TROUBLESHOOTING
MALFUNCTION POSSIBLE REASON
Ţ PLUG&PLAY INSTALLATION Ţ
WHAT TO DO
After connecting the battery to the
Controller, the LED indicator does
not light on. WARFET does not
react.
After a trigger action, the LED
indicator blinks red. Even though
the motor is connected, the AEG
does not fire.
After a trigger action, the LED
indicator blinks green shortly. Even
though the motor is connected, the
AEG does not fire.
After a trigger action, the LED
indicator glows red. Even though
the motor is connected, the AEG
does not fire.
The WARFET does not react to
any trigger action. The AEG does
not fire.
The battery is discharged.
No contact with the battery.
A permanent damage to the
Controller.
A weak contact with the contact
cube.
A weak contact with the motor
connectors.
The motor wires are damaged.
The motor windings are damaged.
The battery is discharged.
The BATTERY PROTECTION
function is badly programmed.
No contact with the battery.
A short-circuit between the signal
wires and the motor wires (in
Hardwired Installation only).
A short-circuit of the motor wires.
A short-circuit of the motor.
The battery is discharged.
No contact in the switch assembly.
No contact with the motor
connectors.
The motor wires are broken.
The motor windings are broken.
Charge the battery.
Clean the battery connector.
Clean the Controller connector.
Contact GATE Technical Support:
support@gatee.eu
Clean the contact cube or replace
it with a new one.
Clean the motor connector in the
Controller.
Check the motor connectors.
Check and repair the motor wires.
Repair the motor or replace it with
a new one.
Charge the battery.
Program the BATTERY
PROTECTION function correctly.
Clean the battery connector.
Clean the WARFET connector.
Check and repair the signal wires
insulation and the motor wires
insulation.
Connect another motor.
Charge the battery.
Clean the switch assembly.
Clean the motor connector in the
Controller.
Check the motor connectors.
Repair the wires.
Repair the motor or replace it with
a new one.
-20-
