IndoorManagertm Owners Manual

FCC RF Exposure Statement

To satisfy RF exposure requirements, this device and its antenna must operate with a
separation distance of at least 20 centimeters from all persons and must not be co-located
or operating in conjunction with any other antenna or transmitter.

INSTRUCTION TO THE USER

This equipment has been tested and found to comply with the limits for a class B digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a typical installation. This
equipment generates, uses and can radiate radio frequency energy and if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:

• Reorient or relocate the receiving antenna on the device experiencing the

interference

• Increase the separation between the IndoorManager and the equipment

experiencing the interference.

• Connect the equipment into an outlet on a circuit different from that to which the

IndoorManager is connected

• Consult the dealer or experienced technician for the device experiencing the

interference

In order to maintain compliance with FCC regulations, no changes can be made to this
equipment without the approval of Gatekeeper Systems, Inc. The user is cautioned that
any changes or modifications made to the equipment without the approval of Gatekeeper
Systems, Inc. could void the user’s authority to operate this equipment.

Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.

This device has been designed to operate with the antennas listed below, and having a
maximum gain of 12 dBi. Antennas not included in this list or having a gain greater than
12 dBi are strictly prohibited for use with this device. The required antenna impedance is
50 ohms.

Approved Antenna List:

1. Cushcraft S2401240P12NF

2. Cushcraft S2408P12NF

3. Nearson S151AM-2450S

To reduce potential radio interference to other users, the antenna type and its gain should
be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than
that permitted for successful communication.

The Gatekeeper Systems IndoorManagertm (IM) is a general purpose transmitter used to
communicate with the Gatekeeper Systems SmartWheel

tm

family of wheels.

Installation and configuration of the IM should only be performed by qualified
Gatekeeper Systems personnel.

To power on the IM, open the cover and press the power switch down. See figure 1.

The status of the IM may be determined by the status LEDs located on the side of the IM.
See figure 2 and Table 1 for details.

Power Switch Location

Figure 1

Figure 2

Status LEDs

Status LED Summary

LED Meaning

Solid Green Unit is powered up (either by AC or from the internal battery)
Solid Yellow Unit is operating from internal battery – check AC power
Flashing Yellow Internal battery fault or disconnected – Contact Gatekeeper Systems
Flashing Red Unit is misconfigured – Contact Gatekeeper Systems
Solid Red Hardware fault – Contact Gatekeeper Systems

Table 1

Contacting Gatekeeper Systems

For more information about the Indoor Manager and troubleshooting, to order
parts or report an issue, contact the Gatekeeper Systems Inc. regional Customer
Support office nearest to your location.

USA

Gatekeeper Systems, Inc.
8 Studebaker
Irvine, CA 92618
[phone]

Canada

Gatekeeper Systems Canada, Ltd.
272 Galaxy Boulevard
Etobicoke, Ontario
Canada
M9W 5R8
[phone]

All Other Areas

Gatekeeper Systems SAS
58 rue de Neuilly
Parc des Guillaumes
93130 Noisy Le Sec
France
[phone]
