GBS Elektronik MCA-166 User Manual

MCA-166, MCA-527
Multi-Channel Analyzers
GBS Elektronik GmbH Bautzner Landstraße 22 01454 Großerkmannsdorf Germany
Tel.: 0049 (0)351 21 70 07 - 0 Fax: 0049 (0)351 21 70 07 - 21 E-Mail: kontakt@gbs-elektronik.de Website: www.gbs-elektronik.de
Description of the MCA
Description of the MCA
Communication DLL
Communication DLL
MCA527
Exclusion of liability
The information in this document has been carefully reviewed and is believed to be accurate and reliable. However, the GBS Elektronik GmbH assumes no liabilities for inaccuracies in this manual. This manual is subject to change without notice.
Last update: 2014-06-27
Address: GBS-Elektronik GmbH Bautzner Landstraße 22 01454 Großerkmannsdorf Tel.: (0351) 217007-0 Fax: (0351) 217007-21
Internet: http://www.gbs-elektronik.de Email to: kontakt@gbs-elektronik.de
2
Description of the MCA Communication DLL
Table of Contents
1 MS-Windows DLL for Communication with MCA166 and MCA527................................4
2 Initializing and Closing the Communication Port.............................................................4
3 Sending Firmware Commands to the MCA.....................................................................7
4 Functions to work with the MCA......................................................................................8
5 Managing the USB port..................................................................................................31
6 MS-Windows DLL for the Communication with Several MCAs.....................................32
3
MCA527

1 MS-Windows DLL for Communication with MCA166 and MCA527

The dynamic link library (mca32com.dll) is provided for Win32 applications. It must reside in the Windows system directory or in the same directory as the calling application. In order to include the DLL in your program, you have to use the file MCA32COM.BAS for Visual Basic or the files MCA_COMM.H and MCA32COM.LIB for C/C++. All functions and structures are declared in these files.
The description of the communication DLL refers to version 2.07.0008.

2 Initializing and Closing the Communication Port

Before you can use any other function, the communication port must be initialized. There are three functions for initializing the communication port: COMM_INIT_EX2 initializes a RS232 or USB communication port. COMM_INIT_ETHERNET initializes an Ethernet communication port. COMM_INIT_SELECT is the most recently added function and usable for all possible communication ports. It also offers the most comfort for the developer. For this reason, it is the most commendable function.
Before the application will be exited, the communication port has to be closed with COMM_CLOSE. Only one communication port can be used at the same time. If the communication port shall be changed, the current communication port has to be closed before the new one can be initialized.
Name
COMM_INIT_EX2
Description The function initializes the RS232 or USB communication.
Declaration
short CALLBACK COMM_INIT_EX2(LPSTR lpszInterface,clock_t lTimeOut, int nTryAgain,unsigned long ulBaudRate);
lpszInterface
Interface name (e. g. “COM1”)
lTimeOut
Time out [milliseconds] for the communication. It should be set to about 1000 milliseconds, because there are commands that run a short measurement before they return. The parameter can be set to a higher value if needed.
nTryAgain
Number of tries to send the command
ulBaudRate
Baud rate (38.400, 115.200, 307.200 or 3.000.000)
Return value If the function succeeds, the return value is nonzero.
Name
COMM_INIT_ETHERNET
Description The function initializes the Ethernet communication.
Declaration
short CALLBACK COMM_INIT_ETHERNET(unsigned short unNumberToFind, clock_t lTimeOut,int nTryAgain,HWND hWnd);
unNumberToFind
Serial number of the MCA527 which shall be connected to the application. If the parameter is unequal 0, the function exclusively tries to connect to the MCA527 with this serial
number. If the parameter is equal 0, the function searches for all available MCA527. If MCA527's are available,
they are displayed in a list, from what the user can choose the desired one.
lTimeOut
Time out [milliseconds] for the communication. It should be set to about 1000 milliseconds, because there are commands that run a short measurement before they return. The parameter can be set to a higher value if needed.
nTryAgain
Number of tries to send the command
hWnd
Handle to the parent window
Return value If the function succeeds, the return value is nonzero.
4
Description of the MCA Communication DLL
Name COMM_INIT_SELECT
Description The function initializes the communication with any MCA. The function detects all available MCA's.
Declaration
short CALLBACK COMM_INIT_SELECT(MCA_COMM_INIT* init,clock_t lTimeOut, int nTryAgain,HWND hWnd);
init
Pointer to a MCA_COMM_INIT structure.
lTimeOut
Time out [milliseconds] for the communication. It should be set to about 1000 milliseconds, because there are commands that run a short measurement before they return. The parameter can be set to a higher value if needed.
nTryAgain
Number of tries to send the command
hWnd
Handle to the parent window
Return value If the function succeeds, the return value is nonzero.
Name MCA_COMM_INIT
Description A pointer of the structure has to be passed to the COMM_INIT_SELECT function.
Declaration
struct MCA_COMM_INIT { unsigned short unSize; unsigned short unNumberToFind; VB_BOOL bMca166; unsigned short unMca166FwVersion; VB_BOOL bMca527; unsigned short unMca527FwVersion; VB_BOOL bShowLogo; VB_BOOL bUserInterface; unsigned short unInterfaceId; unsigned long ulBaudrate; };
unSize
Size of the structure.
unNumberToFind
[In] If this number is nonzero, the function tries to initializes the communication to the MCA with the corresponding serial number. If the communication with this MCA is possible, the communication is initialized and the function return. If the corresponding MCA is not detected or not usable, all detected MCA are listed within a dialog window.
If this number is zero, all detected MCA are always listed within a dialog window.
bMca166
[In] If this parameter is nonzero, the MCA-166 is assumed to be applicable.
unMca166FwVersion
[In] This parameter sets the earliest MCA-166 firmware version that is assumed to be applicable.
bMca527
[In] If this parameter is nonzero, the MCA-166 is assumed to be applicable.
unMca527FwVersion
[In] This parameter sets the earliest MCA-527 firmware version that is assumed to be applicable.
bShowLogo
[In] If this parameter is nonzero, the function displays the MCA logo.
bUserInterface
[In] If this parameter is nonzero, the function displays message windows for signaling the work progress.
unInterfaceId
[In] If this parameter is unequal to 0xFFFF, it determines the communication port that shall be used. [Out] This parameter returns the ID of the used communication port.
ulBaudrate
[Out] If the communication port is RS232 or USB, the parameter returns the current baud rate.
Name COMM_CLOSE
Description The function closes the communication.
Declaration
void CALLBACK COMM_CLOSE();
5
MCA527
Name GET_COMM_PARAM
Description The function returns the communication parameters.
Declaration
void CALLBACK GET_COMM_PARAM(MCA_COMM_PARAM* param);
param
Pointer to a MCA_COMM_PARAM structure.
Name
MCA_COMM_PARAM
Description The structure contains the MCA communication parameters. A pointer of the structure is passed to the
GET_COMM_PARAM function.
Declaration
struct MCA_COMM_PARAM { unsigned short unSize; unsigned short unInterfaceId; unsigned long ulBaudrate; unsigned short unComPortNumber; };
unSize
Size of the structure.
unInterfaceId
This parameter identifies the used communication interface. 0 = Ethernet
1 … 256 = RS232 (COM1 … COM256) 257 = USB, the MCA battery cannot be charged
1
258 = USB, the MCA battery can be charged
ulBaudrate
The baud rate is valid with RS232 and USB interface.
unComPortNumber
The virtual port number (COM1 … COM256) of the USB interface.
Name SET_TIMEOUT
Description The function sets the time out for the communication.
Declaration
void CALLBACK SET_TIMEOUT(clock_t lTimeOut);
lTimeOut
Time out [milliseconds] for the communication. It should be set to about 1000 milliseconds, because there are commands that run a short measurement before they return. The parameter can be set to a higher value if needed.
1 The MCA can only be charged over USB if the computer is connected directly with the USB connector
and not only via a USB adapter with the RS232 connector.
6
Description of the MCA Communication DLL

3 Sending Firmware Commands to the MCA

For information about MCA firmware commands (CMD_XXX) see document “Description of the MCA527 Firmware Commands” or appendix “Description of the MCA166 firmware functions” within
the MCA-166 User's Manual.
Name MCA_COMM, MCA_COMM6
Description These functions allow to send single firmware commands to the MCA. These function are only intended
for testing. The function MCA_COMM6 has been added because new MCA527 commands need more than 4 parameters. For the real work with the MCA you should use the other functions (MMCA_ ...) described in chapter 4.
Regardless of its type, each parameter of the firmware command is passed to one unsigned long parameter each. It will be cast within the function to the required type.
Declaration
ERROR_FLAG CALLBACK MCA_COMM(LPSTR command,LPSTR rec_data, unsigned long param1=0,unsigned long param2=0, unsigned long param3=0,unsigned long param4=0);
ERROR_FLAG CALLBACK MCA_COMM6(LPSTR command,LPSTR rec_data, unsigned long param1=0,unsigned long param2=0, unsigned long param3=0,unsigned long param4=0 unsigned long param5=0,unsigned long param6=0);
command
Command name (e. g. “CMD_START”)
rec_data
Pointer to RECDATA or command specific structure in which the received data is returned.
param1
1st parameter if required
param2
2nd parameter if required
param3
3rd parameter if required
param4
4th parameter if required
param5
5th parameter if required
param6
6th parameter if required
Return value ERROR_OK = 0 successful data transfer
ERROR_INTERFACE = 1 communication port is not initialized ERROR_UNKNOWN_COMMAND = 2 unknown command ERROR_COMMUNICATION = 3 faulty data transfer ERROR_INVALID_PARAM = 4 invalid parameter ERROR_RUNNING_MEAS = 5 measuring is running, but stopped
measurement is required for this command ERROR_VIOLATED_RIGHT = 6 execution right violation ERROR_STOPPED_MEAS = 7 measurement is stopped, but running
measurement is required for this command ERROR_WRONG_MODE = 8 wrong mode for using this command ERROR_UNHANDLED_COMMAND = 9 not handled by this firmware version ERROR_FILE_WRITING_IN_PROCCESS = 10 file writing is in process; this command must
not be called before the process is finished
7
MCA527

4 Functions to work with the MCA

For the work with the MCA a lot of functions are available. The functions can be subdivided in five groups:
Function for resetting the MCA (MMCA_RESET)
Functions for starting and stopping the data acquisition (MMCA_..._AQUIRE)
Functions for clearing (MMCA_CLEAR_...)
Functions for setting (MMCA_SET_...)
Functions for query (MMCA_QUERY_...)
The query functions are handed over a reference to a specific data structure. You can derive the name of the structure from the name of the function, by leaving out ”MMCA_” from the function name. (e. g. function MMCA_QUERY_STATE requires the data structur QUERY_STATE). You can also find important information in the files mca_comm.h (C/C++) and mca32com.bas (Visual Basic).
For information about MCA firmware commands (CMD_XXX) see document “Description of the MCA527 Firmware Commands” or appendix “Description of the MCA166 firmware functions” within the MCA-166 User's Manual.
MCA Reset function:
Name
MMCA_RESET
Description All MCA parameters will be reset to their initial state and all spectra are cleared. The measurement is
aborted. MCA-166: The states of the preamplifier power and the value of the high voltages are unchanged! MCA-527: The preamplifier power and the high voltage are turned off!
Declaration
ERROR_FLAG CALLBACK MMCA_RESET();
Return value See MCA_COMM function
MCA Acquire functions:
Name MMCA_START_ACQUIRE
Description The acquisition is started or continued with the current parameters (see CMD_START).
Declaration
ERROR_FLAG CALLBACK MMCA_START_ACQUIRE(unsigned short unFlags, unsigned long ulStartTime);
unFlags
Flags (see CMD_START)
ulStartTime
Start time (see CMD_START)
Return value See MCA_COMM function
Remarks Note, that the flags for MCA166 and MCA527 differ.
Name
MMCA_STOP_ACQUIRE
Description The acquisition is stopped.
Declaration
ERROR_FLAG CALLBACK MMCA_STOP_ACQUIRE();
Return value See MCA_COMM function
8
Description of the MCA Communication DLL
MCA Mode functions:
Name MMCA_SET_GENERAL_MODE
Description The function sets the general MCA527 mode.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_GENERAL_MODE(unsigned short unMode);
unMode
General MCA527 mode (see CMD_SET_GENERAL)
Return value See MCA_COMM function
Name MMCA_SET_MODE_MCA
Description The function sets the acquire mode to Multi-Channel Analyser.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MODE_MCA();
Return value See MCA_COMM function
Name
MMCA_SET_MODE_MCS
Description The function sets the acquire mode to Multi-Channel Scaler. The MCS input remains unchanged.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MODE_MCS();
Return value See MCA_COMM function
Name MMCA_SET_MODE_MCS_TTL
Description The function sets the acquire mode to Multi-Channel Scaler and the MCS input to “extern TTL”.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MODE_MCS_TTL();
Return value See MCA_COMM function
Name
MMCA_SET_MODE_MCS_ICR
Description The function sets the acquire mode to Multi-Channel Scaler and the MCS input to “Input Rate”.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MODE_MCS_ICR();
Return value See MCA_COMM function
Name MMCA_SET_MODE_MCS_DISCR
Description The function sets the acquire mode to Multi-Channel Scaler and the MCS input to “LLD/ULD”.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MODE_MCS_DISCR();
Return value See MCA_COMM function
MCA Clear functions:
Name
MMCA_CLEAR_MEMORY
Description MCA166: The acquisition is stopped and the spectrum is cleared.
MCA527: The acquisition is stopped and the spectrum, the real time and the dead time are cleared.
Declaration
ERROR_FLAG CALLBACK MMCA_CLEAR_MEMORY();
Return value See MCA_COMM function
9
MCA527
Name MMCA_CLEAR_TIME
Description MCA166: The acquisition is stopped and the real time and the dead time are cleared.
MCA527: The acquisition is stopped and the spectrum, the real time and the dead time are cleared.
Declaration
ERROR_FLAG CALLBACK MMCA_CLEAR_TIME();
Return value See MCA_COMM function
Name MMCA_CLEAR_ROI
Description The acquisition is stopped and the ROI limits are set to LLD and ULD
Declaration
ERROR_FLAG CALLBACK MMCA_CLEAR_ROI();
Return value See MCA_COMM function
Name
MMCA_CLEAR_ALL
Description The function is a combination of MMCA_CLEAR_ROI, MMCA_CLEAR_MEMORY and
MMCA_CLEAR_TIME
Declaration
ERROR_FLAG CALLBACK MMCA_CLEAR_ALL();
Return value See MCA_COMM function
MCA Setup functions:
Name MMCA_SET_PRESET_NONE
Description None automatic stop condition.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_PRESET_NONE();
Return value See MCA_COMM function
Name
MMCA_SET_PRESET_LIVE_TIME
Description The function sets the time for the automatic stop condition (dead time corrected).
Declaration
ERROR_FLAG CALLBACK MMCA_SET_PRESET_LIVE_TIME(unsigned long ulLiveTime);
ulLiveTime
Live time: MCA166: 1 ... 65535 sec
MCA527: 1 ... 4294967295 sec
Return value See MCA_COMM function
Name MMCA_SET_PRESET_REAL_TIME
Description The function sets the time for the automatic stop condition.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_PRESET_REAL_TIME(unsigned long ulRealTime);
ulRealTime
Real time: MCA166: 1 ... 65535 sec
MCA527: 1 ... 4294967295 sec
Return value See MCA_COMM function
Name
MMCA_SET_PRESET_INTEGRAL
Description The function sets the value for the ROI integral
Declaration
ERROR_FLAG CALLBACK MMCA_SET_PRESET_INTEGRAL(unsigned long ulIntegral);
ulIntegral
Integral: 1 ... 4294967295
Return value See MCA_COMM function
10
Description of the MCA Communication DLL
Name MMCA_SET_PRESET_AREA
Description The function sets the value for the ROI area
Declaration
ERROR_FLAG CALLBACK MMCA_SET_PRESET_AREA(unsigned long ulArea);
ulArea
Area: 1 ... 4294967295
Return value See MCA_COMM function
Name MMCA_SET_PRESET_REAL_TIME_MILLISECONDS
Description The function sets the time for the automatic stop condition. The function is only usable for MCA527,
firmware version 14.03 or higher.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_PRESET_REAL_TIME_MILLISECONDS(unsigned long ulRealTime);
ulRealTime
Real time: 1 ... 4294967295 msec
Return value See MCA_COMM function
Name MMCA_SET_ADC_RES_DISCR
Description The function sets the ADC resolution and the software discriminator range.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_ADC_RES_DISCR(unsigned short unCountOfChannels, unsigned short unLLD, unsigned short unULD)
unCountOfChannels
Channels: MCA166: 128, 256, 512, 1024, 2048 or 4096
MCA527: 128, … maximum channels count
unLLD
LLD: 0 <= LLD < ULD
unULD
ULD: MCA166: LLD < ULD < Channels - Channels/32
MCA527: LLD < ULD < Channels
Return value See MCA_COMM function
Name MMCA_SET_ROI
Description The function sets the begin and end of the ROI for the preset integral and area.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_ROI(unsigned short unROIBegin, unsigned short unROIEnd);
unROIBegin
ROI begin channel: LLD <= begin < end
unROIEnd
ROI end channel: LLD < end <= ULD
Return value See MCA_COMM function
Name MMCA_SET_REPEAT
Description The function sets the number of sweeps for repetitive measurement.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_REPEAT(unsigned short unRepeat);
unRepeat
Sweeps: 0 ... 65535 (0 = infinite)
Return value See MCA_COMM function
11
MCA527
Name MMCA_SET_MCS_CHANNEL
Description The function sets the number of channels for the MCS and Rate mode.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MCS_CHANNEL(unsigned short unChannel);
unChannel
MCS channels: MCA166: 128, 256, 512, 1024, 2048, 4096
MCA527: 1 … 16384
Return value See MCA_COMM function
Name
MMCA_SET_TIME_PER_CHANNEL
Description The function sets the dwell time per channel for the MCS mode.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_TIME_PER_CHANNEL(unsigned short unTime);
unTime
Real time per channel: 1 ... 65535 * 10 msec
Return value See MCA_COMM function
Name
MMCA_SET_TIME_PER_CHANNEL527
Description The function sets the dwell time per channel for the MCS mode.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_TIME_PER_CHANNEL527(unsigned long ulTime);
ulTime
Real time per channel: 1 ... 268435455 * 0.1 msec
Return value See MCA_COMM function
Remark This function is only usable for MCA527.
Name MMCA_SET_MCS_INPUT_ICR
Description The function selects the count rate signal as MCS input.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MCS_INPUT_ICR();
Return value See MCA_COMM function
Name
MMCA_SET_MCS_INPUT_TTL
Description The function selects the external TTL signals as MCS input.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MCS_INPUT_TTL();
Return value See MCA_COMM function
Name MMCA_SET_MCS_INPUT_DISCR
Description The function selects the software discrimination of ADC-input pulses as MCS input.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MCS_INPUT_DISCR();
Return value See MCA_COMM function
12
Description of the MCA Communication DLL
Name MMCA_SET_GAIN
Description The function sets the amplifier coarse and fine gain.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_GAIN(unsigned short unCoarseGain, unsigned short unFineGain);
unCoarseGain
Coarse gain: 2, 5, 10, 20, 50, 100, 200, 500 or 1000
unFineGain
Fine gain: MCA166: 5000 ... 15000 * 0.0001 (if coarse gain=1000, max. fine gain=10000 )
MCA527: 5000 … 65000 * 0.0001
Return value See MCA_COMM function
Name MMCA_SET_OFFSET_DAC
Description The function sets the offset DAC of the MCA527.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_OFFSET_DAC(unsigned short unValue);
unValue
DAC value: 0 … 16383
Return value See MCA_COMM function
Remarks The function is only usable for MCA527.
Name
MMCA_SET_MCA_INPUT_AMPLIFIER
Description The function sets the input to 'amplifier' (MCA166) or 'shaping' (MCA527).
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MCA_INPUT_AMPLIFIER();
Return value See MCA_COMM function
Name MMCA_SET_MCA_INPUT_AMPLIFIER_POS
Description The function sets the amplifier input polarity to positive.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MCA_INPUT_AMPLIFIER_POS();
Return value See MCA_COMM function
Name
MMCA_SET_MCA_INPUT_AMPLIFIER_NEG
Description The function sets the amplifier input polarity to negative.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MCA_INPUT_AMPLIFIER_NEG();
Return value See MCA_COMM function
Name MMCA_SET_MCA_INPUT_DIRECT
Description The function sets the ADC input to direct.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MCA_INPUT_DIRECT();
Return value See MCA_COMM function
Remarks This function is only usable for MCA527. For MCA166 use exclusively
MMCA_SET_MCA_INPUT_DIRECT_POS or MMCA_SET_MCA_INPUT_DIRECT_NEG.
Name MMCA_SET_MCA_INPUT_DIRECT_POS
Description The function sets the ADC input to direct (0 to +3V input range) and PUR to off.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MCA_INPUT_DIRECT_POS();
Return value See MCA_COMM function
13
MCA527
Name MMCA_SET_MCA_INPUT_DIRECT_NEG
Description The function sets the ADC input to direct (0 to -3V input range) and PUR to off.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_MCA_INPUT_DIRECT_NEG();
Return value See MCA_COMM function
Name
MMCA_SET_INPUT_POLARITY_POS
Description The function sets the input polarity to positive.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_INPUT_POLARITY_POS();
Return value See MCA_COMM function
Name MMCA_SET_INPUT_POLARITY_NEG
Description The function sets the ADC input polarity to negative.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_INPUT_POLARITY_NEG();
Return value See MCA_COMM function
Name
MMCA_SET_THRESHOLD
Description The function sets the analog threshold .
Declaration
ERROR_FLAG CALLBACK MMCA_SET_THRESHOLD(unsigned short unThreshold);
unThreshold
0 ... 60 %
Return value See MCA_COMM function
Name
MMCA_SET_THRESHOLD_TENTHS
Description The function sets the analog threshold .
Declaration
ERROR_FLAG CALLBACK MMCA_SET_THRESHOLD_TENTHS(unsigned short unThreshold);
unThreshold
0 ... 600 * 0.1 %
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name MMCA_SET_SHAPING_TIME_LOW
Description The function sets the low shaping time.
MCA166: ordinarily 1µs MCA527: value set by MMCA_SET_SHAPING_TIME_PAIR
Declaration
ERROR_FLAG CALLBACK MMCA_SET_SHAPING_TIME_LOW();
Return value See MCA_COMM function
Name MMCA_SET_SHAPING_TIME_HIGH
Description The function sets the high shaping time.
MCA166: ordinarily 2µs MCA527: value set by MMCA_SET_SHAPING_TIME_PAIR
Declaration
ERROR_FLAG CALLBACK MMCA_SET_SHAPING_TIME_HIGH();
Return value See MCA_COMM function
14
Description of the MCA Communication DLL
Name MMCA_SET_SHAPING_TIME_PAIR
Description The function sets the values for the low and high shaping time of the MCA527. Afterwards, the shaping
time is selected with MMCA_SET_SHAPING_TIME_LOW or MMCS_SET_SHAPING_TIME_HIGH. This practice seems to be circumstantial, but it considered the compatibility to the MCA166.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_SHAPING_TIME_PAIR(unsigned short unLow, unsigned short unHigh);
unLow
Low shaping time: 1 … 254 (low shaping time < high shaping time)
unHigh
High shaping time: 2 … 255 (low shaping time < high shaping time)
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name MMCA_SET_TRIGGER_FILTER
Description The function sets the trigger filters used for low and high shaping time.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_TRIGGER_FILTER(unsigned short unTriggerFilterLow, unsigned short unTriggerFilterHigh);
unTriggerFilterLow
Trigger filter for low shaping time: 0 = (-1; +1), 1 = (-1; 0; +1), 2 = (+1; -2; +1), 3 = (+1; 0; -2; 0; +1)
unTriggerFilterHigh
Trigger filter for high shaping time: 0 = (-1; +1), 1 = (-1; 0; +1), 2 = (+1; -2; +1), 3 = (+1; 0; -2; 0; +1)
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name
MMCA_SET_TRIGGER_PARAM
Description The function sets the trigger parameters..
Declaration
ERROR_FLAG CALLBACK MMCA_SET_TRIGGER_PARAM(unsigned short unParam,unsigned long ulValue);
unParam
Parameter to be set 0 = Trigger level for automatic threshold calculation
1 = Trigger level for automatic threshold calculation for direct input 2 = Set trigger threshold
ulValue
New value
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name MMCA_SET_EVAL_FILTER_TYPE
Description The function sets the evaluation filter type.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_EVAL_FILTER_TYPE(unsigned short unFilterType);
unFilterType
Evaluation filter type: 0 = standard filter, 1 = LF filter
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
15
MCA527
Name MMCA_SET_FLAT_TOP_TIME
Description The function sets the flattop time.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_FLAT_TOP_TIME(unsigned short unFlatTopTime);
unFlatTopTime
Flattop time: 0 … 50 * 0.1 µs
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name
MMCA_SET_JITTER_CORRECTION
Description The function sets the jitter correction.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_JITTER_CORRECTION(unsigned short unOffOn);
unOffOn
0 turns jitter correction off and 0 turns it on
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name
MMCA_SET_BASELINE_RESTORING
Description The function sets the baseline restorer.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_BASELINE_RESTORING(unsigned char uchOption);
uchOption
See CMD_SET_BASELINE_RESTORING
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name MMCA_SET_PILE_UP_REJECTION
Description The function sets the pile up rejection.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_PILE_UP_REJECTION(unsigned short unOffOn);
unOffOn
0 turns PUR off and 0 turns it on
Return value See MCA_COMM function
Name
MMCA_SET_FAST
Description The function sets the fast discriminator threshold.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_FAST(unsigned short unFast);
unFast
0 ... 2499, default 400
Return value See MCA_COMM function
Name
MMCA_SET_SLOW
Description The function sets the slow discriminator threshold.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_SLOW(unsigned short unSlow);
unSlow
0 ... 2499, default 400
Return value See MCA_COMM function
16
Description of the MCA Communication DLL
Name MMCA_SET_PZC_MANUAL
Description The function sets the PZC value and returns the PZC offset.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_PZC_MANUAL(unsigned short unPZC,LPSTR rec_data);
unPZC
PZC value: 0 ... 2499
rec_data
Pointer to a SET_MEASURE_PZC structure. See CMD_SET_MEASURE_PZC, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Remarks MCA166: Please note that this function may cause a firmware hang up if the following requirements
are not meets:
- statistical distributed input pulses with a count rate between 500 and 30000 Cps
- the significant peak is located above the first quarter of the spectrum
Name MMCA_SET_PZC_VALUE
Description The function sets the PZC value.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_PZC_VALUE(unsigned short unPZC,LPSTR rec_data);
unPZC
PZC value: 0 ... 2499
rec_data
Pointer to a SET_MEASURE_PZC structure. However, the function has no effect on this structure. See CMD_SET_MEASURE_PZC, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Remarks See remarks for MMCA_SET_PZC_MANUAL function.
Name
MMCA_SET_PZC_TIME_OFFSET
Description The function sets the time offset for the PZC measurement.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_PZC_TIME_OFFSET(unsigned short unOffset1, unsigned short unOffset3)
unOffset1
Offset for low DTC: 0 ... 31, default 15
unOffset3
Offset for high DTC: 0 ... 31, default 15
Return value See MCA_COMM function
Name
MMCA_SET_GATING
Description The function sets the gating.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_GATING(unsigned char uchMode, unsigned char uchSignal, unsigned char uchShift);
uchMode
Mode: 0 = none, 1 = discard, 2 = sort
uchSignal
Signal: 0 = low, 1 = high
uchShift
Time shift: 0 … 255 * 100 nsec
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
17
MCA527
Name MMCA_SET_COMMON_MEMORY_FILL_STOP
Description The function sets the fill stop for the common memory. The common memory is used for acquiring raw
data from the ADC (general mode = GMODE_TRANSFER_ADC_VALUES). The MCA acquires data until the fill stop is reached.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_COMMON_MEMORY_FILL_STOP(unsigned long ulFillStop);
ulFillStop
0 … common memory size (see CMD_QUERY_STATE527_EX, mca_comm.h or
mca32com.bas.)
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name
MMCA_SET_TTL_LEVELS
Description The function sets the low and high level for TTL input signals.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_TTL_LEVELS(unsigned short unLowLevel, unsigned short unHighLevel);
unLowLevel
1 … 99 * 0.1 V
unHighLevel
2 … 100 * 0.1 V
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name MMCA_SET_CORE_CLOCK
Description The function sets the parameters for the oscilloscope mode.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_CORE_CLOCK(unsigned short unClock);
unClock
Clock: 1 … 6 [*100 MHz]
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name
MMCA_SET_OSCI_TRIGGER
Description The function sets the parameters for the oscilloscope mode.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_OSCI_TRIGGER(unsigned char uchMode, char chTimeResolution, unsigned short unThreshold, unsigned short unPosition);
uchMode
Mode: 0 … 4
chTimeResolution
Time resolution: -5 … +13
unThreshold
Threshold: 0 … 16383
unPosition
Position: 0 … 499
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
18
Description of the MCA Communication DLL
MCA Stabilization functions:
Name MMCA_SET_STABILISATION
Description The function sets the peak stabilization.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_STABILISATION(unsigned short unStateOrChannel, unsigned short unROIBegin, unsigned short unROIEnd);
unStateOrChannel
Stabilization flags (see CMD_SET_STABILISATION)
unROIBegin
Peak ROI begin: LLD<= begin < end
unROIEnd
Peak ROI end: begin < end <= ULD, (end-begin) < 250
Return value See MCA_COMM function
Name MMCA_SET_STAB_PARAM
Description The function sets the peak stabilization parameters.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_STAB_PARAM(unsigned short unStabTime, unsigned long ulStabArea);
unStabTime
Stabilization time: default 10 sec interval
ulStabArea
Stabilization area: default 25000
Return value See MCA_COMM function
MCA Detector Power functions:
Name MMCA_SET_PREAMPLIFIER_POWER
Description The function sets the preamplifier power.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_PREAMPLIFIER_POWER(unsigned short unPreamplifierPower);
unPreamplifierPower
Preamplifier switches: 0x80 -24V
0x40 +24V 0x20 -12V 0x10 +12V
Return value See MCA_COMM function
Name MMCA_SET_HIGH_VOLTAGES
Description The function sets the detector high voltage and controls the HV-inhibit-signal.
2
Declaration
ERROR_FLAG CALLBACK MMCA_SET_HIGH_VOLTAGES(unsigned short unHighVoltage, long lInhibit);
unHighVoltage
High voltage: 0 ... 3600 V
lInhibit
High voltage inhibit: 0 = Inhibit off
1 = ”Canberra HPGe mode”, HV shut down if inhibit input < 0.5V
3
2 = “DSG HPGe mode”, HV shut down if inhibit input < 0.5V
3
-1 = ”Ortec HPGe mode”, HV shut down if inhibit input ≥ 5V
Return value See MCA_COMM function
2 The high voltages will ramp up or down by the MMCA. 3 Mode 1 and 2 are identical. The difference is made by reasons of legacy.
19
MCA527
Name MMCA_SET_PIN5_CURRENT_SOURCE
Description The function switches the current source on SUB-D9 pin5 on or off.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_PIN5_CURRENT_SOURCE(unsigned char uchOption);
uchOption
0 = off, 1 = on
Return value See MCA_COMM function
Remarks The function is only usable for MCA527.
MCA Data Setup functions:
Name
MMCA_SET_TDF
Description The function sets the dead time correction parameter.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_TDF(unsigned short unTdf);
unTdf
100 ... 3000, default 800
Return value See MCA_COMM function
Name
MMCA_SET_USER_DATA
Description The function stores any 32 bit value in the MCA memory.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_USER_DATA(unsigned short unNumber, unsigned long ulUserData);
unNumber
Number: MCA166: 0 ... 63
MCA527: 0 … 255
ulUserData
32 bit value
Return value See MCA_COMM function
Remarks Appendix 5 contains additional information about user data.
Name MMCA_SET_TIME
Description The function writes the current PC time to the internal MCA clock.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_TIME();
Return value See MCA_COMM function
Remarks The function is only usable for MCA527.
Name MMCA_SET_UF6_ROIS
Description The function sets the begin and the end of a ROI used by the other UF6 functions.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_UF6_ROIS(unsigned short unNumber, unsigned short unBegin, unsigned short unEnd);
unNumber
ROI number: 1 ... 3
unBegin
ROI begin: LLD<= begin < end
unEnd
ROI end: begin < end <= ULD, (end-begin) < 250
Return value See MCA_COMM function
20
Description of the MCA Communication DLL
Name MMCA_SET_AHRC_PARAM
Description The function sets the parameters for analog high rate counting (AHRC).
Declaration
ERROR_FLAG CALLBACK MMCA_SET_AHRC_PARAM(unsigned short unThreshold, unsigned long ulGroupWidth);
unThreshold
AHRC trigger threshold
ulGroupWidth
AHRC group width
Return value See MCA_COMM function
Remarks This function is only usable for MCA527. See CMD_SET_AHRC_PARAM.
Name
MMCA_SET_IP_ADDRESS
Description The function sets the IP address.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_IP_ADDRESS(unsigned char* lpuchAddress);
lpuchAddress
Pointer to a 4 byte long IP address.
Return value See MCA_COMM function
Remarks This function is only usable for MCA527. See CMD_SET_IP_ADDRESS.
21
MCA527
MCA Query functions:
Name MMCA_QUERY_USER_DATA
Description The function reads 32 user data (32 bit values) from the MCA parameter memory.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_USER_DATA(unsigned short unNumber, LPSTR rec_data);
unNumber
Number of the first entry: MCA166: 0 ... 63
MCA527: 0 … 255
rec_data
Pointer to a QUERRY_USER_DATA structure. See CMD_QUERY_USER_DATA, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Remarks Appendix 5 contains additional information about user data.
Name MMCA_QUERY_POWER
Description The function reads the MMCA power state.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_POWER(LPSTR rec_data);
rec_data
Pointer to a QUERRY_POWER structure. See CMD_QUERY_POWER, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Name
MMCA_QUERY_STATE
Description The function reads the MCA state.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_STATE(LPSTR rec_data);
rec_data
Pointer to a QUERRY_STATE structure. See CMD_QUERY_STATE, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Name MMCA_QUERY_STATE527
Description The function reads the MCA527 state.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_STATE527(LPSTR rec_data);
rec_data
Pointer to a QUERRY_STATE527 structure. See CMD_QUERY_STATE527, mca_comm.h or mca32com.bas. (This function converts the 32 bits value at byte offset 12 to year, month, day, hour, minute and second
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name
MMCA_QUERY_STATE527_EX
Description The function reads the extended MCA527 state.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_STATE527_EX(LPSTR rec_data);
rec_data
Pointer to a QUERRY_STATE527_EX structure. See CMD_QUERY_STATE527_EX, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
22
Description of the MCA Communication DLL
Name MMCA_QUERY_STATE527_EX2
Description The function reads the extended MCA527 state.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_STATE527_EX2(LPSTR rec_data);
rec_data
Pointer to a QUERRY_STATE527_EX2 structure. See CMD_QUERY_STATE527_EX2, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name MMCA_QUERY_SYSTEM_DATA
Description The function reads the MMCA system data.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_SYSTEM_DATA(LPSTR rec_data);
rec_data
Pointer to a QUERRY_SYSTEM_DATA structure. See CMD_QUERY_SYSTEM_DATA, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Name
MMCA_QUERY_SPECTRA
Description The function read the MMCA spectrum data.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_SPECTRA(unsigned short unFirstChannel, unsigned long ulCompressFactor, LPSTR rec_data)
unFirstChannel
Number of first channel (bit 11 … 0): 0 … channels count – 32 * compress factor – 1 and buffer control (bit 15 … 12): 0 … 15 (see CMD_QUERY_SPECTRA_EX).
ulCompressFactor
Compress factor (MCA166: 1 ... 32, MCA527: 1 … 128)
rec_data
Pointer to a QUERRY_SPECTRA structure. See CMD_QUERY_SPECTRA, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Name MMCA_QUERY_SPECTRA_EX
Description The function read the MMCA spectrum data.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_SPECTRA_EX(unsigned short unFirstChannel, unsigned short unCompressFactor, unsigned short unBufferControl, LPSTR rec_data)
unFirstChannel
Number of first channel: 0 … channels count – 32 * compress factor - 1
unCompressFactor
Compress factor: (MCA166: 1 ... 32, MCA527: 1 … 128)
unBufferControl
Buffer control (see CMD_QUERY_SPECTRA_EX).
rec_data
Pointer to a QUERRY_SPECTRA structure. See CMD_QUERY_SPECTRA, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Remarks This function can be used for both MCA166 and MCA527. The function decides based on the para-
meters which firmware command (CMD_QUERY_SPECTRA or CMD_QUERY_SPECTRA_EX) has to be applied. The developer has to make sure that the parameters suit to the connected MCA type.
23
MCA527
Name MMCA_QUERY_IMAGE
Description The function reads the MCA166 spectrum image (120x256). It should only be used to display the
spectrum in a 120 x 256 pixel window.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_IMAGE(unsigned short unFirstChannel, unsigned short unCompressFactor, unsigned short unVerticalFullScale, LPSTR rec_data);
unFirstChannel
Number of first channel
unCompressFactor
Compress factor: 1 ... 32
unVerticalFullScale
Vertical full scale
rec_data
Pointer to a QUERRY_IMAGE structure. See mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Remarks This function is only usable for MCA166.
Name MMCA_QUERY_ENRICHMENT
Description The function reads current dead time, real time and the integral of two ROIs.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_ENRICHMENT(unsigned short unRoi1Begin, unsigned short unRoi1End, unsigned short unRoi2Begin, unsigned short unRoi2End, LPSTR rec_data);
unRoi1Begin
Peak begin integer value LLD<= begin < end
unRoi1End,
Peak end integer value begin < end <= ULD, (end-begin) < 250
unRoi2Begin
Background begin integer value LLD<= begin < end
unRoi2End
Background end integer value begin < end <= ULD, (end-begin) < 250
rec_data
Pointer to a QUERRY_ENRICHMENT structure. See CMD_QUERY_ENRICHMENT, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Name
MMCA_QUERY_UF6_INFO
Description The function reads current dead time, real time the integral, begin and end of the UF6 ROIs
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_UF6_INFO(LPSTR rec_data);
rec_data
Pointer to a QUERRY_UF6_INFO structure. See CMD_QUERY_UF6_INFO, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Name MMCA_QUERY_UF6_ROIS
Description The function reads the begin and end of the 3 ROIs
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_UF6_ROIS(LPSTR rec_data);
rec_data
Pointer to a QUERRY_UF6_ROIS structure. See CMD_QUERY_UF6_ROIS, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
24
Description of the MCA Communication DLL
Name MMCA_QUERY_CENTROID
Description The function reads peak centroid of the specified ROI
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_CENTROID(unsigned short unRoiBegin, unsigned short unRoiEnd, LPSTR rec_data)
unRoiBegin
Peak ROI begin: LLD<= begin < end
unRoiEnd
Peak ROI end: begin < end <= ULD, (end-begin) < 250
rec_data
Pointer to a QUERRY_CENTROID structure. See CMD_QUERY_CENTROID, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Name
MMCA_QUERY_VOLTAGE_CURRENT
Description The function reads the voltages and currents from the MCA.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_VOLTAGE_CURRENT(LPSTR rec_data);
rec_data
Pointer to a QUERRY_VOLTAGE_CURRENT structure. See CMD_QUERY_VOLTAGE_CURRENT, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Name MMCA_QUERY_COMMON_MEMORY
Description The function reads the common memory from the MCA527.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_COMMON_MEMORY(unsigned long ulOffset, unsigned short* lpunData);
ulOffset
Even-numbered offset to be read from.
lpunData
Pointer to an array of 720 unsigned short values. See CMD_QUERY_COMMON_MEMORY, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name MMCA_QUERY_HISTOGRAM
Description The function causes the MCA527 to acquire a histogram from 500.000 ADC samples (= 50 ms).
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_HISTOGRAM(unsigned short unOffset, unsigned short unCompressFactor, unsigned long* lpulData);
unOffset
Offset to be read from (0 ... 16384 – 256 * class interval width).
unCompressFactor
Class interval width ( 1, 2, 4 ... 64).
lpunData
Pointer to an array of 256 unsigned long values.
Return value See MCA_COMM function
Remarks This function is only usable for MCA527. See CMD_QUERY_HISTORY, mca_comm.h or
mca32com.bas.
25
MCA527
Name MMCA_QUERY_OSCI_SCREEN
Description The function reads the data for the oscilloscope screen.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_OSCI_SCREEN(unsigned long ulPosition, LPSTR rec_data);
ulPosition
-1 or the previously returned position.
rec_data
Pointer to a QUERY_OSCI_SCREEN structure. See CMD_QUERY_OSCI_SCREEN or mca_comm.h.
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
The oscilloscope mode is described in document: “MCA527 Oscilloscope Mode”.
Name MMCA_QUERY_OSCI_SCREEN_EX
Description The function reads the data for the oscilloscope screen.
Besides, it initiates the convolution of the data with the trigger filter and the main filter. The results can be read afterwards with the functions MMCA_QUERY_OSCI_TRIGGER_FILTER_RESULTS and MMCA_QUERY_OSCI_MAIN_FILTER_RESULTS.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_OSCI_SCREEN_EX(unsigned short unFlags, LPSTR rec_data);
unFlags
Bit 0: convolve data with trigger filter Bit 1: convolve data with main filter
rec_data
Pointer to a QUERY_OSCI_SCREEN_EX structure. See CMD_QUERY_OSCI_SCREEN_EX or mca_comm.h.
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
The oscilloscope mode is described in document: “MCA527 Oscilloscope Mode”.
Name
MMCA_QUERY_OSCI_TRIGGER_FILTER_RESULTS
Description The function returns the results of the convolution of the oscilloscope data with the trigger filter. The
calculation is initiated by the function MMCA_QUERY_OSCI_SCREEN_EX.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_OSCI_TRIGGER_FILTER_RESULTS(unsigned short unFlag, LPSTR rec_data);
unFlag
0 = read 360 values, ≠0 = read 720 values.
rec_data
Pointer to a QUERY_OSCI_TRIGGER_FILTER_RESULTS structure. See CMD_QUERY_OSCI_TRIGGER_FILTER_RESULTS or mca_comm.h.
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name MMCA_QUERY_OSCI_MAIN_FILTER_RESULTS
Description The function returns the results of the convolution of the oscilloscope data with the main filter. The
calculation is initiated by the function MMCA_QUERY_OSCI_SCREEN_EX.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_OSCI_MAIN_FILTER_RESULTS(LPSTR rec_data);
rec_data
Pointer to a QUERY_OSCI_MAIN_FILTER_RESULTS structure. See CMD_QUERY_OSCI_MAIN_FILTER_RESULTS or mca_comm.h.
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
26
Description of the MCA Communication DLL
Name MMCA_QUERY_AHRC_HISTOGRAM
Description The function causes the MCA527 to acquire a corresponding histogram.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_AHRC_HISTOGRAM(unsigned short unClassWidth, LPSTR rec_data);
unClassWidth
Class interval width ( 1, 2, 4 ... 32768).
rec_data
Pointer to an array of 360 unsigned long values. See CMD_QUERY_AHRC_HISTOGRAM, mca_comm.h or mca32com.bas.
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name MMCA_QUERY_ADJUSTMENT_TABLE
Description The function returns the ADC values that has been measured with different settings at open signal input.
These data can be used to interpolate the ADC value which corresponds to the ground line.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_ADJUSTMENT_TABLE(LPSTR rec_data);
rec_data
Pointer to a QUERRY_ADJUSTMENT_TABLE structure. See CMD_QUERY_ADJUSTMENT_TABLE or mca_comm.h.
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name MMCA_QUERY_ON_LINE
Description The function checks the communication between the MCA and the PC.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_ON_LINE();
Return value See MCA_COMM function
27
MCA527
MCA527 Extension Port functions:
Name MMCA_SET_EXTENSION_PORT
Description The function configures the parts of the extension port..
Declaration
ERROR_FLAG CALLBACK MMCA_SET_EXTENSION_PORT(unsigned char uchA, unsigned char uchB, unsigned char uchC, unsigned char uchD, unsigned char uchE, unsigned char uchF)
uchA … uchF
The parameters assign the parts their job.
Return value See MCA_COMM function
Remarks This function is only usable for MCA527. See CMD_SET_EXTENSION_PORT.
Name MMCA_SET_EXTENSION_POLARITY
Description The function sets the polarity for the parts of the extension port.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_EXTENSION_POLARITY(unsigned short unPart, unsigned short unPolarity);
unPart
Part of the extension port.
unPolarity
Polarity
Return value See MCA_COMM function
Remarks This function is only usable for MCA527. See CMD_SET_EXTENSION_POLARITY.
Name
MMCA_SET_EXTENSION_PULSER_PERIOD
Description The function sets the pulser period for the parts of the extension port.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_EXTENSION_PULSER_PERIOD(unsigned short unPart, unsigned long ulPeriod);
unPart
Part of the extension port.
ulPeriod
Pulser period
Return value See MCA_COMM function
Remarks This function is only usable for MCA527. See CMD_SET_EXTENSION_PULSER_PERIOD.
Name MMCA_SET_EXTENSION_PULSER_WIDTH
Description The function sets the pulser width for the parts of the extension port.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_EXTENSION_PULSER_PERIOD(unsigned short unPart, unsigned long ulWidth);
unPart
Part of the extension port.
ulWidth
Pulser width
Return value See MCA_COMM function
Remarks This function is only usable for MCA527. See CMD_SET_EXTENSION_PULSER_WIDTH.
28
Description of the MCA Communication DLL
Name MMCA_SET_EXTENSION_RS232
Description The function configures the RS232 interface of the extension port.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_EXTENSION_RS232(unsigned short unBaudrate, unsigned char uchFlags);
unBaudrate
Baud rate
uchFlags
Flags
Return value See MCA_COMM function
Remarks This function is only usable for MCA527. See CMD_SET_EXTENSION_RS232.
Name
MMCA_WRITE_TO_EXTENSION
Description The function writes a string to the RS232 interface of the extension port.
Declaration
ERROR_FLAG CALLBACK MMCA_WRITE_TO_EXTENSION(LPSTR lpszBuffer);
lpszBuffer
Pointer to a null-terminated string.
Return value See MCA_COMM function
Remarks This function is only usable for MCA527.
Name MMCA_READ_FROM_EXTENSION, MMCA_READ_FROM_EXTENSION_EX
Description The function reads a string from the RS232 interface of the extension port.
Declaration
ERROR_FLAG CALLBACK MMCA_READ_FROM_EXTENSION(LPSTR lpszBuffer, unsigned short unBufferSize);
ERROR_FLAG CALLBACK MMCA_READ_FROM_EXTENSION_EX(unsigned short unOption, LPSTR lpszBuffer, unsigned short unBufferSize);
unOption
0 = current data 1 = buffered data 2 = buffered data, unlock buffer 3 = buffered data, lock buffer
lpszBuffer
Pointer to a null-terminated string.
Return value See MCA_COMM function,
Remarks This function is only usable for MCA527. See CMD_QUERY_EXTENSION_RS232_RX.
Name MMCA_QUERY_EXTENSION_RS232_RX
Description The function reads bytes from the RS232 interface of the extension port.
Declaration
ERROR_FLAG CALLBACK MMCA_QUERY_EXTENSION_RS232_RX(unsigned short unOption, LPSTR rec_data);
unOption
0 = current data 1 = buffered data 2 = buffered data, unlock buffer 3 = buffered data, lock buffer
rec_data
Pointer to a QUERY_EXTENSION_RS232_RX structure. See CMD_QUERY_EXTENSION_RS232_RX or mca_comm.h.
Return value See MCA_COMM function,
Remarks This function is only usable for MCA527.
29
MCA527
Name MMCA_SET_EXTENSION_OUTPUT
Description The function sets the selected output of the extension port.
Declaration
ERROR_FLAG CALLBACK MMCA_SET_EXTENSION_OUTPUT(unsigned short unRelevantParts, unsigned short unPartB, unsigned short unPartD);
unRelevantParts
1 = part B (output2) 3 = part D (output1) 7 = part B (output2) and part D (output1)
unPartB unPartD
0 = off, ≠0 = on
Return value See MCA_COMM function,
Remarks This function is only usable for MCA527. See CMD_SET_EXTENSION_OUTPUT.
30
Description of the MCA Communication DLL

5 Managing the USB port

There are special functions for the USB port. The function COMM_INIT_ETHERNET returns information about the communication port to the argument init.unInterfaceId. This parameter shows whether the communication port is an USB port and whether the MCA batteries are rechargeable over the USB interface.
Name
GET_USB_CHARGER
Description The function gets information as to whether USB charging is switched on or off.
Declaration
VB_BOOL CALLBACK GET_USB_CHARGER();
Return value If nonzero, the USB charging is switched on.
Name SET_USB_CHARGER
Description The function switches USB charging on or off.
Declaration
void CALLBACK SET_USB_CHARGER(VB_BOOL bCharge);
bCharge
If nonzero, the USB charging will be switched on otherwise off.
Name
GET_USB_CHARGER_STATE
Description The function gets the USB charging state. The MCA batteries are recharged over USB if USB charging is
switched on and no external charger is plugged.
Declaration
VB_BOOL CALLBACK GET_USB_CHARGER();
Return value If nonzero, the MCA batteries are recharged over USB.
Name GET_CURRENT_LATENCY_TIMER
Description The function gets the latency time of the USB port.
Declaration
VB_BOOL CALLBACK GET_CURRENT_LATENCY_TIMER(LPDWORD lpdwTime);
lpdwTime
Pointer to the returned latency time.
Return value If the function succeeds, the return value is nonzero.
Name SET_CURRENT_LATENCY_TIMER
Description The function sets the latency time of the USB port. Changing the latency time can speed up the
communication.
Declaration
VB_BOOL CALLBACK SET_CURRENT_LATENCY_TIMER(DWORD dwTime);
dwTime
Latency time
Return value If the function succeeds, the return value is nonzero.
31
MCA527

6 MS-Windows DLL for the Communication with Several MCAs

There is a further dynamic link library (mca32cmx.dll) which allows applications to communicate with several MCAs simultaneously. In order to include the DLL in your program, you have to use the file MCA32CMX.BAS for Visual Basic or the files MCA_COMX.H and MCA32CMX.LIB for C/C++. All functions and structures are declared in these files.
The function names of mca32cmx.dll. are identical to the function names of mca32com.dll. However, not all functions are provided. The initialization functions COMM_INIT, COMM_INIT_EX, COMM_INIT_EX2, COMM_INIT_EX3, COMM_INIT_ETHERNET and COMM_INIT_ETHERNET_IP has been omitted. Use the function COMM_INIT_SELECT for initialization. The function works like the corresponding function within mca32com.dll, with one exception, there is an additional parameter.
short CALLBACK COMM_INIT_SELECT(unsigned short* lpunIndex, MCA_COMM_INIT* init, clock_t lTimeOut,int nTryAgain, HWND hWnd);
If the function succeeds, the additional parameter lpunIndex returns the index for the communication path that has to been passed to all other functions. The index is always the first parameter. All functions are defined corresponding to the following template.
return_type CALLBACK function_name(unsigned short unIndex[,parameters_equal_to_mca32com.dll]);
The functions IS_USB_PORT, SET_LATENCY_TIMER and SET_LATENCY_TIMER_EX has also been omitted. All omitted functions are no more needed. There are alternative functions for it. Mca32com.dll provides these functions only for compatibility reasons.
32
Loading...
