONE .................................... 24

CORDLESS HANDSET ................................ 25

ANSWERING SYSTEM INDICATOR ........... 25

SCREENING CALLS FROM THE HANDSET ....... 25

MEMORY FULL ........................................ 25

ACCESSING THE ANSWERING SYSTEM FROM

ANOTHER LOCATION .................... 26

CHANGING THE SECURITY CODE ................. 26

CONNECTING THE BELT CLIP ...................... 27

CONNECTING AN OPTIONAL HEADSET TO

THE HANDSET ............................. 27

BATTERY SAFETY PRECAUTIONS ................. 28

HANDSET SOUND SIGNALS ........................... 29

DISPLAY ID MESSAGES ................................ 29

ANSWERING SYSTEM DISPLAY MESSAGES ....... 30

TROUBLESHOOTING GUIDE ............................ 31

CORDLESS PHONE SOLUTIONS ................... 31

CALLER ID SOLUTIONS ............................. 32

ANSWERING SYSTEM SOLUTIONS ............... 33

GENERAL PRODUCT CARE ............................. 34

CAUSES OF POOR RECEPTION ........................ 34

SERVICE ..................................................... 35

INDEX ........................................................ 36

LIMITED W ARRANTY ..................................... 38

ACCESSORY ORDER FORM ............................ 38

INTRODUCTION

CAUTION: When using telephone equipment, there are basic safety

instructions that should always be followed. Refer to the IMPORTANT SAFETY INSTRUCTIONS provided with this product and save them for future reference.

This telephone/answering system is designed to be simple to use, however, you can reach its full potential more quickly by taking a few minutes to read this user’s guide.

This telephone /answering system is a multifunction product for use with Call Waiting Caller ID services available from your local telephone company.

Your Call Waiting Caller ID phone allows you to:

•View the name and telephone number of a caller while you are on the phone (Call Waiting Caller ID).

• Identify callers before you answer the phone.

•View the time and date of each incoming call.

•Record up to 40 Caller ID messages sequentially.

• Know who called while you are on the other line or when you were away.

•Screen unwanted calls, eliminate harassment from annoying calls, or to get prepared before answering a call.

IMPORTANT: In order to use all of the Caller ID features of this telephone,

you must subscribe to two separate services available from your local telephone company: the standard Name/Number Caller ID Service to know who is calling when the phone rings and Call Waiting Caller ID Service to know who is calling while you are on the phone.

Because cordless phones operate on electricity, you should have at least one phone in your home that isn’t cordless, in case the power in your home goes out.

BEFORE YOU BEGIN

PARTS CHECKLIST

Make sure your package includes the items shown here.

page

erase

volume

memo

rev

ip k s

play/ stop

play/stop

erase

answerer

Handset battery

Base

Handset

Mounting bracket

TELEPHONE JACK REQUIREMENTS

Belt clip

Long telephone line cord

AC power supply

Wall plate

To use this phone, you need an RJ11C type modular telephone jack, which might look like the one pictured here, installed in your home. If you don’t have a modular jack, call your local phone company to find out how to get one installed.

INSTALLA TION NOTE: Some cordless telephones operate at frequencies that

may cause interference to nearby TVs microwave ovens, and VCRs. To minimize or prevent such interference, the base of the cordless telephone should not be placed near or on top of a TV, microwave ovens, or VCR. If such interference continues, move the cordless telephone farther away from these appliances.

Certain other communications devices may also use the 5.8/2.4 GHz frequency for communication, and, if not properly set, these devices may interfere with each other and/or your new telephone. If you are concerned with interference, please refer to the owner’s manual for these devices on how to properly set channels to avoid interference. Typical devices that may use the

5.8/2.4 GHz frequency for communication include wireless audio/video senders, wireless computer networks, multi-handset cordless telephone systems, and some long-range cordless telephone systems.

Modular telephone line jack

HANDSET AND BASE LAYOUT

handset indicator

antenna

display

mute/format button

cid/vol down button

redial button

review button

exit button

delete/answerer button

program button erase button

page button

charge/in use indicator

display

erase button

memo button

rev button

play/stop button skip button

TALK/call back

cid/vol up button

memory button

play/stop button

play/stop

erase

skip button

pause button

answerer

flash button

antenna

page

answerer on/off button

announce button

day/check button

erase

memo

volume

rev

skip

play/ stop

hour button

min button

volume button

INSTALLATION

• Never install telephone wiring during a lightning storm.

• Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.

• Never touch non-insulated telephone wires or terminals, unless the telephone line has been disconnected at the network interface.

• Use caution when installing or modifying telephone lines.

•Temporarily disconnect any equipment connected to the phone such as faxes, other phones, or modems.

IMPORTANT INSTALLATION GUIDELINES

• Install telephone near both a telephone (modular) jack and an electrical power outlet.

•Avoid sources of noise, such as a window by a busy street, and electrical noise, such motors, microwave ovens, and fluorescent lighting.

•Avoid heat sources, such as heating air ducts, heating appliances, radiators, and direct sunlight.

•Avoid areas of excessive moisture or extremely low temperature.

•Avoid dusty locations.

•Avoid other cordless telephones or personal computers.

INSTALLING THE PHONE

1. Choose an area near an electrical outlet and telephone wall jack (RJ11C).

2. Plug the AC power supply into the electrical outlet and the DC connector into the power jack on the back of the base.

CAUTION: Use only ATLINKS, Inc. power supply 5-2605 that came with

this unit. Using other power supplies may damage the unit.

3. Install the handset battery.

NOTE: You must connect the handset battery before use. NOTE: Battery and battery door are packaged together inside a plastic bag

and are separate from the handset.

•Locate the battery compartment on the back of the handset.

• Insert the battery pack.

• Plug the battery pack cord into the jack inside the compartment.

BATTERY

RED WIRE

PRESS DOWN FIRMLY

NOTE: It is important to maintain the polarity (black and red wires) to the

jack inside the compartment as shown in the illustration

BLACK WIRE

•Replace the battery compartment door.

4. Connect the telephone line cord by plugging one end of the telephone line cord into the jack on the back of the base and the other end into a telephone wall jack.

5. Set the RINGER switch (on the handset) to ON, and place the handset in the cradle on the base. The charge indicator on the base turns on to indicate the handset battery is charging.

6. Allow handset to charge for 16 hours prior to first use. If you don’t properly charge the handsets, battery performance is compromised.

WALL MOUNTING

NOTE: For best results, charge the telephone/answering system on a flat

surface before hanging it on the wall.

1. Turn the base over.

2. Attach the wall mounting pedestal by first inserting the tabs on the open edge of the pedestal into the slots on the lower portion of the bottom of the base. Then push down and snap the pedestal into place.

3. Slip the mounting holes (on the back of the base and pedestal) over the wall plate posts and slide the unit down into place. (Wall plate not included.)

ANSWERING SYSTEM SETUP

This section shows you how to set up your answering system to receive incoming calls. Before you begin the set up process, you must turn on the answering system.

•Press the answerer on/off button to turn the answering system on and off. The MESSAGES indicator lights when the answering system is on. The indicator blinks when you have messages.

NOTE: The answering system displays “- -” when it is off.

VOICE TIME/DAY STAMP

1. Make sure the answering system is ON.

2. Press and hold the day/check button to set the day of the week.

3. Press and hold the hour button to set the hour (a.m. or p.m.). Example:

12AM, 1AM

4. Press and hold the min button to set the minute. The time advances in 5-minute intervals.

5. Press and release the day/check button to review the day and time settings.

, or

12PM, 1PM

SPEAKER VOLUME

Use the volume up/down buttons to adjust speaker volume on the base to a comfortable level. L1 is the minimum speaker volume and L8 is the maximum.

VOICE INSTRUCTIONS

Using the Base:

1. Press and hold the announcement button to record an announcement. Release the button to stop recording.

2. Press the announcement button to review the announcement.

3. Press and hold the minute or hour button to set the time.

4. Press the minute button to set the minute.

5. Press and hold the day time/check button to set the day.

6. Press the day time/check button to review the time /day.

Using the Handset :

1. Press the two key to play messages (press two key again to stop).

2. Press the zero key while playing a message to erase.

3. Press the one key to review messages.

4. Press the three key to skip messages.

5. Press the four key to turn messages off/on.

6. Press the seven key to review the menu.

If you need additional assistance, press the rev (review) button on the base and the answerer/delete button on the handset and follow the voice instructions.

RECORDING THE OUTGOING ANNOUNCEMENT

For best results when recording, you should be about nine inches from the microphone, and eliminate as much background noise as possible.

1. Make sure the answering system is ON.

2. Press and hold the announce button.

3. Begin speaking after you hear the beep.

4. Release the button when you finish your announcement.

NOTE: If you choose not to record an outgoing announcement, a default

announcement plays instead. To return to the default announcement after you have recorded your own outgoing announcement, press the announce button and release it when you hear the beep.

Sample Outgoing Announcement

Hi, this is (use your name here), I can't answer the phone right now, so please leave your name, number and a brief message after the tone, and I'll get back to you. Thanks.

REVIEWING THE ANNOUNCEMENT

Press and release announce button to review your outgoing announcement.

RING SELECT

Set the RING SELECT switch on the back of the unit to choose the number of times you want the phone to ring before the answering system answers the call. You can choose 3 rings or 5 rings.

ANSWERING SYSTEM OPERATION

This section discusses the buttons and features on the answering system.

MESSAGES INDICATOR

The MESSAGES indicator shows you how many new messages you have received, and the indicator blinks when new messages are received. The answer on/off button must be on in order for the MESSAGES indicator to work.

SCREENING CALLS FROM THE BASE

You may screen incoming calls by waiting for the caller to begin leaving a message (to hear who is calling), then pick up the handset, and press TALK/ callback to speak to the caller. The answering system automatically stops recording when you activate the handset or pick up an extension phone.

TIP: Make sure the volume on the base is set loud enough to hear your

incoming calls.

MESSAGE PLAYBACK

The messages indicator lets you know when you have messages. To play messages, press play/stop.

While a message is playing, you may do the following:

•Press play/stop to stop the message playback.

•Press and release rev (review) to restart the current message; continue to press and release rev (review) to go to previous messages.

•Press and release skip to go to the next message.

•Press play/stop to stop message playback.

MEMORY FULL

When the memory is full, the system answers after 10 rings. You should erase some messages so the answering system may record new messages.

ERASING MESSAGES

You may erase messages three ways: one message at a time from the base; all messages from the base; or one message at a time from the handset or a phone in another location.

1. To erase one message at a time from the base:

•Press play/stop. The message plays.

•Press and release the erase button.

2. To erase all reviewed messages from the base:

• When the answering system is idle, press and hold the erase button until the unit beeps. All previously reviewed messages are deleted.

3. To erase a message from the handset:

•Press answerer/delete button to enter into the handset remote access operation.

•Press play/stop on the handset (the 2 button). The message plays.

•Press erase (the 0 button) to erase the message during message playback.

NOTE: Erased messages cannot be restored.

LEAVING A MEMO

Use the memo feature to leave a message.

1. Press and hold the memo button.

2. Begin speaking after you hear the beep.

3. Release the memo button when you finish.

TELEPHONE SET UP

PROGRAMMABLE MENUS

There are four programmable menus available: Language, Local Area Code, Tone/Pulse and Factory Default. When you program these settings, make sure the phone is OFF ( not in talk mode).

DISPLAY LANGUAGE

1. P ress the program button until

2. Use the CID/VOL left (-) or right (+) arrow button or the handset touchtone pad to enter your selection.

3. Press program to confirm.

NOTE: Press the EXIT button once to keep the previous setting and return to

the standby screen.

1 ENGLISH 2 FRA 3 ESP

shows in the display.

LOCAL AREA CODE

1. Press the program button until default is - - -.

2. Use the handset touch-tone pad to enter the area code.

SET AREA CODE

shows in the display. The

3. Press program to confirm.

NOTE: Press the EXIT button once to keep the previous setting and return to

the standby screen.

NOTE: To restore the default setting to - - - , press delete/answerer when SET AREA CODE shows in the display.

TONE/PULSE

Most telephone systems use tone dialing, however, some may still use pulse dialing. This system is pre-set to tone dialing. Depending on your service type, set the dialing mode as follows:

1. Press the program button until The default dialing mode is

SET TONE/PULSE

TONE

shows in the display.

2. Use the CID/VOL left (-) or right (+) arrow button or the handset touchtone pad to enter your selection.

3. Press program to confirm.

NOTE: Press the EXIT button once to keep the previous setting and return to

the standby screen.

FACTORY DEFAULT

As you become familiar with this system, you may prefer to use the system’s original settings. Follow the steps below to return to the factory default settings.

1. Press the program button until The default is

2 NO

2. Use the CID/VOL left (-) or right (+) arrow button or the handset touchtone pad to select

1 YES

3. Press program to confirm.

NOTE : The default settings are ENGLISH, LOCAL AREA CODE - - -, and TONE. NOTE : Press the EXIT button once to keep the previous setting and return to

the standby screen.

DEFAULT SETTING

2 NO

shows in the display.

TELEPHONE OPERATION

MAKING A CALL

1. Press the TALK/callback button.

2. When you hear a dial tone, dial a telephone number.

3. When finished, press the TALK/callback button again to hang up.

1. Dial the phone number first, then press the TALK/callback button.

2. When finished, press the TALK/callback button again to hang up.

ANSWERING A CALL

1. Pick up the handset and press the TALK/callback button.

NOTE: The TALK/callback button is disabled when the handset is in

the cradle.

2. To disconnect a call, place the handset back in the cradle or press the TALK/callback button again.

IMPORTANT: Because cordless phones operate on electricity, you should

have at least one phone in your home that isn’t cordless, in case the power in your home goes out.

IN USE INDICATOR

The phone is ON when the indicator on the handset is lit and the charge/in use indicator on the base is lit. The handset indicator and the in use indicator on the base flashes when you receive a call.

REDIAL

1. Press the TALK/callback button.

2. Press the redial button to redial the last number you called (up to 32 digits). If you get a busy signal, and want to keep dialing the number, press redial to dial the number directly.

FLASH

Use the flash button to activate custom calling services such as call waiting or call transfer, which are available through your local phone company.

TIP: Don't use the TALK/callback button to activate custom calling services

such as call waiting, or you’ll hang up the phone.

VOLUME

When the phone is ON, press the CID/VOL left (-) or right (+) arrow button to adjust the volume of the handset's earpiece to a comfortable level. There are four settings to choose from. VOL 1 is the minimum volume level and VOL 4 is the maximum.

EXIT

Press the EXIT button to exit a menu function and return to the standby screen.

MUTE

Use the mute button during a phone conversation to speak privately and off-line with a third party.

1. Press the mute button. The handset indicator blinks. The party on the telephone can not hear your conversation.

2. Press mute when finished. The handset indicator stops blinking.

RINGER SWITCH

The handset ringer switch may be set to ON or OFF. If the switch is off, the unit does not ring.

PAGING THE HANDSET

This feature helps locate a misplaced handset.

1. Press the PAGE button on the base. The handset beeps for two minutes, and

PAGING FROM BASE

2. To cancel the page press the TALK/callback button on the handset or the PAGE button on the base

NOTE: You may still page the handset with the ringer off.

shows on the handset’s display.

CALLER ID (CID)

Caller ID (CID) is a service available from your local telephone company. For Caller ID to work on this system, you must subscribe to Caller ID service from your local telephone company.

This unit receives and displays information transmitted by your local phone company. This information can include the phone number, date, and time; or the name, phone number, date, and time. The unit can store up to 40 calls for later review.

Time

Date

Number of calls

Caller ID phone number

Caller ID name

CALL WAITING CALLER ID

To receive Caller ID (CID) information from a Call Waiting call, you must subscribe to the combined Call Waiting Caller ID service from your local telephone company. Call Waiting Caller ID service allows you to see CID information for an incoming call while you are on the telephone.

IMPORTANT: In order to use all of the Caller ID features of this unit, you

must subscribe to either the standard Name/Number Caller ID Service or Call Waiting Caller ID Service. To know who is calling while you are on the phone, you must subscribe to Call Waiting Caller ID Service.

RECEIVING AND STORING CALLS

When you receive a call, the information is transmitted by the phone company to your Caller ID telephone between the first and second ring.

When the memory is full, a new call automatically replaces the oldest call.

NEW

appears in the display for calls received that have not been reviewed.

NOTE: Check with your local phone company regarding name service

availability.

REVIEWING CID RECORDS

As calls are received and stored, the display is updated to let you know how many calls have been received.

1. Make sure the phone is OFF (not in talk mode).

2. Press the CID/VOL left (-) arrow button to scroll through the call records from the most recent to the oldest.

3. Press the CID/VOL right (+) arrow button to scroll through the call records from the oldest to the newest.

DELETING A CID RECORD

1. Make sure the phone is OFF (not in talk mode).

2. When reviewing the current record, press the answerer/delete button. The display shows

3. Press answerer/delete button again to confirm. The display shows

DELETE CALL ID?

DELETED

DELETING ALL CID RECORDS

1. Make sure the phone is OFF (not in talk mode).

2. Press the CID/VOL left (-) or right (+) arrow button until a CID record is displayed.

3. Press and hold answerer/delete. The display shows

4. Press answerer/delete again to erase all records.

DELETE ALL?

STORING CID RECORDS IN MEMORY

If necessary, format the CID information before storing it in memory.

1. Make sure the phone is OFF (not in talk mode).

2. Press the CID/VOL left (-) or right (+) arrow button until the desired Caller ID record is displayed.

3. Press the memory button.

4. Press a number key (0-9) to store the CID record in that memory location.

5. Press the memory button again to confirm. You will hear a confirmation tone.

NOTE: If the memory location is occupied, REPLACE MEMO? is displayed,

and you must confirm replacement by pressing the memory button.

STORING A REDIAL NUMBER

1. Make sure the phone is OFF (not in TALK mode).

2. Press the memory button.

3. Press any number key (0-9) to store the phone number in that memory location.

4. Press memory and

5. Use the handset number pad to enter the name, then press memory and

ENTER TEL NUMBR

6. Press redial to display the redial number and name.

7. P ress memory again to confirm.

NOTE: If the redial number has more than 24 digits, the redial number

cannot be stored in memory.

To r eplace an old redial number stored in a memory location with a new redial number:

1. Repeat steps 1 through 5, then press redial to display the new redial number and name.

2. Press memory again and the new redial number replaces the old redial number in that memory location.

ENTER NAME

shows on the display.

DIALING A CID NUMBER

1. Make sure the phone is OFF (not in TALK mode).

2. Use the CID/VOL left (-) or right (+) arrow button to display the desired Caller ID record.

3. Press the TALK/callback button to dial the number.

CHANGING THE NUMBER FORMAT

The FORMAT button lets you change the format of the displayed number. The available formats are as follows.

7-digit 7-digit telephone number. 10-digit 3-digit area code + 7-digit telephone number. 11- digit long distance code “1” + 3-digit area code + 7-digit

telephone number.

1. Make sure the phone is OFF (not in TALK mode).

2. Use the CID/VOL left (-) or right (+) arrow button to scroll to the number you want to call back.

3. If the number does not dial as shown, press the mute/format button. Repeat if necessary, until the correct number of digits are shown.

4. Press TALK/callback to dial the number.

MEMORY

Store up to ten 24-digit numbers in memory for quick dialing. This memory feature is in addition to the 40 Caller ID records that can be stored in memory.

STORING A NAME AND NUMBER IN MEMORY

1. Press the memory button.

2. Press the desired memory location button (0 through 9 keys). If the memory location is occupied, the memory location and stored name and number appear on the screen. If the memory location is empty,

EMPTY

3. Press the memory button again. The display shows

4. Use the handset touch-tone pad to enter a name (up to 15 characters). More than one letter is stored in each of the number keys. For example, to enter Bill Smith, press the 2 key twice for the letter B. Press the 4 key 3 times for the letter I. Press the 5 key 3 times for the letter L, then press the 5 key 3 times for the second letter L, and press the 1 key to insert a space between the first and last name. Press the 7 key 4 times for the letter S; press the 6 key once for the letter M; press the 4 key 3 times for the letter I; press the 8 key for the letter T; press the 4 key twice for the letter H.

5. Press the memory button again to save your selection. The display shows

6. Use the handset touch-tone pad to enter the area code followed by the telephone number (up to 24 digits, including pauses) and press the memory button again to save your selection. The unit beeps to confirm.

7. To enter another name and number in a different memory location, return to step 1 and repeat the process.

CHANGING A STORED NUMBER

Use the Storing A Number In Memory procedure to change a stored number, and simply replace the old phone number with a new phone number.

appears in the display.

ENTER NUMBER

ENTER NAME

DIALING A STORED NUMBER

1. Make sure the phone is ON by pressing the TALK/callback button.

2. Press the memory button.

3. Press the number (0-9) for the desired memory location. The number dials automatically.

1. Make sure the phone is OFF (not in TALK mode).

2. Press the memory button.

3. Use the CID/VOL left (-) or right (+) arrow button to scroll through the numbers stored in memory until the desired number is shown.

4. Press TALK/callback. The number dials automatically.

IMPORTANT: If you make test calls to emergency numbers stored in memory,

remain on the line and briefly explain the reason for the call to the dispatcher. Also, it’s a good idea to make these calls in off-peak hours, such as early morning or late evening.

CHAIN DIALING FROM MEMORY

Use this feature to make calls which require a sequence of numbers such as using a calling card for a frequently called long distance number. You dial each part of the sequence from memory. The following example shows how you can use chain dialing to make a call through a long distance service:

The Number For Memory Location

Long distance access number 7 Authorization code 8 Frequently called long distance number 9

1. Make sure the phone is ON by pressing the TALK/callback button.

2. Press the memory button and then press 7.

3. When you hear the access tone, press memory again and then press 8.

4. At the next access tone, press memory and then 9.

TIP: Wait for the access tones before pressing the memory button, or your call

might not go through.

INSERTING A PAUSE IN THE DIALING SEQUENCE

Press the # pause button to insert a delay in the dialing sequence of a stored telephone number. A pause is needed to wait for a dial tone (for example after you dial 9 for an outside line, or to wait for a computer access tone). Each pause counts as 1 digit in the dialing sequence.

REVIEWING AND DELETING STORED NUMBERS

1. Make sure the phone is OFF (not in TALK mode).

2. Press the memory button.

3. Use the CID/VOL left (-) or right (+) arrow button to scroll to the desired memory location or press 0-9.

4. While the entry is displaying, press the answerer/delete button to delete the entry. The display shows

DELETE?

5. Press answerer/delete again to confirm. The display shows

DELETED

ADVANCED FEATURES

TEMPORARY TONE

This feature is useful only if you use pulse dialing service. Temporary tone dialing enables pulse (rotary) service phone users to access touch-tone services offered by banks, credit card companies, etc. For example, when you call your bank you may need to enter your account number. Using the temporary tone feature allows you to temporarily switch to touch tone mode so you can enter and send your number.

1. Dial the telephone number and wait for the line to connect.

2. When your call is answered, press the *tone/exit button on your handset number pad to temporarily change from pulse dialing to tone dialing.

3. Follow the automated instructions to get the information you need.

4. Hang up the handset and the phone automatically returns to pulse (rotary) dialing mode.

+ 56 hidden pages
