SINGLE & TWIN WOK COOKER
Model No. CS2112 / CS2123
High performance dual ring brass burner
which is ideal for high speed cooking
Integrated piezo ignition
Easy to clean stainless steel body
Heavy duty removable enamel coated trivets
Cast iron and brass burners
Hose and regulator included
Propane / ULPG use only
Gas certified to Australian Standards
For outdoor use only
CS2112
CS2123
NOTE: ONLY USE ON A NON-COMBUSTIBLE SURFACE
Gasmate® is a registered trademark of
Sitro Group Australia Pty Ltd www.gasmate.com.au
Aber Living, N.Z www.gasmate.co.nz
04071 01/20
Important: Retain these instructions for future use
GENERAL WARNINGS
WARNING
• Read these instructions for use carefully.
Familiarise yourself with the appliance
before connecting it to its gas container.
Keep these instructions for future reference.
• This appliance shall only be connected to a
Propane/ULP gas cylinder with a POL/QCC
cylinder valve certified to AS2469 standards.
• It maybe hazardous to attempt to fit other
types of gas containers or cartridges.
• This appliance shall only be used with the Hose
and Regulator Assembly supplied, Regulator
is set to 2.75 kPa and is not adjustable – Do Not
Modify.
• This appliance is designed for outdoor use
only and must be operated away from any
flammable material or surfaces and materials.
• This appliance is to be stored in a dry and well ventilated location free from direct sunlight.
• Do not store when appliance is still connected
to the cylinder.
• Make sure that the cylinder is disconnected
and is stored in a well-ventilated area, free from
direct sunlight, heat and ignition sources.
• If being stored indoors, ensure that the location
complies with the standard AS/NZS1596.
• This appliance must only be serviced by an
authorised service agent, contact SITRO Group
for assistance with repairs and spare parts.
DANGER
• During operation all surfaces will be extremely
hot and should not be touched or handled.
• Do not use the appliance if it is leaking,
damaged or does not operate properly.
• This appliance must only be serviced by an
authorized person.
• Handle with care even after brief use, always
pick up using the body not the cylinder.
• It may be hazardous to attempt to fit other
types of gas containers or cartridges.
• Use only in well ventilated areas.
• Always operate appliance a minimum of
500mm from flammable materials, walls and
1200mm from the ceiling.
• Do not modify appliance to fit other connectors
or cylinders.
• Only use the hose assembly as supplied with
this appliance for connection to the cylinder
– DO NOT USE ADAPTORS.
• Avoid twisting or kinking the flexible hose
• Do not modify this appliance
• Do not use multiple appliances to heat a
single utensil.
• Children must be supervised by an adult at
all times.
• Never leave appliance unattended when
operating.
• Use as a cooking appliance only, not to be
used as heater or modified for any other
reason.
• Avoid boil over and spills on to burners.
CARBON MONOXIDE HAZARD
Using this appliance in an enclosed space may
cause DEATH. Do not use in caravans, tents,
marine craft, cars, mobile homes or similar
locations.
ONLY USE IN WELL VENTILATED AREAS
2
IMPORTANT
• Use outdoors only.
• Keep children away at all times.
• CAUTION: Accessible parts may be very hot.
Please take care when handling or moving the
appliance.
• Appliance is to be used on a stable, level, flat,
non-flammable surface. The appliance should
be protected from direct drafts and in a well
ventilated place.
• Only cooking vessels with a minimum diameter
of 200mm and a maximum of 300mm are
to be used with this appliance.
• This appliance shall only be used in an above
ground open air situation with natural
ventilation, without stagnant areas, where
gas leakage and products of combustion
are rapidly dispersed by wind and natural
convection.
• Take care that the primary air intakes, located
on the burner tube of this appliance are not
obstructed, or that air flow is restricted by
placing items or other appliances close to or
adjacent to the inlets.
• If there is a leak on your appliance (smell of
gas), immediately attempt to turn off the
cylinder valve. Remove the appliance to a well ventilated location away from any ignition
source. Check for leaks using soapy water. Do
not try to detect leaks using a flame.
• Do not attempt to move or relocate the
appliance when it is operating, extinguish
the burner and allow to cool, disengage the
gas cylinder then move the appliance.
CHECKING FOR GAS LEAKS
• Check that all connections are tight and that
the gas cylinder connection has been tightened
before you turn the cylinder gas valve on.
• NEVER check for leaks with a flame or pilot
light.
• Using Gas Leak Detection Spray or soapy
water, coat all connections, if bubbles appear
turn the cylinder gas control off and retighten
the connection before re-testing.
• Inspect the appliance regularly for signs of
wear, leaks or incorrect operation.
If symptoms such as flaring of the burner, issues
with lighting, damages to hoses or connections
or leaks from seals or gas controls are identified
do not attempt to repair, return to your authorised
stockist for service and maintenance.
CHANGING GAS CYLINDER
• To check if gas remains in the cylinder,
disconnect from the appliance and hold the
cylinder in a vertical position then shake from
side to side, if there is a sound or feel of liquid
movement inside, the cylinder contains gas.
• When changing gas cylinders ensure this is
conducted outside in a well- ventilated location
free from people, animals and ignition sources
such as naked flames, pilot lights and electrical
equipment with heaters or elements.
3
GENERAL INFORMATION
GAS INSTALLATION CODES
• Appliance must be used in accordance with
the installation requirements of your gas supply
authority, or the appropriate installation code issued
by Standards Australia AS 5601.
• Appliances for use with bottled gas are labelled
‘propane gas’.
• Only use on a non-combustible surface.
CLEARANCES
Minimum Clearances from combustible materials
must be: Cylinder - 500mm
Wall - 500mm
Above - 1200mm
Below - never use on a flammable surface.
Only use on a non-combustible surface.
Gas connection is 3/8” SAE
HOSE & REGULATOR SAFETY
The regulator and hose assembly supplied with the
appliance are suitable for propane gas only.
The pressure regulator and hose assembly supplied
with the appliance must be used. Replacement
pressure regulators and hose assemblies must be
those specified by the appliance manufacturer.
Only use the hose assembly supplied with this
appliance for direct connection to the cylinder
“DO NOT USE ADAPTORS”. Check the regulator
“O” Ring periodically for wear or damage and
replace if required.
When connecting the hose and regulator assembly
to the gas cylinder, take care to avoid unnecessary
twisting or kinking of the flexible hose. Maximum hose
length is 1 metre.
After the assembly has been secured, turn on the gas
and check for leaks by brushing a soap and water
solution overall connections.
DO NOT USE this appliance if it is leaking, damaged
or does not operate properly.
If you are unable to correct the leak by tightening the
connections, turn off the gas and contact the supplier
immediately.
Always ensure the appliance is kept away from
flammable materials and the gas cylinder clear of
any heat source. When changing over from an empty
gas cylinder to a full one make sure this procedure
is carried out in a well ventilated location, preferably
outside, away from people and away from any sources
of ignition; such as naked flames, pilot flames, electric
heaters/equipment.
SPECIFICATIONS
Appliance specifications can be found on the data label
attached to the appliance body.
GAS CYLINDER USE & SAFETY
This is a low pressure appliance and must only be used
with the hose and regulator supplied. This appliance
shall only be used with propane gas cylinders certified
to AS 2469. It may be hazardous to attempt to fit other
types of gas containers.
The gas cylinder should be filled by a reputable gas
supplier and visually inspected and re-qualified at
each filling.
Always keep cylinder in an upright position. Always
close the cylinder valve when the appliance is not
in use.
Do not subject gas cylinder to excessive heat.
GAS INSTALLATION CODES
• Appliance must be used in accordance with
the installation requirements of your gas supply
authority, or the appropriate installation code issued
by Standards Australia AS 5601.
• Appliances for use with bottled gas are labelled
‘propane/ULPG gas’.
• Only use on a non-combustible surface.
NEVER STORE YOUR GAS
CYLINDER INDOORS
If you store your appliance indoors, ALWAYS
disconnect the gas cylinder first and store the cylinder
safely outside. Cylinders must be stored outdoors in
a well ventilated area out of reach of children, and
must not be stored in a building, garage or any other
enclosed area.
LOCATION OF YOUR APPLIANCE
Only use on a non-combustible surface. DO NOT
use your appliance in garages, porches, sheds,
breezeways, or other enclosed areas. Your appliance
is to be used OUTDOORS ONLY. The appliance is not
intended to be installed in or on recreational vehicles
and/or boats and should not be placed on any surface
that will burn. Do not obstruct the flow of combustion
and ventilation air around the appliance.
4
PROTECT CHILDREN
Keep children away from appliance during use and
until appliance has cooled after you have finished. Do
not allow children to operate appliance.
Always ensure that no sporting or physical activities
are carried out in close proximity to the appliance
during use and while still hot.
PRODUCT DETAILS
CS2112
Single Burner
Wok Cooker
Gas Type
Propane / ULPG
CS2123
Twin Burner
Wok Cooker
TOOLS YOU WILL NEED
Adjustable spanner, phillips screwdriver.
CHECK APPLIANCE FOR ANY DAMAGE
Inspect appliance parts as you proceed. Contact
your supplier for assistance regarding replacement of
any damaged or missing parts. Do not assemble or
operate a appliance that appears damaged. Appliance
for use with gas cylinders are labelled ‘propane/ULPG
gas’. Check labelling at the gas connection on your
appliance.
For any queries or assistance call
Customer Service
Australia Only
1300 174 876
Hours of operation: Monday to Friday 8.00am - 5.00pm EST
Email: sales@sitro.com.au
Injector Size
Gas
Consumption
Gas Pressure
Gas Inlet
Certificate
0.63 /1.03mm
18.8MJ/h
374g/h
2.75kPa
3/8”SAE
AGA Approval No. 8872G
37.6MJ/h
748g/h
Do not return to place of purchase.
Keep your purchase receipt, this will be required to make any claims under the 12 month warranty.
New Zealand Only
For warranty details visit
www.gasmate.co.nz
For warranty claims return to place of purchase. Your purchase receipt will be required for warranty claims.
5
GENERAL ASSEMBLY
CONNECTING & DISCONNECTING
TO GAS SOURCE
Familiarise yourself with the general information and
safety guidelines located at the front of this manual.
Note: Remove any transit protection material.
ASSEMBLY & CONNECTION
Review the contents of the package. Make sure all
listed components are included.
1. Check that the Burner Caps, Drip Tray & Trivet are in
correct locations (Pic. 1).
2. Attach the LP Gas hose to the cooker using a
spanner – Do Not Over Tighten (Pic. 2).
3. Check that the cylinder is filled, a sloshing sound will
be heard when shaken.
4. Connect the Regulator to the cylinder valve and
tighten (Pic. 3).
5. Check for any damage to either the cylinder
connection or the hose. NEVER attempt to
use damaged equipment.
6. Turn the gas cylinder valve on and spray gas leak
detection spray or soapy water on all connections to
check for leaks. If a leak is detected turn the valve
off, retighten all connections and retest.
LIGHTING THE COOKER
1. Turn the gas cylinder valve on, in an anti-clockwise
direction for one full turn (Pic. 4).
2. Turn the Gas Control in the Anti-Clockwise Direction
till you hear the Piezo “click” and a Ignition Flame
will ignite the Burner (Pic. 5).
3. If the burner does not ignite, turn the gas control
in the clockwise direction to the “OFF” position and
allow the residual gas to disperse before attempting
to reignite the burner (Pic. 6).
PIC. 1
PIC. 2
PIC. 3
IMPORTANT
• Do not smoke when attempting to ignite appliance.
• Always use protective gloves when handling
hot components.
• Do not smoke at any time when attempting to
ignite the appliance burners.
Caution: Do not move the appliance while in operation.
• Do not leave the appliance unattended when alight.
Before connecting and disconnecting appliance to
gas source, make sure burner controls are in ‘OFF’
position.
PIC. 4
6
TURNING THE APPLIANCE OFF
If the appliance is no longer to be used and to reduce
the risk of blocked gas jets caused by excess gas being
left in the hose, all remaining gas must be expelled from
the hose assembly.
1. With the flame still operating, turn the valve on the
gas cylinder in the clockwise direction until it is off.
Allow the flame to burn down then extinguish once all
remaining gas in the hose has been used (Pic. 7).
2. Turn the gas controls on the appliance clockwise to
the “OFF” position (Pic. 8).
CARE INSTRUCTIONS
As with all appliances, proper care and maintenance will
keep them in top operating condition and prolong their
life. By following these cleaning procedures on a timely
basis, your appliance will be kept clean and working
properly with minimum effort
Using warm soapy water with a mild detergent wipe
down all surfaces and areas of the appliance, taking
care not to allow water to enter the burner outlets or
aeration holes located in the burner tube.
DO NOT submerge the appliance in a sink or bowl.
DO NOT use abrasive cleaners or bleach.
MAINTENANCE & SERVICE
During operation if it is noted that the burner flame is
unstable, is changing colour from blue to yellow or has
a distinct smell it is important that you contact customer
service for your local authorised gas appliance repairer
for inspection. Periodically check the gas control is tight
and has no leaks, follow the testing for leaks procedure.
Check the gas connection and regulator for any signs of
wear or damage, if identified contact customer service
for a replacement assembly immediately.
PIC. 5
PIC. 6
OFF
PIC. 7
IMPORTANT
Caution: When the appliance is not in use, the gas
must be turned off at the cylinder.
Check that the seals between the appliance and
the gas cylinder are in place and in good condition
before connecting the gas cylinder.
Do not use this appliance if it has damaged or
worn seals.
• Beware of spiders and wasps. Burner tube
should be inspected and cleaned periodically.
• This appliance must only be serviced by an
authorised person.
NOTE: ONLY USE ON A NON-COMBUSTIBLE SURFACE
PIC. 8
7
SAFETY INSTRUCTIONS
This appliance shall only be used in an above ground
open air situation with natural ventilation without
stagnant areas where gas leakage is rapidly dispersed
by wind and natural convection.
Any enclosure in which appliance is used should comply
with one of the following:
A. An enclosure with walls on all sides, but with no
overhead cover.
B. Within a partial enclosure that includes an
overhead cover and no more than two walls.
C. Within a partial enclosure that includes an overhead
cover and more than two walls, the following must
apply:
1. At least 25% of the total wall area is completely
open.
2. 30% or more in total of the remaining wall
side, back and front wall areas is open and
unrestricted.
3. In the case of balconies, 20% or more of the total
wall area must remain open and unrestricted.
1
The figures shown are diagrammatic representations
of outdoor areas. Rectangular areas have been used in
these figures - the same principles apply to any other
shaped areas.
1
2
1
2
Loading...
