USER GUIDE
Last update on MARCH 19, 2019
www.gatee.eu
USER GUIDE
GATE Enterprise Sp. z o.o. Sp. K. does not take any responsibility for damages,
injuries and accidents resulting in the use of this product or the use of Air Electric
Gun with the product installed.
Notice
Information contained in this document is subject to updating without notice.
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE INSTALLING THE DEVICE
Safety Summary
THE DEVICE COVER MUST NOT BE REMOVED BY THE USER
DANGER!
Caution must be exercised to prevent short circuiting the battery as the
consequences can be very dangerous.
FOR YOUR SAFETY
We recommend that this product should be installed by an experienced airsoft
service.
02
WWW.GATEE.EU
USER GUIDE
WARNING: Before starting installation process, please ensure that your AEG is
empty and there are no BBs inside.
NOTE:
Please check if you have downloaded the latest manual from the Technical Support
section of our website: www.gatee.eu. The Product Warranty Form is also available
there.
In case you have any difficulties while installing or using this product, we
recommend to email us at support@gatee.eu.
WWW.GATEE.EU
PRODUCT DISPOSAL INSTRUCTIONS
The symbol shown here means that the product is classed as Electrical or Electronic Equipment
and should not be disposed with other household and commercial waste at the end of its
working life. The Waste of Electrical and Electronic Equipment (WEEE Directive 2012/19/UE)
has been put in place to recycle products using best available recovery and recycling
techniques to minimize the impact on the environment. Purchasers shall take any old electrical
equipment to waste recycling public centers or points of sale.
CERTIFICATE OF CONFORMITY
GATE Enterprise Sp. z o.o. Sp. K. hereby declares under our sole responsibility that the product
GATE X-ASR is in conformity with the essential requirements of the following Directives:
EC DIRECTIVE 2011/65/EU
This product has been certified as RoHS Compliant.
03
Table of Contents:
USER GUIDE
Safety Summary .......................................................................................................
Table of Contents ......................................................................................................
01. Overview .............................................................................................................
• Key Functions ......................................................................................................
• Scheme............... ................................................................................................
02. Installation ...........................................................................................................
• AEG standard installation diagram ......................................................................
• Installation of X-ASR without replacement of wires............................................
03. Troubleshooting....................................... ...........................................................
04. GATE Limited Warranty Policy ...........................................................................
2
4
5
5
6
7
7
7
8
9
04
WWW.GATEE.EU
USER GUIDE
01. Overview
We introduce the world’s first 4th generation mosfet. X-ASR is a highly reliable AEG
controller. It has automatic resettable protection against battery reverse polarity,
SMART FUSE and built-in self-test. It does not require additional fuse in AEG
installation.
Key Functions
MOSFET
Do you want to achieve higher rate of fire and faster trigger
response? Are you planning power upgrade of your rifle? In that case,
you need a MOSFET.
It targets the energy from the battery directly to the motor,
bypassing the mechanical trigger contacts. As a result, you gain a
higher rate of fire of the rifle and faster trigger response, and the
contacts are protected against burn out.
Debouncing (Digital Interface)
This provides full compatibility with the micro-switches. It is fully
resistant to contact bounce. You gain a bigger ROF, a faster trigger
response and your MOSFET is less prone to heating.
WWW.GATEE.EU
Built-In Self-Test
It allows you to quickly check whether the AEG controller works
properly. If you have problems with your AEG, the BUILT-IN SELF-TEST
allows you to check that the problem is not caused by the controller.
05
USER GUIDE
Coating
Thanks to its special conformal coating, it is resistant to atmospheric
conditions (Military Specification MIL-V-173C).
Scheme
Battery
connector
LED
indicators
Trigger wire TERMINAL
Motor NEGATIVE TERMINAL (-)
Motor POSITIVE TERMINAL (+)
For installation you will need:
3 pcs. of 2.8x0.5mm female terminals
3 pcs. of 3.2x18mm [0.126x0.71 inch] heat-shrink tubes
1 pc. of 445mm [17.52 inch] of 16 - 22 AWG wire
06
AEG
Connectors
WWW.GATEE.EU
02. Installation
USER GUIDE
BATTERY
UP TO 12.8V
C
A B
CONTACTS
AEG Motor
Fig 1. Standard AEG wiring scheme
To adapt the standard AEG installation to work with X-ASR it is necessary to get to
the trigger contacts. In case of GB v2 contacts are located inside a gearbox. With a
version 3 gearbox, the installation will be easier because the contacts are outside of
the gearbox. Please consult a local airsoft technician if you have never
disassembled a gearbox before or if you have any installation concerns.
a) Installation of X-ASR without replacement of wires. Using this method, the
original wiring is kept intact, and the connections are modified. Referencing
Fig 1., de-solder A wire from the one of the trigger contacts and then solder it to the
B wire. It does not matter which wire you disconnect from the trigger switches, just
join the two wires together at one terminal. In the place of the A wire, solder the
additional single signal wire. The trigger wire can be very thin because it handles
very low current and it is only used for switch-detection.
BATTERY
UP TO 12.8V
WWW.GATEE.EU
AEG Motor
1.
CONTACTS
07
USER GUIDE
03. built-in self-test
Overload - temperature too high,
X-ASR is designed up to M120 spring
08
WWW.GATEE.EU
USER GUIDE
06. GATE Limited Warranty Policy
GATE Enterprise Sp. z o.o. Sp. K. warrants that its Product is free from
manufacturing and material defects at the date of purchase and for a period of two
(2) year from the date of purchase and it is not-extendable. This Limited Warranty is
conditioned upon proper use of Product by Purchaser.
1. This Limited Warranty is valid provided that the owner provides a proof of
purchase and properly completed warranty form.
2. This Limited Warranty does not cover: (a) defects or damage (eg. mechanical,
thermal or chemical) resulting from accident, misuse (misinterpretation of the
instructions), abuse, neglect, unusual physical, electrical or electromechanical
stress, water immersion, repairs or structural modification of any part of Product
(eg. heat-shrink tube removal), or (b) the Product that has the serial number
removed or made illegible; (c) defects or damage from improper operation,
maintenance or installation, (d) installation of the products.
3. Requests for warranty are processed as soon as possible, not exceeding seven
(7) working days. The company's obligation under this Limited Warranty shall be
limited to providing replacement of part/s only.
Contact: support@gatee.eu
