We bring good things to life.
2.4 GHz Cordless Dual-Handset
Speakerphone/Answering System
with Call Waiting Caller ID
User’s Guide
21091
Page 3
2
US NUMBER IS LOCATED ON THE CABINET BOTTOM
REN NUMBER IS LOCATED ON THE CABINET BOTTOM
EQUIPMENT APPROVAL INFORMATION
Your telephone equipment is approved for connection to the Public Switched Telephone Network and is in compliance with
parts 15 and 68, FCC Rules and Regulations and the Technical Requirements for Telephone Terminal Equipment published
by ACTA.
1 Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other information, the US number and Ringer Equivalence
Number (REN) for the equipment. You must, upon request, provide this information to your telephone company.
The REN is useful in determining the number of devices you may connect to your telephone line and still have all of
these devices ring when your telephone number is called. In most (but not all) areas, the sum of the RENs of all
devices connected to one line should not exceed 5. To be certain of the number of devices you may connect to your
line as determined by the REN, you should contact your local telephone company.
A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the
applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug is
provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. See
installation instructions for details.
Notes
• This equipment may not be used on coin service provided by the telephone company.
•Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone equipment if
you are on a party line. Check with your local telephone company.
• Notice must be given to the telephone company upon permanent disconnection of your telephone from your line.
• If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this
product does not disable your alarm equipment. If you have questions about what will disable alarm equipment,
consult your telephone company or a qualified installer.
2 Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the telephone network, the telephone company shall,
where practicable, notify you that temporary discontinuance of service may be required. Where prior notice is not
practicable and the circumstances warrant such action, the telephone company may temporarily discontinue service
immediately. In case of such temporary discontinuance, the telephone company must: (1) promptly notify you of such
temporary discontinuance; (2) afford you the opportunity to correct the situation; and (3) inform you of your right to bring a
complaint to the Commission pursuant to procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.
The telephone company may make changes in its communications facilities, equipment, operations or procedures where
such action is required in the operation of its business and not inconsistent with FCC Rules and Regulations. If these changes
are expected to affect the use or performance of your telephone equipment, the telephone company must give you adequate
notice, in writing, to allow you to maintain uninterrupted service.
INTERFERENCE INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference; and (2) This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna (that is, the antenna for radio or television that is “receiving” the interference).
•Reorient or relocate and increase the separation between the telecommunications equipment and receiving antenna.
• Connect the telecommunications equipment into an outlet on a circuit different from that to which the receiving antenna is
connected.
If these measures do not eliminate the interference, please consult your dealer or an experienced radio/television
technician for additional suggestions. Also, the Federal Communications Commission has prepared a helpful booklet,
“How To Identify and Resolve Radio/TV Interference Problems.” This booklet is available from the U.S. Government Printing
Office, Washington, D.C. 20402. Please specify stock number 004-000-00345-4 when ordering copies.
HEARING AID COMPATIBILITY (HAC)
This telephone system meets FCC standards for Hearing Aid Compatibility.
Page 4
3
TABLE OF CONTENTS
EQUIPMENT APPROVAL INFORMATION........ 2
INTERFERENCE INFORMATION ................... 2
HEARING AID COMPATIBILITY (HAC)........ 2
INTRODUCTION ..................................... 5
HANDSET AND BASE LAY OUT .................. 7
BEFORE Y OU BEGIN .............................. 8
PARTS CHECKLIST ............................. 8
TELEPHONE JACK REQUIREMENTS ........ 8
IMPORTANT INSTALLATION INFORMATION .... 9
IMPORTANT INSTALLATION GUIDELINES .. 9
INSTALLING THE PHONE ........................ 10
CONNECTING THE T ELEPHONE LINE ..... 10
CONNECTING THE AC (ELECTRICAL)
POWER .......................................... 10
TELEPHONE SETUP ............................... 11
PROGRAMMABLE FUNCTIONS .............. 11
USING THE SOFT KEYS ..............11
LANGUAGE ......................................11
DISPLAY CONTRAST ......................... 12
AREA CODE ................................... 13
RINGER T ONE ................................. 15
TONE/PULSE .................................. 16
HANDSET REGISTRATION .................. 17
HANDSET DE-REGISTRATION .............. 20
GLOBAL DEREGISTRATION ................. 21
WALKIE T ALKIE ............................... 22
TIME OF DAY .................................. 24
DEFAULT ........................................ 24
CORDLESS PHONE BASICS .................... 26
SPEAKERPHONE .............................. 26
CHARGE INDICATOR ......................... 26
MAKING A CALL ............................. 26
HANDSET ............................... 26
SPEAKERPHONE ....................... 26
ANSWERING A CALL ........................ 27
HANDSET ............................... 27
SPEAKERPHONE ....................... 27
CALL T IMER .................................... 27
AUTO STANDBY .............................. 27
RINGER VOLUME CONTROL ............... 27
HANDSET ............................... 27
BASE ............................................ 28
CALL WAITING ................................ 28
FLASH ........................................... 29
LAST NUMBER REDIAL ..................... 29
HOLD ............................................ 29
EXIT ............................................. 30
PAGING ......................................... 30
TRANSFERRING CALLS ...................... 32
MUTE ........................................... 33
TEMPORARY T ONE DIALING ............... 33
CORDLESS HANDSET VOLUME
CONTROL ............................ 34
SPEAKERPHONE/ANSWERING
SYSTEM VOLUME CONTROL ... 34
INTERCOM ...................................... 34
SEE MARKING ON BOTTOM / BACK OF PRODUCT
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO
PREVENT FIRE OR
ELECTRICAL SHOCK
HAZARD, DO NOT
EXPOSE THIS
PRODUCT TO RAIN
OR MOISTURE.
THE LIGHTNING
FLASH AND ARROW
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
“DANGEROUS
VOLTAGE” INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR
BACK). NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
CAUTION:
Page 5
4
MAKING AN INTERCOM CALL ............. 34
RECEIVING AN INTERCOM CALL ... 35
RECEIVING AN EXTERNAL T ELEPHONE
CALL DURING AN INTERCOM CALL ..... 36
BETWEEN HANDSETS ................ 36
BETWEEN BASE AND HANDSET .. 36
USING INTERCOM OR
CONFERENCE WITH
EXTERNAL CALLS ................. 36
MEMORY ........................................... 37
STORING A NAME AND NUMBER IN
MEMORY ....................................... 38
STORING A REDIAL NUMBER ............. 39
INSERTING A PAUSE IN THE DIALING
SEQUENCE ..................................... 40
REVIEWING, CHANGING OR DELETING
STORED NUMBERS .......................... 40
TO REVIEW: ............................ 40
TO CHANGE: ........................... 40
TO DELETE: ............................ 41
DIALING A STORED NUMBER ............. 41
HANDSET ............................... 41
BASE ..................................... 42
CHAIN DIALING FROM MEMORY ......... 42
CALLER ID (CID) ............................... 43
RECEIVING AND STORING CID
RECORDS ....................................... 43
REVIEWING CID RECORDS ................ 44
TRANSFERRING CID RECORDS
TO
MEMORY................................... 44
DIALING A CALLER ID NUMBER ......... 45
DELETING THE CALLER ID RECORD
SHOWING IN THE DISPLAY ................. 46
DELETING ALL CALLER ID RECORDS .. 47
CALLER ID ERRORS ......................... 48
ANSWERING SYSTEM SET UP ............... 48
TURNING THE ANSWERING
SYSTEM OFF AND ON ...................... 49
RECORDING THE OUTGOING
ANNOUNCEMENT............................. 50
SAMPLE OUTGOING
ANNOUNCEMENT............................. 51
SETTING THE RINGS TO A NSWER ........ 51
SETTING THE SECURITY CODE
FOR
REMOTE ACCESS ....................... 52
DEFAULT SETTINGS ......................... 53
ANSWERING SYSTEM OPERATION .......... 54
STANDBY DISPLAY ........................... 54
SPEAKER VOLUME ........................... 54
SCREENING CALLS AT THE BASE ......... 54
MESSAGE PLAYBACK ....................... 55
ERASING MESSAGES ....................... 55
MEMO .......................................... 56
REMOTE ACCESS ............................. 57
ACCESSING THE ANSWERING
SYSTEM WITH THE
CORDLESS HANDSET ............. 57
SCREENING CALLS WITH THE
CORDLESS HANDSET ............. 57
ACCESSING THE ANSWERING
SYSTEM FROM ANOTHER LOCATION .... 58
MEMORY FULL ............................... 58
REPLACING THE BAT TERY ...................... 60
BATTERY SAFETY PRECAUTIONS......... 60
HEADSET AND BELT CLIP
INSTALLATION .............................. 61
CONNECTING AN OPTIONAL
HEADSET TO THE HANDSET ................ 61
CONNECTING THE BELT CLIP .............. 61
DISPLAY MESSAGES ............................ 62
HANDSET SOUND SIGNALS .................. 63
TROUBLESHOOTING GUIDE ................... 63
GENERAL PRODUCT CARE .................... 67
CAUSES OF POOR RECEPTION ............... 67
INDEX ............................................... 68
SERVICE ............................................ 70
ACCESSORY ORDER FORM ................... 71
LIMITED W ARRANTY ............................ 72
Page 6
5
INTRODUCTION
CAUTION: When using telephone equipment, there are basic safety
instructions that should always be followed. Refer to the IMPORTANT
SAFETY INSTRUCTIONS provided with this product and save them for
future reference.
Congratulations on purchasing this GE cordless telephone/answering
system with Call Waiting Caller ID. This telephone has been designed to be
simple to use, however, you can reach its full potential more quickly by
taking a few minutes to read this instruction book. This telephone is a
multifunction product for use with Call Waiting and Caller ID services
available from your local telephone company.
Your Caller ID Call Waiting phone allows you to:
• view the name and telephone number of a caller while you are on the
phone (Call Waiting Caller ID).
• identify callers before you answer the phone.
• view the time and date of each incoming call.
• record up to 40 Caller ID messages sequentially in each handset and
the base.
• know who called while you are on the other line or when you
were away.
• screen unwanted calls, eliminate harassment from annoying calls, or to
get prepared before answering a call.
Page 7
6
IMPORTANT: Because cordless phones operate on electricity, you should
have at least one phone in your home that isn’t cordless, in case the power in
your home goes out.
IMPORTANT: In order to use all of the features of this telephone, you must
subscribe to two separate services available from your local telephone
company: the standard Name/Number Caller ID Service to know who is
calling when the phone rings and Caller ID with Call Waiting Service to know
who is calling while you are on the phone.
INSTALLATION NOTE: Some cordless telephones operate at frequencies
that may cause interference to nearby TVs, microwave ovens, and VCRs. To
minimize or prevent such interference, the base of the cordless telephone
should not be placed near or on top of a TV, microwave ovens, or VCR. If such
interference continues, move the cordless telephone farther away from these
appliances. Certain other communications devices may also use the 2.4 GHz
frequency for communication, and, if not properly set, these devices may
interfere with each other and/or your new telephone. Typical devices that may
use the 2.4 GHz frequency for communication include wireless audio/video
senders, wireless computer networks, multi-handset cordless telephone
systems, and some long-range cordless telephone systems.
Page 8
7
HANDSET AND BASE LAYOUT
i
n
t
9
wxyz
6
mno
3
def
8
tuv
5
jkl
2
abc
7
pqrs
4
ghi
1
0
oper
#
pause
*
tone
v
v
ringerpage
f
l
a
s
h
r
e
d
ia
l
TALK
format
c
o
n
f
e
r
e
n
c
e
c
a
l
l
b
a
c
k
c
i
d
/
v
o
l
* tone button
# pause button
Display
format/
conference
button
TALK/callback
button
redial
button
page/int
button
ringer
button
flash
button
cid/vol
button
soft key
buttons
Back Side
9
wxyz
6
mno
3
def
8
tuv
5
jkl
2
abc
7
pqrs
4
ghi
1
0
oper
#
pause
*
tone
speaker
page/int.
charge/
VMWI
volume
v
v
v
v
r
e
d
i
a
l
f
o
r
m
a
t
r
i
n
g
e
r
f
l
a
s
h
c
o
n
f
.
c
a
l
l
b
a
c
k
memo
play/stop
C
I
D
/
m
e
s
s
a
g
e
s
CID/
messages
button
volume
button
charge/
indicator
page/int. button
* tone button
speaker/callback button
# pause button
format/
conference
button
ringer button
flash button
Display
redial button
soft key buttons
memo button
play/stop button
Page 9
8
BEFORE YOU BEGIN
PARTS CHECKLIST
Make sure your package includes the items shown here.
TELEPHONE JACK REQUIREMENTS
To use this phone, you need an RJ11C type modular
telephone jack, which might look like the one pictured
here, installed in your home. If you don’t have a
modular jack, call your local phone company to find out
how to get one installed.
Base
Dual HandsetsMounting pedestal
2 Belt clips
AC power supply
Telephone line cord
2 Handset
battery packs
i
n
t
9
wxyz
6
mno
3
def
8
tuv
5
jkl
2
abc
7
pqrs
4
ghi
1
0
oper
#
pause
*
tone
v
v
ringerpage
flash
r
e
d
i
a
l
TALK
format
c
o
n
f
e
r
e
n
c
e
c
a
l
l
b
a
c
k
c
i
d
/
v
o
l
i
n
t
9
wxyz
6
mno
3
def
8
tuv
5
jkl
2
abc
7
pqrs
4
ghi
1
0
oper
#
pause
*
tone
v
v
ringerpage
flash
r
e
d
i
a
l
TALK
format
c
o
n
f
e
r
e
n
c
e
c
a
l
l
b
a
c
k
c
i
d
/
v
o
l
Modular
telephone
line jack
Wall plate
9
wxyz
6
mno
3
def
8
tuv
5
jkl
2
abc
7
pqrs
4
ghi
1
0
oper
#
pause
*
tone
speaker
page/int.
charge/
VMWI
volume
v
v
v
v
r
e
d
i
a
l
f
o
r
m
a
t
r
i
n
g
e
r
f
l
a
s
h
c
o
n
f
.
c
a
l
l
b
a
c
k
memo
play/stop
C
I
D
/
m
e
s
s
a
g
e
s
charge
Handset Charge Cradle
Page 10
9
IMPORTANT INSTALLATION INFORMATION
• Never install telephone wiring during a lightning storm.
• Never install telephone jacks in wet locations unless the jack is
specifically designed for wet locations.
• Never touch non-insulated telephone wires or terminals, unless the
telephone line has been disconnected at the network interface.
• Use caution when installing or modifying telephone lines.
•Temporarily disconnect any equipment connected to the phone such as
faxes, other phones, or modems.
IMPORTANT INSTALLATION GUIDELINES
• Install telephone near both a telephone (modular) jack and an electrical
power outlet.
•Avoid sources of noise, such as a window by a busy street, and electrical
noise, such motors, microwave ovens, and fluorescent lighting.
•Avoid heat sources, such as heating air ducts, heating appliances,
radiators, and direct sunlight.
•Avoid areas of excessive moisture or extremely low temperature.
•Avoid dusty locations.
•Avoid other cordless telephones or personal computers.
Page 11
10
CONNECTING THE TELEPHONE LINE
On the base, plug the one end of the telephone line cord into the jack on
the back of the base and the other end into a modular phone jack.
NOTE: One base unit can support up to two handsets.
CONNECTING THE AC (ELECTRICAL) POWER
1. Plug the power supply cord into the power jack on the back of the
base and the other end into an electrical outlet.
2. Plug the handset charge cradle into an electrical outlet.
3. Place one handset in each cradle. The charge indicators turn on to
indicate the batteries are charging.
CAUTION: Use only the ATLINKS USA, Inc. power supply 5-2579 that
came with this unit. Using other power supplies may damage the unit.
Allow the system to charge for 12 hours prior to first use. If you don’t
properly charge the phone, battery performance is compromised.
INSTALLING THE PHONE
Choose the best location to install your base and handset charge cradle.
Your base and handset charge cradle should be placed on a level surface
such as a desk or table top, or you may mount the base on a wall.
Page 12
11
TELEPHONE SETUP
PROGRAMMABLE FUNCTIONS
This system uses a menu structure and soft key function buttons to give
you access to all of the built-in features.
USING THE SOFT KEYS
There are three buttons under the display box which represent several soft
key (programmable) functions. Use the buttons to activate the soft key
icons that appear in the display box. You may program the following items
with the soft keys: Language, Display Contrast, Area Code, Ringer Tone,
Time, Tone/Pulse, Registration, Deregistration, Walkie-Talkie, and Default
Setting.
LANGUAGE
This setting may be made with the handset or the base.
Make sure your phone is OFF (not in TALK mode).
1. Press the MENU soft key to go to the main menu.
2. Press cid/vol ( and ) button on the handset or the CID/messages
( and ) button on the base to scroll to
LANGUAGE
.
3. Press the OK soft key and
SET LANGUAGE 1ENG 2 FRA 3ESP
shows in
the display.
LANGUAGE
OK
AREA CODE
EXIT
Page 13
12
4. Use the touch tone pad on your handset to select
1ENG, 2FRA
, or
3ESP
,
or use the cid/vol ( or ) button on the handset or the CID/messages
( or ) button on the base to scroll to your selection. English is the
default setting.
NOTE: Press the EXIT soft key to keep the previous setting and return to the
main menu.
5. Press the OK soft key to save your selection, and return to the main
menu. The selected language displays for two seconds.
BASE DISPLAY HANDSET DISPLAY
DISPLAY CONTRAST
This setting may be made with the base only. Make sure your base is at
the main menu, and make sure your phone is OFF (not in TALK mode).
1. Press the CID/messages ( or ) button to scroll to
CONTRAST
.
SET LANGUAGE
OK
1 ENG 2 FRA 3 ESP
EXIT
ENGLISH
LANGUAGE
OK EXIT
AREA CODE
LANGUAGE
OK EXIT
CONTRAST
LANGUAGE
OK
CONTRAST
EXIT
Page 14
13
2. Press the OK soft key and
SET CONTRAST 1 2 3
shows in the display.
3. Use the touch tone pad on your base to select 1, 2, or 3, or use the CID/
messages ( or ) button to scroll to your selection. Contrast level 1 is
the default setting.
NOTE: Press the EXIT soft key to keep the previous setting and return to the
main menu screen.
4. Press the OK soft key to save your selection and return to the main
menu. The selected contrast level displays for two seconds.
AREA CODE
If you enter a 3-digit area code in the area code menu, your local area code
will not appear in Caller ID messages you receive. Instead, you will see
only the local seven digit number. Calls you receive from outside your
local area code will show the full ten-digit number.
SET CONTRAST
OK
1 2 3
EXIT
CONTRAST - 2
LANGUAGE
OK
CONTRAST
EXIT
Page 15
14
This setting may be made with the handset or the base. Make sure your
phone is OFF (not in TALK mode).
1. Press the cid/vol ( or ) button on the handset or the CID/messages
( or ) button on the base to scroll to
AREA CODE
.
HANDSET DISPLAY BASE DISPLAY
2. Press the OK soft key, and
SET AREA CODE
- - - shows in the display. - - -
is the default setting.
3. Use the touch-tone pad on your base or handset to enter your three digit
area code.
NOTE: Press the EXIT soft key to keep the previous setting and return to the
main menu screen.
4. Press the OK soft key to save your selection and return to the main
menu. The selected area code displays for two seconds.
HANDSET DISPLAY BASE DISPLAY
AREA CODE
OK EXIT
LANGUAGE
RINGER TONE
OK
AREA CODE
EXIT
LANGUAGE
OK
AREA CODE
EXIT
SET AREA CODE
OK
- - -
EXIT
AREA CODE - 317
RINGER TONE
OK
AREA CODE
EXIT
Page 16
15
RINGER TONE
Make sure your handset or base is at the main menu.
This setting may be made with the handset or the base. You may choose
from six different ringer tones. Make sure your phone is OFF (not in
TALK mode).
1. Press the cid/vol ( or ) button on the handset or the CID/messages
( or ) button on the base to scroll to
RINGER TONE
.
HANDSET DISPLAY BASE DISPLAY
2. Press the OK soft key and
SET RINGER TONE 1 2 3 4 5 6
shows in the
display. You will hear the current ringer tone.
3. Use the touch tone pad on your handset or base to select
1, 2, 3, 4, 5, 6 ,
or use
the cid/vol ( or ) button on the handset or the CID/messages ( or )
button on the base to scroll to your selection. The default setting is 1.
NOTE: When you use the handset or base to set a ringer tone, the ringer tone
plays after you make your selection.
NOTE: Press the EXIT soft key to keep the previous setting and return to the
main menu screen.
RINGER TONE
OK EXIT
REGISTRATION
RINGER TONE
OK
AREA CODE
EXIT
SET RINGER TONE
OK
1 2 3 4 5 6
EXIT
Page 17
16
4. Press the OK soft key to save your selection, and return to the main
menu. The new ringer tone is displayed for two seconds.
HANDSET DISPLAY BASE DISPLAY
TONE/PULSE
Most telephone systems use tone dialing, however, some may still use
pulse dialing. Depending on your telephone system, set the dialing mode
as follows:
This setting may be made with the base only. Make sure the base is at the
main menu. Make sure your phone is OFF (not in TALK mode).
1. Press the CID/messages ( or ) button on the base to scroll to
TONE/PULSE
.
2. Press the OK soft key and
SET TONE/PULSE 1TONE 2PULSE
shows in
the display.
3. Use the touch tone pad on the base to select
1TONE
or
2PULSE
, or press
the CID/messages ( or ) button to scroll to your selection. The default
setting is 1.
RINGER TONE
OK
REGISTRATION
EXIT
RINGER TONE
OK
AREA CODE
EXIT
TONE / PULSE
OK
TIME
EXIT
SET TONE / PULSE
OK
1 TONE 2 PULSE
EXIT
RINGER TONE - 2
Page 18
17
NOTE: Press the EXIT soft key to keep the previous setting and return to the
main menu screen.
4. Press the OK soft key to save your selection, and return to the main
menu. The dialing mode displays for two seconds.
NOTE: If you aren’t sure which dialing system you have, set the telephone to
tone dialing and make a test call. If the call connects, the setting is correct. If
the call does not connect, set the telephone to pulse dialing.
HANDSET REGISTRATION
This setting may be made with the handset only. During the registration
process, keep your handset near the base. When your handset shows the
following:
1. Press the cid/vol ( or ) button to scroll to
REGISTRATION
.
TONE
TONE / PULSE
OK
TIME
EXIT
RINGER TONE
OK
REGISTRATION
EXIT
OUT OF RANGE
MENU DIR
Page 19
18
2. Press the OK soft key and
REGISTER HANDSET?
shows in the display.
3. Press the OK soft key and
HOLD BASE PAGE WAIT FOR BEEP
shows in
the display.
4. Press and hold the page/int button on the base until you hear a long
beep and the handset displays
CONFIRM REGISTRATION?
5. Press the OK soft key on the handset to confirm the registration.
HANDSET # REGISTERED
displays for two seconds. When handset
registration is complete, you may name the handset.
ENTER NAME
shows in the display.
HOLD BASE PAGE
WAIT FOR BEEP
EXIT
CONFIRM
REGISTRATION ?
OK EXIT
HANDSET 2
REGISTERED
ENTER NAME
OK EXITDEL
REGISTER
OK
HANDSET ?
EXIT
Page 20
19
6. Use the touch-tone pad to enter the name.
More than one letter is stored in each of the number keys. For example,
to enter the name Bill Smith, press the 2 key twice for the letter B.
Briefly pause and the cursor moves to the next field. Press the 4 key 3
times for the letter I. Briefly pause and the cursor moves to the next
field. Press the 5 key 3 times for the letter L. Briefly pause and the cursor
moves to the next field. Press the 5 key 3 times for the second letter L,
press 1 key to add a space. Press the 7 key 4 times for the letter S.
Briefly pause and the cursor moves to the next field. Press the 6 key
once for the letter M. Briefly pause and the cursor moves to the next
field. Press the 4 key 3 times for the letter I. Briefly pause and the cursor
moves to the next field. Press the 8 key for the letter T. Briefly pause and
the cursor moves to the next field. Press the 4 key twice for the letter H.
NOTE: If you make a mistake press the DEL soft key to backspace and erase
the wrong character(s).
NOTE: Press the EXIT soft key once to keep the previous setting and return to
the main menu. Or press and hold the EXIT soft key on the handset to return
to standby mode.
7. P ress the OK soft key to save the name and return to the main menu.
You will hear a confirmation tone.
ENTER NAME
OK EXITDEL
B
ENTER NAME
OK EXITDEL
BILL SMITH
BILL SMITH
HANDSET 2
MENU DIR
ANS
Page 21
20
HANDSET DE-REGISTRATION
This setting may be made with the handset only. Deregistration cancels a
handset’s registration. If you do not know a handset’s name, you should
deregister the handset according to the steps below. During the deregistration process, keep the handset near the base.
WARNING: It is not recommended that a handset be de-registered unless
absolutely necessary because once a handset is de-registered, that handset's
telephone features cannot be used until the handset is re-registered.
Make sure your handset is in menu mode. Make sure your phone is OFF
(not in TALK mode).
1. Press the cid/vol ( or ) button to scroll to
DEREGISTRATION
.
2. Press the OK soft key and
DE-REGISTER HANDSET?
shows in the display.
3. Press the OK soft key to de-register the handset, and
MOVE NEAR TO
BASE
displays until the handset is moved closer to the base.
WALKIE TALKIE
OK EXIT
DEREGISTRATION
DE - REGISTER
HANDSET 1 ?
OK EXIT
MOVE NEAR TO
BASE
EXIT
Page 22
21
Then the handset displays
CONFIRM DEREGISTRATION?
NOTE: Press the EXIT soft key once to keep the previous setting and return to
the main menu screen.
4. Press the OK soft key to confirm the deregistration.
HANDSET #
DEREGISTERED
followed by
REGISTER HANDSET?
shows in the display.
GLOBAL DEREGISTRATION
If one or more handsets becomes lost, you should de-register all handsets
to ensure proper system operation.
WARNING: It is not recommended that a handset be de-registered unless
absolutely necessary because once a handset is de-registered, that handset's
telephone features cannot be used until the handset is re-registered.
1. Press and hold the base page/int button on the base until the charge
indicator flashes.
2. Press and hold the base page/int button again until the charge indicator
flashes rapidly.
3. Press and release the page/int button on the base. The charge indicator
stops blinking, and the base display shows
ALL HANDSET
DEREGISTERED
for five seconds to confirm that all handsets are deregistered. Then the base returns to standby mode, and each handset
displays
REGISTER HANDSET?
CONFIRM
DEREGISTRATION ?
EXIT
OK
HANDSET 1
DEREGISTERED
Page 23
22
WALKIE TALKIE
This feature allows a pair of handsets to be used like walkie talkies
(electrical power to the base unit is not required for walkie talkie
operation). This setting may be made with the handset only. Make sure
both handsets are at the main menu.
1. On both handsets, press the cid/vol ( or ) button to scroll to
WALKIE TALKIE
.
2. On both handsets, press the OK soft key and
WALKIE TALKIE ENABLE?
shows in the display.
3. On both handsets, press the OK soft key and
WALKIE TALKIE ENABLED
followed by
WALKIE TALKIE HANDSET# shows
in the display.
NOTE: Both handsets must be in walkie talkie mode to send and receive.
4. Press the page/int button on either handset, and then enter the handset
number/extension you want to call. The selected handset is paged.
When the page/int or TALK button on the receiving handset is pressed,
and the page is answered, the walkie talkie feature is activated between
both handsets. Both handsets display
WALKIE TALKIE WITH HANDSET #
.
DEREGISTRATION
WALKIE TALKIE
OK EXIT
WALKIE TALKIE
ENABLE ?
OK EXIT
WALKIE TALKIE
ENABLED
WALKIE TALKIE
HANDSET 1
EXIT
Page 24
23
5. When your conversation is finished, either the sending or receiving
handset may press the EXIT soft key to disable the walkie talkie and
return to the walkie talkie standby mode.
NOTE: Only one handset is required to press EXIT to terminate the
conversation. If EXIT is pressed on both handsets, one handset exits the
walkie talkie standby mode and returns to the normal standby mode.
6. Press the EXIT soft key again to disable the walkie talkie and return the
handset to standby mode.
WALKIE TALKIE DISABLED
shows briefly in
the display.
NOTE: When two handsets are in walkie talkie mode, they are isolated from
the base and cannot receive pages or dial out until the walkie talkie is disabled.
NOTE: While in walkie talkie mode, neither handset rings for incoming calls,
and incoming calls may not be answered until the walkie talkie is disabled.
WALKIE TALKIE
EXTENSION ?
EXIT
PAGING
HANDSET #
EXIT
WALKIE TALKIE
WITH HANDSET #
MUTE
EXIT
WALKIE TALKIE
HANDSET #
EXIT
WALKIE TALKIE
DISABLED
NAME
HANDSET 1
DIR
MENU
ANS
Page 25
24
TIME OF DAY
This setting may be made with the base only. Make sure your base is at
the main menu. Make sure your phone is OFF (not in TALK mode).
1. Press the CID/messages ( or ) to scroll to
TIME
.
2. Press the OK soft key and
SET TIME - - : - - AM PM
shows in the display.
3. Use the touch-tone pad to enter the current time. The cursor
automatically moves to the AM field. Press the CID/messages ( or )
button to move the arrow to
PM.
4. Press the OK soft key to save your selection. The current time displays
for two seconds. Then the screen displays
SET DATE M T W H F S SU
.
NOTE: If you want to keep the current time, press the OK soft key when the
display shows - - : - - AM PM. You will hear two beeps, and the current time
displays for two seconds.
5. Press the CID/messages ( or ) to scroll to and select the day.
6. Press OK soft key to save your selection.
DEFAULT
As you become familiar with this system, you may prefer to use the
system’s original settings. Follow the steps below to return to the factory
default settings.
SET DATE
M T W H F S SU
TONE/PULSE
TIME
EXIT
OK
SET TIME
_ _ : _ _ AM PM
EXIT
OK
Page 26
25
Make sure your handset or base is in menu mode. Make sure your phone
is OFF (not in TALK mode).
1. Press the cid/vol ( or ) button on the handset or CID/messages
( or ) button on the base to scroll to
DEFAULT SETTING
.
2. Press the OK soft key and then use the touch-tone pad on your handset
or base to enter
1YES
or
2NO
, or use the cid/vol ( or ) button on your
handset or the CID/messages ( or ) button on your base to scroll to
your selection.
2NO
is the default setting.
NOTE: If you choose YES all settings in the programmable menu return to the
factory default settings.
NOTE: Press the EXIT soft key once to keep the previous setting and return to
the main menu.
3. Press the OK soft key to save your selection, and return to the main
menu. The default setting you choose shows on the display for two
seconds.
HANDSET & BASE DISPLAY HANDSET & BASE DISPLAY
DEFAULT SETTING
LANGUAGE
EXIT
OK
DEFAULT SETTING
1 YES 2NO
EXIT
OK
DEFAULT SETTING
LANGUAGE
EXIT
OK
DEFAULT SETTING
NO
Page 27
26
CORDLESS PHONE BASICS
SPEAKERPHONE
For hands-free operation and convenience, your dual-handset system is
equipped with a speakerphone.
For best speakerphone performance, avoid the following:
• Areas with high background noise. (The microphone might pick up
these sounds.)
• Surfaces affected by vibration.
•Recessed areas such as in a corner, under a cupboard, or next to a
cabinet, which can generate an echo effect.
Note the following guidelines when using the speakerphone:
• Stay reasonably close to the phone so that you can be clearly heard by
the person to whom you are talking.
CHARGE INDICATOR
When the charge indicator is lit, the handset is correctly seated in the
cradle and is charging. The indicator flashes when the base is paged, when
the base pages the handset, or when you receive an incoming call.
MAKING A CALL
HANDSET
1. Pick up the handset and press the talk/callback button on the handset.
Listen for a dial tone.
2. Dial the desired number, or pre-dial the number first then press the talk/
callback button.
3. When finished, press the talk/callback button again to hang up.
SPEAKERPHONE
1. Press the speaker/callback button on the base. You will hear a dial tone.
2. Dial the number you wish to call. Or, you may pre-dial the number and
then press the speaker/callback button.
3. When finished, press the speaker/callback button to hang up.
Page 28
27
ANSWERING A CALL
HANDSET
1. When the phone rings, press the talk/callback button on the handset.
2. When finished, press the talk/callback button again to hang up.
SPEAKERPHONE
1. When the phone rings, press the speaker/callback button to answer a call.
2. When finished press speaker/callback to hang up.
NOTE: If you are using the handset and want to switch to the speakerphone,
press the speaker/callback button on the base first, and then either press the
talk/callback button on the handset to switch it off, or put the handset in the
base cradle. When the speaker/callback button is pressed, the button lights.
If you want to switch from speakerphone to handset, press the talk/callback
button on the handset first, and then press the speaker/callback button on
the base.
CALL TIMER
After you press talk/callback on the handset or speaker/callback on the
base, the built-in call timer shows in the display and counts the length of
time of the call in minutes and seconds.
AUTO STANDBY
Placing the handset in the base cradle or handset charge cradle while the
handset is off hook (during a call) automatically hangs up the handset.
RINGER VOLUME CONTROL
HANDSET
1. Press the ringer button and the current ringer setting shows in the display.
1 ON 2 OFF
RINGER ON
EXIT
OK
Page 29
28
1 HI 2 LO 3 OFF
EXIT
OK
RINGER HIGH
RINGER LOW
2. Use the touch-tone pad on your handset to enter
1 ON
or
2 OFF,
or use
the cid/vol ( or ) to scroll to your selection.
3. Press the OK soft key to save your selection. You will hear a confirmation
tone, and the ringer setting displays for two seconds.
NOTE: If you turn the ringer OFF, the ringer off icon shows in the display.
BASE
1. Press the ringer button and the current ringer setting shows in the display.
2. Use the touch tone pad on your handset to enter
1HI, 2LOW
, or
3OFF
, or
use the CID ( or ) to scroll to your selection.
3. Press the OK soft key to save your selection, and the ringer setting
shows in the display for two seconds then returns to standby mode.
CALL WAITING
If you subscribe to the combined Call Waiting Caller ID service from your local
telephone company, you will receive Caller ID information (if available) on Call
RINGER ON
NAME
MENU
HANDSET 1
DIR
ANS
Page 30
29
Waiting calls. During a phone call you will hear a beep, which indicates
another call is waiting on the line, and Caller ID information shows in the
handset display. To connect to the waiting call, press the flash button on the
handset or base, and your original call is put on hold. You may switch back
and forth between the two calls by pressing the flash button.
FLASH
Use the flash button on the handset or base to activate custom calling
services, such as call waiting, which are available through your local
phone company.
TIP: Don’t press the talk/callback button on the handset or the speaker/
callback button on the base to activate a custom calling service, such as call
waiting, or you’ll hang up the phone.
LAST NUMBER REDIAL
To quickly redial the last number you dialed:
1. Press the talk/callback button on the handset or the speaker/callback
button on the base.
2. Press the redial button.
-OR-
3. Press the redial button first then press the talk/callback button or the
speaker/callback button.
-OR-
4. If you get a busy signal and want to keep dialing the number, press the
redial button to quickly redial the number.
HOLD
When you are on the phone, press the HOLD soft key on the handset or
base to put a call on hold.
LINE ON HOLD
shows in the handset display.
LINE ON HOLD
CONF
TALK 00:10 VOL 2
EXIT
TRANS
Page 31
30
MUTE
TALK 00:05 VOL 2
DIR
HOLD
LINE ACTIVE
PAGING
EXTENSION ?
EXIT
Your phone stays on hold until you press the EXIT soft key and release the
line, or press the talk/callback or speaker/callback button to return to
standby mode. If you continue the call on a separate extension phone, or
other registered handset, your cordless phone releases the line to the
extension phone.
If the handset with the call on hold is placed back on the cradle, the holding
call is transferred to the base speakerphone and the handset returns to
standby mode.
EXIT
Press the EXIT soft key to end an operation, such as HOLD or
TRANSFER. The display shows
LINE ACTIVE
for two seconds then
returns to the TALK mode.
PAGING
This feature helps you locate a misplaced handset and send and receive
pages for intercom calls. All handsets must be registered to use the page
function. If your handsets are not registered, follow the instructions in the
Handset Registration section of this manual.
Make sure the phone is OFF (not in TALK mode).
1. Press the page/int button on the handset or base.
Page 32
31
2. Use the touch tone pad on your handset or base to select
1
or 2.
PAGING
EXTENSION
shows in the display.
NOTE: Press the * key to page all registered handsets or press the 0 key to
page the base.
3. The receiving handset or base is paged, and both the sending and
receiving handsets or base emit a paging tone and the following
information shows in the display:
SENDING HANDSET/BASE
RECEIVING HANDSET/BASE
When the talk/callback or speaker/callback or page/int on the receiving
handset or base is pressed, the page is answered. If the page is not answered
after two minutes,
NO ANSWER
shows in the display of sending handset or
base and the page is cancelled. The unit returns to standby mode.
NOTE: If a personalized name is assigned to the handset during registration,
then that name is displayed instead of handset number.
NOTE: To cancel the page, press the EXIT soft key or the page/int button at
the sending handset or base.
HANDSET 2
EXIT
PAGING
HANDSET 1
PAGING FROM
Page 33
32
HANDSET 2
PAGING FROM
STEVE
EXIT
PAGING/LINE ON HOLD
TRANSFERRING CALLS
This feature lets you transfer calls between handsets or the base in
TALK mode.
1. Press the HOLD soft key to put the call on hold.
2. Press the TRANS soft key.
3. Enter the handset number you want to transfer the call to, and the
receiving handset is paged. During the page, a page tone is emitted on
the receiving handset. For example, HANDSET 2 pages Steve’s handset
and the following information shows in the displays:
RECEIVING HANDSET
SENDING HANDSET
TALK 00:10 VOL 2
TRANS
CONF
EXIT
LINE ON HOLD
EXTENSION ?
EXIT
LINE ON HOLD
TALK 00:10 VOL 2
HOLD
MUTE DIR
Page 34
33
NOTE: If the page isn’t answered, press the EXIT soft key or the page/int
button to cancel the transfer.
When the page/int or talk/callback button is pressed on the receiving
handset, the unit goes into intercom mode. When the talk/callback button
on the sending handset is pressed, the call is transferred.
Note: 1) If talk/callback button on the sending handset is pressed BEFORE
page/int or talk/callback button is pressed on the receiving handset, the
receiving handset emits the ringer tone (not the page tone), and
TRANSFERRING FROM
and the handset number shows in the display.
2) If the other extension does not take the call within 30 seconds, the call is
transferred back to your handset or base, and
CALLBACK
is displayed.
MUTE
To have a private, off-line conversation use the mute feature. The party on
the other end of the line cannot hear you, but you can still hear them.
1. During a phone conversation press the MUTE soft key.
MUTE ON
shows
in the display.
2. Press the MUTE soft key again to cancel mute and return to your phone
conversation.
TEMPORARY TONE DIALING
This feature is useful only if you use pulse dialing service. Temporary tone
dialing enables pulse (rotary) service phone users to access touch-tone
services offered by banks, credit card companies, etc. For example, when
TALK 00:10 VOL 2
HOLD
MUTE ON
MUTE DIR
TALK 00:05 VOL 2
HOLD
MUTE DIR
Page 35
34
you call your bank you may need to enter your account number. Using the
temporary tone feature allows you to temporarily switch to touch tone
mode so you can enter and send your number.
1. Dial the telephone number and wait for the line to connect.
2. When your call is answered, press the *tone button on your handset
number pad to temporarily change from pulse dialing to tone dialing.
3. Follow the automated instructions to get the information you need.
4. Hang up the handset and the phone automatically returns to pulse
(rotary) dialing mode.
CORDLESS HANDSET VOLUME CONTROL
When the cordless handset is ON (in TALK mode) adjust the receiver
volume by pressing the cid/vol ( or ) button on the cordless handset.
There are four volume levels, and each press of the cid/vol ( or ) button
adjusts the receiver volume by one level.
SPEAKERPHONE/ANSWERING SYSTEM VOLUME CONTROL
When the speakerphone is ON, adjust the volume by pressing the ( or )
buttons on the base. There are eight volume levels, and each press of the
volume button adjusts the speaker volume by one level.
NOTE: You may also adjust the volume during walkie talkie mode, intercom
mode, and conference mode.
INTERCOM
The intercom feature allows you to have an unlimited-duration, two-way
conversation between two handsets or the base and a handset.
MAKING AN INTERCOM CALL
1. Make sure the phone is OFF (not in TALK mode).
2. Press the page/int button on the handset or base.
PAGING EXTENSION
shows in the display.
Page 36
35
3. Enter the handset number you want to intercom with, or enter 0 to
intercom with the base. The receiving party is paged.
NOTE: To cancel the page, press the page/int button again or press the
EXIT button.
THE SENDING PARTY THE RECEIVING PARTY
4. When the receiving party answers the page, the intercom is activated.
When the intercom is setup the following information shows in the display:
THE SENDING PARTY THE RECEIVING PARTY
5. When finished, press the EXIT soft key or the page/int button on either
handset to deactivate the intercom.
NOTE : During the intercom, if a handset is assigned a name, that name is
displayed instead of handset number.
RECEIVING AN INTERCOM CALL
When an intercom call is received, the handset or base beeps. To answer
the intercom call, press the page/int or speaker/callback button on the base
or the talk/callback button on the handset.
EXTENSION ?
EXIT
PAGING
HANDSET 2
PAGING FROM
HANDSET 1
EXIT
INTERCOM
MUTE
HANDSET 1
EXIT
PAGING
HANDSET 2
EXIT
INTERCOM
MUTE
Page 37
36
EXTENSION ?
EXIT
LINE ON HOLD
RECEIVING AN EXTERNAL TELEPHONE CALL DURING AN INTERCOM CALL
BETWEEN HANDSETS
If you receive a telephone call during an intercom call, both users are
alerted with a beep in the earpiece every 4 seconds. Press the talk/callback
button on the handset to end the intercom first, and then press the talk/
callback button again to answer the external telephone call.
BETWEEN BASE AND HANDSET
If you receive a telephone call during an intercom call, the intercom
between the handset and the base automatically ends and the unit rings.
Press the talk/callback on the handset or the speaker/callback button on the
base to take the external telephone call.
USING INTERCOM OR CONFERENCE WITH EXTERNAL CALLS
During an external telephone call, you may page other handsets and have offline, private intercom conversations between an external caller and the
handsets, or you may have a 3-way conference with external line and another
handset or the base.
1. During an external call, press the HOLD soft key on the handset to place
the external call on hold.
LINE ON HOLD
shows in the sending handset
or base display.
2. Press the CONF soft key on your handset or base.
LINE ON HOLD
EXTENSION?
shows in the display.
TALK 00:10 VOL 2
EXIT
LINE ON HOLD
CONF
TRANS
Page 38
37
3. Enter the handset number you want to conference with, or enter 0 to
conference with the base. The receiving party is paged.
SENDING HANDSET RECEIVING HANDSET
4. The receiving handset or base must press the page/int or speaker/
callback button on the base or the talk/callback button on the handset to
answer the intercom, then both intercom users may speak privately. The
external caller cannot hear the intercom conversation.
SENDING HANDSET RECEIVING HANDSET
5. Either sending or receiving party may press the format/conference
button to start the 3-way conference.
NOTE: Press the EXIT soft key on either handset to cancel the intercom call,
and the sending party may continue to talk to the external party. Or the calling
party may press the talk/callback button to transfer the call to the receiving
party who may speak to the external caller independently.
NOTE: A handset or the base can enter conference directly by pressing talk/
callback on the base while the other handset or the base is on an external call.
MEMORY
The handset and base each have their own separate memory dialing
storage areas. Fifty 15-character names and 24-digit telephone numbers
can be stored in the handset memory. Fifty 15-character names and 24digit telephone numbers can be stored in the base memory.
HANDSET 2
EXIT
PAGING/LINE ON HOLD
HANDSET 1
PAGING FROM
HANDSET 2
LINE ON HOLD/INTERCOM
EXIT
MUTE
HANDSET 1
INTERCOM
EXIT
MUTE
Page 39
38
STORING A NAME AND NUMBER IN MEMORY
1. Make sure the phone is OFF (not in TALK mode).
2. Press the DIR soft key.
3. Press the desired memory location button (01 through 50) or, use the cid/
vol ( or ) button on handset or CID/messages ( or ) button on the
base to select the memory location. If the memory location is occupied, the
memory location and stored name and number appear in the display. If the
memory location is empty,
EMPTY
shows in the display.
4. Press the EDIT soft key. The display shows
ENTER NAME
.
5. Use the touch-tone pad on your handset or base to enter a name (up to
15 characters). More than one letter is stored in each of the number
keys. For example, to enter Bill Smith, press the 2 key twice for the letter
B. Press the 4 key 3 times for the letter I. Press the 5 key 3 times for the
letter L. Wait for 1 second. Press the 5 key 3 times for the second letter L,
HANDSET 1
NAME
MENU DIR
* * EMPTY * *
EXIT
0 3
MEMO
#
EDIT
DEL
ENTER NAME
EXIT
0 3
MEMO
#
OK DEL
SELECT MEMORY
EXIT
--
MEMO
#
01-50
Page 40
39
and press the 1 key to insert a space between the first and last name.
Press the 7 key 4 times for the letter S; press the 6 key once for the letter
M; press the 4 key 3 times for the letter I; press the 8 key for the letter T;
press the 4 key twice for the letter H.
6. Press the OK soft key to confirm your selection. The display shows
ENTER TEL NUMBR
.
7. Use the touch-tone pad on your handset or base to enter the area
code followed by the telephone number (up to 24 digits, including
pauses) and press the OK soft key again to save your selection. The
unit beeps to confirm.
8. To enter another name and number in a different memory location,
please follow step 1 and repeat the process.
STORING A REDIAL NUMBER
1. Make sure the phone is OFF (not in TALK mode).
2. Press the DIR soft key.
3. Press any number key (01-50) to store the phone number in that
memory location, or press the cid/vol ( or ) button on the handset or
CID/messages ( or ) button on the base to select the memory
location.
4. Press the EDIT soft key and
ENTER NAME
shows in the display.
5. Use the touch-tone pad on your handset or base to enter the name, then
press the OK soft key and
ENTER TEL NUMBR
shows in the display.
ENTER TEL NUMBR
EXIT
0 3
MEMO
#
OK DEL
HANDSET 1
DIR
MENU
NAME
ANS
Page 41
40
PETER CHAN
EXIT
EDIT
317 - 123 - 4567
DEL
0 3
MEMO
#
6. Press the redial button to display the redial number.
7. P ress the OK soft key again to confirm.
NOTE: If the redial number has more than an 24 digits, the redial number
cannot be stored in memory.
INSERTING A PAUSE IN THE DIALING SEQUENCE
If a pause is needed to wait for a dial tone press the # pause button on
the touch-tone pad to insert a delay in dialing sequence of a stored
telephone number (for example, after you dial 9 for an outside line, or
wait for a computer access tone.) Each pause counts as one digit in the
dialing sequence.
REVIEWING, CHANGING OR DELETING STORED NUMBERS
TO REVIEW:
1. Make sure the phone is OFF (not in TALK mode).
2. Press DIR soft key.
3. Press the cid/vol ( or ) button on the handset or CID/messages ( or )
button on the base to scroll through the stored numbers. Or use the touchtone pad on your handset or base to enter the memory location number.
TO CHANGE:
Use the same procedure to change a stored number as you do to store a
number except replace one stored phone number with a different one.
HANDSET 1
DIR
MENU
NAME
ANS
Page 42
41
TO DELETE:
1. Make sure the phone is OFF (not in TALK mode).
2. Press DIR soft key
3. Press the cid/vol ( or ) button on the handset or CID/messages
( or ) button on the base to scroll to a desired record.
4. When the record shows in the display, press the DEL soft key to mark
the record for deletion. The display shows
DELETE?
5. Press the OK soft key to delete the record.
DELETED
shows in the display.
NOTE: If you don’t want to change or delete a number, simply press EXIT
soft key, or wait for one minute to exit the review mode automatically.
DIALING A STORED NUMBER
HANDSET
1. Make sure the phone is ON by pressing the talk/callback button.
2. Press the DIR soft key.
3. Enter the memory location number (01-50) for the desired memory
location. The number will be dialed automatically.
-OR-
1. Make sure the phone is OFF (not in TALK mode).
2. Press the DIR soft key.
DELETE ?
EXIT
OK
317 - 123 - 4567
0 3
MEMO
#
* * DELETED * *
Page 43
42
3. Press the number key (01-50) for the desired memory location or use the
cid/vol ( or ) button to scroll through memory until the desired
number displays.
4. Press the talk/callback button. The number dials automatically.
BASE
1. Make sure the phone is ON by pressing the pressing the speaker/
callback button.
2. Press the DIR soft key.
3. Press the number key (01-50) for the desired memory location. The
number dials automatically.
-OR-
1. Make sure the phone is OFF (not in talk mode)
2. Press the DIR soft key.
3. Press the number key (01-50) for the desired memory location, or use
the CID/messages ( or ) button to scroll through memory until the
desired number displays.
4. Press the speaker/callback button. The number dials automatically.
CHAIN DIALING FROM MEMORY
Use this feature to make calls that require a sequence of numbers, such as
a calling card number used for a frequently called long distance number.
The following example shows how you can store each part of the long
dialing sequence and use chain dialing to make a call through a long
distance service:
1. Make sure the phone is ON .
The Number For Memory Location
Long Distance Access Number 7
Authorization Code 8
Frequently called long distance number 9
Page 44
43
2. Press DIR soft key and then press 07.
3. When you hear the access tone, press DIR soft key, and then press 08.
4. At the next access tone, press DIR soft key then press 09.
CALLER ID (CID)
Caller ID (CID) is a service available from your local telephone company.
For Caller ID to work on this system, you must subscribe to Caller ID
service. To receive Caller ID information for a Call Waiting call, you must
subscribe to the combined Caller ID Call Waiting service.
When your telephone rings, and you are subscribed to Caller ID Call
Waiting service, you will receive information (if available) transmitted by
your local telephone company. You will also receive Caller ID information
from Call Waiting calls. If you receive an incoming call and you are already
on the phone, a beep indicates the presence of a Call Waiting Call on the
line, and Caller ID information for the Call Waiting call shows on the
display. This information may include the phone number, date and time; or
the name, phone number, and date and time.
RECEIVING AND STORING CID RECORDS
When you receive a call, Caller ID information is transmitted by the phone
company to your Caller ID telephone between the first and second ring.
The Caller ID information appears on the display while the phone rings,
giving you a chance to monitor the information and decide whether or not
to answer the call.
If you are not at home or cannot answer, your telephone’s Caller ID
memory automatically stores the call number, date, time, phone number,
and name for the 40 most recent calls received so you can see who called
while you were unavailable. Caller ID records are stored sequentially, in
the order they are received. When the 41st call is received, the oldest
Caller ID record is automatically deleted.
You may review the stored information for the most recent 40 calls at any
time. Calls received since your last review show as
NEW
in the display.
Page 45
44
REVIEWING CID RECORDS
As CID records are received and stored, the display is updated to let you
know how many calls have been received.
1. Press the cid/vol () on the handset or the CID/messages () button on
the base to review the oldest call and scroll toward the most recent calls
(higher numbers). When you reach the newest call, the display shows
END OF LIST
.
2. Press the cid/vol () button on the handset or CID/messages () button
on the base to review the newest call and scroll to older calls (lower
numbers). When you reach the oldest call, the display shows
END OF LIST
.
As you review calls, the display shows you the following information for
each call:
• The telephone number of the caller.
• The number of the call, with regard to the order received.
• The name of the caller, if this service is available in your area.
NOTE: If a name is received which exceeds 15 characters, the extra characters
are removed.
•Time and date the call was received.
•
NEW
appears at the top right corner of the display for all calls that have
not been reviewed.
NOTE: Check with your local phone company regarding name service
availability.
•
NEW
and
REPT
appears at the top right corner of the display for all
calls received more than once which have not been reviewed.
TRANSFERRING CID RECORDS TO MEMORY
You may transfer a Caller ID record to your phone ’s memory.
NOTE: It is important that you format CID records correctly before storing in
memory. It is not possible to reformat CID records stored in memory. For
details, please see Dialing a Caller ID Number.
Page 46
45
1. Use the cid/vol ( or ) button on the handset or CID/messages ( or )
button on the base to scroll to the desired CID record.
2. Press the SAVE soft key.
3. Press the desired memory location button. Example, press the number
01 key to store the record in memory location 1. If the memory location
is occupied and, you want to replace it, you must confirm the
replacement by pressing the OK soft key.
NOTE: Press EXIT soft key once to keep the previous setting and return to
the Caller ID menu. Or, press and hold the EXIT soft key on handset to return
to standby mode.
DIALING A CALLER ID NUMBER
While reviewing Caller ID records, you may dial the phone number
showing in the display.
1. Make sure the phone is OFF (not in talk mode).
2. Press cid/vol ( or ) button on the handset or CID/messages ( or )
button on the base until the desired CID record is displayed. Depending
on (a) how the incoming phone number was formatted when it was
received, and (b) whether or not you previously pre-programmed your
PETER CHAN
EXIT
SAVE
317 - 123 - 4567
01
CALL
#
DEL
9:58
AM
11/24
NEW
01-50
EXIT
SELECT MEMORY
--
#
MEMO
REPLACE MEMO?
EXIT
765-4321
01
#
MEMO
OK
Page 47
46
HANDSET 1
DIR
MENU
NAME
ANS
local area code into memory, you may need to adjust the format of the
incoming caller ’s stored phone number before dialing it back. The
format button lets you change the format of the displayed number.
Available formats include:
Number of digits Explanation Example
Eleven digits long distance code “1 ” 1-317-888-8888
+3- digit area code +7-digit
telephone number.
Ten digits 3-digit area code +7-digit 317-888-8888
telephone number.
Seven digits 7-digit telephone number. 888-8888
NOTE: If the incoming number is a Direct Dial Number, it is supplied by your
local phone company, and you may not adjust its format. When you press the
format/conference button on handset or the format/conf. button on the base,
PRESS TALK KEY displays. Press the talk/callback button on handset or the
speaker/callback button on base to dial the number.
3. If the number does not dial as shown, press the format/conference
button on handset or format/conf on the base. Repeat if necessary, until
the correct number of digits show in the display.
4. Press the talk/callback button on the handset or speaker/callback on the
base. The number dials automatically.
NOTE: If the number is corrupted, such as a number in a name or an
alphabetical character in a number, an error tone sounds from the handset or
base and the number cannot be dialed.
DELETING THE CALLER ID RECORD SHOWING IN THE DISPLAY
1. Make sure the phone is OFF (not in talk mode).
Page 48
47
2. Use the cid/vol ( or ) button on the handset or CID/messages
( or ) button on the base to display the desired CID record.
3. Press DEL soft key. The display shows
DELETE CALL ID?
4. Press OK soft key to erase the record. The display shows briefly shows
DELETED
, and then confirms the deletion with a confirmation tone.
NOTE: Press EXIT soft key once to return to the CID review menu. Or, press
and hold the EXIT soft key on the handset to return to standby mode.
DELETING ALL CALLER ID RECORDS
To delete all of the Caller ID records in memory:
1. Make sure the phone is OFF (not in talk mode).
* *DELETED * *
STEVE
EXIT
SAVE
12 34567890 1 2 34 5
01
CALL
#
DEL
9:58
AM
11/24
NEW
DELETE CALL ID?
EXIT
OK
HANDSET 1
DIR
MENU
NAME
ANS
Page 49
48
NAME
EXIT
SAVE
12 34567890 1 2 34 5
01
CALL
#
DEL
9:58
AM
11/24
NEW
DELETE ALL ?
EXIT
OK
NO CALLS
2. Use the cid/vol ( or ) button on the handset or CID/messages ( or )
button on the base to display any Caller ID record.
3. Press and hold the DEL soft key for two seconds. The display shows
DELETE ALL?
4. Press the OK soft key to erase all CID records from memory. The display
shows
NO CALLS
. You will hear a confirmation tone.
NOTE: Press the EXIT soft key once to return to the CID review menu. Or,
press and hold the EXIT soft key to return to standby mode.
CALLER ID ERRORS
If there is an error in the transmission of information to your phone,
ERROR
or
INCOMPLETE DATA
shows in the display. If you are not
subscribed to Caller ID (CID) service, or it is not working properly,
NO
DATA
shows in the display.
ANSWERING SYSTEM SET UP
This section shows you how to set up your answering machine to receive
incoming calls. Answering system setup may only be done at the base.
Page 50
49
TURNING THE ANSWERING SYSTEM OFF AND ON
1. Make sure the base is OFF (not in TALK mode.
2. Press the ANS soft key, and
XX NEW MESSAGE
shows in the display.
3. Press the SETUP soft key. The arrow in the display points to
ANSWER
ON/OFF.
4. Press the OK soft key and
SET ANSWERER 1ON 2OFF
shows in the
display. The arrow in the display points to the current setting.
5. Press the CID/messages ( or ) button on the base or use the touch-
tone pad on the base to select
1ON
or
2OFF
. The default is ON.
6. Press the OK soft key again to confirm your selection. You will hear a
confirmation tone. The display briefly shows
ANSWERER ON
or
ANSWERER OFF,
and then returns to the answerer setup menu. If a
change is made, the unit announces the new choice.
NOTE: Press the EXIT soft key once to return to the answerer setup menu, or
press and hold the EXIT soft key to return to standby mode.
EXIT
DEL
02 NEW MESSAGE
SETUP
EXIT
OK
ANSWER ON/OFF
ANNOUNCE
EXIT
OK
SET ANSWERER
1 ON 2 OFF
ON
ANSWERER
OFF
ANSWERER
Page 51
50
RECORDING THE OUTGOING ANNOUNCEMENT
The outgoing announcement is heard by the incoming caller when the
answering system answers the call. The default announcement is:
PLEASE
LEAVE YOUR MESSAGE AFTER THE TONE
. You may, however, choose to
record a personal outgoing announcement.
For best results when recording a personal announcement, you should be
about nine inches from the microphone and try to eliminate as much
background noise as possible.
1. Make sure your base is in ANSWERER SETUP menu.
2. Press the CID/messages ( or ) button to scroll to ANNOUNCE.
3. Press the OK soft key.
RECORD ANNOUNCE
shows in the display.
4. Press the PLAY soft key to play the current outgoing announcement.
5. Press and hold the REC soft key and begin speaking after you hear the
beep. The display shows
ANNOUNCE RECORDING
. Release the button
when finished recording and your new announcement plays.
EXIT
OK
ANSWER ON/OFF
ANNOUNCE
EXIT
REC
RECORD
ANNOUNCE
PLAY
REC
RECORDING
ANNOUNCE
Page 52
51
SAMPLE OUTGOING ANNOUNCEMENT
Hi, this is (use your name here), I can't answer the phone right now, so please leave your
name, number, and a brief message after the tone, and I'll get back to you. Thanks.
NOTE: You have up to two minutes to record a personal outgoing
announcement.
NOTE: If you choose not to record a personal announcement, the system uses
the default announcement. To hear the default announcement, press the
PLAY soft key instead of the REC soft key.
NOTE: To return to the default announcement, press the REC soft key and
release it when you hear the beep. The default announcement plays.
SETTING THE RINGS TO ANSWER
You may set the number of times you want the phone to ring before the
answering system answers a call.
1. Make sure your base is in the answering system SETUP mode.
2. Press the CID/messages ( or ) button to scroll to
RING SELECT
.
3. Press the OK soft key, and
RING SELECT 3 4 5 6
shows in the display.
The arrow in the display points to the current setting.
4. Use the CID/messages ( or ) button on the base or use the touchtone pad to select the desired rings to answer. For example, press the 5
key to choose
RING SELECT 5
.
EXIT
OK
RING SELECT
SECURITY CODE
EXIT
OK
RING SELECT
3 4 5 6
Page 53
52
EXIT
OK
SECURITY CODE
1 2 3
5. Press the OK soft key to confirm. You will hear a long confirmation tone
and
RING SELECT 5
shows in the display.
6. Press the EXIT soft key to keep the current setting and the unit returns to
the answerer setup menu.
SETTING THE SECURITY CODE FOR REMOTE ACCESS
The product provides you with the ability to access the answering system
from a tone dialing telephone in another location. The security code is
required for remote access, and it prevents unauthorized access to your
answering system. The default security code is 1 2 3, and you may only
change the security code at the base.
1. Make sure the phone is OFF (not in talk mode), and make sure the
phone is in the answerer setup mode.
2. Use the CID/messages ( or ) button on the base to scroll to
SECURITY CODE
.
3. Press the OK soft key, and
SECURITY CODE 123
shows in the display.
4. Use the touch-tone pad on the base to enter your new 3-digit security code.
For example, press the 6, 2, and 8 number key for security code
628
.
RING SELECT
5
EXIT
OK
RING SELECT
SECURITY CODE
Page 54
53
NOTE: If you want to re-enter the security code, enter the numbers again and
press the OK soft key. The new numbers will replace the old numbers.
5. Press the EXIT soft key to keep the current security code and return to
the answerer setup menu.
6. Press the OK soft key, and you will hear a confirmation tone. The new
security code shows in the display.
DEFAULT SETTINGS
If you prefer to use the system’s original settings, follow the steps below to
return the answering system to the factory default settings.
1. Make sure your base is in the answerer setup mode.
2. Use the CID/messages ( or ) button to scroll to
DEFAULT SETTING
.
3. Press the OK soft key and
DEFAULT SETTING 1YES 2NO
shows in
the display.
EXIT
OK
SECURITY CODE
628
SECURITY CODE
628
EXIT
OK
SECURITY CODE
DEFAULT SETTING
EXIT
OK
DEFAULT SETTING
1YES 2NO
Page 55
54
4. Use the CID/messages ( or ) button or the touch-tone pad on the
base to enter
1YES
or
2NO
. For example, press the 2 number key to
select
NO
.
NOTE: If you choose 1YES, all settings in the answering system menu return to
the factory default.
5. Press the OK soft key. You will hear a confirmation tone, and
DEFAULT
SETTING NO
briefly shows in the display.
6. Press the EXIT soft key twice to return to the main menu.
ANSWERING SYSTEM OPERATION
STANDBY DISPLAY
When the phone is not in use, the base displays the status of the answering
system. If the answering system is turned on, it displays
ANSWERER ON
, if it
is off, then it displays
ANSWERER OFF
. The number of new messages and the
number of new CID records received flashes alternately.
The answering system stores up to 59 messages or up to 15 minutes of
messages (including the outgoing announcement). When the answering
system's memory is full, the display shows
ANSWERER ON
and
FULL
.
Messages are limited to three minutes in length for incoming calls.
SPEAKER VOLUME
Use the ( or ) buttons to adjust the speaker volume to a
comfortable level.
SCREENING CALLS AT THE BASE
1. Make sure the phone stops ringing, the answering system starts, and
the display shows
ANSWERING CALL
.
NOTE: No key press is required; the callers voice is heard through the speaker
on the base.
EXIT
OK
DEFAULT SETTING
NO
Page 56
55
2. Press the speaker/callback any time to speak to the caller.
TIP: Make sure the volume on the base is set loud enough for you to hear
incoming calls.
MESSAGE PLAYBACK
The base display lets you know when you have new messages. To play
messages, press the play/stop button. While a message is playing, you
may do the following:
1. Press the play/stop button to stop message playback.
2. Press CID/messages () button once to re-play the current message.
3. Press CID/messages () button twice to review previous messages.
4. Press CID/messages () button to skip to the next message.
5. Press the DEL soft key to erase the current message.
ERASING MESSAGES
You may erase messages at the base two ways:
To erase a message while it is playing-
1. Press and release play/stop button.
2. Press CID/messages ( or ) button to play the message you want
to erase.
3. Press the DEL soft key on the base.
TIPS: You may access the answering system remotely with a cordless handset or
touch-tone phone in another location. See REMOTE ACCESS.
PLAYING MSG 01
TUE 12:52 AM
DEL
Page 57
56
To erase all previously played messages-
1. Make sure the base is OFF (not in talk mode).
2. Press the ANS soft key to display the number of new messages.
3. Press DEL soft key to display
DELETE ALL PLAYED MSG?
4. Press EXIT soft key to exit to display the number of new messages
5. Press the OK soft key to confirm.
MEMO
Use the Memo feature to leave a message for yourself.
1. Press and hold the memo button.
2. Begin speaking after you hear the beep.
3. Release the memo button when you are finished recording the memo.
PLAYING MSG 01
TUE 12:52 AM
DEL
MESSAGE 01
DELETED
EXIT
OK
DELETE ALL
PLAYED MSG?
ALL PLAYED
MESSAGES DELETED
Page 58
57
REMOTE ACCESS
This section explains how to use the cordless handset, or any touch tone
phone, to access the answering system with your 3-digit security code.
TIPS: If you access the answering system with any other touch-tone phone, a
voice menu guides you through the steps.
ACCESSING THE ANSWERING SYSTEM WITH THE CORDLESS HANDSET
1. Make sure your handset is in standby mode.
2. Press the ANS soft key to access the answering system. The display
shows
ANSWERER REMOTE ACCESS
.
3. Press the PLAY soft key to play messages, press the ANS soft key to
setup, or press EXIT to return to standby mode.
4. When you are finished reviewing your messages, press the STOP soft
key to stop message playback, and then press the EXIT soft key to exit
the
ANSWERER REMOTE ACCESS
mode.
SCREENING CALLS WITH THE CORDLESS HANDSET
You may use the cordless handset to remotely screen calls.
1. Make sure the phone stops ringing and the answering system answers
the call.
2. Press the ANS soft key to access the answering system.
3. Listen as the caller leaves a message.
4. Press the TALK/callback button to speak to the caller, or press the ANS
soft key again to stop screening the call.
MEMO
RECORDING
Page 59
58
ACCESSING THE ANSWERING SYSTEM FROM ANOTHER LOCATION
You can access your answering system from any touch-tone phone by
entering your 3-digit security code after you hear the outgoing
announcement.
1. Dial the phone number to which the answering system is connected.
2. When the answering system answers enter the security code after you
hear the tone.
3. Follow the voice menu to use the answering system’s remote functions.
TIP: During remote access you may bypass the outgoing announcement by
pressing any number key on the touch tone pad while the announcement is
playing. Then, enter your security code to access the answering system.
MEMORY FULL
When you access your answering system remotely, and the answering
system’s memory is full, the system answers after 10 rings, beeps, and
waits for you to enter the 3-digit security code. You have 10 seconds to
enter the security code before the phone disconnects. You should erase
some of the old messages so the system can record new messages.
NOTE: The unit also answers after the 10th ring if it is turned off. To access the
answering machine, enter your 3-digit security code after you hear the beep.
Page 60
59
To Press this Button
Replay the current message press 1 once
Review the previous message press 1 twice
Play back messages 2
Stop message playback 2
Erase messages 0
(during message playback)
Skip message 3
Turn answering system off/on 4
Review voice menu options 7
Page 61
60
REPLACING THE BATTERY
CAUTION: To reduce the risk of fire or personal injury, use only the
battery 5-2579, which is compatible with this unit.
Make sure the telephone is OFF before you replace battery.
1. Remove the battery compartment door.
2. Disconnect the cord attached to the battery pack
from the jack inside the battery compartment and
remove the battery pack from the handset.
3. Insert the new battery pack and reconnect the
battery plug.
4. Put the battery compartment door back on.
5. Place handset in the base to charge. If you don’t
charge the handset battery properly (for 12 hours)
when you first set up the phone and/or when you
install a new battery pack, the battery’s long-term
performance will be compromised.
BATTERY SAFETY PRECAUTIONS
• Do not burn, disassemble, mutilate, or puncture. Like other batteries of
this type, toxic materials could be released which can cause injury.
•Keep batteries out of the reach of children.
•Remove batteries if storing over 30 days.
Page 62
61
HEADSET AND BELT CLIP INSTALLATION
CONNECTING AN OPTIONAL HEADSET TO THE HANDSET
For hands free conversation, insert the headset plug into the headset jack.
Adjust the headset to rest comfortably on the ear. Move the microphone to
approximately 2 to 3 inches from your mouth.
•Press the talk/callback button to answer or place a call while using the
headset.
CONNECTING THE BELT CLIP
There are two slots, one on each side of the handset.
•Attach the belt clip by inserting the sides of the belt clip into the slots.
Snap the ends of the belt clip into place.
Headset
jack
Headset
plug
Slot for
belt clip
Slot for
belt clip
Page 63
62
DISPLAY MESSAGES
The following indicators show the status of a message or of the unit.
ERROR Caller information has been interrupted during
transmission or the phone line is excessively noisy.
ENTER NAME Prompt telling you to enter the name in one of the 50
memory locations. (NOTE: The memory records in
` the base and the cordless handsets do not overlap
and cannot be shared. The base and handset has 50
individual memory locations.)
DELETE ALL? Prompt asking if you want to erase all Caller ID
records.
DELETE CALL ID? Prompt asking if you want to erase the current
Caller ID record that is shown on the display.
DELETE? Prompt asking if you want to erase one of the 50
numbers stored in the phone’s outgoing memory.
END OF LIST Indicates that there is no additional information in
Caller ID memory.
NEW Indicates call or calls have not been reviewed.
UNKNOWN CALL The incoming call is from an area not serviced by
Caller ID or the information was not sent
PAGING Someone has pressed the page/intercom button on
the base or handset.
BLOCKED NUMBER The person is calling from a number that has been
blocked from transmission.
REPT Repeat call message. Indicates that a new call from
the same number was received more than once.
NO DATA No Caller ID information was received.
Page 64
63
HANDSET SOUND SIGNALS
Signal Meaning
A long warbling tone (with ringer on) Signals an incoming call
Three short beeps Page signal
One short beep (every 7 seconds) Low battery warning
TROUBLESHOOTING GUIDE
TELEPHONE SOLUTIONS
No dial tone
• Check or repeat installation steps.
• Make sure base power cord is connected to a working electrical outlet.
Make sure the telephone line cord is connected to the base and the
modular phone jack.
• Connect another phone to the same jack; if there is still no dial tone, the
problem might be your wiring or local service.
• The cordless handset may be out of range of the base. Move closer to
the base.
• Make sure the battery is properly charged (12 hours).
• Make sure the battery pack is installed correctly.
• Did the handset beep when you pressed the talk/callback button? Did
the charge indicator on the base turn on? The battery may need to be
charged.
• Place handset in cradle for at least 20 seconds to reset.
Page 65
64
Dial tone is OK but can’t dial out
• Make sure the TONE/PULSE setting on the base is set to the type of
phone service you are subscribed to.
Handset/Base does not ring
• Make sure the handset ringer setting is on and the base ringer is
programmed to HI.
• The cordless handset may be out of range of the base. Move closer to
the base.
•You may have too many extension phones on your line. Try unplugging
some phones.
• Check for dial tone.
• Is the handset Walkie Talkie enabled?
You experience static, noise, or fading in and out
• The cordless handset may be out of range of the base. Move closer to
the base.
•Relocate the base. Make sure base is not plugged into an outlet with
another household appliance.
• Charge the battery.
Unit beeps
• Place the handset in the cradle for 20 seconds. If it still beeps, charge
battery for 12 hours.
• Clean charging contacts on cordless handset and base/charge cradle
with a soft cloth or an eraser.
•See solutions for “No dial tone”.
•Replace the battery.
Page 66
65
Charge indicator on the base flashes
•Provided your phone company offers voice message service and you
subscribe to it, the charge indicator on the base flashes when the phone
is not in use to indicate there is a message waiting. It stops flashing
after the message has been reviewed.
Memory Dialing doesn't work
• Did you program the memory location keys correctly?
• Did you follow proper dialing sequence?
Unit locks up and no communication between the base and cordless
handset
• Unplug the AC power supply from the wall outlet and the back of the
base/charge cradle. Remove the handset battery. Wait for 30 seconds
and plug the power adapter back into the base/charge cradle and wall
outlets. Reconnect the battery and charge for 12 hours. Re-register the
handset.
CALLER ID SOLUTIONS
No Display
• Charge or replace the battery.
• Make sure that the unit is connected to a non-switched electrical outlet.
Disconnect the AC power supply from the base/charge cradle and
reconnect it.
Page 67
66
Caller ID Error Message
• The unit displays this message if it detects anything other than valid
Caller ID information during the silent period after the first ring. This
message indicates the presence of noise on the line.
No Caller ID
•You must be subscribed to Caller ID service from your local telephone
company to receive Caller ID records.
BATTERY SOLUTIONS
If you experience any of the following problems, even after fully
recharging the battery, you may need to replace the battery pack:
• Short talk time
•Poor sound quality
• Limited range
• Charge indicator fails to light when the handset is placed in the base or
charge cradle.
Page 68
67
GENERAL PRODUCT CARE
To k eep your unit working and looking good, follow these guidelines:
•Avoid putting the phone near heating appliances and devices that
generate electrical noise (for example, motors or fluorescent lamps).
• DO NOT expose to direct sunlight or moisture.
•Avoid dropping the handset, as well as other rough treatment to
the phone.
• Clean the phone with a soft cloth.
• Never use a strong cleaning agent or abrasive powder because this will
damage the finish.
•Retain the original packaging in case you need to ship the phone at a
later date.
•Periodically clean the charge contacts on the handset and base with a
clean pencil eraser.
CAUSES OF POOR RECEPTION
• Aluminum siding.
•Foil backing on insulation.
• Heating ducts and other metal construction that can shield radio signals.
•You’re too close to appliances such as microwaves, stoves,
computers, etc.
• Atmospheric conditions, such as strong storms.
• Base is installed in the basement or lower floor of the house.
• Base is plugged into AC outlet with other electronic devices.
• Baby monitor is using the same frequency.
• Handset battery is low.
•You’re out of range of the base.
Page 69
68
INDEX
A
Accessing the Answering System from
Another Location 58
Accessing the Answering System with
the Cordless Handset 57
Accessory Order Form 71
Answering a Call 27
Answering System Operation 54
Answering System Set Up 48
Area Code 13
Auto Standby 27
B
Base 28, 42
Battery Solutions 66
Battery Safety Precautions 60
Before You Begin 8
Between Base and Handset 36
C
Call Timer 27
Call Waiting 28
Caller ID Solutions 65
Caller ID (CID) 43
Caller ID Errors 48
Causes of Poor Reception 67
Chain Dialing from Memory 42
Charge Indicator 26
Connecting an Optional Headset to the
Handset 61
Connecting the AC (Electrical) Power 10
Connecting the Belt Clip 61
Connecting the Telephone Line 10
Cordless Handset Volume Control 34
Cordless Phone Basics 26
D
Default 24
Default Settings 53
Deleting All Caller ID Records 47
Deleting the Caller ID Record Showing in
the Display 46
Dialing a Caller ID Number 45
Dialing a Stored Number 41
Display Contrast 12
Display Messages 62
E
Equipment Approval Information 2
Erasing Messages 55
Exit 30
F
Flash 29
G
General Product Care 67
Global Deregistration 21
H
Handset and Base Layout 7
Handset De-registration 20
Handset Registration 17
Handset Sound Signals 63
Headset and Belt Clip Installation 61
Hearing Aid Compatibility (HAC) 2
Hold 29
I
Important Installation Guidelines 9
Important Installation Information 9
Inserting a Pause in the Dialing
Sequence 40
Installing the Phone 10
Intercom 34
Interference Information 2
Introduction 5
Page 70
69
L
Language 11
Last Number Redial 29
Limited Warranty 70
M
Making a Call 26
Making an Intercom Call 34
Memo 56
Memory 37
Memory Full 58
Message Playback 55
Mute 33
P
Paging 30
Parts Checklist 8
Programmable Functions 11
R
Receiving an External Telephone Call
During an Intercom Call 36
Receiving an Intercom Call 35
Receiving and Storing CID Records 43
Recording the Outgoing
Announcement 50
Remote Access 57
Replacing the Battery 60
Reviewing, Changing or Deleting Stored
Numbers 40
Reviewing CID Records 44
Ringer Tone 15
Ringer Volume Control 27
S
Sample Outgoing Announcement 51
Screening Calls at the Base 54
Screening Calls with the Cordless
Handset 57
Service 70
Setting the Rings to Answer 51
Setting the Security Code for Remote
Access 52
Speaker Volume 54
Speakerphone/Answering System
Volume Control 34
Standby Display 54
Storing a Name and Number
in Memory 38
Storing a Redial Number 39
T
Telephone Solutions 63
Telephone Jack Requirements 8
Telephone Setup 11
Temporary Tone Dialing 33
Time of Day 24
To erase a message while it is playing 55
To erase all previously played
messages 56
Tone/Pulse 16
Transferring Calls 32
Transferring CID Records to Memory 44
Troubleshooting Guide 63
Turning the Answering System Off and
On 49
U
Using Intercom or Conference with
External Calls 36
Using the Soft Keys 11
W
Walkie Talkie 22
Page 71
70
SERVICE
If trouble is experienced with this equipment, for repair or warranty
information, please contact customer service at 1-800-448-0329. If the
equipment is causing harm to the telephone network, the telephone
company may request that you disconnect the equipment until the
problem is resolved.
This product may be serviced only by the manufacturer or its authorized
service agents. Changes or modifications not expressly approved by
ATLINKS USA, Inc. could void the user’s authority to operate this product.
For instructions on how to obtain service, refer to the warranty included in
this guide or call customer service at 1-800-448-0329.
Or refer inquiries to:
ATLINKS USA, Inc.
Manager, Consumer Relations
P O Box 1976
Indianapolis, IN 46206
Attach your sales receipt to the booklet for future reference or jot down the
date this product was purchased or received as a gift. This information will
be valuable if service should be required during the warranty period.
Purchase date ________________________________________________
Name of store ________________________________________________
Page 72
71
Please make sure that this form has been filled out completely.
A
CCESSORY
O
RDER
F
ORM
CUSTOMER: CUT ALONG DOTTED LINE.
✂
*Prices are subject to change without notice.
Total Merchandise.........................................$_______________
Sales Tax........................................................$_______________
We are required by law to collect the appropriate sales tax for each individual state,
county, and locality to which the merchandise is being sent. Duties will apply for
shipments to Canada.
Use VISA or Master Card or Discover preferably. Money order or check must be in U.S.
currency only. No COD or Cash. All accessories are subject to availability. Where
applicable, we will ship a superseding model.
Shipping/Handling....................................... $_______________
Total Amount Enclosed.................................$_______________
Mail order form and money order or check (in U.S. currency)
made payable to Thomson to:
Thomson
Mail Order Department
P. O. Box 8419
Ronks, PA 17573-8419
Name_______________________________________________________
Address_____________________________________ Apt.____________
City ________________________State________ ZIP_________________
Daytime Phone Number ( )_______________________________
$5.00
____________________________________________________________________
Authorized Signature
My card expires:
Copy the number above your
name on the Master Card
For credit card purchases
Your complete charge card number, its expiration date and your
signature are necessary to process all charge card orders.
Copy your complete account number from your VISA card.
My card expires:
Copy your complete account number from your
Master Card or Discover.
To order, call 1-800-338-0376 (for accessories only) or complete this order form.
DESCRIPTION
AC power adapter
MODEL NUMBER
TOTAL
PRICE*
$36.35
Replacement Handset Battery
Belt Clip
Headset
5-2579
5-2561
$18.35
$8.75
$11.90
5-2459
5-2425
QTY.
Remote Charger
5-2565
Page 73
Model 21091
16047100 (Rev. 1 E/S)
03-15
Printed in China
ATLINKS USA, Inc.
101 West 103rd Street
Indianapolis, IN 46290
© 2003 ATLINKS USA, Inc.
Trademark(s) ® Registered
Marca(s) Registrada(s)
LIMITED WARRANTY
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• One year, from date of purchase.
(The warranty period for rental units begins with the first rental or 45 days from date of shipment to the rental firm,
whichever comes first.)
What we will do:
•Provide you with a new or, at our option, a refurbished unit. The exchange unit is under warranty for the remainder of
the original product’s warranty period.
How you get service:
•Properly pack your unit. Include any cables, etc., which were originally provided with the product. We recommend
using the original carton and packing materials.
•”Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that the product is within the
warranty period, must be presented to obtain warranty service.” For rental firms, proof of first rental is also required.
Also print your name and address and a description of the defect. Send via standard UPS or its equivalent to:
ATLINKS USA, Inc.
c/o Thomson
11721 B Alameda Ave.
Socorro, Texas 79927
•Pay any charges billed to you by the Exchange Center for service not covered by the warranty.
• Insure your shipment for loss or damage. ATLINKS accepts no liability in case of damage or loss.
•A new or refurbished unit will be shipped to you freight prepaid.
What your warranty
does not
cover:
• Customer instruction. (Your Owner’s Manual provides information regarding operating instructions and user controls.
Any additional information, should be obtained from your dealer.)
• Installation and setup service adjustments.
• Batteries.
• Damage from misuse or neglect.
•Products which have been modified or incorporated into other products.
•Products purchased or serviced outside the USA.
• Acts of nature, such as but not limited to lightning damage.
Product Registration:
• Please complete and mail the Product Registration Card packed with your unit. It will make it easier to contact you
should it ever be necessary. The return of the card is not required for warranty coverage.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION GIVEN BY ATLINKS USA, INC., ITS
AGENTS, OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER.
ATLINKS USA, INC. SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE
USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS
PRODUCT. THIS DISCLAIMER OF WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF THE
STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE APPLICABLE
WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to this warranty:
•Some states do not allow the exclusion nor limitation of incidental or consequential damages, or limitations on how
long an implied warranty lasts so the above limitations or exclusions may not apply to you.
• This warranty gives you specific legal rights, and you also may have other rights that vary from state to state.
If you purchased your product outside the USA:
• This warranty does not apply. Contact your dealer for warranty information.
Page 74
Creamos cosas buenas para la vida.
Teléfono Inalámbrico/Altavoz/
Sistema Contestador de Dos
Auriculares, de 2.4 GHz con
Identificador de Llamada en Espera
Guía del Usuario
21091
Page 75
2
El número de la US está ubicado en el fondo de la base
El numero REN esta ubicado en el fondo de la base
INFORMACIÓN SOBRE LA APROBACIÓN DE EQUIPO
El equipo de su teléfono esta aprobado para la conexión con la red Telefónica Pública (Public Switched Telephone Network) y cumple con los
requisitos establecidos en las secciones 15 y 68 de las Reglas y Regulaciones de la FCC y con los Requerimientos Técnicos para Equipos de
Terminales Telefónicas (Technical Requirements for Telephone Terminal Equipment), publicado por ACTA.
1 Notificación a la Compañía Telefónica Local
En la parte de abajo de este equipo hay una etiqueta que indica, entre otra información, el número de US y el Número de Equivalencia de
Timbres (REN) para este equipo. Usted debe, cuando sea requerido, proveer esta información a su compañía telefónica.
El REN es útil para determinar el número total de artefactos que Ud. puede conectar a su línea telefónica, todavía asegurando que todos
estos artefactos sonarán cuando se llame su número telefónico. En la mayoría de las áreas (pero no en todas), el total de los números REN
de todos los artefactos conectados a una línea no debe exceder 5. Para estar seguro del número total de artefactos que Ud. pueda
conectar a su línea (determinado por el REN), Ud. deberá ponerse en contacto con su compañía telefónica local.
Cualquier enchufe y conexión que se utilice para conectar este equipo al cableado del edificio y a la red telefónica, debe estar en
conformidad con el reglamento de la FCC Parte 68 que ha sido adoptado por la ACTA. Un cable telefónico y un enchufe modular que han
sido aprobados y están en conformidad con dicho reglamento han sido provistos con este producto. Están diseñados para ser conectados
a un enchufe modular compatible, que también esté en conformidad. Para más detalles, vea las instrucciones para la instalación.
NOTAS:
• No se puede usar este equipo con un teléfono de previo pago proveído por la compañía telefónica.
• Las líneas compartidas son sujetas a las tarifas del estado, y por eso, es posible que Ud. no pueda usar su propio equipo telefónico si
Ud. estuviera compartiendo la misma línea telefónica con otros abonados.
• Se debe notificar la compañía telefónica cuando se desconecte permanentemente su teléfono de la línea.
• Si su casa tiene algún equipo de alarma especial conectado a la línea telefónica, asegúrese que la instalación de este producto no
desactive su equipo de alarma. Si usted tiene alguna pregunta sobre qué puede desactivar su equipo de alarma, consulte a su
compañía telefónica o a un instalador calificado.
2 Derechos de la Compañía Telefónica
Si su equipo causase algún problema en su línea que pudiera dañar la red telefónica, la compañía telefónica siempre que sea posible le
avisará de la posible interrupción temporal de su servicio. En caso que la compañía no pudiera avisarle de antemano y hubiera necesidad
de tomar tal acción, la compañía telefónica podrá interrumpir su servicio inmediatemente. En caso de tal interrupción telefónica temporal
la compañía debe : (1) darle aviso al momento de tal interrupción temporal de servico, (2) concederle a Ud. la oportunidad de corregir la
situación, (3) informarle a Ud. de sus derechos de presentar una questa a la Comisión de acuerdo con los procedimientos dictados en la
Subparte E de la Parte 68 de las Regulaciones y Reglas de la FCC.
La compañía telefónica puede hacer los cambios en sus instalaciones de comunicación, en equipos, en sus funcionamientos o
procedimientos que digne necesarios para el manejo de sus negocios y que no sean incompatibles con las Reglas y Regulaciones de l a
FCC. Si estos cambios pudieran alterar el uso o el funcionamiento de su equipo telefónico, la compañía telefónica deberá darle aviso
adecuado en escrito para que Ud. goce de un servico ininterrumpido.
INFORMACIÓN DE INTERFERENCIAS
Este artefacto cumple con la Parte 15 de las Reglas de la FCC. Su funcionamiento es sujeto a las dos condiciones siguientes: (l) Este artefacto
no puede causar interferencia dañosa, y (2) Este artefacto debe aceptar cualquier interferencia recibida, incluyendo interferencia que puede
causar un funcionamiento no deseado.
Este equipo ha sido probado y cumple con los límites para un artefacto digital de la Clase B, de conformidad con la Parte 15 de las Reglas de la
FCC. Estos límites han sido diseñados para proporcionar una protección razonable contra una interferencia dañosa que pueda existir en una
instalación doméstica.
Este equipo genera, usa y puede radiar la energía de frecuencia de una radio y, si no fuera instalado y usado de acuerdo con las instrucciones,
puede causar interferencia dañosa a las transmisiones radiales. Sin embargo, no hay garantía que la interferencia no ocurrirá en una
instalación en particular.
Si este equipo causa en efecto una interferencia dañosa a la recepción de la radio o de la televisión, lo cual puede ser determinado apagando y
prendiendo el equipo, le animamos a Ud. de tratar de corregir la interferencia por medio de una (o más) de las sugerencias siguientes:
• Cambie la posición o la ubicación de la antena (quiere decir la antena de la radio o de la televisión que está recibiendo la interferencia).
• Cambie la posición o cambie la ubicación y aumente la distancia entre el equipo de telecomunicaciones y la antena receptora de la radio
o de la televisión que está recibiendo la interferencia.
• Conecte el equipo de telecomunicaciones a una toma en un circuito diferente del circuito al cual la antena receptora esté conectada.
Si estas medidas no eliminan la interferencia, favor de consultar a su distribuidor o a un técnico de radio/televi
sión experto por otras sugerencias. También, la Comisión Federal de Comunicaciones (FCC) ha preparado un folleto muy útil, “How To Identify
and Resolve Radio/TV Interference Problems” (“Como Identificar y Resolver Problemas de Interferencia de Radio/Televisión”). Este folleto se
puede obtener del U.S. Goverment Printing Office, Washington, D.C. 20402. Favor de especificar el número 004-000-00345-4 cuando haga su
pedido.
COMPATIBILIDAD CON AUDÍFONOS (CCA)
Se juzga que este teléfono es compatible con audífonos, en base a las normas de la FCC.
Page 76
3
TABLA DE CONTENIDO
INFORMACIÓN SOBRE LA APROBACIÓN
DE
EQUIPO .......................................... 2
INFORMACIÓN DE INTERFERENCIAS .................... 2
COMPATIBILIDAD CON AUDÍFONOS (CCA) ......... 2
INTRODUCCIÓN ............................................. 5
FORMATO DEL A URICULAR Y LA BASE ............... 7
ANTES DE COMENZAR ................................... 8
LISTA DE PARTES ...................................... 8
REQUERIMIENTOS PARA ENCHUFE
TELEFÓNICO ............................................. 8
INFORMACIÓN IMPORTANTE PARA LA
INSTALACIÓN ........................................ 9
INDICACIONES IMPORTANTES PARA LA
INSTALACIÓN: ........................................... 9
INSTALACIÓN DEL T ELÉFONO .......................... 10
PARA CONECTAR LA LÍNEA T ELEFÓNICA ...... 10
PROGRAMACIÓN DEL T ELÉFONO ..................... 11
FUNCIONES PROGRAMABLES ..................... 11
PARA UTILIZAR LAS T ECLAS SUAVES .. 11
IDIOMA ................................................. 11
CONTRASTE DE LA PANTALLA .................... 12
CLAVE DE ÁREA ..................................... 13
TONO DEL T IMBRE ................................... 15
TONO/PULSO ......................................... 16
REGISTRO DEL AURICULAR ........................ 17
CANCELACIÓN DEL REGISTRO DEL
AURICULAR ............................................ 20
CANCELACIÓN GLOBAL DEL REGISTRO ........ 21
RADIO T ELÉFONO PORTÁTIL (WALKIE-
TALKIES) ............................................... 22
HORA DEL DÍA ....................................... 24
PROGRAMACIÓN DE FÁBRICA ..................... 24
OPERACIÓN BÁSICA DEL T ELÉFONO
INALÁMBRICO ..................................... 26
ALTA VOZ ............................................... 26
INDICADOR DE CARGA .............................. 26
PARA HACER UNA LLAMADA .................... 26
AURICULAR ................................... 26
ALTA VOZ ....................................... 26
PARA CONTESTAR UNA LLAMADA .............. 27
AURICULAR ................................... 27
ALTA VOZ ....................................... 27
TEMPORIZADOR (TIMER) .......................... 27
AUTO ALERTA ........................................ 27
SELECTOR DE VOLUMEN DEL T IMBRE .......... 27
AURICULAR ................................... 27
BASE .................................................... 28
LLAMADA EN ESPERA .............................. 28
FLASH .................................................. 29
ÚLTI MO NÚMERO MARCADO .................... 29
EN ESPERA ........................................... 29
SALIDA ................................................. 30
LOCALIZANDO EL AURICULAR .................... 30
PARA T RANSFERIR LLAMADAS ................... 32
ENMUDECEDOR ...................................... 33
TONO T EMPORAL .................................... 33
CONTROL DE VOLUMEN DEL
AURICULAR INALÁMBRICO ............ 34
CONTROL DE VOLUMEN DEL
ALTA VOZ ................................... 34
INTERFONO ............................................ 34
PARA HACER UNA LLAMADA DE
INTERFONO ............................................ 34
PARA RECIBIR UNA LLAMADA DE
INTERFONO ................................ 35
PARA RECIBIR UNA LLAMADA
TELEFÓNICA EXTERNA DURANTE UNA
LLAMADA DE INTERFONO .......................... 36
VEA ADVERTENCIA EN LA PARTE POSTERIOR/BASE DEL PRODUCTO.
RIESGO DE SACUDIDA
ELÉCTRICA NO ABRA
ADVERTENCIA: PARA
PREVENIR
EL RIESGO DE
UNFUEGO O DE UNA
SACUDIDA
ELECTRICA, NO
EXPONGA
ESTE APARATO A LA
LLUVIA O A LA
HUMEDAD.
EL RELÁMPAGO Y LA
PUNTA DE FLECHA
DENTRO DEL TRIÁNGULO
ES UNA SEÑAL DE
ADVERTENCIA,
ALERTÁNDOLE A UD. DE
QUE HAY "VOLTAJE
PELIGROSO" DENTRO DEL
PRODUCTO.
CUIDADO: PARA REDUCIR
EL RIESGO DE UNA SACUDIDA
ELÉCTRICA, NO QUITE LA
CUBIERTA (O PARTE
POSTERIOR) NO USE PARTES
DE REPUESTO DENTRO.
CONSULTE A ALGUNA
PERSONA CALIFICADA DEL
SERVICIO DE REPARACIONES.
EL SIGNO DE
EXCLAMACIÓN DENTRO
DEL TRIÁNGULO ES UNA
SEÑAL DE
ADVERTENCIA,
ALTERTÁNDOLE A UD. DE
QUE EL PRODUCTO, TRAE
INCLUCIDO,
INSTRUCTIONES MUY
IMPORTANTES.
ATTENTION:
Page 77
4
ENTRE AURICULARES ....................... 36
ENTRE LA BASE Y EL AURICULAR ....... 36
PARA UTILIZAR EL INTERFONO O LA
FUNCIÓN DE CONFERENCIA CON
LLAMADAS EXTERNAS ................. 36
MEMORIA .................................................. 37
PARA ALMACENAR UN NOMBRE Y
NÚMERO EN LA MEMORIA ........................ 38
PARA ALMACENAR UN NÚMERO DE
VOLVER A MARCAR ................................. 39
PARA INTRODUCIR UNA PAUSA EN LA
SECUENCIA DE MARCADO ........................ 40
PARA REVISAR, CAMBIAR, O BORRAR
NÚMEROS ALMACENADOS ........................ 40
PARA REVISAR: .............................. 40
PARA CAMBIAR: ............................. 40
PARA BORRAR: .............................. 41
PARA MARCAR UN NÚMERO
ALMACENADO ........................................ 41
AURICULAR ................................... 41
BASE ............................................ 42
MARCADO EN CADENA DESDE
LA
MEMORIA ......................................... 42
FUNCIONES DEL IDENTIFICADOR DE
LLAMADAS (CALLER ID) ...................... 43
PARA RECIBIR Y ALMACENAR ARCHIVOS
DE
LLAMADAS ........................................ 43
PARA REVISAR LA LISTA DE ARCHIVOS
DEL
IDENTIFICADOR (CID) ........................ 44
PARA T RANSFERIR ARCHIVOS DEL
IDENTIFICADOR DE LLAMADAS A
LA
MEMORIA ......................................... 44
PARA MARCAR UN NÚMERO DEL
IDENTIFICADOR DE LLAMADAS ................... 45
PARA BORRAR EL ARCHIVO ACTUAL DEL
IDENTIFICADOR DE LLAMADAS QUE APARECE
EN
LA PANTALLA ..................................... 46
PARA BORRAR T ODOS LOS ARCHIVOS DEL
IDENTIFICADOR DE LLAMADAS: .................. 47
ERRORES DEL IDENTIFICADOR
DE
LLAMADAS ........................................ 48
PROGRAMACIÓN DEL SISTEMA CONTESTADOR .. 48
PARA ENCENDER O APA GAR EL SISTEMA
CONTESTADOR ....................................... 49
PARA GRABAR EL ANUNCIO SALIENTE ........ 50
EJEMPLO DE ANUNCIO SALIENTE ............... 51
PARA PROGRAMAR LOS T IMBRES PARA
CONTESTAR ........................................... 51
PARA PROGRAMAR EL CÓDIGO
DE
SEGURIDAD PARA T ENER ACCESO DESDE
OTRO
T ELÉFONO ...................................... 52
PROGRAMACIONES DE FÁBRICA ................. 53
OPERACIÓN DEL SISTEMA CONTESTADOR ........ 54
PANTALLA DE ALERTA .............................. 54
VOLUMEN DE LA BOCINA ......................... 54
REPRODUCCIÓN DE MENSAJES .................. 55
PARA BORRAR MENSAJES ....................... 55
RECADOS (“MEMO”) ........................... 56
ACCESO REMOTO ................................... 57
PARA T ENER ACCESO AL SISTEMA
CONTESTADOR CON EL T ELÉFONO
INALÁMBRICO ............................. 57
PARA FILTRAR LLAMADAS CON EL
AURICULAR INALÁMBRICO ............ 57
PARA T ENER ACCESO AL SISTEMA
CONTESTADOR DESDE OTRA
LOCALIZACIÓN ........................................ 58
MEMORIA LLENA .................................... 58
PARA CAMBIAR LA BATERÍA .......................... 60
PRECAUCIONES DE SEGURIDAD PARA
LA
BATERÍA ............................................ 60
INSTALACIÓN DE AUDÍFONOS Y DEL GANCHO
DEL
CINTURÓN ................................... 61
PARA CONECTAR UNOS AUDÍFONOS
OPCIONALES AL AURICULAR ...................... 61
PARA CONECTAR EL GANCHO DEL
CINTURÓN CON LOS AUDÍFONOS ................ 61
MENSAJES EN LA PANTALLA ......................... 62
SEÑALES SONORAS DEL AURICULAR .............. 63
SOLUCIÓN DE PROBLEMAS ........................... 63
CUIDADO GENERAL DEL PRODUCTO ................ 67
CAUSAS DE UNA MALA RECEPCIÓN ............... 67
ÍNDICE ...................................................... 68
CÓMO OBTENER SERVICIOS DE
MANTENIMIENTO ................................ 70
FORMULARIO PARA HACER PEDIDOS DE
ACCESORIOS ...................................... 71
GARANTÍA LIMITADA ................................... 72
Page 78
5
INTRODUCCIÓN
CUIDADO: Cuando utilice equipo telefónico, hay instrucciones básicas de
seguridad que siempre deben seguirse. Refiérase a la guía de INSTRUCCIONES
DE SEGURIDAD IMPORTANTES provista con este producto y guárdela para
referencia futura.
Felicitaciones por su compra de este Teléfono Inalámbrico/ Sistema Contestador
GE con Identificador de Llamada en Espera. Este sistema ha sido diseñado para
ser de fácil manejo; sin embargo, usted puede aprovechar al máximo de su
potencial si se toma unos minutos ahora mismo para leer este manual de
instrucciones. Este teléfono es un producto con múltiples funciones que puede
ustilizarse junto con los servicios de Identificador de Llamada en Espera y de
Identificador de Llamadas, que le son disponibles a través de su compañía
telefónica local.
Su teléfono con Identificador de Llamada en Espera le permite:
•Ver el nombre y número telefónico de la persona que llama, mientras que usted
está en el teléfono (Identificador de Llamada en Espera).
• Identificar a las personas que llaman antes de contestar el teléfono.
•Ver la hora y fecha de cada llamada entrante.
• Grabar hasta 40 mensajes del Identificador de Llamadas en secuencia en el
auricular y la base
•Saber quién llamó mientras usted estaba en la otra línea o mientras estaba
fuera.
• Filtrar llamadas no deseadas, eliminar llamadas molestas, o prepararse para
contestar una llamada.
Page 79
6
CUIDADO: Como los teléfonos inalámbricos operan con electricidad, usted debe tener
por lo menos un teléfono en su casa que no sea inalámbrico, en caso de una
interrupción de corriente.
IMPORTANTE: Para poder utilizar todas las funciones de este teléfono, usted debe
suscribirse a dos servicios distintos a través de su compañía telefónica: el Servicio
Estándar de Identificador de Nombre/ Número para saber quién llama cuando timbra
el teléfono, y el Servicio Identificador de Llamadas con Identificación de Llamada en
Espera para saber quién llama mientras usted está en otra línea.
NOTA SOBRE LA INSTALACIÓN: Algunos teléfonos inalámbricos operan a frecuencias
que pueden causar interferencia con aparatos de televisión, hornos de microondas,
hornos, o videocaseteras que se encuentren cerca de este aparato. Para minimizar o evitar
dicha interferencia, la base del teléfono inalámbrico no debe ser colocada cerca o encima
de la televisión, de un horno de microondas, o de la videocasetera. Si dicha interferencia
continúa, mueva el teléfono lejos del aparato eléctrico causante de la interferencia.
Algunos otros accesorios para la comunicación pueden utilizar frecuencias de 2.4 GHz
para comunicarse, y si no están adecuadamente instalados, estos aparatos pueden
interferir entre sí, o con su aparato de teléfono nuevo. Si usted teme tener problemas con
esta interferencia, refiérase al manual de instrucciones de dichos accesorios para ver cómo
puede programar los canales para evitar esta interferencia. Los accesorios típicos que
pueden utilizar la frecuencia de 2.4 GHz para comunicarse incluyen transmisores
inalámbricos de audio o video, redes inalámbricas para computadoras, sistemas telefónicos
inalámbricos con varios auriculares, y algunos teléfonos inalámbricos de largo rango.
Page 80
7
FORMATO DEL AURICULAR Y LA BASE
i
n
t
9
wxyz
6
mno
3
def
8
tuv
5
jkl
2
abc
7
pqrs
4
ghi
1
0
oper
#
pause
*
tone
v
v
ringerpage
f
l
a
s
h
r
e
d
ia
l
TALK
format
c
o
n
f
e
r
e
n
c
e
c
a
l
l
b
a
c
k
c
i
d
/
v
o
l
Botón para marcar por
tono (“*tone”)
Botón para pausa
(“# pause”)
Pantalla
Botón de
formato/
conferencia
Botón para hablar/devolver el
llamado (“talk/callback”)
Botón para volver a
marcar (“redial”)
Botón para el interfono
(“page/intercom”)
Botón del timbre
Botón para servicios
(“flash”)
Botones del
identificador/
volumen
Teclas suaves
Lado Posterior
9
wxyz
6
mno
3
def
8
tuv
5
jkl
2
abc
7
pqrs
4
ghi
1
0
oper
#
pause
*
tone
speaker
page/int.
charge/
VMWI
volume
v
v
v
v
r
e
d
i
a
l
f
o
r
m
a
t
r
i
n
g
e
r
f
l
a
s
h
c
o
n
f
.
c
a
l
l
b
a
c
k
memo
play/stop
C
I
D
/
m
e
s
s
a
g
e
s
Botón del
Identificador
/Mensajes
(“CID/
messages”)
Botón para
volumen
(“volume”)
Ivor de carga
Botón para el
interfono (“page/
intercom”)
Botón para marcar por
tono (“*tone”)
Botón para altavoz/ para
volver a llamar
Botón para pausa
(“# pause”)
Botón de
formato/
conferencia
Botón del timbre
Botón para
servicios
(“flash”)
Pantalla
Botón para volver a
marcar (“redial”)
Teclas suaves
Botón para recados
(“memo”)
Botón para reproducir
mensajes (“play/stop”)
Page 81
8
ANTES DE COMENZAR
LISTA DE PARTES
Asegúrese que su paquete incluye los artículos mostrados aquí.
REQUERIMIENTOS PARA ENCHUFE TELEFÓNICO
Para utilizar este teléfono, usted puede necesitar un enchufe
modular telefónico tipo RJ11C como el ilustrado aquí,
instalado en su hogar. Si usted no tiene este tipo de enchufe,
llame a su compañía telefónica local para preguntar cómo
conseguirlo.
Base
Dos auriculares
Pedestal para
Montaje
2 ganchos para
Cinturón
Cable de corriente
AC
Cable de línea
telefónica
2 paquetes de
baterías para el
Auricular
i
n
t
9
wxyz
6
mno
3
def
8
tuv
5
jkl
2
abc
7
pqrs
4
ghi
1
0
oper
#
pause
*
tone
v
v
ringerpage
flash
r
e
d
i
a
l
TALK
format
c
o
n
f
e
r
e
n
c
e
c
a
l
l
b
a
c
k
c
i
d
/
v
o
l
i
n
t
9
wxyz
6
mno
3
def
8
tuv
5
jkl
2
abc
7
pqrs
4
ghi
1
0
oper
#
pause
*
tone
v
v
ringerpage
flash
r
e
d
i
a
l
TALK
format
c
o
n
f
e
r
e
n
c
e
c
a
l
l
b
a
c
k
c
i
d
/
v
o
l
9
wxyz
6
mno
3
def
8
tuv
5
jkl
2
abc
7
pqrs
4
ghi
1
0
oper
#
pause
*
tone
speaker
page/int.
charge/
VMWI
volume
v
v
v
v
r
e
d
i
a
l
f
o
r
m
a
t
r
i
n
g
e
r
f
l
a
s
h
c
o
n
f
.
c
a
l
l
b
a
c
k
memo
play/stop
C
I
D
/
m
e
s
s
a
g
e
s
charge
Base para carga del
auricular
Enchufe
telefónico
modular
Placa de pared
Page 82
9
INFORMACIÓN IMPORTANTE PARA LA INSTALACIÓN
• Nunca instale cableado telefónico durante una tormenta de relámpagos.
• Nunca instale enchufes telefónicos en localizaciones mojadas a menos que el
enchufe haya sido diseñado específicamente para localizaciones mojadas.
• Nunca toque cables o terminales no aislados, a menos que la línea telefónica
haya sido desconectada en la interfaz de la red.
• Utilice precaución cuando instale o modifique líneas telefónicas.
• Desconecte temporalmente cualquier equipo conectado al teléfono, como
faxes, otros teléfonos o modems.
INDICACIONES IMPORTANTES PARA LA INSTALACIÓN:
• Instale el teléfono cerca de un enchufe telefónico (modular) y un enchufe de
corriente eléctrica.
• Evite áreas de mucho ruido, como una ventana hacia una calle con mucho
tráfico, y ruido eléctrico como motores, hornos de micro ondas, o lámparas de
luz fluorescente.
• Evite fuentes de calor, como conductos de calefacción, aparatos eléctricos que
se calientan, radiadores y luz de sol directa.
• Evite áreas con humedad excesiva o temperaturas demasiado bajas.
• Evite áreas con mucho polvo.
• Evite colocar cerca de otros teléfonos o computadoras personales.
Page 83
10
PARA CONECTAR LA LÍNEA TELEFÓNICA
En la base, conecte un extremo del cable de la línea telefónica dentro del enchufe
localizado en la parte trasera de la base y el otro extremo en un enchufe modular
de pared.
NOTA: La base de un aparato puede respaldar hasta dos auriculares.
Para Conectar la Corriente AC (Eléctrica)
1. Conecte el cable de corriente en un enchufe en la parte posterior de la base y el
otro extremo dentro de un enchufe eléctrico.
2. Conecte la base para cargar el auricular dentro del enchufe eléctrico.
3. Coloque un auricular sobre cada una de las bases para carga. El indicador de
carga se ilumina para indicar que las baterías están cargando.
CUIDADO: Utilice únicamente el cable de corriente ATLINKS USA , Inc. 5-2579
que es compatible con esta unidad. El uso de otros cables de corriente puede
resultar en daño al aparato.
Deje que el teléfono se cargue durante seis horas antes de utilizarlo por primera
vez. Si usted no carga adecuadamente el teléfono, el funcionamiento de la batería
podría deteriorarse.
INSTALACIÓN DEL TELÉFONO
Escoja la mejor localización para instalar su sistema inalámbrico con múltiples
auriculares. Su sistema inalámbrico con múltiples auriculares debe ser colocado
sobre una superficie plana y nivelada como una mesa o un escritorio.
Page 84
11
PROGRAMACIÓN DEL TELÉFONO
FUNCIONES PROGRAMABLES
Este sistema utiliza un menú estructurado y un sistema de teclas suaves para darle
acceso a todas las funciones integradas.
PARA UTILIZAR LAS TECLAS SUAVES
Hay tres botones debajo de la pantalla, que representan varias funciones
(programables) de las teclas suaves. Utilice los botones para activar los símbolos
de las teclas suaves que aparecen en la pantalla. Usted puede programar las
siguientes cosas con las teclas suaves: Idioma, Contraste de la Pantalla, Clave de
Área, Tono del Timbre, Hora, Tono/ Pulso, Registro, Cancelación de Registro, Radio
Teléfono Portátil (“Walkie-Talkie”), y Programación de Fábrica.
IDIOMA
Esta programación puede hacerse con el auricular o con la base.
Asegúrese que el teléfono esté desactivado (OFF) (no en modalidad para hablar –
TALK).
1. Oprima la tecla suave de menú (“MENU”) para ir al menú principal.
2. Oprima el botón para revisar archivos del identificador (“cid/vol”) ( o ) en el
auricular o el botón del identificador (“CID/messages”) ( o ) en la base para
mover la flecha hasta la indicación de idioma (“
LANGUAGE
”).
3. Oprima la tecla suave “OK” y la indicación de idioma (“
SET LANGUAGE 1ENG
2FRA 3ESP
”) aparece en la pantalla.
LANGUAGE
OK
AREA CODE
EXIT
Page 85
12
4. Utilice el teclado numérico en su auricular para seleccionar el idioma (“
1ENG
2FRA 3ESP
”), o utilice el botón para revisar archivos del identificador (“cid/vol”)
(5 or 6) en el auricular o el botón del identificador (“CID/messages”) (5 or 6) en
la base para mover la flecha hasta su selección. Inglés es la programación de
fábrica.
NOTA: Oprima la tecla suave “EXIT” para una vez para conservar la programación
previa y regresar al menú principal.
5. Oprima la tecla suave “OK” para salvar su selección, y regresar al menú
principal. El idioma seleccionado aparece en la pantalla durante dos segundos.
PANTALLA DE LA BASE PANTALLA DEL AURICULAR
CONTRASTE DE LA PANTALLA
Esta programación puede hacerse únicamente en la base. Asegúrese que la base
esté en el menú principal, y asegúrese que el teléfono esté apagado (OFF) (no en
modalidad para hablar –“TALK”).
1. Oprima el botón del Identificador de Llamadas ( o ) para ir a la pantalla
“
CONTRASTE
.”
SET LANGUAGE
OK
1 ENG 2 FRA 3 ESP
EXIT
ESPANOL
IDIOMA
OK
SALIR
AREA LOCAL
IDIOMA
OK
SALIR
CONTRASTE
IDIOMA
OK
CONTRASTE
SALIR
Page 86
13
2. Oprima la tecla suave “OK” y la indicación de contraste (“
PROG CONTRASTE 1
2 3
”) aparece en la pantalla.
3. Utilice el teclado numérico en la base para seleccionar el nivel 1, 2, o 3, o utilice
el botón para revisar archivos del Caller ID-“CID” ( o ) para mover la flecha
hasta su selección. El nivel de contraste 1 es la programación de fábrica.
Oprima la tecla suave “EXIT” para una vez para conservar la programación previa y
regresar al menú principal.
4. Oprima la tecla suave “OK” para salvar su selección, y regresar al menú
principal. El nivel de contraste aparece en la pantalla durante dos segundos.
CLAVE DE ÁREA
Asegúrese que la base esté en el menú principal. Si usted inscribe una clave de
área de 3 dígitos en el menú de clave de área, su clave de área local no aparecerá
en los mensajes del Identificador de Llamadas que usted reciba. Usted únicamente
verá el número local de siete dígitos. Las llamadas que usted reciba desde fuera
de su clave de área local aparecerán en forma de números de diez dígitos.
PROGRM CONTRASTE
OK
1 2 3
SALIR
CONTRASTE - 2
IDIOMA
OK
CONTRASTE
SALIR
Page 87
14
Esta programación será hecha con el auricular o la base. Asegúrese de que el
teléfono esté apagado (OFF) (no en modalidad para hablar –“TALK”).
1. Utilice el botón para revisar archivos del Caller ID-“cid/vol” ( o ) en el
auricular o el botón del Caller ID-“CID” ( o ) en la base para llegar al menú
de “
AREA LOCAL
.”
PANTALLA DEL AURICULAR PANTALLA DE LA BASE
2. Oprima la tecla suave “OK” y la indicación “
PROG AREA LOCAL
- - -“ aparece
en la pantalla. La programación de fábrica es “- - - .”
3. Utilice el teclado numérico en la base o en el auricular para inscribir su clave de
área de tres dígitos.
NOTA: Oprima la tecla suave “EXIT” para una vez para conservar la programación
previa y regresar al menú principal.
4. Oprima la tecla suave “OK” para salvar su selección y regresar al menú
principal. La clave de área seleccionada aparece durante dos segundos.
PANTALLA DEL AURICULAR PANTALLA DE LA BASE
AREA LOCAL
OK
SALIR
IDIOMA
TONO TIMBRE
OK
AREA LOCAL
SALIR
IDIOMA
OK
AREA LOCAL
SALIR
OK
- - -
SALIR
PROG AREA LOCAL
AREA LOCAL - 317
TONO TIMBRE
OK
AREA LOCAL
SALIR
Page 88
15
TONO DEL TIMBRE
Asegúrese de que el auricular y la base estén en el menú principal.
Esta programación puede hacerse en el auricular o en la base. Usted puede
escoger entre seis tonos de timbre diferentes. Asegúrese que su teléfono esté
apagado (OFF) (no en modalidad para hablar –“TALK”).
1. Utilice el botón para revisar archivos del identificador (“cid/vol”) ( o ) en el
auricular o el botón del identificador (“CID/messages”) ( o ) en la base
para llegar al menú de “
TONO TIMBRE
.”
PANTALLA DEL AURICULAR PANTALLA DE LA BASE
2. Oprima la tecla suave “OK” y la indicación de programación (“
PROG TONO
TIMBR 1 2 3 4 5 6
”) aparece en la pantalla. Usted escuchará el tono del timbre
actual.
3. Utilice el teclado numérico en el auricular o en la base para seleccionar el
número del timbre
1,2,3,4,5,6
o utilice el botón para revisar archivos del
identificador (“cid/vol”) ( o ) en el auricular o el botón del identificador
(“CID/messages”) ( o ) en la base para mover la flecha a su selección. El
timbre de fábrica es
1
.
NOTA: Cuando usted utiliza el auricular o la base para programar un tono del timbre,
este tono se reproduce en cuanto usted hace la selección.
NOTA: Oprima la tecla suave “EXIT” una vez para conservar la programación previa y
regresar al menú principal.
TONO TIMBRE
OK
SALIR
REGISTRAR
TONO TIMBRE
OK
AREA LOCAL
SALIR
PROG TONO TIMBR
OK
1 2 3 4 5 6
SALIR
Page 89
16
4. Oprima la tecla suave “OK” para confirmar su selección y regresar al menú
principal. El nuevo tono del timbre aparece en la pantalla durante dos
segundos.
PANTALLA DEL AURICULAR PANTALLA DE LA BASE
TONO/PULSO
La mayoría de los teléfonos utilizan la modalidad de marcado por tono, pero
algunos pueden todavía utilizar el marcado por pulso. Dependiendo del tipo de
servicio, programe la modalidad de marcado de la siguiente manera:
Esta programación puede hacerse únicamente con la base. Asegúrese que la base
esté en el menú principal. Asegúrese que su teléfono esté en modalidad de
apagado (OFF) (No en modalidad de marcar).
1. Oprima el botón para revisar archivos del identificador (“CID/messages”) ( o
) en la base para ir al menú de “
TONO/PULSO
.”
2. Oprima la tecla suave “OK” y la indicación de tono o pulso (“
PROG TONO/
PULSO 1TONO 2PULSO
”) aparece en la pantalla.
3. Utilice el teclado numérico en la base para seleccionar “
1 TONO
” o “
2 PULSO
,”
o utilice el botón para revisar archivos del identificador (“CID/messages”) ( o
) en la base para mover la flecha a la selección deseada. La programación de
fábrica es
1
.
TONO TIMBRE
OK
REGISTRAR
SALIR
TONO TIMBRE
OK
AREA LOCAL
SALIR
TONO/PULSO
OK
HORA
SALIR
PROG TONO/PULSO
OK
1 TONO 2 PULSO
SALIR
TONO TIMBRE - 2
Page 90
17
NOTA: Oprima la tecla suave “EXIT” una vez para conservar la programación previa y
regresar al menú principal.
4. Oprima la tecla suave “OK” para confirmar su selección, y regresar al menú
principal. La modalidad para marcar aparece en la pantalla durante dos
segundos.
NOTA: Si usted no está seguro qué servicio de marcado tiene, programe el teléfono en
marcado por tono y haga una llamada de prueba. Si la llamada hace conexión, la
programación está correcta. Si no hace conexión, entonces programe el teléfono para
modalidad de pulso.
REGISTRO DEL AURICULAR
Esta programación puede hacerse únicamente con el auricular. Durante el proceso
de registro, mantenga su auricular cerca de la base. Asegúrese que su auricular
esté en el menú principal. Cuando la pantalla del auricular muestra lo siguiente:
1. Oprima el botón para revisar archivos del Caller ID-“cid/vol” ( o ) para ir al
menú de registro (“
REGISTRAR
”).
TONO
TONO/PULSO
OK
HORA
SALIR
TONO TIMBRE
OK
REGISTRAR
SALIR
FUERA DE RANGO
MENU DIR
Page 91
18
2. Oprima la tecla suave “OK” y el aparato le preguntará si registra el auricular. La
pregunta “
REGISTRAR AURICULR?
” aparece en la pantalla.
3. Oprima la tecla suave “OK” y el aparato le indica que el auricular necesita
registrarse. La indicación “
HOLD BASE PAGE ESPERE AL BIP
”aparece en la
pantalla.
4. Oprima y sostenga el botón “page/int” en la base hasta que usted escuche un
tono largo y la pantalla del auricular le pregunta si registra (“
CONFIRMAR
REGISTRAR?
”).
5. Oprima la tecla suave “OK” en el auricular para confirmar el registro. La
indicación “
AURICULR # REGISTRADO
” aparece durante dos segundos. Cuando
el registro del auricular ha concluido, usted puede nombrar el auricular. La
indicación “
INSCRIBA NOMBRE
” aparece en la pantalla.
HOLD BASE PAGE
ESPERE AL BIP
SALIR
CONFIRMAR
REGISTRAR ?
OK
SALIR
AURICULR 2
REGISTRADO
INSCRIBA NOMBRE
OK
SALIRBORR
REGISTRAR
OK
AURICULR ?
SALIR
Page 92
19
6. Utilice el teclado de tono para inscribir el nombre.
Más de una letra está almacenada en cada tecla numérica. Por ejemplo, para
inscribir “Bill Smith”, oprima la tecla del 2 dos veces para la letra B. Haga una
breve pausa y el cursor se mueve al siguiente lugar. Oprima la tecla del 4 tres
veces para la letra I. Haga una breve pausa y el cursor se mueve al siguiente
lugar. Oprima la tecla del 5 tres veces para la L. Haga una breve pausa y el
cursor se mueve al siguiente lugar. Oprima la tecla del 5 nuevamente tres veces
para la segunda L, oprima el 1 para hacer una pausa. Oprima la tecla del 7
cuatro veces para la letra S. Haga una breve pausa y el cursor se mueve al
siguiente lugar. Oprima la tecla del 6 una vez para la M. Haga una breve pausa y
el cursor se mueve al siguiente lugar. Oprima el 4 tres veces para la I. Haga una
breve pausa y el cursor se mueve al siguiente lugar. Oprima el 8 para la T. Haga
una breve pausa y el cursor se mueve al siguiente lugar. Oprima el 4 dos veces
para la H.
NOTA: Si usted comete un error, oprima la tecla suave para borrar (“DEL”) para
retroceder y borrar el número equivocado.
NOTA: Oprima la tecla suave “EXIT” para una vez para conservar la programación
previa y regresar al menú principal. U oprima y sostenga la tecla suave para salir
(“EXIT”) en el auricular para regresar a la modalidad de alerta.
7. Oprima la tecla suave “OK” para salvar el nombre y volver al menú principal.
Usted escuchará un tono de confirmación.
INSCRIBA NOMBRE
OK
SALIRBORR
B
INSCRIBA NOMBRE
OK
SALIRBORR
BILL SMITH
BILL SMITH
AURICULR 2
MENU DIR
CONT
Page 93
20
CANCELACIÓN DEL REGISTRO DEL AURICULAR
Este procedimiento puede llevarse a cabo únicamente con el auricular. Esta
función cancela el registro del auricular. Si usted no sabe el nombre de un
auricular, usted debe cancelar el registro del auricular siguiendo los pasos a
continuación. Durante el proceso de cancelación del registro, mantenga el
auricular cerca de la base.
ADVERTENCIA: No es recomendable que el registro de un auricular sea cancelado a
menos que sea absolutamente necesario porque una vez que este proceso se lleva a cabo,
las funciones telefónicas del auricular no pueden ser usadas hasta que éste sea registrado
nuevamente.
Asegúrese que su auricular esté en modalidad de menú. Asegúrese que su
teléfono esté en modalidad de apagado (OFF) (No en modalidad de marcar).
1. Oprima el botón para revisar archivos del Caller ID-“cid/vol” ( o ) para ir al
menú de Cancelación de Registro y la indicación “
DES-REGISTRAR
” aparece en
la pantalla.
2. Oprima la tecla suave “OK” y el aparato le preguntará si cancela el registro del
auricular (“
DES-REGISTRAR AURICULR?
”).
3. Oprima la tecla suave “OK” para des-registrar el auricular, y la indicación
“
ACERCAR BASE
” aparece en la pantalla hasta que el auricular esté cerca de la
base.
RAD TEL PORTATI
OK
SALIR
DES-REGISTRAR
DES - REGISTRAR
AURICULR 1 ?
OK
SALIR
ACERCAR
BASE
SALIR
Page 94
21
Entonces el aparato muestra la indicación “
CONFIRMAR DES-REGISTRAR?
” en la
pantalla.
NOTA: Oprima la tecla suave “EXIT” para una vez para conservar la programación
previa y regresar al menú principal.
4. Oprima nuevamente la tecla suave “OK” y el aparato confirma que ha
cancelado el registro en la pantalla indicando “
AURICULR # DEREGISTRAR
” e
inmediatamente después la indicación “
AURICULR DESREGISTRADO?
”
CANCELACIÓN GLOBAL DEL REGISTRO
Si uno o más de los auriculares se pierde, usted debe cancelar el registro en todos
los demás auriculares para asegurar el funcionamiento adecuado del sistema.
ADVERTENCIA: No es recomendable que el registro de un auricular sea cancelado a
menos que sea absolutamente necesario porque una vez que este proceso se lleva a cabo,
las funciones telefónicas del auricular no pueden ser usadas hasta que éste sea registrado
nuevamente.
1. Oprima y sostenga el botón localizador (“page/int”) en la base hasta que el
indicador de carga parpadee.
2. Oprima y sostenga nuevamente el botón localizador (“page/int”) en la base
hasta que el indicador de carga parpadee rápidamente.
3. Oprima y suelte el botón localizador (“page/int”) en la base. El indicador deja
de parpadear y la pantalla de la base muestra la indicación “
TODO AURICULR
DEREGISTRADO
” durante cinco segundos para confirmar que todos los
auriculares están desregistrados. Después la base regresa a la modalidad de
alerta, y cada auricular muestra la indicación “
REGISTRAR AURICULR?
” en la
pantalla.
CONFIRMAR
DES-REGISTRAR ?
SALIROK
AURICULR 1
DEREGISTRADO
Page 95
22
RADIO TELÉFONO PORTÁTIL (WALKIE-TALKIES)
Esta función le permite utilizar dos auriculares como si fueran walkie-talkies (para
la operación de radio-teléfono portátil, la corriente eléctrica en la base del aparato
no es necesaria). Esta programación puede únicamente ser activada desde el
auricular. Asegúrese que ambos auriculares estén en modalidad de menú.
1. En ambos auriculares, oprima el botón para revisar archivos del identificador
(“cid/vol”) ( o ) para ir al menú de Walkie-Talkie (“
RAD TEL PORTATI
”).
2. En ambos auriculares, oprima la tecla suave “OK” y el aparato le preguntará si
activa la modalidad de walkie-talkies (“
RAD TEL PORTATI ACTIVAR?
”).
3. En ambos auriculares, oprima nuevamente la tecla suave “OK” y el aparato
confirma que la modalidad de walkie talkies está activada (“
RAD TEL PORTATI
ACTIVADO
”) y el aparato indica el número de auricular (“
RAD TEL PORTATI
AURICULR #
”) en la pantalla.
NOTA: Ambos auricular deben estar en modalidad de radio teléfono portátil para
transmitir y recibir.
4. Oprima el botón localizador (“page/int”) en cada auricular, y después inscriba el
número/ extensión del auricular que usted quiera marcar. El auricular
seleccionado es llamado. Cuando el botón “page/int” en el recibidor del
auricular es oprimido, y el llamado del localizador es contestado, la función del
radio teléfono portátil es activada entre los dos auriculares. Los dos auriculares
muestran la indicación “
RAD TEL PORTATI CON AURICULR #
.”
DES-REGISTRAR
RAD TEL PORTATI
OK
SALIR
RAD TEL PORTATI
ACTIVAR ?
OK
SALIR
RAD TEL PORTATI
ACTIVADO
RAD TEL PORTATI
AURICULR 1
SALIR
Page 96
23
5. Cuando su conversación ha terminado, en ambos auriculares, el que recibe y el
que transmite, se puede oprimir el botón para salir (“EXIT”) para desactivar la
función del radio teléfono portátil y volver a la modalidad de alerta del radio
teléfono portátil.
NOTA: Únicamente un auricular es requerido para oprimir “EXIT” y terminar la
conversación. Si el botón de salida (“EXIT”) es oprimido en ambos auriculares, un
auricular sale de la modalidad de alerta en radio teléfono portátil y regresa a la
modalidad de alerta normal.
6. Oprima nuevamente el botón de salida (“EXIT”) para desactivar el radio teléfono
portátil y volver a la modalidad de radio teléfono portátil alerta. La indicación de
desactivado (“
RAD TEL PORTATI DESACTIVADO
”) aparece en la pantalla.
NOTA: Cuando dos auriculares están en modalidad de radio teléfono portátil, están
aislados de la base y no pueden recibir llamadas del localizador o hacer llamadas hasta
que el radio teléfono portátil haya sido desactivado.
NOTA: Mientras los auriculares estén en modalidad de radio teléfono portátil, ninguno
de éstos suena al recibir llamadas entrantes, y las llamadas entrantes no pueden ser
contestadas hasta que la modalidad de radio teléfono portátil haya sido desactivada.
RAD TEL PORTATI
EXTENSION ?
SALIR
LOCALIZANDO
AURICULR #
SALIR
RAD TEL PORTATI
CON AURICULAR #
ENMU
SALIR
RAD TEL PORTATI
AURICULR #
SALIR
RAD TEL PORTATI
DESACTIVADO
NOMBRE
AURICULR 1
DIR
MENU
CONT
Page 97
24
HORA DEL DÍA
Esta programación puede hacerse únicamente desde la base. Asegúrese que la
base esté en modalidad de menú. Asegúrese que su teléfono esté en modalidad de
apagado (OFF) (No en modalidad de marcar).
1. Oprima el botón para revisar archivos del identificador (“CID/messages”) ( o
) para ir al menú de hora (“
HORA
”).
2. Oprima la tecla suave “OK” y la indicación “
PROGRAMAR HORA - - :- - AM PM
”
aparece en la pantalla.
3. Utilice el teclado de tono para inscribir la hora actual. La flecha se mueve
automáticamente al campo de AM. Oprima el botón para revisar archivos del
Caller ID-“CID/messages” ( o ) para mover la flecha a
PM
.
4. Oprima la tecla suave “OK” para salvar su selección y regresar a la modalidad
de menú. La hora actual aparece durante dos segundos. Después la pantalla
muestra la indicación “
PROGRAME FECHA L M MI J V S D
.”
NOTA: Si usted quiere conservar la hora actual, oprima la tecla suave “OK” cuando la
pantalla muestra “- - :- -“ AM PM. Usted escuchará dos tonos y la hora actual aparecerá
durante dos segundos.
5. Oprima el botón de mensajes “CID/ messages” ( o ) para recorrer y
seleccionar la fecha.
6. Oprima la tecla “OK” para salvar su selección.
PROGRAMACIÓN DE FÁBRICA
Conforme usted se familiariza con este sistema, usted puede preferir utilizar las
programaciones originales. Siga los pasos a continuación para volver a las
programaciones de fábrica.
PROGRAME FECHA
L M MI J V S D
TONO/PULSO
HORA
SALIR
OK
PROGRAMAR HORA
_ _ : _ _ AM PM
SALIR
OK
Page 98
25
Asegúrese que el auricular o la base esté en la modalidad de menú. Asegúrese que su
teléfono esté en modalidad de apagado (OFF) (No en modalidad de marcar).
1. Oprima el botón para revisar archivos del identificador (“cid/vol”) en el auricular
o (“CID/ messages”) ( o ) en la base para mover la flecha a “
PROG DE
FABRICA.
”
2. Oprima la tecla “OK” y utilice el teclado de tono en su auricular o en la base
para inscribir “
1SI
” o “
2NO
”, o utilice el botón para revisar archivos del Caller
ID-(“cid/vol”) ( o ) en el auricular o el botón para revisar archivos del Caller
ID-“CID/messages” ( o ) en la base para mover la flecha a su selección. La
programación de fábrica es “
2NO
.”
NOTA: Si usted selecciona “sí” (“YES”), todas las funciones programables del menú
regresan a su programación original.
NOTA: Oprima la tecla suave “EXIT” para una vez para conservar la programación
previa y regresar al menú principal.
3. Oprima la tecla suave “OK” para salvar su selección, y regresar a la modalidad
de menú. La programación de fábrica que usted escoja aparece en la pantalla
durante dos segundos.
PANTALLA DEL AURICULAR PANTALLA DEL AURICULAR Y DE Y
DE LABASE LA BASE
PROG DE FABRICA
IDIOMA
SALIR
OK
PROG DE FABRICA
1 SI 2NO
SALIR
OK
PROG DE FABRICA
IDIOMA
SALIR
OK
PROG DE FABRICA
NO
Page 99
26
OPERACIÓN BÁSICA DEL TELÉFONO INALÁMBRICO
ALTAVOZ
Para la operación a manos libres y para su conveniencia, su sistema de dos
auriculares está equipado con un altavoz.
Para el mejor funcionamiento del altavoz, evite lo siguiente:
• Áreas con mucho ruido de fondo. (El micrófono puede recoger estos sonidos).
• Superficies afectadas por vibración.
• Áreas remetidas, como una esquina, abajo de una gaveta, o junto a un
gabinete, los cuales pueden generar un efecto de eco.
Siga las siguientes pautas cuando utilice el altavoz:
•Quédese razonablemente cerca del teléfono para que pueda ser escuchado
claramente por la persona con la que está hablando.
INDICADOR DE CARGA
Cuando el indicador de carga está iluminado, el auricular está colocado
correctamente sobre la base y está cargando. El indicador parpadea cuando la
base está siendo localizada, cuando la base está localizando al auricular, o cuando
usted recibe una llamada entrante.
PARA HACER UNA LLAMADA
AURICULAR
1. Levante el auricular y oprima el botón “talk/callback” en el auricular. Espere a
escuchar el tono de marcar.
2. Marque el número deseado, o marque el número primero y después el botón
“talk/ callback.”
3. Cuando usted haya terminado, oprima el botón “talk/callback” para colgar.
ALTAVOZ
1. Oprima el botón “callback/ speaker” en la base. Usted escuchará un tono de
marcar.
2. Marque el número que usted quiera marcar. O, usted puede marcar el número
primero y después oprimir el botón “speaker / callback.”
3. Cuando haya terminado, oprima el botón “speaker/callback” para colgar.
Page 100
27
PARA CONTESTAR UNA LLAMADA
AURICULAR
1. Cuando el teléfono timbre, oprima el botón “talk/callback” en el auricular.
2. Cuando haya terminado, oprima nuevamente el botón “talk/callback” para
colgar.
ALTAVOZ
1. Cuando el teléfono timbre, oprima el botón “speaker/callback” para contestar
una llamada.
2. Cuando haya terminado, oprima nuevamente el botón “speaker/callback” para
colgar.
NOTA: Si usted ha estado usando el auricular y quiere cambiar a altavoz, oprima el
botón “callback/speaker” en la base primero, y después oprima ya sea el botón “talk/
callback” o el auricular para desactivarlo, o ponga el auricular sobre la base. Cuando se
oprime el botón “speaker/ callback”, el indicador del altavoz se ilumina.
Si usted quiere cambiar de altavoz a auricular, oprima el botón “talk/ callback” en el
auricular primero, y después oprima el botón “speaker/callback” en la base.
TEMPORIZADOR (TIMER)
Después de que usted ha oprimido el botón “talk/callback” en el auricular o el
botón “speaker/callback” en la base, el temporizador integrado aparece en la
pantalla y empieza a contar la duración de la llamada en minutos y segundos.
AUTO ALERTA
Si usted coloca el auricular sobre la base, mientras el auricular está descolgado,
(durante una llamada), el auricular automáticamente desconecta la llamada.
SELECTOR DE VOLUMEN DEL TIMBRE
AURICULAR
1. Oprima el botón del timbre y la programación actual de timbre aparece en la
pantalla.
1 ON 2 OFF
TIMBRE ACTIVADO
SALIR
OK
Loading...
