GE 106575, 71045 User Manual

Household Type

Owner’s Guide Model 106575

Important Safeguards ........ 2

Service Information ............ 4

Assembly .......................... 5-6

Use .................................... 7-8

Thermal Cut Off ........... 4 & 8

Accessories .......................... 9

Hose Blockage ................... 10

Brush Roll .......................... 11

For Customer Assistance Please Call: 1-877-207-0923

Part No. 71045 (9/00)

Brush Roll Belt .............. 11-12

Dust Bag ....................... 12-13

Filters ............................ 13-14

Light Bulb .......................... 14

Problem Solving ............... 15

Customer Order Form ...... 17

Warranty ............................ 19

www.wal-mart.com

Vacuum Cleaner Safety

IMPORTANT SAFEGUARDS

When using an electrical appliance, basic precautions should always be followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER.

WARNING

To reduce the risk of fire, electric shock, or injury:

• Do not use outdoors or on wet surfaces.

• Do not leave vacuum cleaner when plugged in. Turn

off the switch and unplug the electrical cord when not in use and before servicing.

• Do not allow to be used as a toy. Close attention is necessary when used by or near children.

• Use only as described in this manual. Use only manufacturer’s recommended attachments.

• Do not use with damaged cord or plug. If vacuum cleaner is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, have unit serviced before using.

• Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not run vacuum cleaner over cord. Keep cord away from heated surfaces.

• Do not use extension cords or outlets with inadequate current carrying capacity.

• Turn off all controls before unplugging.

• Do not unplug by pulling on cord. To unplug, grasp

the plug, not the cord.

• Do not handle plug or vacuum cleaner with wet hands.

• Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything that may reduce airflow.

• This vacuum cleaner creates suction and contains a revolving brush roll. Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.

• Do not place cleaner on furniture or stairs as the brush roll may cause damage. Place cleaner on floor with the handle in storage position while using attachments.

• Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.

• Do not use without dust bag in place.

• Belt pulleys can become hot during normal use.

To prevent burns, avoid touching the belt pulley when servicing the drive belt.

• Use extra care when cleaning on stairs.

• Do not use to pick up flammable or combustible

liquids such as gasoline, or use in areas where they may be present.

• Store your cleaner indoors in a cool, dry area.

• Keep your work area well lighted.

• Unplug electrical appliances before vacuuming

them.

SAVE THESE INSTRUCTIONS

Vacuum Cleaner Safety

CONSEILS DE SÉCURITÉ

Lors de l’utilisation d’un appareil électrique, quelques précautions élémentaires doivent être observées, incluant les suivantes:

LISEZ TOUTES LES INSTRUCTIONS AVANT D’UTILISER VOTRE ASPIRATEUR.

AVERTISSEMENT

Pour réduire le risque de feu, de choc électrique, ou de blessure:

• Ne pas utiliser à l’extérieur ou sur des surfaces

mouillées.

• Ne pas laisser l’aspirateur seul quand il est branché.

Mettre l’interrupteur sur arrêt et débrancher l’appareil lorsque vous ne l’utilisez pas ou avant l’entretien.

• Ne permettez pas qu’il soit utilisé comme jouet. Une attention particulière est nécessaire lorsque utilisé par ou prés d’un enfant.

• Suivez les recommandations d’utilisation de ce manuel. Utilisez uniquement les accessoires recommandés par le fabriquant.

• Ne pas utiliser si le cordon ou la fiche sont endommagés. Si l’aspirateur ne fonctionne pas comme il le devrait, s’il a été échappé, s’il est endommagé, s’il a été laissé à l’extérieur ou échappé dans l’eau, retournez-le à un centre de service avant d’utiliser.

• Ne pas le tirer ou le transporter par le cordon, ne pas utiliser le cordon en guise de poignée. Ne pas fermer une porte sur le cordon ou tirer le cordon sur des coins ou bordures pointus. Ne pas circuler sur le cordon avec l’aspirateur. Tenir le cordon à distance des surfaces chauffantes.

• Ne pas utiliser des rallonges ou des prises qui n’ont pas de capacité suffisante pour transporter le courant.

• Fermer tous les contrôles avant de débrancher.

• Ne pas rien insérer dans les ouvertures. Ne pas

utiliser si des ouvertures sont bloquées; assurez-vous qu’elles soient dégagées de poussière, mousse, cheveux ou toute autre chose qui pourrait réduire le passage de l’air.

• Cet aspirateur créé de la succion et contient un rouleau-brosse tournant. Tenir les parties mobiles et les ouvertures loin des cheveux, du linge, des doigts et de toute partie du corps.

• Ne pas mettre l’aspirateur sur les meubles ou sur les escaliers car le rouleau-brosse peut faire des dommages. Placer l’aspirateur sur le plancher avec le manche en entreposage position temps que les accessoires sont en usage.

• Ne pas ramasser des objets qui brûlent ou fument comme les cigarettes, allumettes ou cendres chaudes.

• N’utilisez pas sans le sac de poussière en place.

• Les poulies du courroie peuvent devenir chaudes

pendant l’utilisation normale. Pour prévenir des brûlures, évitez de touché la poulie du courroie lorsque vous réparez la courroie.

• Portez une attention particulière lorsque vous nettoyez les escaliers.

• Ne pas utiliser pour ramasser des liquides inflammables ou combustibles comme de l’essence: Ne pas utiliser dans les endroits où ces liquides pourraient être présents.

• Entreposez votre aspirateur à l’intérieur dans un endroit propre et sec.

• Ne pas débrancher en tirant sur le cordon. Pour débrancher, tenez la fiche et non le cordon.

• Ne pas manipuler la fiche ou l’aspirateur avec les mains mouillées.

CONSERVEZ CES INSTRUCTIONS

• Maintenez un bon éclairage à l’endroit où vous travaillez.

• Débrancher les appareils électrique avant de les balayer.

To reduce the risk of electric shock, this appliance has a polarized plug (one blade wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way.

Afin de réduire le risque de choc électrique, cet appareil est muni d’une fiche polarisée (une des lames est plus large). Cette fiche ne peut être insérée dans une prise polarisée que d’une seule façon. Si la fiche ne peut être insérée dans la prise, retourner la fiche. Si la fiche ne peut toujours pas être insérée dans la prise, faire installer une prise adéquate par un électricien qualifié. Ne pas modifier la fiche.

General Information

The cleaner is designed to pick up dirt and dust particles. Avoid picking up hard or sharp objects with the cleaner to prevent bag tears, hose clogs, and fan blade breakage with subsequent motor damage.

DO NOT OIL the motor or the brush roll at any time. The bearings are permanently lubricated and sealed.

Customer Assistance

The instructions in this booklet serve as a guide to routine maintenance. For additional service information please call, 877-207-0923. You should know the model, type and serial numbers when you call.

Rating Plate

The model, type, and serial numbers are indicated on the rating plate located on the underneath side of the cleaner. For prompt and complete service information, always refer to these numbers when inquiring about service.

Model & Type__________________________

Serial No. _____________________________

Thermal Cut Off

This vacuum cleaner has a special thermostat that protects the cleaner in case of motor overheating. If the cleaner suddenly shuts off, turn the switch off and unplug the cleaner. Check the cleaner for a possible source of overheating such as a full bag, a blocked hose or clogged filters. If these conditions are found, fix them and wait at least 30 minutes before attempting to use the cleaner. After the 30 minute period, plug the cleaner back in and turn on the switch. If the cleaner still does not run, then call 877-207-0923 for customer assistance.

How To Assemble

CAUTION: Assemble the cleaner completely before plugging into an electrical outlet. CAUTION: Moving parts, stay clear of brush roll when plugging in.

NOTE: Features may vary by model yet all parts assemble the same.

Step A Remove Bag Cover

Bag Cover Latch

Bag Cover

Handle

Two Screw Locations

Step B Attach Handle

Handle

Tabs

Slots

Bag Cover

1. Remove bag cover from unit to expose the two screw installation locations. Release the bag cover by rotating the bag cover latch to the left. Pull out and up on the bag cover handle to remove bag cover from unit.

Screw

2. Position handle as above. Slide the handle down over the top of the unit, inserting handle tabs into slots on unit.

3. Find the two screws in the accessory bag included in the carton. To secure the handle on the unit, install the two screws.

Screw

Step C Replace Bag Cover

NOTE: Make sure bag is properly installed. Check to

see bag has not shifted away from bag inlet during shipping. See page 13 for further instructions.

Bag Cover

Latch

Step D Store Accessories

Dusting/

Upholstery

Brush

Nesting

Extension

Wands

Tabs

4. Replace front cover by aligning tabs at bottom of front cover into groove on cleaner. Pivot front cover up against cleaner and rotate the bag cover latch to the right to secure.

Bag Inlet

Groove

Step E Store Electrical Cord

Crevice

Tool

Cord

Retainer

5. You will find your cord retainer on the handle above the upper cord hook. Firmly push the electrical cord down into the cord retainer. This

Cord Hook

will place the cord out of the way the next time you vacuum.

6. Next wind the cord around the two cord hooks on the back of the cleaner.

7. Secure the plug to the cord to prevent unwinding.

How To Use

CAUTION: Do not plug in cleaner until you

understand all controls and features.

7 8

1. Cord Retainer. To use, push electrical cord down into cord

retainer.

2. ON/OFF Switch. International symbol I means On,

International symbol O means Off.

3. Bag Cover Latch. When bag cover latch is pointing to the

left, the bag cover is unlocked. When bag cover latch is pointing to the right the bag cover is locked. See the locked/ unlocked symbols on the unit.

4. Micron Filter Compartment. To open, slide micron filter

door up and pull away from unit. To close, place micron filter door at top of opening pressing against unit, slide down into place.

5. Bag Change Indicator. The bag change indicator is to remind

you to change the bag. The indicator on the bag cover moves down the window as the airflow through the bag decreases.

NOTE: Certain types of fine particles like powder, plaster dust,

or fine road dust can restrict airflow very quickly. The fine particles will decrease performance even before the bag appears to be full. Change the dust bag to restore maximum performance.

6. Disposable Dust Bag Compartment. To open, turn bag

cover latch (3) to the left pointing to unlock symbol, then pull top of dust bag cover out and away from unit. To close, place dust bag cover tabs (at the bottom) in groove at the bottom of compartment, rotating dust bag cover up and against unit. Then turn bag cover latch to the right pointing to the lock symbol.

7. Stair Handle. To use when cleaning stairs.

8. Handle Release. Step on handle release. Pull handle back to

a comfortable position. Press release again to lower handle further to clean under furniture.

9. Light Bulb Compartment. To gain access to light bulb

compartment remove the two screws in the lens.

10. Brush Roll Belt Window. To check condition of belt watch

to see if white dots on belt are moving through the window. This indicates the brush roll is turning.

11. Screws to release hood. Remove these screws to release

hood and give access to brush roll belt area.

12. Cleaner Height Setting. The front of the cleaner has an

adjustment that raises or lowers the cleaner base to match the type of floor surface. With the cleaner cord unplugged, set the adjustment to lowest setting for maximum carpet cleaning. If the cleaner is difficult to push, move adjustment to next highest setting until cleaner is comfortable to push. The brush roll must reach the carpet for effective cleaning. For ease in moving the adjustment knob, place handle in operating position and tilt cleaner back to remove weight from front wheels.

WARNING: Avoid injury. Keep loose clothing, hair, fingers,

and all other parts of body away from any moving part (such as the revolving brush). Turn off the switch and unplug the cleaner before changing the cleaner height setting.

13. Extension Wands. Use these wands on the end of the hose

for added cleaning reach.

How To Use (continued)

14. Hose Retainers (3). Place hose on retainers to

store hose on unit.

15. Carrying Handle. Use this handle to carry unit

from one place to another.

16. Dusting/Upholstery Brush. Store dusting brush

here.

17. Electrical Cord Hooks (2). Wrap electrical cord

around them to store electrical cord on unit. Top hook rotates down for quick release of the electrical cord. Rotate back up to store electrical cord.

18. Clear Tube Quarter Turn Fastener. Turn this

fastener to the unlock position to remove the clear tube. To replace tube, place tube on the back of the unit and turn fastener to lock position.

19. Crevice Tool. Store crevice tool here.

20. Hose adapter. Place the end of the hose into hose

adapter for floor/carpet cleaning.

Thermal Cut Off

This cleaner has a special thermostat that protects the cleaner in case of motor overheating. If the cleaner suddenly turns off, follow this procedure:

1. Push on/off switch to off.

2. Unplug cleaner.

3. Check for source of overheating problem (i.e. full

bag, clogged hose or clogged filters).

4. If a full bag, clogged hose or clogged filters are

found, replace the bag, unclog the hose or replace the filters.

5. Wait at least 30 minutes before attempting to reuse

the cleaner.

6. After 30 minute cool down period, plug the cleaner

in and push the switch pedal. The cleaner should turn on.

7. If the cleaner still does not operate, call 877-207-

0923 for customer assistance.

How To Use Accessories

CAUTION: Do not place cleaner on furniture or steps as the brush roll may cause damage. Place cleaner on floor

with the handle in storage position while using accessories.

1. Remove hose from hose adapter on the back of cleaner.

2. Place desired accessory onto end of hose or wand.

Dusting/Upholstery Brush is for furniture, blinds, books,

lamp shades, shelves, curtains, draperies, cushions and fabrics.

Dusting/

Upholstery

Crevice

Tool

Brush

Hose

Adapter

Hose or

Wand

Crevice Tool cleans corners, baseboards, between cushions.

Extension wands (Some models use 1 wand) Nested extension wands to add reach.

• Grasp both wands near ridges.

• Pull apart.

• Turn ridge end to center. • Push wands together.

How to Check and Clear Hose Blockages

Low suction or poor pickup may be due to a blockage in the vacuum cleaner.

1. Remove hose from hose retainer and check suction at end of hose - if little or no suction, check disposable dust bag. Change if needed. If no improvement proceed to step 2.

CAUTION: Turn off the switch and unplug the electrical

cord before clearing hose.

Electrical Cord

2. Remove electrical cord from cord hooks. Disconnect the clear tube by turning quarter turn fastener to the right to release, then lift away from cleaner.

Check for any obstructions that may be in the tube. Any obstructions can be removed by using a blunt instrument to clear the tube.

3. To completely release hose from the unit, remove two screws.

Any obstructions can be removed by using a blunt instrument to clear the hose. Flexing the hose may help loosen the blockage.

After clearing blockage, reverse above steps to reassemble unit.

Quarter

Tur n

Fastener

Hose Retainer

1. Remove hose from hose retainer and check suction at end of hose.

Two Screws

Clear Tube

2. Disconnect Clear Tube.

3. Release hose from unit.

How To Maintain

The instructions in this booklet serve as a guide to routine maintenance. To avoid unnecessary service calls, check the bag, belt, and brush roll often.

Brush Roll

The brush roll turns as it sweeps and combs the carpet nap. Remove hair and threads from the brush roll so it continues brushing the carpet. To maintain the most efficient cleaning, the bristles must touch the carpet. To test the bristle length, hold a ruler against the underneath side of the cleaner. If the bristles no longer touch the ruler, replace the brush roll.

Brush Roll Belt

The brush roll belt turns the brush roll to agitate, sweep, and comb the carpet nap. Check the belt regularly to be sure it is in good condition. Replace the belt if it stretches, cracks or loses tension. Cut away any hair or threads wound around the brush roll or the belt pulley because the buildup could cause the belt to rotate unevenly.

How To Replace Brush Roll Belt – Style GE-1

CAUTION: Turn off the switch and unplug the electrical cord before replacing belt. Belt pulleys can become hot

during normal use. To prevent injury, avoid touching the motor pulley when checking the belt.

1. Lower handle to floor to change belt.

2. Remove two screws to release hood. Lift hood to remove.

3. Lift left end of brush roll.

4. Remove and discard belt.

5. Clean debris from brush roll area.

Motor Shaft

Belt

Brush Roll

+ 25 hidden pages
